Manual 1
Annex No.5
Page 1 of 79
User Manual
(User Manual ARCHOS 605 H WiFi – v.2.0)
ARCHOS 605 H WiFi
Dear Customer,
Thank you for choosing this ARCHOS product. We hope that you will enjoy
using it and that it will give you entire satisfaction for many years to come.
Please do register your product on our website (www.archos.com/register) to
ensure that you get access to our help line and to be informed of free software
updates for your product.
Wishing you the best Multimedia experience,
The ARCHOS Team.
All the information contained in this manual was correct at the time of
publication. However, as our engineers are always updating and improv-
ing our products, your device’s software may have a slightly different
appearance or modied functionality than presented in this manual.
ENGLISH
Please visit www.archos.com/manuals to download the latest version of this manual.
GEN 5 ENGLISH USER MANUAL
405
Version 2.0
Entertainment
way
605 WIFI
MANUAL
V2.0
GEN 5 TABLE OF CONTENTS > P. 2
TABLE OF CONTENTS
INTRODUCTION ........................................................................................4
ARCHOS DESCRIPTION ......................................4
FIRST TIME USAGE: CHARGING THE BATTERY . . . . . . . . . . . . . . . . . . . . 6
TURNING THE ARCHOS ON/OFF ................................7
USING THE ARCHOS INTERFACE ...............................7
CHANGING THE LANGUAGE ..................................10
PRODUCT CARE ...........................................10
1. PLAYING VIDEO ..................................................................................11
1.1 BROWSING THROUGH YOUR VIDEOS . . . . . . . . . . . . . . . . . . . . . . . . 11
1.2 VIDEO PLAYBACK .......................................12
1.3 VIDEO PLAYER SETTINGS .................................15
1.4 PUTTING VIDEOS ONTO YOUR ARCHOS . . . . . . . . . . . . . . . . . . . . . . 16
1.5 RECORDING VIDEO ......................................17
1.6 PLAYING YOUR PC’S SHARED VIDEOS . . . . . . . . . . . . . . . . . . . . . . 17
2. PLAYING MUSIC ...............................................................................18
2.1 BROWSING THROUGH YOUR MUSIC FILES . . . . . . . . . . . . . . . . . . . . 18
2.2 MUSIC PLAYBACK ......................................20
2.3 MUSIC PLAYER SETTINGS ................................22
2.4 PLAYLISTS ............................................24
2.5 PUTTING MUSIC ONTO YOUR ARCHOS . . . . . . . . . . . . . . . . . . . . . . . 26
2.6 RECORDING ANALOGUE AUDIO . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
2.7 PLAYING YOUR PC’S SHARED MUSIC . . . . . . . . . . . . . . . . . . . . . . . 28
3. VIEWING PHOTOS ..........................................................................29
3.1 BROWSING THROUGH YOUR PHOTOS . . . . . . . . . . . . . . . . . . . . . . . . 29
3.2 PHOTO VIEWER .........................................30
3.3 PHOTO VIEWER SETTINGS ................................32
3.4 PLAYING A SLIDESHOW ..................................33
3.5 VIEWING PHOTOS WHILE LISTENING TO MUSIC . . . . . . . . . . . . . . . 33
3.6 PUTTING PHOTOS ONTO YOUR ARCHOS . . . . . . . . . . . . . . . . . . . . . . 34
3.7 PLAYING YOUR PC’S SHARED PHOTOS . . . . . . . . . . . . . . . . . . . . . . 34
4. USING THE FILE BROWSER ......................................................35
4.1 NAVIGATION ...........................................35
4.2 USING THE VIRTUAL KEYBOARD . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
4.3 USING THE FILE BROWSER WHILE LISTENING TO MUSIC . . . . . . . . 38
4.4 BROWSING OTHER COMPUTERS ON THE NETWORK . . . . . . . . . . . . 39
4.5 USING THE PDF READER .................................39
TABLE OF CONTENTS CONTINUED ON NEXT PAGE...
MANUAL
V2.0
GEN 5 TABLE OF CONTENTS > P. 3
5. CONNECTING TO A WIFI NETWORK .....................................42
5.1 WIFI CONNECTION PROCEDURE . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
5.2 WIFI NETWORK CONFIGURATION . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
6. THE WIFI FEATURES ................................................................... 46
6.1 BROWSING THE WEB ....................................46
6.2 PLAYING YOUR PC’S SHARED MEDIA FILES . . . . . . . . . . . . . . . . . . 48
6.3 THE ARCHOS CONTENT PORTAL. . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
7. TRANSFERRING FILES .................................................................52
7.1 CONNECTING THE ARCHOS TO A COMPUTER . . . . . . . . . . . . . . . . . 52
7.2 PUTTING FILES ONTO THE ARCHOS . . . . . . . . . . . . . . . . . . . . . . . . . 52
7.3 DISCONNECTING ........................................53
8. MAIN SETTINGS ..............................................................................55
8.1 “SOUND” SETTINGS .....................................55
8.2 “DISPLAY” SETTINGS ....................................57
8.3 “APPEARANCE” SETTINGS ................................58
8.4 “LANGUAGE (AND REGION)” SETTINGS . . . . . . . . . . . . . . . . . . . . . . 59
8.5 “TV CONTROL” SETTINGS ................................59
8.6 “CLOCK” SETTINGS .....................................60
8.7 “POWER” SETTINGS .....................................61
8.8 “FIRMWARE AND PLUG-INS” SETTINGS . . . . . . . . . . . . . . . . . . . . . 62
8.9 UPDATING THE FIRMWARE ................................63
8.10 “SYSTEM” SETTINGS ...................................64
9. OPTIONAL FUNCTIONALITIES ..................................................66
9.1 ARCHOS ACCESSORIES ..................................66
9.2 ARCHOS PLUG-INS ......................................67
9.3 SCHEDULING A TV RECORDING . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
9.4 RECORDING EXTERNAL VIDEO MANUALLY . . . . . . . . . . . . . . . . . . . 68
9.5 RECORDING EXTERNAL AUDIO MANUALLY . . . . . . . . . . . . . . . . . . . 69
9.6 DISPLAYING THE ARCHOS ON A TV . . . . . . . . . . . . . . . . . . . . . . . . . 69
9.7 EDITING VIDEO FILES ....................................69
TROUBLESHOOTING ..........................................................................72
RESETTING YOUR ARCHOS ..................................72
SYSTEM RECOVERY ........................................72
TOUCHSCREEN PROBLEMS ..................................73
REPAIR AND FORMATTING TOOLS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
TECHNICAL SPECIFICATIONS ........................................................75
TECHNICAL SUPPORT INFORMATION ......................................78
MANUAL
V2.0
GEN 5 INTRODUCTION > P. 4
INTRODUCTION
The information presented in this manual might vary ac-
cording to which ARCHOS Gen 5 model you have.
Every time you see one of these icons, it means that the
following section will only concern this and only this
model.
•
•
405
605
ARCHOS DESCRIPTION
MAIN BUTTONS
On top of the device:
ARCHOS 605 WiFi
Press and hold to turn your ARCHOS on/off.*
The LED indicator, located on the right of the button, lights up when the
device is on.
•
•
* When you press this button to turn off the ARCHOS, your device will keep
using a small amount of battery power to allow a quick start up.
If you do not plan on using the ARCHOS for an extended period of time, you
should turn it off completely, so that there is absolutely no battery usage. See
“Power” Settings.
TV/
LCD
Press once to switch the display of the image between the built-in LCD
screen and a TV (with the optional DVR Station Gen 5, Mini Dock or Battery
Dock, available at www.archos.com). See
Optional Functionalities
.
When the image is displayed on a TV, the TV/LCD LED indicator lights up
and the built-in LCD screen turns off.
Press and hold to lock/unlock your device’s buttons/touchscreen. This can
be useful if your ARCHOS is in your pocket, for example, and you do not
want to press a button or touch the screen by accident.
•
•
•
MANUAL
V2.0
GEN 5 INTRODUCTION > P. 5
LED INDICATORS
405
On top of the device:
605
On the left side of the device*:
* On the high capacity ARCHOS 605, the LED indicators are located on top of
the device, next to the buttons.
CHG Battery charge indicator.
light on: the battery is charging
ashing: the battery is fully charged
•
•
HDD Hard Disk Drive activity indicator
(depending on model)
:
the light ickers when the hard drive is active (playing/transferring les) •
TV/
LCD
Video display indicator:
the light is on when the image of the ARCHOS is displayed on a TV (see TV/
LCD button).
•
CONNECTORS
On the left side of the device:
Headphone jack: to connect headphones
Underneath the device:
These connectors allow you to:
Connect your ARCHOS to a computer (see
Connecting the ARCHOS to a Computer
)
Charge the battery of your ARCHOS (see
First Time usage: Charging the Battery
).
The Docking connectors also allow you to plug one of our
optional accessories (available from www.archos.com):
Connect a compatible USB device to the ARCHOS, with the optional DVR
Station Gen 5, Mini dock or Battery Dock.
Record external audio/video, with the optional DVR Station Gen 5 or DVR
Travel Adapter.
See Optional Functionalities.
•
•
•
•
•
MANUAL
V2.0
GEN 5 INTRODUCTION > P. 6
605
BUILT-IN LOUDSPEAKER
On the right side of the device, below the buttons
605
LEG STAND
Your ARCHOS is equipped with a leg stand, located on the back of the device.
Carefully pull it out, and it will allow your ARCHOS to stand by itself on a at,
stable surface.
MEMORY CARD SLOT
(depending on model)
The memory card slot, located on top of the device, on the right
side, allows you to insert one of the following cards (which are
not supplied):
SD
MMC
Mini and micro SD (with adapter)
RS MMC (with adapter)
•
•
•
•
To learn how to browse the contents of your card, see: Browsing Through
your Videos, Browsing Through your Music Files, Browsing Through your
Photos or Using the File Browser.
FIRST TIME USAGE: CHARGING THE BATTERY
Before using your ARCHOS for the rst time, completely charge its battery. The bat-
tery of your ARCHOS charges via your computer’s USB port:
Plug the ARCHOS USB cable into your ARCHOS (which is off).
Plug the USB end of the cable into your computer (which is turned on).
The ARCHOS will turn on and start charging:
A lightning bolt symbol will ash over the battery icon in the task bar while
the battery is charging: .
The CHG indicator LED is on while the battery is charging. It will blink when
the battery is fully charged.
You can also charge your ARCHOS device without a computer, and more rap-
idly, via the optional DVR Station Gen 5, Mini Dock or Battery Dock (available
at www.archos.com). See Optional Functionalities.
•
•
1.
2.
3.
-
-
MANUAL
V2.0
GEN 5 INTRODUCTION > P. 7
TURNING THE ARCHOS ON/OFF
ARCHOS 605 WiFi
Press and hold the button to turn your ARCHOS on/off. See
ARCHOS Description
.
The LED indicator, next to the button, lights up when the device is on.
USING THE ARCHOS INTERFACE
INTERFACE DESCRIPTION
Status Bar
In the top right corner of the screen, the status
bar indicates the volume, the battery level and
the current time of your device.
•
Tabs
In the top left corner of the screen, the tabs area
shows other available applications and screens. They
vary, depending on where you are in the interface.
When there is only one tab available, the Tab icon
in the top left corner is grayed out.
•
•
Contextual Menu
In the lower right corner of the screen, the contextual menu area
shows the menu icons. The available options will vary, depending on
where you are in the interface.
In the Home screen, choose the “Settings” menu item to access
the main settings of your ARCHOS.
In the Home screen, the “Resume” menu item allows you to re-
sume the last-played music or video le, if it was interrupted before
the end. If the “Resume” menu icon does not appear, it means that
no music or video le playback can be resumed.
•
•
•
(depending
on model)
•
•
MANUAL
V2.0
GEN 5 INTRODUCTION > P. 8
(depending on model)
Home Screen
This is the main screen of your ARCHOS, showing
its main functions.
•
605
USING THE TOUCHSCREEN
Your ARCHOS is equipped with a touchscreen. Below is a description of the
main tactile screen areas and a few tips on how to use the touchscreen.
In order to avoid damaging the screen surface, you should use only the in-
cluded stylus or your ngernail.
Main Touchscreen Actions
To open an application/screen via its icon or item, tap on the icon/item to high-
light it, and tap on it again.
In the different applications, you can go back one level in the hierarchy by tapping
on the Exit icon (in the top right corner of the screen). Wherever you are in the
hierarchy, you can go back directly to the Home screen by tapping and holding
the Exit icon.
When several tabs are available, you can switch between them by tapping on the
Tab icon (in the top left corner of the screen). You can also tap directly on one
of the tabs to access the corresponding screen.
To execute a menu item’s function, simply tap on its icon. In order to display a
text description of the icon, tap on the menu word.
While playing a video or song, you can pause/resume it by tapping on the Pause
/ Play icon.
