SB8200
DOCSIS 3.1 Ultra Fast Cable Modem
PRODUCT OVERVIEW:
FEATURES:
•2x2 OFDM/ OFDMA DOCSIS® 3.1 channels and/or 32x8 SCQAM
DOCSIS® 3.0
•1.2 GHz Full Capture Bandwidth Tuner
•Multi Processor Technology with ARM based Application Processor
•Dual Gigabit Ethernet Ports with Auto Negotiate and Auto MDIX
•Switchable upstream filters for 42 MHz or 85MHz operation
•Switchable downstream filters for 85MHz or 108MHz with option
for 258MHz and an upper edge of 1218MHz
•US and DS spectrum analyzer
•LEDs indicate DOCSIS 3.0 or DOCSIS 3.1 Operation
•Color coded Rear Panel for ease of installation
•ARRIS Consumer Support via Phone, Email, and Chat
•PNM based network monitoring and diagnosis for Service Provider
troubleshooting
SB8200 supporting DOCSIS 3.1 allows unprecedented data rates to be delivered to Retail consumers. The SB8200 is
designed to easily deploy Gigabit+ data services. Switchable US and DS filters are designed to produce superior RF
performance while reducing interference in the home network and allowing the flexibility required for the Cable
Operators to transition from DOCSIS 3.0 to DOCSIS 3.1. Increased DRAM and Flash allow new applications to be
deployed on the modem. This feature-packed unit is intended to serve as the hub of the subscribers network,
connecting all IP capable devices (Internet, Data, Voice and Video) throughout the customers premises.
Residential and Small Business High Speed Data Customers often opt to purchase and control their own network
devices, avoiding Cable Operator modem lease fees. With the SB8200, consumers can leverage the newest
technology and highest data rates offered by their Service Providers. The SB8200 is backward compatible to the
highest DOCSIS 3.0 speeds possible, allowing a purchaser to ‘future proof’ their purchase with the best DOCSIS 3.0
speeds until the Service providers upgrade their network technology to offer DOCSIS 3.1 service.
The SB8200 will help lead the future to advanced home and small office services.
Copyright Statement: © 2016 ARRIS Enterprises LLC. All rights reserved. No part of this publication may be reproduced in any form or by any means or used to make any
derivative work (such as translation, transformation, or adaptation) without written permission from ARRIS Enterprises, LLC (“ARRIS”). ARRIS reserves the right to revise this
publication and to make changes in content from time to time without obligation on the part of ARRIS to provide notification of such revision or change. ARRIS, SURFboard and
the ARRIS logo are all registered trademarks of ARRIS Enterprises, LLC. Other trademarks and trade names may be used in this document to refer to either the entities claiming the
marks or the names of their products. ARRIS disclaims proprietary interest in the marks and names of others.
Note: The capabilities, system requirements and/or compatibility with third-party products described herein are subject to change without notice.
For information on additional SURFboard products please visit
www.SURFboard.com
For product support please visit
www.arris.com/consumers
Specifications
SB8200
DOCSIS3.1 Cable Modem
2000 Mbps
GigE
10,000 Mbps
1000 Mbps x 2
DOCSIS 3.1 Upstream
Interface Speeds
Physical
Operating Temperature °C0 to 50
Operating Relative Humidity 5-85% (Non condensing)
Storage Temperature °C-40 to 70
Dimensions (H x W x D) in. 5.24” x 5.24” x 1.65”
Weight lbs 2.1
Diagnostic LED’s (Front) Power, US/DS, Online,
Diagnostic LED’s (Rear) Ethernet Link/Speed
Interfaces
RF Interface 1 External‘F’type connector
Data Interfaces (bridged) 2 x 10/100/1000 Base-T Ethernet
(RJ-45 connector)
Home port
Input Voltage (nominal) 115VAC, 60 Hz
RF Downstream
Bonded Channels Up to 32 SCQAM or 2 OFDM
Tuner Configuration
Configurable Diplex Filter Full capture tuning range
108MHz-258MHz
Frequency Range (MHz) 108MHz-1218MHz DOCSIS
DOCSIS Data Rate (Mbps Max.) 10 Gbps
RF Input Sensitivity Level (dBmV) -15 to +15 (DOCSIS)
RF Upstream
Bonded Channels Up to 8 SCQAM or 2 OFDMA
Frequency Range (MHz)
Configurable Diplex Filter 5 MHz to 85 MHz
42MHz-85MHz
Data Rate (Mbps Max.) Over 2 Gbps
RF Output Level (dBmV ) +65 dBmV (64 QAM, single
upstream)
+57dBmv (64QAM, 4-8 upstreams)
+65dBmV (16 QAM, single
upstreams)
Ordering Information
Model Description Part Number
SB8200 DOCSIS3.1 Cable
Modem 1000205
DOCSIS 3.1 Downstream OFDM
Compliance
Certification Compliant Class B Digital Device –
Part 15 of the Federal
Communications Commission (FCC),
DOCSIS 3.1
Environmental RoHS, Energy Efficient Ethernet,
CeC, Pb-Free, Compliant with SNE
Voluntary Environmental Agreement
