Arris SVG2482AC User Guide Manual SVG2482AC: UG

User Manual: Arris SVG2482AC SVG2482AC: User Guide

Open the PDF directly: View PDF .
Page Count: 64

Safety and Regulatory Information
Getting Started
Product Overview
Installing the Gateway
- Connect the SVG2482AC to Your Client Device
  - Connect Your Telephone
  - Install the Battery
- Establish an Internet Connection
Setting Up a Wireless Network Connection
Using the Gateway Web Manager
- Start the SVG2482AC Web Manager
  - SVG2482AC Web Manager Menu Links
- Exit the SVG2482AC Web Manager
Configuring Your Wireless Network
- Set Up Your Wireless Network
- Set Up WPS on Your Wireless Network
Protecting & Monitoring Your Wireless Network
Managing Your Gateway and Connected Networks
Troubleshooting Tips
- Solutions
- Front Panel LED Icons and Error Conditions
Warranty Information

SURFboard® SVG2482AC

Wireless Voice Gateway

For XFINITY® Customers

User Guide

April 2017

ARRIS Copyrights and Trademarks

No part of this publication may be reproduced in any form or by any means or used to make

any derivative work (such as translation, transformation, or adaptation) without written

permission from ARRIS Enterprises, LLC (“ARRIS”). ARRIS reserves the right to revise this

publication and to make changes in content from time to time without obligation on the part

of ARRIS to provide notification of such revision or change.

ARRIS, SURFboard, and the ARRIS logo are all trademarks of ARRIS Enterprises, LLC. Other

trademarks and trade names may be used in this document to refer to either the entities

claiming the marks or the names of their products. ARRIS disclaims proprietary interest in

the marks and names of others.

Wi-Fi Alliance®, Wi-Fi®, the Wi-Fi logo, the Wi-Fi CERTIFIED logo, Wi-Fi Protected Access®

(WPA), the Wi-Fi Protected Setup logo, and WMM® are registered trademarks of Wi-Fi

Alliance. Wi-Fi Protected Setup™, Wi-Fi Multimedia™, and WPA2™ are trademarks of Wi-Fi

Alliance.

ARRIS provides this guide without warranty of any kind, implied or expressed, including, but

not limited to, the implied warranties of merchantability and fitness for a particular purpose.

ARRIS may make improvements or changes in the product(s) described in this manual at any

time.

The capabilities, system requirements and/or compatibility with third-party products

described herein are subject to change without notice.

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

Table of Contents

1. Safety and Regulatory Information .......................................................................... 5

Important Safety Instructions ............................................................................................ 5

FCC Statements .................................................................................................................. 7

Wireless LAN Information.................................................................................................. 8

Caring for the Environment by Recycling Your ARRIS Equipment ..................................... 9

2. Getting Started ..................................................................................................... 10

Introduction ..................................................................................................................... 10

In The Box ............................................................................................................... 10

System Requirements ...................................................................................................... 11

Contact Information ........................................................................................................ 12

3. Product Overview ................................................................................................. 13

Front Panel ...................................................................................................................... 13

Wi-Fi Protected Setup™ (WPS) ............................................................................... 14

Rear Panel ........................................................................................................................ 14

Gateway Label ................................................................................................................. 16

4. Installing the Gateway .......................................................................................... 17

Connect the SVG2482AC to Your Client Device .............................................................. 17

Connect Your Telephone ........................................................................................ 18

Install the Battery ................................................................................................... 19

Establish an Internet Connection .................................................................................... 19

5. Setting Up a Wireless Network Connection ............................................................ 21

Set Up a Wireless Network Connection Using Your Client Device .................................. 21

Quick Connect Using the Windows Taskbar ........................................................... 22

Connect Using the Windows Control Panel ............................................................ 25

Connect Your WPS-Enabled Device ................................................................................. 27

Test Your Wireless Network Connection ......................................................................... 27

6. Using the Gateway Web Manager ......................................................................... 28

Start the SVG2482AC Web Manager ............................................................................... 28

SVG2482AC Web Manager Menu Links .................................................................. 30

Exit the SVG2482AC Web Manager ................................................................................. 32

7. Configuring Your Wireless Network ....................................................................... 33

Set Up Your Wireless Network ........................................................................................ 33

Set Up WPS on Your Wireless Network ........................................................................... 36

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

8. Protecting & Monitoring Your Wireless Network ................................................... 38

Prevent Unauthorized Access .......................................................................................... 38

Change the Default Administrator Password .................................................................. 38

Logging on to the SVG2482AC ................................................................................ 39

Changing Your Admin Password ............................................................................. 41

Set Up Firewall Protection ............................................................................................... 41

Set Up Parental Control ................................................................................................... 44

Manage Website Access ......................................................................................... 44

Set Up Port Forwarding ................................................................................................... 46

Set Up Port Triggers ......................................................................................................... 48

Set Up the DMZ Host ....................................................................................................... 49

9. Managing Your Gateway and Connected Networks ............................................... 51

View the Gateway Hardware Information ...................................................................... 51

View the Gateway Software Version ............................................................................... 51

View the Gateway Network Connections ........................................................................ 52

View the Network Connection Settings .......................................................................... 53

View the XFINITY Network Connection Status ................................................................ 54

Reboot Your SVG2482AC ................................................................................................. 55

Reboot SVG2482AC Using the Reset Button .......................................................... 55

Reboot SVG2482AC Using the Web Manager ........................................................ 55

Reset Your SVG2482AC .................................................................................................... 56

Reset SVG2482AC Using the Reset Button ............................................................. 57

Reset SVG2482AC Using the Web Manager ........................................................... 57

Exit the SVG2482AC Web Manager ................................................................................. 58

10. Troubleshooting Tips ............................................................................................. 59

Solutions .......................................................................................................................... 59

Front Panel LED Icons and Error Conditions .................................................................... 60

11. Warranty Information ........................................................................................... 62

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

Chapter 1

Safety and Regulatory Information

Important Safety Instructions

Read This Before You Begin — When using your equipment, basic safety precautions should

always be followed to reduce the risk of fire, electric shock, and injury to persons, including

the following:

 Read all of the instructions listed here and/or in the user manual before you operate this

device. Give particular attention to all safety precautions. Retain the instructions for

future reference.

 This device must be installed and used in strict accordance with manufacturer’s

instructions, as described in the user documentation that is included with the device.

 Comply with all warning and caution statements in the instructions. Observe all warning

and caution symbols that are affixed to this device.

 To prevent fire or shock hazard, do not expose this device to rain or moisture. The device

must not be exposed to dripping or splashing. Do not place objects filled with liquids, such

as vases, on the device.

 This device was qualified under test conditions that included the use of the supplied

cables between system components. To ensure regulatory and safety compliance, use

only the provided power and interface cables and install them properly.

 Use only the Power cord supplied for this model in the original packaging or supplied as a

replacement by ARRIS or your service provider.

 Installation of this device must be in accordance with national wiring codes and conform

to local regulations.

 Operate this device only from the type of power source indicated on the device’s marking

label. If you are not sure of the type of power supplied to your home, consult your dealer

or local power company.

 Do not overload outlets or extension cords, as this can result in a risk of fire or electric

shock. Overloaded electrical outlets, extension cords, frayed power cords, damaged or

cracked wire insulation, and broken plugs are dangerous. They may result in a shock or

fire hazard.

 Route power supply cords so that they are not likely to be walked on or pinched by items

placed upon or against them. Pay particular attention to cords where they are attached to

plugs and convenience receptacles, and examine the point where they exit from the

device.

Chapter 1: Safety and Regulatory Information

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

 Place this device in a location that is close enough to an electrical outlet to accommodate

the length of the power cord.

 Place the device to allow for easy access when disconnecting the power cord of the device

from the electrical wall outlet.

 Do not connect the plug into an extension cord, receptacle, or other outlet unless the plug

can be fully inserted with no part of the blades exposed.

 Place this device on a stable surface.

 Avoid damaging the device with static by touching the coaxial cable when it is attached to

the earth-grounded coaxial cable-TV wall outlet.

 Always first touch the coaxial cable connector on the device when disconnecting or

reconnecting the Ethernet cable from the device or user’s PC.

 It is recommended that the customer install an electrical surge protector in the electrical

outlet to which this device is connected. This is to avoid damaging the device by local

lightning strikes and other electrical surges.

 Postpone installation until there is no risk of thunderstorm or lightning activity in the area.

 Do not use this product near water: for example, near a bathtub, washbowl, kitchen sink

or laundry tub, in a wet basement, or near a swimming pool.