Other Touchscreen Actions
When watching a video or listening to music, you can tap on the progres-
sion bar to go directly to a different location in the video or song. You can
also use the stylus to drag the cursor in the progression bar to another loca-
tion in the video or song.
In the screens where it appears, the volume bar can be dragged in the same way.
In the different browsers (File, Music, Video, Photo), you can drag the scroll
bar up and down to scroll the le list up and down. You can also scroll faster
by tapping above or below the cursor in the scroll bar.
•
•
•
•
•
•
•
•
MANUAL
V2.0
GEN 5 INTRODUCTION > P. 9
In the Web browser and the PDF viewer, you can scroll up and down by tapping
on the page and dragging it up or down (be careful however not to tap on a link!).
USING THE BUTTONS
The navigation buttons are located on the right side of the device:
Exit button
(Escape / Back / Stop)
OK button
(Enter/Accept or Play/Pause/Resume)
Up Accelerator button
(high-speed fast forward, list scrolling or zoom in)
Navigation buttons
(move from an item to another)
Down Accelerator button
(high-speed fast rewind, list scrolling or zoom out)
Tab button
(tab between available screens)
Menu button
(display a text description of the available menu icons)
Volume button
(increase/decrease volume)
Main Button Actions:
To open an application/screen via its icon or item, use the Navigation buttons to
highlight the icon/item and press OK.
In the different applications, you can go back one level in the hierarchy by press-
ing the Exit button once. Wherever you are in the hierarchy, you can go back
directly to the Home screen by holding the Exit button.
When several tabs are available, you can switch between them by pressing the
Tab button .
To execute a menu icon’s function, press the menu button, select a menu item
with the navigation pad, and press OK.
While playing a video, song or photo slideshow, you can pause/resume it by
pressing OK.
•
•
•
•
•
•
MANUAL
V2.0
GEN 5 INTRODUCTION > P. 10
Other Button Actions
When watching a video or listening to music, you can hold the left/right
Navigation buttons to move the cursor in the progression bar to another
location in the video or song.
To increase/decrease volume, use the Volume button .
In the different browsers (File, Music, Video, Photo), you can hold the up/
down Navigation buttons to scroll the le list up and down. You can also
scroll faster by using the Accelerator buttons.
In the Web browser
(depending on model)
and the PDF viewer, you can
scroll up and down by holding the up/down Navigation buttons.
•
•
•
•
CHANGING THE LANGUAGE
The interface of your ARCHOS is available in various languages.
If your language is not available, go to the ARCHOS website (www.
archos.com/rmware) and download and install the latest version
of the rmware. New languages are included in the rmware as they
become available. See
Updating the Firmware
.
•
•
To change the system’s language:
In the Home screen, select the “Settings” menu item, and choose “Language
(and Region)”.
Select a different language using
the left/right arrows (your settings
are saved instantly).
2.
Close the screen to exit and go back to the Home screen.
PRODUCT CARE
Your ARCHOS is an electronic product that needs to be treated with care:
Do not subject it to unnecessary shock or vibration.
Do not subject it to heat, keep it ventilated (especially when connected to a computer).
Keep it away from water and excessively humid areas.
Keep it away from high electromagnetic elds.
Do not open it up. There are no user-serviceable parts inside. Opening will void
your warranty.
1.
3.
•
•
•
•
•
MANUAL
V2.0
GEN 5 PLAYING VIDEO > P. 11
1. PLAYING VIDEO
In the Home screen, select the “Video” icon to enter the Video mode.
1.1 BROWSING THROUGH YOUR VIDEOS
The “Video” browser allows you to navigate through the Video folder of the
ARCHOS’ hard drive.
You can go back one level in the hierarchy by closing the current screen .
Wherever you are in the hierarchy, you can go back directly to the Home screen
by pressing and holding the Exit icon/button.
THE VIDEO BROWSER
The rst screen of the Video mode
shows you all the videos and sub-
folders located in the Video folder.
To play a video, highlight it, then
open it.
If a video is in a subfolder of the
Video folder, open the subfolder, and
you will see your video.
•
•
•
In the “Video” browser, each video le appears with a thumbnail, displayed
on the left of the le’s name.
To dene a new thumbnail for a video le, open the video, select the “Set”
menu item, and choose “Thumbnail” (see: Video Playback Menu Items).
•
•
BROWSING THROUGH YOUR MEMORY CARD’S VIDEOS
(Depending on model)
If you have inserted a memory card into the ARCHOS (see:
Memory Card Slot
),
select the line “SD/MMC card”, in the rst screen of the “Video” Browser.
You can now browse the contents of your card and play your videos (if your card
contains any). In the Video browser, only video les and folders will appear.
•
•
•
•
MANUAL
V2.0
GEN 5 PLAYING VIDEO > P. 12
VIDEO BROWSER MENU ITEMS
“Info”
displays a message box with information about the highlighted video le.-
“File Management”
“Rename”: allows you to change the name of the highlighted video le using
the virtual keyboard. See:
Using the Virtual Keyboard
.
“Delete”: allows you to delete the highlighted video le. A conrmation
screen will pop up.
-
-
“Bookmark”
“Resume”: will resume playing the highlighted video from the bookmark.
“Clear”: will remove the bookmark from the highlighted video le.
-
-
“Bookmark” only appears in the menu when a bookmarked video le is high-
lighted.
“Settings”
you can choose to display the Video Player settings screen (see:
Video Player
Settings
) or the “Sound” settings screen (see:
“Sound” Settings
).
-
1.2 VIDEO PLAYBACK
To play a video, highlight the le and open it. The menu overlay will disappear auto-
matically after a few seconds.
VIDEO PLAYBACK SCREEN
1. Exit icon
2. video le name
3. Tab icon
4. volume level
5. play / pause icon
6. video progression bar
7. menu items
MANUAL
V2.0
GEN 5 PLAYING VIDEO > P. 13
605
VIDEO PLAYBACK TOUCHSCREEN CONTROLS
To pause/resume the video, tap on the Pause / Play icon (see n° 5 in the
previous screen).
To display the menu overlay again, tap once anywhere on the screen. To make it
disappear again, wait for a few seconds or tap on the Tab icon , in the top left
corner (see n° 3).
You can tap on the progression bar to go directly to a different location in the vid-
eo. You can also use the stylus to drag the cursor in the progression bar to another
location in the video (see n° 6).
The volume bar can be dragged in the same way (see n° 4).
To execute a menu item’s function, simply tap on its icon. In order to display a
text description of the icon, tap on the menu word (see n° 7).
To stop the video and go back to the “Video” browser, tap on the Exit icon
(see n° 1).
To exit the Video mode and go back directly to the Home screen, tap
and hold the Exit icon.
VIDEO PLAYBACK BUTTON CONTROLS
press once: stop the video and go back to the
“Video” browser
hold: exit the Video mode and go back directly to
the Home screen.
-
-
pause/resume the video
accelerated fast forward
left/right: fast rewind/forward
accelerated fast rewind
display/hide the menu overlay
display available menu items
increase/decrease volume
VIDEO PLAYBACK MENU ITEMS
“Info”
displays a message box with information about the current video le.-
•
•
•
•
•
•
MANUAL
V2.0
GEN 5 PLAYING VIDEO > P. 14
“Soundtrack” and/or “Subtitles”
allows you to select a different audio track (only if the video le contains sev-
eral audio tracks).
allows you to choose subtitles (only if the video le includes subtitles).
-
-
This menu item only appears in the menu if the video le includes subtitles or
several audio tracks.
“Format”
allows you to change the way the image is displayed.
“Auto”: adjusts the video size to best adapt to the built-in screen (or TV, with the op-
tional DVR Station Gen 5, Mini Dock or Battery Dock: see
Optional Functionalities
).
“Full Screen”: enlarges the picture to ll the screen. In order to t the
ARCHOS’ screen, your device might need to cut small parts of the image,
most likely at the top and bottom.
“Maximized”: enlarges the picture to ll the screen, considering the image is
encoded in 2.35 format with black bands at the top and bottom.
“Original”: displays the entire picture in its original format.
-
-
-
-
-
“Speed”
will play the current video in slow motion or high speed.
while paused in slow motion, you can advance frame by frame, using the right
arrow.
-
-
“Set”
“Bookmark”: sets a bookmark at the current spot in the video. Only one
bookmark per le is allowed. You can bookmark up to 32 les. Bookmarked
videos will appear, in the “Video” browser, with a bookmark symbol and a
progression bar.
to resume playing a video from a bookmark, go to the “Video” browser and
highlight the bookmarked video le. Select the “Bookmark” menu item, then
choose “Resume” (“Clear” will remove the bookmark from the video).
“Thumbnail”: saves the current image as a new thumbnail for this le. In the
“Video” browser, the video’s thumbnail will be replaced by the new one.
“Wallpaper”: the current image will be dened as your device’s background
image.
-
-
-
-
“Settings”
you can choose to display the Video Player settings screen (see:
Video Player
Settings
) or the “Sound” settings screen (see:
“Sound” Settings
).
-
MANUAL
V2.0
GEN 5 PLAYING VIDEO > P. 15
1.3 VIDEO PLAYER SETTINGS
In the Video mode, you can access the Video Player settings screen by using the
“Settings” menu item .
Use the left/right arrows to select a different setting for a parameter.
“PlayMode”, “Repeat & Shufe”
the following table explains how the video player will work according to the set-
tings you chose in “PlayMode” AND “Repeat & Shufe”.
“PlayMode” “Repeat &
Shufe” What the video player does...
“Single” “Normal”plays the current video le and stops.-
“Repeat”plays the current video le repeatedly.-
“Folder”“Normal”plays all the video les of the current folder
one after the other, and then stops.
-
“Repeat”plays all the video les of the current folder
one after the other. This will be repeated in-
denitely.
-
“Shufe” plays all the videos of the current folder ran-
domly.
-
605 “Network thumbnails (UPnP)”
here you can enable/disable the video thumbnails while browsing through your
PC’s shared videos (see:
Playing your PC’s Shared Media Files
). If you choose
“Disabled”, you will be able to browse through your PC’s shared videos faster.
•
•
-
-
MANUAL
V2.0
GEN 5 PLAYING VIDEO > P. 16
“LCD Backlight”, “Brightness”, “Contrast” and “Gamma”
adjusts the level of backlight/contrast/brightness/gamma of the built-in screen.
you can also reset the LCD parameters to the default values (“Reset” button).
1.4 PUTTING VIDEOS ONTO YOUR ARCHOS
605 On the ARCHOS Content Portal, you have the possibility to purchase
videos directly from your ARCHOS, without using a computer. See:
The ARCHOS Content Portal.
There are two main methods to transfer the videos stored on your computer onto the
ARCHOS:
Windows Media® Player: copy your videos using Windows Media® Player 10 or
higher*:
Use Windows Media® Player 10 or higher* (Sync tab) to synchronize
your computer’s video les with the ARCHOS.
See
Putting Files onto the ARCHOS
to learn more about how to transfer
your computer’s video les with Windows Media® Player.
-
-
* For best performance, we recommend that users update to Windows Media®
Player 11 or higher.
Windows® Explorer: Copy and paste your video les from your computer into the
Video folder of your ARCHOS.
To learn how to connect/disconnect the ARCHOS from your computer, see the
Transferring Files
section.
CREATING COMPATIBLE VIDEO FILES WITH YOUR COMPUTER
If some of your videos don’t play on your ARCHOS, you may need to transcode them
to a compatible format:
The easiest way to do this is by using Windows Media® Player 10 or higher to
transfer videos to your ARCHOS. Windows Media® Player will automatically con-
vert most formats to the WMV format that your device can play.
See your Windows Media
®
Player help instructions for more information.
If you don’t want to use Windows Media® Player, a search on the Internet should
allow you to nd suitable utility programs to do this job.
If you would like to simply copy and paste unprotected DVD video les from
your PC onto your ARCHOS without converting them to WMV format, you can
-
-
1.
2.
•
•
•
MANUAL
V2.0
GEN 5 PLAYING VIDEO > P. 17
purchase the Cinema plug-in from the ARCHOS website (www.archos.com). The
same is also true for video podcasts in the H.264 format. In this case, purchase
the Video Podcast plug-in.
1.5 RECORDING VIDEO
With the optional DVR Station Gen 5, DVR Travel Adapter, or
Helmet CamCorder (available at www.archos.com), your ARCHOS
will be able to record video from most any standard video source.
See:
Optional Functionalities
.
•
•
With the optional DVR Station Gen 5, you will also have the pos-
sibility to schedule TV recordings easily, via the TV Program Guide
(EPG).
See the manual of your DVR Station Gen 5 to learn more about this
feature.
•
•
DVR TRAVEL ADAPTER DVR STATION GEN 5
605 1.6 PLAYING YOUR PC’S SHARED VIDEOS
When connected to your home WiFi network, your ARCHOS gives
you the possibility to watch, directly on your device, shared videos
stored in your PC’s Windows Media® Library.
