Anker Technology A7910 Bluetooth Speaker User Manual
Anker Technology Co., Limited Bluetooth Speaker Users Manual
User Manual
Anker A7910 Pocket Bluetooth Speaker
Package Contents
Anker A7910 Pocket Bluetooth Speaker
Micro USB charging cable (2.3 ft)
AUX to Micro USB audio cable (2.3 ft)
Welcome Guide
Product Features
●Ring-box size profile fits easily into your pocket, or the small side pocket of your backpack.
●Impressively full sound powered by a powerful 3 watt audio driver.
●12 hours o
f
play time significantly outlasts other Bluetooth speakers.
●Non-Bluetooth devices enjoy unhampered compatibility with the provided
A
UX to Micro USB
audio cable.
●NFC compatibility enables easier pairing.
●Connects automatically to the last-connected device once powered on.
Specifications
Product Model A7910
Bluetooth Standard 3.0
Product Weight 90 ± 5g / 3.2 ± 0.2oz
Product Size 45 × 45 × 45mm / 1.8 × 1.8 × 1.8in
Play Time 12 hours
Charge Time 1.5 hours
Input 5V / 1A
Operating Range 10m / 33ft
Speaker Output Power 3W
Audio Cable Type AUX to Micro USB audio cable
Supported Bluetooth
Profiles
A2DP, AVRCP
Product Overview
Power button
LED indicator
Micro USB charging & audio 2-in-1 port
NFC chip location
How to Turn On / Off the Speaker
Press the power button for 3 seconds to turn the speaker on or off.
How to Pair with Your Device
1. Press the power button for 3 seconds. The speaker will turn on and automatically enter pairing mode
indicated by the flashing blue LED.
2. Activate your device’s Bluetooth function and search for the device.
3. Once the Bluetooth speaker has been detected, select the product name “Anker A7910” to connect.
(For devices with Bluetooth versions below 3.0, press “Yes” to confirm pairing. Enter a passkey or PIN
code “0000” (4 zeros), then press the “Yes” or “OK” key to finish pairing.)
4. When the Bluetooth speaker and your device are successfully paired, the blue LED will go on and
remain on while connected.
How to Pair with a NFC-Supportive Device
1. Press the power button for 3 seconds. The speaker will turn on and the indicator will start flashing
blue.
2. Enable your device’s NFC function.
3. Put your device near the NFC chip location.
4. Click “Yes” on your device’s screen to confirm Bluetooth connection.
5. When the Bluetooth speaker and your device are successfully paired, the blue indicator will go on
and remain on while connected.
Note: When turning on the speaker, it will automatically connect to the last-connected device
(Bluetooth function needs to be enabled). When pairing with an additional device, disable the
Bluetooth function on the previous device, the speaker will automatically return to pairing mode. Then,
repeat the pairing process.
How to Recharge
When the speaker’s battery is low, the speaker will announce “Battery low”, and the red battery
indicator will flash for about 10 minutes.
1. Plug the Micro USB cable into the speaker’s Micro USB charging port.
2. Insert the remaining end of the USB power wire into (a) a USB AC adapter (not included) connected
to a wall socket, or (b) a charging computer USB port. A steady red battery indicator will show that it is
charging.
3. The red battery indicator will go off when the speaker is fully charged.
LED Indicator Instructions
LED indicator Meaning
Blue indicator rapidly flashing Pairing mode
Steady blue indicator Connected to a device
Red indicator flashing Low Battery
Steady red indicator Charging
Red indicator goes off Fully charged
Usage Tips
1. Power off the speaker when not in use and before storing.
2. The operational range of the speakers may be influenced by obstructions, such as walls, pillars, etc.
To ensure a stable connection, we recommend avoiding such obstructions whenever possible and/or
shortening the distance during use.
3. To protect the long-term performance of the battery, please do not place the speaker in high
temperatures above 140°F/60℃, such as in a hot vehicle or under direct sunlight.
4. Do not expose the speaker or any of its supplied parts to water or liquids.
FAQ and Solutions
1. Why can’t the speaker connect to my device?
a. Check to ensure your device’s Bluetooth function is enabled.
b. Make sure your device is within 3ft/1m of the speaker.
c. Delete the pairing record(s) on the speaker or your device.
2. Can I use the speaker to play music while charging?
To protect the long-term performance of the battery, it is better to charge it when the speaker is turned
off, especially when the battery is low.
3. Can I make or answer phone calls through the speaker?
No. The speaker does not feature a built-in microphone.
4. Why can’t I connect by NFC?
a. Make sure that your device supports NFC functionality.
b. Keep your mobile device close to the NFC chip location of the speaker when attempting to
connect.
c. Disable the Bluetooth connection o
f
the speaker to other devices.
FCC STATEMENT :
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause
undesired operation.
Warning: Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
RF warning statement:
The device has been evaluated to meet general RF exposure requirement. The device can be used in
portable exposure condition without restriction.
