Arcadyan Technology WN4401CARC WLAN Mini PCI Card User Manual WN4401C ZZ spec revised
Arcadyan Technology Corporation WLAN Mini PCI Card WN4401C ZZ spec revised
Users Manual
WN4401C-ZZ 1
WN4401C-ZZ
IEEE 802.11b/g single chip miniPCI
V 0.1
Arcadyan Technology Corporation
4F, No 9 Park Avenue II, Science-based Industrial Park
HsinChu 300, Taiwan
Subject to Change without Notices
©Copyright 2003 by Arcadyan. Confidentical / All right reserved.
WN4401C-ZZ 2
Table of Contents
Contents _____________________________________________________________ 2
Revision History ______________________________________________________ 3
Chapter 1 Introduction_________________________________________________ 4
1.1 Product Features ________________________________________________ 4
1.2 Application ____________________________________________________ 5
Chapter 2 Hardware ___________________________________________________ 5
2.1 General Overview _______________________________________________ 5
2.2 Hardware Architecture ___________________________________________ 5
2.3 Main Chipset Information_________________________________________ 5
Chapter 3 Software ____________________________________________________ 6
3.1 Operating Systems Supported ____________________________________ 6
3.2 WEP Security _________________________________________________ 6
3.3 Configuration Utility ___________________________________________ 6
Chapter 4 Specifications ________________________________________________ 7
References __________________________________________________________ 10
WN4401C-ZZ 3
Revision History
Edition # Reason for revision Issue date Written by
V 0.1 ♦ Initial Document Sep. 23, 2004 Jason Lee
♦
WN4401C-ZZ 4
Chapter 1 Introduction
1. Introduction
WN4401C is an industrial miniPCI Card which enables wireless networking systems to attain
data transmission speeds at least up to 54 megabits-per-second (Mbps), while remaining
backward compatible to the existing installed base of over 15 million Wi-Fi systems
worldwide. It supports operation to both the IEEE 802.11b and IEEE 802.11g standards.
WN4401C will enable a next generation of high-data-rate platforms for operation in the 2.4
GHz band that deliver a five-fold speed increase. It is fully IEEE 802.11g standard
compliant, and uses prioritization algorithms and enhanced protection mechanisms to
significantly increase pure 802.11g as well as mixed-mode network performance. The cost and
performance advantages will make it an ideal solution for high bandwidth enterprise
applications, such as wireless video conferencing and large file transfers, as well as advanced
home networking applications such as multi-channel CD-quality audio and DVD-quality
video streaming. WN4401C incorporates the 802.11g Standard's mandatory modulation
schemes—Complementary Code Keying (CCK), which is used in 802.11b, and Orthogonal
Frequency Division Multiplexing (OFDM), used in 802.11g. Using CCK ensures
backward-compatibility with the installed Wi-Fi 802.11b base, while OFDM provides the
speed required for today's high-bandwidth applications.
1.1 Product Features
♦ High speed for wireless LAN connection, up to 54 Mbps data rate.
♦ Extended Range feature supported
♦ Backward compatible to the existing IEEE 802.11b WLAN infrastructure.
♦ An user-friendly utility to configure SSID, security setup and site survey.
♦ Wireless data encryption using WEP 64, 128-bit encryption for security.
♦ Support for WPA and Wi-Fi, WPA2 upgradeable
♦ Built-in Hirose antenna connectors.
♦ Firmware upgrade-able by only changing driver.
1.2 Applications
♦ Home networking for device sharing.
♦ Wireless multimedia.
♦ Wireless office for extension Ethernet range.
♦ Mobile networking for notebook PC, PDA, Web Pad or Wireless Gateway Built-in
Application.
WN4401C-ZZ 5
Chapter 2 Hardware
2.1 General Overview
♦ Power: 3.3V, DC input.
♦ Antenna connector: Two Hirose, FL-R-SMT (01) coaxial connectors.
2.2 Hardware Architecture
2.3 Main Chipset Information
2.3.1 AR2413: An IEEE 802.11g MAC + Baseband processor, AES Hardware accelerator,
on-chip SRAM memory and MiniPCI/PCI bus interface. Radio-on-Chip (RoC). A
zero-IF direct down conversion transceiver. a 2.4GHz power amplifier, 5GHz SiGe
monolithic VCO.
WN4401C-ZZ 6
Chapter 3 Software
3.1 Operating System Supported
♦ Windows 98SE, Windows ME, Windows 2000, Windows XP and Linux.
