Arts Digital Technology SMK480 MIC GUY Sing-along with Bluetooth Music User Manual SMK480 CE971 IM English 161125
Arts Digital Technology (HK) Limited MIC GUY Sing-along with Bluetooth Music SMK480 CE971 IM English 161125
User Manual
SMK480
MIC GUY Sing-along with
Bluetooth Music
INSTRUCTION MANUAL
Thank you for purchasing this Singalong. Please read this instruction manual carefully before using
this product to ensure proper use. Keep this manual in a safe place for future reference.
EN - 1
WARNINGS
C A UTION:TO P R EVEN T T H E RI SK O F
ELECTRIC SHOCK, DO NOT REMO V E
COVER OR BACK. NO USER-SERVICEABLE
PARTS INSIDE. REFER SERVICING TO
QUALIFIED PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING: TO REDUCE THE RISK OF
FIRE OR SHOCK HAZARD, DO NOT EXPOSE
THIS PRODUCT TO RAIN OR MOISTURE.
This symbol is intended to alert you to
the presence of uninsulated dangerous
voltage within the product’s enclosure
that might be of sufficient magnitude to
constitute a risk of electric shock. Do
not open the product’s case.
This symbol is intended to inform you
t h at important operating and
maintenance instructions are included
in the literature accompanying this
product.
DRIPPING WARNING
The product shall not be exposed to dripping or
splashing and that no objects filled with liquids,
such as vases, shall be placed on the product.
VENTILATION WARNING
The normal ventilation of the product shall not be
impeded for intended use.
Class ll equipment symbol
This symbol indicates that the power
adaptor has a double insulation system.
IC Warning
RSS-Gen Issue 4 November 2014"&"CNR-Gen 4e
éditionNovember 2014:
- English:
This device complies with Industry Canada licence-
exempt RSS standard(s).
Operation is subject to the following two conditions:
(1) This device may not cause interference, and (2)
This device must accept any interference, including
interference that may cause undesired operation of
the device.
- French:
Le présentappareilestconforme aux CNR d'Industrie
Canada applicables aux appareils radio exempts de
licence. L'exploitationestautorisée aux deux
conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareildoit accepter tout
brouillageradioélectriquesubi, mêmesi le brouillageest
susceptible d'encompromettre le fonctionnement.
FCC WARNING
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television (which can be
determined by turning the equipment off), the user is encouraged to try to correct the interference by one or
more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced / TV technician for help.
1. Read these Instructions.
2. Keep these Instructions.
3. Heed all Warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any of the ventilation openings. Install in accordance with the manufacturers instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding - type plug. A polarized plug has two
blades with one wider than the other. A grounding type plug has two blades and a third grounding prong.
The wide blade or the third prong are provided for your safety. When the provided plug does not fit
into your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with a cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid
injury from tip-over.
Portable Cart Warning
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been exposed to rain or moisture , does not operate normally,
or has been dropped.
EN - 2
The device has been evaluated to meet general RF exposure requirement. The device can be used in
portable exposure condition without restriction.
Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your
authority to operate this equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.
Avertissement: pour réduire le risque d’incendie ou de choc électrique, ne pas exposer cet appareil
sous la pluie et l’humidité.
The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such
as vases, shall be placed on apparatus.
L’appareil ne doit pas être exposé aux écoulements ou aux éclaboussures et aucun objet ne contenant
de liquide, tel qu’un vase, ne doit être placé sur l’objet.
The MAINS plug / power adaptor is used as the disconnect device, it should remain readily operable
during intended use.
In order to disconnect the apparatus from the mains completely, the main plug / power adaptor should
be disconnected from the mains socket outlet completely.
La prise du secteur ne doit pas être obstruée ou doit être facilement accessible pendant son utilisation.
Pour être complètement déconnecté de l’alimentation d’entrée, la prise doit être débranchée du secteur.
WARNINGS:
Battery shall not be exposed to excessive heat such as sunshine, fire or the like.
Les piles ne doivent pas être exposées à de forte chaleur, tel qu’à la lumière du soleil, au feu ou
autres choses de semblable.
IMPORTANT SAFETY INSTRUCTIONS
EN - 3
Caution Marking and rating plate was located at bottom enclosure of the apparatus.
Les marquages sont inscrits en bas de l'appareil.
Les précautions d'emploi sont inscrites en bas de l'appareil.
Class II equipment
AC voltage
DC voltage
RECYCLING
This product bears the selective
sorting symbol for Waste electrical
and electronic equipment (WEEE).
