DOC.1.00 DL Lp May 4, 2007 Manufactured in Canada by Autostart
AUTOMATIC TRANSMISSION MULTI-CHANNEL REMOTE STARTER SYSTEM
AS-1221 / AS-1222
User Guide
WARNING
It is the responsibility of the vehicle operator to ensure
their vehicle is parked in a safe and responsible manner.
1. When leaving the vehicle, it is the user’s
responsibility to ensure that the gearshift lever is in
“Park” in order to avoid accidents upon remote starting.
2. It is the user's responsibility to ensure that the remote
starter is disabled or put into valet mode before
servicing.
INDUSTRY CANADA USER NOTICE:
Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must
accept any interference, including interference that may cause undesired operation of the device.
To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent
isotropically radiated power (EIRP) is not more than that required for successful communication.
FCC USER NOTICE (U.S.A.):
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may
not cause harmful interference, and (2) this device must accept any interference received, including interference that may
cause undesired operation.
NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this
equipment. Such modifications could void the user's authority to operate the equipment.
P. 2 User Guide
Table of contents
Introduction .......................................................2
Vehicle Presets .................................................2
Heater and Heated Seat ...............................2
Windshield Wipers, Radio and Headlights....2
Remote-starting Your Vehicle ...........................3
Remote-starting ............................................3
Driving Off.....................................................3
Remote Starter Features...................................3
Idle Mode ......................................................3
Valet Modes ..................................................3
Panic Mode...................................................4
Cold Weather Mode ......................................4
Advanced Features: Installation-programmable
options...............................................................4
Arming the Starter Kill...................................5
Remote Door Locks ......................................5
Ignition-controlled Door Locks Option ..........5
Secure Lock Option ......................................5
Remote Trunk Release Option .....................6
Starter Kill / Anti-Grind.................................. 6
Engine Run Time .......................................... 6
Troubleshooting Poor Transmitting Range Issues
..........................................................................6
LIMITED LIFETIME WARRANTY ....................7
Introduction
This Module is a state-of-the-art remote car starter system. With many advanced function,
this product will satisfy any one of the user’s expectations from high-end commodity systems,
without neglecting the standard features commonly offered by entry-level starters.
Please note:
Button Ι is for START (by default).
Button ΙΙ is for STOP (by default).
Buttons Ι & ΙΙ (together) is for the TRUNK release function.
The LED is NOT included in this model.
The valet button is optional.
Vehicle Presets
Heater and Heated Seat
When leaving the vehicle it is recommended to preset the accessory controls in preparation
for the next remote start. Settings for the blower motor (fan), front and rear, as well as
heated seats (if equipped) should not be left on HIGH. It is recommended to leave the settings
on LOW or MEDIUM instead.
Windshield Wipers, Radio and Headlights
Certain vehicles require the radio and / or windshield wiper and / or headlight circuits to
become energized while running under remote start. When leaving the vehicle you must
ensure that the windshield wiper and headlight switches are OFF. Leaving the headlight
switch on on certain types of vehicles could cause them to remain on even after the remote
starter shuts down, resulting in a dead battery.
Transmitter Part Number: AS-2402
Receiver Part Number: SH 433-110
User Guide P. 3
Remote-starting Your Vehicle
Remote-starting
Press the Ι button for approx. 1 second. The parking lights will come on, informing you that
the unit has received your signal. Approx. 5 seconds later, the engine will start. The parking
lights will remain on during the pre-programmed run time.
If the vehicle doesn’t start the first time, the system will shut down, wait a few seconds, and
try to start the engine again. It will try to start the engine 3 times before giving up.
Driving Off
Enter the vehicle and do the following:
• Turn the ignition key to the IGNITION ON (RUN) position.
• Press the brakes to disengage the remote starter unit.
You are now ready to drive off.
Note: Press button Ι to DISARM the module and to UNLOCK the doors (if button Ι is
programmed as LOCK or UNLOCK button).
Caution: do not turn the key to the CRANK position with the engine running. This will cause
the starter motor to re-engage, unless your vehicle is equipped with the Start Kill / Anti-
Grind Feature (Optional).
Remote Starter Features
Idle Mode
This feature allows the user to engage the remote starter to take over the vehicle while it is
already running with the key in the IGNITION switch. The vehicle will keep running for the pre-
programmed run time, or until it is shut down by remote.