3.2 Security
♦ Wired Equivalent Privacy (WEP) supports 64, and 128 bit keys.
♦ Support WPA, WPA2 upgradeable
3.3 Configuration Utility
♦ A Utility to set SSID, WEP key and dynamically view configuration and receiving signal
quality.
♦ Support worldwide country channel selection.
WN4401C-ZZ 7
Chapter 4 Specifications
♦ Frequency Band:
802.11g Radio: 2.4 GHz
802.11b Radio: 2.4 GHz
USA – FCC 2412~2462MHz (Ch1~Ch11)
Canada – IC 2412~2462MHz (Ch1~Ch11)
Europe – ETSI 2412~2472MHz (Ch1~Ch13)
Spain 2412~2472MHz (Ch1~Ch13)
France 2457~2472MHz (Ch10~Ch13)
Japan – STD-T66 2412~2472MHz (Ch1~Ch13)
♦ Modulation TYPE:
DSSS BPSK, QPSK, CCK
OFDM BPSK, QPSK, 16QAM, 64QAM
♦ Operating Channels:
IEEE 802.11b compliant:
11 channels (US, Canada)
13 channels (ETSI)
13 Channels (Spain)
4 Channels (France)
13 channels (Japan)
IEEE 802.11g compliant:
11 channels (US, Canada)
13 channels (ETSI)
13 Channels (Spain)
4 Channels (France)
13 channels (Japan)
♦ Security: 64/128-bit WEP/TKIP/AES-CCM/AES-OCB/ 802.1x, and WPA
♦ Operating Voltage: 3.15V ~ 3.45V
♦ Transmitted Power: See Table 1
♦ Rates/Sensitivity/Allowable Path Loss: See the Table 2
♦ Mechanical specification:
♦ MiniPCI Type 3B
♦ Regulatory compliance:
♦ Power Limit: FCC 15.407
♦ ETSI, CE
♦ Current consumption: TX:480 mA Max; RX: 420mA Max; Power Saving: 20mA
WN4401C-ZZ 8
♦ Operating Temperature: 0 ~ 55 oC ambient
♦ Storage Temperature: -20 ~ 75 oC ambient
♦ Humidity: 5 ~ 90% and must be non-condensing
♦ ESD: EN61000-4-2, which specifies 4kV contact and 8kV air discharge.
WN4401C-ZZ 9
Table 1: Modulation Scheme and Transmit Power
Modulation Rate Output Power
2.4-2.5GHz (dBm)
802.11b – 1Mbps 17
802.11b – 2Mbps 17
802.11b – 5.5Mbps 17
802.11b – 11Mbps 17
Modulation Rate Output Power
2.4-2.5GHz (dBm)
802.11g – 6Mbps 16
802.11g – 9Mbps 16
802.11g – 12Mbps 16
802.11g – 18Mbps 16
802.11g– 24Mbps 15
802.11g – 36Mbps 15
802.11g– 48Mbps 13
802.11g – 54Mbps 13
Table 2: Typical Range at Which Frame (1000 Bytes PDUs) Packet Error Rate < 10%
Modulation Rate Receiver Sensitivity (dBm)
2.412 ~ 2.484 GHz
802.11b – 1Mbps -90
802.11b – 2Mbps -88
802.11b – 5.5Mbps -85
802.11b– 11Mbps -82
Modulation Rate Receiver Sensitivity
Typical (dBm)
802.11g – 6Mbps -88
802.11g – 9Mbps -87
802.11g – 12Mbps -84
802.11g – 18Mbps -82
802.11g– 24Mbps -79
802.11g – 36Mbps -75
802.11g– 48Mbps -68
802.11g – 54Mbps -68
WN4401C-ZZ 10
References
♦ IEEE 802.11b Standard Specification
♦ IEEE 802.11g Draft Specification D8.2
The drawings, specifications and the data contain herein are the exclusive property of Arcadyan
Technology Corp. issued in strict confidence and shall not, without the prior written permission of
Arcadyan Technology Corp., be reproduced, copied or used, in parts or as a whole, for any purpose
whatsoever, except the manufacture of articles for Arcadyan Technology Corp.
Arcadyan makes no warranties with respect to the correctness, accuracy or wholeness of this
specification. The information in this document is subject to change without notice. Arcadyan
reserves the right to make revisions to this document and the product described herein without
obligation to notify any person or entity of any such changes.
