Arts Electronics CN897153 Bluetooth Alarm Clock User Manual
Arts Electronics Co., Ltd Bluetooth Alarm Clock
User Manual
897153 TimeSmart Alarm Clock
Size:4”Wx4"H_Output:100%_Prints:1/1,Blk
TimeSmart
®
APP-CONTROLLED ALARM CLOCK
897153
Find thousands more
great ideas online
Merrimack, New Hampshire, USA 03054 • 800-846-3000 • Brookstone.com
897153 TimeSmart Alarm Clock
Size:4”Wx4"H_Output:100%_Prints:1/1,Blk
TABLE OF CONTENTS
Warnings and Cautions.........................................1
FCC Information ..............................................6
Location of Parts and Controls (Clock) ......................... 8
Location of Controls (App) ...................................10
Pairing Your Device..........................................14
Downloading Free App.......................................15
Setting the Clock ............................................16
Setting Alarm 1 ..............................................18
Setting Alarm 2 ..............................................20
Activating and Deactivating Alarm 1...........................23
Activating and Deactivating Alarm 2...........................25
Adjusting the LCD Display Backlight ..........................27
Listening to Audio ...........................................29
Charging with USB ..........................................29
Installing the Back-Up Battery ................................30
Reset .......................................................31
Care and Maintenance .......................................31
App Compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Specifications ...............................................33
Troubleshooting..............................................34
Warranty ....................................................36
37
Warranty does not apply to any non-Big Blue Audio products. Manufacturers or
suppliers other than Big Blue Audio may provide their own warranties to the purchaser,
but Big Blue Audio, in so far as permitted by law, provides these products “as is.”
This warranty does not apply to: a) damage caused by failure to follow instructions
relating to product’s use or the installation of components; b) damage caused
by accident, abuse, misuse, fire, floods, earthquake or other external causes; c)
damage caused by service performed by anyone who is not a representative of
Big Blue Audio; d) accessories used in conjunction with a covered product; e) a
product or part that has been modified to alter functionality or capability; f) items
intended to be periodically replaced by the purchaser during the normal life of the
product including, without limitation, batteries or light bulbs; g) any product sold “as
is” including, without limitation, floor demonstration models and refurbished items;
or h) a product that is used commercially or for a commercial purpose.
BIG BLUE AUDIO SHALL NOT BE LIABLE FOR INCIDENTAL OR
CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THIS
PRODUCT, OR ARISING OUT OF ANY BREACH OF THIS WARRANTY.
TO THE EXTENT PERMITTED BY APPLICABLE LAW, BIG BLUE AUDIO
DISCLAIMS ANY AND ALL STATUTORY OR IMPLIED WARRANTIES,
INCLUDING, WITHOUT LIMITATION, WARRANTIES OF MERCHANTABILITY,
FITNESS FOR A PARTICULAR PURPOSE AND WARRANTIES AGAINST
HIDDEN OR LATENT DEFECTS. IF BIG BLUE AUDIO CANNOT LAWFULLY
DISCLAIM STATUTORY OR IMPLIED WARRANTIES, THEN TO THE EXTENT
PERMITTED BY LAW, ALL SUCH WARRANTIES SHALL BE LIMITED IN
DURATION TO THE DURATION OF THIS EXPRESS WARRANTY.
Some states disallow the exclusion or limitation of incidental or consequential
damages or how long an implied warranty lasts, so the above exclusions or
limitations may not apply to you. This warranty gives you specific legal rights and
you may also have other rights, which vary from state to state.
36
ONE (1) YEAR LIMITED WARRANTY
Big Blue Audio LLC warrants this product against defects in materials and/
or workmanship under normal use for a period of ONE (1) YEAR from the
date of purchase by the original purchaser (“Warranty Period”). If a defect
arises and a valid claim is received within the Warranty Period, at its option,
Big Blue Audio will either 1) repair the defect at no charge, using new
or refurbished replacement parts, or 2) replace the product with a new
product that is at least functionally equivalent to the original product, or
3) provide a store credit in the amount of the purchase price of the original product.
A replacement product or part, including a user-installable part installed in
accordance with instructions provided by Big Blue Audio, assumes the remaining
warranty of the original product. When a product or part is exchanged, any
replacement item becomes your property and the replaced item becomes Big Blue
Audio’s property. When a store credit is given, the original product must be returned
to Big Blue Audio and becomes Big Blue Audio’s property.