Caution: Do not leave children or pets unattended in a car running in Idle Mode.
To activate Idle Mode:
To enable Idle Mode, press and hold button Ι on your remote transmitter while the engine is
running.
Note: When enabling Idle Mode, pressing button Ι will automatically unlock the doors (if
button Ι is programmed as LOCK or UNLOCK button.)
The parking lights will come on. Remove the key, exit the vehicle and lock the doors (if
desired). The engine will continue running and will turn itself OFF when the pre-programmed
run time expires.
Valet Modes
Ignition Valet
The system can be placed in Valet Mode to disable the remote starting capabilities. If the
vehicle needs to be serviced, or if you park it indoors, Valet Mode will prevent the engine
from being accidentally started by remote control.
To ENTER Valet Mode
1. With the key in the Ignition switch, turn the key to the ON (RUN/IGNITION) and then OFF
positions 5 times within 10 seconds.
2. The Parking Light will flash 3 times indicating the Module is now in Valet Mode.
The LED will turn on solid
To EXIT Valet Mode
1. With the key in the Ignition switch, turn the key to the ON (RUN/IGNITION) and then OFF
positions 5 times within 10 seconds.
P. 4 User Guide
2. The Parking Light will flash twice indicating the Module is now out of Valet Mode.
The LED will turn OFF.
Valet Mode Using the Valet Button
(Available only of the plug-in Valet switch is installed)
To put the system into Valet Mode:
1. Turn the key to the IGNITION ON (RUN) position.
2. Press (for at least 1 second) and release the Valet Button. The parking lights will
flash 3 times and then turn the key to IGNITION OFF position. The L.E.D. will come on.
To take the system out of Valet Mode:
1. Turn the key to the IGNITION ON (RUN) position.
2. Press (for at least 1 second) and release the Valet Button. The parking lights will
flash twice and the L.E.D. will go OUT.
The Valet button can only be used if the vehicle keys are in the IGNITION ON (RUN) position.
Panic Mode
Note: Panic mode can only be activated if the horn has been adequately configured
by your installer and if button Ι is programmed as LOCK or UNLOCK button.
In an emergency situation, you can activate panic mode using the Ι button. This will:
• shut down the engine,
• unlock the doors (with the Ι button)
• or lock the doors (with the Ι button),
• disarm the Starter Kill and
• activate the horn for 25 sec.
Note: See the description of the starter kill option later in this Guide.
To activate panic mode:
• Press and hold the Ι, button for approximately 3 sec. until the sound signal starts and
the parking lights flash: this will unlock the doors before the sound signal starts.
• Or press and hold the Ι, button for approximately 3 seconds until the sound signal
starts and the parking lights flash: this will lock the doors before the sound signal
starts.
Panic Mode will automatically shut down after 25 sec.
Note: To stop panic mode before the end of its delay, press the Ι button until the sound
signal stops.
Cold Weather Mode
When Cold Weather Mode is active, the engine starts every 2 hours and runs for 3 minutes
(or for 20 minutes with Diesel engines); the routine goes on for a period of 24 hours.
To enter Cold Weather Mode:
• Press and hold button ΙΙ until the parking lights flash 3 times.
To exit Cold Weather Mode, do any one of the following:
• Open the hood.
• Start the engine using the remote control.
• Turn the ignition key to the IGNITION ON (RUN) position.
• Press and hold button ΙΙ for 3 seconds
(until the parking Lights flash once)
• Set the vehicle to Valet Mode.
Advanced Features: Installation-programmable options
The system was designed with flexibility and OEM integration in mind. With its programmable
options, this unit can control nearly any electrical system in your vehicle.
User Guide P. 5
Note: The programming of these features should be left to a professional. Changing any
one of the settings may adversely affect the operation the Module.
Arming the Starter Kill
Note: Can only be activated if button Ι is programmed as LOCK or UNLOCK button.
If installed, the Starter Kill can be programmed to arm in Active Mode (will not arm
automatically) or in Passive Mode (will arm automatically).
• To disarm the Starter Kill in Active or Passive Mode, press button Ι on the transmitter. The
parking lights will flash twice. (If Remote Door Locks were installed, this will also unlock
the doors.) In Passive Mode, the system will automatically rearm 1 or 3 minutes after the
doors were unlocked.
