LIST PRICE BOOK No. 29

Effective January 1, 2015

www.arrowlock.com

ASSA ABLOY, the global leader

in door opening solutions

ARROW USA

100 Arrow Drive

New Haven, CT 06536-0915

Phone: (800) 839-3157

Fax: (800) 421-6615

info@arrowlock.com

ORDERS & CUSTOMER SERVICE:

Arrow Lock & Door Hardware

P.O. Box 3075

Salem, VA 24153

Phone USA: 800-839-3157

Fax: 800-421-6615

INVOICE PAYMENTS ONLY

Arrow Lock Accounts Receivable

P.O. Box 640711

Pittsburgh, PA 15264

RETURN GOODS ONLY (RGA# REQUIRED)

Arrow Lock & Door Hardware

100 Arrow Drive

New Haven, CT 06511

Canada

Arrow Canada

160 Four Valley Drive

Vaughn, ON L4K 4T9

Canada

Phone: 1.888.633.3264

Fax: 1.888.263.3326

Note: The prices contained in this price book will vary from those in our Canadian price book.

Table of Contents

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

Limited Warranty 2

Terms & Condition of Sale 4

Finishes 9

Stand Alone Touchscreen Locks

V1 Series 10

V2 Series 12

V3 Series 13

Mortise Locks

AM Series 14

BM Series 19

Cylindrical & Tubular Locks

QL Series 32

Q Series 34

GL Series 40

HK Series 42

H Series 44

ML Series 48

MK Series 53

MLX Series 57

RK Series 59

RL Series 60

RLX 62

CK/CL Series 64

Auxiliary Locks

DB Series 68

D Series 70

E Series 71

N Series 74

Padlocks 76

Keys & Cylinders

Keys & Keying Charges 77

Mortise & Rim Cylinder 78

KIK, Lever & Deadbolt Cylinders 79

IC Housings 80

Arrow Pointe SFIC Cylinders 81

Pointe Flex SFIC Cylinders 83

Sliding Door Lock 83

Cam Lock 84

Plus Housings 85

Cylinder Parts & Tools 86

Panic Devices

30 Series 87

40 Series (narrow stile) 91

Electrified Options 94

S1150/S1250 95

ED900 Series 95

500/600 Series 96

Mullions 98

Closers and Operators

7700 Series 102

7800/7900 Series 103

DC300 Series 105

DC500 Series 106

900N Series 107

5016N Series 108

Alarmed Hardware 109

ARROW LOCK®warrants that its products sold under the “ARROW LOCK” trade name in the United States of America are

free from defects in workmanship and materials under normal use and service.

This warranty does not cover defects or damage arising from improper installation, lack of or improper maintenance,

improper storage, shipping and handling, corrosion, erosion, ordinary wear and tear, misuse, abuse, accident,

unauthorized service, or use with unauthorized non-ARROW LOCK products or parts.

This warranty is void if any modification is made to the warranty product, regardless of whether the modification causes or

contributes to the alleged defect. All modifications are made at the risk of the party making the modification.

The only liability of ARROW LOCK®, in tort or contract whether under this warranty or otherwise, shall be limited to the

repair or replacement of any product or component part which shall prove defective as covered by this warranty, within the

stated time period listed below, after delivery to the original purchaser.

10 Years

• 5016N Series

• 900N Series

• DC 300 Series

• DC 500 Series

• HK Series

• MLX Series

• QL Series

• RLX Series

• ED900 Series

5 Years

• 3000 & 4000 Series

• 500 & 600 Series

• AM & BM Series

• CK & CL Series

• GL Series

• RK & RL Series

Limited Warranty/

Conditions of Sale

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

Limited Warranty

3 Years

• ML Series

• Q Series

• S1150 & S1250 Series

• V1 Series

2 Years

• 7800 & 7900 Series

V2 & V3 Series

• 1 year electronics

• Lifetime mechanical & finish for residential use

• 3 years mechanical & finish for commercial use

1 Year

• 7700 Series

• All other ARROW LOCK products

Warranty for Cylinders Factory or Field Combinated

Cylinders shall be periodically lubricated depending on environmental conditions. Dry graphite, molybdenum disulfide, or

Polylube®is recommended. Petroleum based liquid lubricants should only be used in cylinders in harsh or

corrosive environments and should not be mixed with dry lubricants.

Warranty for Cylinders Field Combinated

1. Keys shall be cut to the ARROW LOCK®key bitting specifications required for the particular keyway

and depth system.

2. All pin lengths shall be selected according to prevailing factory standards.

3. Original ARROW LOCK®cylinder components, including pin tumblers and key blanks, shall be used.

We reserve the right to void the warranty if we deem that a malfunction is a result of non-original

components which do not conform to ARROW LOCK®standards.

Keying Systems

All bittings shall be originated or authorized by the ARROW LOCK®Key Systems Department to be compatible with one

another in a specific type of cylinder (conventional, security, high security, interchangeable core, removable core) and with-

in a particular keying system.

ARROW LOCK®will not pay for the cost of repair performed other than in accordance with this warranty.

Refer to our Returned Goods Policy regarding the return of a product or component part believed to be defective as covered

by this warranty. A brief description of the defect will be required. Product will be examined upon return. In the event such

examination reveals a defect covered by this warranty, the product will be repaired or replaced.

THIS WARRANTY IS IN LIEU OF ALL OTHER EXPRESS WARRANTIES. TO THE EXTENT PERMITTED BY LAW, ALL IMPLIED

WARRANTIES ARE LIMITED TO THE DURATION OF THIS WARRANTY. ARROW LOCK®MANUFACTURING COMPANY

SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES. NO AGENT, SALES REPRESENTATIVE OR

DEALER HAS THE AUTHORITY TO INCREASE OR ALTER THE OBLIGATIONS OF THIS WARRANTY.

SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS OR THE EXCLUSION OR

LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT

APPLY TO YOU.

THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM

STATE TO STATE.

ARROW LOCK®Manufacturing Company

Limited Warranty

Limited Warranty/

Conditions of Sale

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

Terms & Conditions of Sale

Acceptance

ARROW LOCK®reserves the right to decline an order, in whole or in part, when the type or quantity of goods or credit

worthiness of the Purchaser is not satisfactory to us in our sole and absolute discretion.

Purchase Orders, Quote requests, Acknowledgements or the like issued by the Purchaser that have contrary standard terms

and conditions are not binding on ARROW LOCK®, unless such terms and conditions are approved in a separate written

agreement by ARROW LOCK’s authorized representatives. In the event of an acceptance of Purchaser’s Purchase Order

by ARROW LOCK®, the Purchaser agrees that such acceptance is solely conditioned on Purchaser’s acceptance of the

terms and conditions set forth in this instrument, regardless of the terms and conditions specified in the Purchaser’s

Purchase order. The terms and conditions in Purchaser’s Purchase order which conflict with terms and conditions of

this instrument shall be disregarded and are hereby rejected, and this instrument shall constitute the entire

agreement between ARROW LOCK®and the Purchaser.

In the event that ARROW LOCK®does not enforce or require strict performance of any term or condition hereof, or of

any other document, instrument or other agreement relating to goods sold, such lack of enforcement or

requirement of strict performance will not waive, affect or diminish any right of ARROW LOCK®to enforce or require

strict performance of such term or condition in the future.

Prices

All prices are subject to change without notice and are not guaranteed. All shipments will be made at prices in effect

at the time of order acceptance.

Possession of this price list does not constitute an agreement to sell.

We reserve the right to correct clerical, stenographic and other obvious errors at any time.

Terms

2% 10 net 30 days after invoice date.

It is understood that ARROW LOCK®may impose and charge a finance charge which is the lesser or one and one-half

percent (1-1/2%) per month or the highest rate allowed by law on any amount which becomes past due and

delinquent. Additionally the Customer shall be responsible for all collection costs, court costs and reasonable attorney’s

fees (where allowed by law) in connection with the recovery of any delinquent amount.

Freight

All orders are shipped FOB factory/warehouse, except as expressly provided below. When delivered to the

Transportation Company, the Purchaser assumes the risk of loss or damage in transit.

Customer orders with net product value in excess of $5,000.00 will be shipped prepaid to a single destination point

in the United States.

Customer order with net product value less than $5,000.00 will be shipped prepaid by ARROW LOCK’s carrier

of choice, and the shipping charges will be added to Customer’s invoice. ARROW LOCK®will choose the carrier and

routing. If a Customer requests an alternative carrier, freight charges will be incurred on Customer’s invoice.

Limited Warranty/

Conditions of Sale

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

Limited Warranty/

Conditions of Sale

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

Great Grand Master keys, Grand Master keys, Master keys, Construction Master keys, Control Keys, which are shipped

separate from customer order, for security reasons, with net product value less than $5,000.00 will be shipped

prepaid by ARROW LOCK’s carrier of choice, and the shipping charges will be added to Customer’s invoice.

Minimum Invoice

Minimum invoice for complete product is $200.00 net product value. The minimum invoice for parts orders is $100.00

net product value.

This policy does not include the following: Cut (bitted) Keys of any type, Master Keyed Cylinders, Master Keyed

Padlocks and Factory Generated Bitting Lists.

Same day order expedites will be invoiced at book net.

Quotations

If ARROW LOCK®elects to offer a Quote; such Quote will be valid for sixty (60) days. Complete shipment of the order

must be accepted by Purchaser within nine (9) calendar months from the date of price issuance.

The Quote number must be referenced on the order.

Any invoiced order that has the incorrect discount applied to it and did not have a Quote copy attached to the order

or the Quote number written on the order will have a service fee of $100.00 net DEDUCTED from any sales credit

issued for the difference in discount.

The Quote is null and void if the Purchase Order does not include ALL product lines listed on the Quote or if the

quantities for an item covered by the Quote deviate by 10% or more.

With the issuance and acceptance of a Quote for the purchase of products, the Purchaser agrees that products so

purchased will not be resold or transferred to any Distributor not authorized by ARROW LOCK®to sell its products.

This would be inclusive of branches of the quoted Distributor. Failure to abide by this restriction may result in the

Distributor’s ineligibility for Price Concession Authorizations, or other actions in ARROW LOCK’s discretion.

ARROW LOCK®and its sales representatives reserve the right, in their sole discretion and for any reason, to refuse a

Distributor’s request to quote a price other than ARROW LOCK’s standard list price and regardless of whether ARROW

LOCK®or its sales representatives have previously quoted discounted prices to the Distributor on some or all of

its orders.

Non-Cataloged Products

Products not cataloged or listed in this price book will be considered as special products, and will not be

manufactured without prior approval from ARROW LOCK®.

A minimum special handling charge of $50.00 will be added for non-cataloged product. Any additional labor or

material required will be charged accordingly.

Special products require special handling, and therefore standard lead times may not apply. Please consult with your

Sales Representative for further details.

Terms & Conditions of Sale

Changes / Cancellation of Orders

Changes or cancellations to an order will result in a charge of costs for material and labor expenses that have been

incurred prior to notification from Customer. Handling charges are billed on Customer’s original order.

If products have already been made and/or are located in the shipping room, a 45% restocking fee will apply.

All Non-Cataloged Goods and ARROW LOCK®Arrow Express Orders may not be changed or cancelled.

All change requests for goods, other than for the two reasons stated above, must be submitted in writing to Customer

Service within two (2) business days of receipt of acknowledgement of the order.

Add–On Orders to Quote

Any new order requesting special pricing to match an existing Quote number, which has already been ordered, will be

accepted up to 60 days after the acknowledgement of the original order. All add-on orders must reference the

original factory order number and the corresponding Quote number to receive the quoted pricing discount. Add-on

orders for stock will not be accepted.

Delivery

Orders will be acknowledged and given a scheduled delivery date based on estimated manufacturing lead times.

Complete information is required to process all orders. Orders with insufficient information for processing (i.e. keying

information, door sizes, etc.) may be subject to extended lead times which are relative to the time required in obtaining

the necessary information for order processing. Manufacturing lead time will begin once all information is received to

process an order. ARROW LOCK®will use reasonable efforts to deliver products as estimated, but makes no guarantees

as to delivery dates.

ARROW LOCK®will not be liable for back charges incurred based on availability of product or as a result of delays in

delivery caused by insufficient information required to process an order.

ARROW LOCK®will not be held responsible for delays in delivery caused by strikes, fires, floods or any other causes

beyond our control, including the delivery of material to us. Under no circumstances shall ARROW LOCK®be liable or

accountable for consequential damages due to failure of delivery.

Claims

In the event of Company or Customer error, claims for shortages, pricing errors and/or incorrectly filled orders must

be submitted in writing to Customer Service within thirty (30) days from receipt of material.

Any claims for shortages or damage by the Carrier must be made by the Customer directly to the Carrier.

Limited Carrier insurance is typically offered for all orders. If the Customer requires additional insurance, please

contact an ARROW LOCK®Customer Service Representative upon submittal of the order. ARROW LOCK®will obtain

requested insurance and the additional cost will be included on Customer’s invoice.

Invoice Deduction

An ARROW LOCK®Sales Representative or Customer Service Representative must be notified of any disputed invoices

within sixty 60 days from the date of invoice. Deductions should only be taken for the disputed amount and the

balance of the invoice is due and payable within standard payment terms.

Limited Warranty/

Conditions of Sale

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

Limited Warranty/

Conditions of Sale

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

Returned Goods

It is the policy of ARROW LOCK®to not accept returns of any materials that are correctly furnished as per the

Distributor’s Purchase Order. Return of product due to customer order error or accommodation must be

pre-arranged with ARROW LOCK®and approved in writing by Sales Management.

All products returned as “Goodwill” must meet the following criteria to be considered a return:

• Be in original, unmarked, and undamaged cartons.

• Be valued in excess of $200.00 net.

• Shipped and invoiced within the previous 120 days.

• Custom, non-cataloged goods, master-keyed or ARROW LOCK®Arrow Express shipped product

is not returnable.

AMINIMUM restocking fee of 45% will be charged. Upon receipt and verification by ARROW LOCK®that the returned

merchandise meets the foregoing conditions, a credit will be issued for the original invoice amount less the MINIMUM

45% restocking fee.

Defective goods and “Goodwill” products that meet the foregoing criteria may be returned by fulfilling the following

conditions:

• Send an RGA request in writing to the ARROW LOCK®Sales Representative serving

the Purchaser’s area.

• Ensure the RGA labels that are sent to Purchaser by ARROW LOCK®

are visible on return goods shipment.

• Ensure that the RGA number appears on the return shipment label and is legible.

• Return the authorized merchandise within sixty (60) days from the date of RGA issuance date.

• Return shipments must be freight prepaid to the location specified on the RGA.

• ARROW LOCK®is not liable for damages to product during shipping.

No credit may be taken or issued prior to RGA approval and receipt of product.

All defective goods within the terms of our limited warranty may be returned for credit or replacement.

Taxes

Prices do not include any present or future Federal, State, or Local property, license, privilege, sales, use, and excise,

gross receipts or other like taxes or assessments, which may result from transactions or any services

performed in connection herewith.

Governing Law

The rights and obligations of the parties shall be governed by the laws of the State of New York, excluding any

conflicts of law provisions. The United Nations Convention on Contracts for the International Sale of Goods shall not

apply to this Agreement.

Terms & Conditions of Sale

Limited Warranty

The Terms and Conditions outlined above are subject to ARROW LOCK®Limited Warranty, which is included in this

Price List and incorporated herein by reference.

Product Modifications

ARROW LOCK products are not designed for or intended for aftermarket modification. The warranty on ARROW LOCK

products becomes void if the product is modified in any way, regardless of whether the modification causes or

contributes to any alleged defect. Warranty voiding modifications include, but are not limited to, third-party

electrification of non-electric products and/or the installation of non-approved or non-ARROW LOCK components.

If an ARROW LOCK product is modified it no longer meets industry certification and quality control standards

applicable to the original product and is no longer a genuine ARROW LOCK product. A modified product may not be sold

as an ARROW LOCK product and no ARROW LOCK trademarks or certification marks based on the original ARROW LOCK

product, such as U.L. or ANSI/BHMA marks, may appear anywhere on the modified product or on any packaging,

literature or instructions sold with the modified product.

All original ARROW LOCK packaging and literature carrying ARROW LOCK trademarks and must be destroyed if

the original ARROW LOCK product is modified. Portions of the product that carry an ARROW LOCK trademark or

certification mark, such as mortise faceplates, lock bodies, etc. must be discarded and/or replaced by the party making

the modification. U.L. and other certification testing and marking are also the responsibility of the party making

modification. The use of ARROW LOCK trademarks on modified products constitutes trademark infringement.

Individual Components

It is company policy that components including but not limited to latches sold separate from locksets are intended to

be sold as replacement components for appropriate ARROW LOCK products only. All other uses require prior written

approval from ARROW LOCK.

Any retrofit or other field modification to a fire-rated opening can potentially impact the fire rating of the opening, and

ARROW LOCK makes no representations or warranties concerning what such impact may be in any specific situation.

When retrofitting any portion of an existing fire-rated opening, or specifying and installing a new fire-rated opening,

please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure

compliance with all applicable codes and ratings.

Trademarks

ARROW LOCK®is a registered trademark of ARROW LOCK Manufacturing Company.

Other product brand names may be trademarks or registered trademarks of their respective owners and are

mentioned for reference purposes only.

Limited Warranty/

Conditions of Sale

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

Terms & Conditions of Sale

Limited Warranty/

Conditions of Sale

January 1, 2015

Finishes

ASSA ABLOY, the global leader

in door opening solutions

Bright brass 03 605 US3

Satin brass 04 606 US4

Antique brass 05A 609 US5

Satin bronze 10 612 US10

Dark oxidized satin bronze, oil rubbed 10B 613 US10B

Dark oxidized satin bronze, electroplated 10BE 613E US10BE

Dark oxidized satin bronze, clear coated 10BP 614 US10BL

Satin nickel 15 619 US15

Bright chromium plated 26 625 US26

Satin chromium plated 26D 626 US26D

Bright stainless steel 32 629 US32

Satin stainless steel 32D 630 US32D

Description Arrow Code BHMA Code U.S. Code

Aluminum painted or powder coated AL 689 -

Black painted or powder coated BLK 693 -

Dark bronze painted or powder coated BRZ/DBZ 690 -

Satin brass painted or powder coated GL 696 -

Light bronze painted or powder coated LBZ 691 -

Red painted or powder coated RD - -

• Not all finishes are available for all product lines. Consult product sections for applicable finishes.

Description Arrow Code BHMA Code

January 1, 2015

Stand Alone

Touchscreen Locks

ASSA ABLOY, the global leader

in door opening solutions

V1 Series

SR VR BRR

Certification BHMA A156.2, Series 4000, Grade 1

Door Thickness 1-3/4", kit available for 1-3/8" thick doors

Strike Standard: ANSI 1-1/4" x 4-7/8"; T-strike available

Latch 2-3/4" backset, 1-1/8" front

Cylinder Standard: 6-pin, solid brass, 2 nickel-silver keys; IC prep available

Handing Non-handed

Case Quantity 3

Average Case Weight 22 lbs.

Warranty 3 years

Features

V1-51 Touchscreen $536.00 $606.00

Function Description 10BE, 26D 03

Bright Brass 03 605 US3

Dark Oxidized Satin Bronze, Electroplated 10BE 613E US10BE

Satin Chromium Plated 26D 626 US26D

Available Finishes Arrow Code BHMA Code U.S. Code

ANSI V14 Standard

T-Strike V18 No Add

ANSI with box strike V10 $2.60

Strike Options Specify Price Add

2-3/4" backset, 1-1/8" beveled front V44 Standard

2-3/4" backset, 1-1/8" flat front V45 No Add

Latch Options Specify Price Add

Keyed different KD Standard

Less Cylinder LC -$25.00

O-Bitted OB No Add

Lock prepared to accept a 6- or 7-pin SFIC cylinder (not included) IC No Add

Lock prepared to accept an LFIC Medeco or ASSA cylinder (not included) LIC No Add

Lock prepared to accept an LFIC Schlage cylinder (not included) SIC No Add

Lock prepared to accept an LFIC Corbin Russwin cylinder (not included) CIC No Add

Keying & Cylinder Options Specify Price add

Function V151

Trim V151-SR

Finish V151-SR-26D

Strike V151-SR-26D-V14

Latch V151-SR-26D-V14-V44

Keying V151-SR-26D-V14-V44-KD-AR

How to Order

January 1, 2015

Stand Alone

Touchscreen Locks

ASSA ABLOY, the global leader

in door opening solutions

V1 Series

Parts

ANSI Strike, 1-1/4" lip V14 $31.26

T-Strike, 1-1/4" lip V18 $10.42

Box strike V10 $2.60

Strikes Part No. Price

2-3/4" Backset, 2-1/4" x 1-1/8" beveled front V44 $40.39

2-3/4" Backset, 2-1/4" x 1-1/8" flat front V45 $40.39

2-3/4" Backset, 2-1/4" x 1" front V351$40.39

2-3/8" Backset, 2-1/4" x 1" front V381$40.39

Latches Part No. Price

Standard AR cylinder with tailpiece 100C-V1 $25.00

Alternate CS cylinder with tailpiece 100CS-V1 $25.00

Standard keyblank K6A $1.23

Tailpiece for standard cylinder 550V1-44 $2.48

Cylinder & Related Part No. Price

Inside SR lever - all functions MS-01A-V1A $56.54

Outside SR lever - V50 function MS-01A-V1B $56.54

Outside SR lever - standard cylinder prep; less cylinder MS-56A-V1 $56.54

Outside SR lever - SFIC cylinder prep; less cylinder MSCR-56A-V1 $68.82

Outside escutcheon assembly (o/s escutcheon; touchscreen assembly) V1-ESC-OS $231.06

Inside escutcheon assembly (i/s escutcheon, electronics, batteries, battery cover) V1-ESC-IS $231.06

1-3/8" Thin door kit (includes I/S & O/S escutcheons and a V381latch) V1-KIT1 $69.60

Motorized lock chassis V15X-LB $110.62

Battery cover V1-BCOV $34.42

Weather gasket kit (inside & outside gasket replacements) V1-GSK-PK $41.79

Remote unlock and power wire harness V1-RMTE $59.00

5" Extension link (used only with V44 or V45 latches) V25 x 51$41.52

Pro-Lok door prep template for the Arrow V1 Series IN490 $258.11

Pro-Lok universal clamp for holding door prep template INCL $258.11

Trimplate pack (included 3 pairs with screws) RP1 $35.11

Display mount MOUNT-V1 $92.79

Lever return spring 14-5300-1021-999 $4.33

1Sold only as a separate part. Not tested to grade 1 specifications. If substituted for standard latch, grade 1 rating is voided.

Parts & Accessories Part No. Price

January 1, 2015

Stand Alone

Touchscreen Locks

ASSA ABLOY, the global leader

in door opening solutions

V2 Series

V251 Touchscreen

Certification BHMA A156.36, Grade 2

Door Thickness Fits 1-3/8" to 2-1/4", factory set for 1-3/4" (gasket req. for 1-3/8" thick door)

Strike 1-1/8" x 2-3/4", round corners

Latch 2-3/8" - 2-3/4" adjustable backset, 1" front, round corners

Cylinder Standard: 6-pin, solid brass, 2 brass keys; IC prep available

Handing Non-handed

Case Quantity 5

Average Case Weight 11 lbs.