Obtaining Service: To obtain warranty service, call Big Blue Audio Limited Warranty
Service at 866-577-8955. Please be prepared to describe the product that needs
service and the nature of the problem. A purchase receipt is required. All repairs and
replacements must be authorized in advance. Service options, parts availability and
response times will vary. You are responsible for delivery and the cost of delivery
of the product or any parts to the authorized service center for replacement, per
our instructions.
Limits and Exclusions: Coverage under this Limited Warranty is limited to the
United States of America, including the District of Columbia and the U.S. Territories
of Guam, Puerto Rico, and the U.S. Virgin Islands. This Limited Warranty applies only
to products manufactured for Big Blue Audio that can be identified by the “Big Blue
Audio” trademark, trade name, or logo affixed to them or their packaging. The Limited
897153 TimeSmart Alarm Clock
Size:4”Wx4"H_Output:100%_Prints:1/1,Blk
1
CAUTION
• TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER.
THERE ARE NO SERVICEABLE PARTS INSIDE.
• TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.
The lightning flash with arrow-head symbol within
an equilateral triangle is intended to alert the user
to the presence of uninsulated “dangerous voltage”
within the unit’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock.
The exclamation point within an equilateral triangle
is intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the unit.
IMPORTANT SAFETY INSTRUCTIONS
All of the safety and operating instructions should be read,
adhered to and followed before the unit is operated.
897153 TimeSmart Alarm Clock
Size:4”Wx4"H_Output:100%_Prints:1/1,Blk
SAFETY AND HANDLING INFORMATION
For maximum product life, do not drop, throw, or crush the
speaker. Do not expose it to humidity, dust, or operating
temperatures outside 32°F to 113°F (0°C to 45°C).
SAVE THESE INSTRUCTIONS
2
ISSUE SOLUTION
TROUBLESHOOTING (CONTINUED)
35
Turn the VOLUME DIAL clockwise
on the clock to increase the volume.
Can not hear alarm
sound when tap icon
in app.
App is no longer
syncing clock to
device clock.
If the time setting was changed on the
clock, the app setting was changed to
Manual Set. To change to SYNC TO
DEVICE CLOCK, go into the app
and tap the CLOCK SET icon or
the clock. The clock set window will
come on screen. Select SYNC TO
DEVICE CLOCK.
897153 TimeSmart Alarm Clock
Size:4”Wx4"H_Output:100%_Prints:1/1,Blk
34
ISSUE SOLUTION
Bluetooth®
disconnection.
Ensure your device is within 33 feet of
the clock and reconnect your device
to "TimeSmart Alarm Clock."
TROUBLESHOOTING
Clock does not
play audio.
Confirm device is paired to clock.
Note: The clock remembers the last
device paired. If you would like to
use another device, pair that device
manually. Please refer to page 14 for
pairing instructions.
Clock and app settings
do not sync.
The clock may have auto-paired to
another device in the immediate
area. If "TimeSmart Alarm Clock" is
shown as a Bluetooth® connection
on a device other than your own, turn
Bluetooth® off on the other device.
DANGER
To reduce the risk of electric shock, burns, fire or injury:
1. Do not use while bathing or in a shower.
2. Do not place or store unit where it can fall or be pulled
into a tub or sink.
3. Do not place in, drop or submerge in water or
other liquid.
4. Do not reach for a unit that has fallen into water.
Unplug it immediately.
5. Care should be taken so that objects do not fall and
liquids are not spilled onto the unit.
WARNING
1. Close supervision is necessary when this appliance/
product is used by or near children or mentally
disabled individuals.
2. Use this unit only for its intended use as described in
this manual.
3
897153 TimeSmart Alarm Clock
Size:4”Wx4"H_Output:100%_Prints:1/1,Blk
4
3. Unplug this unit during lightning storms or when unused
for long periods of time.
4. Never drop or insert an object into any opening.
5. Protect the power cord from being walked on or pinched,
particularly at plug outlets, convenience receptacles and
the point where it exits the unit.
6. Do not allow cord to touch hot surfaces. Wrap cord loosely
around the unit when storing.