 Do not cover the device or block the airflow to the device with any other objects. Keep the

device away from excessive heat and humidity and keep the device free from vibration

and dust.

 Wipe the device with a clean, dry cloth. Never use cleaning fluid or similar chemicals. Do

not spray cleaners directly on the device or use forced air to remove dust.

 For added protection, unplug the device from the wall outlet and disconnect the cables to

avoid damage to this device during lightning activity or power surges.

 Upon completion of any service or repairs to this device, ask the service technician to

perform safety checks to determine that the device is in safe operating condition.

 Do not open the device. Do not perform any servicing other than that contained in the

installation and troubleshooting instructions. Refer all servicing to qualified service

personnel.

 This device should not be used in an environment that exceeds 104° F (40° C).

SAVE THE ABOVE INSTRUCTIONS

Note to CATV System Installer — This reminder is provided to call the CATV system installer’s

attention to Article 820.93 and 820.100 of the National Electric Code, which provides

guidelines for proper grounding and, in particular, specifies that the Coaxial cable shield shall

be connected to the grounding system of the building, as close to the point of cable entry as

practical.

Chapter 1: Safety and Regulatory Information

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

FCC Statements

FCC Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential environment. This equipment

generates, uses, and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If

this equipment does cause harmful interference to radio or television reception, which can be

determined by turning the device off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

 Reorient or relocate the receiving antenna.

 Increase the separation between the device and receiver.

 Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

 Consult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1) This device may not cause harmful interference, and (2) This device must

accept any interference received, including interference that may cause undesired operation.

FCC Caution: Any changes or modifications not expressly approved by ARRIS for compliance

could void the user’s authority to operate the equipment.

FCC Declaration of Conformity

ARRIS Enterprises, LLC, 3871 Lakefield Drive, Suwanee, GA 30024, declares that the SURFboard

DOCSIS 3.0 Wireless Voice Gateway-SVG2482AC complies with 47 CFR Parts 2 and 15 of the

FCC rules as a Class B digital device.

FCC Radiation Exposure Statement

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled

environment. To comply with the FCC RF exposure compliance requirements, the separation

distance between the antenna and any person’s body (including hands, wrists, feet and

ankles) must be at least 8 inches (20.3 centimeters).

This transmitter must not be co-located or operating in conjunction with any other antenna or

transmitter except those already approved in this filing.

The availability of some specific channels and/or operational frequency bands are country

dependent and are firmware programmed at the factory to match the intended destinations.

The firmware setting is not accessible by the end user.

Chapter 1: Safety and Regulatory Information

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

Wireless LAN Information

This device is a wireless network product that uses Direct Sequence Spread Spectrum (DSSS)

and Orthogonal Frequency-Division Multiple Access (OFDMA) radio technologies. The device

is designed to be interoperable with any other wireless DSSS and OFDMA products that

comply with:

 The IEEE 802.11 Standard on Wireless LANs (Revision AC, Revision B, Revision G, and

Revision N), as defined and approved by the Institute of Electrical Electronics Engineers

 The Wireless Fidelity (Wi-Fi) certification as defined by the Wireless Ethernet Compatibility

Alliance (WECA).

Restrictions on the Use of Wireless Devices

In some situations or environments, the use of wireless devices may be restricted by the

proprietor of the building or responsible representatives of the organization. For example,

using wireless equipment in any environment where the risk of interference to other devices

or services is perceived or identified as harmful.

If you are uncertain of the applicable policy for the use of wireless equipment in a specific

organization or environment, you are encouraged to ask for authorization to use the device

prior to turning on the equipment.

The manufacturer is not responsible for any radio or television interference caused by

unauthorized modification of the devices included with this product, or the substitution or

attachment of connecting cables and equipment other than specified by the manufacturer.

Correction of the interference caused by such unauthorized modification, substitution, or

attachment is the responsibility of the user.

The manufacturer and its authorized resellers or distributors are not liable for any damage or

violation of government regulations that may arise from failing to comply with these

guidelines.

Note: The use of the 5150-5250 MHz frequency band is restricted to Indoor Use Only.

Security Warning: This device allows you to create a wireless network. Wireless network

connections may be accessible by unauthorized users. For more information on how to

protect your network, see Protecting & Monitoring Your Wireless Network (page 38) in this

guide for more information or visit the ARRIS Support website at www.arris.com/consumer

(http://www.arris.com/consumer).

Chapter 1: Safety and Regulatory Information

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

Caring for the Environment by Recycling Your ARRIS

Equipment

Please do not dispose of this product or any included electronic accessories, i.e.,

power supply or battery, with your residential or commercial waste. ARRIS devices

may be disposed of through the ARRIS Product Recycling program, further

described at corporateresponsibility.arrisi.com/phoenix.zhtml. You may also contact

your local community authorities for information regarding where you may dispose

of your ARRIS devices.

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

Chapter 2

Getting Started

Introduction

The ARRIS SURFboard® SVG2482AC is a DOCSIS 3.0® telephony cable modem and four-port

Ethernet router device with Wi-Fi and optional battery backup. It uses DOCSIS 3.0 technology

to provide ultra high-speed Internet access on your home or small business network. Using

the connection capabilities of the gateway, you can connect your client device and other

network-enabled devices via the four Ethernet ports or the 2.4 GHz and 5 GHz Wireless

connections. The SVG2482AC connects to the existing coaxial cable connection in your home.

The SVG2482AC also includes a Wi-Fi® Pairing (WPS) button option for quick and easy

connections for your WPS-enabled devices.

This guide provides instructions for installing and configuring your SVG2482AC, setting up

secure wireless network connections, and managing your SVG2482AC and network

configurations.

In The Box

Before installing the SVG2482AC, check that the following items are also included in the box. If

any items are missing, please call ARRIS Technical Support at 1-877-466-8646 for assistance.

Table 1. SVG2482AC Package Contents

Item

Description

Blinking

On (Solid)

SVG2482AC

Wireless Voice

Gateway

High-speed DOCSIS 3.0 cable modem, two

wireless access points, and four-port Ethernet

router

Power Cord

Power adapter and cord for an electrical wall

outlet connection

Ethernet Cable

Standard Category 5 (CAT5) or higher

network cable

Chapter 2: Getting Started

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

Item

Description

Blinking

On (Solid)

Software License &

Warranty Card

Safety and regulatory information, software

license, and warranty for the gateway

Support Information

Card

Contact information for obtaining technical

support assistance with any issues you may

have with your SURFboard device.

SVG2482AC Quick

Start Guide

Provides basic information for installing the

gateway and setting up a secure wireless

connection on your home network.

Additional Items Needed (Not Included)

The following items are not included in the box and must be purchased separately, if required:

 Coaxial (coax) cable, if one is not already connected to a cable wall outlet

 RF splitter (for additional coaxial cable connections, such as a set-top box or Smart TV)

 Ethernet cable for each additional Ethernet-enabled device

System Requirements

 High-speed Internet access account

 Web browser access – Internet Explorer, Google Chrome, Firefox, or Safari

 Compatible operating systems:

 Windows®10

 Windows 8

 Windows 7 Service Pack 1 (SP1)

Note: Although older versions of Microsoft Windows operating systems are no longer

specifically supported, they should still function with this model.

 Mac® 10.4 or higher

 UNIX®

 Linux®

Chapter 2: Getting Started

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

Contact Information

For technical support and additional ARRIS product information:

 Visit the ARRIS Consumer Support website: www.arris.com/selfhelp

 Call ARRIS Technical Support: 1-877-466-8646

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

Chapter 3

Product Overview

Front Panel

Figure 1: SVG2482AC Front View

Table 2. SVG2482AC Front Panel LED Icons

LED Icon

Blinking

On (Solid)

WPS

BUTTON

WPS Pairing process is in progress.

Not applicable; LED will turn OFF after

the WPS-enabled device is connected.

POWER

Not applicable – LED does not blink.

Power is properly connected with the

device power cord and the battery is

not connected.

Scanning for Upstream (Send) and

Downstream (Receive) channel

connection.

Upstream and Downstream channels

are connected.

ONLINE

Scanning for an Internet connection.

SVG2482AC is connected to your home

network.

Chapter 3: Product Overview

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

LED Icon

Blinking

On (Solid)

WIRELESS

2.4 GHz wireless connection is active;

SVG2482AC is sending or receiving

Wi-Fi data.

Wi-Fi is enabled.

WIRELESS

5 GHz wireless connection is active;

SVG2482AC is sending or receiving

Wi-Fi data.

Wi-Fi is enabled.

TEL1

Telephone line 1 is off-hook or call is

in progress.

Telephone service for line 1 is

connected and activated; on-hook.