Features

Bright Brass 03 605 US3

Dark Oxidized Satin Bronze, Clear Coated 10BP 614 US10BL

Satin Nickel 15 619 US15

Available Finishes Arrow Code BHMA Code U.S. Code

Strike V2S Standard

Latch V2L Standard

Keyed Different KD Standard

V251 function prepared to accept 6- or 7-pin SFIC cylinder (not included) IC No Add

Options Specify Price Add

Strike V2S $3.38

Latch V2L $14.85

Drive-in latch1V2LD $14.85

Standard CS cylinder with tailpiece 96CS-V2 $25.00

Alternate AR cylinder with tailpiece 96C-V2 $25.00

Tailpiece for standard cylinder V2-44 $2.48

SFIC housing for V251 V2-51-HSG $37.14

Battery cover V2-BCOV $4.50

V251 gasket for 1-3/8" thick door V23-51-GSK $3.94

Display mount MOUNT-V23 $127.31

1Sold only as a separate part.

Parts & Accessories Part No. Price

Function V251

Finish V251-15

Strike V251-15-V2S

Latch V251-15-V2S-V2L

Keying V251-15-V2S-V2L-CS-KD

How to Order

V251 Touchscreen $317.24

Functions Description Price

January 1, 2015

V3 Series

Stand Alone

Touchscreen Locks

ASSA ABLOY, the global leader

in door opening solutions

V351 Touchscreen

Certification BHMA A156.36, Grade 2

Door Thickness Fits 1-3/8" to 1-3/4", factory set for 1-3/4"

Strike Full lip 1-3/8" x 2-3/4", round corners

Latch 2-3/8" - 2-3/4" adjustable backset, 1" front, round corners

Cylinder Standard: 5-pin, solid brass, 2 brass keys

Handing Non-handed

Case Quantity 5

Features

Bright Brass 03 605 US3

Dark Oxidized Satin Bronze, Clear Coated 10BP 614 US10BL

Satin Nickel 15 619 US15

Available Finishes Arrow Code BHMA Code U.S. Code

Function & Trim V351-LR

Finish V351-LR-03

Strike V351-LR-03-V3S

Latch V351-LR-03-V3S-V3L

Keying V351-LR-03-V3S-V3L-CSKD

How to Order

V351-LR Touchscreen $317.24

Function Description 03, 10BP, 15

Full lip 1-3/8" x 2-3/4" V3S Standard

Strike Option Specify Price Add

2-3/8" - 2-3/4" adjustable backset, 1" front V3L Standard

Latch Option Specify Price Add

Keyed different, CS keyway CSKD No add

Keying & Cylinder Option Specify Price Add

Cylinder 100C-V3 $25.00

Strike V3S $8.08

Latch V3L $14.85

Drive-in Latch1V3LD $14.85

Replacement lever set V3LVRPK $38.19

Display mount MOUNT-V23 $127.31

1Sold only as a separate part.

Parts & Accessories Part No. Price

Mortise Locks

January 1, 2015

AM Series

ASSA ABLOY, the global leader

in door opening solutions

Certification BHMA A156.13, Series 1000, Operationsl Grade 1, UL Listed

Door Thickness 1-3/4"

Strike Standard: ANSI 1-1/4" x 4-7/8", straight lip, with box; curved lip available

Latch 3/4" throw, stainless steel

Bolt 1" throw, stainless steel

Backset 2-3/4"

Cylinder Standard: 6-pin, solid brass, 2 nickel-silver keys; IC prep available

Handing Handed, field reversible without disassembling lock case

Case Quantity 10

Average Case Weight 58 lbs.

Warranty 5 years

Features

Bright brass 03 605 US3

Satin brass 04 606 US4

Satin bronze 10 612 US10

Dark oxidized satin bronze, oil rubbed 10B 613 US10B

Dark oxidized satin bronze, electroplated 10BE 613E US10BE

Bright chromium plated 26 625 US26

Satin chromium plated 26D 626 US26D

Satin stainless steel 32D 630 US32D

Available Finishes Arrow Code BHMA Code U.S. Code

Function AM11

Trim AM11-HTHA

Finish AM11-HTHA-26D

Strike AM11-HTHA-26D-460

Handing AM11-HTHA-26D-460-RH

Keying AM11-HTHA-26D-460-RH-KD-AR

How to Order

Mortise Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

HTHA HTHD HBHA HBHD

AM Series

Knob Designs

AM31 F14 Storeroom $707.29 $748.69 $762.01

AM32 F09 Vestibule $704.00 $745.40 $758.72

AM33 - Storeroom $704.00 $745.40 $758.72

AM34 - Storeroom $707.29 $748.69 $762.01

AM37 F32 Classroom $704.00 $745.40 $758.72

•Specify HTHB or HBHB trim design for large 3-1/4” diameter rose and add $14.88 to list price.

Function ANSI Description 26D 03, 04, 10, 10B, 10BE,26 32D

AM01 F01 Passage $519.78 $561.18 $574.50

AM02 F19 Privacy $587.89 $629.29 $642.61

AM07 - Exit $584.26 $604.96 $611.62

AM26 F22 Privacy $587.89 $629.29 $642.61

AM08 - Single Dummy $235.91 $256.61 $263.27

AM09 - Full Dummy $438.69 $480.09 $493.41

Function ANSI Description 26D 03, 04, 10, 10B, 10BE,26 32D

Non-Keyed Functions

Double Cylinder Functions

AM11 F12 Apartment $682.45 $723.85 $737.17

AM12 F07 Storeroom $675.82 $717.22 $730.54

AM13 F21 Front Door $682.45 $723.85 $737.17

AM15 F15 Hotel $775.27 $816.67 $829.99

AM16- Hotel $775.27 $816.67 $829.99

AM17 F05 Classroom $675.82 $717.22 $730.54

AM19 F13 Dormitory $682.45 $723.85 $737.17

AM20 F20 Entrance $682.45 $723.85 $737.17

AM21 F08/F10 Entrance $682.45 $723.85 $737.17

AM22 F04 Office $675.82 $717.22 $730.54

AM23 - Vestibule $675.82 $717.22 $730.54

AM24 - Storeroom $675.82 $717.22 $730.54

AM27 - Institutional Privacy $675.82 $717.22 $730.54

Function ANSI Description 26D 03, 04, 10, 10B, 10BE,26 32D

Single Cylinder Functions

Mortise Locks

AM Series

Knob Designs

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

HTG HTH HBG HBH

AM31 F14 Storeroom $700.03 $741.43 $754.75

AM32 F09 Vestibule $696.74 $738.14 $751.46

AM33 F30 Storeroom $696.74 $738.14 $751.46

AM34 F35 Storeroom $700.03 $741.43 $754.75

AM37 F32 Classroom $696.74 $738.14 $751.46

Function ANSI Description 26D 03, 04, 10, 10B, 10BE, 26 32D

AM01 F01 Passage $512.52 $553.92 $567.24

AM02 F19 Privacy $580.63 $622.03 $635.35

AM07 F31 Exit $580.63 $601.33 $607.99

AM26 F22 Privacy $580.63 $622.03 $635.35

AM08 - Single Dummy $232.28 $252.98 $259.64

AM09 - Full Dummy $431.43 $472.83 $486.15

Function ANSI Description 26D 03, 04, 10, 10B, 10BE, 26 32D

Non-Keyed Functions

Double Cylinder Functions

AM11 F12 Apartment $675.19 $716.59 $729.91

AM12 F07 Storeroom $668.56 $709.96 $723.28

AM13 F21 Front Door $675.19 $716.59 $729.91

AM16 F15 Hotel $768.01 $809.41 $822.73

AM17 F05 Classroom $668.56 $709.96 $723.28

AM19 F13 Dormitory $675.19 $716.59 $729.91

AM20 F20 Entrance $675.19 $716.59 $729.91

AM21 F08/F10 Entrance $675.19 $716.59 $729.91

AM22 F04 Office $668.56 $709.96 $723.28

AM23 - Vestibule $668.56 $709.96 $723.28

AM24 - Storeroom $668.56 $709.96 $723.28

AM27 - Institutional Privacy $668.56 $709.96 $723.28

Function ANSI Description 26D 03, 04, 10, 10B, 10BE, 26 32D

Single Cylinder Functions

Mortise Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

AM Series

Knob Designs

TA BD

AM01 F01 Passage $401.18 $442.58

AM02 F19 Privacy $469.29 $510.69

AM07 - Exit $524.96 $545.66

AM26 F22 Privacy $469.29 $510.69

Function ANSI Description 26D 03, 04, 10, 10B, 10BE, 26

Non-Keyed Functions

AM11 F12 Apartment $563.85 $605.25

AM12 F07 Storeroom $557.22 $598.62

AM13 F21 Front Door $563.85 $605.25

AM15 F15 Hotel $656.67 $698.07

AM16 - Hotel $656.67 $698.07

AM17 F05 Classroom $557.22 $598.62

AM19 F13 Dormitory $563.85 $605.25

AM20 F20 Entrance $563.85 $605.25

AM21 F08/F10 Entrance $563.85 $605.25

AM22 F04 Office $557.22 $598.62

AM23 - Vestibule $557.22 $598.62

AM24 - Storeroom $557.22 $598.62

AM27 - Institutional Privacy $557.22 $598.62

Function ANSI Description 26D 03, 04, 10, 10B, 10BE, 26

Single Cylinder Functions

AM31 F14 Storeroom $588.69 $630.09

AM32 F09 Vestibule $585.40 $626.80

AM33 - Storeroom $585.40 $626.80

AM34 - Storeroom $588.69 $630.09

AM37 F32 Classroom $585.40 $626.80

Function ANSI Description 26D 03, 04, 10, 10B, 10BE, 26

Double Cylinder Functions

Mortise Locks

AM Series

Knob Designs

& Deadlocks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

TG TH BG BH

AM01 F01 Passage $419.44 $460.84

AM02 F19 Privacy $487.55 $528.95

AM07 - Exit $534.09 $554.79

AM26 F22 Privacy $487.55 $528.95

AM08 - Single Dummy $185.74 $206.44

AM09 - Full Dummy $338.35 $379.75

Function ANSI Description 26D 03, 04, 10, 10B, 10BE, 26

Non-Keyed Functions

AM11 F12 Apartment $582.11 $623.51

AM12 F07 Storeroom $575.48 $616.88

AM13 F21 Front Door $582.11 $623.51

AM16 - Hotel $674.93 $716.33

AM17 F05 Classroom $575.48 $616.88

AM19 F13 Dormitory $582.11 $623.51

AM20 F20 Entrance $582.11 $623.51

AM21 F08/F10 Entrance $582.11 $623.51

AM22 F04 Office $575.48 $616.88

AM23 - Vestibule $575.48 $616.88

AM24 - Storeroom $575.48 $616.88

AM27 - Institutional Privacy $575.48 $616.88

Function ANSI Description 26D 03, 04, 10, 10B, 10BE, 26

Single Cylinder Functions

AM31 F14 Storeroom $606.95 $648.35

AM32 F09 Vestibule $603.66 $645.06

AM33 - Storeroom $603.66 $645.06

AM34 - Storeroom $606.95 $648.35

AM37 F32 Classroom $603.66 $645.06

Function ANSI Description 26D 03, 04, 10, 10B, 10BE, 26

Double Cylinder Functions

AM40 F18 Cylinder One Side $407.28

AM41 F17 Cylinder x Thumbturn $429.64

AM42 F16 Double Cylinder $452.14

AM44 - Classroom - Cylinder x Thumbturn $429.64

Function ANSI Description 03, 04, 10, 10B, 10BE, 26, 26D

Deadlock Functions (No Trim)

Mortise Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

BM Series

Certification BHMA A156.13, Series 1000, Operationsl Grade 1, UL Listed

Door Thickness 1-3/4"

Strike Standard: ANSI 1-1/4" x 4-7/8", straight lip, with box; curved lip available

Latch 3/4" throw, stainless steel

Bolt 1" throw, stainless steel

Backset 2-3/4"

Cylinder Standard: 6-pin, solid brass, 2 nickel-silver keys; IC prep available

Handing Handed, field reversible without disassembling lock case

Case Quantity 10

Average Case Weight 62 lbs.

Warranty 5 years

Features

Bright brass 03 605 US3

Satin brass 04 606 US4

Satin bronze 10 612 US10

Dark oxidized satin bronze, oil rubbed 10B 613 US10B

Dark oxidized satin bronze, electroplated 10BE 613E US10BE

Bright chromium plated 26 625 US26

Satin chromium plated 26D 626 US26D

Bright stainless steel 32 629 US32

Satin stainless steel 32D 630 US32D

Available Finishes Arrow Code BHMA Code U.S. Code

Function BM11

Trim BM11-XL

Finish BM11-XL-26D

Strike BM11-XL-26D-460

Handing BM11-XL-26D-460-RH

Keying BM11-XL-26D-460-RH-KD-AR

How to Order

Mortise Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

BM Series

Lever Designs

BRL HSL NL

BM01 F01 Passage $423.43 $465.51 $478.99

BM02 F19 Privacy $483.18 $525.26 $538.74

BM07 - Exit $531.02 $552.06 $558.80

BM26 F22 Privacy $483.18 $525.26 $538.74

BM08 - Single Dummy $176.61 $197.65 $204.39

BM09 - Full Dummy $333.84 $375.92 $389.40

Function ANSI Description 26D 03, 04, 10, 10B, 10BE, 26 32, 32D

Non-Keyed Functions

BM11 F12 Apartment $552.88 $594.96 $608.44

BM12 F07 Storeroom $536.29 $578.37 $591.85

BM13 F21 Front Door $552.88 $594.96 $608.44

BM15 F15 Hotel $670.65 $712.73 $726.21

BM16 F15 Hotel $670.65 $712.73 $726.21

BM17 F05 Classroom $536.29 $578.37 $591.85

BM19 F13 Dormitory $552.88 $594.96 $608.44

BM20 F20 Entrance $552.88 $594.96 $608.44

BM21 F08/F10 Entrance $552.88 $594.96 $608.44

BM22 F04 Office $536.29 $578.37 $591.85

BM23 - Vestibule $536.29 $578.37 $591.85

BM24 - Storeroom $536.29 $578.37 $591.85

BM27 - Institutional Privacy $536.29 $578.37 $591.85

Function ANSI Description 26D 03, 04, 10, 10B, 10BE, 26 32, 32D

Single Cylinder Functions

BM31 F14 Storeroom $594.32 $636.40 $649.88

BM32 F09 Vestibule $577.67 $619.75 $633.23

BM33 - Storeroom $577.67 $619.75 $633.23

BM34 - Storeroom $594.32 $636.40 $649.88

BM37 F32 Classroom $577.67 $619.75 $633.23

BM38 - Classroom Security $654.84 $696.92 $710.40

Function ANSI Description 26D 03, 04, 10, 10B, 10BE, 26 32, 32D

Double Cylinder Functions

Mortise Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

BM Series

Lever Designs

JL1VLXL WL1

BM01 F01 Passage $519.09 $561.17 $574.65

BM02 F19 Privacy $578.84 $620.92 $634.40

BM07 - Exit $578.85 $599.89 $606.63

BM26 F22 Privacy $578.84 $620.92 $634.40

BM08 - Single Dummy $224.44 $245.48 $252.22

BM09 - Full Dummy $429.50 $471.58 $485.06

Function ANSI Description 26D 03, 04, 10, 10B, 10BE, 26 32, 32D

Non-Keyed Functions

BM11 F12 Apartment $648.54 $690.62 $704.10

BM12 F07 Storeroom $631.95 $674.03 $687.51

BM13 F21 Front Door $648.54 $690.62 $704.10

BM15 F15 Hotel $766.31 $808.39 $821.87

BM16 F15 Hotel $766.31 $808.39 $821.87

BM17 F05 Classroom $631.95 $674.03 $687.51

BM19 F13 Dormitory $648.54 $690.62 $704.10

BM20 F20 Entrance $648.54 $690.62 $704.10

BM21 F08/F10 Entrance $648.54 $690.62 $704.10

BM22 F04 Office $631.95 $674.03 $687.51

BM23 - Vestibule $631.95 $674.03 $687.51

BM24 - Storeroom $631.95 $674.03 $687.51

BM27 - Institutional Privacy $631.95 $674.03 $687.51

Function ANSI Description 26D 03, 04, 10, 10B, 10BE, 26 32, 32D

Single Cylinder Functions

BM31 F14 Storeroom $689.98 $732.06 $745.54

BM32 F09 Vestibule $673.33 $715.41 $728.89

BM33 - Storeroom $673.33 $715.41 $728.89

BM34 - Storeroom $689.98 $732.06 $745.54

BM37 F32 Classroom $673.33 $715.41 $728.89

BM38 - Classroom Security $750.50 $792.58 $806.06

1JL & WL trim designs not available in 32 or 32D finish.

Function ANSI Description 26D 03, 04, 10, 10B, 10BE, 26 32, 32D

Double Cylinder Functions

Mortise Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

BRH BRG NH NG HSH HSG

BM Series

Lever Designs

BM01 F01 Passage $468.07 $510.15 $523.63

BM02 F19 Privacy $527.82 $569.90 $583.38

BM07 - Exit $553.34 $574.38 $581.12

BM26 F22 Privacy $527.82 $569.90 $583.38

BM08 - Single Dummy $198.93 $219.97 $226.71

BM09 - Full Dummy $378.48 $420.56 $434.04

Function ANSI Description 26D 03, 04, 10, 10B, 10BE, 26 32, 32D

Non-Keyed Functions

BM11 F12 Apartment $597.52 $639.60 $653.08

BM12 F07 Storeroom $580.93 $623.01 $636.49

BM13 F21 Front Door $597.52 $639.60 $653.08

BM16 F15 Hotel $715.29 $757.37 $770.85

BM17 F05 Classroom $580.93 $623.01 $636.49

BM19 F13 Dormitory $597.52 $639.60 $653.08

BM20 F20 Entrance $597.52 $639.60 $653.08

BM21 F08/F10 Entrance $597.52 $639.60 $653.08

BM22 F04 Office $580.93 $623.01 $636.49

BM23 - Vestibule $580.93 $623.01 $636.49

BM24 - Storeroom $580.93 $623.01 $636.49

BM27 - Institutional Privacy $580.93 $623.01 $636.49

Function ANSI Description 26D 03, 04, 10, 10B, 10BE, 26 32, 32D

Single Cylinder Functions

BM31 F14 Storeroom $638.96 $681.04 $694.52

BM32 F09 Vestibule $622.31 $664.39 $677.87

BM33 - Storeroom $622.31 $664.39 $677.87

BM34 - Storeroom $638.96 $681.04 $694.52

BM37 F32 Classroom $622.31 $664.39 $677.87

BM38 - Classroom Security $699.48 $741.56 $755.04

Function ANSI Description 26D 03, 04, 10, 10B, 10BE, 26 32, 32D

Double Cylinder Functions

Mortise Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

BM Series

Lever Designs

VG XH XGWH1

WG1

JH1

JG1VH

BM01 F01 Passage $563.73 $605.81 $619.29

BM02 F19 Privacy $623.48 $665.56 $679.04

BM07 - Exit $601.17 $622.21 $628.95

BM26 F22 Privacy $623.48 $665.56 $679.04

BM08 - Single Dummy $246.76 $267.80 $274.54

BM09 - Full Dummy $474.14 $516.22 $529.70

Function ANSI Description 26D 03, 04, 10, 10B, 10BE, 26 32, 32D

Non-Keyed Functions

BM11 F12 Apartment $693.18 $735.26 $748.74

BM12 F07 Storeroom $676.59 $718.67 $732.15

BM13 F21 Front Door $693.18 $735.26 $748.74

BM16 F15 Hotel $810.95 $853.03 $866.51

BM17 F05 Classroom $676.59 $718.67 $732.15

BM19 F13 Dormitory $693.18 $735.26 $748.74

BM20 F20 Entrance $693.18 $735.26 $748.74

BM21 F08/F10 Entrance $693.18 $735.26 $748.74

BM22 F04 Office $676.59 $718.67 $732.15

BM23 - Vestibule $676.59 $718.67 $732.15

BM24 - Storeroom $676.59 $718.67 $732.15

BM27 - Institutional Privacy $676.59 $718.67 $732.15

Function ANSI Description 26D 03, 04, 10, 10B, 10BE, 26 32, 32D

Single Cylinder Functions

BM31 F14 Storeroom $734.62 $776.70 $790.18

BM32 F09 Vestibule $717.97 $760.05 $773.53

BM33 - Storeroom $717.97 $760.05 $773.53

BM34 - Storeroom $734.62 $776.70 $790.18

BM37 F32 Classroom $717.97 $760.05 $773.53

BM38 - Classroom Security $795.14 $837.22 $850.70

1JH, JG, WG, & WH trim designs not available in 32 or 32D finish.

Function ANSI Description 26D 03, 04, 10, 10B, 10BE, 26 32, 32D

Double Cylinder Functions

Mortise Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

AM & BM Series

Options

Keyed different KD Standard

Master keyed (except Hotel function) MK $12.38 per cylinder

Construction master keyed CMK $7.77 per cylinder

Master keyed & construction master keyed MK-CMK $20.15 per cylinder

O-Bitted OB No Add

Less cylinder LC -$13.50

Lock prepared to accept 6-pin IC cylinder, less core IC61No Add

Lock prepared to accept 7-pin IC cylinder, less core IC71No Add

1Not available with hotel function 15 or 16.

Keying & Cylinder Options Specify Price Add

Abrasive outside lever (BM Series) 113 $55.60

Abrasive inside lever (BM Series) 114 $55.60

Knurled outside lever (BM Series) 103 $78.34

Knurled inside lever (BM Series) 104 $78.34

Lead lined case 123 $131.52

Lead lined knobs (inside & outside) 127 $263.03

Lead lined roses (inside & outside) 133 $197.36

Rabbeted front and strike 144 $100.17

Hold back latch for 12 function HB $53.91

Security Head Screws SHS2$13.74

2Only available for locks in 26, 26D, 32, or 32D finish. Not available for T Knob, B Knob, or any escutcheon design.

NOTE: Arrow mortise locks are designed for standard 1-3/4" door applications. See Non-Cataloged Products in the Terms & Conditions of Sale section for

additional details.

Miscellaneous Options Specify Price Add

Straight lip 02, 11, 13, 15, 16, 19, 20, 21, 31, 34, 38 460 Standard

Straight lip 01, 07, 12, 17, 22, 23, 24, 26, 27, 32, 33, 37 463 Standard

Straight lip 40, 41, 42, 44 456 Standard

Curved lip Optional strike for 01, 07, 12, 17, 22, 23, 24, 26, 27, 32, 33, 37 462 (LH, RR) No Add

464 (RH, LR)

Curved lip Optional strike for 02, 11, 13, 15, 16, 19, 20, 21, 31, 34 466 (LH, RR) No Add

468 (RH, LR)

Less strike LST -$10.10

Note: Straight Lip Strike = 1-1/8" Lip-to-Center

Curved Lip Strike = 1-1/4" Lip-to-Center

Strike Options Lock Function Specify Price Add

Mortise Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

AM & BM Series

Options

AM Series BM Series

Fail-safe trim control (applied to 17 function) 12V AC/DC 177 $449.37

24V AC/DC 179 $449.37

Fail-secure trim control (applied to 17 function) 12V AC/DC 181 $449.37

24V AC/DC 183 $449.37

Latchbolt monitoring LM2$259.31

Request to exit - authorized RE $259.31

Security monitoring SM 2$490.22

1Electrification charges do not include price of locksets.

