Arcadyan Technology WN7511A 2Wire 802.11N Wireless USB Adapter User Manual
Arcadyan Technology Corporation 2Wire 802.11N Wireless USB Adapter
User Manual
Product Specification
WN7511A 1
User’s manual
AWN11N
AWN11NAWN11N
AWN11N-
--
-001
001001
001
IEEE 802.11n USB2.0 Adapter
v.02 draft
Product Specification
WN7511A 2
Table of Contents
Chapter 1 _________________________________________________ Introduction
4
1. Introduction_________________________________________________ 4
1.1 Product Features ___________________________________________ 4
1.2 Applications _______________________________________________ 4
Chapter 2 Hardware _______________________________________________ 5
2.1 General Overview ___________________________________________ 5
2.2 Hardware Architecture _______________________________________ 5
2.3 Main Chipset Information _____________________________________ 5
Chapter 3 Software ________________________________________________ 5
3.1 Operating System Supported __________________________________ 6
3.2 Wireless Mode Supported_____________________________________ 6
3.3 Security___________________________________________________ 6
3.4 Configuration ______________________________________________ 6
Chapter 4 Appearance______________________________________________ 7
Chapter 5 Specifications ____________________________________________ 8
Table 1: Modulation Scheme and Nominal Transmit Power ___________________11
Product Specification
WN7511A 3
Revision History
Edition # Reason for revision Issue date Written by
V 01 ♦ Initial Document Jan 18, 2008 Katherine Hsieh
V02 ♦ Remove second LED behavior Nov 18 2009 Troy Chen
Product Specification
WN7511A 4
Chapter 1 Introduction
1. Introduction
AWN11N-001 is a wireless 1x1 802.11n USB Adapter which enables wireless networking
systems to attain data communication speeds up to 150 megabits-per-second (Mbps), while
remaining backward compatible to the existing installed base of Wi-Fi systems worldwide. It
supports operation to the IEEE 802.11b and IEEE 802.11g ,and draft IEEE 802.11n standards.
AWN11N-001 will enable a next generation of high-data-rate platforms for operation in
the 2.4 GHz band that deliver a five-fold speed increase. The cost and performance
advantages will make it an ideal solution for high bandwidth enterprise applications,
such as wireless video conferencing and large file transfers. It is compatible with
802.11g standard's mandatory modulation schemes—Complementary Code Keying
(CCK), which is used in 802.11b, and Orthogonal Frequency Division Multiplexing
(OFDM), used in 802.11g and draft 802.11n. Using CCK ensures
backward-compatibility with the installed Wi-Fi 802.11b base, while OFDM provides
the speed required for today's high-bandwidth applications.
This Wire 802.11N wireless USB Adapter is for use only with compatible UL Listed
Computer that installation Instruction detailing user installation of card cage
accessories
1.1 Product Features
♦ High speed for wireless LAN connection, RX up at 150 Mbps data rate.
♦ Backward compatible to the existing IEEE 802.11b/g WLAN infrastructure.
♦ User-friendly utility to configure SSID, security setup and site survey.
♦ Wireless data encryption with 64, 128 encryption for security.
♦ Internal antenna
♦ Support USB v2.0
♦ Key type housing
♦ WPS Button for easy security
1.2 Applications
♦ Home networking for device sharing.
♦ Wireless multimedia.
♦ Wireless office for extension Ethernet range.
♦ Mobile networking for notebook PC, Desktop PC, Monitor, PDA with USB port
ready device.
Product Specification
WN7511A 5
Chapter 2 Hardware
2.1 General Overview
♦ USB 2.0 Interface and 802.11 n chipset-on-board design.
♦ Antenna: 1 Internal Antenna on board
2.2 Hardware Architecture
Ralink 3070 single chip USB2.0
2.3 Main Chipset Information
RT3070: An 1T1R MIMO MAC + Baseband processor and RF with fully forward compatible with IEEE
802.11n draft2.0 standard.
2.4 PCB dimension
16.5mmx43mm
Product Specification
WN7511A 6
Chapter 3 Software
3.1 Operating System Supported
♦ Windows 2000 , Windows XP, Windows Vista
3.2 Wireless Mode Supported
♦ AP (Infrastructure) mode(Software AP)
♦ AP (Infrastructure) Client mode
♦ Ad-hoc mode
3.3 Security
♦ AP (Infrastructure) mode supports
♦ Static WEP that support both 64 and 128 bit keys.
♦ WPA(TKIP) with PSK
♦ Ad-hoc mode supports
♦ None (plaintext)
♦ Static WEP that supports both 64 and 128 bit keys.
3.4 Configuration
♦ User should be able to select
♦ Mode of operations: AP or ad-hoc mode
♦ Different security modes: none (plaintext), static WEP, WPA(TKIP)/PSK or
802.1X/LEAP as supported by the respective operating mode.
♦ Channel to operate on
♦ User should be able to perform key management on WPA/PSK and static WEP as
supported by the respective operating mode
♦ A Utility to set SSID, WEP key, site survey, profile manager and dynamically view
configuration and receiving signal quality.