For this to work, you will need a WiFi connection and Windows
Media® Player 11 or higher* installed on your PC.
The ARCHOS uses the UPnP (Universal Plug-and-play) standard to
stream shared videos from your PC’s Windows Media® Library.
See:
Playing your PC’s Shared Media Files
.
•
•
•
•
* There are other products on the market that also can share media les using
the UPnP standard.
MANUAL
V2.0
GEN 5 PLAYING MUSIC > P. 18
2. PLAYING MUSIC
In the Home screen, select the “Music” icon to enter the Music mode.
2.1 BROWSING THROUGH YOUR MUSIC FILES
There are two types of views for you to browse through your songs: the Music
Library and the Music Browser.
In both views, you can go back one level in the hierarchy by closing the current
screen . Wherever you are in the hierarchy, you can go back directly to the
Home screen by pressing and holding the Exit icon/button.
THE MUSIC LIBRARY
The Music Library (default view)
shows your music sorted by cat-
egories (Artist, Album, Genre, etc.) if
your music les contain these song
information tags.
When new music is copied to the
ARCHOS, the Music Library will be
updated automatically.
If some of your music les do not
contain information tags, they will
be classied as (Unknown) in the
Music Library.
•
•
•
THE MUSIC BROWSER
The music browser allows you to
navigate through the Music folder
of your device’s hard drive.
To use it, select “Browse Hard
Drive” in the initial Music Library
view.
•
•
•
•
MANUAL
V2.0
GEN 5 PLAYING MUSIC > P. 19
BROWSING THROUGH YOUR MEMORY CARD’S SONGS
(Depending on model)
If you have inserted a memory card into the ARCHOS (see:
Memory Card Slot
),
select the line “SD/MMC card”, in the initial Music Library view.
You can now browse the contents of your card and play your songs (if your card
contains any). In Music mode, only music les, playlists and folders will appear.
When you insert a memory card, its contents (songs and playlists) are auto-
matically integrated into the Music library.
MUSIC LIBRARY AND MUSIC BROWSER MENU ITEMS*
“Info”
displays a message box with information about the highlighted music le.-
“Show playlist”
opens a playlist edition window on the right (see:
Playlists
).-
“Bookmark”
“Resume”: will resume playing the highlighted song from the bookmark.
“Clear”: will remove the bookmark from the highlighted music le.
-
-
“Bookmark” only appears in the menu when a bookmarked music le is high-
lighted.
“File Management”
“Rename”: allows you to change the name of the highlighted music le using
the virtual keyboard. See:
Using the Virtual Keyboard
.
“Delete”: allows you to delete the highlighted music le. A conrmation
screen will pop up.
-
-
“Settings”
you can choose to display the Music Player settings screen (see:
Music Player
Settings
) or the “Sound” settings screen (see:
“Sound” Settings
).
-
* The available menu items will vary depending on the mode you chose (Music
Library or Music Browser).
•
•
MANUAL
V2.0
GEN 5 PLAYING MUSIC > P. 20
2.2 MUSIC PLAYBACK
Use the scroll bar to browse through the list of audio tracks.
To play a song, highlight the corresponding le and open it.
MUSIC PLAYBACK SCREEN
1. Exit icon
2. artist name, album
title, song title, play-
back status icon(s)
and track number
3. available tabs
4. volume level
5. play / pause icon
6. previous track
7. next track
8. progression bar
9. menu items
605
MUSIC PLAYBACK TOUCHSCREEN CONTROLS
To pause/resume the song, tap on the Pause / Play icon (see n° 5 above).
To play the previous/next song, tap in the corresponding area (n° 6 or 7).
To browse through your songs while listening to music, simply tap on the Tab icon
. This will take you to the Music Library or browser screen that you launched
the current song from (see n° 3).
You can tap on the progression bar to go directly to a different location in the
song. You can also drag the cursor in the progression bar to another location in
the song (see n° 8).
The volume bar can be dragged in the same way (see n° 4).
To execute a menu item’s function, simply tap on its icon. In order to display a
text description of the icon, tap on the menu word (see n° 9).
To stop the song and go back to the Music Library or browser, tap on the Exit icon
(see n° 1). To exit the Music mode and go back directly to the Home screen, tap
and hold the Exit icon.
•
•
•
•
•
•
•
•
•
MANUAL
V2.0
GEN 5 PLAYING MUSIC > P. 21
MUSIC PLAYBACK BUTTON CONTROLS
press once: stop the song
and go back to the
“Music”
Library or browser
hold: exit the Music mode and go back directly to
the Home screen.
-
-
pause/resume the video
accelerated fast forward
left:
press once: back to the beginning of the song, or
previous song (in the rst 10 seconds of a track)
hold: fast rewind
right:
press once: next song
hold: fast forward
-
-
-
-
accelerated fast rewind
tabs back to the Music Library or Music browser (de-
pending on which mode you launched the song from)
display available menu items
increase/decrease volume
MUSIC PLAYBACK MENU ITEMS
“Info”
displays a message box with information about the current music le.-
“ARCHOS home screen”
allows you to go back to the Home screen, and browse your hard drive or
view your photos while listening to music.
-
“Set bookmark”
sets a bookmark at the current spot in the song. Only one bookmark per le is
allowed. You can bookmark up to 32 les.
to resume playing a song from a bookmark, go to the Music Library or the Music
Browser, highlight the bookmarked music le. Select the “Bookmark” menu
item, then choose “Resume” (“Clear” will remove the bookmark from the song).
-
-
MANUAL
V2.0
GEN 5 PLAYING MUSIC > P. 22
“Set rating”
allows you to give a rating to the current song (1-5) or to remove the rating
(none).
-
“Settings”
you can choose to display the Music Player settings screen (see next section)
or the “Sound” settings screen (see:
“Sound” Settings
).
-
2.3 MUSIC PLAYER SETTINGS
In the Music mode, you can access the Music Player settings screen by using the
“Settings” menu item .
Use the left/right arrows to select a different setting for a parameter.
“PlayMode”, “Repeat & Shufe”
the following table explains how the audio player will work according to the set-
tings you chose in “PlayMode” AND “Repeat & Shufe”.
An icon shows the current modes in the Music playback screen.
“PlayMode” “Repeat &
Shufe” What the video player does...
“Single”“Normal” plays the current song and stop.-
“Repeat” plays the current song repeatedly.-
Table continued on next page...
•
•
-
-
MANUAL
V2.0
GEN 5 PLAYING MUSIC > P. 23
“PlayMode” “Repeat &
Shufe” What the video player does...
“Folder”“Normal” plays all the songs of the current folder one
after the other, and then stops.
-
“Repeat” plays all the songs of the current folder one
after the other. This will be repeated inde-
nitely.
-
“Shufe” plays the songs of the current folder ran-
domly.
-
“All”“Normal”plays all the songs of your ARCHOS one
after the other, and then stops.
-
“Repeat” plays all the songs of your ARCHOS one
after the other. This will be repeated inde-
nitely.
-
“Shufe” plays all the songs of your ARCHOS ran-
domly.
-
“Queue”allows you to select a track to be played after the current one
is nished.
while a track is playing, switch to the browser window, select
a track to highlight it, then open it. This is your queued track,
which will be played after the current track.
you can only queue one track at a time, and you need to se-
lect the song to queue before the end of the current track.
-
-
-
“Intro”plays the rst few seconds of each track. You can dene the
length to play in “Intro duration”. Press OK during the intro
period to let the whole song play.
-
“Intro duration”
denes for how long each track will be played when “PlayMode” is set to “Intro”.-
MANUAL
V2.0
GEN 5 PLAYING MUSIC > P. 24
2.4 PLAYLISTS
A playlist is a list of audio tracks that the music player will automatically
play one after the other.
On your ARCHOS, you can play, create and edit as many playlists as you want.
In the ARCHOS Browser, playlists are the les with the icon.
•
•
•
Note: when you delete a playlist, you are only deleting the list and not the mu-
sic itself.
PLAYING A PLAYLIST
In the Music Library, highlight the
“Playlist” line and open it.
Highlight a playlist and open it. A
panel showing the contents of the
playlist will open on the right.
Open the rst item in the playlist to
start playing from the rst track.
•
•
•
PLAYLIST MENU ITEMS
These menu items appear when a music le is highlighted on the left panel:
“Add to playlist”
“Selected le”: will add the highlighted track at the end of the current playlist.
“All les”: will add all the tracks (from the left panel) at the end of the current
playlist.
-
-
“Insert in playlist”
“Selected le”: will insert the highlighted track before the selected item in
the current playlist.
“All les”: will add all the tracks (from the left panel) before the selected
item the current playlist.
-
-
These menu items appear when the focus is on the right panel (playlist editor):
“Track”
“Remove track”: deletes the highlighted track from the playlist.
“Move”: allows you to change the position of the highlighted track within the
playlist. Highlight the track you want to move, select the “Track” menu item,
then choose “Move”. Now highlight the position to which you want to move
the track and validate.
-
-
MANUAL
V2.0
GEN 5 PLAYING MUSIC > P. 25
“Playlist”
“Clear”: clears the current playlist.
“Shufe”: randomly shufes the order of the songs in the current playlist.
-
-
“Save playlist”
“Save”: saves the current playlist to the Playlists folder.
“Save As”: same as “Save”, but it also allows you to give a personalized name
to the playlist. See:
Using the Virtual Keyboard
.
-
-
“Hide playlist”
closes the playlist editor.-
“Settings”
you can choose to display the Music Player settings screen (see
Music Player
Settings
) or the “Sound” settings screen (see:
“Sound” Settings
).
-
CREATING A NEW PLAYLIST
While you are in the Music browser, select the “Show playlist” menu item. A
playlist panel will open on the right. By default, the new playlist contains the
same songs as the last opened playlist. You can now start modifying the playlist.
In the left panel, locate the songs you would like to add to your playlist. Highlight
a song and open it to add it to the playlist. Repeat this operation with all the
tracks you want.
To add all the songs of a folder to a playlist: open the folder in the left panel
and highlight the rst song. Then use the “Add to playlist” or “Insert in playl-
ist” menu item and choose “All les”.
When you are satised with your new playlist, select the “Save playlist” menu
item, and then choose “Save as”.
Enter the name of your new playlist with the virtual keyboard (see:
Using the
Virtual Keyboard
) and select “OK”.
Use the tabs to jump back and forth between the left and right panels.
EDITING A PLAYLIST
To edit an existing playlist:
In the Music Library, highlight the “Playlist” line and open it.
1.
2.
3.
4.
1.
MANUAL
V2.0
GEN 5 PLAYING MUSIC > P. 26
Highlight the playlist you want to modify and open it. A panel showing the con-
tents of the playlist will open on the right.
You can now add, shufe, move or remove tracks within the playlist, using the
appropriate menu items. The available menu items will vary according to which
panel you selected (see:
Playlist Menu Items
).
After you have made the changes you want, select the “Save playlist” menu item
and choose “Save” to save the playlist. If you wish to give it a different name,
choose “Save As”.
ADDING SONGS TO A PLAYLIST WHILE LISTENING TO MUSIC
While playing a song, use the tab button/icon to go back to the Music Library or
Music Browser, and select the “Show playlist” menu item.
Your window will then have two panels: the music les on the left and the last-
opened playlist on the right.
While listening to your song, you can edit the last-opened playlist.
Close the playlist editor to return to the playback screen.
Please note: this can only be done if you have entered the Music folder via the
“Music” icon in the Home screen and not via the “Files” icon.
2.5 PUTTING MUSIC ONTO YOUR ARCHOS
There are two main methods to transfer the music stored on your computer onto the
ARCHOS:
Windows Media® Player: copy your music using Windows Media® Player 10 or
higher*:
Use Windows Media® Player 10 or higher* (Sync tab) to synchronize
your computer’s music les with the ARCHOS.
See
Putting Files onto the ARCHOS
to learn more about how to transfer
your computer’s music les with Windows Media® Player.
-
-
* For best performance, we recommend that users update to Windows Media®
Player 11 or higher.
Windows® Explorer: Copy and paste your music les from your computer into the
Video folder of your ARCHOS.
To learn how to connect/disconnect the ARCHOS from your computer, see the
Transferring Files
section.
2.
3.
4.
1.
2.
3.
4.
1.
2.
MANUAL
V2.0
GEN 5 PLAYING MUSIC > P. 27
TRANSFERRING YOUR CD COLLECTION TO YOUR ARCHOS
You can easily create audio content with your computer by using Windows Media®
Player 10 or higher to convert your own CDs to MP3 or WMA format:
Place a music CD in your computer, and
Windows® will ask you what action you would
like to perform.
Choose Rip music from CD, and Windows
Media® Player will start ripping the CD. The
songs will be automatically extracted from the
CD and encoded into the MP3 or WMA for-
mat, according to what you chose in Windows
Media® Player’s ripping options. The default
format is WMA.
Once this is done, the album will become part
of your Music Library.