2LM and SM options cannot be combined.

Fail-safe Power on locks outside lever

Inside lever always free

Latch retracted by keys when locked electrically

Fail-secure Power off locks outside lever

Inside lever always free

Latch retracted by keys when locked electrically

Latchbolt monitoring

Full extension of the latch monitored by a SPDT switch

Request to exit - authorized egress

Inside trim monitored by an SPTD switch. Switch can be used to shunt a door alarm to allow egress,

signal a control console when the trim is activated, or activate a door alarm.

Security monitoring

Monitors, in series, solenoid status (locked or unlocked) and latch status (deadlatch position).

Specifications 12VAC/VDC @ 612mA

24VAC/VDC @ 330mA

Description Voltage Specify Price Add1

Electrification Options (extended lead time required)

Mortise Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

AM & BM Series

Parts

Standard mortise cylinder • MC61-001 $38.95

MC61-AM2 $38.95

Hotel cylinder • MCH61-AM2 $57.50

Emergency key for Hotel function 16CRH-207 $8.32

Emergency key for privacy function 16L-207 $1.75

Cylinder cams For functions 12, 17, 22, 23, 24, 27, 32 (I/S), 33, 37 001 $3.30

For functions 11, 13, 19, 20, 21, 31, 32 (O/S), 34, 38, 40, 41, 42, 44 AM2 $3.30

Cylinder collar & spring • 16-113A $8.80

Mortise housing to accept 6-pin IC cylinder, less core • 16CR-16X001 $37.47

16CR-16XAM2 $37.47

Mortise housing to accept 7-pin IC cylinder, less core •16CR-27X001 $37.47

16CR-27XAM2 $37.47

Housing cams For functions 12, 17, 22, 23, 24, 27, 32 (I/S), 33, 37 16CR-001 $3.30

For functions 11, 13, 19, 20, 21, 31, 32 (O/S), 34, 38, 40, 41, 42, 44 16CR-AM2 $3.30

Cylinders & Related Specify Finish Part No. Price

Straight lip 02, 11, 13, 15, 16, 19, 20, 21, 31, 34, 38 • 460 $31.77

Straight lip 01, 07, 12, 17, 22, 23, 24, 26, 27, 32, 33, 37 • 463 $31.77

Straight lip 40, 41, 42, 44 • 456 $31.77

Curved lip 01, 07, 12, 17, 22, 23, 24, 26, 27, 32, 33, 37 • 462 (LH, RR) $31.77

464 (RH, LR)

Curved lip 02, 11, 13, 15, 16, 19, 20, 21, 31, 34, 38 • 466 (LH, RR) $31.77

468 (RH, LR)

Box Strike For all strikes above BX70 $4.84

Strikes Lock Function Specify Finish Part No. Price

Mortise Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

AM & BM Series

Parts

01, 24, 26 • AM01-305 $28.60

02, 13, 19, 31 • AM02-305 $28.60

07, 12, 17, 27, 32, 33, 37 • AM12-305 $28.60

11, 21, 34 • AM11-305 $28.60

Face plates 15, 16, 38 • AM15-305 $28.60

20 • AM20-305 $28.60

22 • AM22-305 $28.60

23 • AM23-305 $28.60

40, 41, 42, 44 • AM41-305 $28.60

AM trim with H escutcheon AM-385A $19.11

Spindles AM trim with G escutcheon or rose trim AM-386A $22.33

BM trim with H escutcheon or rose trim BM-385A $19.11

BM trim with G escutcheon BM-386A $22.33

Thumbturn for sectional trim • 16-17A $20.72

Emergency rose for privacy function with sectional trim • 16-04A $9.61

Emergency key for privacy function 16L-207 $1.75

BM Series rose 17-03-2 $30.97

Hotel indicator for sectional trim • AM-396 $33.38

Stud for mounting plate BM-94 $0.85

Mounting plate for lever x rose trim BM-93A $8.80

Standard screw pack • AM-201 $2.48

Supplement screw pack for G escutcheon • AM-201G $0.94

Supplement screw pack for H escutcheon • AM-201H $0.94

Faceplate screw 16-306 $0.37

Black nylon bushing insert 16-14 $0.80

Lever handle set screw 17-388 $0.85

Description Lock Function Specify Finish Part No. Price

Parts & Accessories

Mortise Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

AM & BM Series

Lockbodies

01 AM01-LB $202.82

02, 19 AM02-LB $280.41

07, 12 AM12-LB $267.70

11 AM11-LB $280.41

13, 31 AM13-LB $280.41

15, 16 AM15-LB $348.71

17, 32, 37 AM17-LB $267.70

For AM knobs 20 AM20-LB $280.41

21, 34 AM21-LB $280.41

22 AM22-LB $267.70

23 AM23-LB $267.70

24 AM24-LB $267.70

26 AM26-LB $267.70

27 AM27-LB $267.70

33 AM33-LB $267.70

For deadlocks less trim 40, 41, 42 AM41-LB $258.26

44 AM44-LB $258.26

01 BM01-LB $202.82

02, 19 BM02-LB $280.41

07, 12 BM12-LB $267.70

11 BM11-LB $280.41

13, 31 BM13-LB $280.41

15, 16 BM15-LB $348.71

17, 32, 37 BM17-LB $267.70

For BM levers 20 BM20-LB $280.41

21, 34 BM21-LB $280.41

22 BM22-LB $267.70

23 BM23-LB $267.70

24 BM24-LB $267.70

26 BM26-LB $267.70

27 BM27-LB $267.70

33 BM33-LB $267.70

38 BM38-LB $305.60

• Faceplates and screwpacks are not included with lockbodies.

Lockbodies Lock Function (specify handing - RH, LH, RR, or LR) Part No. Price

Mortise Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

AM Series

Trim Packs

01, 12, 17, 22, 23, 24, 31, 32, 33, 34, 37 4 $267.70 $289.85 $296.24

HBHA, HBHD, 11, 13, 16, 19, 20, 21, 27 6 $289.85 $312.12 $316.82

HTHA, HTHD 02, 26 7 $296.24 $319.93 $326.32

15 8 $319.93 $337.37 $350.01

01, 12, 17, 22, 23, 24, 31, 32, 33, 34, 37 4 $283.58 $304.11 $312.12

HBHB, HTHB 11, 13, 16, 19, 20, 21, 27 6 $304.11 $326.32 $332.65

02, 26 7 $312.12 $337.37 $343.75

15 8 $337.37 $361.18 $365.91

01 3 $267.70 $289.85 $296.24

12, 17, 22, 23, 24 4 $267.70 $289.85 $296.24

HBG, HBH, 31, 32, 33, 34, 37 5 $267.70 $289.85 $296.24

HTG, HTH 11, 13, 16, 19, 20, 21, 27 6 $289.85 $312.12 $316.82

02, 26 7 $296.24 $319.93 $326.32

01, 12, 17, 22, 23, 24, 31, 32, 33, 34, 37 4 $207.58 $212.29

TA, BD 11, 13, 16, 19, 20, 21, 27 6 $228.18 $232.89

02, 26 7 $237.60 $242.45

15 8 $261.29 $267.70

01 3 $217.01 $221.84

12, 17, 22, 23, 24 4 $217.01 $221.84

BG, BH, TG, TH 31, 32, 33, 34, 37 5 $217.01 $221.84

11, 13, 16, 19, 20, 21, 27 6 $237.60 $242.45

02, 26 7 $247.11 $251.94

• Example - HBHA trim for an “01” function: HBHA4x finish.

• Trim packs are supplied less cylinder. Each pack includes inside & outside trims, spindle, turnpiece (where applicable), & mounting screws.

Trim Design Lock Function Suffix No. 26D 03, 04, 10, 10B, 10BE, 26 32D

AM Knob Trims

Mortise Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

BM Series

Trim Packs

01, 12, 17, 22, 23, 24, 31, 32, 33, 34, 37, 38 4 $251.94 $274.08 $289.85

BRL, HSL, NL 11, 13, 16, 19, 20, 21, 27 6 $274.08 $296.24 $312.12

02, 26 7 $283.58 $304.11 $319.93

15 8 $304.11 $326.32 $343.75

01, 12, 17, 22, 23, 24, 31, 32, 33, 34, 37, 38 4 $312.12 $332.65 $350.01

JL1, VL, 11, 13, 16, 19, 20, 21, 27 6 $332.65 $350.01 $369.07

WL1, 2, XL 02, 26 7 $343.75 $361.18 $378.55

15 8 $365.91 $386.50 $402.39

01 3 $267.70 $289.85 $304.11

BRG, BRH, NG, 12, 17, 22, 23, 24 4 $267.70 $289.85 $304.11

NH, HSG, HSH 31, 32, 33, 34, 37, 38 5 $267.70 $289.85 $304.11

11, 13, 16, 19, 20, 21, 27 6 $289.85 $312.12 $326.32

02, 26 7 $299.40 $319.93 $337.37

01 3 $332.65 $350.01 $365.91

JG1, JH1, VG, VH, 12, 17, 22, 23, 24 4 $332.65 $350.01 $365.91

WG1, 2, WH1, 2, 31, 32, 33, 34, 37, 38 5 $332.65 $350.01 $365.91

XG, XH 11, 13, 16, 19, 20, 21, 27 6 $350.01 $372.28 $386.50

02, 26 7 $361.18 $381.65 $395.92

• Example - BRL trim for an "01" function: BRL4x finish

• Trim packs are supplied less cylinder. Each pack includes inside & outside trims, spindle, turnpiece (where applicable), & mounting screws.

1JL, JG, JH, WL, WG, & WH trim designs not available in 32 or 32D finish

2WL, WG, & WH trim designs require handing

Trim Design Lock Function Suffix No. 26D 03, 04, 10, 10B, 10BE, 26 32, 32D

BM Lever Trims

ASSA ABLOY, the global leader

in door opening solutions

Arrow’s heavy-duty Professional

Replacement Products.

Fewer parts, stronger security.

QL Series

BHMA Certified

Grade 1

10-Year Warranty

MLX Series

BHMA Certified

Grade 2

For more information, visit

www.arrowlock.com.

Comparably priced and easy to install,

the QL and MLX Series are efficient and

economical options that deliver fast

retrofitting and robust security features.

Cylindrical &

Tubular Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

QL Series

Certification BHMA A156.2, Series 4000, Grade 1, UL Listed

Freewheeling Lever Action Standard

Door Thickness Fits 1-3/8" to 1-3/4", factory set for 1-3/4"

Strike ANSI 1-1/4" x 4-7/8"

Latch 2-3/4" backset, 1-1/8" front

Cylinder Standard 6 Pin, solid brass, 2 nickel-plated brass keys, IC prep available

Handing Non-handed

Case Quantity 6 per case

Average Case Weight 27 lbs.

Warranty 10 years

Features

Bright Brass 03 605 US3

Dark Oxidized Satin Bronze, Clear Coated 10BP 614 US10BL

Satin Chromium Plated 26D 626 US26D

Available Finishes Arrow Code BHMA Code U.S. Code

Function & Trim QL81-SB

Finish QL81-SB-26D

Strike QL81-SB-26D-306

Latch QL81-SB-26D-306-Q71

Keying QL81-SB-26D-306-Q71-ARKD

How to Order

QL01-SB Passage $191.00

QL72-SB Privacy $222.00

QL81-SB Entrance $248.00

QL82-SB Storeroom $248.00

QL87-SB Classroom $248.00

QL97-SB Classroom Intruder $309.00

Function Description 03, 10BP, 26D

QL02-SB Privacy $222.00

QL11-SB Entrance $248.00

QL12-SB Storeroom $248.00

QL17-SB Classroom $248.00

QL19-SB Dormitory $248.00

QL33-SB Asylum $284.00

QL37-SB Classroom Intruder $309.00

Rigid Lever Function Description 03, 10BP, 26D

QL89-SB Dormitory $248.00

QL93-SB Asylum $284.00

Specify SR trim for QL design with removable thru-bolts.

Freewheeling Function Description 03, 10BP, 26D

* * * AVAILABLE THROUGH SELECT DISTRIBUTORS – CONTACT ARROW LOCK FOR MORE INFORMATION * * *

Cylindrical &

Tubular Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

Keyed different, AR keyway ARKD Standard

Keyed different, CS keyway CSKD No Add

Lock prepared to accept a 6- or 7-pin SFIC cylinder (not included) IC No Add

Lock prepared to accept Schlage LFIC cylinder (not included) S IC 1$25.00

1Not available with 10BP finish, 03 finish, or the QL97 function.

Keying & Cylinder Options Specify Price Add

QL Series

Standard cylinder with tailpiece – AR keyway 700HD $25.00

Standard cylinder with tailpiece – CS keyway 700HD-CS $25.00

Strike 306 $25.44

Latch - 2-3/4" backset Q731or Q712$20.28

Screw pack QL-201 $1.80

IC Tailpiece pack (6- & 7- pin tailpieces) RLX-44-201 $4.79

SIC Tailpiece QL-44S $13.00

1Used only with non-keyed functions.

2Used only with keyed functions.

Parts Part No. Price

2-3/4" backset x 1-1/8" front Q73 Q71 Standard

Latch Options Spring Latch Dead Latch Price Add

Cylindrical &

Tubular Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

Q Series

Certification BHMA A156.2, Series 4000, Grade 1, UL Listed

Door Thickness 1-3/4"

Strike Standard: ANSI 1-1/4" x 4-7/8"; alternate strikes available

Latch Standard: 2-3/4" backset, 1-1/8" front; 3-3/4" backset available

Cylinder Standard: 6-pin, solid brass, 2 nickel-silver keys; IC prep available

Handing Non-handed

Case Quantity 10

Average Case Weight 46 lbs.

Warranty 3 years

Features

Bright brass 03 605 US3

Satin brass 04 606 US4

Satin bronze 10 612 US10

Dark oxidized satin bronze, oil rubbed 10B 613 US10B

Bright chromium plated 26 625 US26

Satin chromium plated 26D 626 US26D

Available Finishes Arrow Code BHMA Code U.S. Code

Function Q11

Trim Q11-SR

Finish Q11-SR-26D

Strike Q11-SR-26D-306

Latch Q11-SR-26D-306-161

How to Order

DISCONTINUED. LIMITED AVAILABILITY THROUGH DISTRIBUTION ONLY.

CONTACT CUSTOMER SERVICE FOR ADDITIONAL INFORMATION.

Cylindrical &

Tubular Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

Q Series

Standard Functions

SR Trim

Q01 F75 Passage $327.68 $343.68

Q02 F76 Privacy $399.53 $415.53

Q03 F111 Communicating Passage $327.68 $335.68

Q06 F76 Hospital Privacy $449.08 $465.08

Q07 F89 Exit $399.53 $415.53

Function ANSI Description 26D 03, 04, 10, 10B, 26

Non-Keyed Functions

Q11 F109 (F81 & F82) Entrance/Office $441.09 $457.09

Q12 F86 Storeroom $441.09 $457.09

Q13 F82 Exterior $441.09 $457.09

Q14 F92 Service Station $476.23 $492.23

Q151F93 Hotel $556.16 $572.16

Q17 F84 Classroom $441.09 $457.09

Q19 F90 Dormitory $476.23 $492.23

Function ANSI Description 26D 03, 04, 10, 10B, 26

Single Cylinder Functions

Q31 F80 Communicating $528.93 $544.93

Q32 F88 Public Entrance $528.93 $544.93

Q33 F87 Asylum $528.93 $544.93

Q35 F91 Exterior $528.93 $544.93

Q37 F110 Intruder Classroom $556.16 $572.16

1Hotel function with IC option is only available for 6-pin SFIC core cylinder.

Function ANSI Description 26D 03, 04, 10, 10B, 26

Double Cylinder Functions

DISCONTINUED. LIMITED AVAILABILITY THROUGH DISTRIBUTION ONLY.

CONTACT CUSTOMER SERVICE FOR ADDITIONAL INFORMATION.

Cylindrical &

Tubular Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

Q Series

Overdrive™Functions

SR Trim

Q72 F76 Privacy $412.31 $428.31

Q76 F76 Hospital Privacy $461.86 $477.86

Q77 F89 Exit $412.31 $428.31

Function ANSI Description 26D 03, 04, 10, 10B, 26

Non-Keyed Functions

Q81 F109 (F81 & F82) Entrance/Office $453.85 $469.85

Q82 F86 Storeroom $453.85 $469.85

Q83 F82 Exterior $453.85 $469.85

Q84 F92 Service Station $489.01 $505.01

Q87 F84 Classroom $453.85 $469.85

Q89 F90 Dormitory $489.01 $505.01

Function ANSI Description 26D 03, 04, 10, 10B, 26

Single Cylinder Functions

Q91 F80 Communicating $541.78 $557.78

Q92 F88 Public Entrance $541.78 $557.78

Q93 F87 Asylum $541.78 $557.78

Q95 F91 Exterior $541.78 $557.78

Q97 F110 Intruder Classroom $569.00 $585.00

Function ANSI Description 26D 03, 04, 10, 10B, 26

Double Cylinder Functions

DISCONTINUED. LIMITED AVAILABILITY THROUGH DISTRIBUTION ONLY.

CONTACT CUSTOMER SERVICE FOR ADDITIONAL INFORMATION.

Cylindrical &

Tubular Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

Q Series

Options

306 320 302 303

ANSI 1-1/4” x 4-7/8”, 1-1/4” lip, square corner, no box 306 Standard

T-Strike 1-1/8” x 2-3/4”, 1-1/4” lip, square corner, no box 320 No Add

Full Lip D-Type 1-3/4” x 2-1/4”, 1-1/4” lip, square corner 302 No Add

Radius D-Type 1-3/4” x 2-1/4”, 1-1/4” lip, 1/4” radius corner 303 No Add

Less Strike LST -$8.10

Box Strike Supplied when specified WBS No Add

Strike Options Description Specify Price Add

1-1/8”, square corner 160 161 Standard

2-3/4” Backset 1-1/8”, square corner, 3/4” throw - 179 $129.85

Drive-in - 164 No Add

3-3/4” Backset 1-1/8”, square corner 165 166 $63.40

Less latch LAT -$16.60

Latch Options Description Specify >>> Spring Latch Dead Latch Price Add

Keyed different KD Standard

Master keyed (except Hotel function) MK $12.38 per cylinder

Construction master keyed CMK $7.77 per cylinder

Master keyed & construction master keyed MK-CMK $20.15 per cylinder

O-Bitted OB No Add

Less cylinder LC -$8.50

Lock prepared to accept 6 or 7-pin SFIC cylinder, less core IC No Add

SR design prepared to accept Medeco or ASSA LFIC cylinder, less core LIC $14.97

Keying & Cylinder Options Specify Price Add

Abrasive outside lever 113 $55.60

Abrasive inside lever 114 $55.60

Lead lined roses (inside & outside) 133 $197.36

Miscellaneous Options Specify Price Add

DISCONTINUED. LIMITED AVAILABILITY THROUGH DISTRIBUTION ONLY.

CONTACT CUSTOMER SERVICE FOR ADDITIONAL INFORMATION.

Cylindrical &

Tubular Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

Q Series

Options

Fail-safe trim control (applied to 12 function only) 12V AC/DC 177 $449.37

24V AC/DC 179 $449.37

Fail-secure trim control (applied to 12 function only) 12V AC/DC 181 $449.37

24V AC/DC 183 $449.37

1Electrification charges do not include price of locksets.

Fail-safe Power on locks outside lever

Inside lever always free

Latch retracted by keys when locked electrically

Fail-secure Power off locks outside lever

Inside lever always free

Latch retracted by keys when locked electrically

Specifications 12VAC/VDC @ 250mA 51 ohms

24VAC/VDC @ 150mA 165.5 ohms

Description Voltage Specify Price Add1

Electrification Options

DISCONTINUED. LIMITED AVAILABILITY THROUGH DISTRIBUTION ONLY.

CONTACT CUSTOMER SERVICE FOR ADDITIONAL INFORMATION.

Cylindrical &

Tubular Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

Q Series

Parts

ANSI 1-1/4” x 4-7/8”, 1-1/4” lip, square corner • 306 $25.44

T-Strike 1-1/8” x 2-3/4”, 1-1/4” lip, square corner • 320 $12.83

Full Lip D-Type 1-3/4” x 2-1/4”, 1-1/4” lip, square corner • 302 $8.08

Radius D-Type 1-3/4” x 2-1/4”, 1-1/4” lip, 1/4” radius corner • 303 $8.08

Box Strike Used with 306 ANSI strike BX70 $4.84

Box Strike Used with 320, 302, or 303 strike BX10 $4.84

Strikes Description Specify Finish Part No. Price

2-3/4” Backset 1-1/8”, square corner • 160 161 $50.74

2-3/4” Backset 1-1/8”, square corner, 3/4” throw • - 179 $180.59

3-3/4” Backset 1-1/8”, square corner, UL • 165 166 $114.14

2-3/4” Backset Drive-in - 164 $50.74

5" Extension link Used only with 160 or 161 latch H25X5 $79.21

Latches Description Specify Finish Spring Latch No. Dead Latch No. Price

Standard cylinder (includes tailpiece) • 600HD $25.00

Hotel cylinder • H100HD $38.95

Standard keyblank K6A $1.23

Standard tailpiece (except hotel function) 1001-44 $2.48

Hotel function tailpiece 1001H-44 $2.48

SFIC 6 & 7 pin tailpiece pack (except 19 function) HSCR-44-201 $4.79

SFIC 6 & 7 pin tailpiece pack for 19 function HSTCR-44-201 $4.79

LFIC tailpiece HSCRA-44 $3.02

LFIC tailpiece retainer HSCRA-66 $0.42

Cylinder & Related Specify Finish Part No. Price

DISCONTINUED. LIMITED AVAILABILITY THROUGH DISTRIBUTION ONLY.

CONTACT CUSTOMER SERVICE FOR ADDITIONAL INFORMATION.

Cylindrical &

Tubular Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

GL Series

Certification BHMA A156.2, Series 4000, Grade 1, UL Listed

Door Thickness Fits 1-3/4" - 2", factory set for 1-3/4"

Strike ANSI 1-1/4" x 4-7/8"

Latch 2-3/4" backset, 1-1/8" front

Cylinder Standard: 6-pin, solid brass, 2 brass keys; IC prep available

Handing Non-handed

Case Quantity 10

Average Case Weight 50 lbs.

