1. Refer to the setup and operating instructions that came
with the 2.4 GHz Video Receiver, Model VR30A (sold
separately) to set up the Receiver.
2. Mount the camera in a suitable location observing the
direction arrow so the camera is the right way up. If
you install it outdoors, run the small cable adapter
through a hole in the wall so you can plug the power
supply into an AC outlet indoors.
3. Plug the power supply’s jack into the adapter cable on
the camera.
4. Plug the power supply into any 120V AC outlet.
5. Set the channel switch on the camera to the same setting
as the one on the VR30A Video Receiver.
6. Adjust the antenna on the camera if necessary to aim
it in the direction of the VR30A Video Receiver that
you have connected to your TV or monitor.
X10 (USA) INC. LIMITED 1-YEAR WARRANTY
X10 (USA) Inc. warrants X10 products to be free from
defective material and workmanship for a period of one (1)
year from the original date of purchase at retail. X10 (USA)
Inc. agrees to repair or replace, at it’s sole discretion, a
defective X10 product if returned to X10 (USA) Inc. within
the warranty period and with proof of purchase.
If service is required under this warranty:
1. Call 1-800-675-3044 or e-mail sales@x10.com for
details on how to return your unit(s).
2. Enclose a check for $4.00 to cover postage and
handling.
3. Enclose a dated proof of purchase.
4. X10 is not responsible for shipping damage.
Units to be returned should be packed carefully.
5. For additional warranty information, contact X10.
X10 (USA) Inc. 1-800-675-3044 sales@x10.com
●Extremely small size.
●Built-in 2.4 GHz Video Sender.
●Powered from a plug-in power supply (included).
●Use it outdoors to monitor your front door, back yard, etc.
●Use it indoors to monitor a child’s bedroom, etc.
Model XX10A
XX10A-10/99
The XX10A is a very small and compact color video camera with built-in 2.4 GHz Video Sender. It is powered
from a plug-in power supply (included). You can attach it to that wall anywhere you want to monitor. The XX10A
transmits video and sound to the VR30A 2.4 GHz receiver (sold separately) which is connected to your TV located
somewhere else in your home (up to 100 ft. away).
XCam Anywhere Indoor/Outdoor Color Video Camera
Adjust antenna.
Plug power
supply in here.
Important:
Unplug power
supply before
unplugging
power jack.
XX10A
™
(with built-in 2.4 GHz transmitter)
2
4
Plug into
any AC
outlet
Attach the
to a wall.
5
3Cable adapter.
6
Set channel
switch to
match setting
on VR30A
Receiver.
F.C.C. CAUTION - THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING
TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT
ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. NOTE: NO
CHANGES OR MODIFICATIONS MAY BE MADE TO THE UNITS. ANY CHANGES MADE TO THE UNITS WILL VOID THE
USER'S AUTHORITY TO OPERATE THE EQUIPMENT.
Outdoors
Indoors