TEL2

Telephone line 2 is off-hook or call is

in progress.

Telephone service for Line 2 is

connected and activated; on-hook

BATTERY

AC power has failed or is not

connected; battery charge is low;

telephone is connected.

Battery is installed and fully charged.

Wi-Fi Protected Setup™ (WPS)

Wi-Fi Protected Setup (WPS) is a wireless network setup option that provides a quick and easy

solution for setting up a secure wireless network connection for any WPS-enabled device;

such as a tablet, gaming device, or printer. WPS automatically configures your wireless

network connections and sets up wireless security. See Connect Your WPS-Enabled Device

(page 27) for more information.

Rear Panel

Figure 2: SVG2482AC Rear View

Chapter 3: Product Overview

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

Table 3. SVG2482AC Rear Panel Ports & Connectors

Port Name

Description

Reset Button

Recessed button located on the rear of your SVG2482AC can be used to

restart your gateway. See Reset SVG2482AC Using the Reset Button (page

57) for more information.

USB 2.0 port connection to power on your USB device(s)

Telephone Line

Ports (1 & 2)

Two telephony ports for RJ-11 cable connections:

 VoIP connection for a single or two-line telephone

 VoIP connection for a single-line telephone

Note: For an Alarm system connection, see Connect Your

Telephone (page 57) for more information.

10/100/1000

Four one-gigabit Ethernet ports for RJ-45 cable connections:

 Yellow: LED is ON - Indicates a data transfer rate of one gigabit per

second

 Yellow: LED is Blinking - Indicates data traffic is in progress

 Amber: LED is ON - Indicates a data transfer rate of less than one gigabit

per second

 Amber: LED is Blinking - Indicates data traffic is in progress

Coaxial cable connector

MoCA

MoCA LED:

 ON – MoCA is enabled

 OFF – MoCA is disabled

Note: This is a Comcast feature along with other components that

Comcast must install.

115 VAC Power Input connector

WARNING! To avoid any damage to your SVG2482AC, only use the

power cord provided in the box.

Chapter 3: Product Overview

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

Gateway Label

Figure 3: Sample SVG2482AC Gateway Labels

The gateway label is located on the bottom of the SVG2482AC. It contains the gateway

information that you may need when contacting your service provider or ARRIS Technical

Support (page 12).

To receive Internet service, contact your service provider for assistance. You may need to

provide the following information listed on the gateway label:

 Gateway Model name (SVG2482AC)

 Gateway MAC address (HFC MAC)

 Gateway Serial number (S/N)

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

Chapter 4

Installing the Gateway

Caution: This product is for indoor use only. Do not route the Ethernet cable(s) outside of the

building. Exposure of the cables to lightning could create a safety hazard and damage the

product.

Connect the SVG2482AC to Your Client Device

Before installing your SVG2482AC:

 Check with Comcast, your service provider, to ensure that broadband cable service is

available in your area.

To set up a wireless network, you will need a high-speed Internet connection provided by

Comcast.

Note: When contacting Comcast, you may need your gateway information listed on

the gateway label located on the bottom of your SVG2482AC (see Gateway Label

page 15).

 Choose a location in your home where your client device and gateway are preferably near

existing cable and electrical wall outlets.

For the best Wi-Fi coverage in your home, a central location in your home or building is

recommended.

Note: The following installation procedure covers the wired Ethernet connection

process so that you can confirm that the SVG2482AC was properly installed and can

connect to the Internet.

Chapter 4: Installing the Gateway

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

Figure 4: SVG2482AC Connection Diagram

1. Check that a coaxial cable is already connected to a cable wall outlet or RF splitter (not

included).

2. Connect the other end of the coaxial cable to the Cable connector on the rear of the

SVG2482AC.

Use your hand to tighten the connectors to avoid damaging them.

3. Connect the Ethernet cable (included) to the Ethernet port on your client device.

4. Connect the other end of the Ethernet cable to an open Ethernet port on the rear of the

SVG2482AC.

Optional: Repeat steps 3 and 4 for an additional client device or other network device that

you want to install as a wired connection on your home network.

5. Connect the power cord (included) to the Power port on the rear of the SVG2482AC.

6. Plug the other end of the power cord into an electrical wall outlet that is not controlled by

a wall switch.

Note: This automatically powers ON the SVG2482AC.

Connect Your Telephone

f you are migrating your current XFINITY service from an existing device, your current phone

service and phone number will be transferred to the SVG2482AC when the installation is

finished. Please note, that if you do not currently have Telephony service from Comcast, you

will have to call 1-855-OK-BEGIN (1-855-652-3446) to set up an account that includes

Telephony service.

Chapter 4: Installing the Gateway

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

Note: The SVG2482AC has battery back-up capability for Telephony backup only. Battery

usage is optional. To install the battery, see Install the Battery for more information.

1. Connect a telephone cord (not included) to the TEL LINE port on your telephone.

2. Connect the other end of the telephone cord to the TEL 1 port on the rear of the

SVG2482AC.

Note: Use the Tel1 port to connect a two-line telephone. Then, contact a VoIP service

provider to activate your Telephony service.

3. Optional: For a second telephone, connect a telephone cord of a single-line telephone to

the TEL 2 port on the rear of the SVG2482AC.

Note: For an Alarm System connection with a single telephone line, connect the

Alarm Panel to the Tel2 port. If both telephone lines are providing telephony services,

use an RJ-31X adapter (not included) on the Tel1 port.

4. Check to confirm that your telephone has a dial tone.

Install the Battery

The SVG2482AC has battery backup capability for Telephony backup only. Battery usage is

optional. The SVG2482AC battery is available for purchase online at the ARRIS SURFboard

website, shop.surfboard.com/arris-telephony-modem-back-up-batteries.

1. Place the SVG2482AC on its side and locate the battery cover on the bottom of the device.

2. Press down and pull on the locking tab of the battery cover to remove it.

3. Slide the battery (label side up) with the terminal end first into the battery compartment

until it is fully seated in place.

4. Replace the battery cover with the locking tab facing upward, and then push the cover

until it snaps in place.

Note: It may take up to 12 hours for the battery to reach a full charge.

Establish an Internet Connection

Although your client device may already be configured to automatically connect to the

Internet, you should still perform the following gateway connectivity test to check that your

devices were installed properly and are successfully connected on your home network.

1. Power ON your Wi-Fi enabled device (e.g., laptop, smartphone) connected to the

SVG2482AC if it is turned off, and then log on.

2. Check the front panel LEDs on your SVG2482AC.

During startup, the Power and US/DS (Upstream/Downstream) LEDs will FLASH and then

light up SOLID white. Please note that both Wireless LEDs will blink when your Wi-Fi

enabled device is connected on your home network.

Chapter 4: Installing the Gateway

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

Note: If you are a current voice subscriber with Comcast and also purchased the

SVG2482AC, please call Comcast Customer Support at 1-855-OK-BEGIN

(1-855-652-3446) to activate your SVG2482AC.

Note: If you are a new voice subscriber with Comcast, continue with the following

steps to set up your new XFINITY telephony service account and activate your

SVG2482AC.

3. Open a web browser and then type www.xfinity.com/activate to open the XFINITY

Activation page.

4. Follow the online instructions to enter your XFINITY account number and phone number.

5. Enter the following to set up your online XFINITY login account and Wi-Fi network login

information:

 XFINITY Account Login Name

 XFINITY Account Password

 Wi-Fi Network Name

 Wi-Fi Network Password

Note: Select Show More Settings if you want to set up separate network names and

passwords for the 2.4 GHz and 5 GHz wireless radios on your SVG2482AC.

If you already have an existing Wi-Fi network and you are replacing your router or

gateway, ARRIS suggests that you use the same Wi-Fi Network Name and Password that is

currently set for your Wi-Fi network.

Your Wi-Fi devices will automatically connect to your SVG2482AC Wi-Fi network.

6. To check for Internet connectivity, open a web browser (such as Internet Explorer, Google

Chrome, Firefox, or Safari) on your device.

7. Type a valid URL (such as www.SURFboard.com) in the address bar and press Enter.

The ARRIS SURFboard website should open. If the website fails to open, please contact

your service provider to set up your Internet service or activate your SVG2482AC.

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

Chapter 5

Setting Up a Wireless Network Connection

ARRIS recommends that you first verify that your client device can connect to the Internet

using a wired Ethernet connection before configuring your wireless network.

You must currently have access to an Internet service in your home before you can set up a

wireless network connection. Please note that if you do not have Internet service already set

up in your home, contact Comcast Customer Support at 1-855-OK-BEGIN (1-855-652-3446) for

assistance. Before proceeding, make sure your client device and the SVG2482AC are

connected through an Ethernet connection.