Warranty 5 years

Features

Bright Brass 03 605 US3

Dark Oxidized Satin Bronze, Oil Rubbed 10B 613 US10B

Satin Chromium Plated 26D 626 US26D

Available Finishes Arrow Code BHMA Code U.S. Code

Function & Trim GL81-SR

Finish GL81-SR-26D

Strike GL81-SR-26D-306

Latch GL81-SR-26D-306-G71

Keying GL81-SR-26D-306-G71-KD-AR

How to Order

GL01-SR F75 Passage $197.42 $213.38

GL02-SR F76 Privacy $230.30 $246.26

GL08-SR - Single Dummy $105.29 $113.27

GL81-SR F109 Entrance $256.59 $272.55

GL82-SR F86 Storeroom $256.59 $272.55

GL87-SR F84 Classroom $256.59 $272.55

GL97-SR F110 Classroom Intruder $322.38 $338.34

Function ANSI Description 03, 26D 10B

Cylindrical &

Tubular Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

GL Series

Options & Parts

ANSI Strike 306 Standard

Latch (keyed functions) - 2-3/4" backset, 1-1/8" front G71 Standard

Latch (non-keyed functions) - 2-3/4" backset, 1-1/8" front G73 Standard

Strike & Latch Options Specify Price Add

Keyed different KD Standard

Master keyed MK $12.38 per cylinder

Construction master keyed CMK $7.77 per cylinder

Master keyed & construction master keyed MK-CMK $20.15 per cylinder

Keyed alike KA No Add

O-Bitted OB No Add

Less cylinder LC -$8.50

Lock prepared to accept 6 or 7-pin SFIC cylinder, less core IC No Add

Lock prepared to accept Medeco or ASSA LFIC cylinder, less core LIC $14.97

Keying & Cylinder Options Specify Price Add

ANSI Strike 306 $25.44

Standard dead latch (for keyed functions) G71 $20.28

Standard spring latch (for passage & privacy functions) G73 $20.28

Standard cylinder w/tailpiece 600HD-GL $25.00

Standard keyblank K6A $1.23

Standard tailpiece 1001GL-44 $2.48

LIC tailpiece pack HSCRAGL-44-201 $3.97

Parts Part No. Price

2-3/8" Backset 1" front G72 G70 $20.28

3-3/4" Backset 1-1/8" front G83 G81 $25.86

5" Backset 1-1/8" front G93 G91 $30.15

Backset Description Specify >>> Spring Latch Dead Latch Price

Alternate Latches (sold only as separate parts)

Cylindrical &

Tubular Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

HK Series

Certification BHMA A156.2, Series 4000, Grade 1, UL Listed

Door Thickness Fits 1-3/8" to 2" factory set to 1-3/4"

Strike ANSI 1-1/4" x 4-7/8"

Latch 2-3/4" backset, 1-1/8" front

Cylinder Standard 6 Pin, solid brass, 2 nickel-plated brass keys, IC prep available

Handing Non-handed

Case Quantity 16

Average Case Weight 50 lbs.

Warranty 10 years

Features

Bright Brass 03 605 US3

Dark Oxide Satin Bronze, Clear Coated 10BP 614 US10BL

Satin Stainless Steel 32D 630 US32D

Available Finishes Arrow Code BHMA Code U.S. Code

Function & Trim HK11-BB

Finish HK11-BB-32D

Strike HK11-BB-32D-306

Latch HK11-BB-32D-306-Q71

Keying HK11-BB-32D-306-Q71-ARKD

How to Order

HK01-BB Passage $191.00

HK02-BB Privacy $232.00

HK08-BB Single Dummy $114.00

HK11-BB Entrance $273.00

HK12-BB Storeroom $273.00

HK17-BB Classroom $273.00

Function Description 03, 10BP, 32D

Keyed different, AR keyway ARKD Standard

Keyed different, CS keyway CSKD No Add

Lock prepared to accept a 6- or 7-pin SFIC cylinder (not included) IC No Add

Keying & Cylinder Options Specify Price Add

2-3/4" backset x 1-1/8" front Q73 Q71 Standard

Latch Options Spring Latch Dead Latch Price Add

HK33-BB Asylum $299.00

Function Description 03, 10BP, 32D

* * * AVAILABLE THROUGH SELECT DISTRIBUTORS – CONTACT ARROW LOCK FOR MORE INFORMATION * * *

Cylindrical &

Tubular Locks

January 1, 2015

HK Series

ASSA ABLOY, the global leader

in door opening solutions

Standard cylinder with tailpiece – AR keyway 700HD $25.00

Standard cylinder with tailpiece – CS keyway 700HD-CS $25.00

Strike 306 $25.44

Latch - 2-3/4" backset Q731or Q712$20.28

Screw pack HK-201 $4.79

IC tailpiece pack (6&7-pin tailpieces) RLX-44-201 $4.79

1Used only with non-keyed functions.

2Used only with keyed functions.

Parts Part No. Price

Cylindrical &

Tubular Locks

January 1, 2015

H Series

ASSA ABLOY, the global leader

in door opening solutions

Certification BHMA A156.2, Series 4000, Grade 1, UL Listed

Door Thickness 1-3/4"

Strike Standard: ANSI 1-1/4" x 4-7/8"; alternate strikes available

Latch Standard: 2-3/4" backset, 1-1/8" front; 3-3/4" backset available

Cylinder Standard: 6-pin, solid brass, 2 nickel-silver keys; IC prep available

Handing Non-handed

Case Quantity 12

Average Case Weight 33 lbs.

Warranty 1 year

Features

Bright Brass 03 605 US3

Satin Brass 04 606 US4

Satin Bronze 10 612 US10

Bright Chromium Plated 26 625 US26

Dark Oxidized Satin Bronze, Oil Rubbed 10B 613 US10B

Satin Chromium Plated 26D 626 US26D

Satin Stainless Steel 32D 630 US32D

Available Finishes Arrow Code BHMA Code U.S. Code

Function H11

Trim H11-TA

Finish H11-TA-26D

Strike H11-TA-26D-306

Latch H11-TA-26D-306-161

Keying H11-TA-26D-306-161-KD-AR

How to Order

DISCONTINUED. LIMITED AVAILABILITY THROUGH DISTRIBUTION ONLY.

CONTACT CUSTOMER SERVICE FOR ADDITIONAL INFORMATION.

Cylindrical &

Tubular Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

H Series

TB BD1BB1

H01 F75 Passage $433.12 $446.48 $459.72

H02 F76 Privacy $530.24 $543.60 $556.84

H03 F111 Communicating Passage $433.15 $439.83 $446.45

H04 F77 Terrace $530.24 $543.60 $556.84

H05 F78 Communicating $555.17 $568.53 $581.77

H07 F89 Exit $433.12 $446.48 $459.72

H08 - Single Dummy $259.88 $266.56 $273.18

Function ANSI Description 04, 10, 26D 03, 10B, 26 32D

Non-Keyed Functions

H11 F109 (F81 & F82) Entrance/Office $614.15 $627.51 $640.75

H12 F86 Storeroom $614.15 $627.51 $640.75

H13 F82 Exterior $614.15 $627.51 $640.75

H14 F92 Service Station $645.17 $658.53 $671.77

H152F93 Hotel $799.83 $813.19 $826.43

H17 F84 Classroom $614.15 $627.51 $640.75

H18 - Communicating $614.17 $620.85 $627.47

H191F90 Dormitory $645.17 $658.53 $671.77

Function ANSI Description 04, 10, 26D 03, 10B, 26 32D

Single Cylinder Functions

H31 F80 Communicating $737.87 $751.23 $764.47

H32 F88 Public Entrance $737.87 $751.23 $764.47

H33 F87 Asylum $737.87 $751.23 $764.47

H35 F91 Exterior $737.87 $751.23 $764.47

1BD & BB trim designs not offered in 32D finish or available with H19 function.

2Hotel function with IC option is only available for 6-pin SFIC core cylinder.

Function ANSI Description 04, 10, 26D 03, 10B, 26 32D

Double Cylinder Functions

DISCONTINUED. LIMITED AVAILABILITY THROUGH DISTRIBUTION ONLY.

CONTACT CUSTOMER SERVICE FOR ADDITIONAL INFORMATION.

Cylindrical &

Tubular Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

H Series

Options

1-1/8”, square corner 160 161 Standard

2-3/4” Backset 1-1/8”, square corner, 3/4” throw - 179 $129.85

Drive-in - 164 No Add

3-3/4” Backset 1-1/8”, square corner 165 166 $63.40

Less latch LAT -$16.60

Latch Options Description Specify >>> Spring Latch Dead Latch Price Add

Keyed different KD Standard

Master keyed MK $12.38 per cylinder

Construction master keyed CMK $7.77 per cylinder

Master keyed & construction master keyed MK-CMK $20.15 per cylinder

O-Bitted OB No Add

Less cylinder LC -$8.50

TA or TB design prepared to accept 6 or 7-pin IC cylinder, less core IC No Add

Keying & Cylinder Options Specify Price Add

ANSI 1-1/4” x 4-7/8”, 1-1/4” lip, square corner, no box 306 Standard

T-Strike 1-1/8” x 2-3/4”, 1-1/4” lip, square corner, no box 320 No Add

Full Lip D-Type 1-3/4” x 2-1/4”, 1-1/4” lip, square corner 302 No Add

Radius D-Type 1-3/4” x 2-1/4”, 1-1/4” lip, 1/4” radius corner 303 No Add

Less Strike LST -$8.10

Box Strike Supplied when specified WBS No Add

Strike Options Description Specify Price Add

Lead lined knobs (inside & outside) 127 $263.03

Lead lined roses (inside & outside) 133 $197.36

Miscellaneous Options Specify Price Add

306 320 302 303

DISCONTINUED. LIMITED AVAILABILITY THROUGH DISTRIBUTION ONLY.

CONTACT CUSTOMER SERVICE FOR ADDITIONAL INFORMATION.

Cylindrical &

Tubular Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

H Series

Parts

1-1/8”, square corner • 160 161 $50.74

2-3/4” Backset 1-1/8”, square corner, 3/4” throw • - 179 $180.59

Drive-in - 164 $50.74

3-3/4” Backset 1-1/8”, square corner, UL • 165 166 $114.14

5" Extension link Used only with 160 or 161 latch H25X5 $79.21

Latches Description Specify Finish Spring Latch No. Dead Latch No. Price

T-Strike 1-1/8” x 2-3/4”, 1-1/4” lip, square corner • 320 $12.83

ANSI 1-1/4” x 4-7/8”, 1-1/4” lip, square corner • 306 $25.44

Full Lip D-Type 1-3/4” x 2-1/4”, 1-1/4” lip, square corner • 302 $8.08

Radius D-Type 1-3/4” x 2-1/4”, 1-1/4” lip, 1/4” radius corner • 303 $8.08

Box Strike Used with 306 ANSI strike BX70 $4.84

Box Strike Used with 320, 302, or 303 strike BX10 $4.84

Strikes Description Specify Finish Part No. Price

Standard cylinder (includes tailpiece) • 600HD $25.00

Hotel cylinder • H100HD $38.95

Standard keyblank K6A $1.23

Standard tailpiece (except hotel function) 1001-44 $2.48

Hotel function tailpiece 1001H-44 $2.48

IC core cylinder - See Keys & Cylinders section --

6 & 7 pin IC cylinder tailpiece pack (except 15 & 19 functions) 100CR-44-201 $4.79

6 & 7 pin IC cylinder tailpiece pack for 19 function 100TCR-44-201 $4.79

Cylinder & Related Specify Finish Part No. Price

DISCONTINUED. LIMITED AVAILABILITY THROUGH DISTRIBUTION ONLY.

CONTACT CUSTOMER SERVICE FOR ADDITIONAL INFORMATION.

Cylindrical &

Tubular Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

ML Series

Certification BHMA A156.2, Series 4000, Grade 2, UL Listed

Door Thickness Fits 1-3/8" - 1-3/4", factory set for 1-3/4"

Strike Standard: ANSI 1-1/4" x 4-7/8"; alternate strikes available

Latch Standard: 2-3/4" backset, 1-1/8" front; alternate latches available

Cylinder Standard: 6-pin, solid brass, 2 nickel-silver keys; IC prep available

Handing Non-handed

Case Quantity 10

Average Case Weight 42 lbs.

Warranty 3 years

Features

Bright Brass 03 605 US3

Satin Brass 04 606 US4

Satin Bronze 10 612 US10

Dark Oxideized Satin Bronze, Oil Rubbed 10B 613 US10B

Bright Chromium Plated 26 625 US26

Satin Chromium Plated 26D 626 US26D

Available Finishes Arrow Code BHMA Code U.S. Code

Function ML11

Trim ML11-SR

Finish ML11-SR-26D

Strike ML11-SR-26D-306

Latch ML11-SR-26D-306-161

Keying ML11-SR-26D-306-161-KD-AR

How to Order

DISCONTINUED. LIMITED AVAILABILITY THROUGH DISTRIBUTION ONLY.

CONTACT CUSTOMER SERVICE FOR ADDITIONAL INFORMATION.

Cylindrical &

Tubular Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

ML Series

Standard

Functions

ML01 F75 Passage $213.15 $227.97

ML02 F76 Privacy $242.51 $257.33

ML03 F111 Communicating Passage $213.16 $220.57

ML06 F76 Hospital Privacy $297.51 $312.33

ML07 F89 Exit $242.51 $257.33

ML08 - Single Dummy Trim $188.52 $195.93

ML09 - Full Dummy Trim $248.65 $263.47

Function ANSI Description 26D 03, 04, 10, 10B, 26

Non-Keyed Functions

ML11 F109 (F81 & F82) Entrance/Office $290.05 $304.87

ML12 F86 Storeroom $290.05 $304.87

ML13 F82 Exterior $290.05 $304.87

ML14 F92 Service Station $333.02 $347.84

ML17 F84 Classroom $290.05 $304.87

Function ANSI Description 26D 03, 04, 10, 10B, 26

Single Cylinder Functions

ML31 F80 Communicating $381.94 $396.76

ML32 F88 Public Entrance $381.94 $396.76

ML33 F87 Asylum $381.94 $396.76

ML35 F91 Exterior $381.94 $396.76

Function ANSI Description 26D 03, 04, 10, 10B, 26

Double Cylinder Functions

SR Trim

DISCONTINUED. LIMITED AVAILABILITY THROUGH DISTRIBUTION ONLY.

CONTACT CUSTOMER SERVICE FOR ADDITIONAL INFORMATION.

Cylindrical &

Tubular Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

ML Series

Overdrive™

Functions

ML72 F76 Privacy $254.38 $269.20

ML76 F76 Hospital Privacy $309.38 $324.20

ML77 F89 Exit $254.38 $269.20

Function ANSI Description 26D 03, 04, 10, 10B, 26

Non-Keyed Functions

SR Trim

ML81 F109 (F81 & F82) Entrance/Office $301.94 $316.76

ML82 F86 Storeroom $301.94 $316.76

ML83 F82 Exterior $301.94 $316.76

ML84 F92 Service Station $344.83 $359.65

ML87 F84 Classroom $301.94 $316.76

Function ANSI Description 26D 03, 04, 10, 10B, 26

ML91 F80 Communicating $393.69 $408.51

ML92 F88 Public Entrance $393.69 $408.51

ML93 F87 Asylum $393.69 $408.51

ML95 F91 Exterior $393.69 $408.51

Function ANSI Description 26D 03, 04, 10, 10B, 26

Single Cylinder Functions

Double Cylinder Functions

DISCONTINUED. LIMITED AVAILABILITY THROUGH DISTRIBUTION ONLY.

CONTACT CUSTOMER SERVICE FOR ADDITIONAL INFORMATION.

Cylindrical &

Tubular Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

ML Series

Options

306 300 302 303

1-1/8”, Square Corner 274 284 Standard

2-3/4” Backset 1”, Square Corner - 282 No Add

1”, Round Corner - 290 No Add

1”, Square Corner 271 281 No Add

2-3/8” Backset 1-1/8”, Square Corner 273 283 No Add

1”, Round Corner 279 289 No Add

3-3/4” Backset 1-1/8”, Square Corner 278 288 $20.59

Less Latch LAT -$9.85

Latch Options Description Specify >>> Spring Latch Dead Latch Price Add

ANSI 1-1/4” x 4-7/8”, 1-1/4” lip, square corner, no box 306 Standard

T-Strike 1-1/8” x 2-3/4”, 1-1/4” lip, square corner, no box 300 No Add

Full Lip D-Type 1-3/4” x 2-1/4”, 1-1/4” lip, square corner, no box 302 No Add

Radius D-Type 1-3/4” x 2-1/4”, 1-1/4” lip, 1/4” radius corner, no box 303 No Add

Less Strike LST -$8.10

Box Strike Supplied when specified WBS No Add

Strike Options Description Specify Price Add

Keyed different KD Standard

Master keyed MK $12.38 per cylinder

Construction master keyed CMK $7.77 per cylinder

Master keyed & construction master keyed MK-CMK $20.15 per cylinder

O-Bitted OB No Add

Less Cylinder LC -$8.50

Lock prepared to accept 6 or 7-pin SFIC cylinder, less core IC No Add

SR design prepared to accept Medeco or ASSA LFIC cylinder, less core LIC $14.97

Keying & Cylinder Options Specify Price Add

Abrasive outside lever 113 $55.60

Abrasive inside lever 114 $55.60

Lead lined roses (inside & outside) 133 $197.36

Miscellaneous Options Specify Price Add

DISCONTINUED. LIMITED AVAILABILITY THROUGH DISTRIBUTION ONLY.

CONTACT CUSTOMER SERVICE FOR ADDITIONAL INFORMATION.

Cylindrical &

Tubular Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

ML Series

Parts

ANSI 1-1/4” x 4-7/8”, 1-1/4” lip, square corner • 306 $25.44

T-Strike 1-1/8” x 2-3/4”, 1-1/4” lip, square corner • 300 $8.08

Full Lip D-Type 1-3/4” x 2-1/4”, 1-1/4” lip, square corner • 302 $8.08

Radius D-Type 1-3/4” x 2-1/4”, 1-1/4” lip, 1/4” radius corner • 303 $8.08

Box Strike Used with 306 ANSI strike BX70 $4.84

Box Strike Used with 300, 302, or 303 strike BX10 $4.84

Strikes Description Specify Finish Strike No. Price

1-1/8”, square corner • 274 284 $30.15

2-3/4” Backset 1”, square corner • - 282 $30.15

1”, round corner • - 290 $30.15

1”, square corner • 271 281 $30.15

2-3/8” Backset 1-1/8”, square corner • 273 283 $30.15

1”, round corner • 279 289 $30.15

3-3/4" Backset 1-1/8", square corner • 278 288 $50.74

Latches Description Specify Finish Spring Latch No. Dead Latch No. Price

Standard cylinder (includes tailpiece) • 600HD $25.00

Hotel cylinder • H100HD $38.95

Standard keyblank K6A $1.23

Standard tailpiece 1001-44 $2.48

SFIC 6 & 7 pin tailpiece pack (except 15 & 19 functions) HSCR-44-201 $4.79

SFIC 6 & 7 pin tailpiece pack for 19 function HSTCR-44-201 $4.79

LFIC tailpiece HSRCM-44 $3.02

LFIC tailpiece retainer HSCRA-66 $0.42

Cylinder & Related Specify Finish Part No. Price

DISCONTINUED. LIMITED AVAILABILITY THROUGH DISTRIBUTION ONLY.

CONTACT CUSTOMER SERVICE FOR ADDITIONAL INFORMATION.

Cylindrical &

Tubular Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

MK Series

Certification BHMA A156.2, Series 4000, Grade 2, UL Listed

Door Thickness Fits 1-3/8" - 1-3/4", factory set for 1-3/4"

Strike Standard: T-strike, 1-1/8" x 2-3/4"; alternate strikes available

Latch Standard: 2-3/4" backset, 1-1/8" front; alternate latches available

Cylinder Standard: 6-pin, keyed 5, solid brass, 2 brass keys; IC prep available

Handing Non-handed

Case Quantity 24

Average Case Weight 32 lbs.

Warranty 1 year

Features

Bright brass 03 605 US3

Satin brass 04 606 US4

Antique brass 05A 609 US5

Satin bronze 10 612 US10

Dark oxidized satin bronze, oil rubbed 10B 613 US10B

Dark oxidized satin bronze, electroplated 10BE 613E US10BE

Satin nickel 15 619 US15

Bright chromium plated 26 625 US26

Satin chromium plated 26D 626 US26D

Available Finishes Arrow Code BHMA Code U.S. Code

Function MK11

Trim MK11-TA

Finish MK11-TA-26D

Strike MK11-TA-26D-300

Latch MK11-TA-26D-300-114

Keying MK11-TA-26D-300-114-KD-AR

How to Order

Cylindrical &

Tubular Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

MK Series

BD1DD1

03, 26D 04,05A,10,10B, 10BE, 15, 26

$176.59 $186.85

$192.95 $203.21

$244.71 $254.97

$192.95 $203.21

$176.61 $181.74

03, 26D 04,05A,10,10B, 10BE, 15, 26

$260.98 $271.24

Prices below include: “TA” trim

prepared for IC cylinder(s), ANSI strike,

& UL latch

MK01 F75 Passage $77.16 $87.42

MK02 F76 Privacy $81.56 $91.82

MK03 F111 Communicating Passage $77.16 $82.29

MK04 F77 Patio $83.07 $93.33

MK05 F78 Communicating $113.26 $123.52

MK08 - Single Dummy $54.96 $60.09

Function ANSI Description 03, 26D 04, 05A, 10, 10B, 10BE,15,26

Non-Keyed Functions

MK11 F109 (F81 & F82) Entrance/Office $115.55 $125.81

MK12 F86 Storeroom $115.55 $125.81

MK13 F82 Exterior $115.55 $125.81

MK14 F92 Service Station $131.91 $142.17

MK151F93 Hotel $183.67 $193.93

MK17 F84 Classroom $131.91 $142.17

MK18 F113 Communicating Classroom $115.57 $120.70

Function ANSI Description 03, 26D 04, 05A, 10, 10B, 10BE,15,26

Single Cylinder Functions

MK31 F80 Communicating $199.94 $210.20

MK32 F88 Public Entrance $199.94 $210.20

MK33 F87 Asylum $199.94 $210.20

MK34 - Exterior $199.94 $210.20

1Not available with IC option.

Function ANSI Description 03, 26D 04, 05A, 10, 10B, 10BE,15,26

Double Cylinder Functions

Cylindrical &

Tubular Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

MK Series

Options

T-Strike 1-1/8” x 2-3/4”, 1-1/4” lip, square corner, no box 300 Standard

ANSI11-1/4” x 4-7/8”, 1-1/4” lip, square corner, no box 3061$17.36

Full Lip D-Type 1-3/4” x 2-1/4”, 1-1/4” lip, square corner 302 No Add

Radius D-Type 1-3/4” x 2-1/4”, 1-1/4” lip, 1/4” radius corner 303 No Add

Less Strike LST -$2.50

Box Strike Supplied when specified WBS No Add

Strike Options Description Specify Price Add

1-1/8”, square corner 104 114 Standard

1-1/8”, square corner, UL122411241$18.92

2-3/4” Backset 1”, square corner 102 112 $4.16

1”, square corner, UL 222 122 $18.92

Drive-in - 116 $6.26

1”, square corner 101 111 No Add

2-3/8” Backset 1”, square corner, UL 221 121 $18.92

1”, round corner 109 - $4.16

Drive-in - 115 $6.26

Less Latch LAT -$3.65

Latch Options Description Specify >>> Spring Latch Dead Latch Price Add

Keyed alike in four (quantity permitting otherwise KD) KA4 Standard

Keyed different KD No Add

Master keyed MK $12.38 per cylinder

Construction master keyed CMK $7.77 per cylinder

Master keyed & construction master keyed MK-CMK $20.15 per cylinder

O-Bitted OB No Add

Less Cylinder LC -$8.50

TA or TB design prepared to accept 6 or 7-pin SFIC cylinder, less core IC 1$24.76

1Unless otherwise specified, locksets requesting “IC” option will be provided with an ANSI strike and UL latch at additional costs shown above.

