Aukey E Business SK-M36 Bluetooth speakers User Manual SK M36 EN
SHENZHEN AUKEY E BUSINESS CO., LTD. Bluetooth speakers SK M36 EN
Users manual
User Manual
Radius Wireless Speaker
AUKEY International Ltd.
www.aukey.com | support@aukey.com
No.102, Building P09, Electronics Trade Center
Huanan City, Pinghu Town, Longgang District
Shenzhen, Guangdong, 518111, CN
Model: SK-M36
English 01~06
Italiano 22~26
日本語 27~31
Deutsch 07~11
Français 12~16
Español 17~21
Contents
材质: 105g铜版纸
尺寸: 100x100 mm
印刷: 单黑双面印刷
装订方式: 骑马钉装
请不要把目录页放在封面的背面
- 01 - - 02 - - 03 - - 04 - - 05 - - 06 -
Thank you for purchasing the AUKEY SK-M36 Radius Wireless Speaker. Please read this user manual
carefully and keep it for future reference. If you need any assistance, please contact our support
team with your product model number and Amazon order number.
Package Contents
Radius Wireless Speaker
Micro-USB Cable
3.5mm Audio Cable
User Manual
Warranty Card
Product Diagram
Play / Pause
Volume + / Next Track
Volume - /
Previous Track
Mode Button
On/Off Button &
LED Indicator
Microphone
Specifications
Model
Technology
Audio Output Power
Frequency Response
Signal-to-Noise Ratio
Microphone Sensitivity
Input
Charging Time
Play Time
Talk Time
Battery Type
Operating Range
Operating Temperature
Dimensions
Weight
Micro-USB
Charging Port
Reset (inside
audio input)
Audio Input
SK-M36
BT 4.1, A2DP, AVRCP, HSP, HFP
10W
180Hz - 20kHz
>70dB
42dB ±3dB
DC 5V
4 hours
10 hours (at 50% volume)
8 hours
Li-ion (2200mAh 7.4V)
Up to 10m / 33ft
-10°C - 50°C / 14°F - 122°F
218 × 212 × 83mm / 8.58” × 8.34” × 3.27”
750g / 26.45oz
Charging
Please fully charge this speaker before first use. Connect it to a USB charger or charging port with
the included micro-USB cable to charge. When the red LED indicator turns off, your speaker is fully
charged and ready for use. Charging takes around 4 hours.
Powering On / Off
● To power on/off, press and hold the on/off button for 2 seconds, and the LED indicator will turn
blue / turn off
Pairing
1. When you turn on the speaker, it will automatically enter pairing mode and the LED indicator will
start to flash blue rapidly
2. Activate the pairing function on your phone or other compatible device and select “AUKEY
SK-M36”
3. If a code or pin is required for pairing, enter “0000”
4. When successfully paired, you will hear a tone and the LED indicator will stay on
Notes
● To reset the speaker (to clear program errors), use a straightened paper clip or a toothpick to
carefully short-press the reset button (towards the top at the back, furthest inside the 3.5mm audio
input jack)
● The speaker will automatically shut down after 10 minutes in pairing mode if no devices are paired
● If your paired device is switched off or manually disconnected, the speaker will enter pairing
mode and automatically shut down after 10 minutes
● If the speaker or connected device exceeds the operating range, the speaker will disconnect.
The connection to the last successfully connected device will be re-established once you re-enter
wireless range within 10 minutes. To connect to other devices, repeat the previous “Pairing” steps
Playing Audio via Audio Input Connection
Connect the SK-M36 to your PC, laptop, or other device with audio output port using the included
3.5mm audio cable. Press the on/off button to turn on, and the LED indicator will flash blue once
every 2 seconds.
Notes
● The speaker will disconnect from your phone or other paired devices when an audio cable is
plugged into the audio input jack. Short-press the mode button to switch back to BT mode
● When playing audio using the audio input jack, short-press the volume + / - to adjust the volume
and short press play/pause to pause or resume. Next / previous track control on the speaker is
disabled in audio input mode
● For some computers, you may need to access the audio control panel to manually set the speaker
as the default audio device
Controls & LED Indicator
Functions
Cancel pairing
Answer / End a call
Reject an incoming call
Redial last-called number
Adjust volume
Next / Previous track
Pause / Resume
Instructions
When connected, press and hold play/pause for
more than two seconds
Short-press play/pause
Press and hold play/pause for more than 3 seconds
Double-press play/pause in standby
Short-press volume + / -
Long-press volume + / -
Press play/pause once
LED Indicator
Blue flashing rapidly
Solid blue
Blue flashing once every 2 seconds
Red on
Red off (after charging)
Status
Pairing mode / Disconnected
Connected
Playing music / In call / Audio input mode
Charging
Fully charged
Product Care & Use
● Keep away from liquids, extreme heat, and strong magnetic fields
● Do not use this speaker at high volume for extended periods, as this may cause permanent hearing
damage or loss
Warranty & Customer Support
For questions, support, or warranty claims, contact us at the address below that corresponds with
your region. Please include your Amazon order number and product model number.
Amazon US orders: support.us@aukey.com
Amazon EU orders: support.eu@aukey.com
Amazon CA orders: support.ca@aukey.com
Amazon JP orders: support.jp@aukey.com
*Please note, AUKEY can only provide after sales service for products purchased directly from AUKEY. If you have purchased
from a different seller, please contact them directly for service or warranty issues.
Notice for US
Changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment. This device complies with Part 15 of the FCC
Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause
undesired operation
FCC Rules
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
● Reorient or relocate the receiving antenna
● Increase the separation between the equipment and receiver
● Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected
● Consult the dealer or an experienced radio/TV technician for help
Caution
Changes or modifications made to this device not expressly approved by AUKEY may void the FCC
authorization to operate this equipment.