• To arm the Starter Kill in Active or Passive Mode, press and hold button Ι on the
transmitter. The parking lights will flash once. (If Remote Door Locks were installed, this
will also lock the doors). In Passive Mode, the system will automatically arm 1 or 3 minutes
after the engine is shut down.
Remote Door Locks
Note: Can only be activated if button Ι is programmed as LOCK or UNLOCK button.
If your system was installed with the Remote Door Locks option, you will have the
convenience of remote keyless entry.
To LOCK your doors and ARM the Starter Kill:
1. Press and hold button Ι for approx. 1 sec.
2. The parking lights will flash once and the L.E.D. will flash slowly to confirm that the
doors have been locked and that the Starter Kill feature is enabled if it was
installed.
To UNLOCK your doors and DISARM the Starter Kill:
1. Press and hold button Ι for approx. 1 sec.
2. The parking lights will flash twice and the L.E.D. will go out to confirm that the
doors have been unlocked and that the Starter Kill feature is disarmed if it was
installed.
Note: If installed and configured in Passive Mode at installation, the Starter Kill feature will
rearm automatically 60 seconds after the doors are unlocked. For that reason, you may
have to unlock your doors a second time if some time elapses before you actually start
the engine.
Ignition-controlled Door Locks Option
This is an added security feature. If your system was installed with the Ignition-controlled
Door Locks option, the doors will automatically be locked as soon as the user presses the
brakes while the ignition key is in the IGNITION ON (RUN) position.
When the key is turned to the Ignition OFF position, the doors will automatically be unlocked.
(Only available if remote Door Lock Option is installed)
Secure Lock Option
Before it can remote-start your vehicle, the module must first disarm the factory security
system.
The Secure Lock feature may be required on certain vehicle models with factory security
systems that automatically unlock the doors when the security system is disarmed.
To keep your vehicle protected when the factory security system is disarmed for a remote
start, Secure Lock will relock your doors as soon as the vehicle has started.
Once the engine run cycle ends, Secure Lock will rearm your factory security system.
P. 6 User Guide
Remote Trunk Release Option
If your system was installed with the remote trunk release, you can open your trunk by
pressing buttons Ι & ΙΙ simultaneously on the remote transmitter. Vehicles must have an
electric trunk switch or a remote trunk button on the vehicle’s OEM transmitter for this option
to be compatible with the module.
Starter Kill / Anti-Grind
This added security feature will immobilize your vehicle when the system is armed
(LOCKED). If your Module was installed with the Starter Kill option, you will not be able to
start your vehicle with the key unless the system has been disarmed first (UNLOCKED).
The Starter Kill option can be programmed to be ACTIVE (will not arm automatically) or PASSIVE
(will arm automatically). In PASSIVE Mode, your installer can program it to arm automatically in
1 minute. Note that in Mode 1- Function 3- Option 3, pressing button Ι will always give an
Unlock pulse during 1minute passive arming timeout.
Once the vehicle has been remote started, the Anti-Grind feature prevents the starter motor
from re-engaging when the ignition key is accidentally turned to the CRANK position.
Note: Automobile insurance companies sometimes offer a rebate for vehicles with a
passive starter kill device.
Engine Run Time
If you have a gas engine, your system can be programmed to run the engine for 3, 15, or 25
minutes (15 minutes by default). If you have a diesel engine, it can be programmed to run the
engine for 8, 20, or 30 minutes).
Troubleshooting Poor Transmitting Range Issues
Many factors may affect the operating range of the transmitter. Some of these are:
• The condition of the battery in the transmitter.
• The operating environment (for example: downtown radio-frequency noise, airports,
cellular phone towers…)
• Metal: any type of metal will affect operating range. This includes the metal in the car.
• The shape of the vehicle can affect range as well; vans in general have an especially poor
range.
• The shape of the roof and A-pillars brings about considerable radio-frequency deflection
(in this case the signal from the remote control). As a result, the direction in which the
vehicle is facing in relation to the remote control can affect the range. Straight on –
standing in front of the vehicle – generally gives you the greatest range; the second best
performance is from the back. Using the remote control from either side of the vehicle will
usually give the lowest range.
• The range will be significantly lower in a crowded parking lot than in open space.
• Always hold the transmitter high, approximately at shoulder height. Holding the transmitter
against your chin will also increase your range: your head acts as an antenna.