Set Up a Wireless Network Connection Using Your

Client Device

Note: You will need the Wi-Fi Network Name (SSID) and Wi-Fi Security Key (Network

Password) to connect your client devices to your home network. The default network

name and password are listed on the SVG2482AC gateway label.

Choose one of the following wireless network connection options to set up a wireless network

connection for your client device on your home network:

 Personal Computer (PC) – Select one of the following:

 Quick Connect Using the Windows Taskbar

 Connect Using the Windows Control Panel

The steps for setting up your Wi-Fi network connection may differ slightly depending on

the version of Microsoft Windows running on your client device. The steps used in this

section apply to Windows 7.

 Android Device

From any screen on your client device:

a. Select to open the Settings screen.

b. Select Wi-Fi to turn it ON.

Your device will automatically start searching and then display a list of available

wireless networks.

c. Select your wireless network name (SSID) from the list.

d. If prompted, type your Wi-Fi Security Key (network password).

Please note that your network password may be case-sensitive.

Chapter 5: Setting Up a Wireless Network Connection

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

e. Select Connect.

If your Wi-Fi connection is successful, “Connected” will display under your wireless

network name.

 Apple Computer

From any screen on your client device:

a. Click (Wi-Fi icon) to display a list of available wireless networks.

b. Select the wireless network name (SSID) for your home network from the list.

c. If prompted, enter your network password in the Password field.

Note: Checkmark Remember this network if you want your Mac computer/client

device to automatically connect to your home network when you log on. Your

computer must be within range of your wireless network to connect to it.

d. Click OK.

 Apple Mobile Device

From the Home screen on your client device:

a. Select Settings to open the Wi-Fi screen.

b. Select Wi-Fi to turn it ON.

Your device will automatically start searching and then list the available wireless

networks.

c. Select the wireless network name (SSID) for your home network from the list to

connect it.

If your Wi-Fi connection is successful,  will display next to the wireless network

name.

Note: For more information on setting up your Wi-Fi network connections, refer to the

user documentation for your specific client device.

Quick Connect Using the Windows Taskbar

1. From the Windows taskbar on your client device, click the Wireless Link icon (see Figure 5)

to open the list of available wireless networks (see Figure 6).

Figure 5: Windows Taskbar Icons

Note: If the Wireless Link icon is not visible, left-click on the Show hidden icons

button on the Windows taskbar (see Figure 5) to open the list of additional icons.

Chapter 5: Setting Up a Wireless Network Connection

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

Figure 6: Sample Available Wireless Networks Window

2. Locate and left-click on the SVG2482AC wireless network name or SSID (for example,

SVG2482AC-#### or ARRIS-####) from the list of available wireless networks.

3. Select Connect automatically (see Figure 7) to set up your wireless devices to

automatically connect to your wireless network without having to log on using a user

password.

Figure 7: Sample Available Wireless Networks Screen

Chapter 5: Setting Up a Wireless Network Connection

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

4. Click Connect to open the Connect to a Network window and set up your new network

password.

Figure 8: Network Connection Window

5. Enter the Wi-Fi Security Key (your wireless network password) in the Security key field.

Note: You can use the default Wi-Fi Security Key code listed on the SVG2482AC

Gateway label or enter your own personal wireless network password. See Prevent

Unauthorized Access (page 38) for more information on creating user passwords.

If you have already changed your wireless network password using the SVG2482AC

Web Manager, enter that password in the Security key field.

Figure 9: Network Connection-Create Network Password Window

6. Select Hide characters and then click OK to encrypt (or hide) your network password.

Chapter 5: Setting Up a Wireless Network Connection

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

Connect Using the Windows Control Panel

1. From the Windows taskbar on your client device, click Start button and then click Control

Panel.

2. Click Network and Sharing Center to open the Network and Sharing Center window.

Figure 10: Control Panel-Network and Sharing Center Window

3. Click Manage wireless networks under Control Panel Home side panel to open the

Manage Wireless Networks window.

4. Click Add to open the Manually Connect to a Wireless Network window.

Figure 11: Manually Connect to a Wireless Network Window

Chapter 5: Setting Up a Wireless Network Connection

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

5. Click Manually create a network profile to open another Manually Connect to a Wireless

Network window.

Figure 12: Manually Connect to a Wireless Network Window

6. Enter the SVG2482AC wireless network name or SSID that you set up to activate your

SVG2482AC.

Note: You can use the SVG2482AC Web Manager to change your Wi-Fi Network

Name and Password. If you make any changes, you will have to reconnect the

devices that are connected to your Wi-Fi network.

7. Select the wireless Security level for your wireless network from the Security type

drop-down list.

Note: WPA/WPA2-PSK is the recommended wireless security level for your wireless

home network. It is the default security level for the SVG2482AC and is also the

highest security level available.

8. Select the password encryption type from the Encryption type drop-down list.

This is used for securing your wireless network.

 TKIP – Temporal Key Integrity Protocol

 AES – Advanced Encryption Standard (recommended). AES is the default encryption

type for the SVG2482AC.

9. Enter your Wi-Fi network password (Network Security Key) in the Security Key field.

Note: Remember to use a unique combination of letters, numbers, and special

characters to create a more secure password. See Prevent Unauthorized Access

(page 38) for more information.

10. Select Hide characters checkbox to prevent your Wi-Fi Security Key (network password)

from displaying in the field.

Chapter 5: Setting Up a Wireless Network Connection

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

11. Select Start this connection automatically so that your wireless devices will automatically

connect to your wireless network when they are powered on.

12. Click Next to complete the wireless network setup.

The Successfully added <Network name> message for your new wireless network should

appear.

13. Click Close to exit.

Connect Your WPS-Enabled Device

You can use the Wi-Fi Protected Setup (WPS) Pairing button on the SVG2482AC to connect

your WPS-enabled devices. WPS automatically assigns a random wireless network name (SSID)

and Wi-Fi Security Key (network password) to the SVG2482AC and your other WPS-enabled

devices to connect them to your wireless network. See Set Up WPS on Your Wireless Network

(page 36) for information on setting up WPS on your wireless network.

Note: To use the WPS Pairing button option, your client device hardware must support WPS

and also have WPA security compatibility.

1. Power ON the SVG2482AC and your other WPS-enabled devices that you want to connect

to your wireless network.

2. Press and hold the WPS button located on the top of the SVG2482AC for five to 10

seconds and then release (see Front Panel (page 13) for the SVG2482AC front view).

3. If applicable, press the WPS button on your WPS-enabled device or other

WPS-enabled device.

4. Repeat step 3 for each additional WPS-enabled device that you want to connect to your

wireless network.

Test Your Wireless Network Connection

Perform the following connectivity test to check that wireless connections were established

for the SVG2482AC and the other wireless devices on your home network:

1. Check if your wireless devices successfully connected to your wireless network, then

disconnect the Ethernet cable, if connected, from the SVG2482AC and your client

device(s).

2. Check that the Wireless LEDs on the SVG2482AC front panel light up SOLID.

3. Open a web browser on your client device, such as Internet Explorer, Google Chrome,

Firefox, or Safari.

4. Type a valid URL (such as www.SURFboard.com) in the address bar and then press Enter.

If the website failed to open, please call ARRIS Technical Support at 1-877-466-8646 for

assistance.

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

Chapter 6

Using the Gateway Web Manager

Use the SVG2482AC Web Manager to view and monitor the network configuration settings

and operational status of your SVG2482AC. You can also configure your network connections

and wireless security settings. See Protecting & Monitoring Your Wireless Network (page 38)

for more information.

Start the SVG2482AC Web Manager

Perform the following steps to open the SVG2482AC Web Manager:

1. Open a web browser (such as Internet Explorer, Google Chrome, Firefox, or Safari) on the

device connected to the SVG2482AC.

2. Type the XFINITY default LAN IP address, 10.0.0.1, in the Address bar and then press

Enter to log onto the SVG2482AC and open the SVG2482AC Login screen.

Figure 13: SVG2482AC Login Screen

3. Type the default user name and password. Both entries are case-sensitive.

Username: admin

Password: password

Note: You must enter the default user name and password if you are logging onto

the SVG2482AC Web Manager for the first time.

Chapter 6: Using the Gateway Web Manager

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

Figure 14: SVG2482AC Login Screen

4. Click LOGIN to open the SVG2482AC Web Manager.

The following message dialog box displays:

Figure 15: SVG2482AC Change Default Password Dialog Box

5. Click OK to change the default password (highly recommended for security purposes) or

Cancel to keep the default password.