This means that this product must
be handled pursuant to European
directive 2012/19/EU in order to
be recycled or dismantled to
minimize its impact on the
environment.
User has the choice to give his
product to a competent recycling
organization or to the retailer when
he buys a new electrical or
electronic equipment.
Hazard live parts
Symbols Explantation
Non-rechargeable batteries are not to be recharged,
Rechargeable batteries are to be removed from the
toy before being charged,
Rechargeable batteries are only to be charged under
adult supervision,
Different types of batteries or new and used batteries
are not to be mixed,
Batteries are to be inserted with the correct polarity,
Exhausted batteries are to be removed from the toy.
The supply terminals are not to be short-circuited,
Not connected more than recommended number of
power supplied
Warning ! Not suitable for children under 36 months
The toy is not intended for children under 3 years old
The model number or specification of a suitable
transformer for use with the toy
The transformer is not a toy,
Toys liable to be cleaned with liquid are to be disconnected from the transformer before cleaning.
Transformers (Input 100 - 240V ~ 50/60 Hz 0.5A, Output DC 5V / 0.6A) used with the toy are to be
regularly examined for damage to the cord, plug, enclosure and other parts, and that, in the event of
such damage, the toys must not be used with this transformer until the damage has been repaired.
The toy must only be used with the transformer for
toys
EN - 4
Contents
SMK480 Main Unit with Microphone1.
AC Power Adaptor
2.
Instruction Manual4.
Warranty Card
5.
Line-in Cable3.
WHAT’S IN THE BOX
EN - 5
CONTROL LOCATIONS
Play/ Pair
with LED indicator
Record
with LED indicator
Volume +
Volume -
Handle
Power on/off
with LED indicator
Song 1
Song 2
Effect 3
Mic 1 Jack
Mic 2 Jack
Line In Jack
Effect 2
Effect 1
Song 3
Microphone
Microphone
on/off switch
Speaker
Battery
Compartment
DC Jack
EN - 6
POWER CONNECTION
Connecting AC Power
Plug the Power Adaptor into the AC jack that
located on the rear of the product and plug
the other end into a standard AC socket.
CAUTION: The AC Adaptor has a polarized plug that fits into the wall outlet only one way.
If the plug does not fit properly, turn it over and try again. Do not force it.
NOTE: When the unit is intended for being unused for a long period of the time. Please turn off the unit and unplug
the power adaptor from the AC wall outlet.
Battery Operation
Before installing batteries (not included), ensure
that the unit is disconnected from the mains
supply.
Remove the battery compartment cover on the
bottom of the unit by a screw driver. The battery
cover can then be lifted away.
Fit 3 x 1.5V AA-size batteries (not included),
referring to the polarity markings inside the
battery compartment. Never mix old and new
batteries. Finally, replace the cover.
For battery operation, switch off the mains
supply and remove the AC power adaptor from the power
socket, battery operation will be selected
automatically.
Caution:
There is a danger of explosion if batteries are replaced incorrectly.
Replace batteries with the same type and same brand only.
If the unit will not be used for a long period of time, turn OFF the unit and remove all batteries from
the main unit.
EN - 7
First time pairing
1. Press the power button to turn on the unit.
2. The unit will search the paired device with the Bluetooth indicator flashing quickly.
3. Turn on Bluetooth function of your device and enable the search or scan function to find the main unit.
(See your device's instructions to add or setup a Bluetooth device).
4. Select "SMK480" from the device list when it appears on your device screen.
5. After successfully paired with a device, the Bluetooth indicator will stay lit in blue and you will hear “paired” which
confirms the pairing had been done.
To pair with another Bluetooth device
1. Press and hold the PAIR button for 2 seconds to unpair your Bluetooth device.
2. Repeat above step 2 to 5 to pair another Bluetooth device.
Playing from a paired Bluetooth device
You can play music from your Bluetooth device wirelessly to the main unit by following the steps below after
successfully paired.
1. To play your favorite song, press the PLAY button on your Bluetooth device to start playback.
2. Press the VOLUME +/- buttons on the main unit until you obtain a comfortable listening level.
3. Press the SKIP buttons of the Bluetooth device to skip to previous or next song.
Note:
1. Remember to turn off the main unit after you have finished listening.
2. Please do not forget to switch off the power of your external audio device as well if you do not use it
for other purpose.
NOTE:
Before pairing, make sure the LINE IN cable is not plugged into the LINE IN jack.
BLUETOOTH PAIRING AND CONNECTION
Establish a safe sound level
Over time your hearing will adapt to continuous loud sound and will give the impression that the volume
has in fact been reduced. What seems normal to you may in fact be harmful. To guard against this before
your hearing adapts, set the volume to a low level.
