Avantech Mobile CT7558 GSM 900/1800/1900 Mobile Phone User Manual Philips755 GB 4311 255 58341

Avantech Mobile GSM 900/1800/1900 Mobile Phone Philips755 GB 4311 255 58341

User Manual

Discover your phone

Philips continuously strives to improve its products.

Therefore, Philips reserves the rights to revise this user

guide or withdraw it at any time without prior notice.

Philips provides this user guide as is and does not

accept, except as required by applicable law, liability

for any error, omission or discrepancy between this

user guide and the product described. The device is

meant to be connected to GSM/GPRS networks.

Keypad

Microphone

Navigation &

keys

65,000 colours

touchscreen

camera key

on the side

key

(

Pick up key Hang up and

)

on/off key

Back of the phone:

camera lens

key

Stylus pen

How to...

Switch phone On/Off

Press and hold

)

Enter PIN code

Enter your PIN code using

the keypad and press

to confirm.

Make a call

Enter the phone number on

the keypad and press

(

dial.

Answer a call

Press

(

when your phone

rings.

Set conversation

volume

Press the navigation key

during the call.

End a call

Press

)

Reject a call

Press

)

Access the main

Press

in idle mode.

Access the

Contacts

Press

in idle mode.

Philips755_00_DiscoverYourPhone_GB.fm Page 1 Mercredi, 12. mai 2004 10:25 10

Warning! The stylus pen shipped with your product is

the only one to be used when tapping the touchscreen.

Do NOT use any other tool on the touchscreen.

Your mobile phone features a touchscreen, which is a

faster and more intuitive way of navigating through

lists and menus. It becomes available as soon as you

enter any of the available menus (it isn’t available

when in idle mode) and you operate it with the stylus

located on the side of your phone. Double tap a

Use the

Contacts

Browse the list by

moving

and

press

(

to call the selected

name.

Access the

Call list

Press

in idle mode.

Go to previous menu

Press

Quickly return

to idle when

browsing menus

Press and hold

, or press

)

View the last call

made

Press

(

in idle mode.

Lock/Unlock the

keypad

Press and hold

when in

idle mode.

Access a function

in the menu

Press

, move

and

select a function, then press

to enter the sub-menu.

Repeat to reach the desired

function.

Quickly open the

Picture Album

Press the

Tag It !

key when in

idle mode. Then select a

picture and press

to tag

it.

Activate a

programmed

Voice command

Press and hold the

key.

Quickly send an

SMS

Press

in idle mode

(opens the names list for you

to select the recipient).

Activate the

Camera

Slide the camera door on the

back of the phone.

Launch

WAP

Long press

when in

idle mode.

Open the

Hotkeys

list

Long press

when in

idle mode.

Touchscreen

Philips755_GB_4311 255 58341.book Page 2 Mardi, 11. mai 2004 11:02 11

menu/icon to enter/activate it, and then simply apply

a reasonable pressure, as if you were writing on paper.

You will not always be able to use the touchscreen, as

in some cases, it will not replace the keys for

interaction.

As shown opposite, clickable areas in

lists and menus will soon become

familiar and will allow you, with the

stylus pen, to select an item, move up/

down, select items, etc.

In most contexts, an

arrow

in the upper right

corner of the screen or a

red cross

together with

a warning allows you to cancel the last action or go

back one level. The

green check mark

icon will let you validate your choice or action. Using

these touchscreen items are similar to pressing the

keys on the keypad.

An on-screen keyboard will appear in

all text edition contexts when

entering your PIN code, typing a

message (SMS, EMail, MMS, etc.),

entering a name in the phonebook,

etc. This allows you to enter text using the stylus pen,

like you would do on a PC keyboard. Using the stylus

is equivalent to pressing the actual keys of the phone.

The matrix is the graphic representation of the menus,

featuring the icons. Each icon represents a feature or

operation of your phone. You access the matrix by

pressing

when in idle mode. Then use the stylus

pen or the navigation key to select or activate a menu

or option, and press

to cancel.

Pressing

will alternate between two

options, such as Activate/Deactivate, On/Off,

Increase/Decrease a value, etc.

Browse menus and lists until you reach the desired

feature or option. When navigating in a list, a scroll

On screen keyboard

Matrix

Philips755_GB_4311 255 58341.book Page 3 Mardi, 11. mai 2004 11:02 11

bar located on the right hand side of the screen shows

your actual position in the list. With the stylus and the

navigation key, you can then select or adjust all the

functions of your phone as described in the relevant

chapter of this user guide.

Some events may modify the idle screen (missed call,

new message, etc.). Press

to access the

corresponding menu or

to go back to the idle

screen.

Events

Philips755_GB_4311 255 58341.book Page 4 Mardi, 11. mai 2004 11:02 11

Table of contents i

Table of contents

1. Getting started ............................................1

Insert the SIM card ...........................................1

Switch on the phone ........................................2

Set date and time ..............................................2

Copy the SIM phonebook ...............................2

Calibration ..........................................................2

Charge the battery ...........................................2

2. Main features ................................................4

Access and view the phonebook ...................4

Make a call ..........................................................4

Answer and end a call ......................................4

Tag and send pictures ......................................4

QuickCall ............................................................5

TV slideshow ......................................................5

Take a picture ....................................................5

Navigation icon ..................................................5

Fotocall: see and hear who’s calling ..............6

Foto Talk: send voice clips with pictures ....6

Call handsfree ....................................................6

Change the ringer .............................................7

Activate the silence mode ..............................7

Activate the vibra alert ....................................7

Read your mobile phone number .................7

Adjust the earpiece volume ...........................7

Mute the microphone ......................................7

Unmute the microphone ................................7

Clear the call list ...............................................8

Clear the SMS list .............................................8

Record a conversation ....................................8

Clear the phonebook ......................................8

Quickly scroll a list ...........................................8

3. Menu tree .......................................................9

4. Text or number entry .........................12

T9® Text input .............................................. 12

Basic text input ............................................... 13

5. Taking pictures ......................................... 14

How to... .......................................................... 14

Pictures shots ................................................. 14

Settings ............................................................. 17

6. BeDJ ................................................................ 19

How to... .......................................................... 19

Getting started ............................................... 19

Record a mix .................................................. 20

Create your own style and mix ................. 21

Save your own styles .................................... 22

Philips755_GB_4311 255 58341TDM.fm Page i Jeudi, 13. mai 2004 11:02 11

Receive a call ................................................... 22

7. Contacts .......................................................23

Settings .............................................................23

Add contacts in a phonebook ..................... 24

Fotocall: see & hear who’s calling ..............24

Edit and manage contacts .............................25

8. Settings .......................................................... 27

Sounds ..............................................................27

Display ..............................................................28

Short cuts ........................................................ 29

Security ............................................................. 31

Calibration .......................................................32

Network ..........................................................32

Time and date .................................................33

Language ...........................................................34

Profiles ..............................................................34

9. Messages .......................................................36

SMS .................................................................... 36

E-Mail ................................................................ 39

SMS chat ...........................................................44

Broadcast SMS ................................................ 44

Quick message ................................................ 44

MMS .................................................................. 45

10. Infrared .......................................................50

Position of devices ......................................... 50

Send data ......................................................... 50

Receive data .................................................... 50

11. Multimedia ................................................ 52

Sound album ................................................... 52

Picture album .................................................. 52

TV Slideshow .................................................. 55

Memory status ................................................ 56

Demo mode ....................................................56

Sound recording ............................................. 56

BeDJ .................................................................. 56

12. Games & Applications ...................... 57

Euro converter ............................................... 57

Calculator ........................................................ 57

Alarm clock ..................................................... 57

Organiser ......................................................... 57

JAVA ................................................................. 59

Brick game ....................................................... 59

13. Call information .................................... 60

Call settings ..................................................... 60

Call list .............................................................. 61

Call counters .................................................. 62

14. Operator services ............................... 64

WAP ................................................................. 64

DTMF tones ....................................................66

Make a second call ......................................... 67

Philips755_GB_4311 255 58341TDM.fm Page ii Jeudi, 13. mai 2004 11:02 11

iii

Answer a second call ....................................67

Answer a third call .........................................67

Conference call ...............................................68

Explicit call transfer .......................................68

Icons & symbols .............................................69

Troubleshooting ........................................... 70

Precautions ....................................................... 73

Philips authentic accessories .................76

Philips755_GB_4311 255 58341TDM.fm Page iii Jeudi, 13. mai 2004 11:02 11

Getting started 1

1 • Getting started

Read the safety instructions in the «Precautions» section

before use.

To use your phone, you must insert a valid SIM card

supplied by your GSM operator or retailer. The SIM

card contains your subscription, your mobile number,

and memory in which you can store phone numbers

and messages (see “Contacts” page 23).

Push the release button as shown below and

remove the battery cover.

Insert the SIM card: first slide it under the left

plastic part until it stops, then push the metal

clip holder until it maintains the card.

Be careful that the clipped corner of the card is

in the correct corner.

Slide the battery door into its slot, metallic

connectors downwards, until it stops. Then lock

it by pushing it downwards.

Replace the back cover of your phone: hook the

front housing onto the hinges on the top of the

phone, then press the bottom down until the

latch catches.

Insert the SIM card

Philips755_GB_4311 255 58341.book Page 1 Mardi, 11. mai 2004 11:02 11

2Getting started

Remove the protective film covering the screens

and the camera lens before using the phone.

To switch on the phone, press the

)

key. Enter

the PIN code if required (i.e. the 4 to 8-digit secret

code of your SIM card). It is preconfigured and

communicated to you by your operator or retailer. To

personalise the PIN code, see page 43.

If you enter a wrong PIN code 3 times, your SIM card

is blocked. To unblock it, you must request the PUK

code from your operator.

As prompted by the phone at first switch on, set the

date by pressing the appropriate numeric keys (press

to erase a number), then set the time.

For complete date and time options, see page 46.

If at first switch on, if you do not copy the SIM

phonebook , see “Contacts select” page 23.

The mobile phone detects a SIM card that already

contains names and a message asks you if you want to

copy your SIM phonebook onto the built-in

phonebook. Press

to cancel or

to accept.

