WLU5200 H/W SPECIFICATIONS
Host Interfaces RGMII
Form factor L*W*H = 101.6mm*69.85mm*2.3mm
Chipset Atheros AR9342
Operation Voltage 3.0 VDC~3.6 VDC
Network Standards
IEEE 802.11 a/b/g/n Standard
Modulation Techniques
DBPSK, DQPSK, BPSK, QPSK, CCK, 16QAM, 64QAM, MIMO
Modulation Technology OFDM, DSSS
Data Rate
802.11b: 11, 5.5, 2, 1 Mbps
802.11g: 54, 48, 36, 24, 18, 12, 9, 6 Mbps
802.11n: MCS0-15 (HT20: 150Mbps / HT40:300 Mbps PHY rate )
Network Architectures Infrastructure and Ad Hoc
Operating Frequency
802.11 b/g/n: 2412 GHz ~ 2462 GHz
802.11 a/n: 5180 GHz ~ 5825 GHz
Operating Channel
802.11b/g: Ch1 to Ch11
IEEE 802.11n ,Mode: MCS0-15
RF Output Power
2.4G:
802.11b: 15~18 dBm, output power
802.11g: 18~24 dBm, output power
802.11n:(HT20/HT40) : 17~23dBm
5G:
802.11a: 27~28 dBm, output power
802.11n:(HT20/HT40) : 27~28dBm
UNII Band:
IEEE 802.11a CH36 - CH48 CH52 - CH64 CH100 – CH140
16~23dBm
IEEE802.11an HT20 CH36 - CH48 CH52 - CH64 CH100 – CH140
16~23dBm
IEEE802.11anHT40 CH38 - CH46 CH54 - CH62 CH102 – CH134
16~23dBm
Security
1.WPA™ (personal) and WPA2™ (personal) certified for powerful encryption
and authentication
2.AES and TKIP in hardware for faster data encryption and IEEE 802.11i™
compatibility
Temperatures (AMBIENT)
Operates from 0 to 70 C;
Storage from -20 to 80 C
Humidity(non-condensing)
5 to 95%
SETUP WLAN MODULE CONNECTION
1) WLAN Card from PC set fixed IP:192.168.1.10 , Mask : 255.255.255.0
2) Use telnet and link to Mi124 board
telnet 192.168.1.2
user name: root
password : 5up
Prepare one ROUTER，ROUTER domain 192.168.1.xx, then you can PING ROUTER
after setting command as below.
3) Set command as below:
//for 2.4G Mode:
cfg -x
cfg -a AP_STARTMODE=multi
cfg -a AP_MODE=sta
cfg -a AP_CHMODE=11NGHT40PLUS
cfg -a AP_SSID="dlink2g"
cfg -c
apup
iwpriv ath0 wds 1
iwpriv ath0 autoassoc 1
iwpriv ath0 vap_ind 1
iwpriv ath0 extap 1
//for 5G Mode:
cfg -x
cfg -a AP_STARTMODE=multi
cfg -a AP_MODE=sta
cfg -a AP_CHMODE=11NAHT40PLUS
cfg -a AP_SSID="dlink5g"
cfg -c
apup
iwpriv ath0 wds 1
iwpriv ath0 autoassoc 1
iwpriv ath0 vap_ind 1
iwpriv ath0 extap 1
Federal Communication Commission Interference Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to operate
this equipment.
This transmitter must not be co-located or operating in conjunction with any
other antenna or transmitter.
Operations in the 5.15-5.25GHz band are restricted to indoor usage only.
Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated
with minimum distance 20cm between the radiator & your body.
Note: The country code selection is for non-US model only and is not
available to all US model. Per FCC regulation, all WiFi product marketed in US
must fixed to US operation channels only.
This device is intended only for OEM integrators under the following conditions:
1) The antenna must be installed such that 20 cm is maintained between the
antenna and users, and
2) The transmitter module may not be co-located with any other transmitter
or antenna.
As long as 2 conditions above are met, further transmitter test will not be
required. However, the OEM integrator is still responsible for testing their
end-product for any additional compliance requirements required with this
module installed
IMPORTANT NOTE: In the event that these conditions can not be met (for
example certain laptop configurations or co-location with another transmitter),
then the FCC authorization is no longer considered valid and the FCC ID can not
be used on the final product. In these circumstances, the OEM integrator will
be responsible for re-evaluating the end product (including the transmitter) and
obtaining a separate FCC authorization.
End Product Labeling
This transmitter module is authorized only for use in device where the antenna
may be installed such that 20 cm may be maintained between the antenna and
users. The final end product must be labeled in a visible area with the following:
“Contains FCC ID: H8N-WLU5200”. The grantee's FCC ID can be used only when
all FCC compliance requirements are met.
Manual Information To the End User
The OEM integrator has to be aware not to provide information to the end user
regarding how to install or remove this RF module in the user’s manual of the
end product which integrates this module.
The end user manual shall include all required regulatory information/warning
as show in this manual.
