Augury Systems AC00009 Vibration sensor User Manual
Augury Systems LTD. Vibration sensor Users Manual
Users Manual
Endpoint 3XS
Assembled product Model No.: AC00009
Sub-assembly part No.: SA00005
(Part of APUS* the Augury Continuous Monitoring System)
*Temporary name
Technical Datasheet
Revised 11/05/2017
Endpoint-3XS Cat NO. AC00009
General description:
The Augury Endpoint 3XS is a smart wireless vibration, temperature, and magnetic sensor. The
Endpoint-3XS enables real-time continuous health monitoring of rotating machinery. The Endpoint
is part of the Augury continuous monitoring solution system giving a comprehensive picture of the
machinery status for enhanced operations, reliability and maintenance practices. The endpoint it
connects via BLE to the Augury Gateway and sends critical information about the machine for the
Augury analytics and and monitoring APPs.
Accelerometer
Value
Number of sensors
Tri-Axial
Sensitivity
Measurement range
±50g
Dynamic Range
Repeatability
Temperature dependence
Noise floor
Low power Accelerometer
Value
Number of sensors
Tri-Axial
Dynamic Range
Sensitivity
Noise floor
Magnetic Sensor
Value
Sensitivity
Measurement range
Dynamic Range
Repeatability
Frequency accuracy
Temperature Sensor
Value
Temperature Range
-40 ~ 125 (-40 ~ 257 )
Temperature Accuracy
±1 (±1 )
Temperature sensitivity
Wireless specification
Value
Radio
2.4 GHz
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications to this equipment not expressly approved by the party
responsible for compliance (Augury Systems Ltd.) could void the user’s authority to
operate the equipment.
To comply with FCC and IC RF exposure compliance requirements, the device should be
located at a distance of at least 20 cm from all persons during normal operation. The
antennas used for this product must not be co-located or operated in conjunction with
any other antenna or transmitter.
This device complies with FCC Rules Part 15 and with Industry Canada license-exempt
RSS standard(s). Operation is subject to two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference that may be
received or that may cause undesired operation.
Environmental Specifications
Value
Operating Temperature Range
-40～85 (-40～185)
Safety
UL 94-V0
Sealing
IP67
Hazardous environment
Atex zone 0 class 1 div 1
(Equivalent Ex I M1 Ex ia I Ma and Ex II 1 G Ex ia IIC T3
Ga)
Solvent resistant
Contact temperature
Up to 110 (230)
Compliance
CE, IEC
Electrical Specifications
Value
Battery type
Primary lithium-thionyl chloride (Li-SOCl2), C size with
connector - Use only Augury Batters
Battery voltage
3.6V
Battery capacity
8.5Ah
Operating time
3Y (Depending on sample cycle)
Memory
2 days of full vibration sample (depending on sampling
cycle)
Mechanical Specifications
Value
Size
49mm × 49mm × 85mm (1.92” × 1.92” x 3.34”)
Weight
185 gr (6.52 Oz)
Case material
Anodized Aluminum, reinforced polyamide (V0)
Mounting
Augury Stainless steel stud
