Anker Innovations T8300M eufy Security SpaceView (monitor with FHSS) User Manual
Anker Innovations Limited eufy Security SpaceView (monitor with FHSS) Users Manual
Users Manual
User Manual
eufy Security SpaceView
Baby Monitor
Anker Innovations Limited. All rights reserved. Eufy and
the Eufy logo are trademarks of Anker Innovations Limited,
registered in the United States and other countries. All other
trademarks are the property of their respective owners.
51005001157 V01
FCCID: 2AOKB-T8300M
Tabel of Content
What’s in the Box 01
Feature Introduction 02
Setting Up the Camera and Monitor 03
Monitor Installation 03
Replacing the Camera lens 06
Safety 07
Customer service 10
01 02
What’s in the Box
Baby Camera
(T8300-M)
Baby Monitor
(T8300-C)
Camera Adapter
(5V 2A)
Monitor Adapter
(5V 2A)
Camera Stand
Wide-Angle Lens
Monitor Micro-USB
Power Cable (1.5 m)
Camera Micro-USB
Power Cable (3 m)
Screw Kit
User manual
Feature Introduction
Monitor Features:
6
5
7
9
10
1211
8
13
2
134
1Volume controls 8microSD card slot
2Screen 9Support stand
3Power button 10
Micro USB charging port
4Menu button 11 LED indicator
5Navigation buttons 12 Microphone
6
Return to previous level
of menu / Talk button
13 Speaker
7Monitor Antenna
Press and hold the Talk button to speak to the camera.
When Menu is opened, press Talk button once to return
to previous level of menu. Press Power button to switch
on / off the monitor screen. Press and hold the Power
button for 2 seconds to switch on / off the monitor.
Power adapter varies by region.
03 04
Camera Features:
2
1
3
4
5
6
1Standard camera lens 4Speaker
2Microphone 5Micro USB port
3Power LED Status indicator 6Pairing button
Setting Up the Camera and Monitor
Monitor Installation
Fully charge the monitor before use. To charge:
Connect the baby monitor to the monitor adapter with the
Micro USB cable, and then connect the adapter to a power
outlet. Connect the other end of the baby monitor’s Micro
USB power cable to the Micro USB port in the monitor to
charge it. Press and hold the power button for 2 seconds to
turn the baby monitor on.
Camera Installation
Connect the baby camera’s Micro USB power cable to the
camera adapter (5V 2A), and then connect the adapter to
a power outlet. Finally, connect the other end of the baby
camera’s micro USB power cable to the micro USB port in the
camera.
Camera Placement (on the Wall Mount)
1. Use the monitor to test the viewing angle from
your desired mounting spot.
2. Mark the screw holes with a pencil.
3. Drill 1/5” holes into the wall and then insert the
anchors into the holes.
4. Insert the screws through the mounting holes of
the base and screw into the anchors.
5. Place the camera on the base.
05 06
On-screen Menu Icons
Icon Icon Description
Wireless signal strength
Night Vision Mode is enabled
1
Shows the camera that is currently
presenting on the baby monitor screen
Cycle Cameras enabled
Temperature Alert enabled / Sound Alert
enabled
27°C Ambient temperature of the room the
camera is in
Sound level of the room the camera is in
17: 30 Current time
Current battery level of the baby monitor
Replacing the Camera lens
Lens type Usage Demonstration
Standard camera
lens (default lens)
This lens is
recommended for
general viewing;
infants are clearly
seen within a 2~3m
range.
The lens angle of
view for standard
camera lens is 62°.
Wide-angle lens This lens provides a
wide-angle view of
the room. The lens
angle of view for
wide-angle lens is
110°.
Front
Back
The standard camera lens is not removable. When you want
to use the wide-angle lens, simply place it over the standard
camera lens and fasten.
07 08
Safety
Warning
Strangulation Hazard: Children have STRANGLED in cords.