The phone phonebook is always set as your default

phonebook. To switch back to the SIM phonebook,

see “Contacts select” page 23.

This menu allows you to calibrate your screen, in

order to obtain a better accuracy when using it with

the stylus pen. Simply press

and follow the

instructions. You must press all three signs one after

the other to complete the process.

Your phone is powered by a rechargeable battery. A

new battery is partially charged and an alarm will warn

you when the battery reaches low. If the battery is

completely flat,it will take 2 or 3 minutes of charging

for its icon to reappear.

You may lose all your personal settings if you

remove

the battery when the phone is switched on.

Once the battery and battery cover are clipped

on the phone, plug the connector of the charger

Switch on the phone

Set date and time

Copy the SIM phonebook

Calibration

Charge the battery

Philips755_GB_4311 255 58341.book Page 2 Mardi, 11. mai 2004 11:02 11

Getting started 3

(supplied with the phone, in the box) into the

LEFT

hand socket at the base of the phone on

one end, then plug it into a main AC power

socket with easy access on the other end.

The battery symbol indicates the state of charge:

- during charging, the 4 charge indicators scroll;

Each bar represents around 25% of charge and

it takes around 1.45 hours to fully recharge

your mobile phone.

- when all 4 bars are steady the battery is fully

charged: disconnect the charger. Depending

on the network and condition of use, talk time

goes from 2 to 4 hrs and stand-by time from

200 to 400 hrs.

Keeping the charger plugged to the mobile when the

battery is fully charged doesn’t damage the battery.

The only way to turn off the charger is to unplug it, so

use an easily accessible AC power socket. You can

connect the charger to an IT supply (Belgium only).

Philips755_GB_4311 255 58341.book Page 3 Mardi, 11. mai 2004 11:02 11

4 Main features

2 • Main features

In idle mode, press

. Depending

on the selected phonebook (in SIM or

in phone, see “Contacts” page 23), the

content that appears on the screen may vary.

To view the phonebook during a call, press

and

select View Names List. Press

twice to return to

the in-call screen.

Press

, enter the first letters of the name you are

searching, and press

to jump directly to that

name.

In idle mode, enter the phone number using the

keypad. To correct an error, press

Press

(

to dial the number and press

)

hang up.

For an international call, press and hold

to enter

the «+» sign instead of the usual international prefix.

When receiving a call, the number of the caller may be

displayed. If you stored his/her number, his/her name

is displayed instead of the number.

To answer the call, press

(

To reject a call, press

)

. If you have activated

“Call forward” (see page 60), the call is diverted

to a number or voice mail.

To hang up, press

)

The phone will not ring if in Silence mode (see

page 7). If you have selected Any Key Answer (see

page 61), you can accept a call by pressing any key

(except

)

Thanks to its touch-screen and stylus, your mobile

phone allows you to quickly tag and send the pictures

you have taken to your friends and relatives. See

“Touchscreen” page 2 to learn about the touch screen

and how to use the stylus, “Taking pictures” page 14

to know how to take pictures and refer to “Picture

album”, “TagIt” page 52 for further information on

tagging/modifying pictures.

Access and view the phonebook

Make a call

Contacts

Answer and end a call

Tag and send pictures

Philips755_02_Main features_GB.fm Page 4 Jeudi, 13. mai 2004 9:56 09

Main features 5

This feature allows you to display your

pictures listed in the Picture Album

(automatically in a slideshow, or

manually, one-by-one) on a TV screen via the TV

Link accessory, or on the main (internal) screen of

your phone.

Connect the TV Link to the TV video yellow

(RCA) jack on one end, and to your mobile’s

audio jack at the other end.

A default picture will automatically appear on

the TV screen, while the TV slideshow menu

will be displayed on the screen of your phone.

Use the menu of your phone to set an automatic

slideshow, or display the pictures manually by

pressing

and

TV Link only support JPEG pictures, up to VGA size

(640 x 480 pixels). See “TV Slideshow” page 55 for

details about this feature.

This feature allows you to set your 4 preferred or most

frequently dialled numbers. You then quickly call one

of them by double-tapping the corresponding icon or

picture on the screen, without entering and browsing

the Contacts list.

Press

to access the QuickCall screen.

Select a thumbnail to configure. Press

once

to select a name in the Contacts list, and a

second time to access the Picture album and

associate a picture to this name’s thumbnail.

Proceed the same way for each thumbnail.

To call one of the associated names, press

when in idle mode, then double-tap the

thumbnail of your choice with the stylus pen.

To reconfigure a thumbnail, select it and press

to Replace the name and/or picture.

Your mobile phone features a camera, allowing you to

take pictures and send them to your friends and

relatives. See “Taking pictures” page 14 for complete

information on this subject.

A Navigation icon appears in idle mode and allows

you to spot the menus that can be accessed via the

phone’s navigation key. See “Navigation icon”

page 30 for details on how to activate/deactivate it.

TV slideshow

QuickCall

TV Slideshow

Take a picture

Navigation icon

Philips755_02_Main features_GB.fm Page 5 Jeudi, 13. mai 2004 9:56 09

6 Main features

This feature allows you to quickly send a message

made of a picture and a sound.

When in idle mode, press the camera key to

activate the camera. If needed, press

switch to the Clip mode.

Press the camera key to take a picture; Record

sound then opens automatically.

Record the sound or message of your choice,

press

to cancel or

to stop the recording

(you can also wait for the maximum recording

time of 30 seconds to be reached).

Then send your message via MMS (see “MMS”

page 45 for details).

This feature is available only when selecting the

phonebook in the phone (not the one in the SIM card).

This feature allows you to link one or several names to

a group. When a name in that group calls, it will

appear along with the corresponding picture and the

melody defined for that group will ring.

When in idle mode, press the camera key once to

activate the camera, and a second time to take a

picture of your friend.

Select Contacts > Settings > Groups setting.

Rename a group and select the Ringer of your

choice, then your friend’s picture.

When making a group of only one person, you can also

select Multimedia > Sound recording > New, record

him/her saying something, then select the recording as

the Ringer.

Select a name in your phonebook, choose Select

group and link it to the group you renamed.

For your own comfort and safety, ensure you move the

phone away from your ear when calling handsfree,

especially when increasing the volume.

If you selected the phonebook in your SIM card,

select a name, press

twice, select Call

handsfree and press

to dial the number.

If you selected the phonebook in your phone,

proceed the same way to call the default number,

or press

, select a number in the list,

then press

and select Call handsfree.

Foto Talk: send voice clips with

pictures

Fotocall: see and hear who’s

calling

Call handsfree

Philips755_02_Main features_GB.fm Page 6 Jeudi, 13. mai 2004 9:56 09

Main features 7

If already on the phone, press

twice to switch to

handsfree mode and back.

Select Settings > Sounds > Ringer, press

and

move

to select a ringer in the list. Press

to confirm your choice.

If you don’t want your phone to ring

when you receive a call, deactivate the

ringer by selecting Settings > Sounds >

Silent. Press

until the volume is set to On.

If you want your phone to vibrate when

you receive a call, activate the vibra alert

by selecting Settings >Sounds >Vibra

alert, then On or Off.

Activating the vibra doesn’t mute the ringer. If you

want to both mute it and keep the vibra On, activate

the Silent mode as described above.

The vibra alert is automatically set to Off when you

plug the charger.

To read your own mobile phone number, press

when in idle mode and select Own numbers > Show.

Your number is displayed if present on your SIM card.

If not, select New, then follow the instructions.

If your own number has been stored in the phonebook,

you can read it during a call. See “Access and view the

phonebook” page 4.

During a call, move the side key up or down to

increase/decrease the volume.

You can mute the microphone so that

your caller cannot hear you. During a

call, press

, select Mute and press

again.

To unmute the microphone during a

call, press

, select Unmute and

confirm by pressing

Change the ringer

Activate the silence mode

Activate the vibra alert

Silent

Vibra alert

Read your mobile phone number

Adjust the earpiece volume

Mute the microphone

Unmute the microphone

Mute

Unmute

Philips755_02_Main features_GB.fm Page 7 Jeudi, 13. mai 2004 9:56 09

8 Main features

In most countries, conversation

recording is subject to law regulation.

We advise you to notify the caller if you

intend to record the conversation you have with them

and only record if they agree. You should also keep any

recording private. 1 min. is the maximum recording

time available (see “Sound recording” page 56).

To record a conversation during a call, press

select Record dialogue and press

. Press

or hang up to end the recording: an edit

window allows you to name the recording, which is

then available in Multimedia > Sound album.

If you select Mute, then Record dialogue, only the

caller’s voice is recorded.

To clear your call list, press

and

select Call Info > Call list > Reset. Press

twice to reset the call list.

To clear the whole messages list at once, press

and select Messages > SMS > Read SMS > Delete all

SMS. Press

twice to reset the SMS list.

You can also delete all the SMS messages from the SMS

Archive menu. Deleting your SMS list is useful to free

memory space in order to receive new messages.

To clear the content of your phonebook at once, press

and select Contacts > Settings > Delete all.

Press

to reset the phonebook content.

This option only applies to the phonebook in your

phone, NOT to the SIM phonebook.

In a list (of ringers, events, etc.), long press

to scroll page per page instead of item by item.

Record a conversation

Clear the call list

Record dialogue

Reset

Clear the SMS list

Clear the phonebook

Quickly scroll a list

Philips755_02_Main features_GB.fm Page 8 Jeudi, 13. mai 2004 9:56 09

Menu tree 9

3 • Menu tree

The table below describe the complete menu tree of

your mobile phone, and the page reference you should

refer to for more information concerning each feature

or setting.

