FCC WARNING
FCC Certification
The United States Federal Communication Commission (FCC) and the Canadian
Department of Communications have established certain rules governing the use of
electronic equipment.
(15.21)
Warning: Changes or modifications to this unit not expressly approved by the
party responsible for compliance could void the user authority to operate the
equipment.
15.19 (a)(3)
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
The users manual or instruction manual for an intentional or unintentional radiator
shall caution the user that changes or modifications not expressly approved by the
party responsible for compliance could void the user’s authority to operate the
equipment.
CAUTION:
1. To comply with FCC RF exposure compliance requirements, a separation
distance of at least 20 cm must be maintained between the antenna of this device
and all persons.
2. This Transmitter must not be co-located or operating in conjunction with any
other antenna or transmitter
If you have any trouble with use this equipment, please contact customer care service:
Company Name: Accton US
Address: 2880 Lakeside Drive Suite#200, Santa Clara, CA 95054
Tel: +408-330-0940 / Fax: +408-330-0945
802.11g Wireless DSL/Cable Gateway Router F5D7230-4
Belkin Corporation Confidential
Networking Group 3
Table of Contents
1. Introduction ……………………………………………………………………... 3
2. Product Overview……………………………………………………………….. 3
2.1 Features………………………………………………………………… 3
2.2 System Requirements…………………………….……………………. 3
3. Product Hardware……………………………………………………………….. 4
3.1 Physical Specifications………………………………………………… 4
3.2 Chipset Platform……………………………………………………….. 4
3.3 Ports……………………………………………………………………. 4
3.4 Antenna………………………………………………………………… 4
3.5 LED Indicators…………………………………………………………. 4
3.6 Supported Clients……………………………………………………….4
3.7 Operating Range……………………………………………………….. 5
3.8 Power Consumption…………………………………………….……... 5
3.9 Environment Conditions………………………………………………. 5
4. Product Software………………………………………………………………… 5
4.1 Wireless Specfications…………………………………………………. 5
4.1.1 Modulation…………………………………………………… 5
4.1.2 Data Rates……………………………………………………. 5
4.1.3 Wireless Channels…………………………………………… 6
4.1.4 Wireless Security…………………………………………….. 6
4.2 Client Utility…………………………………………………………… 6
4.2.1 Features.……………………………………………………... 6
4.3 WAN connections.……………………………………………………... 6
4.4 Firewall.…………………………………………………….………….. 7
4.5 Configuration.…………………………………………………….……. 7
4.6 Compatibility.…………………………………………………….…… 7
4.7 Firmware.………………………………………………………………. 7
4.8 Port Forwarding.…………………………………………………….…. 8
5. Bill of Materials…………………………………………………………………. 8
6. Regulatory Certifications………………………………………………………... 8
7. Intended Markets…………………………………………………………………8
802.11g Wireless DSL/Cable Gateway Router F5D7230-4
Belkin Corporation Confidential
Networking Group 4
1. Introduction
This document covers the functional description, specification and deliverables of this
project.
2. Product Overview
The Belkin F5D7230-4 Wireless 11G Router is a WLAN Router with 4 LAN ports. The
Router conforms to the IEEE 802.11b/g wireless standards. The router operates on
2.4GHz frequencies and can access 802.11b and 802.11g WLAN networks. The Router
is to be used with either a Broadband ADSL or Cable Modem via the WAN port to share
broadband connections with up to 4 computers via the LAN ports and 32 computers via
the WLAN. Each LAN port supports 10/100 Base-T Networks with auto sensing and
switching compatibilities. The Router’s EZ install software operates on Microsoft’s
Windows 98SE, Me, 2000 and XP. The Router can be configured through a web-browser
interface. The product is designed for the home and small office and will be available
through major retailers and online retailers.
2.1 Features
Enables sharing of broadband Internet connection
Connects four computers through the LAN ports
Connects 32 computers wirelessly
Operates on 2.4 frequency band
Conforms to IEEE 802.11b and 802.11g standards
Security supports WPA and WEP Encryption
Windows OS supports Windows 98SE, ME, 2000 and XP
WAN supports include:
Dynamic
Static
PPPoE
PPTP
LED indicators include:
Power,
WAN,
4x LAN,
WLAN
Internet connections.