Keying & Cylinder Options Specify Price Add

Cylindrical &

Tubular Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

MK Series

Parts

T-Strike 1-1/8” x 2-3/4”, 1-1/4” lip, square corner • 300 $8.08

ANSI 1-1/4” x 4-7/8”, 1-1/4” lip, square corner • 306 $25.44

Full Lip D-Type 1-3/4” x 2-1/4”, 1-1/4” lip, square corner • 302 $8.08

Radius D-Type 1-3/4” x 2-1/4”, 1-1/4” lip, 1/4” radius corner • 303 $8.08

Box Strike Used with 306 ANSI strike BX70 $4.84

Box Strike Used with 300, 302, or 303 strike BX10 $4.84

Strikes Description Specify Finish Strike No. Price

1-1/8”, square corner • 104 114 $11.23

1-1/8”, square corner, UL • 224 124 $30.15

2-3/4” Backset 1”, square corner • 102 112 $15.39

1”, square corner, UL • 222 122 $30.15

Drive-in - 116 $17.49

1”, square corner • 101 111 $11.23

2-3/8” Backset 1”, square corner, UL • 221 121 $30.15

1”, round corner • 109 - $15.39

Drive-in - 115 $17.49

3-3/4"1Backset 1-1/8", square corner • 108 118 $31.77

Latches Description Specify Finish Spring Latch No. Dead Latch No. Price

Standard cylinder (except for B knob) (drilled 6, pinned 5) • 100C $25.00

Standard cylinder for B knob (drilled 6, pinned 5) 100C-750 $25.00

Alternate Cylinder (except for B knob) (drilled 6, pinned 6) • 300C $25.00

Alternate Cylinder for B knob (drilled 6, pinned 6) 300C-750 $25.00

Hotel cylinder • H100C $38.95

Standard keyblank K5A $1.23

Standard tailpiece (except for B knob or hotel function) 550AM-44 $2.48

Standard tailpiece for B knob (except hotel function) 750-44 $2.48

Hotel function tailpiece (except for B knob) 550H-44 $2.48

Hotel function tailpiece for B knob 750H-44 $2.48

IC core cylinder - See Keys & Cylinders section --

IC core tailpiece pack (6 & 7 pin included) 550CR-44-201 $4.79

1Sold only as a separate part.

Cylinder & Related Specify Finish Part No. Price

Cylindrical &

Tubular Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

MLX Series

Certification BHMA A156.2, Series 4000, Grade 2, UL Listed

Freewheeling Lever Action Standard

Door Thickness Fits 1-3/8" to 1-3/4", factory set for 1-3/4"

Strike ANSI 1-1/4" x 4-7/8"

Latch 2-3/4" backset, 1-1/8" front

Cylinder Standard: 6 Pin, solid brass, 2 nickel-plated brass keys; IC prep available

Handing Non-handed

Case Quantity 6 per case

Average Case Weight 27 lbs.

Warranty 10 years

Features

Bright Brass 03 605 US3

Dark Oxide Satin Bronze, Clear Coated 10BP 614 US10BL

Satin Chromium Plated 26D 626 US26D

Available Finishes Arrow Code BHMA Code U.S. Code

Function & Trim MLX81-SB

Finish MLX81-SB-26D

Strike MLX81-SB-26D-306

Latch MLX81-SB-26D-306-R21

Keying MLX81-SB-26D-306-R21-ARKD

How to Order

MLX01-SB Passage $119.00

MLX08-SB Single Dummy $47.00

MLX72-SB Privacy $129.00

MLX81-SB Entrance/Office $140.00

MLX82-SB Storeroom $140.00

MLX87-SB Classroom $140.00

Function Description 03, 10BP, 26D

MLX02-SB Privacy $129.00

MLX11-SB Entrance $140.00

MLX12-SB Storeroom $140.00

MLX17-SB Classroom $140.00

MLX19-SB Dormitory $140.00

MLX33-SB Asylum $176.00

Rigid Lever Function Description 03, 10BP, 26D

MLX89-SB Dormitory $140.00

MLX93-SB Asylum $176.00

Specify SR trim for MLX design with removable thru-bolts.

Freewheeling Function Description 03, 10BP, 26D

* * * AVAILABLE THROUGH SELECT DISTRIBUTORS – CONTACT ARROW LOCK FOR MORE INFORMATION * * *

Cylindrical &

Tubular Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

MLX Series

Keyed different, AR keyway ARKD Standard

Keyed different, CS keyway CSKD No Add

Lock prepared to accept a 6- or 7-pin SFIC cylinder (not included) IC No Add

Lock prepared to accept Schlage LFIC cylinder (not included) S IC 1$25.00

1Not available with 10BP or 03 finishes.

Keying & Cylinder Options Specify Price Add

Standard cylinder with tailpiece – AR keyway 700HD $25.00

Standard cylinder with tailpiece – CS keyway 700HD-CS $25.00

Strike 306 $25.44

Latch - 2-3/4" backset R231or R212$14.85

Screw pack QL-201 $1.80

IC Tailpiece pack (6- & 7- pin tail pieces) RLX-44-201 $4.79

Alternate latch – 2-3/8" backset x 1" front (sold only as a separate part) R221or R202$14.85

1Used only with non-keyed functions.

2Used only with keyed functions.

Parts Part No. Price

2-3/4" backset x 1-1/8" front R23 R21 Standard

Strike & Latch Options Spring Latch Dead Latch Price Add

Cylindrical &

Tubular Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

RK Series

Certification BHMA A156.2, Series 4000, Grade 2, UL Listed

Door Thickness Fits 1-3/8" - 1-3/4", factory set for 1-3/4"

Strike Standard: T-strike, 1-1/8" x 2-3/4"; alternate strikes available

Latch Standard: 2-3/8" backset, 1" front; alternate latches available

Cylinder Standard: 6-pin, solid brass, 2 brass keys; IC prep available

Handing Non-handed

Case Quantity 10

Average Case Weight 13 lbs.

Warranty 5 years

Features

Bright Brass 03 605 US3

Satin Brass 04 606 US4

Satin Bronze 10 612 US10

Dark Oxidized Satin Bronze, Oil Rubbed 10B 613 US10B

Dark Oxidized Satin Bronze, Electroplated 10BE 613E US10BE

Polished Stainless Steel 32 629 US32

Satin Stainless Steel 32D 630 US32D

Available Finishes Arrow Code BHMA Code U.S. Code

Function & Trim RK11-BD

Finish RK11-BD-32D

Strike RK11-BD-32D-R60

Latch RK11-BD-32D-R60-R70

Keying RK11-BD-32D-R60-R70-KD-AR

How to Order

Less Cylinder

(specify “LC” suffix)

03, 32D 04, 10, 10B, 10BE, 32

——

$45.22 $55.42

RK01 F75 Passage $47.19 $57.39

RK02 F76 Privacy $48.39 $58.59

RK08 — Single Dummy $17.33 $22.43

RK11 F109 Entrance $53.72 $63.92

RK12 F86 Storeroom $53.72 $63.92

RK17 F84 Classroom $53.72 $63.92

Function ANSI Description 03, 32D 04,10,10B, 10BE, 32

Cylindrical &

Tubular Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

RL Series

BRR TrimSR Trim

Certification BHMA A156.2, Series 4000, Grade 2, UL Listed

Door Thickness Fits 1-3/8" - 1-3/4", factory set for 1-3/4"

Strike Standard: ANSI 1-1/4" x 4-7/8"; alternate strikes available

Latch Standard: 2-3/4" backset, 1-1/8" front; alternate latches available

Cylinder Standard: 6-pin, solid brass, 2 brass keys; IC prep available

Handing Non-handed

Case Quantity 10

Average Case Weight 38 lbs.

Warranty 5 years

Features

Function RL11

Trim RL11-SR

Finish RL11-SR-26D

Strike RL11-SR-26D-R62

Latch RL11-SR-26D-R62-R71

Keying RL11-SR-26D-R62-R71-KD-AR

How to Order

Bright Brass 03 605 US3

Satin Brass 04 606 US4

Satin Bronze 10 612 US10

Dark Oxidized Satin Bronze, Oil Rubbed 10B 613 US10B

Dark Oxidized Satin Bronze, Electroplated 10BE 613E US10BE

Bright Chromium Plated 26 625 US26

Satin Chromium Plated 26D 626 US26D

Available Finishes Arrow Code BHMA Code U.S. Code

Less Cylinder

(specify “LC” suffix)

03, 26D 04,10,10B,10BE, 26

——

$101.11 $111.07

RL01 F75 Passage $90.01 $99.97

RL02 F76 Privacy $93.94 $103.90

RL03 — Communicating $93.95 $98.93

RL08 — Single Dummy $33.96 $38.94

RL11 F109 Entrance $109.61 $119.57

RL12 F86 Storeroom $109.61 $119.57

RL17 F84 Classroom $109.61 $119.57

Function ANSI Description 03, 26D 04,10,10B, 10BE, 26

Cylindrical &

Tubular Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

RK & RL Series

Options & Parts

T-Strike 1-1/8” x 2-3/4”, 1-1/4” lip, square corner – standard with RK Series R60 No Add

Square Corner 1-3/4” x 2-1/4”, 1-1/4” lip, square corner – full lip R61 No Add

ANSI 1-1/4” x 4-7/8”, 1-1/4” lip, square corner – standard with RL Series R62 No Add

Strike Options Description Specify Price Add

T-Strike 1-1/8” x 2-3/4”, 1-1/4” lip, square corner R60 $7.56

Square Corner 1-3/4” x 2-1/4”, 1-1/4” lip, square corner R61 $7.56

ANSI 1-1/4” x 4-7/8”, 1-1/4” lip, square corner R62 $24.01

Strikes Description Part No. Price

Parts

2-3/8" Backset 1”, square corner R72 R70 $15.39

Drive-in 1R76 R74 $15.39

2-3/4" Backset 1-1/8”, square corner R73 R71 $15.39

Drive-in 1R77 R75 $15.39

Latches Description Spring Latch Dead Latch Price

2-3/8” Backset 1”, square corner – standard with RK Series R72 R70 No Add

2-3/4” Backset 1-1/8”, square corner – standard with RL Series R73 R71 No Add

Latch Options Description Specify>>> Spring Latch No. Dead Latch No. Price Add

Keyed different, AR Keyway ARKD Standard

Keyed different, CS Keyway CSKD No Add

Master Keyed MK $12.38 per cylinder

Construction Master Keyed CMK $7.77 per cylinder

Master Keyed & Construction Master Keyed MK-CMK $20.15 per cylinder

Keyed Alike KA No Add

O-bitted OB No Add

Less Cylinder LC -$8.50

Lock prepared to accept 6 or 7-pin SFIC Cylinder, less core IC No Add

Keying & Cylinder Options Specify Price Add

Standard cylinder 100C-RK $25.00

RK Series Standard keyblank K5A $1.23

Standard tailpiece 550RK-44 $2.48

IC tailpiece pack 100CR-44-201 $4.79

Standard cylinder 600HD $25.00

RL Series Standard keyblank K6A $1.23

Standard tailpiece 1001-44 $2.48

IC tailpiece pack HSCR-44-201 $4.79

1Sold only as a separate part; specify 26D or 03 finish.

Cylinders & Related Part No. Price

Cylindrical &

Tubular Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

RLX Series

Certification BHMA A156.2, Series 4000, Grade 2, UL Listed

Freewheeling Lever Action Standard

Door Thickness Fits 1-3/8" to 1-3/4", factory set for 1-3/4"

Strike ANSI 1-1/4" x 4-7/8"

Latch 2-3/4" backset, 1-1/8" front

Cylinder Standard: 6-pin, solid brass, 2 nickel-plated brass keys; IC prep available

Handing Non-handed

Case Quantity 6 per case

Average Case Weight 26 lbs.

Warranty 10 years

Features

Bright Brass 03 605 US3

Dark Oxide Satin Bronze, Oil Rubbed 10B 613 US10B

Satin Chromium Plated 26D 626 US26D

Available Finishes Arrow Code BHMA Code U.S. Code

Function & Trim RLX81-SR

Finish RLX81-SR-26D

Strike RLX81-SR-26D-306

Latch RLX81-SR-26D-306-R21

Keying RLX81-SR-26D-306-R21-ARKD

How to Order

RLX01-SR Passage $101.33 $112.59

RLX08-SR Single Dummy $38.22 $43.85

RLX72-SR Privacy $105.75 $117.01

RLX81-SR Entrance/Office $123.39 $134.65

RLX82-SR Storeroom $123.39 $134.65

RLX87-SR Classroom $123.39 $134.65

Function Description 03, 26D 10BP

* * * AVAILABLE THROUGH SELECT DISTRIBUTORS – CONTACT ARROW LOCK FOR MORE INFORMATION * * *

Cylindrical &

Tubular Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

RLX Series

Options & Parts

2-3/4" backset x 1-1/8" front R23 R21 Standard

Latch Options Spring Latch Dead Latch Price Add

ANSI 306 Standard

Strike Option Specify Price Add

Keyed different, AR keyway ARKD Standard

Keyed different, CS keyway CSKD No add

Lock prepared to accept a 6- or 7-pin SFIC cylinder (not included) IC No add

Keying & Cylinder Options Specify Price Add

Standard cylinder with tailpiece – AR keyway 700HD $25.00

Standard cylinder with tailpiece – CS keyway 700HD-CS $25.00

Strike 306 $25.44

Latch - 2-3/4" backset R231or R212$14.85

Latch - 2-3/8" backset latch x 1" front (sold only as separate part) R221or R202$14.85

Screw pack for latch & strike RLX-201.26D $1.06

Screw pack for chassis, rose, & thru-bolts RLX-201A.FIN $1.80

IC Tailpiece pack (6- & 7-pin tailpieces) RLX-44-201.FIN $4.79

1Used only with non-keyed functions

2Used only with keyed functions

Parts Part No. Price

Cylindrical &

Tubular Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

CK & CL Series

Certification BHMA A156.2, Series 4000, Grade 2

Door Thickness Fits 1-3/8" - 1-3/4", factory set for 1-3/4"

Strike Standard: Full lip 1-5/8" x 2-1/4"; alternate strikes available

Latch Standard: 2-3/8" - 2-3/4" adj. backset, 1" front; alternate latches available

Cylinder 6-pin, solid brass, 2 brass keys

Handing Non-handed

Case Quantity 20

Average Case Weight CK Series - 25 lbs.; CL Series - 38 lbs.

Warranty 5 years

Features

Bright Brass 03 605 US3

Satin Brass 04 606 US4

Antique Brass 05A 609 US5

Satin Nickel 15 619 US15

Bright Chromium Plated 26 625 US26

Satin Chromium Plated 26D 626 US26D

Available Finishes Arrow Code BHMA Code U.S. Code

Function CK11

Trim CK11-TE

Finish CK11-TE-26D

Strike CK11-TE-26D-502

Latch CK11-TE-26D-502-511

Keying CK11-TE-26D-502-511-KD-AR

How to Order

Cylindrical &

Tubular Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

CK & CL Series

LC 1

SC VC OC1

CK01 Passage $41.86 $39.52 $39.02

CK02 Privacy $45.14 $42.80 $42.30

CK04 Patio $45.14 $42.80 $42.30

CK08 Single Dummy $21.06 $19.89 $19.64

CK11 Entrance $76.94 $74.60 $74.10

CK12 Storeroom $76.94 $74.60 $74.10

Function Description TE BE DE

CK Series Functions

CL01 Passage $69.51 $66.21 $63.37

CL02 Privacy $74.99 $71.69 $68.85

CL04 Patio $74.02 $70.72 $67.88

CL08 Single Dummy $32.28 $30.63 $29.21

CL11 Entrance $98.20 $94.90 $92.06

CL12 Storeroom $98.20 $94.90 $92.06

1Handing required for LC & OC trim designs.

Function Description SC VC LC, OC

CL Series Functions

BETE DE

Cylindrical &

Tubular Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

CK & CL Series

Options

500 506 502 503

T-Strike 1-1/8” x 2-3/4”, 1-1/4” lip, square corner 500 No Add

ANSI 1-1/4” x 4-7/8”, 1-1/4” lip, square corner 506 $7.67

Full Lip D-Type 1-3/4” x 2-1/4”, 1-1/4” lip, square corner 502 Standard

Radius D-Type 1-3/4” x 2-1/4”, 1-1/4” lip, 1/4” radius corner 503 No Add

Less Strike LST -$1.50

Strike Options Description Specify Price Add

2-3/8” - 2-3/4” Includes 3 faceplates 501 511 Standard

Adjustable Backset Includes 3 faceplates, UL 531 521 $7.77

Drive-in 505 515 No Add

Less Latch LAT -$4.10

Latch Options Description Specify >>> Spring Latch Dead Latch Price Add

Keyed alike in four (quantity permitting otherwise KD) KA4 Standard

Keyed different KD No Add

Master keyed MK $12.38 per cylinder

Construction master keyed CMK $7.77 per cylinder

Master keyed & construction master keyed MK-CMK $20.15 per cylinder

O-Bitted OB No Add

Less Cylinder LC -$8.50

Keying & Cylinder Options Specify Price Add

Cylindrical &

Tubular Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

CK & CL Series

Parts

T-Strike 1-1/8” x 2-3/4”, 1-1/4” Lip, Square Corner • 500 $4.84

ANSI 1-1/4” x 4-7/8”, 1-1/4” Lip, Square Corner • 506 $12.51

Full Lip D-Type 1-3/4” x 2-1/4”, 1-1/4” Lip, Square Corner • 502 $4.84

Radius D-Type 1-3/4” x 2-1/4”, 1-1/4” Lip, 1/4” Radius Corner • 503 $4.84

Strikes Description Specify Finish Part No. Price

Includes 3 faceplates • 501 511 $12.51

2-3/8” - 2-3/4” Includes 3 faceplates, UL • 531 521 $20.28

Adjustable Backset Drive-in 505 515 $12.51

Latches Description Specify Finish Spring Latch No. Dead Latch No. Price

Standard key blank K5A $1.23

Standard cylinder for CL Series 100YC $25.00

Standard tailpiece for CL Series 10CL-44 $2.48

Cylinder & Related Part No. Price

Standard cylinder for CK Series with TE or DE trim 100YC1 $25.00

BE trim 100YC1-750 $25.00

Standard tailpiece for CK Series with TE or DE trim 10CB2-44 $2.48

BE trim 10CB1-44 $2.48

Components for CK Series shipments beginning April 2011 Trim Part No. Price

Standard cylinder for CK Series with TE or DE trim 100YC $25.00

BE trim 100YC-750 $25.00

Standard tailpiece for CK Series with TE or DE trim 10CL-44 $2.48

BE trim 10CB-44 $2.48

Components for CK Series shipments prior to April 2011 Trim Part No. Price

Auxiliary Locks

January 1, 2015

DB Series

ASSA ABLOY, the global leader

in door opening solutions

Certification ANSI A156.5, Grade 2, UL Listed

Door Thickness Fits 1-3/8" to 1-3/4", factory set to 1-3/4"

Strike 2-3/4" x 1-1/8", round corners

Bolt 2-3/8" - 2-3/4" adjustable backset, 1" front, includes spacer for 1-1/8" prep

Cylinder 6-pin, solid brass, keyed alike in 4, CS keyway, includes 2 brass keys

Handing Non-handed

Case Quantity 12 per case

Average Case Weight DB61-22lbs. / DB62-27lbs.

Warranty 1 year

Features

Function DB61

Finish DB61-32D

Strike DB61-32D-394

Latch DB61-32D-394-157

Keying DB61-32D-394-157-KA4-CS

How to Order

Bright Brass 03 605 US3

Dark Oxide Satin Bronze, Clear Coated 10BP 614 US10BL

Satin Stainless Steel 32D 630 US32D

Available Finishes Arrow Code BHMA Code U.S. Code

DB61 Cylinder x Thumbturn $42.78 $50.44

DB62 Double Cylinder $60.90 $68.56

Function Description 32D 03, 10B

Auxiliary Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

DB Series

Options & Parts

2-3/4" x 1-1/8", round corners 394 Standard

Strike Option Specify Price Add

2-3/8" to 2-3/4" adjustable backset 157 Standard

Bolt Option Specify Price Add

Keyed alike in 4, CS keyway CSKA4 Standard

Keyed alike in 4, AR keyway ARKA4 No Add

Lock prepared to accept a 6- or 7-pin SFIC cylinder (not included) IC $18.67

Keying & Cylinder Options Specify Price Add

DB61 Cylinder, keyed different, CS keyway 95C-CS KD $19.43

DB61 Cylinder, keyed different, AR keyway 95C KD $19.43

DB62 Cylinder, keyed different, CS keyway 95DC-CS KD $19.43

DB62 Cylinder, keyed different, AR keyway 95DC KD $19.43

Strike 394 $6.27

Standard bolt 157 $13.59

Optional drive-in bolt 157D $13.59

Screw Pack DB61 DB61-201 $8.08

DB62 DB62-201 $8.08

Thick Door Pack, up to 2" DB61 DB61-TDP $8.08

DB62 DB62-TDP $8.08

Parts Description Specify Price

D Series

Auxiliary Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

Certification BHMA A156.5, Grade 1, UL Listed

Door Thickness Fits 1-3/8" - 1-3/4", factory set for 1-3/4"

Strike Standard: 1-1/8" x 2-1/4"; alternate strikes available

Latch Standard: 2-3/4" backset, 1-1/8" front; alternate bolts available

Cylinder Standard: 6-pin, solid brass, 2 nickel-silver keys; IC prep available

Handing Non-handed

Case Quantity 12

Average Case Weight 22 lbs.

Warranty 1 year

Features

D60 E01111 Thumbturn x Blank Plate $89.52 $99.82

D61 E0151 Cylinder x Thumbturn $102.70 $113.00

D62 E0141 Double Cylinder $133.48 $143.78

D63 E0161 Cylinder x Blank Plate $107.59 $117.89

D64 E0171 Cylinder x Thumbturn (classroom) $107.59 $117.89

D71-IC1 E0151 Cylinder x Thumbturn $138.99 $149.29

D73-IC1 E0161 Cylinder x Blank Plate $138.99 $149.29

D74-IC1 E0171 Cylinder x Thumbturn (classroom) $138.99 $149.29

1Concealed mounting screws standard on D71 & D73 functions.