Settings p27

Sounds p27

Silent / Ringer volume / Ringer / Messages

ringer / Equaliser / Key tones / Sounds alerts

/ Vibra alert

Display p28

Screen saver / Animation / Backlight /

Wallpaper

Short cuts p29

Hotkeys / Voice command / Voice dial /

Navigation icon

Security p31

Public names / Call barring / Change codes /

PIN protection

Calibration p32

Network p32

GPRS attach / Register again / Preferred list

/ Access settings

Time and date p33

Clock display / Set date / Date format / Time

zone / Daylight saving / Set time

Language p34

List of available languages

Profiles p34

Messages p36

SMS p36

Send SMS / Read SMS / SMS settings / SMS

Archive

E-Mail p39

For each available mail box:

Settings / Open mailbox / Send mail

Philips755_GB_4311 255 58341.book Page 9 Mardi, 11. mai 2004 11:02 11

10 Menu tree

Broadcast SMS p44

Reception / Topics / District codes

SMS chat p44

Quick message p44

MMS p45

New MMS / Receive an MMS / Manage

folders / Settings

Contacts p23

View names list

Phonebook settings

Delete all / Contacts select / Group settings /

Copy to phone

Games & Applications p57

Euro converter p57

Calculator p57

Alarm clock p57

Organiser p57

Brick game p59

Call information p60

Call settings p60

Call forward / Mailboxes / Auto redial / Any

key answer / Call waiting / Caller ID

Call list p61

Call list / Reset

Call counters p62

GSM counters / GPRS counters

Infrared p50

Philips755_GB_4311 255 58341.book Page 10 Mardi, 11. mai 2004 11:02 11

Menu tree 11

Camera p14

Multimedia p52

Picture album p52

List of available pictures

Sound album p52

List of available sounds

Demo mode p56

Memory status p56

Sound recording p56

TV Slideshow p55

BeDJ p56

Operator services p64

Service numbers

The numbers available in this menu are

operator and subscription-dependent, please

check with your operator.

WAP p64

Services +

This menu is operator and subscription-

dependent, please check with your operator.

Philips755_GB_4311 255 58341.book Page 11 Mardi, 11. mai 2004 11:02 11

12 Text or number entry

4 • Text or number entry

Text can be entered in editing screens in two different

ways: by using T9® predictive Text Input, or basic

text input. Two other modes for numbers and

punctuation marks are also available. Icons appearing

on the screen show the active text mode.

Reminder: the on-screen keyboard allows you to enter

text using the stylus pen, like you would do on a PC

keyboard. Using the stylus is equivalent to pressing the

actual keys.

T9® predictive Text Input is an

intelligent editing mode for messages,

including a comprehensive dictionary.

It allows you to quickly enter text. Press

only once on the key corresponding to

each letter needed to spell a word:

keystrokes input are analysed and the word suggested

by T9® is displayed in the edit screen. If several words

are available according to the keys used, the word you

entered is highlighted: press

to browse

the list and to choose from those proposed by the T9®

built-in dictionary (see example below).

How to use it?

Alphabets and symbols represented by each key are as

follows:

Example: how to enter the word "home":

Press

The screen displays the first word of a list:

Good

Press

to scroll and select

Home

Press

to confirm selection of the

word

Home

T9® Text input

Tegic Euro. Pat.

App. 0842463

To key in letters.

To browse the list of candidate words.

To confirm entry.

Short press to clear one entry, long

press to clear all text.

Shift from standard, to lower, to upper

case.

Shift from T9® to basic mode, to

numeric mode.

Shift to symbols and punctuation

mode.

Philips755_GB_4311 255 58341.book Page 12 Mardi, 11. mai 2004 11:02 11

Text or number entry 13

If you wish to access the basic text input, press

This method requires multiple key presses to reach the

desired character: the letter "h" is the second letter on

the

key, so you must press it twice to enter "h".

Example: how to enter the word "home":

Press

(

)

(

O),

(

). Press

when

the message is completed.

Letters, numbers and symbols are located on each key

as follows:

Basic text input

Short press Long press

space 1 @ _ # = < > ( ) & £ $ ¥ 1

a b c 2 à ä å æ ç 2

d e f 3 é è D F3

g h i 4 G ì4

j k l 5 L5

m n o 6 ñ ò ö 6

p q r s 7 b P Q S7

t u v 8 ü ù 8

w x y z 9 ø W X Y9

. 0 , / : ; » ’ ! ¡ ? ¿ * + - % 0

Philips755_GB_4311 255 58341.book Page 13 Mardi, 11. mai 2004 11:02 11

14 Taking pictures

5 • Taking pictures

Your mobile phone features a digital camera that

allows you to take pictures, store them in your phone,

use them as wallpaper or send them to your friends.

Within any menu, long press

to cancel any

current action and go back to idle mode.

Preview mode settings

Open the camera shutter and/or press the

camera key to display the camera preview

screen. The lens of the camera is

automatically focused and icons are

How to...

Activate the camera

Open the camera door or

press the camera button.

Zoom in/out

In all modes except VGA

(see “Preview mode settings”

below), press the navigation

key

Change the

vision mode

Press

to toggle between

Night

and

Normal

mode.

Change the

camera mode

Press

to switch from

VGA

(640*480 pixels) to

Wallpaper

(128*160 pixels)

Clip

(128*160 pixels) to

Fotocall

(96 x 64 pixels).

Change the

special effect

Press the navigation key

(left) or

(right) to switch

from a special effect (sepia,

embossed, etc.) to another.

Access the

camera settings

Press

when the camera

is active.

Take a picture

Press the camera key when

the camera is active.

Save the picture

Press the camera key right

after the shot.

Delete the picture

Press

right after the

shot.

Access the

shot options

Press

right after the

shot.

Activate/deactivate

the self-timer

Press

Pictures shots

Philips755_GB_4311 255 58341.book Page 14 Mardi, 11. mai 2004 11:02 11

Taking pictures 15

displayed in the bottom(

Zoom

Effect

Camera mode

Shot

) and top (

Self-Timer

Vision

All options and key presses described in this section are

applicable only when the camera mode is active, i.e.

when the preview is displayed on the screen. You can

also press

to access any of them (see “Settings”

page 17).

For all other photo modes, hold the mobile vertically

and press

to switch to

Wallpaper

(128 x 160

pixels), to

Clip

(128 x 160 pixels) to

Fotocall

(96 x 64

pixels). The icon of the

Camera mode

you select is

displayed in the bottom of the screen.

The

Clip

mode allows you to record a voice message

right after you shot the picture. See “Foto Talk: use the

Clip mode” page 16 for details concerning this mode.

Camera

mode

The default picture size of the standard

format is

VGA

640 x 480 pixels. Turn the

mobile phone to a 90° angle to the left

and hold it horizontally to obtain a

fullscreen preview.

In this mode, the VGA icon will appear in

the bottom right corner of the screen.

NAVIGATION KEYS

AUTOMATICALLY

ADAPT TO

VERTICAL OR

HORIZONTAL

POSITION (preview,

key presses, etc.)

Effects

Allows you to choose one of the available

effects, see “Effect mode” page 18.

Self-

timer

Allows you to set the

Self-timer

option

Off

(see “Use the self-timer” page 16).

Vision

mode

Two vision modes are available:

Normal

and

Night mode

(reflected by the moon

icon in the top of the screen). According

to ambiant light level, press

toggle between modes.

Zoom

mode

This option is available in all modes: one-

level zoom (x2) in

Clip

and

Wallpaper

modes (press the navigation key

to zoom in or out) , two-levels zoom

(x2 and x4) in

VGA

mode (as you hold

the phone horizontally, also press

, that actually are the

and

arrows of the navigation key when you

hold the phone vertically).

Philips755_GB_4311 255 58341.book Page 15 Mardi, 11. mai 2004 11:02 11

16 Taking pictures

Take a picture

If the self-timer option is

Off

, and once the

camera was activated, press the camera key to

take a picture.

The number that appears shows its row. Press:

Slide the camera door closed to deactivate the

camera

without

saving the picture.

The number of pictures you can save varies

according to the settings: the higher the

resolution, the bigger the file size. A message will

warn you if there isn’t enough memory left. In

this case, you must delete data before storing a

new picture (see “Memory status” page 56).

When they are saved in the

Picture album

, the pictures

are named «img_1.jpg», etc., up to 9999. This does

not mean you can take up to 9999 pictures, but that

pictures are numbered up to 9999. Numbering will

then restart from 1 on.

Use the self-timer

Set the self-timer option

(see above), then

press the camera key to activate it (or press

if the option is

Off

Put the phone down and orient it for the picture

to be correctly framed.

The countdown starts at 10 seconds (this value

cannot be changed). A sound is played 3 seconds

before the picture is taken, then again when it’s

actually shot.

Press

to stop the timer and go back to preview

mode or press

to just stop the timer.

Once the picture is shot, follow the instructions

starting at point 2 described in “Take a picture”.

Tag / modify a picture

For complete information on this subject, see “TagIt”

page 52.

Foto Talk: use the Clip mode

The

Clip

mode allows you to make a clip made of a

picture and a sound.

To ignore the picture you have just taken

and go back to preview mode.

Camera

key

To save it in the

Picture album

To access the list of available options:

Send

(by MMS, Email or infrared),

Save

in the

Picture Album

Modify

it, or

Take a

new picture

Philips755_GB_4311 255 58341.book Page 16 Mardi, 11. mai 2004 11:02 11

Taking pictures 17

Select the

Clip

mode, then press the camera key

to take the picture.

The

Record sound

window automatically opens:

record the sound or message of your choice

(press

to cancel,

to stop the recording,

or wait for the max. recording time of

30 seconds to be reached).

Press

to access the following options:

Fotocall: see who’s calling

The

Fotocall

mode allows you to make a picture and

to link it to a group. When a name in that group calls,

the corresponding picture appears. See “Fotocall: see

and hear who’s calling” page 6 for details.

Review the pictures

The pictures you save are automatically stored in the

Multimedia

Picture album

menu. See “Picture album”

page 52 for details.

Receive and make a call

When receiving a call while using the camera:

• answering it will quit the camera context and your

phone will return to idle when you hang up,

• rejecting it will also quit the camera context, and

bring you back to the preview screen.

To make a call, you must first go back to the idle

screen.

Press

while the camera mode is active to access

further settings than the ones available directly within

the preview screen.

Settings you last define are saved and available when

reusing the camera or until you change them again.

General settings

Send by

MMS

Send

your clip via MMS.

