Aukey E Business EP-B52 Bluetooth Headset User Manual EP B52 06 19 02
SHENZHEN AUKEY E BUSINESS CO., LTD. Bluetooth Headset EP B52 06 19 02
User Manual
Thank you for purchasing the AUKEY EP-B52 Foldable On-Ear Wireless Headphones. Please
read this user manual carefully and keep it for future reference. If you need any assistance,
please contact our support team with your product model number and Amazon order number.
Package Contents
Foldable On-Ear Wireless Headphones Micro-USB Cable
3.5mm Audio Cable Carrying Case
User Manual Warranty Card
Product Diagram
Specifications
Getting Started
Fully charge your headphones before first use. To charge, simply connect one end of the
included micro-USB cable to a USB charging port and the other end to the input port on the
headphones. When the red charging indicator light turns off, your headphones are fully charged
and ready for use. Charging takes around 3 hours.
Turning On / Off
● To power on, press and hold the multi-function button for 1 second, and the LED indicator
will flash blue 3 times
● To power off, press and hold the multi-function button for 3 seconds, and the LED indicator
will flash red twice
Pairing
Starting with the headphones powered off:
1. Press and hold the multi-function button for 1 second or until the LED flashes blue. The
headphones will automatically enter pairing mode, with the LED flashing red and blue
alternately, after a moment. To avoid automatic connection to a previously paired device,
press and hold for 4 seconds to manually enter pairing mode instead
2. Turn on the pairing function of the device you want to pair with the headphones
3. In the list of available devices, find and select “AUKEY EP-B52”. When connected, the LED
indicator will flash blue once every 5 seconds
4. If a code or PIN is required for pairing, please enter “0000”
Simultaneous Connection with Two Devices
1. Follow the instructions in the “Pairing” section to pair the headphones with Device A
2. Once paired, disable wireless function on Device A
3. Repeat steps 2 and 3 from the “Pairing” section to pair with Device B
4. Once paired with Device B, reactivate wireless function on Device A and select “AUKEY
EP-B52” in the list of paired devices
5. You can now make and receive calls from either of the two paired devices
Notes
● To pair with a new phone when switching on the headphones, press and hold the multi-
function button for 4 seconds or until the LED flashes red and blue alternately (if headphones
are already on, just disconnect the currently connected device). Then repeat steps 2 and
3 from the “Pairing” section
● The headphones will automatically exit pairing mode after 5 minutes if no devices are
paired. Then the LED indicator will flash blue once every 2 seconds and the headphones
will automatically shut down after 5 minutes
● If your paired device is turned off or disconnected, the headphones will automatically
Model
Diaphragm Diameter
Technology
Sensitivity
Frequency Response
Impedance
Battery Life
Charging Time
Charging Input
Battery
Operating Range
Cable Length
Connector
Dimensions
Weight
EP-B52
38mm / 1.5”
BT 4.1, A2DP, AVRCP, HSP, HFP
97dB ± 3dB
32Hz - 18KHz
32 ohm
18 hours
3 hours
DC 5V
Li-Polymer (320mAh)
Up to 10m / 33’
1.2m / 3.94’
3.5mm stereo jack
173 x 183 x 78mm / 6.81” x 7.2” x 3.08”
286g / 10.09oz
enter pairing mode (with the LED indicator flashing red and blue alternately)
● If the headphones exceed the wireless operating range of 33ft, they will disconnect from
your device and flash blue once every 2 seconds. The connection to the last successfully
connected device will be re-established once you re-enter wireless range within 5
minutes. To connect to other devices, please repeat the previous “Pairing” steps
Playing Audio via Audio Input Connection
Connect the EP-B52 to your PC, laptop, or other device with audio output port using the
included 3.5mm audio cable (with the microphone unit nearest the headphones). The
volume +/- and the multi-function button on the headphones are disabled in this wired
mode. Use the button on the cable microphone unit to play/pause or skip to the next
track (and manage calls if connected to a phone). For other playback controls, use your
device. Cable button doesn’t operate on PCs and laptops.
Controls & LED Indicators
Making Calls
Streaming Audio
Once paired, you can wirelessly stream audio from your device to the headphones. Music
will automatically pause when you receive an incoming phone call, and resume once the
call is ended.
FAQ
The headphones are on, but not connecting to my device
In order for both devices to establish a connection, you will need to put them in pairing
mode. Please follow the instructions in the “Pairing” section of this manual.
I have established a connection with my smartphone, but I’m not hearing any sound
Please double-check the volume level on your smartphone and the headphones. Some
smartphones require you to set up the headphones as an audio output device before
audio can be transmitted. If you are using a music player or other device, please make sure
it supports the A2DP profile.
The sound is not very clear or the caller cannot hear my voice clearly
Please adjust the volume on your smartphone and the headphones. Try getting closer to
your smartphone to rule out the possibility of interference or wireless range-related issues.
Can I use the headphones while they are charging?
No.
Answer / End a call
Adjust the volume
Redial last-called number
Reject an incoming call
Mute / Resume
Microphone switch
Phone switch
Play / Pause
Volume control
Next / Previous track
LED Indicator
Blue & red flashing alternately
Blue flashing once every 5 seconds
Blue flashing once every 2 seconds
Blue flashing twice every second
Red on
Red off (after charging)
Status
Pairing mode
Connected / Playing music / In call
Disconnected
Incoming call
Charging
Fully charged
Press the multi-function button once
Press the volume + / - once
Press and hold the volume + / - for 2 seconds
Press the multi-function button once
Press volume + / - once
Double-press the multi-function button when in standby
Long-press the multi-function button
Long-press volume - during a call
Press and hold volume + for 2 seconds during a call to
switch between the microphone and your phone for
talking
Double-press the multi-function button during a call to
switch between two mobile phones
Product Care & Use
● Keep away from liquids and extreme heat
● Do not use headphones at high volume for extended periods, as this may cause permanent
hearing damage or loss
Warranty & Customer Support
For questions, support, or warranty claims, contact us at the address below that corresponds
with your region. Please include your Amazon order number and product model number.
Amazon US orders: support.us@aukey.com
Amazon EU orders: support.eu@aukey.com
Amazon CA orders: support.ca@aukey.com
Amazon JP orders: support.jp@aukey.com
*Please note, AUKEY can only provide after sales service for products purchased directly from AUKEY.
If you have purchased from a different seller, please contact them directly for service or warranty
issues.
Notice for US
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment. This device complies with Part 15
of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause
undesired operation
FCC Rules
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates uses and
can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
● Reorient or relocate the receiving antenna
● Increase the separation between the equipment and receiver
● Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected
● Consult the dealer or an experienced radio/TV technician for help
Caution
Changes or modifications made to this device not expressly approved by AUKEY may void
the FCC authorization to operate this equipment.
Volume - / Previous Track
Multi-Function Button
LED Indicator
Microphone
Micro-USB Charging Port
3.5mm Audio Input
Volume + / Next Track
- 01 - - 02 - - 03 - - 04 - - 05 - - 06 - - 07 -
User Manual
Foldable On-Ear Wireless Headphones
AUKEY International Ltd.
www.aukey.com | support@aukey.com
No.102, Building P09, Electronic Trade Center
Huanan City, Pinghu Town, Longgang District
Shenzhen, Guangdong, 518111, CN
Model: EP-B52
说明书制作说明：
尺寸：90*110mm 材质：105g铜版纸 印刷：单黑 装订方式：骑马钉
English
Deutsch
Français
Español
Italiano
01~07
08~13
14~19
20~25
26~31
32~37
Contents
日本語
FCC Warning
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
NOTE 1: Any changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.