7. The unit should be situated away from direct sunlight
or heat sources such as radiators, electric heaters, heat
registers, stoves, or other units (including amplifiers) that
produce heat. Avoid placing on top of stereo equipment
that radiates heat.
8. Never block the air openings of the unit with materials such
as clothing, plastic bags or papers, or place it on a soft
surface such as a bed or couch, where the air openings
may be blocked.
9. Do not overload the electrical outlet. Use only the power
source as indicated.
10. Do not carry this unit by its cord or use the cord
33
SPECIFICATIONS
Power Supply (input) ........... AC 100V~240V, 50/60 Hz
Power Supply (output) ............ DC 5V, 2A
USB Port (output) ................ DC 5V, 1000mA
Power Output .................... 3W
Range ........................... Class 2, up to 33 ft (10 m)
Speaker ......................... 1.5", 4 Ohm (1)
Clock Compatibility ............... Bluetooth® 2.0 or above with
A2DP/AVRCP
App Compatibility ................. Bluetooth® 4.0/Bluetooth®
Smart Ready
Weight ........................... Approx. .7lbs
Dimensions....................... 5.9" (w) x 2.8" (d) x 3.5" (h)
The Bluetooth® word mark and logos are registered trademarks owned by
Bluetooth SIG, Inc. and any use of such marks by Brookstone is under license.
© Brookstone 2015
897153 TimeSmart Alarm Clock
Size:4”Wx4"H_Output:100%_Prints:1/1,Blk
32
iPhone 6 Plus
iPhone 6
iPhone 5s
iPhone 5c
iPhone 5
iPhone® 4s
iPod touch® 5th generation
iPad Air 2
iPad Air
iPad mini 3
iPad mini 2
iPad mini
iPad® (4th generation)
iPad® (3rd generation)
APP COMPATIBILITY
Visit Brookstone.com for compatibility updates.
Apple® iOS: 6.0 and later
Android 4.3 and later, CPU: 800MHz, RAM: 512M
App is only compatible with select Bluetooth® 4.0 and
Bluetooth® Smart Ready devices.
5
as a handle.
11. Never operate this unit if it has a damaged cord or plug,
if it is not working properly, or if it has been dropped or
damaged, or dropped into water. If the unit’s power supply
cord or plug is damaged, do not attempt to fix it yourself.
12. To avoid the risk of electric shock, do not disassemble or
attempt to repair the unit. Incorrect repair can cause risk of
electric shock or injury to persons when the unit is used.
13. Do not operate in the presence of explosive and/or
flammable fumes.
14. Never remove the plug from the outlet by pulling the
power cord.
897153 TimeSmart Alarm Clock
Size:4”Wx4"H_Output:100%_Prints:1/1,Blk
RESET
Insert a pointed object in the RESET PINHOLE to reset the
clock.
CARE AND MAINTENANCE
Wipe the clock with a soft, dry cloth.
31
FCC INFORMATION
This equipment has been tested and found to comply with
the limits for a Class B Digital Device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is
no guarantee that interference will not occur in a particular
installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the distance between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician
6
897153 TimeSmart Alarm Clock
Size:4”Wx4"H_Output:100%_Prints:1/1,Blk
7
for help.
This equipment complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This equipment may not cause harmful interference.
2. This equipment must accept any interference received,
including interference that may cause undesired operation.
Modifications not authorized by the manufacturer may void the
user’s authority to operate this device.
This device complies with FCC radiation exposure limits set
forth for an uncontrolled environment.
FCC ID: TZI-CN897153
INSTALLING THE BACK-UP BATTERY
When the back-up CR2032 battery (included) is running low,
the low battery icon appear on the LCD display, indicating that
the battery should be replaced.
Note: To avoid manually resetting your clock, replace a spent
battery while the clock is plugged into an outlet.
1. Remove screw on the door of the BATTERY
COMPARTMENT and lift cover.
2. Place 1 new CR2032 button cell battery into the
BATTERY COMPARTMENT according to the polarity
indicator.
3. Replace the BATTERY COMPARTMENT door and secure
screw.