Play clip

Play

it.

Saving clip

Save

the clip you have created: the

picture in

Picture album

and the

recorded sound in

Sound album

Change clip

Change

the clip you made.

Settings

Date & time

To select what will be displayed on the

pictures you take:

Time & date

Date

only

or nothing.

Philips755_GB_4311 255 58341.book Page 17 Mardi, 11. mai 2004 11:02 11

18 Taking pictures

Frames

To choose a frame and apply to the picture you take

(this automatically sets the mode to 128 x 160 pixels),

or to create your own frame, directly from a picture.

Effect mode

To choose an effect and apply to the picture you take:

Normal

Black & white

Sepia

Digital

Embossed

Negative color

Edge

and

Edge 2

Vision mode

To choose one of the two modes available:

Normal

and

Night

. The default mode is

Normal

Self-timer

Set this option to

to activate it and press

go back to camera preview and take pictures (see page

16).

Camera

mode

Allows you to switch from a camera

mode to another: see “Preview mode

settings” page 14.


quality

To choose a quality available among

the following:

Low

Medium

High

Sounds

To set the

Alert

and

Shoot

sounds. The

first one occurs 3 seconds before the

shot, the second one when the picture

is shot. Select

Default

or one of the

available sounds, then press

activate it.

Reset

settings

To reset all values to the default ones.

Philips755_GB_4311 255 58341.book Page 18 Mardi, 11. mai 2004 11:02 11

BeDJ 19

6 • BeDJ

BeDJ allows you to create your own sound by using a

styles, or any SP-MIDI or MIDI ring tones saved in

your phone. You can then send your own mix to

friends and relatives, use it as a ringer or an alarm, etc.

Reminder: in most contexts, the touchscreen allows

you to manage options using the stylus pen, and is

equivalent to pressing the actual keys.

Within BeDJ, the colour orange always shows the

information currently in use, or a selected item.

Activate tracks

Launch BeDJ by selecting

Multimedia

BeDJ

In the upper left part of the BeDJ screen, the

default style selected (e.g., Groovy, Techno,

How to...

Switch

BeDJ

On/

Off Select

Multimedia

BeDJ

Press and hold

to switch

off.

Activate/

deactivate

a track

Press a key from

or tap the red dot above the

track number with the stylus

pen, in the bottom part of the

touchscreen.

Press

to deactivate all

tracks at once.

Record the mix

(start and stop) Press

, or use the stylus pen

to tap the red dot in the upper

left corner of the touchscreen.

When you stop the recording,

the options related to the

recording appear (see page 21).

Activate the

Tempo

field Press

Open the track

selection list Press and hold a key from

Open the

Help

screen Press

Open the BeDJ

Options

list Press

before recording.

Getting started

Philips755_GB_4311 255 58341.book Page 19 Mardi, 11. mai 2004 11:02 11

20 BeDJ

etc.), the current tempo value, the status of the

recording and the name of the track are

displayed.

In the bottom part of the screen, 9 tracks can be

miwed, linked to keys

: press the

key corresponding to the track to be activated.

Up to 14 tracks are available: press and hold keys

to open the track selection list.

Key

is always dedicated to the voice track.

Change track melodies & instruments

Before activating tracks, press and hold keys

to change the default melodies and instruments:

Change the tempo

Press

to activate the

Tempo

field, which is

displayed in bmp (or «beats per minute») and

applies to all tracks.

Press the highlighted

keys to

increase or decrease it, then press

to go back one screen.

You cannot change a

Tempo

while playing tracks or

during a mix recording. You don’t have to save the

Tempo, which is automatically taken into account.

Start recording

When ready to record your mix, press

, or

use the stylus pen to tap the red dot in the upper

left corner of the touchscreen. The timer starts

and the

On air

red icon is selected.

While recording your mix, you can:

Melody The melody used in the selected track

is the one highlighted in the list. Move

to select another one,

then press

to access the

instruments list used in this melody.

Instruments The current instrument used in the

selected melody is the first one

highlighted in the list. Move

to select another one, then press

to go back to the main screen.

Record a mix

Activate a track Press keys

Increase/decrease

the current track

volume.

Move

or use the

stylus pen and tap the +/- signs

on top and bottom of the active

track.

Philips755_GB_4311 255 58341.book Page 20 Mardi, 11. mai 2004 11:02 11

BeDJ 21

The recording will stop automatically when the mix

reaches 50 KB (approximately 2 min.). Capacity

depends on the memory available in your phone: select

Multimedia

Memory Status

for memory information.

Recording options

When you stop recording a mix, a window opens and

displays the following options:

The recording you save will appear under the name of

your choice in

Settings

Sounds

Ringer

list as well as

Multimedia

Sound album

. You can select it as a

ringer for incoming calls and new events.

Advanced options allow you to create and mix your

own styles of music, either directly from the BeDJ

styles available (e.g. Groove, Techno, Disco, etc.), or

from the ringers list (e.g., Bach, Cool, Dream, etc.).

The ringers list includes the MIDI files you might have

downloaded via e-mail, IrDA, etc.

From existing files

When the BeDJ screen is active, press

access the Options list.

When selecting

Mix ringers

BeDJ styles

, simply

choose one of the available melodies in the list

and press

to confirm your choice.

The phone automatically goes back to the BeDJ

screen, and the melody associated to the ringer

you have selected is divided into tracks.

As described above, you can then activate and

deactivate tracks, record your mix, etc.

Highlight the

previous or next

track

Move

: if the track

is active, you can then change its

current volume (see above).

Stop recording Press

Remix To record a new mix by using the

same tracks.

Replay Mix To play the mix you just recorded.

Store Mix To name and store your mix.

Send by MMS To send your mix as part of a

multimedia message.

Send by IRDA To send your mix via IrDA.

Send by Email To send your mix via Email.

Create your own style and mix

Philips755_GB_4311 255 58341.book Page 21 Mardi, 11. mai 2004 11:02 11

22 BeDJ

The number of active tracks depends on the melody

you have chosen.

From scratch

When selecting

Advanced

, BeDJ opens a

complete new set of empty tracks.

Press and hold

: the list of all the MIDI files

present in your phone appears on the screen.

Select one of them and press

A new list appears, showing all tracks of the

selected MIDI file (max.16). Move

to select one of them, then press

apply it to key

Repeat these two steps to apply tracks of your

choice to keys

of the phone.

When ready, record your mix (see page 20).

Press

twice to go back to normal mode.

Have fun and mix: you can apply any of the 16 tracks

of any ringer of your choice to

key of

your phone! This makes thousands of possibilities that

allow you to completely personalise your own mix.

You can save your own

Style

in the BeDJ styles menu,

and reuse it later to create another mix. This new style

will contain all the tracks you have mixed, but without

the effects applied to the mix.

When receiving a call while BeDJ is activated, your

mobile phone will automatically mute the sound.

Answering the call will quit BeDJ and your

phone will return to idle when you hang up.

Rejecting or ignoring the call will allow you to

stay in the BeDJ screen.

Save your own styles

Receive a call

Philips755_GB_4311 255 58341.book Page 22 Mardi, 11. mai 2004 11:02 11

Contacts 23

7 • Contacts

The

Contacts

menu allows you to select one of the two

available phonebooks: the one on your SIM card

(number of entries depending on capacity) or the one

in your phone (up to 499 names), which is the default

selected phonebook. When entering new names in the

Contacts

, they will only be added to the

phonebook you have selected.

499 is the maximum number of names and events

cards, provided that other features (memos, sounds,

pictures, etc.) are not using a significant amount of the

phone’s memory.

Contacts select

Press

and select

Contacts

Settings

Contacts select

. Press

select a phonebook. Contacts added to

the selected phonebook can then be

copied into the other, via the Copy to SIM or Copy

to phone options.

Delete all To delete all contacts at once. This

option only applies to the phonebook

in phone, NOT to the SIM

phonebook.

Copy to phone

If you cancelled or aborted the

automatic copy of your SIM

phonebook at first switch, you can do it

manually: select

Contacts

Settings >

Copy to phone

Your mobile phone only manages one phonebook at

a time and will ignore the information relative to the

other one e.g. if "Smith" is present in both

phonebooks and if you delete it in the phone, it

remains unchanged in the SIM.

Groups settings

Allows you manage groups, rename

them and link a specific melody and

picture to each group.

You link names to groups from the

Contacts

list. See

“Fotocall: see & hear who’s calling” page 24.

Settings

Contacts select

Delete all

Copy to phone

Groups setting

Philips755_GB_4311 255 58341.book Page 23 Mardi, 11. mai 2004 11:02 11

24 Contacts

Contacts will be added to the selected phonebook.

In the SIM phonebook

Press

when in idle mode and select <

New>

Enter the name and the number of your choice,

then the type of number allocated to the name

(

Phone

Fax

Data

) and press

to store this

name in your phonebook.

A number is limited to 40 digits, depending on your

SIM card. Entering international prefix, country &

area codes allows you to dial a number from any

location.

In the phone phonebook

Press

when in idle mode and select <

New>

Enter the first, then last name (up to 20 latin

characters); one of the two fields can be empty,

but not both.

Then select the

Number type

. Numeric fields can

hold up to 40 digits and one «+» sign and

alphanumeric fields (e-mail and note) feature up

to 50 latin characters. Each contact can feature a

maximum of 5 numeric fields (e.g., 2 mobile

numbers, 3 work numbers, an e-mail address

and a text note).

If needed, choose the group you want this

contact to belong to.

Own numbers

The

Own numbers

option that appears in each

phonebook should contain your own phone number.

If not, we advise that you enter your mobile number

as well as any other relevant information.

Although all its fields can be empty, the

Own number

item cannot be deleted.

Emergency number

The emergency number will call the

emergency services number in your

country. In most cases, you can call this

number even if you haven’t yet entered your PIN.

In Europe the standard emergency number is 112, in

the UK it is 999.

This feature is only available when you select the

phonebook of your phone, NOT the SIM phonebook.