Keep this cord out of the reach of children (more than 1m (3ft)
away). Never use extension cords with AC Adapters. Only use
the AC Adapters provided.
This device in compliance with the essential
requirements and other relevant provisions of Directive
2014/53/EU. All essential radio test suites have been carried
out.
This product can be used across EU member states.
The product shall only be connected to a USB Interface of
version 2.0 or higher.
1. The adapter shall be installed near the equipment and shall
be easily accessible.
2. Do not use the product in the environment at too high or too
low temperature,
never expose the mobile phone under strong sunshine or too
wet environment.
The suitable temperature for the product and accessories
is -20°C-60°C.
When charging, please place the product in an environment
that has a normal room
temperature and good ventilation. It is recommended to
charge the product in an environment
with a temperature that ranges from -10°C~45°C. Please
ensure to use only the charger offered by the manufacturer.
Using unauthorized charger may cause danger and violate the
authorization of the phone and the guarantee article.
3. CAUTION RISK OF EXPLOSION IF BATTERY IS REPLACED
BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES
ACCORDING TO THE INSTRUCTIONS
4. RF exposure information: The Maximum Permissible
Exposure (MPE) level has been calculated based on a distance
of d=20 cm between the device and the human body. To
maintain compliance with RF exposure requirement, use
product that maintain a 20cm distance between the device
and human body.
6. Operating Frequency Range: 2410-2477MHz
7. The charger output voltage/current is 5Vdc/2A. The plug
considered as disconnect device of adapter.
8. If you use a third-party charger, the recommended output
voltage/current of the adaptor is 5Vdc/2A,and the adapter
shall be CE approval type.
9. The following importer is the responsible party (contact for
EU matters only)
Importer:Anker Technology (UK) Ltd
Importer Address:Suite B, Fairgate House, 205 Kings Road,
Tyseley, Birmingham,United Kingdom B11 2AA
09 10
This product is designed and manufactured with high
quality materials and components, which can be recycled and
reused.
This symbol means the product must not be discarded
as household waste, and should be delivered to an appropriate
collection facility for recycling. Proper disposal and recycling
helps protect natural resources, human health and the
environment. For more information on disposal and recycling
of this product, contact your local municipality, disposal
service, or the shop where you bought this product.
FCC Statement
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) this device may
not cause harmful interference, and (2) this device must accept
any interference received, including interference that may
cause undesired operation.
Warning: Changes or modifications not expressly approved
by the party responsible for compliance could void the user's
authority to operate the equipment.
Note: Th
is equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a
residential installation.
This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
(1) Reorient or relocate the receiving antenna. (2) Increase the
separation between the equipment and receiver. (3) Connect
the equipment into an outlet on a circuit different from that to
which the receiver is connected. (4) Consult the dealer or an
experienced radio/TV technician for help.
.
The following importer is the responsible party (contact for
FCC matters only)
Company Name: POWER MOBILE LIFE, LLC
Address: 400 108th Ave NE Ste 400, Bellevue, WA 98004-5541
Telephone:(206)383-8247
11 12
Customer service
• Warranty
12-month limited warranty
• Call Us
United States +1 (800) 988 7973 Mon-Fri 9AM-5PM (PT)
United Kingdom +44 (0) 1604 936 200
Mon-Fri 6AM-11AM (GMT)
Germany +49 (0) 69 9579 7960 Mon-Fri 6:00-11:00
• Email Us
Customer Support: support@eufylife.com
FCC Radio Frequency Exposure Statement
The T3800-C device has been evaluated to meet general RF
exposure requirements. The T3800-C can be used in fixed
exposure condition. The min separation distance is 20cm.
This T3800-M was tested for typical body‐worn operations with
the back of the handset kept 0 mm from the body.
RF Exposure Information(SAR)
The Extremity SAR limit of FCC for Hand held is 4.0W/kg.
Device is recommended to use in hand held only and SAR when
hand held is 1.804W/kg
Worn on body will have unexpected RF exposure RISK.