30
897153 TimeSmart Alarm Clock
Size:4”Wx4"H_Output:100%_Prints:1/1,Blk
8
LOCATION OF PARTS AND CONTROLS (CLOCK)
1. Clock Set Button
2. Alarm 1 Button
3. Volume/Set Dial
4. LCD Display
5. Clock
6. Bluetooth® Icon
7. Alarm 1 Time
8. Alarm 1 Wake-To Icon
9. Alarm 2 Wake-To Icon
10. Alarm 2 Time
11. Low Battery Indicator
12. Alarm 2 Button
13. Snooze/Pairing Button
3
1
2
13
12
10
5
6
7
9
11
8
4
LISTENING TO AUDIO
1. Turn the VOLUME DIAL clockwise to increase audio
volume.
2. Turn the VOLUME DIAL counter-clockwise to decrease
audio volume.
CHARGING WITH USB
Plug one end of a USB cable (not included) into the USB
OUTPUT 1A port and the other end into your mobile device to
charge.
29
897153 TimeSmart Alarm Clock
Size:4”Wx4"H_Output:100%_Prints:1/1,Blk
Tap High, Low, Medium, Dim or Off in LCD DISPLAY
BRIGHTNESS to change the LCD display brightness
setting.
Note:
• If your device is connected to the clock, the clock
settings will be updated with the TimeSmart app settings.
• If your device is disconnected and then reconnected
to the clock, or if the TimeSmart app is quit and re-
opened, the TimeSmart app will be updated with the
current clock settings.
28 9
14. USB Output 1A
15. Reset Pinhole
16. Battery Compartment
17. Adapter
18. DC 5V Jack
LOCATION OF PARTS AND CONTROLS (CLOCK)
14 18
15
16 17
897153 TimeSmart Alarm Clock
Size:4”Wx4"H_Output:100%_Prints:1/1,Blk
ADJUSTING THE LCD DISPLAY BACKLIGHT
Press the CLOCK SET button repeatedly to change the
LCD display backlight setting to High, Low, Medium, Dim
or Off.
Note:
• If the LCD display backlight setting is Off, the LCD
display backlight will be Dim when the alarm sounds or
during an alarm snooze.
• If your device is connected to the clock, the TimeSmart
app settings will be updated with the clock settings.
• If your device is disconnected and then reconnected
to the clock, or if the TimeSmart app is quit and re-
opened, the TimeSmart app will be updated with the
current clock settings.
2710
LOCATION OF CONTROLS (APP MAIN SCREEN)
1. Alarm 1 On/Off
2. Alarm 2 On/Off
3. Clock Set
4. LCD Display Brightness
5. Tutorial
6. Bluetooth® Icon
7. Clock
8. Alarm 2 Time
9. Alarm 2 Wake-To Icon/Snooze Setting
10. Alarm 1 Wake-To Icon/Snooze Setting
11. Alarm 2 Time
11
1
3
4
11
10
29
8
7
6
5
LOCATION OF CONTROLS (APP MAIN SCREEN)
to the clock, or if the TimeSmart app is quit and re-
opened, the TimeSmart app will be updated with the
current clock settings.
1. Tap ALARM 2 ON/OFF to activate Alarm 2.
2. Tap ALARM 2 ON/OFF to deactivate Alarm 2.
Note:
• If your device is connected to the clock, the clock
settings will be updated with the TimeSmart app settings.
• If your device is disconnected and then reconnected
to the clock, or if the TimeSmart app is quit and re-
opened, the TimeSmart app will be updated with the
current clock settings.
26
897153 TimeSmart Alarm Clock
Size:4”Wx4"H_Output:100%_Prints:1/1,Blk
897153 TimeSmart Alarm Clock
Size:4”Wx4"H_Output:100%_Prints:1/1,Blk
1
3
2
12
LOCATION OF CONTROLS (APP ALARM SET)
1. Alarm Time Selector
2. Alarm Snooze Setting
3. Alarm Wake-To Setting
Note: The control layout may not appear exactly as shown, depending upon your device.
ACTIVATING AND DEACTIVATING ALARM 2
1. Press the ALARM 2 button to activate Alarm 2. The
Alarm 2 time and Wake-To sound settings are on
the LCD display.
2. Press the ALARM 2 button to deactivate Alarm 2. The
Alarm 2 time and Wake-To sound settings are not on the
LCD display.
3. When Alarm 1 sounds, press the ALARM 2 button to
turn the alarm off or press the SNOOZE button to
snooze the alarm. Alarm 2 will snooze up to 6 times.