Add contacts in a phonebook

Fotocall: see & hear who’s calling

SOS Call

Philips755_GB_4311 255 58341.book Page 24 Mardi, 11. mai 2004 11:02 11

Contacts 25

This feature allows you to personalize the groups

available with their own name («Friends», «Office»,

etc.), a given picture (from the

Picture album

) and a

given melody (from the

Ringers

list). You can then

link one or several names to a group: when a name in

that group calls, it will appear along with the

corresponding picture, and the melody defined for

that group will ring.

Select Contacts > Settings > Groups setting.

Rename the group to be identified («Friends»,

«Kids», etc.) and select the

Melody

and the


to be associated to this group.

Long press

to go back to idle, then

access the phonebook. Select a contact you wish

to link to this group, then choose

Select group

and select the group of your choice.

Press

when in idle mode to access the

Contacts

you have stored. To search for a given name:

In the SIM card

Choose a contact of your phonebook in the SIM card

and press

to access the following options:

Copy to phone will copy the content of your SIM

card into your phone. Selecting this option twice will

duplicate all the names.

In the phone

Choose a contact of your phonebook in phone and

press

to access the following options:

Edit and manage contacts

Press the key for the letter that you

want to go to in the list (e.g., press

twice to access the letter

«U»). The first record starting

with this letter is selected.

Press

, enter the first letters of

the name you are searching, and

press

to jump to that name.

• Call handsfree

•Call

•Send SMS

•Voice dial

•Flash dial

• Copy to phone

•Delete

•Change

•Send by MMS

•Change name

•Call

• Call handsfree

•Send SMS

• Send by MMS

•Select group

•Transmit

•Delete

•Show

Philips755_GB_4311 255 58341.book Page 25 Mardi, 11. mai 2004 11:02 11

26 Contacts

Select Show to access the list of all numbers or fields

saved for this contact, then <New> to create a new

field for this contact. Select one of the fields and press

to access a second set of options, which are:

Alphanumeric fields (note and e-mail) can only be

changed or deleted.

Make default The first number you enter

becomes the default number: it

appears in first position in the

list and is automatically dialled

when pressing the pick-up key.

This option allows you to make

another number default.

Copy to SIM

card To copy a contact of your phone

phonebook into the SIM card (it

is then always updated when

switching phonebooks or when

using another phone).

Show To display the details of the

selected field.

Change type To change or to define the field

type of the selected number.

Philips755_GB_4311 255 58341.book Page 26 Mardi, 11. mai 2004 11:02 11

Settings 27

8 • Settings

The

Settings

menu allows you to customise your

phone and change the settings related to each available

option (sounds, time and date, security, etc.). The

Profiles

menu allows you to change several settings at

once (see page 34).

Silent Allows you to set the

Silence

mode

Off

. When this setting is

, all alerts

are deactivated and the vibra alert is

active.

The

Silent

mode also applies to key tones.

Ringer volume

By default the ringer volume can be set

Medium

. Press

to set the

volume of your ringer from

Silent

Increasing

Ringer Allows you to select a ringer tone. The

list also includes recorded sounds and

melodies you saved. Scroll through the list and wait to

hear the selected melody being played.

You will not hear the melody if the volume ringer is set

Off

or if the

Silence

mode was activated (see page 7).

Messages ringer

Allows you to set an alert beep

Off

, for each time you receive a new

message. When

, this option also

allows you to select the alert of your choice from the

ringers list.

Equaliser This option allows you to choose from

different audio settings, also available

while a call is in progress (in this case,

scroll through the list and wait a few seconds to hear

the difference).

Key tones Allows you to set the key tones

Off

. Even when set

Off

, DTMF are

played during calls (see page 66).

Sounds alerts

Allows you to set alert beeps

Off

for the following items:

Sounds

Silent

Ringer volume

Ringer

Messages Ringer

Equaliser

Key tones

Sounds Alerts

Philips755_GB_4311 255 58341.book Page 27 Mardi, 11. mai 2004 11:02 11

28 Settings

• when an event programmed in your

Organiser

due,

•when there’s a Missed call,

•when the

Battery

alert requires charging,

• to manage the duration of your calls with a Minute

alert (the beep cannot be heard by the caller).

This menu only allows you to set the alert sounds

Off

, NOT the alerts themselves. E.g. setting the

Organiser

alert

Off

will not prevent your phone from

displaying the

Reminder

screen (if you programmed

one), but the corresponding sound will not be played.

Vibra alertAllows you to set the vibra alert

Off

when receiving a call, when an event

set in the organiser is due, when you

receive a message and when the alarm rings.

The vibra alert is always

Off

when you connect the

charger or the Cigarette Lighter Adapter.

Animation Allows you to set the animation of the

menus

Off

. When

, this option

will also scroll texts, such a message

selected in the

Read SMS

menu.

Deactivating this function increases the autonomy of

your phone.

Screen saver

Allows you to set the screen saver

Off

. When

, it will run a slide show

in idle mode, by using the jpeg file(s)

you have stored in your phone and selected.

Setting the Screen saver

Off

automatically activates

the

Economy mode

, i.e., the current time displayed on

a black background. This mode increases battery life.

Select the pictures of your choice, choose

Start delay

and define a value, then choose

Display period

for the

timing. Press

to activate the screen saver.

When in idle mode, the screen saver will start

according to the time limit you have set and the

timing you have set will be applied between each

picture of the slideshow.

Vibra alert

Display

Animation

Screen saver

Philips755_GB_4311 255 58341.book Page 28 Mardi, 11. mai 2004 11:02 11

Settings 29

You must select several pictures (up to 10) in order to

display a slide show. When selecting only one picture

to be used as screen saver, only this picture will be

displayed.

Backlight Allows you to set a backlight

Duration

by selecting one of the available values.

Backlight is activated when receiving

incoming calls or messages, browsing menus, etc.

Deactivating this function increases battery life.

Wallpaper Allows you to set the Wallpaper

Off

. When

, the picture/s you

selected is/are displayed in

Normal

Fade

mode in idle mode, if you didn’t activate a slide

show.

Only JPEG type pictures can be used as Wallpapers.

Hotkeys Allows you to set up direct access to a

specific function by linking it to a key.

A long press on the key will then

automatically activate the function or call the

associated number (Flash dial).

You can only program keys

The following keys are pre-programmed:

(open

list of hotkeys),

(launch Wap),

(call voice

mailbox) and

(dial international call).

Depending on your service provider, other hotkeys

may be predefined and locked.

Select a key from

and press

Browse the list to select the function you wish to

associate with this key and press

. Most

choices will open the menu (e.g., Send message

or E-mail), or launch the function (such as

Calculator or Record).

If the selected key is already set, you can reprogram it:

press

twice and select

Change

. This will bring you

to the list of available functions.

Backlight

Wallpaper

Short cuts

Hotkeys

Philips755_GB_4311 255 58341.book Page 29 Mardi, 11. mai 2004 11:02 11

30 Settings

To use the hotkeys, simply press and hold the key

corresponding to the function you want to launch or

to the number you want to dial while in idle mode.

Voice command

Allows you to set up direct access to a

specific function by linking it to a voice

tag.

You can associate a Voice command to most functions

supported by the

Hotkeys

Select

<New>

, browse the list to select the

function of your choice and press

When

Press OK then speak

appears, follow the

instructions displayed on the screen. When

prompted to record your voice tag, make sure

you are in a quiet environment, choose a short

and simple word and clearly pronounce it.

The next menu gives you access to the Delete,

Play voice tag, Change function and Change

voice options. Press

to create another voice

tag.

To use the voice command, press and hold

when

in idle mode, then say the recorded voice tag.

Voice dial Allows you to set up a voice tag

recording a word that will call the

corresponding name when pronounced.

Proceed as described in the previous section, select the

contact of your choice in the list, then press

When the phonebook in phone is selected, choose the

number of your choice in the list that is displayed.

As for Voice command, when

Add voice tag?

appears,

press

and follow the instructions displayed on

the screen. To use the voice dial, press and hold

when in idle mode, then say the voice tag

corresponding to the number you want to dial.

Up to 15 voice tags can be defined and shared between

voice dial and voice command. Recorded voice tags are

available in their respective menu and can be deleted,

played or changed.

Navigation icon

Allows you to set the Navigation icon

Off

. When

, it appears in idle

mode, and allows you to spot the menus

that can be access via the phone’s navigation key.

Voice Command

Voice Dial

Navigation

Philips755_GB_4311 255 58341.book Page 30 Mardi, 11. mai 2004 11:02 11

Settings 31

Menus can always be accessed this way, even when the

option is set to Off.

Public names

Allows you to manage a specific names

list, called

Public Names

list, and restrict

calls to this list via the

Call restriction

option.

Call barring

Allows you to limit the use of your

phone to specific calls by letting you bar

both outgoing and incoming calls. This

function is network dependent and requires a specific

call barring password supplied by your service

provider. Call barring can be applied both to

Incoming calls (All calls or When roaming) and to

Ougoing calls (

All

calls,

International

calls and

Intl. Exc.

Home

In all cases, the

Cancel

option of these menus applies to

all calls at once. The Status menu allows you to know

whether a type of call is barred or not.

Change codes

Allows you to change your

and

PIN 2

codes, as well as the call

Barring

code

. Depending on your SIM card,

some features or options may require a PIN2 secret

code, given to you by your operator.

If you enter a wrong PIN2 code 3 times, your SIM

card is blocked. To unblock it, request the PUK2 code

from your operator or retailer. If you enter an

incorrect PUK code 10 times in a row, the SIM card

Security

Call

restriction Allows you to restrict the calls to

the

Public Names

list. In this case,

you can only access the names of

the

Public names

list, as opposed to

the

Contacts

of the main menu.

This function is subscription

dependent and requires a PIN2

code (see page 32). This option

might also apply to WAP and

e-mail connections over GPRS.

Public names Allows you to view, edit and

modify your

Public Names

list. via

a PIN2 code.

Public names

Call barring

Change codes

Philips755_GB_4311 255 58341.book Page 31 Mardi, 11. mai 2004 11:02 11

32 Settings

will be blocked and unusable. If this happens, contact

your operator or retailer.