♦ Support for transmitting power configurable.
♦ Support for extended range.
♦ WPS support(Pin code)
♦ WPS Hard Button
Product Specification
WN7511A 7
Chapter 4 Appearance
LED 1 One Power/Link
(Green)
OFF All others states
ON Radio On and Associated
Blink Radio On and Scanning
Flash Radio On and Associated and
TX/RX Data
Product Specification
WN7511A 8
Chapter 5 Specifications
♦ Frequency Band:
Draft 802.11n Radio: 2.4 GHz
802.11g Radio: 2.4 GHz
802.11b Radio: 2.4 GHz
USA – FCC 2412~2462MHz
(Ch1~Ch11)
Canada – IC 2412~2462MHz (Ch1~Ch11)
Europe – ETSI 2412~2472MHz (Ch1~Ch13)
Japan – STD-T66/STD-33 2412~2484MHz (Ch1~Ch14)
♦ Operating Channels:
IEEE 802.11b/g/n compliant:
11 channels (US, Canada)
13 channels (ETSI)
14 channels (Japan)
♦ Transmit Power and Sensitivity:
TX Output Power:(Typical)
11b 11G 11n HT20 11n HT40
Data
Rate
(Mbps)
Power
(dBm)
Data
Rate
(Mbps)
Power
(dBm)
Data
Rate
Power
(dBm)
Data
Rate
Power
(dBm)
1 15 6 15 MCS0 15 MCS0 15
2 15 9 15 MCS1 15 MCS1 15
5.5 15 12 15 MCS2 15 MCS2 15
11 15 18 15 MCS3 15 MCS3 15
24 14 MCS4 14 MCS4 14
36 14 MCS5 14 MCS5 14
48 12 MCS6 12 MCS6 12
54 12 MCS7 12 MCS7 12
Product Specification
WN7511A 9
♦ Rx Sensitivity:(Typical)
data rate specification
1 -90
2 -90
5.5 -86
11b
11 -82
6 -86
9 -85
12 -84
18 -82
24 -78
36 -75
48 -68
11g
54 -68
MCS0 -85
MCS1 -83
MCS2 -80
MCS3 -78
MCS4 -75
MCS5 -71
MCS6 -69
HT20
MCS7 -66
MCS0 -83
MCS1 -80
MCS2 -78
MCS3 -76
MCS4 -72
MCS5 -68
MCS6 -65
HT40
MCS7 -62
♦ Modulation
DBPSK @1Mbps
DQPSK@2Mbp
CCK@5.5/11Mbps
BPSK@6/9 Mbps
Product Specification
WN7511A 10
QPSK@12/18Mbps
16-QAM@24Mbps
64-QAM@48/54Mpb
♦ Current consumption(5V DC):
TX: 200mA (max of all data rate 11b/g/n)
RX: 200mA (max of all data rate 11b/g/n)
Idle: 90mA
Radio off 52mA
♦ Operating Temperature: 0 ~ 40
o
C ambient
♦ Storage Temperature: -10 ~ 70
o
C ambient
♦ Humidity: 5 ~ 90% and must be non-condensing
♦ Regulation and certification compliance available:
♦ WHQL
♦ ETSI/CE
♦ ESD: EN61000-4-2, which specifies 4kV contact and 8kV air discharge.
Product Specification
WN7511A 11
References
♦ Ralink Reference Design Functional Specification
♦ IEEE 802.11b Standard Specification
♦ IEEE 802.11g Standard Specification
♦ IEEE 802.11n draft Standard Specification
The drawings, specifications and the data contain herein are the exclusive property of Arcadyan
Technology Corp. issued in strict confidence and shall not, without the prior written permission of
Arcadyan Technology Corp., be reproduced, copied or used, in parts or as a whole, for any purpose
whatsoever, except the manufacture of articles for Arcadyan Technology Corp.
Arcadyan makes no warranties with respect to the correctness, accuracy or wholeness of this
specification. The information in this document is subject to change without notice. Arcadyan
reserves the right to make revisions to this document and the product described herein without
obligation to notify any person or entity of any such changes.
WARNING
This document is intended for internal use only. A Non-Disclosure Agreement (NDA)
is required to release this document under any circumstances
Product Specification
WN7511A 12
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate this equipment.
IEEE 802.11b or 802.11g operation of this product in the U.S.A. is firmware-limited to
channels 1 through 11.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. End users must follow the specific operating instructions
for satisfying RF exposure compliance. To maintain compliance with FCC RF
exposure compliance requirements, please follow operation instruction as
documented in this manual.
This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
Product Specification
WN7511A 13
SAR compliance has been established in typical laptop computer(s) with USB slot,
and product could be used in typical laptop computer with USB slot. Other application
like handheld PC or similar device has not been verified and may not compliance with
related RF exposure rule and such use shall be prohibited.
The availability of some specific channels and/or operational frequency bands are
country dependent and are firmware programmed at the factory to match the intended
destination. The firmware setting is not accessible by the end user.