See
Transferring Files
to learn how to transfer
the ripped music les onto the ARCHOS.
See your Windows Media® Player help instructions
for more information.
1.
2.
3.
4.
Check the laws and regulations in your country or jurisdiction to know if pri-
vate copying of your CDs for your own use is authorized.
Some music CDs have a special copy protection system that will not allow
Windows Media® Player to make music les from them.
•
•
2.6 RECORDING ANALOGUE AUDIO
With the optional DVR Station Gen 5 or DVR Travel Adapter (avail-
able at www.archos.com), your ARCHOS will be able to record audio
from most any standard line level analogue audio source.
See:
Optional Functionalities
.
•
•
DVR TRAVEL ADAPTER DVR STATION GEN 5
MANUAL
V2.0
GEN 5 PLAYING MUSIC > P. 28
605 2.7 PLAYING YOUR PC’S SHARED MUSIC
When connected to your home WiFi network, your ARCHOS gives
you the possibility to play, directly on your device, shared music
stored in your PC’s Windows Media® Library.
For this to work, you will need a WiFi connection and Windows
Media® Player 11 or higher* installed on your PC.
The ARCHOS uses the UPnP (Universal Plug-and-play) standard to
stream shared music from your PC’s Windows Media® Library.
See:
Playing your PC’s Shared Media Files
.
•
•
•
•
* There are other products on the market that also can share media les using
the UPnP standard.
MANUAL
V2.0
GEN 5 VIEWING PHOTOS > P. 29
3. VIEWING PHOTOS
In the Home screen, select the “Photo” icon to enter the Photo viewer.
3.1 BROWSING THROUGH YOUR PHOTOS
The “Photo” browser allows you to navigate through the Pictures folder of the
ARCHOS’ hard drive.
You can go back one level in the hierarchy by closing the current screen .
Wherever you are in the hierarchy, you can go back directly to the Home screen
by pressing and holding the Exit icon/button.
THE PHOTO BROWSER
The rst screen of the Photo mode
shows all the photos and subfolders
located in the Pictures folder.
To view a photo, highlight its
thumbnail, then open it. If a photo is
in a subfolder of the Pictures folder,
open the subfolder, and you will see
your photo.
The Photo Browser also allows you
to view your pictures, sorted by
date.
•
•
•
In the “Photo” browser each photo is displayed with a thumbnail.
BROWSING THROUGH YOUR MEMORY CARD’S PHOTOS
(Depending on model)
If you have inserted a memory card into the ARCHOS (see:
Memory Card Slot
),
select the line “SD/MMC card”, in the rst screen of the Photo mode.
You can now browse the contents of your card and view your photos (if your card
contains any). In Photo mode, only picture les and folders will appear.
When you insert a memory card, its contents (pictures) are automatically inte-
grated into the Photo library (“All by date” and Browse by date” views).
•
•
•
•
MANUAL
V2.0
GEN 5 VIEWING PHOTOS > P. 30
PHOTO BROWSER MENU ITEMS*
“Info”
displays a message box with information about the highlighted picture.-
“Delete”
allows you to delete the highlighted picture. A conrmation screen will pop
up.
-
“Start slideshow”
starts a slideshow from the highlighted image.
the “Pause slideshow” menu item will appear, allowing you to pause the
slideshow.
-
-
“Settings”
will display the Photo viewer settings screen (see
Photo Viewer Settings
).-
* The available menu items will vary depending on where you are in the
“Photo” Browser.
3.2 PHOTO VIEWER
To view a picture, highlight the corresponding thumbnail and open it. The menu over-
lay will disappear automatically after a few seconds.
PHOTO VIEWER SCREEN
MANUAL
V2.0
GEN 5 VIEWING PHOTOS > P. 31
605
PHOTO VIEWER TOUCHSCREEN CONTROLS
To display the menu overlay again, tap once anywhere on the screen. To make it dis-
appear again, wait for a few seconds or tap on the Tab icon , in the top left corner.
To display the next picture, drag the stylus (anywhere on the screen) from left to
right. Drag from right to left to go back one picture.
To rotate the picture 90° counterclockwise, drag the stylus (anywhere on the
screen) from bottom to top. To rotate the picture 90° clockwise, drag from top to
bottom.
To execute a menu item’s function, simply tap on its icon. In order to display a
text description of the icon, tap on the menu word.
To close the picture and go back to the “Photo” browser, tap on .
To exit the
Photo mode and go back directly to the Home screen, tap and hold the Exit icon.
PHOTO VIEWER BUTTON CONTROLS
press once: close the photo viewer and go back to
the “Photo” browser
hold: exit the Music mode and go back directly to
the Home screen.
-
-
start/pause a slideshow
zoom in
left/right: previous/next picture
down/up: rotate 90° clockwise/counterclockwise
zoom out
display/hide the menu overlay
display available menu items
increase/decrease volume
PHOTO VIEWER MENU ITEMS
“Info”
displays a message box with information about the current picture.-
•
•
•
•
•
MANUAL
V2.0
GEN 5 VIEWING PHOTOS > P. 32
“Rotate”
choose “Left” to rotate the picture 90° counterclockwise.
choose “Right” to rotate the picture 90° clockwise.
-
-
“Start slideshow”
starts a slideshow from the current image.
the “Pause slideshow” menu item will appear, allowing you to pause the
slideshow.
-
-
“Set as wallpaper”
denes the current picture as your ARCHOS’ background image.-
“Settings”
will display the Photo viewer settings screen (see next section).-
“Zoom”
use the slider to magnify/demagnify the current picture.-
3.3 PHOTO VIEWER SETTINGS
In the Photo mode, you can access the Photo viewer settings screen via the
“Settings” menu item .
Use the left/right arrows to select a different setting for a parameter.
“Picture Pause”
denes the time that each picture will be displayed during a slideshow.
•
•
-
MANUAL
V2.0
GEN 5 VIEWING PHOTOS > P. 33
“Transition”
denes the transition effect to be used between two pictures. There are several
cool effects that you can choose from.
“Sequence”
allows you to enable/disable the shufe mode. If this parameter is set to
“Shufe”, your pictures will be displayed randomly. To disable the shufe mode,
select “Normal”.
“Format”
allows you to change the way the picture is displayed.
“Original”: displays the entire picture in its original format.
“Full Screen”: enlarges the picture to ll the screen. In order to t the ARCHOS’
screen, your device might need to cut small parts of the image, most likely at the
top and bottom.
3.4 PLAYING A SLIDESHOW
To view a slideshow, highlight a picture le in the “Photo” browser or while view-
ing photos viewing, and choose the “Start slideshow” menu item.
While a slideshow is playing, you can pause it at any time by selecting the
“Pause slideshow” menu item.
You can dene the time that each picture is displayed and the transition effects
in the “Photo” settings (see:
“Photo” Settings
).
3.5 VIEWING PHOTOS WHILE LISTENING TO MUSIC
You can view photos and play slideshows while listening to music:
Choose the “ARCHOS home screen” menu item while playing a song.
In the Home screen, select the “Photo” icon to enter the Photo mode.
Browse through your photos (see:
Browsing Through your Photos
) or start a slide-
show as normal (see:
Playing a Slideshow
).
To go back to the Music playback screen, go to the Home screen and select the
“Music” icon.
-
-
-
-
-
•
•
•
•
•
•
•
MANUAL
V2.0
GEN 5 VIEWING PHOTOS > P. 34
3.6 PUTTING PHOTOS ONTO YOUR ARCHOS
There are two main methods to transfer the pictures stored on your computer onto
the ARCHOS:
Windows Media® Player: copy your pictures using Windows Media® Player 10 or
higher*:
Use Windows Media® Player 10 or higher* (Sync tab) to synchronize
your computer’s pictures with the ARCHOS.
See
Putting Files onto the ARCHOS
to learn more about how to transfer
your computer’s pictures with Windows Media® Player.
-
-
* For best performance, we recommend that users update to Windows Media®
Player 11 or higher.
Windows® Explorer: Copy and paste your pictures from your computer into the
Video folder of your ARCHOS.
To learn how to connect/disconnect the ARCHOS from your computer, see the
Transferring Files
section.
605 3.7 PLAYING YOUR PC’S SHARED PHOTOS
When connected to your home WiFi network, your ARCHOS gives
you the possibility to view, directly on your device, shared photos
stored in your PC’s Windows Media® Library.
For this to work, you will need a WiFi connection and Windows
Media® Player 11 or higher* installed on your PC.
The ARCHOS uses the UPnP (Universal Plug-and-play) standard to
stream shared photos from your PC’s Windows Media® Library.
See:
Playing your PC’s Shared Media Files
.
•
•
•
•
* There are other products on the market that also can share media les using
the UPnP standard.
1.
2.
MANUAL
V2.0
GEN 5 USING THE FILE BROWSER > P. 35
4. USING THE FILE BROWSER
The ARCHOS File Browser gives you the possibility to navigate the le
system of your ARCHOS’ hard drive. In the Home screen, select the
“Files” icon to enter the File Browser.
You will see two panels:
The one on the left is the panel that
you usually use to navigate through
your device’s hard drive.
The panel on the right is the one
you will use when you want to
copy or move les and folders
(see:
Copying and Moving Files and
Folders
).
•
•
About your ARCHOS’ hard drive:
DO NOT delete or rename the original folders: Music, Pictures, Video,
Playlists, etc. The icons on the Home screen (“Video, “Music”, “Photo”...) lead
directly to these folders and they may no longer work correctly if the folders
are deleted or renamed.
BROWSING THROUGH YOUR MEMORY CARD’S FILES
(Depending on model)
If you have inserted a memory card into the ARCHOS (see:
Memory Card Slot
),
select the line “SD/MMC card”, in the rst screen of the File browser.
You can now browse the contents of your card. In the File browser, all les and
folders will appear.
4.1 NAVIGATION
605
TOUCHSCREEN CONTROLS
You can drag the scroll bar up and down to scroll the le list up and down. You
can also scroll faster by tapping above or below the cursor in the scroll bar.
To open a le or folder, tap on it to highlight it, then tap on it again.
•
•
•
•
MANUAL
V2.0
GEN 5 USING THE FILE BROWSER > P. 36
To jump between the left and right panels, tap on , or tap directly on the panel
that you want to highlight.
To execute a menu item’s function, simply tap on its icon. In order to display a
text description of the icon, tap on the menu word.
You can go back one level in the hierarchy by tapping on
(see n° 1)
. Wherever
you are in the hierarchy, you can go back directly to the Home screen by tapping
and holding the Exit icon.
BUTTON CONTROLS
press once: go back one level in the hierarchy
hold: exit the
File Browser
and go back directly to
the Home screen.
-
-
open a le or folder
scroll up the le list faster
left: go back up one level in the folder hierarchy
up/down: scroll the le list up and down
scroll down the le list faster
jump between the left and right panels.
display available menu items
increase/decrease volume
BROWSER MENU ITEMS
Note that some of the above menu items may not appear if they are not avail-
able for the highlighted le or folder.
“Info”
displays a message box with information about the highlighted le.-
“Create folder”
creates a folder at the current location.
you will have to enter the folder’s name with the virtual keyboard (see:
Using
the Virtual Keyboard
).
-
-
•
•
•
MANUAL
V2.0
GEN 5 USING THE FILE BROWSER > P. 37
“File Management”
“Rename”: allows you to change the name of the highlighted le or folder us-
ing the virtual keyboard. See:
Using the Virtual Keyboard
.
“Delete”: allows you to delete the highlighted le or folder (and all its con-
tents). A conrmation screen will pop up.
-
-
“Copy”
“Copy”: allows you to copy the highlighted le or folder to the location de-
ned in the other browser panel.
“Copy all les”: allows you to copy all the les of the current folder to the
location dened in the other browser panel.
“Move”: allows you to move the highlighted le or folder to the location de-
ned in the other browser panel.
-
-
-
COPYING AND MOVING FILES AND FOLDERS
In the left panel, highlight the le/folder that you want to copy or move.
In the right panel, navigate to the location where you wish to copy the le/folder to.
Go back to the left panel, select the “Copy” menu item and then choose “Copy”,
“Copy all les” or “Move”, depending on the action that you want to carry out.
4.2 USING THE VIRTUAL KEYBOARD
The virtual keyboard is an interface that allows you to type in text, for instance to rename
a le or folder, or when you want to give a title to a playlist that you have just created.
the virtual keyboard might vary according to your model.
if a key is transparent, it means that it is disabled.
•
•
1. current name of the
le/folder
2. Exit icon
3. Shift key
4. Alt/Alt Gr key : en-
able/disable the keys’
secondary functions
5. Caps Lock key
6. move cursor one
character to the left
7. move cursor one
character to the right
8. delete character be-
fore cursor
9. save the name.
•
•
•
MANUAL
V2.0
GEN 5 USING THE FILE BROWSER > P. 38
605
KEYBOARD TOUCHSCREEN CONTROLS
To enter a character, tap on the corresponding key.