Slowly increase the level until you can hear comfortably and clearly and without distortion. Damage to your
hearing is accumulative and is irreversible. Any ringing or discomfort in the ears indicates that the volume
is too loud. Once you have established a comfortable listening level, do not increase the sound level.
Adjusting the Volume
Press the VOLUME buttons to increase / decrease the volume.
EN - 8
SING WITH YOUR MICROPHONE
1. The Mic Guy itself is actually a microphone. Plug the microphone jack into the mic jack at the back of
the unit.
2. The Microphone switch is located on the unit. To turn the microphone ON, pick up the microphone
from its platform, which will automatically switch ON. You can sing with your microphone now. Once you
finish put the microphone back to its platform. It will switch OFF automatically.
3. There is another mic jack for extra microphone (not included). Once you plug in the extra microphone,
please also pick up the Mic Guy microphone in order to switch ON the microphones. The extra
microphone should have ON/OFF switch by itself. Please also turn it ON before singing.
Microphone
(Mic Guy)
Microphone
on/off switch
Toggle
switch
to ON
1 3
3
2
Extra
Microphone
not included
1. Press Power button to turn on the machine. Red LED indicator will turn on. There are 3 built-in songs and 3
sound effects inside the singalong player.
2. Press song 1, 2 and 3 buttons to play three different songs. Press the button again to stop.
3. Press effect 1, 2 and 3 buttons to play three different sound effects.
4. Adjust the volume by pressing Vol + or Vol –
5. You can plug the microphone in and sing with built-in songs.
BUILT-IN SONGS AND SOUND EFFECT
LINE-IN FUNCTION
1. While you are singing, press record button, the record LED flashes. Your voice with music will be
recorded. Press record button again to stop recording.
2. You can listen your recording by pressing the Play button. The record LED stays lit. Press the
button again to stop.
3. Please note that each time when a new recording is being recorded it will cover the old recording.
RECORD AND PLAYBACK FUNCTION
The unit will automatically turn into standby mode in 15 minutes in the following situations. The power LED indicator
will be turned off:
1. No Bluetooth connection for 15 minutes
2. No playback from your external music player for 15 minutes.
3. No button being pressed for 15 minutes.
4. Not playing music & singing to the microphone for 15 minutes.
The unit would be turned on again by pressing any button. The power LED indicator will be turned on.
ENERGY SAVING
1. Press POWER button to turn on the unit. Red LED indicator will turn on.
2. Plug a 3.5mm line-in cable into your external music player and connect the other end into the LINE IN jack on the back
side of the unit.
3. Make sure your external music player is turned on and the unit has been turned on
4. Start music playback on your external music player.
5. Adjust volume by pressing Vol+ or Vol –
6. You can plug the microphone in and sing with music you play.
Note: the player is set to be LINE-IN priority which means once line-in cable plugged in, it will switch to LINE-IN mode
automatically. To go back to Bluetooth mode unplug the line-in cable.
EN - 9
If a fault occurs, first check the points listed below before taking the unit for repair. If you are unale to remedy a
problem by following these hints, consult your dealer or service center.
WARNING: Under no circumstances should you try to repair the unit yourself, as this would invalidate the guarantee.
IMPORTANT: Due to continual revision and improvement on our product design,
specifications are subject to change without further notice.
Power Supply DC 4.5V (“AA” cell 1.5V x 3pcs, not included)
Or
AC power adaptor
Input 100 - 240V ~ 50/60 Hz 0.5A
Output DC 5V / 0.6A
Line in 3.5mm
Power output 1W (RMS)
Dimension 10.4”W x 6.7”H x 3.3”D
PROBLEM POSSIBLE CAUSE REMEDY
No sound in general
No sound from microphone
Volume not adjusted.
No battery in battery
compartment
Microphone is switched off
Press the vol + button
Put 3 new AA size batteries into the
battery compartment according to
instructions
Switch on the microphone
No sound in line in mode The music player is not playing.
The line in cord is not properly
connected.
Start to play the music in your
music player. Adjust volume by
pressing volume buttons on the
unit.
Follow instruction to connect the
line in cord between the unit and
the music player. Adjust volume by
pressing volume buttons on the
unit.
TROUBLESHOOTING
TECHNICAL SPECIFICATOIN
EN - 10
Pair the unit with the BT Device
as the procedures stated in this
manual.
Bluetooth reception failure The external device is far from
the unit
Put the external BT device close
to the unit.
Have not paired