 If you click OK, the Troubleshooting Change Password screen will display:

Figure 16: SVG2482AC Change Password Screen

a) Enter your current admin password in the Current Password field.

b) Enter a new admin password in the New Password field.

c) Repeat the new password in the Re-enter New Password field.

d) Select the Show Typed Password checkbox to confirm that your new passwords

match and then uncheck it when done.

Chapter 6: Using the Gateway Web Manager

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

Note: Remember that passwords are case-sensitive and that you can use

any combination of letters and numbers only. Special characters and spaces

are not acceptable.

 Letters: A through Z (uppercase and lowercase)

 Numbers: 0 to 9

e) Click SAVE to update your password.

f) Find a secure place to write down and keep your new password.

 If you click Cancel, the Gateway At a Glance screen will display (see figure below).

You can change the default password at a later time. See Change the Default Password

(page 38) for more information.

Figure 17: SVG2482R Opening Screen

SVG2482AC Web Manager Menu Links

The SVG2482AC main menu links and related submenu option links are displayed along the

left side of the SVG2482AC Web Manager screen. Click on the main menu link to expand the

list of submenu options.

Chapter 6: Using the Gateway Web Manager

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

Figure 18: SVG2482AC Web Manager Menu Links

Table 4. SVG2482AC Web Manager Menu Links

Menu Link

Function

Gateway

Displays a summary of your network connections and a list of the

connected devices on your home network.

At a Glance

Provides a list of your home network connections and connected

devices.

Connection

Displays the network connection and status information for the

XFINITY network, Local IP network, and your private Wi-Fi network.

Firewall

Configures the gateway firewall settings to protect your home

network from possible attacks from hackers or viruses.

Software

Displays information related to the gateway software version.

Hardware

Displays status information for the gateway hardware, such as the

battery status, Ethernet connection(s), and Wi-Fi connections.

Wizard

Allows you to configure the default network settings on the

gateway to set up a secure home network.

Chapter 6: Using the Gateway Web Manager

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

Menu Link

Function

Connected Devices

Provides general information for the connected devices on your

home network.

Parental Control

Allows you to set up specific restrictions to manage and control

usage for specific users and network devices on your home

network.

Advanced

Allows you to set up Port Forwarding, Port Triggering, Remote

Management for troubleshooting or maintenance purposes, the

DMZ Host, and manage the UPnP network on your home network.

Troubleshooting

Provides several options to help you resolve certain problems that

may occur with your gateway.

Exit the SVG2482AC Web Manager

To log out and close the SVG2482AC Web Manager:

 Click Logout link located in the upper right corner of the SVG2482AC Web Manager

screen.

Figure 19: SVG2482AC Web Manager Logout Link

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

Chapter 7

Configuring Your Wireless Network

The SVG2482AC supports a secure method for setting up multiple wireless access points on

your home network.

Set Up Your Wireless Network

1. From any SVG2482AC Web Manager screen, click the Gateway menu link and then click

the Connection submenu options link.

2. Click Wi-Fi under the Connection submenu options to open the Gateway Connection Wi-Fi

screen.

Figure 20: SVG2482AC Wi-Fi Connection Screen

3. Click the 2.4 GHz Edit or 5 GHz EDIT button in the Private Wi-Fi Network section to select

the wireless frequency range that you are setting up for your wireless network.

Chapter 7: Configuring Your Wireless Network

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

Figure 21: SVG2482AC 2.4 GHz Wi-Fi Connection Screen

Figure 22: SVG2482AC 5 GHz Wi-Fi Connection Screen

Chapter 7: Configuring Your Wireless Network

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

4. Click Enable or Disable in the Wireless Network field to turn ON or OFF wireless

networking on your home network.

5. Do one of the following to set the network name or SSID (Service Set Identifier) for your

home network in the Network Name (SSID) field:

 Enter a new network name for your wireless network.

The wireless network name cannot be the same name as any other SSID on your home

network. You can use any combination of letters (lowercase and uppercase), numbers,

and/or special characters (symbols) up to a maximum of 32 characters.

6. Select the wireless networking mode for your wireless network from the Mode drop-down

list:

 2.4 GHz

o 802.11 g/n

o 802.11 b/g/n (recommended)

 5 GHz

o 802.11 ac

o 802.11 n/ac

o 802.11 a/n/ac

o 802.11 n

7. Select one of the following wireless network security options for your wireless gateway

from the Security Mode drop-down list:

 2.4 GHz & 5 GHz

o WPA2-PSK (AES): Wi-Fi Protected Access version 2 with Pre-Shared Key

o WPA/WPA2-PSK (TKIP/AES) (recommended): Wi-Fi Protected Access version 2

with Pre-Shared Key (most compatible). This is the default network security option

for your SVG2482AC. It provides the highest security and performance for your

wireless network.

o Open (risky; not secure; not recommended): This network security option does not

provide any level of network security for your wireless network. It allows outside

users to connect to your Wi-Fi network without having to use a Wi-Fi Security Key

(network password).

8. Select the wireless Channel Selection mode which is used to control wireless network

interference and improve network connectivity:

 Automatic (default): The SVG2482AC selects the channel with the least amount of

Wi-Fi interference on your home network.

 Manual: Allows you to change the wireless channel number on your SVG2482AC.

9. For Manual channel mode, select a wireless Channel number from the Channel

drop-down list to improve network connectivity or Wi-Fi signal strength on your home

network.

Note: For 2.4 GHz Wi-Fi networks, it is recommended to use Channel 1, 6, or 11. In

the Wi-Fi spectrum, there are multiple wireless channels that overlap and thus

degrade wireless network performance. These channels are used for better network

performance and stability because they do not overlap.

Chapter 7: Configuring Your Wireless Network

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

10. Enter your wireless network password in the Network Password field.

You can use any combination of letters, numbers, and/or special characters.

11. Select the Show Network Password checkbox to display your network password.

12. Select the Enabled checkbox in the Broadcast Network Name (SSID) field to display your

SSID as an available wireless network to outside users.

- or -

Deselect the Enabled checkbox in the Broadcast Network Name (SSID) field to disable

displaying your SSID as an available wireless network to outside users.

Note: When Broadcast Network Name (SSID) is enabled, your SSID is visible and also

available to unauthorized wireless clients that are within range to connect to your

home network.

13. Click SAVE SETTINGS, when you are finished.

Set Up WPS on Your Wireless Network

You can set up either the Wi-Fi Protected Setup (WPS) Push Button or WPS Pin option on the

SVG2482AC to connect your WPS-enabled devices to your home network.

1. From any SVG2482AC Web Manager screen, click the Gateway menu link and then click

the Connection submenu options link.

2. Click Wi-Fi under the Connection submenu options to open the Gateway Connection Wi-Fi

screen.

Figure 23: SVG2482AC Wi-Fi Connection Screen

Chapter 7: Configuring Your Wireless Network

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

3. Click the ADD Wi-Fi PROTECTED SETUP (WPS) CLIENT button to open the Add Wi-Fi Client

(WPS) screen.

Figure 24: SVG2482AC Add Wi-Fi Client (WPS) Screen

4. Click Enable in the Wi-Fi Protected Setup (WPS) field to turn ON WPS wireless networking

on your home network.

- or -

Click Disable in the Wi-Fi Protected Setup (WPS) field to turn OFF WPS wireless

networking on your home network.

5. Click Enable in the WPS Pin Method field to turn ON the WPS Pin connection option.

- or -

Click Disable in the WPS Pin Method field to turn OFF the WPS Pin connection option.

6. Select Push Button or PIN Method from the Connection Options drop-down list to set the

WPS Pairing method for connecting your WPS-enabled devices.

- or -

Click Disable WPS wireless networking on your home network.

7. For WPS Pin connections, enter the WPS Pin number listed in the AP PIN field when you

are prompted on your WPS device screen.

For WPS Push button connections, press and hold the WPS button on your WPS-enabled

device for five or more seconds and then release.

8. Click the PAIR button on the SVG2482AC to connect your WPS-enabled device.

9. Repeat steps 6 through 8 for each additional WPS-enabled device that you want to

connect.

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

Chapter 8

Protecting & Monitoring Your Wireless Network

After you have successfully connected the SVG2482AC and your wireless devices, you should

configure the SVG2482AC to protect your wireless network from unwanted and unauthorized

access by any wireless network devices that are within range of your wireless network.

Although network security for the SVG2482AC is already configured, you can use the

SVG2482AC Web Manager to set the level of security and access that you want to allow on

your wireless network.

Prevent Unauthorized Access

Caution: For security purposes, to prevent unauthorized access to your wireless network,

ARRIS recommends that you change the default admin password after connecting to the

Internet and logging on to the SVG2482AC for the first time.

