Appion MSD1PG PRESSURE GAUGE WITH BLUETOOTH User Manual

Appion Inc. PRESSURE GAUGE WITH BLUETOOTH Users Manual

Users Manual

TM
OPERATION MANUAL
COPYRIGHT © 2013 - APPION INC. - ALL RIGHTS RESERVED
⚠ WARNING TO REDUCE THE RISK OF INJURY OR PRODUCT DAMAGE,
READ OPERATION MANUAL PRIOR TO OPERATING PRODUCT.
Introduction
Table of Contents
Safety .....................................................................3
Display & Controls ..................................................4
Using the Pressure Gauge .....................................5
Regulatory ..............................................................6
2P300/P500/P800 OPERATION MANU-
© 2013 APPION INC. - ALL RIGHTS RESERVED
Safety
• Do not connect to systems exceeding rated
pressure.
• Do not use leaky or damaged batteries.
• Useonlyspeciedbatteriesandcleaningagents.
• Dispose of batteries in accordance with any
applicable local laws and regulations.
3P300/P500/P800 OPERATION MANU
© 2013 APPION INC. - ALL RIGHTS RESERVED
Display
Controls
1- Battery Indicator
2- Auto Power Off
3- Bluetooth Status
4- Measurement
5- Units
1 2 3
4
5
Press a button for the “Press” function above.
Hold a button for 1 second for the “Hold” function.
Press both Backlight and Power to toggle APO.
Press
Backlight ON/OFF
Hold
Units Zero Connect BT
Both
Toggle APO Timer
4P300/P500/P800 OPERATION MANU
© 2013 APPION INC. - ALL RIGHTS RESERVED
Using the Pressure Guage
CAUTION: Always wear hand and eye protection
when handling connections to systems under
pressure.
1. Makesurethatallttingsareproperlytightened
and sealed before connecting the P300/P500/
P800 to a system under pressure.
2. Press the Power button to turn on the P300/P500/
P800. Wait for the power on self-test to complete
before using the readings from the P300/P500/
P800.
Tip: Connect to the Side Access Port on a Valve
Core Removal Tool with the Female Swivel Adapter.
5P300/P500/P800 OPERATION MANU
© 2013 APPION INC. - ALL RIGHTS RESERVED
Regulatory Information
6P300/P500/P800 OPERATION MANU
© 2013 APPION INC. - ALL RIGHTS RESERVED
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received,
including interference that may cause undesired
operation.
Federal Communication Commission
Interference Statement
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation.
This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is
no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
7P300/P500/P800 OPERATION MANU
© 2013 APPION INC. - ALL RIGHTS RESERVED
Regulatory Information
FCC Radiation Exposure Statement
This equipment complies with FCC RF radiation
exposure limits set forth for an uncontrolled environment.
This transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
FCC Caution
To assure continued compliance, any changes or
modifications not expressly approved by the party
responsible for compliance could void the user’s authority
to operate this equipment.
Industry Canada Radio Equipment
This device complies with Industry Canada licence-
exempt RSS-210 standard. Operation is subject to
the following two conditions: (1) this device may not
cause interference, and (2) this device must accept
any interference, including interference that may cause
undesired operation of the device.
Équipement radio d’Industrie Canada
Le présent appareil est conforme aux CNR d’Industrie
Canada applicables aux appareils radio
exempts de licence. L’exploitation est autorisée aux deux
conditions suivantes :
(1) l’appareil ne
doit pas produire de brouillage, et
(2) l’utilisateur de l’appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible
d’en compromettre le fonctionnement.