To exit the keyboard without saving, tap on (see n° 2 in the previous screen).
When you are satised with the name, tap on the Ok key (see n° 9) to save it
and exit the keyboard. A conrmation screen will pop up.
KEYBOARD BUTTON CONTROLS
close keyboard without saving
enters the highlighted character
same as the Shift key
jump from one key to another
same as the Alt/Alt Gr key
(depending on model)
-
-
-
4.3 USING THE FILE BROWSER WHILE LISTENING TO MUSIC
You can browse your les while listening to music:
Choose the “ARCHOS home screen” menu item while playing a song.
In the Home screen, select the “Files” icon to enter the File Browser and start
browsing through your les.
To go back to the Music playback screen, go to the Home screen and select the
“Music” icon.
•
•
•
•
•
•
MANUAL
V2.0
GEN 5 USING THE FILE BROWSER > P. 39
605
4.4 BROWSING OTHER COMPUTERS ON THE NETWORKBROWSING OTHER COMPUTERS ON THE NETWORK
When you are connected to a Windows® network, you can browse* the shared
folders of other computers in the network, using the ARCHOS File Browser.
From the Home screen, select the “Files” icon. In the left panel of the browser,
select the rst line in the list (“Network”). Your device will connect to your WiFi
access point and then search for other computers in the Windows® network. You
can then choose a computer and start browsing its shared folders.
* If the computer with the shared folders normally has a Windows® username
and password, you will be asked to enter these before you can access the
folder contents.
Using the ARCHOS double browser, you will be able to play media les or transfer any
le from a networked computer onto your device. You can also transfer les from your
device onto a computer’s write-enabled shared folder (see
Copying and Moving Files
and Folders
).
If the WiFi is not enabled or if you are not connected to a network, the device
will scan for available networks and connect to a known network or display
the list of available networks so that you can connect to one of them.
4.5 USING THE PDF READER
Your ARCHOS features a PDF reader with hyperlink support.
In the Browser, PDF les are displayed with the icon.
To view a PDF document, highlight the PDF document in the File Browser and
open it.
ATTENTION: The ARCHOS PDF reader may not implement all PDF features.
For example, you will not be able to open password protected PDF les.
•
•
•
•
•
MANUAL
V2.0
GEN 5 USING THE FILE BROWSER > P. 40
605
PDF TOUCHSCREEN CONTROLS
To follow a link, highlight the link (red outline) and tap again.
To display the menu overlay while viewing a PDF document, tap once in the bot-
tom right corner of the screen.
To go to the next/previous page, tap on the “Next/Previous page” menu item.
To exit the PDF reader, tap on .
PDF BUTTON CONTROLS
1st press: t to width (if zoomed)
2nd press: exit PDF reader
-
-
follow a highlighted link
previous page
navigate within the current page
next page
-
display available menu items
-
FOLLOWING HYPERLINKS
Some PDF documents have hyperlinks (for instance, a table of contents, links to
an external website, etc.).
Links are surrounded by a blue outline. A highlighted link (active link) is surround-
ed by a red outline.
If you want to go back to the previous page (where you ‘clicked’ the link), select
the “Link back” menu item.
Note that hyperlinks referring to an external document or to a URL may not
work.
•
•
•
•
•
•
•
MANUAL
V2.0
GEN 5 USING THE FILE BROWSER > P. 41
PDF READER MENU ITEMS
“Hide text overlay”
will hide all overlaid graphics (status bar, menu items, etc.) to only show the PDF
document.
-
“Zoom in”
magnies the document.-
“Zoom out”
demagnies the document.-
“Link back”
will take you back to the page that you came from.
only appears when you have previously followed a link.
-
-
“Go to page...”
allows you to select a specic page.
use the left/right buttons to select a page number.
Select “Ok” to go to this page.
-
-
-
“Previous page”
goes to the previous page in the document.-
“Next Page”
goes to the next page in the document.-
MANUAL
V2.0
GEN 5 CONNECTING TO A WIFI NETWORK > P. 42
605
5. CONNECTING TO A WIFI NETWORK
Your ARCHOS can connect to a variety of wireless networks. You will nd
below the procedure to connect to these different WiFi networks.
5.1 WIFI CONNECTION PROCEDURE
ENABLING WIFI
From the Home screen, select the “Enable WiFi” menu item . Your device will scan
for available WiFi networks.
The rst time you use your device, you may get a message “No congured net-
work found”. Select “View available networks”, and the list of available networks
will be displayed.
If you get the message “Could not connect to any WiFi network!”, select “View
available networks”, and the list of available networks will be displayed.
Once you are connected to a WiFi network, the status bar icon (WiFi not con-
nected) will become (WiFi connected). There is no status bar icon at all when WiFi
is not enabled.
When you enter an application that uses the WiFi (Web Browser, ARCHOS
Content Portal, etc. See: The WiFi Features), your ARCHOS will try to connect
to the WiFi. If a congured network is detected, the ARCHOS will automatically
connect to it and then launch the application.
THE LIST OF AVAILABLE NETWORKS
The list of available networks shows
all the wireless networks in range of
your device.
The list is constantly refreshed au-
tomatically.
In the list of available networks, for
each network you will see the fol-
lowing information:
•
•
•
•
•
MANUAL
V2.0
GEN 5 CONNECTING TO A WIFI NETWORK > P. 43
1. Conguration status: congured network
uncongured network
2. The name of the network (SSID), if it is broadcasted
(if the SSID is not broad-
casted, you will be prompted to enter it in the next conguration screen).
3. The strength of the signal.
4. The type of encryption key that is required:
Open network (no key) WEP key WPA key WPA2 key
5. The channel used by the network.
6. The type of network (Infrastructure or Ad-Hoc).
Ad-Hoc networks are not sup-
ported at this time.
Select the network that you want to connect to (your home wireless network or
a free hotspot).
You will be taken to the conguration screen for this network, where you will
have to enter some information to set up your access to this network.
5.2 WIFI NETWORK CONFIGURATION
In order to connect to a wireless network, the ARCHOS will need some specic in-
formation about the network. Your device will automatically pick up certain pieces
of information that it needs from the WiFi hot spot. You can enter the rest of the in-
formation manually in the network’s conguration screen, as shown in the following
sections.
Note that your device will remember the network connection information that
you enter, in order to re-use it and connect automatically to the network when
it is in range.
•
•
MANUAL
V2.0
GEN 5 CONNECTING TO A WIFI NETWORK > P. 44
OPEN NETWORKS
Open networks do not require an
authentication key.
If the network has automatic con-
guration turned on (DHCP), sim-
ply tap on the “Connect” button,
and your ARCHOS will connect to
this network, provided the signal is
strong enough.
•
•
If the network needs to be cong-
ured manually, use the left/right ar-
rows to select the “Manual” setting
on the “Conguration” parameter.
Other parameters will appear: the
required information can be ob-
tained from the person who man-
ages the network.
•
•
When you have nished entering all the information, tap on the “Connect” button,
and your ARCHOS will connect to this network, provided the signal is strong enough.
PROTECTED NETWORKS (WEP, WPA OR WPA2 KEY)
Protected networks require an en-
cryption key to connect.
The type of key (WEP, WPA or
WPA2) will be detected automati-
cally by your device.
The rest of the required information
can be obtained from the person
who manages the network.
•
•
•
MANUAL
V2.0
GEN 5 CONNECTING TO A WIFI NETWORK > P. 45
You will have to specify the following settings:
“Key length” (for WEP networks only)
the authentication key can be 10 characters long (64bit) or 26 characters long
(128bit).
“Key” (WEP or WPA)
type in the authentication key.
you will be taken to a virtual keyboard (see:
Using the Virtual Keyboard
).
type in the key and tap on “OK” when you have nished.
“Authentication” (for WEP networks only)
the network’s authentication method can be based on an “Open System (de-
fault)” or a “Shared Key”.
“Conguration”
it can be “Automatic (DHCP)” or “Manual”.
if it is “Automatic (DHCP)”, then you do not have to enter any more information.
Simply use the “Connect” button, and your ARCHOS will connect to this network,
provided the signal is strong enough.
if you must congure the network manually, select the “Manual” setting. Other
parameters will appear: the required information can be obtained from the person
who manages the network.
When you have nished entering all the information, use the “Connect” button, and
your ARCHOS will connect to this network, provided the signal is strong enough.
Filtered networks: If your network manager allows only specic devices to
connect to the network (known as MAC address ltering), you can supply the
network manager with the MAC address of your ARCHOS. To nd out what
your MAC address is, select the “Settings” menu item from the Home screen,
then choose “System”. See: “System” Settings.
-
-
-
-
-
-
-
-
MANUAL
V2.0
GEN 5 THE WIFI FEATURES > P. 46
605 6. THE WIFI FEATURES
When connected to a WiFi network, your ARCHOS gives you the possibility to:
rent or purchase on-line videos/music via the ARCHOS Content
Portal. See:
The ARCHOS Content Portal
.
browse the web with the optional Web Browser plug-in, available at
www.archos.com. See next section.
play shared media les stored on other computers in your network.
See:
Playing your PC’s Shared Media Files
.
•
•
•
6.1 BROWSING THE WEB
In order to browse the web, you will need the Web Browser plug-in, avail-
able at www.archos.com. With this Internet browser, specially designed
for your ARCHOS, you will have the possibility to browse websites*, use
web-based e-mailing, download content, etc.
*supports Flash™ content and Javascript. Java virtual machine not supported.
LAUNCHING THE WEB BROWSER
From the Home screen, select the “Web” icon.
If you are already connected to a network, the Web browser will simply open and
you can start browsing the Web.
If WiFi is not enabled or if you are not connected to a network, the device will
scan for available networks and connect to a known network or display the list of
available networks so that you can connect to one of them.
Please note: not all wireless networks offer access to the Internet. Some WiFi net-
works only link several computers together, without any Internet connection.
If the time and date are not correctly set, you might not be able to access cer-
tain web pages (See: “Clock” settings). If you choose to set the clock automat-
ically when the ARCHOS connects to a WiFi network, you will need to select
your Country and City/Zone (see: “Language (and Region)” Settings).
USING THE WEB BROWSER
You can use the Web browser to read your Web-based e-mail, view Web sites, and
download documents from the Internet.
The menu overlay will disappear after a few seconds.
•
•
•
•
•
MANUAL
V2.0
GEN 5 THE WIFI FEATURES > P. 47
The Web browser features ‘tabbed browsing’. You can have several pages opened
at the same time. They will appear in the tabs area, in the upper left corner of the
screen. When several pages are open, simply select a tab to access the page that
you want. See next section.
WEB BROWSER TOUCHSCREEN CONTROLS
You can use your stylus to scroll the current web page horizontally or vertically. To
open a link, simply tap on it.
To switch between the available tabs, tap on , or tap directly on the corre-
sponding tab.
To display the available menu items, tap on the menu word.
When several tabs are displayed, tap on to close the current one or tap and
hold the icon to close the Web browser and go back directly to the Home screen.
When there is only one tab, tap on to exit the Web browser.
WEB BROWSER BUTTON CONTROLS
When several tabs are displayed: press once to close the cur-
rent tab. Press and hold to close the Web browser and go back
directly to the Home screen.
When there is only one tab: press once to close the Web browser.
-
-
validate (enter button)
zoom in
scroll left/right/up/down
zoom out
go to the next tab
display available menu items
increase/decrease volume
•
•
•
•
•
MANUAL
V2.0
GEN 5 THE WIFI FEATURES > P. 48
BROWSER MENU ITEMS
“Reload” / “Stop”
will stop loading the web page, if it is currently loading.
will refresh the current web page, if it has stopped loading.
“Back”
will go back to the previous page that you browsed.
“Zoom”
changes the way the web page is displayed. Select a zoom mode.
“Go to”
“Enter URL...”: allows you to enter the address of a Web site you’d like to visit.
Enter the address with the virtual keyboard (see:
Using the Virtual Keyboard
).
Select “OK” to open the website in the current window, or select “Open in new
tab” to open it in a new window.
“Search...”: allows you to search an address in one of the congured search
engines. Enter the key words using the virtual keyboard (see:
Using the Virtual
Keyboard
). Select “OK” to open the results in the current window, or select “Open
in new tab” to open them in a new window.
“Favorites”
will open the “Favorites” manager. Here you can add favorites, rename or delete
them. Select a favorite and use the “Open in new tab” menu item to open the
corresponding web page in a new window.
“Settings”
will open the “Web Browser” settings screen. Here you can decide whether to
accept/ignore popup windows, enable/disable ash content, delete your Internet
history and cookies, etc.
Please note that some Web features requiring special plug-in software or
Active X controls may not work in this special version of the Web Browser.
6.2 PLAYING YOUR PC’S SHARED MEDIA FILES
When connected to your home WiFi network, your ARCHOS gives you the possi-
bility to watch, directly on your device, shared media les (videos, music or pho-
tos) stored in your PC’s Windows Media® Library.