Alarm 2 will sound for 20 minutes if it is not turned off.
Note:
• The alarm sound incrementally increases in volume
reaching it's loudest setting in 30 seconds.
• If your device is connected to the clock, the TimeSmart
app settings will be updated with the clock settings.
• If your device is disconnected and then reconnected
25
to the clock, or if the TimeSmart app is quit and re-
opened, the TimeSmart app will be updated with the
current clock settings.
1. Tap ALARM 1 ON/OFF to activate Alarm 1.
2. Tap ALARM 1 ON/OFF to deactivate Alarm 1.
Note:
• If your device is connected to the clock, the clock
settings will be updated with the TimeSmart app settings.
• If your device is disconnected and then reconnected
to the clock, or if the TimeSmart app is quit and re-
opened, the TimeSmart app will be updated with the
current clock settings.
24
897153 TimeSmart Alarm Clock
Size:4”Wx4"H_Output:100%_Prints:1/1,Blk
13
LOCATION OF CONTROLS (APP CLOCK SET)
13
2
Note: The control layout may not appear exactly as shown, depending upon your device.
1. 12/24 Clock Display Selector
2. Manual Set/Sync to Device Clock Setting
3. Time Selector
897153 TimeSmart Alarm Clock
Size:4”Wx4"H_Output:100%_Prints:1/1,Blk
PAIRING YOUR DEVICE
1. Prepare your device to pair using Bluetooth®, making
sure the device is within 33 feet of the alarm clock. Refer
to your device’s owners manual for details if necessary.
2. Press and hold the SNOOZE/PAIRING BUTTON until
the BLUETOOTH® ICON on the alarm clock LCD starts
flashing to put the alarm clock in pairing mode.
3. Select “TimeSmart Alarm Clock” on your device. If
prompted, use 0000 as a PIN for the pairing code. The
alarm clock will wait for a connection in pairing mode for
up to 2 minutes.
4. When “TimeSmart Alarm Clock” is selected, the
BLUETOOTH® ICON will stop flashing and the pairing
successful tone will sound to confirm pairing is complete.
Note:
• To cancel pairing mode, wait 2 minutes for the speaker to
cancel pairing automatically. The BLUETOOTH® ICON will
no longer be displayed on the LCD.
• The Bluetooth® icon in the TimeSmart app is blue when
14
ACTIVATING AND DEACTIVATING ALARM 1
1. Press the ALARM 1 button to activate Alarm 1. The
Alarm 1 time and Wake-To sound settings are on
the LCD display.
2. Press the ALARM 1 button to deactivate Alarm 1. The
Alarm 1 time and Wake-To sound settings are not on the
LCD display.
3. When Alarm 1 sounds, press the ALARM 1 button to
turn the alarm off or press the SNOOZE button to
snooze the alarm. Alarm 1 will snooze up to 6 times.
Alarm 1 will sound for 20 minutes if it is not turned off.
Note:
• The alarm sound incrementally increases in volume
reaching it's loudest setting in 30 seconds.
• If your device is connected to the clock, the TimeSmart
app settings will be updated with the clock settings.
• If your device is disconnected and then reconnected
23
2. Use the ALARM TIME SELECTOR to select the alarm
time.
3. Select the Snooze time.
4. Select the Wake-To sound.
5. Tap Save to save the alarm settings.
Note:
• If your device is connected to the clock, the clock
settings will be updated with the TimeSmart app settings.
• If your device is disconnected and then reconnected
to the clock, or if the TimeSmart app is quit and re-
opened, the TimeSmart app will be updated with the
current clock settings.
22
the clock is connected to your device. The Bluetooth® icon
is gray in the TimeSmart app when the clock is not
connected to your device.
15
DOWNLOADING FREE APP
Go to the iTunes® App StoreSM (for Apple devices) or Google
PlayTM (for Android devices) to download the TimeSmart Alarm
Clock App, "TimeSmart".
897153 TimeSmart Alarm Clock
Size:4”Wx4"H_Output:100%_Prints:1/1,Blk
16
SETTING THE CLOCK
1. Press and hold the CLOCK SET button until "12 H"
flashes on the LCD display.
2. Turn the VOLUME/SET DIAL to choose 12-Hour or
24-Hour clock display.