The default password (password) is commonly used and shared on the Internet. One of the

most important recommendations for securing your wireless home network is to change the

default admin password on your SVG2482AC and other wireless devices, if applicable.

To ensure that your wireless home network is secure, ARRIS recommends that you follow

these best practices for creating your admin password(s):

 Always create a secure password or passphrase that is not easily guessed.

 Use phrases instead of names so that it may be easier for you to remember.

 Use a combination of upper and lowercase letters, numbers, and symbols.

 Change your administrator password on a regular basis to protect your network.

Note: If your service provider supplied the SVG2482AC (or you did not purchase it from a retail

store), some restrictions may have been set up to block certain configuration settings, such as

changing the Login user name.

Change the Default Administrator Password

There are two procedures available for changing the administrator (admin) password used to

log on to the SVG2482AC:

 Logging on to the SVG2482AC

 Changing Your Admin Password

Chapter 8: Protecting & Monitoring Your Wireless Network

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

Logging on to the SVG2482AC

When you log on to the SVG2482AC, you will be prompted to change the default

administrator password. You will have the option to either keep the default password or

change it (recommended). Please note that if you do not change the default password, the

same message will appear every time you log on to the SVG2482AC.

1. Open a web browser (such as Internet Explorer, Google Chrome, Firefox, or Safari) on the

client device connected to the SVG2482AC.

2. Type the XFINITY default LAN IP address, 10.0.0.1, in the Address bar and then press Enter

to log onto the SVG2482AC.

The Gateway Login screen displays.

Figure 25: Gateway Login Screen

3. Type the default user name and password as they appear below.

Please note that both entries are case-sensitive:

 Username: admin

 Password: password

4. Click LOGIN to open the SVG2482AC Web Manager.

The following Change Password message displays.

Chapter 8: Protecting & Monitoring Your Wireless Network

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

Figure 26: Gateway Login Screen

5. Click OK to open the Change Password screen.

Figure 27: SVG2482AC Change Password Screen

6. Enter your current admin password in the Current Password field.

7. Enter your new admin password in the New Password field.

8. Enter your new admin password again in the Re-enter New Password field.

9. Select the Show Typed Password checkbox to confirm that the new passwords match.

Note: Remember that passwords are case-sensitive and that you can use any

combination of letters and numbers only. Special characters and spaces are not

acceptable.

 Letters: A through Z (uppercase and lowercase)

 Numbers: 0 to 9

10. Click SAVE to update your admin password.

11. Find a secure place to write down and keep your new password.

Chapter 8: Protecting & Monitoring Your Wireless Network

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

Changing Your Admin Password

ARRIS recommends that you periodically change your administrator password for network

security purposes.

1. From any SVG2482AC Web Manager screen, click the Troubleshooting menu link on the

SVG2482AC Web Manager screen.

2. Click Change Password from the Troubleshooting submenu options list to display the

Troubleshooting Change Password Screen.

Figure 28: SVG2482AC Change Password Screen

3. Enter your current admin password in the Current Password field.

4. Enter your new admin password in the New Password field.

5. Repeat your new admin password in the Re-enter New Password field.

6. Select the Show Typed Password checkbox to confirm that the new passwords match.

Note: Remember that passwords are case-sensitive and that you can use any

combination of letters and numbers only. Special characters and spaces are not

acceptable.

 Letters: A through Z (uppercase and lowercase)

 Numbers: 0 to 9

7. Click SAVE to update your admin password.

8. Find a secure place to write down and keep your new password.

Set Up Firewall Protection

You can set up firewall filters and firewall alert notifications on your wireless network. You can

also block Java Applets, Cookies, ActiveX controls, popup windows, Proxies, and website

access.

Chapter 8: Protecting & Monitoring Your Wireless Network

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

To set the firewall protection level on your SVG2482AC:

1. From any SVG2482AC Web Manager screen, click the Gateway menu link on the

SVG2482AC Web Manager screen.

2. Click Firewall from the Gateway submenu options list and then click IPv4 or IPv6 to display

the Gateway Firewall Security Levels Screen.

Figure 29: Firewall IPv4 Available Security Levels Screen

Figure 30: Firewall IPv6 Available Security Levels Screen

 Low - Common security, higher risk

Figure 31: Firewall IPv4 Security Level – Low Screen

Chapter 8: Protecting & Monitoring Your Wireless Network

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

 Medium – Safer configuration, medium risk

Figure 32: Firewall IPv4 Security Level – Medium Screen

 High – Safest configuration, highest security

Figure 33: Firewall IPv4 Security Level – High Screen

Chapter 8: Protecting & Monitoring Your Wireless Network

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

 Custom Security

Figure 34: Firewall IPv4 Security Level – Custom Screen

3. Select the security level that you want to set for your gateway firewall.

4. Click SAVE SETTINGS, when you are finished.

Set Up Parental Control

You can set up the following Parental Controls to manage and limit the usage and activity for

specific users and client devices on your home network:

 Allow or block access to specific Internet sites

 Allow or block access to specific MAC addresses

 Allow or block access based on specific keywords

 Set time limitations for computer usage or Internet access

Note: Any Parental Control filters that do not include assigned ports, will apply to all

ports. This also applies to MAC addresses as well.

You can also link each user or client device on your home network to specific rules for login,

time-access, and content filtering.

Manage Website Access

To set up managing website access:

1. From any SVG2482AC Web Manager screen, click the Parental Control menu button on

the SVG2482AC Web Manager main menu bar.

2. Click Managed Sites from the Parental Control submenu options list to display the

Parental Control Managed Sites screen.

Chapter 8: Protecting & Monitoring Your Wireless Network

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

3. Click the Enable Managed Sites button to turn ON website and keyword blocking.

Figure 35: Parental Control-Managed Sites Screen

4. Click +ADD button in the Blocked Sites section to open the Add Site to be Blocked screen.

Figure 36: Parental Control-Managed Sites Screen

Chapter 8: Protecting & Monitoring Your Wireless Network

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

5. To fully block a website, enter the website address in the URL field and then click the Yes

Always Block? button.

6. Click SAVE.

7. Repeat steps 5 and 6 for each website that you want to block.

8. To block a website for specific days and times, enter the website address in the URL field

and then click the No Always Block? button.

9. Select the Start from and End on times of the day in the Set Block Time section.

10. Select the days of the week in the Set Blocked Days section.

11. Click SAVE.

Set Up Port Forwarding

Your SVG2482AC firewall may be set up to block all device or application connections from the

Internet to the devices on your home network. Port Forwarding allows you to open specific

ports or IP addresses on the Internet behind the firewall on your home or small business

network. It also allows for remote access to your wireless computer or other client devices.

The inbound traffic from the Internet, such as specific websites or online gaming applications,

is forwarded to the designated open ports that you set up.

Note: ARRIS recommends that you manually configure the TCP/IP settings listed below on the

client device you are setting up for remote access. Otherwise, remote access to your client

device will not be available on the Internet.

 IP address

 Subnet mask

 Default gateway

 DNS address (at least one)

To set up Port Forwarding:

1. From any SVG2482AC Web Manager screen, click the Advanced menu button on the

SVG2482AC Web Manager main menu bar.

2. Click Port Forwarding from the Advanced submenu options list to display the Port

Forwarding Configuration screen.

3. Click the Enable button.

Chapter 8: Protecting & Monitoring Your Wireless Network

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

Figure 37: Advanced Port Forwarding Screen

4. Click +ADD SERVICE button to open the Port Forwarding Add Service screen.

Figure 38: Advanced Port Forwarding Screen

5. Select FTP, AIM, HTTP, PPTP, HTTPs, Telnet, SSH, or Other for the Internet data transfer

protocol from the Common Service drop-down list.

Note: If Other is selected, the Service Name field will display. Enter a name for the

service type you will be using.

6. Select TCP/UDP, TCP, or UDP for the Internet data transmission protocol from the Service

Type drop-down list.

7. Enter the IP address of your local computer that you are setting up for port forwarding in

the Server IPv4 Address field.

-or -

Enter the IP address for your local computer that you are setting up for port forwarding in

the Server IPv6 Address field.

Chapter 8: Protecting & Monitoring Your Wireless Network

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

8. Enter the starting port number of the website or online application in the Start Port field.

9. Enter the ending port number of the website or online application in the End Port field.

10. Click CONNECTED DEVICE to display the list of connected devices on your home network.

a. Select the Add selection box next to the device or website you want to connect to.

b. Click Add to exit.