• The operating range will be somewhat lower on vehicles equipped with an aftermarket or
factory alarm.
• Windows and windshields tinted with lead or metallic tints will decrease the operating
range.
User Guide P. 7
LIMITED LIFETIME WARRANTY
REMOTE STARTERS:
As the manufacturer, 160031 Canada Inc. (“Autostart”) warrants to the original consumer purchaser only (non-transferable) that
the remote starter module (control box) shall be free from defects in materials and workmanship for as long as the original
consumer purchaser continuously owns the vehicle in which the remote starter was originally installed, as specified below:
• 1) For the first year after the date of manufacture, as specified by the serial number on the module,
Autostart will replace the remote starter module free of charge with a new remote starter module.
2) For the second year after the date of manufacture, as specified by the serial number on the module, Autostart will
replace the remote starter module free of charge with a repaired or refurbished remote starter module.
3) For the third year and any consecutive year after the date of manufacture, as specified by the serial number on the
module, Autostart will provide to the original consumer purchaser a repaired or refurbished remote starter module,
for a repair charge of $35.00 plus applicable taxes.
In all cases, the consumer must return the remote starter module to the point of purchase, and must provide a copy of the proof
of purchase to said retailer. A remote starter module will be returned to the retailer for the consumer to claim within a 4 (four)-
week period. For case (3), a cheque in the amount of $35.00 plus applicable taxes must accompany the remote starter module,
or the retailer may refuse the return.
ACCESSORIES:
Autostart warrants to the original consumer purchaser only (non-transferable) that it will replace any Autostart accessory part
for a one-year period from date of purchase. Accessories will only be replaced if proven defective in material or workmanship,
and if, when the accessory is returned to the point of purchase, the retailer is provided with a copy of the proof of purchase. The
accessory will be sent to the retailer for the consumer to claim within a 4 (four)-week period.
THE WARRANTY IS VOID IF:
1) The product has been damaged, altered in any way or tampered with, without the explicit written
consent of an Autostart technician. For remote starter modules, this includes the opening or removal
of the plastic covering of the module, or the removal or alteration of the barcode label on the plastic
covering of the module.
2) The product is damaged due to accident, fire, flood, shipping and handling, misuse, neglect, or other
conditions beyond the control of Autostart.
3) The product has been installed or repaired by anyone other than a certified technician.
4) The product has been improperly installed or used.
THE WARRANTY DOES NOT COVER:
1) Batteries.
2) Scratched or worn transmitter cases.
3) Installation and/or removal charges for all remote starter modules and accessories.
4) Shipping and handling charges incurred for product exchange or replacement.
5) Any material damages other than to the product itself.
6) Harnessing, L.E.D. lights, switches, inverters, relays, etc.
THIS LIMITED LIFETIME WARRANTY SHALL CONSTITUTE THE SOLE LIABILITY OF AUTOSTART FOR OUR
PRODUCTS, AND IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED. THERE ARE NO
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. NO PERSON, FIRM OR
CORPORATION IS AUTHORIZED TO ASSUME FOR AUTOSTART ANY OTHER LIABILITY WITH RESPECT TO THE
SALE OR USE OF OUR PRODUCTS. AUTOSTART’S LIABILITY, WHETHER BASED ON CONTRACT, TORT,
WARRANTY, STRICT LIABILITY, OR ANY OTHER THEORY, SHALL NOT EXCEED THE PRICE OF THE
INDIVIDUAL UNIT WHOSE DEFECT FOR DAMAGE IS THE BASIS OF THE CLAIM. UNDER NO CIRCUMSTANCE
WILL AUTOSTART, ITS DISTRIBUTORS OR THEIR AGENTS BEAR ANY LIABILITY WHATSOEVER FOR
INCIDENTAL OR CONSEQUENTIAL DAMAGES.
The parties hereto elect that any dispute regarding the present document be submitted to the appropriate Court located in the
Province of Quebec, District of Montreal. The parties hereto agree that this document is governed by and interpreted in
accordance with the law of Quebec. If the purchaser is located in a province of Canada other than Quebec, all matters dealing
with the warranty of quality will be governed by and interpreted in accordance with the law of Ontario. If the purchaser is located
outside Canada, all matters dealing with the warranty of quality will be governed by and interpreted in accordance with the
United Nations Convention on Contracts for the International Sale of Goods (the “Vienna Convention”).