For this to work, you will need a WiFi connection and Windows Media® Player 11
or higher installed on your PC*.
-
-
-
-
-
-
-
-
•
•
MANUAL
V2.0
GEN 5 THE WIFI FEATURES > P. 49
This is especially useful when you have a large library of music and video and you
cannot t it all onto the internal hard drive of the ARCHOS.
The ARCHOS uses the UPnP (Universal Plug-and-play) standard to stream shared
media les from your PC’s Windows Media® Library.
Streaming one of your PC’s shared videos and displaying it on your TV
* If you cannot install Windows Media® Player 11 or higher, it is possible to ac-
cess and stream your PC’s les from the ARCHOS File Browser. See Browsing
Other Computers on the Network.
SETTING WINDOWS MEDIA® PLAYER’S SHARING OPTIONS
Connect the ARCHOS to your WiFi network (see
Connecting to a WiFi Network
).
Connect your PC to the same WiFi network and
start Windows Media® Player, version 11 or higher.
Click on the Library tab, and select Media shar-
ing...
1.
2.
3.
Check the box Share my media to, and click on
OK. The ARCHOS’ icon should appear in the win-
dow, with a warning symbol next to it*.
* ATTENTION: the rst time you set your shar-
ing options, it might take a couple of minutes
for your PC to display the ARCHOS’ icon.
4.
•
•
MANUAL
V2.0
GEN 5 THE WIFI FEATURES > P. 50
Select the ARCHOS’ icon and click on the Allow button.
To modify your sharing settings, click on Settings. You can, for example, enter a
name for your shared media les. You will then see this name on your ARCHOS.
Click on OK to save the modications.
Click on OK to close the Media Sharing window.
You can now close Windows Media® Player, and start viewing your PC’s shared
media les directly on your ARCHOS (see next section).
PLAYING YOUR SHARED MEDIA FILES ON THE ARCHOS
Your PC needs to be connected to the same WiFi network as the one the ARCHOS will
connect to. You also need to have congured Windows Media® Player’s sharing op-
tions (see the previous section).
On your ARCHOS, enter the Video, Music or Photo mode.
You will notice that the rst item in the list is the shared media les: “Network
Media Libraries (UPnP)”. Open this item to start scanning for devices and com-
puters sharing their media les on the WiFi network.
If you entered a name for your shared media les in Windows Media® Player, it
should appear. Open it, and you will see all your shared videos, songs or photos.
If you are in the Video mode,
you will then have access to all
the videos stored in your PC’s
Windows Media® Library.
In the same way, the Music and
Photo modes will allow you
to access all the music/photos
stored in your PC’s Windows
Media® Library.
•
•
Note: You may have some video les of very high quality and these require
that the WiFi connection transfers data at a high speed. If your ARCHOS is far
away from your WiFi box, it may happen that the connection speed is reduced
thus not allowing some video les to stream from your PC to the ARCHOS and
the television.
5.
6.
7.
8.
1.
2.
3.
MANUAL
V2.0
GEN 5 THE WIFI FEATURES > P. 51
6.3 THE ARCHOS CONTENT PORTAL
The ARCHOS Content Portal is an on-line store that regroups several
video and music partners. This portal will allow you to purchase or
rent videos and songs, directly on your ARCHOS, without even using
a computer.
Or, if your ARCHOS is connected to the optional DVR Station Gen 5
you will be able to select your internet media content directly from
your television.
•
•
In order to activate the ARCHOS
Content portal, you will need to regis-
ter your ARCHOS product on-line on
the ARCHOS web site (www.archos.
com/register).
Make sure you have congured your
ARCHOS on a WiFi network (see:
Connecting to a WiFi Network
).
Select the ARCHOS “Content Portal”
icon to view available on-line media
stores and purchase videos or songs.
You can also visit the ARCHOS on-line
store to purchase accessories.
1.
2.
3.
4.
Depending on your connection speed, you will have the possibility to start
playing the video/song you purchased or rent while it’s being downloaded.
The videos/songs you get from the ARCHOS Content Portal are saved in the
Video/Music folders.
MANUAL
V2.0
GEN 5 TRANSFERRING FILES > P. 52
7. TRANSFERRING FILES
7.1 CONNECTING THE ARCHOS TO A COMPUTER
Turn on your ARCHOS.
Plug the ARCHOS USB cable into the ARCHOS.
Plug the USB end of the cable into your computer.
The ARCHOS will ask you if you want to connect it or charge its battery. Choose
to connect it.
The ARCHOS’ icon will appear on your computer. You can now start transferring
les to it.
7.2 PUTTING FILES ONTO THE ARCHOS
There are two main methods to transfer your les onto the ARCHOS:
Copy your media les (videos, music, photos) with Windows Media® Player 10 or
higher*:
* For best performance, we recommend that users update to Windows Media®
Player 11 or higher.
The Synchronize button in Windows Media® Player is a one way ‘sync’ button. It will add
video, music and photo les to your ARCHOS. If will give you the possibility to have the
same digital media on your ARCHOS as you have in your Windows Media® Player media
library.
1.
2.
3.
4.
5.
1.
MANUAL
V2.0
GEN 5 TRANSFERRING FILES > P. 53
Connect your ARCHOS to the computer. See
Connecting the ARCHOS
to a Computer
.
On your computer, start Windows Media® Player.
Select the Sync tab.
Choose the media les you want to transfer.
Click on the Start Sync button.
The selected videos, songs or photos will be copied directly into the
corresponding Video, Music or Pictures folder of the ARCHOS.
See your Windows Media
®
Player help instructions for more information.
1.
2.
3.
4.
5.
6.
The second method is to use Windows® Explorer to copy and paste your les
from your computer to the Video, Music or Pictures folder of your ARCHOS.
You cannot copy les larger that 2 GB to the ARCHOS due to the FAT32 le
system constraints. For advanced users: in “PC Hard Drive” connection
modes (mode 2 and 3), the maximum size is 2 GB for .AVI les and 4 GB for
any other type of le. See: “System” Settings.
7.3 DISCONNECTING
When you disconnect the ARCHOS from a computer, your device automati-
cally updates the ARCLibrary, so that the media les you just copied appear in
the Music and Photo Libraries.
Windows® XP or higher & WMP10 or higher
Verify that no data are being transferred between your ARCHOS and your com-
puter (the HDD indicator on your ARCHOS is not ickering).
Now unplug the USB cable from your ARCHOS and/or computer.
Windows® 2000 or Me
DO NOT SIMPLY PULL OUT THE CABLE AT ANY TIME! You must remove/unmount the
ARCHOS from the computer before disconnecting the USB cable to avoid loss of data
or freezing.
Once all your transfers are nished, click on the ‘safely
remove’ icon in the system tray, next to the clock.
•
Click on the ‘safely remove’
message.
•
2.
•
•
MANUAL
V2.0
GEN 5 TRANSFERRING FILES > P. 54
A message will pop up, telling you that it is
now safe to disconnect the device*. You can
now safely unplug the USB cable from your
ARCHOS and/or computer.
•
* If you get a message saying that the device cannot be removed, close any
computer program that may still be using data on your device, such as media
players or Windows® Explorer.
Mac® OS X
DO NOT SIMPLY PULL OUT THE CABLE AT ANY TIME!
You must remove/unmount the ARCHOS from the
computer before disconnecting the USB cable to avoid
loss of data or freezing.
On your desktop, drag the ARCHOS’ icon towards
the trashcan, which will turn into a big eject sym-
bol.
Drop the icon onto this eject symbol: the ARCHOS’
hard drive will disappear from the desktop.
You can now safely unplug the USB cable from
your ARCHOS and/or computer.
•
•
•
Linux
DO NOT SIMPLY PULL OUT THE CABLE AT
ANY TIME!
You must remove/unmount the ARCHOS from
the computer before disconnecting the USB
cable to avoid loss of data or freezing.
On your computer, right-click on the ARCHOS icon and select Safely Remove.
Wait until the ARCHOS icon disappears, and safely unplug the USB cable from
your ARCHOS and/or computer.
•
•
MANUAL
V2.0
GEN 5 MAIN SETTINGS > P. 55
8. MAIN SETTINGS
In the Home screen, select the “Settings” menu item and choose a setting.
605
USING THE TOUCHSCREEN
Tap on the “Settings” menu item, and choose a setting to open its corre-
sponding screen.
Once you are in a settings screen:
tap on a parameter to highlight it.
tap on the left/arrows to select a different setting.
when you have nished adjusting your settings, tap on to save them and
go back to the Home screen.
When it is possible, drag the scroll bar up and down to scroll the screen up
and down.
USING THE BUTTONS
To open a settings screen, press the menu button, use the navigation pad to
highlight the “Settings” menu item, and press OK.
Once you are in a settings screen:
use the up/down navigation buttons to highlight a parameter.
use the left/right navigation buttons to select a different setting.
when you have nished adjusting your settings, press the Exit button to
save them and go back to the Home screen.
When it is possible, use the up/down navigation buttons to scroll the screen
up and down.
8.1 “SOUND” SETTINGS
This screen allows you to adjust the
sound settings of your ARCHOS to
your personal taste.
•
•
-
-
-
-
•
•
-
-
-
-
MANUAL
V2.0
GEN 5 MAIN SETTINGS > P. 56
605 “Built-in Speaker”
“ON” / “OFF”: the built-in speaker remains on or off regardless if headphones are
attached.
“Automatic”: the built-in speaker automatically turns off when you plug in head-
phones or connect your ARCHOS to the optional DVR Station Gen 5.
“Audio Output”
denes whether the audio signal is sent out via the “Analog Line-Out” or the
“SPDIF” interface when connected to a DVR Station Gen 5.
“Bass Boost Level”
adjusts the bass boosting level.
“Preset”
allows you to quickly select a sound prole.
“Set Equalizer”
allows you to use a custom sound prole. Select this option to enter the equalizer
screen (see next section).
“Balance”
allows you to balance the sound between the left and right stereo channels.
“Reset”
resets the sound parameters to the default values.
“EQUALIZER” SCREEN
Your ARCHOS features a 5-band
equalizer.
Select a band (Bass, Mid. bass, Mid.
range, Mid. treble or Treble), then
use the up/down arrows to change
the gain level for these frequency
ranges.
•
•
It is advised that you change these
settings while listening to music, in
order to be able to appreciate the
sound changes.
-
-
-
-
-
-
-
-
MANUAL
V2.0
GEN 5 MAIN SETTINGS > P. 57
8.2 “DISPLAY” SETTINGS
“LCD SETTINGS”
“LCD Backlight”
adjusts the level of backlight of the built-in screen.
605 “Brightness/Contrast”
use this button to adjust the display
parameters of the built-in screen
(contrast, brightness and gamma).
you can also reset the LCD param-
eters to the default values (“Reset”
button).
-
-
605 “Touch-Screen Calibration”
If the touchscreen is not responding properly, use this button and follow the in-
structions on the screen.
405 “LCD stability”
If you nd that the LCD screen ickers, use this button to access the “LCD stabil-
ity” screen.
Press the left/right navigation buttons until the screen stops ickering.
-
-
-
-
MANUAL
V2.0
GEN 5 MAIN SETTINGS > P. 58
“TV SETTINGS”
“TV Standard”
choose between the “NTSC (USA)” and “PAL (Europe)” systems (select the one
that is compatible with your country’s television system).
“TV Format”
“4:3” or “16:9” - the format used by your television set to display images.
the option “Wide screen” becomes available when you set the “TV standard”
parameter to “PAL (Europe)”.
“TV Connection”
when your ARCHOS is connected to the optional DVR Station Gen 5 (available
at www.archos.com), select the type of video output (“Composite”, “S-Video” or
“RGB”), based on how you have connected the DVR Station Gen 5 to your TV.
8.3 “APPEARANCE” SETTINGS
“Picture name”
allows you to select a picture to use as a wallpaper image. Select “None” if you do
not want any background image.
you can choose between all default backgrounds or the images that you have
previously set as wallpapers.
you can also set a picture as wallpaper from the Photo and Video modes.
“Theme color”
denes the theme color for your icons (and for the background, if you have dis-
abled the use of a wallpaper).
-
-
-
-
-
-
-
-
MANUAL
V2.0
GEN 5 MAIN SETTINGS > P. 59
“Cancel”
use this button to discard any changes you may have made since entering this
screen.
8.4 “LANGUAGE (AND REGION)” SETTINGS
“Language”
choose a language.
visit www.archos.com to check the availability of other languages. New lan-
guages are included in the rmware as they become available. See
Updating the
Firmware
.
605 “Select location”
if your clock is set to “Automatic” (see
“Clock” Settings
), select your “Country”,
and “City/Zone”.
605 “WiFi Region”
this is congured automatically according to how you set your location.