11. Click SAVE.

Set Up Port Triggers

You can use Port Triggers to set up your SVG2482AC to monitor outgoing traffic on specific

ports on your home network. Port triggering can be useful for some applications such as video

conferencing, online chatting, and online gaming that may require specific port numbers with

bi-directional traffic to function properly.

To configure Port Triggers:

1. From any SVG2482AC Web Manager screen, click the Advanced menu button on the

SVG2482AC Web Manager main menu bar.

2. Click Port Triggering from the Advanced submenu options list to display the Port

Triggering Configuration screen.

3. Click the Enable button.

Figure 39: Advanced Port Triggering Screen

4. Click +ADD PORT TRIGGER button to open the Add Port Trigger screen.

Chapter 8: Protecting & Monitoring Your Wireless Network

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

Figure 40: Add Port Triggers Screen

5. Enter a name or description for the port trigger in the Service Name field.

6. Select TCP/UDP, TCP, or UDP from the Service Type drop-down list.

7. Enter the starting port number in the Trigger Port From field.

8. Enter the ending port number in the Trigger Port To field.

9. Enter the starting port number in the Target Port From field.

10. Enter the ending port number in the Target Port To field.

11. Click ADD to create the port trigger.

12. Repeat steps 4 thru 11 for each additional port trigger that you want to create.

Set Up the DMZ Host

WARNING! The gaming DMZ host is not protected by the SVG2482AC firewall. It is exposed to

the Internet and thus vulnerable to attacks or hacking from any client device on the Internet.

Consider carefully before configuring a device to be in the DMZ.

You can configure one client device on your home network to be the DMZ Host. That client

device will operate outside of the SVG2482AC firewall and allow remote access from the

Internet to your client device, gaming device, or other IP-enabled device. The DMZ Host

feature will only allow outside users to have direct access to the designated DMZ Host device

and not your home network.

To create the DMZ Host:

1. From any SVG2482AC Web Manager screen, click the Advanced menu link on the

SVG2482AC Web Manager screen.

Chapter 8: Protecting & Monitoring Your Wireless Network

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

2. Click DMZ from the Advanced submenu links list to display the DMZ screen.

3. Click the Enable DMZ button to set up the DMZ Host on your home network.

Figure 41: Advanced DMZ Screen

4. Enter the last one to three digits (from 2 to 254) of the IP address of the client device or

gaming device that you are setting up as the DMZ host.

5. Click Save, when you are finished.

Note: To disable the DMZ Host, click the Disable DMZ button and then click SAVE.

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

Chapter 9

Managing Your Gateway and Connected Networks

You can also use the SVG2482AC Web Manager to view and monitor the network

configuration settings and operational status of your SVG2482AC.

View the Gateway Hardware Information

The Gateway Hardware screen displays specific information related to the gateway device.

This information may be helpful if you have to contact ARRIS or Comcast for technical

assistance.

To open the Gateway Hardware screen:

1. From any SVG2482AC Web Manager screen, click the Gateway menu link.

2. Click Hardware from the Gateway submenu links and then click System Hardware from

the Hardware submenu options to display the Gateway System Hardware screen.

Figure 42: SVG2482AC Hardware Information Screen

View the Gateway Software Version

To open the Gateway Software screen:

1. From any SVG2482AC Web Manager screen, click the Gateway menu link.

2. Click Software from the Gateway submenu links list to display the Gateway Software

screen.

Chapter 9: Managing Your Gateway and Connected Networks

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

Figure 43: SVG2482AC Software Version Screen

View the Gateway Network Connections

The Gateway At a Glance screen displays a summarized list of your Wi-Fi network

configuration and the connected devices (online and offline) on your home network.

To open the Gateway Network Connections screen:

1. From any SVG2482AC Web Manager screen, click the Gateway menu link.

2. Click At a Glance from the Gateway submenu links list to display the Gateway At a Glance

screen.

Figure 44: SVG2482AC Network Connections Screen

3. Click View Connected Devices to display a list of the online and offline devices connected

on your home network.

Chapter 9: Managing Your Gateway and Connected Networks

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

Figure 45: SVG2482AC Connected Devices Screen

View the Network Connection Settings

1. From any SVG2482AC Web Manager screen, click the Gateway menu link.

2. Click Connection from the Gateway submenu links and then click Status from the

Connection submenu options to display the Network Connection Status screen.

Figure 46: Local IP, XFINITY, & SVG2482AC Network Settings Screen

Chapter 9: Managing Your Gateway and Connected Networks

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

View the XFINITY Network Connection Status

1. From any SVG2482AC Web Manager screen, click the Gateway menu link.

2. Click Connection from the Gateway submenu links and then click XFINITY Network from

the Connection submenu options to display the XFINITY Network Connection Status

screen.

Figure 47: XFINITY Network-Connection Status Screen

Chapter 9: Managing Your Gateway and Connected Networks

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

Reboot Your SVG2482AC

Choose one of the following options to reboot (or restart) your SVG2482AC:

 Reboot SVG2482AC Using the Reset Button

 Reboot SVG2482AC Using the Web Manager

Reboot SVG2482AC Using the Reset Button

To reboot (or restart) your SVG2482AC using the SVG2482AC Reset button:

1. Insert the end of a paper clip (or other small object with a narrow tip) into the indented

Reset button opening on the rear of your SVG2482AC.

Figure 48: SVG2482AC Reset Button

2. Press and hold the small object in place for three to four seconds.

WARNING! Do not press the Reset button for more than five seconds. If you do,

your SVG2482AC will automatically reset and your custom gateway configuration

settings (e.g., admin password, network name (SSID) and password, Parental

Controls, etc.) will be deleted and replaced with the factory default configuration.

3. Remove the paper clip or small object from the Reset opening.

Reboot SVG2482AC Using the Web Manager

To reboot (or restart) your SVG2482AC using the SVG2482AC Web Manager:

1. From any SVG2482AC Web Manager screen, click the Troubleshooting menu link.

2. Click Reset/Restore Gateway from the Troubleshooting submenu links.

Chapter 9: Managing Your Gateway and Connected Networks

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

Figure 49: SVG2482AC Reset/Restore Gateway Screen

3. Click RESET located in the Reset / Restore Gateway table. The following message will

display:

Figure 50: Reboot Gateway Message Box

4. Click OK to reboot the SVG2482AC and then log back in.

Reset Your SVG2482AC

WARNING! Resetting your SVG2482AC will delete your current gateway configuration

settings which include your passwords, wireless network name (SSID), firewall, Parental

Control, etc. The SVG2482AC default factory settings will be restored.

Choose one of the following options to reset your SVG2482AC configuration:

 Reset SVG2482AC Using the Reset Button

 Reset SVG2482AC Using the Web Manager

Note: For network security purposes, ARRIS recommends that you change the default

admin password on your SVG2482AC. See Change the Default Password (page 38) for

more information.

Chapter 9: Managing Your Gateway and Connected Networks

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

Reset SVG2482AC Using the Reset Button

WARNING! Resetting your SVG2482AC will delete your current gateway configuration.

To reset your SVG2482AC using the Reset button:

1. Insert the end of a paper clip (or other small object with a narrow tip) into the indented

Reset button opening on the rear of your SVG2482AC.

Figure 51: SVG2482AC Reset Button

2. Press and hold the small object in place for 10 seconds, and then release.

3. Remove the paper clip or small object from the Reset opening.

Reset SVG2482AC Using the Web Manager

WARNING! Resetting your SVG2482AC will delete your current gateway configuration.

From the SVG2482AC Web Manager, do the following to open the Reset/Restore Gateway

screen:

1. From any SVG2482AC Web Manager screen, click the Troubleshooting menu link.

2. Click Reset/Restore Gateway from the Troubleshooting submenu links.

Chapter 9: Managing Your Gateway and Connected Networks

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

Figure 52: SVG2482AC Reset/Restore Gateway Screen

3. Click RESET WI-FI ROUTER located in the Reset / Restore Gateway table.

The message, Are you sure you want to Reset the Wi-Fi Gateway?, will display.

4. Click OK to proceed.

The resetting process will take approximately 60 to 90 seconds to complete and then the

SVG2482AC will reboot.

5. Log back in to the SVG2482AC using the default user name and password.

 Username: admin

 Password: password

Exit the SVG2482AC Web Manager

To log out and close the SVG2482AC Web Manager:

 Click Logout link located in the upper right corner of the SVG2482AC Web Manager

screen.

Figure 53: SVG2482AC Web Manager Logout Link

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

Chapter 10

Troubleshooting Tips

If the solutions listed in the Troubleshooting Solutions table below do not solve your problem,

please contact your service provider for assistance. Your service provider may ask for the

status of the SVG2482AC front panel LEDs (see Front Panel LED Icons and Error Conditions for

more information).