Function ANSI Description 03, 26D 04, 05A, 10, 10B, 10BE, 26

ARROW

Bright Brass 03 605 US3

Satin Brass 04 606 US4

Antique Brass 05A 609 US5

Satin Bronze 10 612 US10

Dark Oxidized Satin Bronze, Oil Rubbed 10B 613 US10B

Dark Oxidized Satin Bronze, Electroplated 10BE 613E US10BE

Bright Chromium Plated 26 625 US26

Satin Chromium Plated 26D 626 US26D

Available Finishes Arrow Code BHMA Code U.S. Code

Function D61

Finish D61-26D

Strike D61-26D-346

Latch D61-26D-346-144

Keying D61-26D-346-144-KD-AR

How to Order

Auxiliary Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

E Series

ARROW

Certification BHMA A156.5, Grade 2, UL Listed

Door Thickness Fits 1-3/8" - 1-3/4", factory set for 1-3/4"

Strike Standard: 1-1/8" x 2-1/4"; alternate strikes available

Latch Standard: 2-3/8" backset, 1-1/8" front; alternate bolts available

Cylinder Standard: 6-pin, keyed 5, solid brass, 2 brass keys; IC prep available

Handing Non-handed

Case Quantity 24

Average Case Weight E61s - 39lbs.; E62s - 50lbs.

Warranty 1 year

Features

Bright Brass 03 605 US3

Satin Brass 04 606 US4

Antique Brass 05A 609 US5

Satin Bronze 10 612 US10

Dark Oxidized Satin Bronze, Oil Rubbed 10B 613 US10B

Dark Oxidized Satin Bronze, Electroplated 10BE 613E US10BE

Satin Nickel 15 619 US15

Bright Chromium Plated 26 625 US26

Satin Chromium Plated 26D 626 US26D

Available Finishes Arrow Code BHMA Code U.S. Code

Function E61

Finish E61-26D

Strike E61-26D-346

Latch E61-26D-346-141

Keying E61-26D-346-141-KD-AR

How to Order

E50 – Occupancy Indicator $54.55 $64.81

E60 E01112 Thumbturn x Blank Plate $47.05 $57.31

E61 E0152 Cylinder x Thumbturn $57.27 $67.53

E62 E0142 Double Cylinder $71.86 $82.12

E63 E0162 Cylinder x Blank Plate $64.60 $74.86

E64 E0172 Cylinder x Thumbturn (classroom ) $64.60 $74.86

E71-IC1 E0152 Cylinder x Thumbturn $82.03 $92.29

E74-IC1 E0172 Cylinder x Thumbturn (classroom ) $89.36 $99.62

E41 Low Profile2– Cylinder x Thumbturn $54.55 $64.81

E42 Low Profile2– Double Cylinder $69.15 $79.41

1Furnished with concealed mounting screws.

2Only available in 03, 26D, and 15 finishes.

Function ANSI Description 03, 26D 04, 05A, 10, 10B, 10BE, 15, 26

Auxiliary Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

D & E Series

Options

347346345 350

Square Corner 1-1/8” x 2-3/4”, for wood jambs 345 No Add

Square Corner 1-1/8” x 2-3/4”, for metal jambs 346 Standard

ANSI 1-1/4” x 4-7/8”, 1-1/4” lip, square corner 347 No Add

T-Strike 1-1/8” x 2-3/4”, 1-1/4” lip, square corner 350 No Add

Less Strike LST -$2.55

Strike Options Description Specify Price Add

2-3/4” Backset 1-1/8”, square corner 144 Standard (D Series)

2-3/8” Backset 1”, square corner 141 Standard (E Series)

2-3/4” Backset 1”, square corner 142 No Add

2-3/8” Backset Drive-in 145 No Add

2-3/4” Backset Drive-in 146 No Add

Less Latch LAT -$5.70

Bolt Options Description Specify >>> Spring Latch Dead Latch Price Add

Keyed different KD Standard (D Series)

Keyed alike in four (quantity permitting) KA4 Standard (E Series)

Master keyed 1MK $12.38 per cylinder

Construction master keyed 1CMK $7.77 per cylinder

Master keyed & construction master keyed 1MK-CMK $20.15 per cylinder

O-Bitted 1OB No Add

Less Cylinder1LC -$8.50

Lock prepared to accept 6 or 7-pin IC cylinder, less core IC $24.76

1Not available with E41 or E42 function.

Keying & Cylinder Options Specify Price Add

Auxiliary Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

D & E Series

Parts

Square Corner 1-1/8” x 2-3/4”, for metal jambs • 345 $8.08

Square Corner 1-1/8” x 2-3/4”, for wood jambs • 346 $8.08

ANSI 1-1/4” x 4-7/8” • 347 $15.93

T-Strike 1-1/8” x 2-3/4”, 1-1/4” lip • 350 $8.08

Box strike for E Series BX91 $2.60

Box strike for D Series BX91D $2.60

Strikes Description Specify Finish Part No. Price

Standard cylinder for E61, E63, E64 • 96C1$25.00

Standard cylinder for E62 • 96DC $25.00

Standard cylinder for E41 • 100 $25.00

Standard cylinder for E42 • 100DC $25.00

Standard cylinder for D61, D63, D64 • 692C $25.00

Standard cylinder for D62 • 692DC $25.00

Single cylinder tailpiece, 1-3/8" to 1-3/4" thick door D61-44 $2.48

E42 tailpiece for 1-3/4" thick door D62-44J $2.48

E42 tailpiece for 1-3/8" thick door D62CR-44 $2.48

Double cylinder tailpiece, 1-3/4" thick door D62-44 $2.48

Double cylinder tailpiece, 1-3/8" thick door D62-44-13/8 $2.48

E60/D60 Function tailpiece E60-44 $2.48

Cam assembly for 6 & 7-pin IC cylinders D61CR-121A $4.79

1When ordered separately, can be installed on E41 for use on 1-3/4" thick door installation.

Cylinder & Related Specify Finish Part No. Price

2-3/4” 1-1/8”, square corner • 144 $17.49

2-3/8” 1”, square corner • 141 $17.49

2-3/4” 1”, square corner • 142 $17.49

2-3/8” Drive-in • 145 $17.49

2-3/4” Drive-in • 146 $17.49

Bolts Description Specify Finish Part No. Price

E60 Screwpack E60-201 $8.08

D60 Screwpack D60-201 $8.08

E61 Screwpack • E61-201 $8.08

D61 Screwpack • D61-201 $8.08

E62/D62 Screwpack • DE62-201 $8.08

E61 Thick door pack, up to 2-1/4" • E61-TDP $8.08

D61 Thick door pack, up to 2-1/4" • D61-TDP $8.08

E62/D62 Thick door pack, up to 2-1/4" • E62-TDP $8.08

Parts & Accessories Specify Finish Part No. Price

Auxiliary Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

N Series

Certification UL Listed

Door Thickness Fits 1-3/8" - 1-3/4"

Strike Standard: 1-1/8" x 3-1/2"; alternate strikes available

Bolt 1" throw with hardened pin

Backset 2-3/4"

Cylinder Standard: 6-pin, solid brass, 2 nickel-silver keys; IC prep available

Handing Non-handed

Case Quantity 20

Average Case Weight 38 lbs.

Warranty 1 year

Features

Bright Brass 03 605 US3

Satin Brass 04 606 US4

Satin Bronze 10 612 US10

Dark Oxidized Satin Bronze, Oil Rubbed 10B 613 US10B

Dark Oxidized Satin Bronze, Electroplated 10BE 613E US10BE

Bright Chromium Plated 26 625 US26

Satin Chromium Plated 26D 626 US26D

Available Finishes Arrow Code BHMA Code U.S. Code

Function N41

Finish N41-26D

Strike N41-26D-380

Keying N41-26D-380-KD-AR

How to Order

N40 - Thumbturn One Side $196.69 $203.65

N41 E06071 Cylinder x Thumbturn $226.35 $233.31

N42 E06061 Double Cylinder $235.01 $241.97

N43 E06081 Cylinder One Side $205.48 $212.44

N44 E06091 Cylinder x Thumbturn (classroom) $229.76 $236.72

Function ANSI Description 26D 03, 04, 10, 10B, 10BE, 26

Auxiliary Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

N Series

Options & Parts

356380

836-17A

Square Corner 1-1/8” x 3-1/2” 380 Standard

ANSI 1-1/4” x 4-7/8” 356 $7.85

Strike Options Description Specify Price Add

Standard mortise cylinder • MC61-004 $38.95

Square corner strike, 1-1/8” x 3-1/2” • 380 $8.08

ANSI strike, 1-1/4” x 4-7/8” • 356 $15.93

Thumbturn • 836-17A $21.84

Faceplate & screw pack • 836-204 $18.73

Lock body only 836K-LB $147.66

Parts Specify Finish Part No. Price

Keyed different KD Standard

Master keyed MK $12.38 per cylinder

Construction master keyed CMK $7.77 per cylinder

Master keyed & construction master keyed MK-CMK $20.15 per cylinder

O-Bitted OB No Add

Less Cylinder LC -$13.50

Lock prepared to accept 6-pin SFIC cylinder, less core IC6 No Add

Lock prepared to accept 7-pin SFIC cylinder, less core IC7 No Add

Keying & Cylinder Options Specify Price Add

Auxiliary Locks

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

Padlocks

1” EPC1-IC $66.15

2” EPC2-IC $67.66

3” EPC3-IC $69.28

Shackle Part No. Price

SFIC Padlocks (cylinder not included)

Keys & Cylinders

January 1, 2015

Keys & Keying

Charges

Standard Cylinders

ASSA ABLOY, the global leader

in door opening solutions

Standard bow, 5-pin key blank, “A” keyway K5A $1.23

Standard bow, 6-pin key blank, “A” keyway K6A $1.23

Large bow, 6-pin key blank, “A” keyway L6A $1.98

Sectional keyway, standard bow, 6-pin K671 x (kwy1) $1.98

Sectional keyway, large bow, 6-pin L671 x (kwy1) $1.98

1Consult factory for Arrow sectional keyways.

Key Blanks Part No. Price

Master keyed $12.38 per cylinder

Construction master keyed $7.77 per cylinder

Keyed different No Add

Keyed alike No Add

0-Bitted No Add

Keying Charges Price

Stamping key with letters and/or numbers (limited to key space) $4.46 per side

Stamping key with US Property Do Not Duplicate $1.61 per side

Stamping non-IC key 2with Do Not Duplicate $1.61 per side

Key Stamping Price

• Bitting lists are provided on disks. Systems not available on disk will be provided on paper.

• Large key systems on paper will be priced on a case-by-case basis.

• Copies of bitting lists may require prior factory approval.

Bitting list only or bitting list copy Bitting List $50.00 net min.

Stamping cylinder (visual) and 2 keys with standard keying symbols VKC $4.46 per set

Stamping cylinder (concealed) and 2 keys with standard keying symbols CKC $4.46 per set

Stamping each additional key with standard keying symbols $2.98 per key

2Coining on IC keys include: Duplication Prohibited or It Is Unlawful To Duplicate This Key.

Key Control for factory-master-keyed systems Specify Price

Extra cut keys $4.12 per key

Master/Grandmaster key $8.32 per key

Construction master key $8.32 per key

Cut Keys Price

K Bow L Bow

Keys & Cylinders

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

Cylinders

Mortise & Rim

Mortise Cylinder Rim Cylinder

Standard 1-1/8” cylinder • MC61-(cam) $38.95

1-1/4” Cylinder • MC61-2-(cam) $38.95

1-1/2” Cylinder • MC61-3-(cam) $57.50

2” Cylinder • MC61-4-(cam) $57.50

1-1/8” Hotel cylinder • MCH61-AM2 $57.50

1Standard 001 cam supplied unless otherwise specified.

Mortise Cylinders1Specify Finish Part No. Price

Standard 6-pin cylinder • RC62 $38.95

Rim Cylinders Specify Finish Part No. Price

Cam for mortise lock functions 12, 17, 22, 23, 24, 27, 32 (I/S), 33, 37 001 $3.30

Cam for mortise lock functions 11, 13, 19, 20, 21, 31, 32 (O/S), 34, 38, 40, 41, 42, 44 AM2 $3.30

Cam for N series, panic device trims, alarms 004 $3.30

Cam for Schlage locks 006 $3.30

Cam for Adam Rite locks AR18 $3.30

Cylinder collar and spring • 16-113A $8.80

Mortise Cylinder Parts Specify Finish Part No. Price

Cam bar for RC62 16RC-44 $2.48

Plug/cam bar retainer 16RC-103 $0.94

Rim Cylinder Parts Part No. Price

Keys & Cylinders

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

Conventional

Cylinders

Cylindrical Locks

& Deadbolts

Cylindrical Lock Cylinder Deadbolt Cylinder

Q, W, H, S, ML, L Series (except hotel function) • 600HD $25.00

Q, W, H, ML Series hotel function • H100HD $38.95

MK Series (except hotel function) • 100C $25.00

MK Series hotel function • H100C $38.95

CL & CK Series (except BE trim design) • 100YC $25.00

CK Series with BE trim design • 100YC-750 $25.00

Cylinder kit (D/B style cyl w/3 D/B cambars, 3 KIK/KIL tail pcs, D/B washer) • K100C $29.50

Cylindrical Lock Cylinders Specify Finish Part No. Price

Q, W, H, S, ML, L & RL Series (except hotel function) 1001-44 $2.48

Q, W, H, & ML Series hotel function 1001H-44 $2.48

S Series SS1001-44 $2.48

MK Series with TA, TB, DD, or DB trim (except hotel function) 550AM-44 $2.48

MK Series with BD or BB trim (except hotel function), and RK Series 750-44 $2.48

MK Series hotel function with TA, TB, DD, or DB trim 550H-44 $2.48

MK Series hotel function with BD or BB trim 750H-44 $2.48

C Series (except BE trim design) 10CL-44 $2.48

C Series with BE trim design 10CB-44 $2.48

Tailpiece Application Part No. Price

D & E Series single cylinder, 1-3/8” to 1-3/4” thick door D61-44 $2.48

D & E Series double cylinder, 1-3/4” thick door D62-44 $2.48

D & E Series double cylinder, 1-3/8” thick door D62-44-13/8 $2.48

Tailpiece Application Part No. Price

E Series single cylinder • 96C $25.00

E Series double cylinder • 96DC $25.00

D Series single cylinder • 692C $25.00

D Series double cylinder • 692DC $25.00

Deadbolt Cylinders Specify Finish Part No. Price

Arrow A AR

Schlage C CS

Schlage E ES

Available Keyways Arrow Equivalent

Keys & Cylinders

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

Mortise IC Housing Rim IC Housing

Standard • 16CR-16X (cam) $37.47

6-pin housings, 1-1/8” Tapered • 16CRT-16XAR18 $38.90

7-pin housings, 1-1/4” Standard • 16CR-27X (cam) $37.47

Tapered • 16CRT-27XAR18 $38.90

1Standard 16CR-001 cam supplied unless otherwise specified.

Mortise Housings1Specify Finish Part No. Price

Cam for mortise lock functions 12, 17, 22, 23, 24, 27, 32 (I/S), 33, 37 16CR-001 $3.30

Cam for mortise lock functions 11, 13, 19, 20, 21, 31, 32 (O/S), 34, 38, 40, 41, 42, 44 16CR-AM2 $3.30

Cam for N series, panic device trims, alarms 16CR-004 $3.30

Cam for Schlage locks 16CR-006 $3.30

Cam for Adams Rite locks 16CR-AR18 $3.30

1/8” Spacer ring • 16CR-123-1 $12.83

1/4” Spacer ring • 16CR-123-2 $12.83

3/8” Spacer ring • 16CR-123-3 $12.83

Mortise Housing Parts Specify Finish Part No. Price

Cam bar 16RCR-44 $2.48

Cam assembly (equal leg prongs) 16RCR-121A $8.08

Spring washer 16RCR-125 $0.74

Yoke plate 961CR-117 $0.94

Pan head screw (2 required) 4-40X1/4 $0.42

• See Plus Housings section for Plus-related components.

Rim Housing Parts Part No. Price

6-pin housing • 16RCR-16 $37.47

7-pin housing • 16RCR-27 $37.47

Rim Housings Specify Finish Part No. Price

IC Housings

Keys & Cylinders

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

Pointe SFIC Cylinders

6-pin core Uncombinated 100CR-UCX (kwy) $19.79

Combinated1100CR- (kwy) $37.42

7-pin core Uncombinated 7100CR-UCX (kwy) $19.79

Combinated17100CR- (kwy) $37.42

SFIC Cylinders with Standard Barrel Caps Part No. 04, 26D

6-pin core Uncombinated 100SR-UCX (kwy) $21.82

Combinated1100SR- (kwy) $40.80

7-pin core Uncombinated 7100SR-USX (kwy) $21.82

Combinated17100SR- (kwy) $40.80

1Combinated cores includes 2 operating keys and related keying charges.

SFIC Cylinders with Slide Cover Part No. 04, 26D

Key blank GB(kwy) $3.07

Operating key $9.22

Control key $9.22

For Keyways: WA, WB, WC, WG, WH, WY Part No. Price

Key blank C(kwy) $1.23

Operating key $4.12

Control key $8.32

For Keyways: 1C, 1D, AB, BB, CB, DB, EB, FB, GB, HB, JB, KB, LB, MB, QB, RB, TA, TB, TC, TD, TE Part No. Price

Keys

Stamping key with letters and/or numbers (limited to key space) $4.46 per side

Stamping key with US Property Do Not Duplicate $1.61 per side

Stamping Charges Price

Stamping cylinder (visual) and 2 keys with standard keying symbols VKC No Add

Stamping cylinder (concealed) and 2 keys with standard keying symbols CKC No Add

Stamping each additional key with standard keying symbols $2.98 per key

Stamping Charges for factory systems Specify Price

ARROW

IT IS UNLAWFUL

TO DUPLICATE

THIS KEY

Keys & Cylinders

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

Construction Cores & Tailpieces

6-pin construction core 100CR.RED $19.79

7-pin construction core 7100CR.RED $19.79

Disposable plastic actuator for construction phase PK725PA $3.75

Construction master key $8.32 per key

Construction control key $8.32 per key

Construction Cores & Components Part No. 04, 26D

Q, W, ML & RL Series (except 15 & 19 functions) HSCR-44-201 $4.79

Q & W series 19 function HSTCR-44-201 $4.79

MK Series 550CR-44-201 $4.79

6/7-pin tailpiece packs H (except 15 & 19 functions) & RK Series 100CR-44-201 $4.79

H Series 19 function 100TCR-44-201 $4.79

S Series (except 19 function) SS100CR-44-201 $4.79

S Series 19 function SS100TCR-44-201 $4.79

6/7-pin cam assembly for D & E Series deadbolts D61CR-121A $4.79

1See Plus Housings section for Plus-related components.

Tailpieces & Cam Assemblies1Application Part No. Price

Keys & Cylinders

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

Pointe Flex

SFIC Cylinders

Patented Product

6-pin core Uncombinated X1CR-UCX (kwy) $30.17

Combinated X1CR-(kwy) $48.77

7-pin core Uncombinated X71CR-UCX (kwy) $30.17

Combinated X71CR-(kwy) $48.77

Key blanks without hole CH (kwy) $1.23

Key blanks with hole CHX (kwy) $4.12

Cut change keys without hole $5.04

Cut change keys with hole $8.32

Master, grandmaster, or control key $8.32 per key

1See Pointe SFIC page for stamping charges.

• Contact factory for Flex keyway information.

Pointe Flex SFIC Cylinders & Keys1Part No. 04, 26D

Q, W, ML & RL Series (except 15 & 19 functions) HSCR-44-201 $4.79

Q & W series 19 function HSTCR-44-201 $4.79

MK Series 550CR-44-201 $4.79

6/7-pin tailpiece packs for Arrow products H (except 15 & 19 functions) & RK Series 100CR-44-201 $4.79

H Series 19 function 100TCR-44-201 $4.79

S Series (except 19 function) SS100CR-44-201 $4.79

S Series 19 function SS100TCR-44-201 $4.79

Choice Flex tailpiece kit X169 $470.59

Tailpiece for use with Falcon… 6-pin core levers X1CRF6-44 $2.46

7-pin core levers X71CRF7-44 $2.46

Tailpiece for use with Best… 6-pin core levers or knobs X1CRB6-44 $2.46

7-pin core levers or knobs X71CRB7-44 $2.46

Tailpiece insert for cylindrical locks X1CR-125PK $7.99 per 100

Arrow system cards X100 $7.99

Tailpieces & Components Application Part No. Price

7-Pin uncombinated SD7100CR-UCX (kwy) $44.56

7-Pin combinated SD7100CR- (kwy) $56.81

Sliding Door Lock Part No. 04, 26D

DUPLICATION PROHIBITED

Keys & Cylinders

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

Cam Locks

Sub-Assembled CLK-10-(kwy1).26D $56.60

Keyed different or keyed alike w/2 cut keys (not master-keyed) CLK-11-(kwy1).26D $71.69

Master-keyed w/2 cut keys CLK-11M-(kwy1).26D $84.07

1Available with standard Arrow IC keyways except for W and Flex.

Cam Lock Kits Part No. Price

Machined Plug IKMPLG-(kwy).26D $11.33

Shell IKSHELL2.26D $18.57

4-40 Screw IKSCRPLT $0.90

Retainer CP-021810 $0.07

90° Stop IKSTOP2 $2.68

3/4" Hex Nut IKHXNUT $0.33

Drive Pin IKDRPIN $1.53

360° Drive Plate (NKR) IKDRPLT $2.72

90° Drive Plate (KR) IKDRPLT2 $4.15

Cam, Straight IKCAM2 $3.00

Cam, Offset IKCAM3 $6.60

Pronged Washer IKWSH1 $0.75

Tumbler Spring IKTSPRNG2$0.05

Pin Hole Cover IKPNCVR2$0.10

2Unit price shown. Sold in multiple quantities of 100. Minimum quantity 100 pieces.

Cam Lock Parts Part No. Price

Spacer, 1/16" IKSPCR1.26D $4.38

Spacer, 1/8" IKSPCR3.26D $5.05

Spacer, 3/16" IKSPCR4.26D $5.34

Spacer, 1/4" (provided with cam lock kit) IKSPCR5.26D $5.47

Spacer, 5/16" IKSPCR2.26D $5.52

Spacer, 3/8" IKSPCR6.26D $6.18

Spacer, 7/16" IKSPCR7.26D $6.47

Cam Lock Accessories Part No. Price

Keys & Cylinders

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

Plus IC Housings

6-pin housings, 1-1/8” Standard • C16CR-16X (cam) $37.47

Tapered • C16CRT-16XAR18 $38.90

7-pin housings, 1-1/4” Standard • C16CR-27X (cam) $37.47

Tapered • C16CRT-27XAR18 $38.90

Mortise Housings for Plus Cores1, 2 Specify Finish Part No. Price

Cam for mortise lock functions 12, 17, 22, 23, 24, 27, 32 (I/S), 33, 37 001 $3.30

Cam for mortise lock functions 11, 13, 19, 20, 21, 31, 32 (O/S), 34, 38, 40, 41, 42, 44 AM2 $3.30

Cam for N series, panic device trims, alarms 004 $3.30

Cam for Schlage locks 006 $3.30

Cam for Adam Rite locks AR18 $3.30

Cam assembly (unequal leg prongs) for 7-pin mortise housing C16CR-121A $8.08

Cam assembly (unequal leg prongs) for 6-pin mortise housing C16CR-121A-1 $8.08

Mortise Housing Parts Specify Finish Part No. Price

6-pin housing • C16RCR-16 $37.47

7-pin housing • C16RCR-27 $37.47

Rim Housings for Plus Cores1Specify Finish Part No. Price

Cam bar 16RCR-44 $2.48

Cam assembly (unequal leg prongs) for 7-pin rim housing C16RCR-121A $8.08

Cam assembly (unequal leg prongs) for 6-pin rim housing C16RCR-121A-1 $8.08

Spring washer 16RCR-125 $0.74

Yoke plate 961CR-117 $0.94

Pan head screw (2 required) 4-40X1/4 $0.42

Rim Housing Parts Part No. Price

Housing shear tool IC281 $176.95

Q, W, ML, & RL Series (except 15 & 19 functions) CL-44-201 $4.79

Q & W series 19 function CL9-44-201 $4.79

MK Series CM-44-201 $4.79

6/7-pin tailpiece packs H (except 15 & 19 functions) & RK Series CH-44-201 $4.79

H Series 19 function CH9-44-201 $4.79

S Series (except 19 function) SSCH-44-201 $4.79

S Series 19 function SSCH9-44-201 $4.79

6-pin cam assembly for D & E Series D61C6-128A $4.79

7-pin cam assembly for D & E Series D61C7-128A $4.79

1Unequal leg prongs.

