Anker Technology 98ANWVM-UBA Anker Wireless Vertical Mouse User Manual USER Manual 01
Anker Technology Co., Limited Anker Wireless Vertical Mouse USER Manual 01
User Manual
98ANWVM-UBA User Manual
VER: 0.1
Page 1 of 8
ModelNAME:AnkerWirelessVerticalMouse
MODELNO. : 98ANWVM-UBA
VERSION:0.1
DATE:2017.5.16
USER MANUAL
98ANWVM-UBA User Manual
VER: 0.1
Page 2 of 8
Version.
#
Revised Date PIC Remark
0.1 16/5/2017 Bob Preliminary
98ANWVM-UBA User Manual
VER: 0.1
Page 3 of 8
Electrical Specification
1. Operating Voltage
Mouse supply voltage: 3V (2AAA battery)
2. Current Consumption
Current use :< 10mA
3. Sleep Mode
3.1 Electrical Current: ＜1mA;
3.2 Wake Up: Press any button
5. Mouse Pointer Performance
5.1 Resolution：800/1200 (default) /1600 DPI
5.2 Speed： 25inches/sec （Max）
5.3 Acceleration：8G
6. LED Indicating Functions
When the battery power is low (battery voltage reduce to <2.1V) the LED will
glisten at the frequency of 1Hz
98ANWVM-UBA User Manual
VER: 0.1
Page 4 of 8
7. Wireless specifications
2.408-2.474GHz frequency coverage.
GFSK RF transceiver
High Speed RF link data rate Max. 1M bit/s
Button Functions
1. Left Button: Mouse left button standard function
2. Right Button: Mouse right button standard function
3. Middle Button: Mouse middle button standard function
4. Wheel: Mouse scroll wheel standard function
5. 4 Button: IE Forward function
6. 5 Button: IE Back function
7. DPI Button: DPI regulate function
98ANWVM-UBA User Manual
VER: 0.1
Page 5 of 8
Operation Process
Step 1
Open the battery cover which in the back of the Mouse.
Insert 2AAA battery which is environment-friendly and safety
Close the battery cover.
Step 2
Place the mouse on a desk or other plane surface. The surface material isn’t metal is better
for wireless distance.
Step 3
Insert a Transceiver in a USB port of PC. The Transceiver is pairing with the mouse.
Step 4
Use the mouse freely.
98ANWVM-UBA User Manual
VER: 0.1
Page 6 of 8
Caution
Please use the Mouse in human house only and keep away water.
Don’t to fixate the light at the mouse bottom.
Children use the mouse with guardian together is necessary.
Keep dry. Humidity, liquids, contain minerals that will corrode
electronic circuits.
Don’t use or store in dusty, dirty areas.
Don’t store in hot areas. High temperature can shorten the life of electronic devices
and warp or melt certain plastics.
Don’t store in very cold areas. Moisture can form inside the case, which may damage
electronic circuit boards.
Don’t attempt to open the case. Non-expert handling of the device may damage the
system.
Avoid dropping and strong impact.
98ANWVM-UBA User Manual
VER: 0.1
Page 7 of 8
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
To assure continued compliance, any changes or modifications not expressly
approved by the party responsible for compliance could void the user’s authority to
operate this equipment. (Example- use only shielded interface cables when
connecting to computer or peripheral devices).
98ANWVM-UBA User Manual
VER: 0.1
Page 8 of 8
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
1) This device may not cause harmful interference, and
2) This device must accept any interference received, including interference that may
cause undesired operation.
Caution!
The manufacturer is not responsible for any radio or TV interference caused by
unauthorized modifications to this equipment. Such modifications could void the
user authority to operate the equipment.