PIN protection

This allows you to set the PIN

protection

Off

. When

, you

will be asked to enter your PIN code

when switching your phone on.

You cannot change your PIN code if this option is

Off

This menu allows you to calibrate your screen. See

“Calibration” page 2 for details.

Contact your phone operator to have full information

about GPRS availability over their network and for

an appropriate subscription. You might also need to

configure your phone with the GPRS settings supplied

by your operator, by using the menus described in this

section. Then select the bearer (GSM or GPRS) in the

menus of each application to be used (e.g., WAP,

MMS, e-mail, etc.).

GPRS attach

This menu allows you to define the

attach mode of your mobile phone to

the GPRS service.

Provides you with a list of the networks

available in the area when the

Manual

mode is selected. Select the network you

want to register with and press

to confirm.

Preferred list

Allows you to build a network list in

order of preference. Once defined, the

Calibration

Network

PIN protection

Always on Your phone will always register to

the GPRS service. This option

allows faster GPRS connection.

However it will increase energy

consumption.

For data calls Your phone will automatically

when required. This option

reduces energy consumption,

however it will increase the

connection delay.

GPRS attach

Preferred list

Philips755_GB_4311 255 58341.book Page 32 Mardi, 11. mai 2004 11:02 11

Settings 33

phone will try to register on a network, according to

your preferences.

Access settings

This menu allows you to create several

data profiles: when using WAP or when

sending MMS, the selected profile will

be used to connect to the GSM or GPRS network.

Options described below are operator and/or

subscription dependent. Error messages during

connections are mainly due to incorrect parameters:

contact your operator before first use, in order to have

the appropriate settings, which you may receive by

SMS in some cases. Some pre-configured profiles

might be locked, preventing re-programming and

renaming.

Select an item in the list and press

to access the

following options:

Clock display

Allows you to select

Analogue

Digital

Tiny

time formats when shown in idle

mode.

Change name To rename the selected profile.

Show To visualise all parameters of the

selected profile.

Access settings

GSM Settings To change the GSM settings:

•Login,

•Password,

•Phone number needed to

establish the connection and

provided by your operator

(ISDN or Analogic),

•Inactivity time, a value of over

30 seconds after which the

phone disconnects automati-

cally (if a connection was in

progress)

GPRS settings To change the GPRS settings

(same fields as the GSM settings).

The APN menu allows you to

enter the address of the external

data network you want to

connect to, a text string used to

establish the connection.

Time and date

Clock display

Philips755_GB_4311 255 58341.book Page 33 Mardi, 11. mai 2004 11:02 11

34 Settings

Set date Allows you to set the date by pressing

the appropriate numeric keys. You can

also set the date by moving

Date format

Allows you to select one of the two

available date formats, either

Western

Thai

Time zone

Time zone and daylight savings should be set first

(double-check date and time if previously set).

Allows you to set the time zone you

belong to, according to GMT

(Greenwich Meridian Time).

Daylight saving

This setting only concerns countries in which time is

set according to summer/winter time (e.g. Greenwich

Meridian Time / British Summer Time).

Allows you to set the daylight savings to

(in summer time) or

Off

(in winter

time). If daylight saving is

and you

set the time to 12:00, it will automatically switch to

13:00 when turning the option to

Off

Set time Allows you to set the time by pressing

the appropriate keys. You can also

increase or decrease the time minute by

minute by pressing

This menu allows you to select a language for all menu

texts. Press

to select the language of

your choice, then press

to confirm.

This menu allows you to access a group of predefined

settings, which let you quickly adapt your phone to

your environment by changing several settings at

once. For example, selecting

Meeting

will set your

ringer volume to silent, activate vibra and deactivate

the key tones (the other items are set according to the

settings you configured). When your meeting is over,

selecting

Personal

will reactivate all your usual settings.

When you associate a hotkey to a profile (e.g. long press

key

activates

Silence

, see “Hotkeys” page 29), also

Set date

Date format

Time zone

Daylight saving

Language

Profiles

Set time

Philips755_GB_4311 255 58341.book Page 34 Mardi, 11. mai 2004 11:02 11

Settings 35

long press this key to deactivate it and go back to the

Personal

settings.

The settings listed in the column

Personal

, in the

following table, are default settings preset during

production. As you can change them, the personal

settings in your phone may differ from the table.

Each box of the table refers to the settings as

stored in the

Personal

menu (whether you have

changed the settings or not).

When connecting an accessory, the settings Headset

and Activate car also become available. When

disconnecting the accessory, the phone goes back to

the

Personal

profile.

Profiles

Vibra alert

On Off On

Ringer volume

Medium Medium

High Silent

Medium Medium

Key tones

On Off

Organi-

ser alerts

Battery low alert

Message alert

Backlight

10 sec Off Off

Zoom

Off

Any key answers

Off On On

Animation

On Off

Personal Autonomy Outdoors Meeting Headset Activate Car

Philips755_GB_4311 255 58341.book Page 35 Mardi, 11. mai 2004 11:02 11

36 Messages

9 • Messages

This menu allows you to send short

messages, with sounds, animations or

pictures, as well as manage the ones you

receive.

Sending SMS isn’t available from the idle mode when

the

SMS Chat

feature is

(see page 44). In this case,

you can only access the

Answer

option.

Send SMS This menu allows you to send an SMS

to a contact of your choice, whether

saved in your phonebook or not (in this

case, simply select

<New>

in the contacts list and

enter a number).

When the phonebook in phone is selected, press

to send the SMS to the default number, or select

another number of your choice (see “Edit and manage

contacts” page 25).

You can choose from three different types of messages:

Press

to access the next set of options, which are

the following:

You can send up to 2 attachments of 2 different types

together with your SMS. Animations and pictures are

exclusive: if you first select an animation, then a

SMS

Send SMS

<New>

To send a new message.

Last message

To edit, modify and re-send the last

message you have sent.

Template

To select a pre-configured message,

such as

Can you ring me back at this

number..

including your number, if

it is the first one of the

Own num.

option (see page 24).

Save

To store the current message and its

associated icon and melody if any

in the

more slides by pressing

Send now

to send the MMS to the

selected recipient(s),

Access the

MMS Options

Philips755_GB_4311 255 58341.book Page 45 Mardi, 11. mai 2004 11:02 11

46 Messages

Sounds can be chosen from the

Sound Album

, or a

sound memo that you record when creating the

MMS: in this case, select

, then

<New>

and

follow the procedure that appears on the screen.

You cannot attach an existing voice memo.

MMS options

The following options are available:

Send MMS

Once your message is complete, simply select

Send

MMS

and press

. If you saved your MMS as a

draft, this option is also available from the

Drafts

menu. If you have already sent the MMS and have

activated the

Auto save

option (see page 49), select it

from the

Outbox

menu and select

Re-send MMS

If the sending of a draft message fails, the message will

be moved to the

Outbox

menu.

Add slide

To create a new slide and add it to

your slide show. Press

to browse slides once you have

created several.

You can also press

when the

last page of the message you are

currently designing is selected.

Next slide /

Previous slide

To move to the next/previous slide.

Edit subject

To edit and change or enter the

subject of your message.

Delete slide

To delete the selected page (if there

is more than one in the message).

Save MMS

as draft

To save your message as a draft, that

you can edit, complete and send

later on (see page 47).

Save

as template

To save your message as a template,

that you can use as a basis for other

MMS (e.g., «Happy birthday» type

of message, see page 47).

Preview MMS

To preview the slide show you have

created.

Slide duration

To change the value of slide

duration set in

Settings

Application

settings

(see page 46), and to set a

delay between each slide.

Philips755_GB_4311 255 58341.book Page 46 Mardi, 11. mai 2004 11:02 11

Messages 47

In all cases, a progress bar allows you to follow the

sending of your message (press

to cancel).

Receive an MMS

If the size of the MMS to download is bigger than the

memory available in your phone, you must free

memory by deleting data (picture, sounds, etc.). See

“Memory status” page 56.

When you receive an MMS an alert message appears

on the screen to inform you. See page “Settings”

page 39 to learn about

Automatic

Manual

retrieval

modes.

If the sender of the message has asked for a

Read

report

, a prompt will ask you to press

to send it

or to press

to cancel.

Once the MMS is downloaded, select it in the

Inbox

list and press

to play it. Press

to access the

following

Player options

Manage folders

Four different folders are available. The default

(active) folder is the one you last selected.

Play

To switch back to automatic

mode: the MMS is then played

as a continuous slide show.

Next /previous

slide

To move to the next or previous

slide. You can also press

when viewing the MMS in

manual mode.

Detach picture

To detach the picture of the

current slide and save it in the

Picture album

Detach sound

To detach the sound of the

current slide and save it in the

Sound album

To close the MMS and go back

to the list of options.

Templates

Lists all messages saved as templates.

You can

Play

Edit

and

Delete

them.

Drafts

Lists all messages saved as drafts, or

automatically saved if you quit the

MMS menu before saving or sending

your MMS. You can

Play

Edit

Send

and

Delete

drafts.

Outbox

Lists the messages you have

Sent

created but

Not sent

yet. You can

Play

Delete

or view the

Details

of all these

messages,

Re-send

Forward

them to

someone.

Philips755_GB_4311 255 58341.book Page 47 Mardi, 11. mai 2004 11:02 11

48 Messages

Notifications are automatically deleted once you have

received the full MMS. Do NOT delete notifications

before you have retrieved the MMS, or you will never

be able to do so.

Messages you have saved can only be sent from the

Draft

Outbox

folders. You can NOT recover an

item (whether message, notification or report) that

you have deleted. Press

to cancel deletion.

Settings

Your phone may have been pre-configured to directly

access the services offered. If not, contact your operator

to receive the information items described in the

present section and enter them as given. With some

operators, access parameters can be set «over the air».

The following settings are available:

Inbox

Lists all the

Notifications

Delivery

and

Read

reports

Read

and

Unread MMS

You can

Read

Delete

notifications

and reports.

You can

Play

Forward

to an

MMS, display its

Details

Delete

it.