2Screw-on cams. Standard 001 cam supplied unless otherwise specified.

Tools & Components Application Part No. Price

Keys & Cylinders

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

Cylinder Parts

& Tools

IC220 Capping Press IC234 Duo Block

IC233 Stamping Tray

1/2 Ton capping press IC220 $1,475.88

Decoding block (to determine control key codes) IC222 $248.66

Dual purpose capping block (standard caps or spring covers) IC223 $248.66

Mortise cylinder installation tool IC230 $46.77

Cam assembly tool for 16CR-xxx housings IC231 $93.37

Stamping tray IC233 $1,563.83

Duo block (for capping) IC234 $220.79

Ejector pin (single ejector) IC235 $32.76

50 Capping strips (200 cores) IC237 $62.23

250 Capping strips (1000 cores) IC238 $304.60

Waffle tray IC239 $65.39

Best style punch machine (A2 system) IC240 $5,891.01

Flex vise for key punch machine IC240A $960.15

IC Tools Part No. Price

Keying kit - pins, springs, slides, retainer rings, plug followers, tail pieces 60-Key-Kit $216.71

Top pins AD142PK $7.63

Replacement pins Bottom pins AB140PK to 149PK $7.63

Note: Bulk packed 100 pcs per pack Master pins AM142PK to 149PK $7.63

Cylinder caps (strips) 60C-111PK $7.63

For conventional cylinders Part No. Price

Keying Kits & Components

Keying kit - pins, springs, cap gauge, pin ejector, capping pin IC200 $633.52

Bottom pins RB100PK to 109PK $8.43

Replacement pins & caps Top pins RM102PK to 119PK $8.43

Note: Bulk packed 100 pcs per pack Springs 100CR-107PK $8.43

Barrel caps 100CR-111PK $8.43

Key gauge IC205 $6.45

Pin ejector IC206 $60.29

Replacement pin for IC206 IC206-1 $9.98

Capping tool IC207 $285.67

Capping pin IC208 $58.04

Slide cap cover For 6-pin cores 100CR-1301$0.46

For 7-pin cores 7100CR-1301$0.46

1Sold only in package quantities of 100 pieces.

For IC cylinders Part No. Price

Exit Devices

January 1, 2015

Architectural Panic Devices

ASSA ABLOY, the global leader

in door opening solutions

Certification BHMA A156.3, Grade 1, available UL Listed

Door Thickness 1-3/4"

Cylinder (where applicable) Standard: 6-pin, solid brass, 2 nickel-silver keys; IC prep available

Handing Right-hand Reverse (RR) or Left-hand Reverse (LR)

Warranty 5 years

Features

Bright brass 03 605 US3

Satin brass 04 606 US4

Satin bronze 10 612 US10

Dark oxidized satin bronze, oil rubbed 10B 613 US10B

Dark oxidized satin bronze, electroplated 10BE 613E US10BE

Bright chromium plated 26 625 US26

Satin chromium plated 26D 626 US26D

Bright stainless steel 32 629 US32

Satin stainless steel 32D 630 US32D

Aluminum painted or powder coated AL 689 –

Available Finishes Arrow Code BHMA Code U.S. Code

Series 38

Function 38-88

Exterior Trim & Finish (optional) 38-88-SL-26D

Door Width138-88-SL-26D-F

Interior Finish (pushbar) 38-88-SL-26D-F-32D

Handing 38-88-SL-26D-F-32D-RR

1F indicates a 36" wide door; E indicates a 24" door; G indicates a 48" door.

How to Order

Exit Devices

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

3880 Series

Rim Panic Device

Exit only 38-81

Classroom function Less SL lever trim 38-88

Less pull trim 38-05 $1,067.00 $1,192.77 $1,243.07

Storeroom function Less trim 38-83

Passage function Less SL lever trim 38-8A

Less pull trim 38-5A

Less Trim Part No. AL 110, 10B, 10BE, 32D 03, 04, 32

Panic Device With Trim

SL2Lever Trim 10, 10B, 10BE, 32D 03, 04, 26, 32

Classroom 38-88-SL $1,635.23 $1,709.71

Storeroom 38-83-SL $1,635.23 $1,709.71

Passage 38-8A-SL $1,594.90 $1,669.38

Dummy Trim 38-82-SL $1,594.90 $1,669.38

SS Pull Trim 10, 10B, 10BE, 32D 03, 04, 26, 32

Classroom 38-05-SS $1,502.81 $1,577.29

Storeroom 38-83-SS $1,502.81 $1,577.29

Passage 38-5A-SS $1,462.47 $1,536.95

Dummy Trim 38-82-SS $1,462.47 $1,536.95

SN2Pull Trim 10, 10B, 10BE, 32D 03, 04, 26, 32

Classroom 38-05-SN $1,464.08 $1,538.56

Storeroom 38-83-SN $1,464.08 $1,538.56

Passage 38-5A-SN $1,423.82 $1,498.30

Dummy Trim 38-82-SN $1,423.82 $1,498.30

SB Pull Trim 10, 10B, 10BE, 32D 03, 04, 26, 32

Classroom 38-05-SB $1,464.08 $1,538.56

Storeroom 38-83-SB $1,464.08 $1,538.56

Passage 38-5A-SB $1,423.82 $1,498.30

Dummy Trim 38-82-SB $1,423.82 $1,498.30

SP Pull Trim 10, 10B, 10BE, 32D 03, 04, 26, 32

Classroom 38-05-SP $1,464.08 $1,538.56

Storeroom 38-83-SP $1,464.08 $1,538.56

Passage 38-5A-SP $1,423.82 $1,498.30

Dummy Trim 38-82-SP $1,423.82 $1,498.30

1AL finish applies to pushrail.

2SL and SN trims are not available in 32D or 32 finish; 26D or 26 supplied.

Trim Only

SL2Lever Trim 10, 10B, 10BE, 26D 03, 04, 26

SL88 $442.46 $466.64

SL83 $442.46 $466.64

SL88A $402.13 $426.31

SL02 $402.13 $426.31

SS Pull Trim 10, 10B, 10BE, 26D, 32D 03, 04, 26, 32

SS05 $310.04 $334.22

SS83 $310.04 $334.22

SS05A $269.70 $293.88

SS02 $269.70 $293.88

SN2Pull Trim 10, 10B, 10BE, 26D 03, 04, 26

SN05 $271.31 $295.49

SN83 $271.31 $295.49

SN05A $231.05 $255.23

SN02 $231.05 $255.23

SB Pull Trim 10, 10B, 10BE, 26D, 32D 03, 04, 26, 32

SB05 $271.31 $295.49

SB83 $271.31 $295.49

SB05A $231.05 $255.23

SB02 $231.05 $255.23

SP Pull Trim 10, 10B, 10BE, 26D, 32D 03, 04, 26, 32

SP05 $271.31 $295.49

SP83 $271.31 $295.49

SP05A $231.05 $255.23

SP02 $231.05 $255.23

Exit Devices

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

3700 Series

Surface Vertical Rod

Panic Device

Panic Device With Trim

SL2Lever Trim 10, 10B, 10BE, 32D 03, 04, 26, 32

Classroom 37-08-SL $2,177.03 $2,266.63

Passage 37-8A-SL $2,136.70 $2,226.30

Dummy Trim 37-02-SL $2,136.70 $2,226.30

SS Pull Trim 10, 10B, 10BE, 32D 03, 04, 26, 32

Classroom 37-05-SS $2,044.61 $2,134.21

Passage 37-5A-SS $2,004.27 $2,093.87

Dummy Trim 37-02-SS $2,004.27 $2,093.87

SN2Pull Trim 10, 10B, 10BE, 32D 03, 04, 26, 32

Classroom 37-05-SN $2,005.88 $2,095.48

Passage 37-5A-SN $1,965.62 $2,055.22

Dummy Trim 37-02-SN $1,965.62 $2,055.22

SB Pull Trim 10, 10B, 10BE, 32D 03, 04, 26, 32

Classroom 37-05-SB $2,005.88 $2,095.48

Passage 37-5A-SB $1,965.62 $2,055.22

Dummy Trim 37-02-SB $1,965.62 $2,055.22

SP Pull Trim 10, 10B, 10BE, 32D 03, 04, 26, 32

Classroom 37-05-SP $2,005.88 $2,095.48

Passage 37-5A-SP $1,965.62 $2,055.22

Dummy Trim 37-02-SP $1,965.62 $2,055.22

Aux. Control 10, 10B, 10BE, 32D 03, 04, 26, 32

Classroom 37-11-S3 $2,067.22 $2,156.82

Storeroom 37-12-S3 $2,067.22 $2,156.82

1AL finish applies to pushrail.

2SL and SN trims are not available in 32D or 32 finish; 26D or 26 supplied.

Trim Only

SL2Lever Trim 10, 10B, 10BE, 26D 03, 04, 26

SL08 $442.46 $466.64

SL08A $402.13 $426.31

SL02 $402.13 $426.31

SS Pull Trim 10, 10B, 10BE, 26D, 32D 03, 04, 26, 32

SS05 $310.04 $334.22

SS05A $269.70 $293.88

SS02 $269.70 $293.88

SN2Pull Trim 10, 10B, 10BE, 26D 03, 04, 26

SN05 $271.31 $295.49

SN05A $231.05 $255.23

SN02 $231.05 $255.23

SB Pull Trim 10, 10B, 10BE, 26D, 32D 03, 04, 26, 32

SB05 $271.31 $295.49

SB05A $231.05 $255.23

SB02 $231.05 $255.23

SP Pull Trim 10, 10B, 10BE, 26D, 32D 03, 04, 26, 32

SP05 $271.31 $295.49

SP05A $231.05 $255.23

SP02 $231.05 $255.23

Aux. Control10, 10B, 10BE, 26D, 32D 03, 04, 26, 32

S311 $332.65 $356.83

S312 $332.65 $356.83

Exit only 37-01

Classroom function Less SL trim 37-08

Less pull trim 37-05 $1,602.10 $1,734.57 $1,799.99

Passage function Less SL trim 37-8A

Less pull trim 37-5A

Less Trim Part No. AL110, 10B, 10BE, 32D 03, 04, 32

Exit Devices

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

3900 Series

Mortise Panic Device

Panic Device With Trim

SL2Lever Trim 10, 10B, 10BE, 32D 03, 04, 26, 32

Classroom 39-08-SL $2,127.62 $2,216.18

Storeroom 39-03-SL $2,127.62 $2,216.18

Passage 39-8A-SL $2,087.29 $2,175.85

Dummy Trim 39-02-SL $2,087.29 $2,175.85

SS Pull Trim 10, 10B, 10BE, 32D 03, 04, 26, 32

Classroom 39-05-SS $1,995.20 $2,083.76

Storeroom 39-03-SS $1,995.20 $2,083.76

Passage 39-5A-SS $1,954.86 $2,043.42

Dummy Trim 39-02-SS $1,954.86 $2,043.42

SN2Pull Trim 10, 10B, 10BE, 32D 03, 04, 26, 32

Classroom 39-05-SN $1,956.47 $2,045.03

Storeroom 39-03-SN $1,956.47 $2,045.03

Passage 39-5A-SN $1,916.21 $2,004.77

Dummy Trim 39-02-SN $1,916.21 $2,004.77

SB Pull Trim 10, 10B, 10BE, 32D 03, 04, 26, 32

Classroom 39-05-SB $1,956.47 $2,045.03

Storeroom 39-03-SB $1,956.47 $2,045.03

Passage 39-5A-SB $1,916.21 $2,004.77

Dummy Trim 39-02-SB $1,916.21 $2,004.77

SP Pull Trim 10, 10B, 10BE, 32D 03, 04, 26, 32

Classroom 39-05-SP $1,956.47 $2,045.03

Storeroom 39-03-SP $1,956.47 $2,045.03

Passage 39-5A-SP $1,916.21 $2,004.77

Dummy Trim 39-02-SP $1,916.21 $2,004.77

1AL finish applies to pushrail.

2SL and SN trims are not available in 32D or 32 finish; 26D or 26 supplied.

Trim Only

SL2Lever Trim 10, 10B, 10BE, 26D 03, 04, 26

SL08 $442.46 $466.64

SL03 $442.46 $466.64

SL08A $402.13 $426.31

SL02 $402.13 $426.31

SS Pull Trim 10, 10B, 10BE, 26D, 32D 03, 04, 26, 32

SS05 $310.04 $334.22

SS03 $310.04 $334.22

SS05A $269.70 $293.88

SS02 $269.70 $293.88

SN2Pull Trim 10, 10B, 10BE, 26D 03, 04, 26

SN05 $271.31 $295.49

SN03 $271.31 $295.49

SN05A $231.05 $255.23

SN02 $231.05 $255.23

SB Pull Trim 10, 10B, 10BE, 26D, 32D 03, 04, 26, 32

SB05 $271.31 $295.49

SB03 $271.31 $295.49

SB05A $231.05 $255.23

SB02 $231.05 $255.23

SP Pull Trim 10, 10B, 10BE, 26D, 32D 03, 04, 26, 32

SP05 $271.31 $295.49

SP03 $271.31 $295.49

SP05A $231.05 $255.23

SP02 $231.05 $255.23

Exit only 39-01

Classroom function Less SL lever trim 39-08

Less pull trim 39-05 $1,509.40 $1,685.16 $1,749.54

Storeroom function Less trim 39-03

Passage function Less SL lever trim 39-8A

Less pull trim 39-5A

Less Trim Part No. AL110, 10B, 10BE, 32D 03, 04, 32

Exit Devices

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

4800 Series

Narrow Stile

Rim Panic Device

Panic Device With Trim

SL1Lever Trim 10, 10B, 10BE, 32D 03, 04, 26, 32

Classroom 48-08-SL $1,792.25 $1,883.23

Storeroom 48-03-SL $1,792.25 $1,883.23

Passage 48-8A-SL $1,751.92 $1,842.90

Dummy Trim 48-02-SL $1,751.92 $1,842.90

SS Pull Trim 10, 10B, 10BE, 32D 03, 04, 26, 32

Storeroom 48-03-SS $1,659.83 $1,750.81

Dummy Trim 48-02-SS $1,619.49 $1,710.47

SN1Pull Trim 10, 10B, 10BE, 32D 03, 04, 26, 32

Storeroom 48-03-SN $1,621.10 $1,712.08

Dummy Trim 48-02-SN $1,580.84 $1,671.82

1SL and SN trims are not available in 32D or 32 finish; 26D or 26 supplied.

• Not available fire-rated.

Trim Only

SL1Lever Trim 10, 10B, 10BE, 26D 03, 04, 26

SL08 $442.46 $466.64

SL03 $442.46 $466.64

SL08A $402.13 $426.31

SL02 $402.13 $426.31

SS Pull Trim 10, 10B, 10BE, 26D, 32D 03, 04, 26, 32

SS03 $310.04 $334.22

SS02 $269.70 $293.88

SN1Pull Trim 10, 10B, 10BE, 26D 03, 04, 26

SN03 $271.31 $295.49

SN02 $231.05 $255.23

Exit only 48-01

Classroom function Less SL lever trim 48-08 $1,349.79 $1,416.59

Storeroom function Less trim 48-03

Passage function Less SL lever trim 48-8A

Less Trim Part No. 10, 10B, 10BE, 32D 03, 04, 32

Exit Devices

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

4900 Series

Narrow Stile

Mortise Panic Device

Panic Device With Trim

SL1Lever Trim 10, 10B, 10BE, 32D 03, 04, 26, 32

Classroom 49-08-SL $1,962.74 $2,043.15

Storeroom 49-03-SL $1,962.74 $2,043.15

Passage 49-8A-SL $1,922.41 $2,002.82

Dummy Trim 49-02-SL $1,922.41 $2,002.82

SS Pull Trim 10, 10B, 10BE, 32D 03, 04, 26, 32

Storeroom 49-03-SS $1,830.32 $1,910.73

Dummy Trim 49-02-SS $1,789.98 $1,870.39

SN1Pull Trim 10, 10B, 10BE, 32D 03, 04, 26, 32

Storeroom 49-03-SN $1,791.59 $1,872.00

Dummy Trim 49-02-SN $1,751.33 $1,831.74

1SL and SN trims are not available in 32D or 32 finish; 26D or 26 supplied.

Trim Only

SL1Lever Trim 10, 10B, 10BE, 26D 03, 04, 26

SL08 $442.46 $466.64

SL03 $442.46 $466.64

SL08A $402.13 $426.31

SL02 $402.13 $426.31

SS Pull Trim 10, 10B, 10BE, 26D, 32D 03, 04, 26, 32

SS03 $310.04 $334.22

SS02 $269.70 $293.88

SN1Pull Trim 10, 10B, 10BE, 26D 03, 04, 26

SN03 $271.31 $295.49

SN02 $231.05 $255.23

Exit only 49-01

Classroom function Less SL lever trim 49-08 $1,520.28 $1,576.51

Storeroom function Less trim 49-03

Passage function Less SL lever trim 49-8A

Less Trim Part No. 10, 10B, 10BE, 32D 03, 04, 32

Exit Devices

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

Architectural Panic Device

Options

For 24” to 32” door widths E No Add

Rail Size For 32-1/4” to 36” door widths F Standard

For 36-1/4” to 48” door widths G No Add

Handing Right-hand reverse RR n/a

Left-hand reverse LR n/a

UL Fire label (except 3700 & 4800 Series) FR $164.43

UL Fire label for 3700 Series1FR $187.96

Cylinder dogging (includes cylinder) (not available with UL fire label devices) CD $79.24

3700 Series less bottom rod LBR2No Add

Fire-rated 3700 Series less bottom rod LBR2$64.05

Sliding bottom bolt for 3700 Series SB3No Add

Vandal-proof lever VP2$283.86

Knurled outside lever 1032$78.34

Architectural Panic Device Options Specify Price

Keyed different KD Standard

Master keyed MK $12.38 per cylinder

Construction master keyed CMK $7.77 per cylinder

Master keyed & construction master keyed MK-CMK $20.15 per cylinder

O-Bitted OB No Add

Less cylinder LC -$13.50

Exit trim prepared to accept 6 or 7-pin SFIC cylinder, less core IC No Add

1Includes through-bolts.

2Used only with SL trim.

3Cannot be combined with FR option.

Keying & Cylinder Options (when ordering trim) Specify Price

Exit Devices

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

Architectural Panic Device

Electrification Options

12V AC/DC 177 $768.33

Fail-safe trim control without key override 2

24V AC/DC 179 $768.33

12V AC/DC 181 $768.33

Fail-secure trim control without key override 2

24V AC/DC 183 $768.33

12V AC/DC 185 $932.04

Fail-safe trim control with key override 3

24V AC/DC 186 $932.04

12V AC/DC 187 $932.04

Fail-secure trim control with key override 3

24V AC/DC 188 $932.04

Latchbolt monitoring LM $259.31

Request to exit - authorized RE $259.31

Electric latch retraction 4E6 4$1,013.07

Signal switch E7 $373.78

Electric dogging E8 $800.68

Architectural Panic Device Electrification Option Voltage Specify Price Add1

Electric latch retraction for up to two doors 1406 $632.61

Interlock 1410 $503.06

1Electrification charges do not include price of panics.

2SL trim only; not available with 3900 or 4900 Series.

3SL trim only; not available with 3700 Series.

4Cannot be combined with options: CD, LM, RE, and E7; not available in rail size E.

• Fail-Safe Trim Control

Power on locks outside lever. Inside lever always free. For options 185, 186, 187, and 188, latch retracted by key when locked electronically.

• Fail-Secure Trim Control

Power off locks outside lever. Inside lever always free. For options 185, 186, 187, and 188, latch retracted by key when locked electronically.

• Latchbolt Monitoring

Full extension of the latch monitored by a SPDT switch.

• Request to Exit — Authorized Egress

Inside trim monitored by an SPDT switch. Switch can be used to shunt a door alarm to allow egress, signal a control console when the trim is

activated, or activate a door alarm.

• Electric Latch Retraction

Provides a remote means of unlocking exit devices by momentary or maintained latch retraction.

• Signal Switch

Consists of two SPDT switches that monitor the touch bar and main latch. This feature also allows for alarm shunt via a mortise cylinder (not

included) located on the tail of the exit device

• Electric Dogging

Simultaneously provides continuous latch retraction and dogging. When energized, first time mechanical activation of the push bar will

continuously hold the latch retracted. When power is removed or interrupted, the latch bolt will extend and the push bar released.

