Artin Co 646100SP-VT Camera for RC Car User Manual 646100SP 316500799E

Artin Industrial Co Ltd Camera for RC Car 646100SP 316500799E

User Manual

CONTROL TIPS
OPERATING THE PLAYSET
OPERATING THE VEHICLE
Turn the Car switch to “ON”. (Located on
the bottom of vehicle)
Turn the Camera switch to “ON”. (Located
on the bottom of vehicle)
Start operating by pressing the buttons
on the controller.
ON OFF
ON OFF
GETTING STARTED
INSTALL THE BATTERIES
CONTROLLER
Removal of the battery cover requires a “Phillips head” screwdriver.
After removing the screw, remove the battery cover.
Make sure the “AA” batteries are new (Do not mix old or used batteries
with new batteries).
Place the batteries in the battery compartment being sure that the (+)
and (-) poles of the batteries are positioned correctly.
Replace the cover.
BATTERY
Car is powered by 4 x 1.5V “AA” size batteries.
Camera is powered by 2 x 1.5V “AAA” size batteries.
Controller is powered by 4 x 1.5V “AA” size batteries.
CAMERA
Removal of the battery cover requires a “Phillips head” screwdriver.
After removing the screw, remove the battery cover.
Make sure the “AAA” batteries are new (Do not mix old or used batteries with new batteries).
Place the batteries in the battery compartment being sure that the (+) and (-) poles of the batteries are positioned correctly.
Replace the cover.
CAR
Removal of the battery cover requires a “Phillips head” screwdriver.
After removing the screw, remove the battery cover.
Make sure the “AA” batteries are new (Do not mix old or used batteries with new batteries).
Place the batteries in the battery compartment being sure that the (+) and (-) poles of the batteries are positioned correctly.
Replace the cover.
CAMERA
Insert the camera into the car in the direction shown
1.
2.
3.
INSTALLATION
4
6
1. TILTING ANGLE CAMERA CONTROL
5. LEFT / RIGHT CONTROL
3. POWER / LCD DISPLAY SWITCH
4. SUN SHIELD COVER
2. FORWARD / REVERSE CONTROL
6. REAL TIME COLOR LCD DISPLAY
7. SWITCH TOTAL ON
RADIO CONTROLLER
WITH COLOR LCD DISPLAY
7
5
2
1
3
45º
TOTAL OFF
PHILLIPS
HEAD
MCS 316500799