2.2 System Requirements
Broadband Internet connection with RJ45
At least one computer with an installed network interface card
TCP/IP networking protocol installed on each computer
EZ Install software (not required to use Router):
802.11g Wireless DSL/Cable Gateway Router F5D7230-4
Belkin Corporation Confidential
Networking Group 5
Windows 98SE, ME, 2000 or XP
Router configuration through Web-Browser:
Internet browser
TCP/IP networking protocol
3. Product Hardware
3.1 Physical Specifications
Dimensions: TBC
Weight: TBD
3.2 Chipset Platform
Atheros 2315
3.3 Ports
1x RJ45 WAN port
4x RJ45 LAN port
3.4 Antenna
1 external dipole “90° angle” antenna with 0 ~ 2 dBi antenna gain
(including cable loss)
1 dipole on-board antenna with 0 ~ 2 dBi antenna gain
(Dimension 4.8cm x 1.1cm)
802.11g Wireless DSL/Cable Gateway Router F5D7230-4
Belkin Corporation Confidential
Networking Group 6
3.5 LED Indicators & Real Panel definition
Power Solid Green – power on
Off – power off
Wireless Blinking Green – wireless enabled
Off – wireless disabled
Internet Blinking Green – connected to the Internet
Off – not connected to the Internet
Modem Blinking Green – connected to the modem
Off – not connected to the modem
1-4 Sold Green – computer 1, 2, 3 or 4 linked to network
Off – computer 1, 2, 3 or 4 not connected to network
Blinking Green - data is transferring on computer 1, 2, 3 or 4
3.6 Supported Clients
The following clients must be tested and verified
Windows 98/98SE/Me/NT SP 6.0 and higher/2000/XP
Mac OS 7 to 10
Linux
Unix
The following clients are expected to be compatible
Any TCP/IP enabled client
802.11g Wireless DSL/Cable Gateway Router F5D7230-4
Belkin Corporation Confidential
Networking Group 7
3.7 Operating Range
Indoor: 200ft
Outdoor: 1500ft
3.8 Power Consumption
Input: 120VAC, 60Hz, 9W
Output: 9VDC, 1A
3.9 Environment Conditions
Temperature Range: Operating - 0 ~ 40℃
Storing - 20 ~ 70 ℃
Humidity: Operating – 10 ~ 85% non-condensing
Storing – 5 ~ 90% non-condensing
4. Product Software
4.1 Wireless Specifications
4.1.1 Modulation
802.11b: CCK (11 Mbps, 5.5 Mbps)
DQPSK (2 Mbps)
DBPSK (1 Mbps)
802.11g: OFDM
4.1.2 Data Rates
802.11b: 11, 5.5, 2, 1 Mbps
< 1Mbps XR (Auto fallback for extended range)
802.11g: 54, 48, 36, 24, 18, 12, 9, 6 Mbps
Auto fallback for extended range
4.1.3 Wireless Channels
802.11b/g North America 1-11
Europe 1-13
Australia 1-11
Most of Asia 1-13
802.11g Wireless DSL/Cable Gateway Router F5D7230-4
Belkin Corporation Confidential
Networking Group 8
4.1.4 Wireless Security
802.11b/g WPA – AES. TKIP
WEP – 64-, 128-bit
4.2 Utility Specifications
4.2.1 Features
HTML configurable from client browsers
Login Screen
DHCP Server
DHCP disable
Adjustable IP range
Adjustable subnet mask
Viewable DHCP Log
Computer Name
IP address
MAC address
Time set
Auto from SNTP server
Time viewable on page
Supports WAN Administration (remote management)
Easy Port Configuration for common applications (250+ settings)
(11K) Video Conferencing
Games
Netmeeting
Manually configurable
UPnP Enabled/Disabled
NAT (rfc1631)
Network Address Port Translation (NAPT)
4.3 WAN Connections
Static
Dynamic
DHCP Client
Host Name
PPPoE (selectable Idle Timeout and connect on demand)
Mac address (including ability to clone a client)
PPTP (selectable Idle Timeout and connect on demand)
DNS Relay
4.4 Firewall
802.11g Wireless DSL/Cable Gateway Router F5D7230-4
Belkin Corporation Confidential
Networking Group 9
All ports stealth
Stateful Packet Inspection (SPI)
ICSA certified
Protection from the following types of attacks
Denial of Service (DoS)
IP Spoofing
Land Attack
Ping of Death
IP with zero length
Smurf Attach
TCP null scan
SYN flood
UDP flooding
Tear Drop Attack
ICMP defect
RIP defect
Fragment flooding
Hacker logging (HTML viewable)
4.5 Configuration
MAC address filtering
HTTP administration
HTTP 1.0 (rfc 1945)
HTTP (rfc1866)
Base64 algorithm
4.6 Compatibility
UPnP (enable/disable)
VPN pass-thru
IPSec
PPTP
L2TP
Checkpoint, Cisco, Nortel, FreeSwan
4.7 Firmware
Upgradeable via file transfer
Automatically notify user of new firmware availability
Ability to back up and restore user settings
4.8 Port Forwarding
Custom Ports
802.11g Wireless DSL/Cable Gateway Router F5D7230-4
Belkin Corporation Confidential
Networking Group 10
DMZ (exposed host) (all ports open)
50 Max forwarding entries
Public / Private port translation
Forward Ranges
Can forward UDP and TCP separately or Simultaneously
5. Bill of Materials
Wireless G Router
CD-ROM
Ethernet Cable
Quick Install Guide
Power Adapter
6. Regulatory Certifications
US: FCC Part 15B & C
Canada: ICES-003 & RSS-210
Europe: EN 301 489-1 & -17, EN 300 328
EN 61000-3-2, EN 61000-3-3, EN 60950-1: 2001
Australia: C-Tick
7. Intended Markets
North America: USA
Canada
Mexico
Europe: United Kingdom
France
Spain
Italy
Germany
Netherlands
Asia / Pacific: Australia
Singapore