Power Supplies Part No. Price

Exit Devices

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

S1150, S1250, ED900

Series

S1150 Vertical Rod S1250 Rim

Surface vertical rod S1150 $667.33

Rim S1250 $348.85

Standard Panic Devices for 32-1/4” to 36” Door Widths AL, BRZ, LBZ Price

Surface vertical rod FS1150 $845.52

Rim FS1250 $505.82

Fire-Rated Panic Devices for 32-1/4” to 36” Door Widths AL, BRZ, LBZ Price

S1150/S1250 Devices Less Trim

Cylinder dogging CD $79.24

Cylinder dogging prepared to accept 6- or 7-pin SFIC cylinder (not included) CDIC $79.24

For 24” to 32” door widths 24 No Add

For 36-1/4”to 48” door widths 48 No Add

Panic Device Options Add Suffix Add to Panic Price

Passage SRX01 $105.03

Storeroom Standard cylinder SRX82 $105.03

SFIC prep, less core SRX82-IC $105.03

Classroom Standard cylinder SRX87 $105.03

SFIC prep, less core SRX87-IC $105.03

Lever Trim 10B, 26D Price

Trims

Passage BD01 or TA01 $135.82

Storeroom Standard cylinder BD12 or TA12 $149.49

SFIC prep, less core TA12-IC $149.49

Classroom Standard cylinder BD17 or TA17 $149.49

SFIC prep, less core TA17-IC $149.49

Knob Trim 03, 04, 10, 10B, 26D Price

Blank Plate SF01 $59.55

Dummy Pull SF02 $65.70

Storeroom Standard cylinder SF12 $107.13

SFIC prep, less core SF12-IC $107.13

Plate Trim AL, BRZ, LBZ Price

Rim device for 31" to 36" door widths ED910-36 $227.00 $309.00

Rim device for 43" to 48" door widths ED910-48 $227.00 $309.00

Strike ES90 $22.36 –

Screw pack ES9-201 $11.94 –

End cap ES9CAP $20.14 $20.14

Description Part No. AL, BRZ 32D

ED900 Panic Device

Exit Devices

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

500 & 600 Series

Rim Device 530 540 $217.05

Rim Device x Through-Bolts3530T 540T $239.78

Fire-Rated Rim Device 530-FR 540-FR $301.54

Fire-Rated Rim Device x Through-Bolts3530T-FR 540T-FR $324.27

500 Series Rim Devices For 36" Doors1For 48" Doors2Price

SVR Device x 90" 630 640 $529.90

SVR Device x 90" x Through-Bolts3630T 640T $609.37

SVR Device x 96" 638 648 $529.90

SVR Device x 96" x Through-Bolts3638T 648T $609.37

Fire-Rated SVR Device x 90" 630-FR 640-FR $614.48

Fire-Rated SVR Device x 90" x Through-Bolts3630T-FR 640T-FR $705.28

Fire-Rated SVR Device x 96" 638-FR 648-FR $614.48

Fire-Rated SVR Device x 96" x Through-Bolts3638T-FR 648T-FR $705.28

1Can be field cut for a minimum 30" wide door

2Can be field cut for a minimum 37" wide door

3Through-bolts for 1-3/4" doors

600 Series Surface Vertical Rod Devices For 36" Doors1For 48" Doors2Price

Panic Devices Less Trim – Specify AL or BRZ finish

500 Series strike (panic & fire-rated) S24 $42.19

500 Series through-bolts for 1-3/4" doors (panic & fire-rated) 500TB $22.36

500 Series Part No. Price

600 Series top strike (panic) S22 $46.47

600 Series bottom strike (panic) S23 $46.47

600 Series top strike (fire-rated) S646 $82.82

600 Series bottom strike (fire-rated) S46 $46.47

600 Series through-bolts for 1-3/4" doors (panic) 600TB $78.06

600 Series through-bolts for 1-3/4" doors (fire-rated) 600TBF $89.27

600 Series Part No. Price

Parts & Accessories

500 Rim

600 Vertical Rod

DISCONTINUED. LIMITED AVAILABILITY THROUGH DISTRIBUTION ONLY.

CONTACT CUSTOMER SERVICE FOR ADDITIONAL INFORMATION.

Exit Devices

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

Panic Device

Accessories

Shim kit for 3880 or 3900 Series S59 $84.71

Shim kit for 3700 Series S57 $101.69

Shim kit for S1150 SH64 $117.54

Shim kit for S1250 SH65 $95.90

18” Extension rod kit for 3700 or S1150 Series VRX-18 $95.54

Dummy push rail for 3000 & 4000 Series For 24” to 32” door widths S3000-24 $366.28

(specify plated finish) For 32-1/4” to 36” door widths S3000-36 $366.28

For 36-1/4” to 48” door widths S3000-48 $366.28

Dummy push rail for 3000 & 4000 Series For 24” to 32” door widths S3000-24 $292.43

(specify sprayed finish) For 32-1/4” to 36” door widths S3000-36 $292.43

For 36-1/4” to 48” door widths S3000-48 $292.43

Accessories Part No. Price

3880 Standard S54 $18.58

UL fire-rated FS54 $18.58

3700 Standard S53 $54.01

UL fire-rated FS53 $61.67

3900 Standard S54 $18.58

UL fire-rated FS54 $18.58

4800 Standard S65 $18.58

4900 Standard S65 $18.58

UL fire-rated FS65 $18.58

S1150 Standard S51 $54.01

UL fire-rated FS51 $61.67

S1250 Standard S52 $18.58

UL fire-rated FS52 $18.58

Series Description Part No. Price

Thru-Bolts

Exit Devices

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

Panic Device

Mullions

Removable mullion - 96” S20 $427.34

Removable mullion - 120” S20-120 $496.79

Key removable mullion - 96”, less cylinder S20-K $939.74

Key removable mullion - 120”, less cylinder S20L-K $984.46

Removable mullion for narrow stile - 96” S20-N $917.99

Removable mullion for narrow stile - 120” S20-N-120 $1,067.35

Fire-rated removable mullion - 96” S21 $572.87

Fire-rated key removable mullion - 96”, less cylinder S21-K $1,070.95

Top Retainer for S20 S10 $47.80

Bottom retainer for S20 S11A $47.80

Top retainer for S20-N S91 $81.68

Bottom retainer for S20-N S92 $81.68

Stabilizer for S20-N S90 $47.80

Top retainer for S21 S88 $81.68

Bottom retainer for S21 S89 $81.68

Mortise cylinder for key removable mullion MC61-004 $38.95

IC housing for key removable mullion 16CR-27X004 $37.47

Mullions Part No. Price

Exit Devices

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

Panic Device

Parts

SL08 spindle adapter (converts trim to SL88) SL-386A $29.29

SL08 spindle adapter (required when using trim with 4800 Series) SLS-386A $40.15

SL trim cover plate (covers stock hollow metal cut-out) 38-88A $146.24

Storeroom function SL93 $345.01

Classroom function for thumb pull trim SL95 $345.01

Mortise lockbody for 3900 or 4900 Series Passage function for thumb pull trim SL95A $345.01

Classroom function for SL trim SL98 $345.01

Passage function for SL trim SL98A $345.01

End cap for 3000 & 4000 Series 32-7027 $20.14

End cap mounting bracket for 3000 & 4000 Series 68-2141 $20.14

End cap for S1150 & S1250 Series 28-0112 $20.14

End cap mounting bracket for S1150 & S1250 Series 68-0080 $20.14

Dogging kit 68-2596 $20.14

Dogging key 97-0001 $9.34

Parts Part No. Price

Plated finish rail assembly For 24” to 32” door widths RCD-24 $458.63

for 3000 Series For 32-1/4” to 36” door widths RCD-36 $458.63

with cylinder dogging For 36-1/4” to 48” door widths RCD-48 $458.63

Sprayed finish rail assembly For 24” to 32” door widths RCD-24 $383.21

for 3000 Series For 32-1/4” to 36” door widths RCD-36 $383.21

with cylinder dogging For 36-1/4” to 48” door widths RCD-48 $383.21

Sprayed finish rail assembly For 24” to 32” door widths PR-24CD $327.82

for S1150 & S1250 Series For 32-1/4” to 36” door widths PR-36CD $327.82

with cylinder dogging For 36-1/4” to 48” door widths PR-48CD $327.82

Rail Assembly with Cylinder Dogging Part No. Price

For 24” to 32” door widths R-24 RF-24 $381.70

Plated finish rail assembly for 3000 Series For 32-1/4” to 36” door widths R-36 RF-36 $381.70

For 36-1/4” to 48” door widths R-48 RF-48 $381.70

For 24” to 32” door widths R-24 RF-24 $306.29

Sprayed finish rail assembly for 3000 Series For 32-1/4” to 36” door widths R-36 RF-36 $306.29

For 36-1/4” to 48” door widths R-48 RF-48 $306.29

For 24” to 32” door widths PR-24 PRF-24 $250.96

Sprayed finish rail assembly For 32-1/4” to 36” door widths PR-36 PRF-36 $250.96

for S1150 & S1250 Series For 36-1/4” to 48” door widths PR-48 PRF-48 $250.96

Standard Rail Assembly Standard Fire-Rated Price

100

Exit Devices

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

Panic Device

Strikes

3880 Standard & fire rated S24 $42.19

Double door S36 $42.19

Standard top S22 $46.47

Standard bottom S23 $46.47

3700 UL fire-rated top S646 $82.82

UL fire-rated bottom S46 $46.47

Sliding bottom bolt S43 $46.47

3900 Standard 48C $27.61

Open back S47 $42.19

Standard S55 $42.19

4800 Double door S36 $42.19

Flush S56 $42.19

4900 Standard 48C $27.61

Open back S47 $42.19

Standard top S22 $46.47

Standard bottom S23 $46.47

S1150 UL fire-rated top S646 $82.82

UL fire-rated bottom S46 $46.47

Sliding bottom bolt S43 $46.47

S1250 Standard & fire rated S24 $42.19

Double door S36 $42.19

Series Description Part No. Price

Strikes

Drawing not to scale.

Same hole pattern

for a fraction of the price.

ARROW DC516

• BHMA Certified Grade 1

• 10-Year Warranty

• Professional Replacement Product

• Retrofits Existing Popular Cast Iron Closer

ASSA ABLOY, the global leader

in door opening solutions

101

102

Door Closers

January 1, 2015

7700 Series

Powered Door Operator

ASSA ABLOY, the global leader

in door opening solutions

Standard unit 7710 $1,538.00

Standard unit with touchless wall switch 7710K1 $1,730.00

Standard unit with power cord 7710P $1,556.00

Standard unit with power cord & touchless wall switch 7710PK1 $1,748.00

RF unit 7710RF1 $1,683.00

RF unit with transmitter 7710EX $1,761.00

RF unit with power cord 7710PRF1 $1,701.00

RF unit with power cord & transmitter 7710PEX $1,779.00

Hinge (Pull) Side of Door Part No. AL, DBZ

Powered Door Operator

Standard unit 7730 $1,479.00

Standard unit with touchless wall switch 7730K1 $1,663.00

Standard unit with power cord 7730P $1,497.00

Standard unit with power cord & touchless wall switch 7730PK1 $1,681.00

RF unit 7730RF1 $1,683.00

RF unit with transmitter 7730EX $1,761.00

RF unit with power cord 7730PRF1 $1,701.00

RF unit with power cord & transmitter 7730PEX $1,779.00

Stop (Push) Side of Door Part No. AL, DBZ

Door Switch - 6" x 6", Radio Frequency, ADA Symbol 7800SW2 $224.00

SPDT Door Switch - 6" x 6", Hard Wired 7800SW4 $137.00

Door Switch - 6" x 6", Radio Frequency 7800SW1 $224.00

SPDT Door Switch - 6" x 6", Hard Wired, ADA Symbol 7800SW3 $137.00

Touchless Wall Switch 7710SW5 $425.00

Radio Frequency (RF1) Kit 7710RK $115.00

Power Cord 7710PC $18.00

Inverter 7710IN $522.00

Cover 7710COV $82.00

Arm and Track Assembly 7710-1 $72.00

Double Lever Arm 7730-1 $72.00

Power Supply 7710PS $88.00

Motor Assembly 7800MA $834.00

Parts & Accessories Part No. Price

103

Door Closers

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

7800/7900 Series

Powered Door Operator

7814H $2,755.00

1-4 ✓7814HR $2,866.00

Hinge/Pull ✓✓7814HRP $3,500.00

7836H $2,755.00

3-6 ✓7836HR $2,866.00

✓✓7836HRP $3,500.00

7814S $2,755.00

1-4 ✓7814SR $2,866.00

Stop/Push ✓✓7814SRP $3,500.00

7836S $2,755.00

3-6 ✓7836SR $2,866.00

✓✓7836SRP $3,500.00

1-4 7814U $2,786.00

Universal ✓7814UR $2,896.00

3-6 7836U $2,786.00

✓7836UR $2,896.00

Mount Application Closer Size Radio Frequency 2 Wall Switches Part No. Price

7800 Series Powered Door Operator AL, DBZ

7914H $2,773.00

1-4 ✓7914HR $2,884.00

Hinge/Pull ✓✓7914HRP $3,518.00

7936H $2,773.00

3-6 ✓7936HR $2,884.00

✓✓7936HRP $3,518.00

7914S $2,773.00

1-4 ✓7914SR $2,884.00

Stop/Push ✓✓7914SRP $3,518.00

7936S $2,773.00

3-6 ✓7936SR $2,884.00

✓✓7936SRP $3,518.00

1-4 7914U $2,804.00

Universal ✓7914UR $2,914.00

3-6 7936U $2,804.00

✓7936UR $2,914.00

Mount Application Closer Size Radio Frequency 2 Wall Switches Part No. Price

7900 Series Powered Door Operator (Power Cord Version) AL, DBZ

104

Door Closers

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

7800/7900 Series

Parts

Chain 7800CH $17.00

Motor Assembly 7800MA $834.00

Inverter 7800IN $522.00

On/Off Switch 7800PS $4.80

Pillow Block 7800PB $66.00

Pinion Extension Clutch Assembly 7800CA $214.00

Door Position Adjustment Assembly 7800AA $78.00

Cover 7800CO $82.00

Arm & Track Assembly 7800TC $240.00

Arm Assembly 7800TA $80.00

Track Assembly 7800TO $164.00

Standard Arm Assembly 7800SC $80.00

Main Arm & Rod 7800SA $66.00

Adjusting Tube & Shoe 7800ST $28.00

Single Channel Hand Held Transmitter 7800T1 $98.00

Two Channel Hand Held Transmitter 7800T2 $124.00

Reed Switch 7800RS $17.00

RF Power Supply 7800PWS $88.00

Operational Signs 7800SK9 $35.00

Signage Kit 1 7800SK1 $6.00

Signage Kit 2 7800SK2 $6.00

Parts/Accessories Part No. Price

105

Door Closers

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

DC300 Series

Size 1-4, std NHO arm, PA bracket DC314 $143.46

Size 1-4, std HO arm, PA bracket DC314-1 $168.79

Size 2-5, std NHO arm, PA bracket DC325 $143.46

Size 2-5, std HO arm, PA bracket DC325-1 $168.79

DC300 Surface Applied Door Closers Part No. Price

Full plastic cover, screw pack, 1-3/8" through-bolts DC3CVR $23.01

Drop plate – parallel arm DC300DP1 $16.39

Through-bolts 2-1/4" DC300TB2 $5.79

• Packed 6 per case.

• Specify AL or DBZ finish.

Parts & Accessories Part No. Price

106

Door Closers

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

DC500 Series

Full Plastic Cover DC500CV $21.71

Drop Plate - Regular DC500DP $21.07

Drop Plate - Parallel Arm DC500DP1 $23.24

Drop Plate - Top Jamb, Flush Ceiling DC500DP3 $21.07

Drop Plate - Top Jamb DC500DP2 $21.07

Thru-bolts 1-3/4" DC500TB1 $5.86

Thru-bolts 1-3/8" DC500TB3 $5.86

Thru-bolts 2-1/4" DC500TB2 $5.86

Supplemental Reaming/Tapping Screw Pack DC500SP1 $9.36

Standard Screw Pack DC500SP2 $9.36

Standard Non-Hold Open Arm DC500A $76.02

Standard Hold Open Arm DC500A1 $87.27

Heavy-Duty Dead Stop Arm Non-Hold Open DC500A2 $91.44

Heavy-Duty Dead Stop Arm Hold Open DC500A3 $102.00

Heavy-Duty Cushion Arm Non-Hold Open DC500A4 $118.45

Heavy-Duty Cushion Arm Hold Open DC500A5 $133.90

• Specify AL or DBZ finish.

Parts & Accessories Part No. Price

Standard arm, non-hold open, with PA bracket DC516 $225.73

Standard arm, hold open, with PA bracket DC516-1 $274.41

Heavy-duty dead stop arm, non-hold open DC516-2 $271.87

Heavy-duty dead stop arm, hold open DC516-3 $300.04

Description Part No. Price

Certification ANSI A156.4 and ANSI ICC A117.1 Grade 1

Size 1 to 6

Cover Included: full plastic

Thru-Bolts Included: 1-3/4"

Case Quantity 4

Average Case Weight 22.5 lbs.

Warranty 10 years

Features

107

900N Series

Standard arm, sizes 1-4 914N $245.50

Standard arm, sizes 3-6 936N $245.50

Hold-open arm, sizes 1-4 914NH $279.74

Hold-open arm, sizes 3-6 936NH $279.74

Tri-Pack Configurations Part No. Price

Drop plate 936DP $40.52

914N Closer body 914BO $171.11

936N Closer body 936BO $171.11

Through-bolts for 1-3/8” thick door 5016TB38 $10.02

Through-bolts for 1-3/4” thick door 5016TB34 $10.02

Complete (tri-pack) standard arm assembly 5016CNA $74.04

Complete (tri-pack) hold-open arm assembly 5016CHA $107.84

• Packed 6 per case. Average case weight 21 lbs.

• Specify AL, DBZ, LBZ, GL, or BLK finish.

Parts & Accessories Part No. Price

Door Closers

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

108

Door Closers

January 1, 2015

5016N Series

ASSA ABLOY, the global leader

in door opening solutions

Standard arm, slim plastic cover 5016NS $320.18

Standard arm, full plastic cover 5016N $326.30

Standard arm, slim plastic cover, delayed action 5016NSD $353.99

Standard arm, full plastic cover, delayed action 5016ND $360.07

Hold-open arm, slim plastic cover 5016NSH $353.99

Hold-open arm, full plastic cover 5016NH $360.07

Hold-open arm, slim plastic cover, delayed action 5016NSHD $387.84

Hold-open arm, full plastic cover, delayed action 5016NHD $393.98

Tri-pack Models – Sizes 1-6 Part No. Price

Slim plastic cover 5016NPS $359.77

Full plastic cover 5016NP $369.34

Slim plastic cover, delayed action 5016NPSD $393.24

Full plastic cover, delayed action 5016NPD $399.45

Hold-open arm, slim plastic cover 5016NPSH $402.44

Hold-open arm, full plastic cover 5016NPH $408.60

Hold-open arm, slim plastic cover, delayed action 5016NPSHD $435.98

Hold-open arm, full plastic cover, delayed action 5016NPHD $442.08

Door Saver Parallel Arm Models – Sizes 1-6 Part No. Price

Drop plate 5016DP $43.26

Full plastic cover 5016FC $21.70

Slim plastic cover 5016SC $15.49

5016N Closer body 5016BO $231.00

5016N Closer body with delayed action 5016BOD $264.80

Through-bolts for 1-3/8” thick doors 5016TB38 $10.02

Through-bolts for 1-3/4” thick doors 5016TB34 $10.02

Complete (tri-pack) standard arm assembly 5016CNA $74.04

Complete (tri-pack) hold-open arm assembly 5016CHA $107.84

Door saver arm assembly, non-hold-open 5016CDNA $117.13

Door saver arm assembly, hold-open 5016CDHA $160.21

• Packed 4 per case. Average case weight 16 lbs.

• Specify AL, DBZ, LBZ, GL, or BLK finish.

Parts & Accessories Part No. Price

109

Alarmed Hardware

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

130N 300 400

Alarmed

Hardware

Stand alone 130N $328.87 --

Stand alone with remote mounting 130NXL $379.46 --

Paddle type 330 - $724.96 $806.41

Push bar type 4302- $850.50 $1,029.66

Fire-rated push bar type F4302- $988.85 $1,168.08

Alarmed Hardware Part. No. TAN AL, BRZ, RD 10, 10B, 26, 26D

Remote monitor1(wiring for remote monitor and power) RM $73.68

Remote power1RP $57.65

Continuous alarm1CA $57.65

Automatic rearming AR $57.65

1RM, RP, & CA options not available with 130N Series.

2Specify LR or RR handing.

• All units designed to accept outside cylinder operation. Supplied less cylinder.

• All units include low battery alert feature.

• 300 Series packed 8 per case.

• 130N packed 20 per case.

• 400 Series packed 1 per case.

Alarm Options Specify Price Add

110

Alarmed Hardware

Trim & Accessories

January 1, 2015

ASSA ABLOY, the global leader

in door opening solutions

Accessories

Trims

Passage SRX01 $105.03

Storeroom Standard cylinder SRX82 $105.03

SFIC prep, less core SRX82-IC $105.03

Classroom Standard cylinder SRX87 $105.03

SFIC prep, less core SRX87-IC $105.03

Lever Trim 10B, 26D Price

Passage BD01 or TA01 $135.82

Storeroom Standard cylinder BD12 or TA12 $149.49

SFIC prep, less core TA12-IC $149.49

Classroom Standard cylinder BD17 or TA17 $149.49

SFIC prep, less core TA17-IC $149.49

Knob Trim 03, 04, 10, 10B, 26D Price

Blank Plate SF01 $59.55

Dummy Pull SF02 $65.70

Storeroom Standard cylinder SF03 $112.00

SFIC prep, less core SF03-IC $112.00

Plate Trim AL, BRZ, LBZ Price

For 300, 400, & F400 Series S24 $42.19

Optional double door strike S36 $42.19

Strikes Part No. Price

For 300 & 400 Series S30 $18.58

For F400 Series S32 $18.58

Thru-Bolts Part No. Price

Surface magnet pack S80 $29.61

Surface actuator switch for remote installation S85 $53.41

Concealed actuator switch for remote installation S86 $53.41

Magnet Actuator Switches Part No. Price

For 300 Series S74 $115.54

For 400 Series S75 $131.82

Narrow Stile Mounting Plates Part No. Price

4” x 5-1/2” english/spanish sign 32-1088 $9.77

5” x 9” english/french sign 32-1089 $9.77

Adhesive label for 300 Series 32-1143 $9.77

Adhesive label for 400 & F400 Series 32-1144 $9.77

Warning Signs & Labels Part No. Price

111

Alarmed Hardware

January 1, 2015

Alarmed Hardware

Parts

ASSA ABLOY, the global leader

in door opening solutions

Roller/micro switch (red & yellow wires) 32-7044 $83.27

On/off switch 32-7062 $50.33

AR On/off switch 32-7097 $50.33

Circuit board (specify x20 or x30) 32-7070 $273.04

Electronics & painted cover for x20 32-7033 $462.81

Electronics & painted cover for x30 32-7035 $462.81

Electronics & plated cover for x20 32-7034 $547.48

Electronics & plated cover for x30 32-7036 $547.48

Battery snap assembly 32-7043 $9.52

Paddle & chassis for 300 Series 32-7065 $214.97

Active chassis for 400 Series 32-7171 $114.55

End cap mounting bracket for 400 Series 68-2141 $20.53

KL switch (green & white wires) 32-7059 $19.79

KL kit 32-7179 $31.53

End cap for 400 Series 32-7027 $20.14

End cap for F400 Series 32-7080 $20.14

Dogging key 97-0001 $9.34

Paddle for 300 Series 32-1224 $89.49

Paddle bracket for 300 Series 32-7028 $27.35

300 & 400 Series Part No. Price

112

January 1, 2015

Notes:

ASSA ABLOY, the global leader

in door opening solutions

For more information regarding

Arrow locksets, exit devices,

door closers and key systems,

contact your authorized

Arrow distributor.

ARRW LT-503117

ARROW USA

Phone: 800-839-3157

Fax: 800-421-6615

ARROW CANADA

Phone: 1-888-633-3264

Fax: 1-888-263-3326

Visit us at our Website:

www.arrowlock.com

ASSA ABLOY is the

global leader in door

opening solutions

dedicated to satisfying

end-user needs for

security, safety and

convenience.

Arrow Pricebook 2015 Price Book January2015

Navigation menu

Versions of this User Manual:

Views

Navigation
