CamShow Remote For use with VK73A VGA Picture Sender
Model UR85A
UR85A-8/01
The CamShow Remote works with the VK73A CamShow system for situations where you want to have an additional
remote, or if you are replacing a lost or broken remote. The remote lets you access all the features of the CamShow
application from the comfort of your easy chair. It can also adjust the color, brightness, contrast, etc., of the picture sent
from the Picture Sender to the Receiver that you connect to your TV. See VK73A owner’s manual for more information.
1. Push the tab and lift off
the battery cover.
2. Insert four AAA alkaline
batteries, taking care to
match the + and - marks in
the battery compartment.
BUTTON DESCRIPTIONS
Indicator light
The indicator light flashes when you press any button.
Start
Launches the CamShow application.
A, B, C, D
Selects the four main functions of the CamShow
application.
Up, Down, Left, Right Arrows
Moves picture on screen.
OK
Selects a selection.
Zoom In/Zoom Out
Zooms in and out on the picture being displayed.
0-9
Enters picture numbers directly.
Forward/Backward
Selects direction to move through your picture album.
Page Up/Page Down
Goes to the next or previous page in your photo album.
Subtitles
Turns subtitles on and off.
Pa
g
e up
Forward
Backward Pa
g
e down
Subtitle
2
1
3
4
56
7
8
0
9
OK
A
BC
D
Start
1. Press A to List photo albums.
2. Press B to View thumbnail
views of the pictures in the
album you selected when you
pressed A.
3. Press C to Search through
collections of photos you have
grouped together.
4. Press D to access Help.
5. Press A to select an album,
then press B to view
thumbnail views of the
pictures in the album, then
press a number button
corresponding to the
thumbnail number of the
photo you want to view.
6. Moves forward and
backwards through
the selected album.
7. Moves through
your albums.
8. Zooms in and out
on the picture
being displayed.
™
F.C.C. CAUTION - THIS DEVICE COMPLIES WITH PART 15
OF THE FCC RULES. OPERATION IS SUBJECT TO THE
FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY
NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS
DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED,
INCLUDING INTERFERENCE THAT MAY CAUSE
UNDESIRED OPERATION.
NOTE: NO CHANGES OR MODIFICATIONS MAY BE MADE
TO THE UNITS. ANY CHANGES MADE TO THE UNITS
WILL VOID THE USER'S AUTHORITY TO OPERATE THE
EQUIPMENT.
LIMITED 1-YEAR WARRANTY
Please visit www.x10.com/warranty
to complete your on-line warranty registration. Thank you.
For help or more information on setup, please visit:
www.x10.com/support