Retrieval

mode

Allows you to choose from:

Manual

: you connect manually to the

server by selecting a notification in the

Inbox

, selecting

Read

to downloading,

then

Play

Automatic:

will place received MMS in

the Inbox. Select the MMS and press

to play it.

This mode is deactivated when roam-

ing.

Validity

period

To select how long your MMS will be

stored on the server, from

1 hour

week

(maximum). This is useful when

the recipient is not connected to the

network (and thus cannot receive your

message immediately).

Read

report

This option can be set

Off

and

informs you (via an SMS) when the

status the MMS you have sent has

changed, i.e. if it was read or deleted.

Philips755_GB_4311 255 58341.book Page 48 Mardi, 11. mai 2004 11:02 11

Messages 49

Delivery

report

This option can be set

Off

and

informs you (via an SMS) the status of

delivery, e.g. if your MMS was

received or rejected.

Auto save

This option can be set

Off

and

allows you to automatically save the

messages sent from the

Outbox

menu.

Slide

duration

Allows you to select the duration

between each slide of the MMS.

Network

settings Network account

is used to choose a

connection profile from the ones you

have set (see “Access settings”

page 33).

Bearer

allows you to select the type of

network used when launching a

connection:

GSM

GPRS

GPRS first

Choose

MMS Center

to enter the

MMS address of the server you will

connect to.

Gateway address

and

Gateway port

will

allow you to enter both IP and Port

numbers of the server’s gateway.

Philips755_GB_4311 255 58341.book Page 49 Mardi, 11. mai 2004 11:02 11

50 Infrared

10 • Infrared

Your mobile phone integrates the infrared technology

(also called IrDA), that allows you to send or receive

data to and from other IrDA-compliant devices

through a wireless link (e.g., another mobile phone, a

PC or PDA, a printer etc.). You can use IrDA to

quickly send a sound you just mixed to a friend’s

mobile phone, or to receive pictures from their PDA.

Files that are copyright-protected cannot be sent.

When connecting with a PC, make sure you have

activated its infrared option.

Before sending or receiving

data to and from another

device, they must be

correctly positioned in

relation to your mobile

phone. Make sure that the

IrDA ports are facing each

other and are a maximum of 50 cm away from each

other (see diagram). Also make sure that nothing

obstructs the IrDA beam.

To send data via IrDA from your mobile phone, you

must first select the item to be sent: when selecting a

picture, a sound, a name or an event, a sub-menu then

gives you access to the

Send

option.

As soon as your phone finds another IrDA-compliant

device to communicate with, the sending

automatically takes place. Messages are displayed on

the screen, for you to follow the process.

If the phone finds several IrDA devices, a list is

displayed on the screen, for you to choose from. Press

to confirm and to send the selected data.

Sending is cancelled if your phone cannot find another

device before the time out is reached, if the infrared

link is broken, or if you cancel the process.

Activate IrDA

To receive data, select

Infrared

Receive

. Your phone then waits for the

other IrDA device to send an item. As

when sending, messages are displayed on the screen

and allow you to follow up the process.

Position of devices

Send data

Receive data

Infrared

Philips755_GB_4311 255 58341.book Page 50 Mardi, 11. mai 2004 11:02 11

Infrared 51

Receiving is cancelled if your phone isn’t contacted by

another device before the time out is reached, if the

infrared link is broken, if the size of the file sent is too

large or if you cancel the process.

Save the data received

Press

to access the following options:

Press

to go back to the idle screen without saving.

Use the phone as a modem

You can also use your mobile phone

together with a PC or a PDA, e.g. to

surf the Internet or send faxes.

To fully benefit from the services available via IrDA

(send and receive SMS, e-mail and fax, upload

pictures and MIDI sounds in your phone, phonebook

synchronization, GPRS Wizard, etc.), you must

install Mobile Phone Tools on your PC. This software

is available on the CD-Rom shipped with your phone.

The software supplied on the CD-Rom is not

compatible with Apple® Macintosh® computers. It

only supports Windows® 98 SE, ME, XP and 2000

(Service Pack 3 and up mandatory in this case).

Specific software modules for Lotus Notes, Lotus

Organizer and Microsoft Outlook are designed to

allow synchronisation from your Philips mobile

phone to these applications (refer to their respective

user guides for detailed information).

Save

To save the data, then go back to

idle. The items you have received

will be saved under their default

name, which you can change by

selecting them in the relevant

menus.

Show

To display the details of the data

you have received (play or sound or

display a picture).

Data

Philips755_GB_4311 255 58341.book Page 51 Mardi, 11. mai 2004 11:02 11

52 Multimedia

11 • Multimedia

This menu allows you to manage and

listen to the sounds stored in your

mobile phone, your Own melodies,

Standard melodies or Records. When entering one

of the available sub-menus, select a sound and press

to access the following options:

JPEG pictures must have the correct size and format

for your mobile phone to store and display them

correctly .

This menu allows you to manage and

display the pictures stored in your

mobile phone.

When entering one of the available sub-menus, the

pictures stored in your phone are displayed as a text

list. To access the graphical display, select a picture in

the list and press

. Press

to access the

options described hereafter.

TagIt

You can also access this menu and related features

when using the camera. When selecting this option,

the picture you have chosen is displayed and

automatically resized to 128 x 160 pixels.

Sound album

Delete To Delete the selected sound.

Sounds in the Standard melodies

folder cannot be deleted.

Send by... To send the selected sound via

E-mail (see page 39), via IrDA (see

page 50) or MMS (see page 45).

You will not be able to send sounds

that are protected by a copyright.

Set as

ringer To set the selected sound as Ringer.

Sound Album

As SMS/

MMS ringer To set the selected sound as

Messages ringer (this option must

be set On in Settings > Sounds, see

page 27).

Rename To Rename the selected sound.

Picture album

Picture Album

Philips755_11_Multimedia_GB.fm Page 52 Mercredi, 12. mai 2004 4:41 16

Multimedia 53

Select a picture add press

to access the options

described below, which the icons located on the left

hand side of the screen allow you to perform. In each

case, press

to go back one step, or

validate and go to the next option. Double-tap an

item to select it, and to insert it automatically in the

middle of the screen.

Within the TagIt menu, the touchscreen interaction

allows you to use the stylus pen in most contexts. Tap

an icon on the left handside of the screen to select it, or

double-tap it to activate it.

Draw To draw on a selected picture. The

first 2 icons allow you to go back one

step or to validate.

The next icons allow you to draw

with the Stylus, Add a shape

(square, rectangle or circle, outlined

or filled), change the Thickness (1 to

8 pixels) of the selected item, change

its Colour, Undo the latest action,

Erase areas in the preview window.

Select the styles of your choice before drawing

anything, as you won’t be able to change them

afterwards.

Add text To add text to the selected picture.

Press the navigation key or tap the

arrows on the screen to move the

shape in any direction (short press to

move it of 1 pixel, long press for 5

pixels).

Tap the screen with the stylus to snap

the center of the shape to that point.

Add frame

or icon To add a frame or an icon to the

selected picture, which you can also

move on the screen by pressing the

arrows. Press

to access

the graphical display when browsing

the lists.

Eraser To Undo the last modification made

on the picture, or to Reset, i.e.,

cancel all changes at once. Press

to cancel or

to validate.

Rotate To apply a rotation to the picture.

Press

to validate.

Philips755_11_Multimedia_GB.fm Page 53 Mercredi, 12. mai 2004 4:41 16

54 Multimedia

Delete

To Delete the selected picture.

Pictures in the Standard Pictures folder cannot be

deleted.

Rename

To Rename it: press

, enter a name and press

again.

Set as wall paper

To set the selected picture as Wallpaper (this option

must be set On in Settings > Display, see page 29).

Rotate

To rotate the picture of 90° or 180°, press

confirm your choice.

Advanced To Crop or Fake a selected picture

(i.e. to cut out an area and paste it

into another picture). In both cases,

tap the screen once to define the top

left corner of the cropping area, and

a second time to indicate its bottom

right corner. A square shape with

white borders will show you the area

you’re cropping. Press

validate. When using the Fake

option, this will take you to the

pictures list: select the second picture

of your choice, and press

paste your cut out.

Save

picture To save the picture including all the

changes you have applied to it: enter

the name of your choice and press

to validate.

If you don’t rename the picture, the original file you

selected from the album will be overwritten. You can

save a picture at any time, even if you are not done

modifying it.

Send

picture To send the picture via IrDA, E-Mail

or MMS (see relevant chapters in the

present user guide for detailed

information).

Help For a better visibility of the preview,

select Help and press

to toggle

between On and Off options.

Philips755_11_Multimedia_GB.fm Page 54 Mercredi, 12. mai 2004 4:41 16

Multimedia 55

Send by Infrared

To send the selected picture via IrDA to another

infrared device (see “Infrared” page 50 for details).

Send by E-mail

To send the selected picture via E-mail (see “E-Mail”

page 39 for details).

Send by MMS

To send the selected picture via an MMS (see “MMS”

page 45 for details).

This feature allows you to display your

JPEG pictures listed in the Picture

album (automatically in a slideshow, or

manually, one-by-one) on a TV screen via the TV

Link accessory or on the screen of your phone.

TV Link may not supplied with your product. In this

case, you must purchase it separately. See “Philips

authentic accessories” page 76 for details.

Manual

Select TV Slideshow, then Manual, and press

and browse the complete list of pictures.

Press

to activate the graphical fullscreen display

and send it to the TV, press

to go back to the list.

Automatic

Select TV Slideshow, select the value to be

applied between each picture and press ,.

Choose (Un)Check all by pressing

to select all pictures at once, or

Browse the list and select/deselect the pictures of

your choice by pressing < or > (selected

pictures feature checked boxes).

In both cases, press

to start the slideshow

and

to stop it.

Select (Un)check all to deselect all pictures at

once.

The last selection/slideshow made is automatically

saved and can be played several times in a row, even

when you quit the TV Slideshow menu.

When browsing manually or or during the automatic

slideshow, press , to open the rotation options

(90°, 180° or 270°), select the option of your choice

and press ,. Changes are automatically stored.

