AUDIO TECHNICA MODEL AEW-5200, AEW-4100 SERIES
UHF WIRELESS SYSTEM
USER INFORMATION.
INTRODUCTION
Thank you for purchasing the AEW -5200, AEW -4100 series wireless system. It is our hope that the system
will bring you years of trouble free pleasure and performance. Please follow the information contained in this
manual closely as it will assist you in using your equipment effectively.
PART1. REGULATORY REQUIREMENTS.
FCC PART 15 COMPLIANCE STATEMENT
CANADA RSS-210 COMPLIANCE STATEMENT
“This device complies with Part 15 of the FCC rules. Operation is subject to the condition that this device
does not cause harmful interference”
“This device complies with INDUSTRY CANADA R.S.S. 210, en confomite avec IC: RSS-210/CNR210.
Operation is subject to the following conditions: (1) This device may not cause harmful interference and
(2) This device must accept any interference received, including interference which may cause undesired
operation.”
Please note that your AEW -5200, AEW -4100 systems operates in a frequency band in a way which may
make its use subject to certain FCC and other regulatory agency restrictions and licensing requirements. For
further information, Please contact your local office of the FCC as applicable.
NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR
TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS
TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE
USER'S AUTHORITY TO OPERATE THE EQUIPMENT.
PART 2. USING THE AEW-T1000 BELTPACK TRANSMITTER
The beltpack transmitter operates on 2 “AA” batteries. Please make sure that your batteries are fresh.
We recommend that you use Alkaline batteries and that you avoid using NiCad if possible.
Open the battery door by slide door lock towards arrow direction and lift door.
Insert two batteries into the battery compartment and close the battery door
Slides the LCD set up buttons cover down to bottom
Push and hold the power switch and turn the AEW -T1000 on
Push the set button once
Using up or down arrow buttons and scrolls the menu until frequency menu appeared.
If current frequency setup appeared on the LCD is not the same as corresponding receiver frequency, push
set button once.
Push down or up arrow button and set frequency to the corresponding frequency as set on receiver.
Push and hold set button until word “Stored” displayed in a while.
Push up or down arrow button and scrolls the menu until input menu (MIC or INSTRUMENT) appeared.
If current input setup appeared on LCD screen is not correct, push set button once
Using up or down arrow button to select input.
Push and hold set button until word “Stored” displayed in a while.
Connect your microphone or guitar cable to the connector on the top of the transmitter.
Confirm that the receiver is receiving RF and the audio is passing through the receiver.
Push up or down arrow button and scrolls the menu until “ESCAPE” appeared.
Push the set button once to return default menu.
You are now ready to use the system.
PART 3. USING THE AEW-T5000SERIES HANDHELD TRANSMITTER
AEW -T5000 transmitter family is as follows:
AEW -T5400
AEW -T3300
AEW -T6100
AEW -T4100
The handheld transmitter operates on 2 “AA” batteries. Please make sure that your batteries are fresh.
We recommend that you use Alkaline batteries and that you avoid using NiCad if possible.
Hold the bottom grip and turn the top grip counter clockwise until bottom grip free to slide.
Slide the bottom grip, insert two batteries into the battery compartment and slide the battery compartment
back into place.
To change the frequency of operation, push and hold the power /mute button located on bottom of the
transmitter to turn it on.
Unscrew the battery cover and pull the cover back.
Push the set button once
Using up or down arrow button and scrolls the menu until frequency menu appeared.
