Athena Smartcard Solution,Inc. ASEDrive DI Users Manual

Users Manual

PRODUCT DATASHEET
Specifications are subject to change without notice. All trademarks and trade names are property of their respective owners.
Copyright © 2012 Athena Smartcard Solutions Inc
ASEDrive IIIe NFC DI Smart Card Reader
Desktop Contact and Contactless Smart Card Reader
Highlights
ASEDrive DI NFC is Athena’s high perform-
ance and cost effective Dual Interface reader
combining Athena’s proven design and experience
in both contact smart card readers and contactless
s m a r t c a r d r e a d e r .
The ASEDrive DI NFC reads virtually any con-
tact smart card and 13.56 Mhz contactless cards
The Athena ASEDrive DI NFC is designed for
easy operation by the end user looking for a Dual
Interface desktop smart card reader and is opti-
mized for a wide variety of Smart card applica-
tions where high speed is essential such as Na-
tional ID CARDS and PKI operations.
The Contactless interface supports fast contactless
transmissions up to 848 Kbps in ISO 14443 A/B
mode , with the Contact interface, based on
Athena’s ASEDrive IIIe USB V3C Smart Card Reader
that supports multiple smart card protocols under
the PC/SC API, with a CCID Interface, utilizing the
USB Full speed connection to increase reliability,
communication speed and ease of operation.
The ASEDrive DI NFC is a CCID based smart card
reader making it a true Plug and Play device, making
ideal for mass deployments where Web SSL, Digital Sig-
nature, Windows logon, VPN, etc services are required.
Contactless Interface
read/write mode supporting ISO/IEC 14443A/B MIFARE
• read/write mode supporting MIFARE
• read/write mode supporting JIS X 6319-4 (FeliCa1)
• passive initiator mode according to ISO/IEC 18092
• read/write mode supporting ISO/IEC 15693
Contact Interface
Interface: USB 2.0/CCID
Acceptor: Friction
Insert/remove cycles: 100,000
Power source: USB
Cards supported: ISO 7816 T=0, T=1, CAC and EMV
Technical Specification
Asia
1-14-16,
Motoyokoyama-cho
Tokyo, 192-0063
Tel: +81 426 607 555
Fax: +81 426 607 106
North America
20380 Town Center Lane
Suite 240
Cupertino, CA 95014
Tel: +1 866 359 2273
Fax: +1 408 608 1818
EMEA & International
Alba Centre Livingston.
EH54 7EG. UK.
Tel: +44 131 208 1202
Fax: +44 131 777 8150
LATAM & Iberia
CL. Padre Jesús Ordoñez
5 1-B, 28002, Madrid,
Spain
Tel: +34 915 644 651
Fax: +34 915 644 651
Poland & Central
Europe
ul. Kasprowicza 8a/4
31-523, Kraków, Poland
Tel: +48 602 315 641
Fax:
+48 123 414322
www.athena -sc s. co m
sales@athena-scs.com
General
Dimensions 106.5mm x 70.03mm x 10mm
Power Supply USB port, 5VDC 150mA
Operating Temperatures -20ºC - +70ºC
Operating Humidity 5-95% rH
Operating Altitude 010K feet (Storage 050K feet)
Operating System Support
(32bit/64 bit)
Windows XP, Vista, 7, 8,
Server 2003/R2, 2008/R2,2012,
Linux,
Mac OS X
Safety & Environmental Standard FCC Class B, VCCI, CE, ROHS, WEEE
Warranty 1 Year
Host Interface
Host Interface CCID • USB 2.0 Full Speed • USB-IF Complaint
Transmission Speed 12 Mbps (USB 2.0 Full Speed)
Contact Interface
Smart Card Support ISO 7816 T=0, T=1
Card-Reader Communication Up to 500Kbps
Smart Card Acceptor ISO 8 contacts (friction), up to 200,000 insertions
Card operating voltage 5V , 3V, 1.8V (ISO7816 Class A,B & C)
Smart Card Reader Compliance PC/SC Compliant
Card-Reader Communication Up to 500Kbps
Smart Card Acceptor ISO 8 contacts (friction), up to 200,000 insertions
Card operating voltage 5V , 3V, 1.8V (ISO7816 Class A,B & C)
Smart Card Reader Compliance PC/SC Compliant
Contactless Interface
Protocols ISO 14443 A/B, Mifare 1k/4, ISO 15693, ISO 18092, FeliCa
PC/SC Driver Support
Windows XP, Vista, 7, 8, Server 2003/R2, 2008/R2,2012,
Linux,
Mac OS X
(32bit/64 bit)
Compliance and Certification CE, FCC, VCCi - in process
Safety and Environment RoHS, FEEEin process
IMPORTANT FCC Part 15
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause undesired operation.
FCC WARNING
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the in-
structions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encour-
aged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICA-
TIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER'S AUTHORITY TO OPERATE THE EQUIPMENT.
