Owner’s Manual
Roav SmartCharge Halo
Important Safety
Instructions
SAVE THESE INSTRUCTIONS – This manual contains important safety
and operating instructions for the car charger (Model R5122).
Please read and understand all instructions before using this product.
If damage is caused by failure to follow the instructions, the warranty
does not apply.
• Read all instructions and cautionary markings before using this product.
• Do not expose to rain, moisture, or snow.
• Use of an attachment is not recommended or sold by the manufacturer
may result in a risk of fire, electric shock, or injury to persons.
• Do not operate this car charger if it has received a sharp blow, been
dropped, or otherwise damaged in any way; take it to a qualified
service person.
• Do not disassemble this car charger; take it to a qualified service
person when service or repair is required. Incorrect reassembly may
result in a risk of electric shock or fire.
• To reduce risk of electric shock, unplug this car charger before
attempting any maintenance or cleaning. Turning o controls will not
reduce this risk.
• To reduce risk of fire or electric shock, do not interconnect output
terminations.
• Avoid long exposure to direct sunlight, which may cause damage to
the device.
• Exposing this product to open flames may cause it to explode.
• Do not use this product in strong magnetic fields.
• Use a dry, soft, lint-free cloth to clean. Do not use any corrosive
cleaner or oil to clean.
• CAUTION - For continued protection against fire risk, replace only with
the same type and ratings of fuse. The fuse rating is 63V DC / 7A.
• Always obey trac laws and pay attention to the road. Do not attempt
to use this device while driving, as some features are limited while the
vehicle is in motion. Failure to pay full attention to the operation of
your vehicle could result in death, serious injury or property damage.
You assume total responsibility and risk for using this device.
Consignes de sécurité
importantes
CONSERVEZ CES CONSIGNES - Ce manuel contient d'importantes
instructions de sécurité et d'utilisation relatives au chargeur de voiture
modèle R5122.
Veuillez lire et comprendre toutes les instructions avant d'utiliser ce
produit. Si le non-respect des instructions entraîne des dommages, la
garantie ne s'appliquera pas.
• Lisez toutes les instructions et les mises en garde avant d'utiliser ce
produit.
• Ne pas exposer à la pluie, l'humidité ou la neige.
• L'utilisation d'un accessoire non recommandé ou vendu par le
fabricant peut entraîner un risque d'incendie, de choc électrique ou
de blessure.
• Ne pas utiliser ce chargeur de voiture s'il a reçu un coup violent, s'il
est tombé ou s'il a été endommagé de quelque façon que ce soit ;
l’apporter à un technicien qualifié.
• Ne pas démonter ce chargeur de voiture ; l’apporter à un technicien
qualifié lorsqu’une réparation est nécessaire. Un réassemblage
incorrect peut entraîner un risque d'électrocution ou d'incendie.
• Pour réduire les risques d'électrocution, débrancher le chargeur de
voiture avant d'eectuer toute opération d'entretien ou de nettoyage.
La désactivation des commandes ne réduit pas ce risque.
• Pour réduire les risques d'incendie ou d'électrocution, ne pas
interconnecter les terminaisons de sortie.
• Éviter toute exposition prolongée à la lumière directe du soleil, qui
pourrait endommager l'appareil.
• L'exposition de ce produit à des flammes nues peut provoquer son
explosion.
• Ne pas utiliser ce produit dans des champs magnétiques puissants.
• Utiliser un chion sec, doux et non pelucheux pour le nettoyage. Ne
pas utiliser de nettoyant corrosif ni d'huile.
• ATTENTION - Pour une protection continue contre les risques
d'incendie, ne remplacer le fusible que par un fusible de même type et
de même spécification. Le fusible utilisé est de 63V DC / 7A.
① Keep these instructions.
② Do not drop, puncture or disassemble this product.
③ This product shall not be exposed to dripping or splashing liquids.
④ Avoid long exposure to direct sunlight, which may cause damage to
this product.
⑤ Exposing this product to open flames may cause explosion.
⑥ Do not use this product in strong magnetic fields.
⑦ Use a clean, soft cloth to clean. Do not use any corrosive cleaner/oil
to clean.
Introduction
Features
• Anker PowerIQ charging technology
• Quick Charge 3.0 charging technology
• Companion Roav Charger app with car battery monitor and car
locator.
• LED indicatorring with colors customizable via the Roav Charger app.
What’s Included
Owner’s Manual
At a Glance
USB charging port (PowerIQ)
USB charging port (Quick Charge 3.0)
LED indicator ring
Adapter
Getting Started
Download the Roav Charger app from the App Store (iOS devices)
or Google Play (Android devices).
ROAV Halo
Plug Roav SmartCharge Halo into your vehicle’s cigarette lighter
socket. Start the engine and Roav SmartCharge Halo will
automatically power on.
Model: R5122
51005001098 V01
LED Indicator Ring Status
Status LED Indicator Ring
Power on Turns blue
Waiting Bluetooth connect Flashes slowly for 90 seconds
Bluetooth connected Steady blue (by default)
Bluetooth not connected Steady red (by default)
Power o O
Note: Users can customize colors for connection status on the Roav
Charger app.
Users can also turn o the LED indicator ring via Roav Charger app.
Open the Roav Charger app and follow the instructions to connect the
device via Bluetooth. Enable Bluetooth on your smartphone and search
for available Bluetooth devices. Select “Roav Halo_XXX” and connect.
Once connected, the LED indicator ring will turn blue by default.
Roav
Halo
_XXX
Now you can locate your car, set a parking timer, check your
vehicle’s car battery, customize the colors of the LED indicator ring,
and find out more via the Roav Charger app.
Charge Your
Devices
Roav SmartCharge Halo has three USB charging ports.
You can charge three devices at the same time with a
maximum output power of 30W.
Specifications
Spec
Specifications are subject to change without notice.
DC input: 12V-24V
Power IQ output: 5V 2.4A
Quick Charge 3.0 output: 3.6V-6.5V 3A, 6.5V-9V 2A, 9V-12V 1.5A
Total wattage: 30W
Bluetooth: V4.1
Operating temperature range: -20°C to 40°C / -4°F to 104°F
Storage temperature range: -40°C to 85°C / -40°F to 185°F
Notice
FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Warning: Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the
equipment.
Note: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment o and
on, the user is encouraged to try to correct the interference by one or
more of the following measures: (1) Reorient or relocate the receiving
antenna. (2) Increase the separation between the equipment and
receiver. (3) Connect the equipment into an outlet on a circuit dierent
from that to which the receiver is connected. (4) Consult the dealer or
an experienced radio/TV technician for help.
FCC Radio Frequency Exposure Statement
The device has been evaluated to meet general RF exposure
requirements. The device can be used in fixed/mobile exposure
condition. The min separation distance is 20cm.
Qualcomm Quick Charge is a product of Qualcomm Technologies, Inc.
Qualcomm and Quick Charge are trademarks of Qualcomm
Incorporated, registered in the United States and other countries. All
Qualcomm Incorporated trademarks are used with permission.
Apple and the Apple logo are trademarks of Apple Inc., registered in
the U.S. and other countries. App Store is a service mark of Apple Inc.,
registered in the U.S. and other countries.
Google Play and the Google Play logo are trademarks of Google Inc.
Customer
Service
18-month limited warranty
Lifetime technical support
support@goroav.com
+1(800) 988 7973 (US) Mon-Fri 9:00-17:00 (PT)
@GoRoav @GoRoav
© Anker Innovations Limited All rights reserved. ROAV and the ROAV
logo are trademarks of Anker Innovations Limited registered in the
United States and other countries. All other trademarks are the property
of their respective owners.