3. Press the CLOCK SET button to save the clock display
setting. The hour will flash on the LCD display. Turn the
VOLUME/SET DIAL to select the hour.
4. Press the CLOCK SET button to save the hour
setting. The minutes will flash on the LCD display. Turn
the VOLUME/SET DIAL to select the minutes.
5. Press the CLOCK SET button to save the clock
settings. If the CLOCK SET button is not pressed, the
clock settings will be saved after 5 seconds.
Note:
• If your device is connected to the clock, the TimeSmart
app settings will be updated with the clock settings.
3. Press the ALARM 2 button to save the Minutes
setting. The Wake-To icon will flash on the display. Turn
the VOLUME/SET DIAL to select the Wake-To sound.
4. Press the ALARM 2 button to save the alarm
settings. If the ALARM 2 button is not pressed, the
alarm settings will be saved after 5 seconds.
Note:
• If your device is connected to the clock, the TimeSmart
app settings will be updated with the clock settings.
• If your device is disconnected and then reconnected
to the clock, or if the TimeSmart app is quit and re-
opened, the TimeSmart app will be updated with the
current clock settings.
1. Tap the ALARM 2 WAKE-TO ICON/SNOOZE SETTING
or the ALARM 2 time. The Alarm 1 set window will come
on screen.
21
897153 TimeSmart Alarm Clock
Size:4”Wx4"H_Output:100%_Prints:1/1,Blk
• If your device is disconnected and then reconnected
to the clock, or if the TimeSmart app is quit and re-
opened, the TimeSmart app will be updated with the
current clock settings.
1. Tap the CLOCK SET icon or the clock. The clock set
window will come on screen.
2. Select MANUAL SET or SYNC TO DEVICE CLOCK. If
SYNC TO DEVICE CLOCK is selected, the clock will
sync to your device's clock.
3. If MANUAL SET is selected, choose 12-Hour or
24-Hour clock display and use the TIME SELECTOR to
select the time. Tap Save to save the clock settings.
Note:
• If your device is connected to the clock, the clock
settings will be updated with the TimeSmart app settings.
17
4. Select the Wake-To sound.
5. Tap Save to save the alarm settings.
Note:
• If your device is connected to the clock, the clock
settings will be updated with the TimeSmart app settings.
• If your device is disconnected and then reconnected
to the clock, or if the TimeSmart app is quit and re-
opened, the TimeSmart app will be updated with the
current clock settings.
SETTING ALARM 2
1. Press and hold the ALARM 2 button until the Hour
flashes on the LCD display. Turn the VOLUME/SET DIAL
to select the hour.
2. Press the ALARM 2 button to save the Hour
setting. The minutes will flash on the LCD display. Turn
the VOLUME/SET DIAL to select the minutes.
20
897153 TimeSmart Alarm Clock
Size:4”Wx4"H_Output:100%_Prints:1/1,Blk
• If your device is disconnected and then reconnected
to the clock, or if the TimeSmart app is quit and re-
opened, the TimeSmart app will be updated with the
current clock settings.
SETTING ALARM 1
1. Press and hold the ALARM 1 button until the Hour
flashes on the LCD display. Turn the VOLUME/SET DIAL
to select the hour.
2. Press the ALARM 1 button to save the Hour
setting. The minutes will flash on the LCD display. Turn
the VOLUME/SET DIAL to select the minutes.
3. Press the ALARM 1 button to save the Minutes
setting. The Wake-To icon will flash on the display. Turn
the VOLUME/SET DIAL to select the Wake-To sound.
4. Press the ALARM 1 button to save the alarm
18 19
settings. If the ALARM 1 button is not pressed, the
alarm settings will be saved after 5 seconds.
Note:
• If your device is connected to the clock, the TimeSmart
app settings will be updated with the clock settings.
• If your device is disconnected and then reconnected
to the clock, or if the TimeSmart app is quit and re-
opened, the TimeSmart app will be updated with the
current clock settings.
1. Tap the ALARM 1 WAKE-TO ICON/SNOOZE SETTING
or the ALARM 1 time. The Alarm 1 set window will come
on screen.
2. Use the ALARM TIME SELECTOR to select the alarm
time.
3. Select the Snooze time.
897153 TimeSmart Alarm Clock
Size:4”Wx4"H_Output:100%_Prints:1/1,Blk