You may have to reset the SVG2482AC gateway configuration to its original factory settings if

the gateway is not functioning properly. See Reset the SVG2482AC Configuration for more

information.

Solutions

Table 5. Troubleshooting Solutions

Gateway Problem

Possible Solution

Power LED Icon is OFF

 Check the power connection on the gateway and to the

electrical outlet.

 Check that the electrical outlet is working. Is the outlet

controlled by a light switch?

If so, unplug the gateway power cord and connect it to

another electrical outlet that is not controlled by a wall switch.

Cannot Send or

Receive Data

 Check each end of the coaxial cable connection on the

gateway and cable wall outlet. Use your hand to tighten each

connector, if necessary.

 Check the Ethernet cable to make sure it is properly connected

to the gateway and client device.

 On the front panel, check the status of the LED icons and refer

to Front Panel LED Icons and Error Conditions to identify the

problem.

 If you have cable television service, check your television to

ensure your cable service is operating properly.

 If none of the above solutions resolves the problem, contact

your service provider or call ARRIS Technical Support at

1-877-466-8646 for assistance.

Chapter 10: Troubleshooting Tips

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

Gateway Problem

Possible Solution

Cannot Access the

Internet

 Check that all cable and power connections on your gateway

and client device are properly connected.

 Check that the Power, Online, and Wireless LED icons on the

front panel are lit up solid.

 Contact your service provider for assistance.

Wireless devices cannot

send or receive data

 If the problem still continues after checking the coaxial cable

and Ethernet connections and your IP address, check the

Wireless Security Mode setting on the Wireless Primary

Network screen.

 If you enabled WPA and configured a passphrase on the

gateway, be sure each affected wireless client has the identical

passphrase. If this does not solve the problem, check if the

wireless client supports WPA.

Front Panel LED Icons and Error Conditions

The SVG2482AC front panel LED icons provide status information for the following error

conditions:

Table 6. Front Panel LED Icons and Error Conditions

LED Icon

Status

If, During Startup:

If, During Normal Operation

OFF

Gateway is not properly plugged

into the electrical wall outlet

Gateway is unplugged

BLINKING

Upstream (send) channel or

Downstream (receive) channel

cannot be acquired

Upstream channel is lost

Downstream channel is lost

BLINKING

IP registration is unsuccessful

IP registration is lost

OFF

No connected device is detected

Device is disconnected

OFF

No connected device is detected

Device is disconnected

OFF

Telephone is not detected

Telephone is disconnected

Chapter 10: Troubleshooting Tips

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

LED Icon

Status

If, During Startup:

If, During Normal Operation

OFF

Telephone is not detected

Telephone is disconnected

OFF

Battery is not detected

Battery is disconnected

PN 365-095-31279 x.2 SURFboard SVG2482AC Wireless Voice Gateway User Guide

Chapter 11

Warranty Information

SURFboard SVG2482AC Wireless Voice Gateway

ARRIS Enterprises, LLC ("ARRIS")

Retail Purchasers: If you purchased this Product directly from ARRIS or from an authorized

ARRIS retail reseller, ARRIS warrants to you, the original end user customer, that (A) the

Product, excluding Software, will be free from defects in materials and workmanship under

normal use, and (B) with respect to Software, (i) the media on which the Software is provided

will be free from defects in material and workmanship under normal use, and (ii) the Software

will perform substantially as described in its documentation. This Limited Warranty to you, the

original end user customer, continues (A) for Software and the media upon which it is

provided, for a period of ninety (90) days from the date of purchase from ARRIS or an

authorized ARRIS reseller, and (B) for the Product (excluding Software), for a period of two (2)

years from the date of purchase from ARRIS or from an authorized ARRIS reseller. To take

advantage of this Limited Warranty or to obtain technical support, you must call the ARRIS

toll-free telephone number 1-877-466-8646. Technical support charges may apply. ARRIS’ sole

and exclusive obligation under this Limited Warranty for retail sales shall be to repair or

replace any Product or Software that does not meet this Limited Warranty. All warranty claims

must be made within the applicable Warranty Period.

Cable Operator or Service Provider Arrangements. If you did not purchase this Product

directly from ARRIS or from a ARRIS authorized retail reseller, ARRIS does not warrant this

Product to you, the end-user. A limited warranty for this Product (including Software) may

have been provided to your cable operator or Internet Service Provider ("Service Provider")

from whom you obtained the Product. Please contact your Service Provider if you experience

problems with this Product.

General Information. The warranties described in this Section shall not apply: (i) to any

Product subjected to accident, misuse, neglect, alteration, Acts of God, improper handling,

improper transport, improper storage, improper use or application, improper installation,

improper testing or unauthorized repair; or (ii) to cosmetic problems or defects which result

from normal wear and tear under ordinary use, and do not affect the performance or use of

the Product. ARRIS’ warranties apply only to a Product that is manufactured by ARRIS and

identified by ARRIS owned trademark, trade name or product identification logos affixed to

the Product. ARRIS does not warrant to you, the end user, or to anyone else that the Software

will perform error free or without bugs.

Chapter 11: Warranty Information

PN 365-095-31279 x.1 SURFboard SVG2482AC Wireless Voice Gateway User Guide

ARRIS IS NOT RESPONSIBLE FOR, AND PROVIDES "AS IS" ANY SOFTWARE SUPPLIED BY 3RD

PARTIES. EXCEPT AS EXPRESSLY STATED IN THIS SECTION ("WARRANTY INFORMATION"),

THERE ARE NO WARRANTIES OF ANY KIND RELATING TO THE PRODUCT, EXPRESS, IMPLIED OR

STATUTORY, INCLUDING BUT NOT LIMITED TO IMPLIED WARRANTIES OF MERCHANTABILITY,

FITNESS FOR A PARTICULAR PURPOSE, OR THE WARRANTY AGAINST INFRINGEMENT

PROVIDED IN THE UNIFORM COMMERCIAL CODE. Some states do not allow for the exclusion

of implied warranties, so the above exclusion may not apply to you.

What additional provisions should I be aware of? Because it is impossible for ARRIS to know

the purposes for which you acquired this Product or the uses to which you will put this

Product, you assume full responsibility for the selection of the Product for its installation and

use. While every reasonable effort has been made to insure that you will receive a Product

that you can use and enjoy, ARRIS does not warrant that the functions of the Product will

meet your requirements or that the operation of the Product will be uninterrupted or error-

free.

ARRIS IS NOT RESPONSIBLE FOR PROBLEMS OR DAMAGE CAUSED BY THE INTERACTION OF

THE PRODUCT WITH ANY OTHER SOFTWARE OR HARDWARE. ALL WARRANTIES ARE VOID IF

THE PRODUCT IS OPENED, ALTERED, AND/OR DAMAGED.

THESE ARE YOUR SOLE AND EXCLUSIVE REMEDIES for any and all claims that you may have

arising out of or in connection with this Product, whether made or suffered by you or another

person and whether based in contract or tort.

IN NO EVENT SHALL ARRIS BE LIABLE TO YOU OR ANY OTHER PARTY FOR ANY DIRECT,

INDIRECT, GENERAL, SPECIAL, INCIDENTAL, CONSEQUENTIAL, EXEMPLARY OR OTHER

DAMAGES ARISING OUT OF THE USE OR INABILITY TO USE THE PRODUCT (INCLUDING,

WITHOUT LIMITATION, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION,

LOSS OF INFORMATION OR ANY OTHER PECUNIARY LOSS), OR FROM ANY BREACH OF

WARRANTY, EVEN IF ARRIS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. IN NO

CASE SHALL ARRIS’ LIABILITY EXCEED THE AMOUNT YOU PAID FOR THE PRODUCT.

These matters are governed by the laws of the Commonwealth of Pennsylvania, without

regard to conflict of laws principles and excluding the provisions of the United Nations

Convention on Contracts for the International Sale of Goods.

Retail Purchasers Only. If you purchased this Product directly from ARRIS or from an ARRIS

authorized retail reseller, please call the ARRIS toll-free telephone number, 1-877-466-8646

for warranty service or technical support. Technical support charges may apply.

Cable Operator or Service Provider Arrangements. If you did not purchase this Product

directly from ARRIS or from an ARRIS authorized retail reseller, please contact your Service

Provider for technical support.

Corporate Headquarters

ARRIS · Suwanee · Georgia · 30024 · USA

T: 1-678-473-2000 F: 1-678-473-8470

www.arris.com

Arris SVG2482AC User Guide Manual SVG2482AC: UG

Navigation menu

Versions of this User Manual:

Views

Navigation