8.5 “TV CONTROL” SETTINGS
This is where you can set the DVR Station’s IR emitter to communicate with
your tuner. This will allow you to schedule recordings easily via the ARCHOS TV
Program Guide (EPG).
See the manual of the optional DVR Station Gen 5.
-
-
-
-
-
•
•
MANUAL
V2.0
GEN 5 MAIN SETTINGS > P. 60
8.6 “CLOCK” SETTINGS
If you use the optional DVR Station Gen 5 to schedule video recordings on
your TV system, make sure that the time and date are set correctly!
“Time Format”
choose between 12h or 24h mode.
605 “Time setting”
“Automatic”: select this parameter if you want to set the clock automatically
when your ARCHOS is connected to a WiFi network. You will need to select your
location in the “Language (and Region)” settings screen (see:
“Language (and
Region)” Settings
).
“Manual”: select this parameter to set the current date & time manually. The fol-
lowing parameters will appear: “Hour”, “Minute”, “Year”, “Month” and “Day”.
605 “Synchronize now”
if the “Time setting” parameter is set to “Automatic”, use this button to set the
clock automatically via a WiFi network.
for this to work, the ARCHOS needs to be connected to a WiFi network.
ATTENTION: If the time & date are not correctly set, you might not be able to
access certain web pages.
“Hour”, “Minute”, “Year”, “Month”, “Day”
these parameters allow you to set the current time and date manually.
-
-
-
-
-
-
MANUAL
V2.0
GEN 5 MAIN SETTINGS > P. 61
8.7 “POWER” SETTINGS
These settings will help you save
battery power, thus allowing a lon-
ger battery autonomy.
You can adjust settings for both
battery operation and power sup-
ply operation (when the ARCHOS
is connected to a powered DVR
Station Gen 5, Mini Dock or
Battery Dock).
•
•
Your ARCHOS will consume more power as these parameters are set to higher
values. In battery operation, it is advised to set these parameters to lower val-
ues in order to save power.
“Device Full Power Off”
If you do not plan on using the ARCHOS for an extended period of time, use this
button to completely turn off your device, so that there is absolutely no battery
usage*.
* Remember that when you turn off the ARCHOS using the button, your de-
vice will keep using a small amount of battery power to allow a quick start up.
“BATTERY OPERATION”
“Power Off”
the amount of time of user inactivity before the device shuts off.
the device will not shut down during a slideshow, audio/video playback, audio/
video recording, or USB connection.
“Backlight Off”
the amount of time of user inactivity before the LCD display turns off.
the display will not turn off while a video or slideshow is playing, or when you are
browsing the web.
605 “Web Browser”
“normal power off”: while browsing the web, the ARCHOS will shut down accord-
ing to the setting selected for the “Power Off” parameter.
“prevents power off”: while browsing the web, the ARCHOS will not shut off au-
tomatically from user inactivity.
-
-
-
-
-
-
-
MANUAL
V2.0
GEN 5 MAIN SETTINGS > P. 62
“POWER SUPPLY OPERATION”
“Standby”
the amount of time of user inactivity before the ARCHOS goes into Standby mode.
the system will not go into Standby mode during a slideshow, audio/video play-
back, audio/video recording, or USB connection.
“Backlight Off”
the amount of time of user inactivity before the LCD display turns off.
the display will not turn off while a video or slideshow is playing.
605 “Web Browser”
“normal power off”: while browsing the web, the ARCHOS will go into Standby
mode according to the setting selected for the “Standby” parameter.
“prevents power off”: while browsing the web, the system will never go into
Standby mode.
8.8 “FIRMWARE AND PLUG-INS” SETTINGS
“Firmware Ver.”
displays the current version of the rmware and Digital Rights Management
(DRM) system.
“Plug-ins”
displays the current plug-ins installed on your device.
“Product Key”
each ARCHOS has a unique number.
you will need this number to register your product online (www.archos.com/register).
“Firmware Update”
use this button to update the rmware manually (see:
Updating the Firmware)
-
-
-
-
-
-
-
-
-
-
-
MANUAL
V2.0
GEN 5 MAIN SETTINGS > P. 63
605 “Online Firmware Update”
use this button to search for an online update via a WiFi network. If there is one
available, it will be installed automatically. See
Updating the Firmware
to learn more.
8.9 UPDATING THE FIRMWARE
The rmware is the operating system (OS) of your ARCHOS. It is periodically updated
to bring new features, improvements and bug xes. There are two main ways to up-
date your product’s rmware:
Directly on your ARCHOS if your device can connect to a WiFi network.
With a computer connected to the internet
605
UPDATE DIRECTLY ON THE ARCHOS (WIFI CONNECTION NEEDED)
This is the easiest way to update the rmware. For this to work, you only need an ac-
cess a WiFi network. See
Connecting to a WiFi Network
.
From to the Home screen, select the “Settings” menu item, and choose
“Firmware and Plug-ins”.
Use the “Online Firmware Update” button.
The ARCHOS will connect to the WiFi and search on-line for a new rmware. If
there is one available, it will start downloading, and it will be installed automati-
cally.
UPDATE USING A COMPUTER (INTERNET CONNECTION NEEDED)
If you do not have access to a WiFi network, or if your ARCHOS is not WiFi-enabled,
you can also update the rmware using a computer connected to the internet:
On your PC, go to www.archos.com/rmware.
Search for the latest rmware available for your ARCHOS.
Compare the latest on-line version with the one installed on your ARCHOS: your
ARCHOS’ rmware version number appears in the “Firmware and Plug-ins” set-
tings screen (see:
“Firmware and Plug-ins” Settings
).
If the on-line version is more recent than yours, follow the instructions to down-
load and install the new rmware.
Your Internet browser may warn you that the contents of the rmware le
could harm your computer. ARCHOS has taken precautions to insure that this
le will not harm your computer.
-
•
•
1.
2.
3.
1.
2.
3.
4.
MANUAL
V2.0
GEN 5 MAIN SETTINGS > P. 64
8.10 “SYSTEM” SETTINGS“SYSTEM” SETTINGS
“Free Storage Space”
displays the amount of free space on the hard drive.
Note: reported number of megabytes is binary-based counting (1Kb=1024
bytes). Thus each reported Mb represents approximately 1.05 megabytes
(decimal), and each reported Gb represents approximately 1.07 gigabytes.
Formatting also takes up space.
“USB preference” (for advanced users)
Your preferred connection mode will be used every time you connect the
ARCHOS to a computer. The connection mode determines how your device inter-
acts with your computer:
Mode 1: “Windows Media Device”: Recommended for users of Windows® XP or
higher & WMP10 or higher. When set to this mode, the ARCHOS uses the Media
Transfer Protocol (MTP).
The ARCHOS will ask you if you want to charge it or con-
nect it: choose to connect it. When connected to your computer, your ARCHOS
will be locked.
You will be able to synchronize your media library automatically
every time you connect your ARCHOS to your computer (with WMP10 or higher).
When your le transfer is over, simply unplug the cable from the ARCHOS, and
your device will update the ARCLibrary (Music/Photo libraries).
Mode 2: “PC Hard Drive”: Recommended for users of Windows® XP with Windows
Media® Player 9, Windows® 2000, Me, Mac® OS X or Linux. The ARCHOS will ask
you if you want to charge it or connect it as a mass storage device (Hard Drive).
Choose to connect it as a mass storage device (external hard drive). When connected
to your computer, your ARCHOS will be locked. Disconnection: when the le transfer
is over, safely unmount the ARCHOS (See:
Disconnecting
) and your device will do a
quick ARCLibrary update (Music/Photo libraries). May not index all les.
Mode 3: “PC Hard Drive (auto-ARCLib)”: Same as mode 2, but with a full
ARCLibrary update (Music/Photo libraries) at disconnection.
“Update ARCLibrary”
Available only when “USB Preference” is set to “PC Hard Drive” (mode 2).
-
-
-
-
-
-
MANUAL
V2.0
GEN 5 MAIN SETTINGS > P. 65
This USB mode only does a quick ARCLibrary update (Music/Photo libraries). Use
the “Update ARCLibrary” button if you want to do a full ARCLibrary update.
“Product Key”
each ARCHOS has a unique number.
you will need this number to register your product online (www.archos.com/register).
605 “MAC address”
some WiFi networks lter MAC addresses. You might need to communicate this
address to the person who manages the network.
“Repair and Formatting Tools”
use this button to access the “Repair and Formatting Tools” settings screen. This
screen allows you to do the following actions:
“Clear temporary system les and cache” (does not erase any data)
605 “Reset WiFi conguration” (WiFi settings are lost)-
“Format Hard Drive” (erase all data, media les, and licenses)
“Full Reinitialization” (erase all data, media les, licenses and settings)
In the event that your ARCHOS freezes or does not respond anymore, try to
reset it (see: Troubleshooting).
If this does not work or if you cannot access the Repair and Formatting Tools,
you can try a system recovery (see: Troubleshooting).
-
-
-
-
-
-
-
-
MANUAL
V2.0
GEN 5 OPTIONAL FUNCTIONALITIES > P. 66
9. OPTIONAL FUNCTIONALITIES
9.1 ARCHOS ACCESSORIES
DVR STATION GEN 5
When connected to your ARCHOS and to your home enter-
tainment system, the DVR Station Gen 5 will allow you to:
schedule TV recordings easily via the ARCHOS TV Program
Guide (EPG) (available for most countries).
record video directly to your ARCHOS, from your cable box, sat-
ellite receiver, digital tuner, or most any standard video source.
connect a compatible USB device to your ARCHOS (Mass
storage or PTP).
play video back to your TV.
charge your ARCHOS.
•
•
•
•
•
DVR TRAVEL ADAPTER
When connected to your ARCHOS, the DVR Travel Adapter will
allow you to:
record audio/video, directly on your ARCHOS, from most
any standard audio/video source.
•
MINI DOCK
When connected to your ARCHOS, the Mini Dock will allow you to:
display the image of the ARCHOS on your TV.
connect a compatible USB device to your ARCHOS (Mass
storage or PTP).
charge your ARCHOS.
•
•
•
BATTERY DOCK
The battery dock is like the Mini Dock but also includes a bat-
tery to give your ARCHOS extra play time.
MANUAL
V2.0
GEN 5 OPTIONAL FUNCTIONALITIES > P. 67
HELMET CAMCORDER
High resolution Mini-Cam with remote control and microphone.
9.2 ARCHOS PLUG-INS
CINEMA PLUG-IN
To allow you to play MPEG-2 (.VOB) video les without any re-en-
coding (type of le found on DVDs). Also allows playback of AC3
audio format.
VIDEO PODCAST PLUG-IN
To allow you to play H.264 video les without any special re-encod-
ing (type of le often used for video podcasts). Also allows playback
of AAC music les (non-protected).
605
WEB BROWSER PLUG-IN
A specially designed Internet browser for your ARCHOS that will
allow you to surf the web on your ARCHOS. Supports websites
with Flash™.
9.3 SCHEDULING A TV RECORDING
With the optional DVR Station Gen 5 connected to your home tuner
(cable box, satellite receiver, digital tuner or VCR), you will be able to
schedule recordings easily via the ARCHOS TV Program Guide (EPG).
In the Home screen, select the “Recorder” icon to display the ARCHOS TV
Program Guide (EPG).
1.
MANUAL
V2.0
GEN 5 OPTIONAL FUNCTIONALITIES > P. 68
This screen’s menu items will allow you
to choose a different day, update the
Program Guide data, or change vari-
ous settings (program guide update and
channel list conguration).
Navigate through the different TV pro-
grams, and simply select the one you
wish to record.
2.
3.
When the time comes, your ARCHOS will automatically start recording the
scheduled program.
The manual that comes with the DVR Station Gen 5 will tell you more about how to setup
and use the TV Program Guide.
9.4 RECORDING EXTERNAL VIDEO MANUALLY
With the optional DVR Station Gen 5, DVR Travel Adapter or Helmet
CamCorder, you will be able to record video from most any standard
video source:
In the Home screen, select the “Recorder” icon and use the tabs to access the
“Video recorder” mode.
This screen will allow you to adjust the recording sound volume (left/right ar-
rows), or change various settings (scheduling and video parameters).
You can now tell the ARCHOS to start recording from the video source (“Start
recording” red icon/menu item).
Close the screen to stop and save the recording*.
The manual that comes with the DVR Station Gen 5 or DVR travel Adapter will tell you
more about how to record external video manually.
* All video recordings made by your ARCHOS device are saved in the Video
folder. If you wish to keep them in a different location, you can use the “Move”
function of the ARCHOS le browser after recording (see: Using the File
Browser).
4.
1.
2.
3.
4.
MANUAL
V2.0
GEN 5 OPTIONAL FUNCTIONALITIES > P. 69
9.5 RECORDING EXTERNAL AUDIO MANUALLY
With the optional DVR Station Gen 5 or DVR Travel Adapter, you will be
able to record audio from most any standard audio source.
