Atomic Monkey AMP10522 SECRET AGENT WALKIE TALKIES User Manual 10522 Secret Agent Walkie Talkies Instuctions CS6
Atomic Monkey Products Ltd. SECRET AGENT WALKIE TALKIES 10522 Secret Agent Walkie Talkies Instuctions CS6
User manual
Ages 6 and up
10522
SpyX Secret Agent
Walkie Talkies
Requires 4 AAA (LR03)
Batteries, not included.
Important: Please save this instruction sheet.
It contains valuable product information.
Talk to fellow spies in secret, just like real secret service agents!
The Set-up
1. Detach the microphone plug from the wrist microphone (you will plug it
back in later).
2. Attach the wrist strap with wrist microphone to your wrist. Wear it like a
watch on top of your wrist or under your wrist for "stealth mode".
3. Clip the power pack unit onto your belt and run the wires up and under your
shirt or jacket.
4. Run the Sleeve wire (with the microphone plug at the end) down your shirt or
jacket sleeve and reattach the microphone plug back into the microphone
jack (make sure it is all the way plugged in).
5. Run the ear bud wire under your shirt and collar and place it in your ear.
6. Turn on each walkie talkie power pack by moving the power switch (Fig 1.)
to the "on" position.
Talking in Secret
The wrist microphone is voice activated, so you just need to start talking into
the wrist microphone and the other agent can hear you.
Hint: Both agents cannot talk at the same time so one of you
will talk while the other listens. You can take turns.
Tip: When finished playing with the SpyX Walkie Talkies please
move the power switch to the "off" position.
BATTERY SAFETY INFORMATION
· Only adults should install and replace batteries.
· Do not recharge non-rechargeable batteries.
· Remove dead or exhausted batteries.
· Insert batteries correctly. Match positive and negative signs.
· The supply terminals are not to be short circuited.
· Do not use rechargeable batteries.
· Do not mix alkaline, standard (carbon-zinc), or rechargeable (nickel-cadmium) batteries.
· Do not mix old and new batteries.
· Only the batteries of the same or equivalent type recommended to be used.
· Do not dispose of batteries in a fire; they may explode.
· Dispose of batteries safely.
ATTENTION ADULTS—TO INSTALL AND REPLACE BATTERIES
SpyX Secret Agent Walkie Talkies.
Each Walkie Talkie requires two AAA (LR03) batteries, not included.
• Locate the belt clip on the back of the walkie talkie. To gain access to the
battery cover, press the tab release on the belt clip and slide the belt clip
upwards to release (Fig. 2).
• Use a small Phillips head screwdriver to loosen the screw and remove
the battery cover (Fig. 2).
• Remove all old batteries.
• Place new batteries in compartments as shown (Fig. 2).
• Replace the battery cover and tighten screw. Then replace the belt clip.
SPYX SECRET AGENT WALKIE TALKIES
10522-4000
Product specifications subject to change.
IF YOU HAVE ANY QUESTIONS, PLEASE
CONTACT US AT
www.atomicmonkeyproducts.com/help
© 2015 Atomic Monkey Products, Ltd. Hong Kong, China, All rights reserved. PRINTED IN CHINA
SECRET AGENT WALKIE TALKIES
™
with Hidden Microphone and Ear Bud Receiver
FCC INFO AREA
Fig 2.
Belt Clip
Battery Cover
Belt Clip
Release Tab
AAA
AAA
Belt Clip
(on back side)
Power Pack
Shirt Wire
Sleeve Wire
ON / OFF
Ear Bud Wire
Wrist Strap
Wrist Microphone
Microphone
Jack
Ear Bud
Receiver
Microphone
Plug
Strap Clasp
Fig 1.
EU Compliance :
This device complies with EU EMF Directive 1999/519/EC can be used in the European
Community.
“ Hereby, (Atomic Monkey Products Ltd.), declares that this device is in compliance with the
essential requirements and other relevant provisions of Directive 1999/5/EC.”
FCC Statement:
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:(1)This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired
operation.
Any Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will
not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
-Consult the dealer or an experienced radio/TV technician for help.
SAR Exemption Statement :
This device measured RF output power is less than the SAR exclusion threshold value for
human head and body. Therefore, SAR test is not necessary.
