AUDIO TECHNICA MODEL ATW-3000
UHF WIRELESS MICROPHONE SYSTEM
USER INFORMATION.
INTRODUCTION
Thank you for purchasing the ATW-3000 series wireless microphone system. It is our hope that the system
will bring you years of trouble free pleasure and performance. Please follow the information contained in this
manual closely as it will assist you in using your equipment effectively.
PART1. REGULATORY REQUIREMENTS.
FCC PART 15 COMPLIANCE STATEMENT
CANADA RSS-210 COMPLIANCE STATEMENT
“This device complies with Part 15 of the FCC rules. Operation is subject to the condition that this device
does not cause harmful interference”
“This device complies with INDUSTRY CANADA R.S.S. 210, en confomite avec IC: RSS-210/CNR210.
Operation is subject to the following conditions: (1) This device may not cause harmful interference and
(2) This device must accept any interference received, including interference which may cause undesired
operation.”
NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized
modifications to this equipment. Such modifications could void the user’s authority to operate this
equipment.
Please note that your ATW-30000 system operates in a frequency band in a way which may make its use
subject to certain FCC and other regulatory agency restrictions and licensing requirements. For further
information, Please contact your local office of the FCC as applicable.
PART 2. USING THE ATW-T310 BELTPACK TRANSMITTER
The beltpack transmitter operates on 2 “AA” batteries. Please make sure that your batteries are fresh.
We recommend that you use Alkaline batteries and that you avoid using NiCad if possible.
Open the battery door by slide door lock towards arrow direction and lift door.
Insert the batteries into the battery compartment and close the battery door
Slides the LCD set up buttons cover down to bottom
Push and hold the power switch and turn the ATW-T310 on
Push the set button once
Using up or down arrow buttons and scrolls the menu until frequency menu appeared.
If current frequency setup appeared on the LCD is not the same as corresponding receiver frequency, push
set button once.
Push down or up arrow button and set frequency to the corresponding frequency as set on receiver.
Push and hold set button until word “Stored” displayed in a while.
Push up or down arrow button and scrolls the menu until input menu (MIC or INSTRUMENT) appeared.
If current input setup appeared on LCD screen is not correct, push set button once
Using up or down arrow button to select input.
Push and hold set button until word “Stored” displayed in a while.
Connect your microphone or guitar cable to the connector on the top side of the transmitter. \
Confirm that the receiver is receiving RF and the audio is passing through the receiver.
Push up or down arrow button and scrolls the menu until “ESCAPE” appeared
Push the set button once to return default menu
You are now set to use the system.
PART 3. USING THE ATW-T341 HANDHELD TRANSMITTER
The handheld transmitter operates on 2 “AA” batteries. Please make sure that your batteries are fresh.
We recommend that you use Alkaline batteries and that you avoid using NiCad if possible.
Hold the bottom grip and turn the top grip counter clockwise until bottom grip free to slide.
Slide the bottom grip, insert the batteries into the battery compartment and slide the battery compartment
back into place.
To change the frequency of operation, push and hold power /mute button located on bottom of transmitter
to turn it on.
Unscrew the battery cover and pull the cover back.
Push the set button once
Using up or down arrow button and scrolls the menu until frequency menu appeared.
Push the set button once.
Push down or up arrow button and set frequency to the corresponding frequency as set on receiver.
Push and hold set button until word “Stored” displayed in a while.
Push up or down arrow button and scrolls the menu until “ESCAPE” appeared
Push the set button once to return default menu
You are now set to use the system.
PART4. USING THE ATW-R310 RECEIVER
Connect the AC adapter DC output connector to The ATW-R310 DC input jack
Plug the 2 blades AC plug on AC adaptor AC cable to an 110V AC outlet.
Push the on off switch. Confirm that the backlight on LCD screen comes on. Check the frequency setting to
confirm that they correspond to the settings of the transmitter
If not, push and hold set button until frequency only displayed on LCD
Push set button once and check that frequency displayed on LCD brink.
Push up or down arrow button to set receiver frequency to corresponding transmitter frequency.
Pus set button once to set frequency.
Push up or down arrow buttons to scrolls menu until VR and percent figures appeared
If it not set to the VR 100%, push set button once and check that item displayed on LCD brink
Push up arrow button to set it to maximum.
Push set button once to set
Push and hold Set button until LCD displayed “DEF” in a while
Connect the balanced or unbalanced audio output to your mixer or PA system. Adjust the Volume setting to
the desired level. Speak into the microphone and listen to the audio out at the speaker. If satisfied with the
audio quality, you ca use the system.