In the Home screen, select the “Recorder” icon and use the tabs to access the
“Video recorder” mode. Then select the “Audio recorder” menu item.
This screen will allow you to adjust the recording sound volume (left/right ar-
rows), or change various settings (recording title, audio format).
You can now tell the ARCHOS to start recording from the audio source (“Start
recording” red icon/menu item).
Close the screen to stop and save the recording*.
The manual that comes with the DVR Station Gen 5 or DVR travel Adapter will tell you
more about how to record external audio manually.
* All audio recordings made by your ARCHOS device are saved in the Music/
(Rec) folder. If you wish to keep them in a different location, you can use the
“Move” function of the ARCHOS le browser after recording (see: Using the
File Browser).
9.6 DISPLAYING THE ARCHOS ON A TV
With the optional DVR Station Gen 5, Battery Dock or Mini dock, you will be able
to display the image of the ARCHOS on your TV.
Connect the ARCHOS with the adapter to the TV, press the TV/LCD button on the
ARCHOS, and the display of the ARCHOS will switch to the TV.
When the image is displayed on a TV, the TV/LCD LED indicator lights up and the
built-in LCD screen turns off.
The manual that comes with the DVR Station Gen 5, Battery Dock or Mini dock will tell you
more about how to display the image of the ARCHOS on your TV.
9.7 EDITING VIDEO FILES
Video les recorded with the ARCHOS DVR Station Gen 5 or Travel Adapter can
be edited by deleting the sections you do not wish included. The editing you can
do is either cropping or cutting of particular segments of the video le.
You will mark a segment of your video le, and then you will tell the ARCHOS to
delete everything except the marked segment or to delete the marked segment from
the video le. These operations can be done multiple times on the same video le.
1.
2.
3.
4.
•
•
•
•
•
MANUAL
V2.0
GEN 5 OPTIONAL FUNCTIONALITIES > P. 70
Once nished, you will have the option to save the edit marks with the video or
to write a new video le. If you save your le with edit marks, you can always go
back and change your edits at another time. The actual video information is not
deleted. On the other hand, you can write a new le which will only include the
video parts that you specied in the edit session. This le will be smaller but you
can never un-edit it.
EXAMPLE 1
You have recorded a music video program and would like to keep one single music
presentation. But you do not want to keep the rest of the television recording.
Beginning of recording Video section to keep End of recording
Open the video le you want to edit and pause it (See:
Playing Video
).
In the progression bar, go to the beginning of the desired section (a), select the
“Insert a mark” menu item, and choose “Start Mark”.
Forward to the end of the desired section (b), select the “Insert a mark” menu
item, and choose “End Mark”.
Select the “Edit Selection” menu item and choose “Crop”, which will delete
everything except the designated section.
EXAMPLE 2
You have recorded a television program but would like to remove certain sections
before the program started, parts during the program, and the program afterwards
because you had recorded a little extra.
Open the video le you want to edit and pause it (See:
Playing Video
).
In the progression bar, go to the beginning of the rst undesired section (a), select
the “Insert a mark” menu item, and choose “Start Mark”. Forward to the end
of the rst undesired section (b), select the “Insert a mark” menu item, and
choose “End Mark”. Select the “Edit Selection” menu item and choose “Cut”,
which will cut out this part of the recording.
•
1.
2.
3.
4.
1.
2.
MANUAL
V2.0
GEN 5 OPTIONAL FUNCTIONALITIES > P. 71
Go to the beginning of the second undesired section (c), select the “Insert a
mark” menu item, and choose “Start Mark”. Forward to the end of the second
undesired section (d), select the “Insert a mark” menu item, and choose “End
Mark”. Select the “Edit Selection” menu item and choose “Cut”, which will cut
out this section.
Do the same for the other section(s) that you want to cut out.
If you want to keep the edit points and be able to re-edit another time, select
the “Save edit” menu item, and choose “Save”.
If you want to save the edited le as a new individual le, select the “Save
edit” menu item, and choose “Write to new File”. A conrmation screen
will pop up.
If you want to cancel the edit points and restart editing, choose the “Cancel
changes and restart edit” menu item.
•
•
•
3.
4.
MANUAL
V2.0
GEN 5 TROUBLESHOOTING > P. 72
TROUBLESHOOTING
RESETTING YOUR ARCHOS
In the event that your ARCHOS freezes or does not respond anymore, try to reset
it: press the button for 15 seconds (the ARCHOS will shut down completely)
and turn it on as usual.
If this does not work, you can also press the “master reset” button as shown be-
low. You can use the end of a paper clip to press the button in the hole.
405
On the left side of the device:
605
Underneath the device:
Note: Resetting your ARCHOS will not erase any data from your device.
SYSTEM RECOVERY
If your ARCHOS does not respond correctly, or does not show certain songs or
videos that you have copied to it, try using the “Repair and Formatting Tools”
(see:
System Settings
).
If using the “Repair and Formatting Tools” did not solve your problem, you can
try a system recovery. It allows you to repair the hard drive, format it, etc.
Press the button to turn on your device.
When the built-in LCD screen turns on, immediately press and hold the TV/LCD
button until the Recovery mode starts (blue screen).
To move from an option to another, use the up/down Navigation buttons.
To validate an option, press OK.
•
•
•
•
•
•
1.
2.
MANUAL
V2.0
GEN 5 TROUBLESHOOTING > P. 73
The system recovery mode gives you several options:
“No”
cancels the system recovery.
“Repair Disk”
attempts to repair the le structure on the hard drive.
does not erase any data.
“Format Disk”
formats the hard drive.
all data (music, photos, videos, etc.), licenses and settings are erased.
605 TOUCHSCREEN PROBLEMS
If the touchscreen is not responding
properly, or if it is not responding
at all, go to the “Display” settings
screen.
Then use the “Touch-Screen
Calibration” button, and follow the
instructions on the screen.
See:
“Touch-Screen Calibration”
.
•
•
•
REPAIR AND FORMATTING TOOLS
to access the “Repair and Formatting Tools” settings screen: from the Home
screen, select the “Settings” menu item, choose “System”, then use the “Repair
and Formatting Tools” button. This screen allows you to do the following actions:
-
-
-
-
-
-
MANUAL
V2.0
GEN 5 TROUBLESHOOTING > P. 74
“Clear temporary system les and cache” (does not erase any data)
605 “Reset WiFi conguration” (WiFi settings are lost)-
“Format Hard Drive” (erase all data, media les, and licenses)
“Full Reinitialization” (erase all data, media les, licenses and settings)
In the event that your ARCHOS freezes or does not respond anymore, try to
reset it (see: Resetting your ARCHOS).
If this does not work or if you cannot access the Repair and Formatting Tools,
you can try a system recovery (see: System Recovery).
-
-
-
MANUAL
V2.0
GEN 5 TECHNICAL SPECIFICATIONS > P. 75
TECHNICAL SPECIFICATIONS
CAPACITY
See packaging
.
DISPLAY
605 High resolution 4.3’’ TFT LCD, 16 million colors, 800x480 pixels.
Touch Screen
-
-
405 High resolution 3.5’’ TFT LCD, 320 x 240. -
VIDEO PLAYBACK**
MPEG-4(2) (ASP@L5 AVI, up to DVD resolution).
WMV (MP@ML, up to DVD resolution).
With optional software plug-ins (available for purchase at www.archos.com):
Video Podcast plug-in: H.264 up to DVD resolution and AAC.
Cinema Plug-in: MPEG-2 MP@ML up to 10 Mbps (up to DVD resolution) and
AC3 stereo sound (5.1).
AUDIO PLAYBACK**
Stereo MP3 decoding @ 30-320 Kbits/s CBR & VBR, WMA, Protected WMA, WAV
(PCM/ADPCM).
With optional software plug-ins (available for purchase at www.archos.com):
AAC(3) stereo audio les.
AC3 stereo audio and 5.1 sound les.
PHOTO VIEWER***
JPEG, BMP, PNG.
PDF VIEWER
Reads PDF documents. May not implement all PDF features.
VIDEO RECORDING(4)
Via the optional DVR Station Gen 5 or DVR Travel Adapter. Records NTSC/PAL/
SECAM in MPEG-4 AVI format with stereo sound, VGA resolution (640 x 480) @
30 or 25 f/s.
•
•
•
•
-
-
•
•
-
-
•
•
•
MANUAL
V2.0
GEN 5 TECHNICAL SPECIFICATIONS > P. 76
AUDIO RECORDING
Via the optional DVR Travel Adapter or DVR Station Gen 5: stereo line-in, WAV
(IMA ADPCM or PCM) format.
INTERFACES
USB 2.0 High-Speed Device (compatible USB 1.1): Mass Storage Class (MSC) and
Media Transport Protocol (MTP).
USB 2.0 Host: Mass Storage Class (MSC) and Picture Transfer Protocol (PTP) with
optional Mini Dock, Battery Dock and DVR Station Gen 5.
CONNECTIONS
605 WiFi (802.11b/g) connection. Optional Internet plug-in (Opera® web
browser - supports Adobe Flash® content) for web browsing. Available for
purchase at www.archos.com)
•
405 USB 2.0 port.•
SD Slot compatible with SD, mini SD and micro SD card
(Only on the models that
feature a built-in ash memory).
3.5 mm mini jack for headphones.
Docking connectors to connect DVR Station Gen 5 and other ARCHOS accessories.
605
SPEAKERS
Built-in speaker
POWER SOURCE
Internal: Lithium-Ion Polymer battery.
Device charges via computer USB port.
External: Power adapter/charger (via optional accessories).
SCALABILITY
Downloadable rmware updates.
PACKAGE INCLUDES
ARCHOS device, headphones, ARCHOS USB cable, protective pouch, DVR Adapter
Quick Start Guide (QSG), legal and safety notice.
605 2 stylus•
•
•
•
•
•
•
•
•
•
•
•
•
MANUAL
V2.0
GEN 5 TECHNICAL SPECIFICATIONS > P. 77
COMPUTER SYSTEM REQUIREMENTS
For Computer:
PC with Windows® ME, 2000, XP, Vista, Media Center.
Macintosh® OS X or higher (with USB Mass Storage Class support).
Linux (with mass storage device support), USB port.
For PlaysForSureTM audio, video and subscription services: PC with Windows® XP
SP1 or higher, Windows Media® Player 10 or higher, and USB 2.0 port.
* 1GB= 1 billion bytes; actual formatted capacity is less.
** Certain bitrates, resolutions, and/or le variations may not be compatible.
*** Certain resolutions and le sizes may not be compatible.
(2)
(MPEG-4: ISO standard by Moving Picture Experts Group; AVI: audio/video le contain-
er by Microsoft) without GMC and Quarter Pixel and WMV (including protected WMV).
(3)
Does not read AAC protected les.
(4)
External video output disabled for Macrovision®-protected contents.
LCD PIXEL POLICY
The LCD screen on your ARCHOS unit has been manufactured to rigorous standards
to provide a high quality viewing experience. Nevertheless, your LCD screen may have
slight imperfections. This is not particular to the ARCHOS screen, but to all devices
which have LCD screens regardless of the original manufacturer of the LCD. Each prod-
uct vendor guarantees that his screen will contain no more than a certain number of
defective pixels. Each screen pixel contains three dot elements (Red, Blue, and Green).
One or all of the dots in a given pixel may be stuck on or stuck off. A single dot stuck
off is the least noticeable. All three dots of a pixel stuck on is the most noticeable.
605 ARCHOS guarantees that this device’s screen will have no more than 3 defec-
tive pixels (regardless if these pixels have one or more defective dots). This means that
during the period of guarantee for your country or jurisdiction, if the screen on your
product has four or more defective pixels, ARCHOS will repair or replace your product
at its cost. Thus, three or less defective pixels is not grounds for replacement or repair
of the product.
405 ARCHOS guarantees that this device’s screen will have no more than 2 defec-
tive pixels (regardless if these pixels have one or more defective dots). This means
that during the period of guarantee for your country or jurisdiction, if the screen on
your product has three or more defective pixels, ARCHOS will repair or replace your
product at its cost. Thus, two or less defective pixels is not grounds for replacement
or repair of the product.
•
-
-
-
•
MANUAL
V2.0
GEN 5
All brands and product names are registered trademarks and the property of their respec-
tive owners. Windows Media® and Windows® are trademarks or registered trademarks
of Microsoft Corporation in the United States and/or other countries. Specications
are subject to change without notice. Errors or omissions excepted. Images and illus-
trations may not always match contents. All the information contained in this guide
was correct at the time of publication.
COPYRIGHT ARCHOS © 2007. All rights reserved.
TECHNICAL SUPPORT INFORMATION > P. 78
TECHNICAL SUPPORT INFORMATION
Need Help? You can nd the information you need:
On our Website: see the frequently asked questions section on
www.archos.com/faq
By asking our technical support team: visit www.archos.com/support for e-mail
support.
U.S. & Canada: Call 877-300-8879 (toll free).
•
•
•