TV Slideshow

Philips755_11_Multimedia_GB.fm Page 55 Mercredi, 12. mai 2004 4:41 16

56 Multimedia

Press

to launch the Demo movie.

If you turned the phone on without having inserted a

SIM card, this menu is available in the first menu

level.

This menu allows you to display the

percentage of memory available in your

phone. Several features share the mobile

capacity: pictures and sound albums, recorded memos

and voice tags for voice commands, messages you have

stored in the phone, phonebook and organiser entries,

games, etc.

Your mobile phone is supplied with many sounds and

pictures. You can only delete sounds or pictures in the

Picture or Sound albums, e.g. to free memory space for

your own sounds and pictures.

Press

to check the memory status. The display

shows you the percentage of memory free and the

phone’s total memory in KB. Press

again and

access the detailed list of memory used by each

feature.

If «List full» appears when saving a new item or to free

memory space, you must delete an item to be able to

create or add a new one.

This menu allows you to record a sound

of 1 minute maximum and up to 20

different sounds, depending on the

Memory status.

Select <New> to record a new sound. Follow the

instructions on the screen and press

once your

sound is recorded. Select it in the list to play it, or

press

to Delete or Rename it.

Recordings can then be used as alarm or incoming call

ringers, etc. Recordings saved cannot be sent by MMS.

This menu allows you to launch BeDJ:

press

(see “BeDJ” page 19 for

details).

Demo mode

Memory status

Demo mode

Memory status

Sound recording

BeDJ

Sound recording

BeDJ

Philips755_11_Multimedia_GB.fm Page 56 Mercredi, 12. mai 2004 4:41 16

Games & Applications 57

12 • Games &

Applications

These menus allow you to convert a

sum from or into Euros by entering the

amount and pressing

The currency used for the conversion is determined by

the country where you have subscribed. The Euro

converter is available upon subscription and only in

countries using the Euro.

This menu provides the following

functions:

Enter the figures using the keypad. Calculator

accuracy is to 2 decimal places and is rounded up to

the higher decimal figure. Press and hold

to get

the dot.

This menu allows you to set the alarm

clock. Press

and select:

Once

Every day

On weekdays

according to

your needs. Then select one of the alarm alerts: a

Melody

, a

Sound recording

(the latter being played only

once) or the

Buzzer

The alarm clock will ring even if you turned off your

phone, and even if the Ringer volume is set to

Off

(see

page 27). Press any key to stop the alarm ringing.

The organiser shares the mobile capacity and memory

with other features (phonebook, picture album, sound,

etc.). To check the memory available in your phone,

select

Multimedia > Memory status

Euro converter

Calculator

Addition

Press

Substraction

Press

twice.

Multiplication

Press

3 times.

Division

Press

4 times.

Equals

Press

-> Euro

Calculator

Alarm clock

Organiser

Alarm clock

Philips755_GB_4311 255 58341.book Page 57 Mardi, 11. mai 2004 11:02 11

58 Games & Applications

Create a new event

This menu allows to create events and

store them in your organiser. When the

organiser alert is

(see page 27), a

beep alerts you when an event is due.

Select

<New>

, then the type of event to create

(

Holiday

Meeting

ToDo

), and enter its starting

and ending date & time.

Name it (e.g. «Meeting with Smith»), then set a

reminder and a frequency: alerts will be triggered

at the chosen time.

The reminder only applies to

Meeting

and

ToDo

events. It will be updated when changing time zones

(see “Time and date” page 33).

Delete old events

This menu allows you to delete past events. Enter the

starting date (past or future) from which all previous

events will be deleted and press

twice to delete all

events preceding this date.

To delete all events set in your organiser, enter a

starting date several years ahead (e.g., 3rd of

December, 2010) to make sure all events preceding

this date are deleted at once.

Manage events

Select an event in the list and press

to access the

following options:

Events views

The

Day view

Week view

and

Month view

display in

the respective format all events stored in your

organiser. To display events in these views, simply

select the view of your choice and press

, then

move

to display the previous or next

day, week or month.

Note that changing time zones will impact all

organiser reminders: the event alarms will be updated

depending on the time displayed on the screen (see

“Time and date” page 33).

Organiser

Delete

To delete the selected event.

Change

To change the selected event.

Changing a repeated event will

also modify all instances of this

event.

Transmit

To transmit the selected event to

another IrDA-compatible device.

Philips755_GB_4311 255 58341.book Page 58 Mardi, 11. mai 2004 11:02 11

Games & Applications 59

This menu can be subscription dependent. As such its

icon and content may vary.

This menu gives you access to the brick

game, which object is to destroy the

bricks by hitting them with the ball.

Destroying all bricks give you access to

the next level. Keys used are the following:

Your mobile phone features JAVA,

which allows you to run JAVA-

compatible applications such as games

downloaded on the network.

Network

Auto-Launch

Allows you to set the automatic launch of JAVA

Off

. When

, a JAVA application will be

automatically launched right after it was installed.

Brick game

and

To move the racket left or

right.

and

To start the game by throw-

ing the ball left or right.

To pause the game up to

2 min. (after which the

screen returns to idle mode

and the game is lost).

JAVA

Brick Game

JAVA

Bearer

To select the type of network used

when launching a connection.

•

GSM

GPRS

: your mobile will

only use the GSM or the GPRS

network for e-mail connections.

•

GPRS first

: your mobile will first

try to connect to the GPRS net-

work, then to the GSM network if

the GPRS network isn’t available.

When selecting this option, you need to

have both GSM and GPRS settings

configured. See page 33 for details.

DNS

address

Allows you to enter the DNS address of

the external data network you want to

connect to.

Network

account

Allows you to select one of the data

profiles you have defined in

Settings

Access settings

(see page 33).

Philips755_GB_4311 255 58341.book Page 59 Mardi, 11. mai 2004 11:02 11

60 Call information

13 • Call information

This menu allows you to set all the call

options (call forward, waiting, etc.) and

gives you access to the menus described

hereafter.

Call forward

To divert incoming calls to your mailbox or to a

number (whether in your contacts or not) and applies

Data calls

Voice calls

and

Fax calls

Before activating this option, you must enter your

voice mailboxes’ numbers (see “Mailboxes” page 60).

This feature is subscription dependent, and different

from the call transfer, which takes place when one/

several calls are in progress.

Mailboxes

To enter your voice mailbox numbers (if not available

on your SIM card).

In some cases, you might have to enter two numbers:

one to listen to your mailbox, the other one to forward

calls. Contact your operator for more information on

this subject.

Auto redial

To set the auto redial

Off

. When

if the

person you are calling is busy, your phone

automatically redials this number until a successful

connection is made or until the maximum number of

attempts is reached (10). The phone beeps at the

beginning of each attempt and emits a special beep if

the connection is successful.

The time between redials increases with each attempt.

Call settings

Unconditional

Will divert all the incoming calls.

Warning! When selecting this

option, you will not receive any calls

at all until you deactivate it.

Call settings

Conditional

Allows you to choose in which

circumstance(s) you want to divert

incoming calls:

If no reply

If not

reachable

If busy

. Each option can

be set independently.

Status

Will display the status of all call

forwarding.

Philips755_GB_4311 255 58341.book Page 60 Mardi, 11. mai 2004 11:02 11

Call information 61

Any key answer

To accept a call by pressing any key, except

)

, used

to reject a call.

Call waiting

Caller ID

Show

Hide

your identity to your correspondent.

The

Status

option will inform you if this function is

activated or not.

This menu provides you with the list of

outgoing and incoming calls, attempts

at auto redialling and call details. The

calls (made, missed and received) are displayed in

chronological order with the most recent on top.

If a number listed is also in your

Contacts

, the

corresponding name is displayed. Move

select the number to redial and press

(

. Press

)

to hang up.

With GSM

call

Applies to

All calls

Voice calls

Fax

calls

and

Data calls

. When this

option is active, you hear a beep if

someone tries to call you while

already on a call. Select the

Status

option to find out whether the

GSM call waiting is active or not.

This function is subscription

dependent. Contact your operator.

With GPRS

call

Allows you to

Activate

Deactivate

the call waiting for voice incoming

calls while a GPRS connection is

ongoing.

Call list

Select an item and press

consult the date, time, number, call

status of any selected call and to

know if it was sent or received.

Press

again to access the

options:

Call

Call handsfree

this

correspondent,

Send a SMS

Send by

MMS

Delete

the selected call or

Store

the associated number.

Reset

To reset the whole list at once.

Call List

Philips755_GB_4311 255 58341.book Page 61 Mardi, 11. mai 2004 11:02 11

62 Call information

This menu allows you to handle the cost

and duration of your calls.

GSM counters

This menu gives you access to the options described

below.

The GSM Call Counters do not include WAP

connections. Most options mentioned below are

subscription dependent.

Call counters

Total duration

Show

Reset

the time duration

Outgoing

Incoming

calls.

Last call info

To display the duration and/or cost

of your last call.

Info at call

end

To set

Off

the systematic

display of the length and/or cost of

each call when hanging up.

Call counters

Total cost

To display the accumulated cost

and to set the counter to zero (may

be protected by PIN/PIN2 codes).

•

Show

will show how much has

been spent, having established

the charge rate.

•

Reset

allows to reset the cur-

rent

Total cost

to 0.

•

Show balance

allows to check

the remaining credit (com-

pared with previously set

limit).

•

Cancel cost limit

allows to can-

cel the cost limit.

•

Cost limit

lets you to enter the

cost limit used in the

Show bal-

ance

menu.

•

Change rate

allows to set or

change the rate per unit. First

enter the currency used (three

characters maximum), then

enter the cost per unit.

Philips755_GB_4311 255 58341.book Page 62 Mardi, 11. mai 2004 11:02 11

Call information 63

GPRS counters

This feature is subscription and network dependent.

Last mobile session

This option will display the last connection session or

transfer volume of your mobile phone (e.g., after a

WAP connection over GPRS).

Last PC session

This option will display the last connection session or

transfer volume of your PC transmission.

The call counters managed by your mobile phone

might differ from the ones used by your operator. You

should therefore consider the call counters displayed on

the screen as informative items, but NOT as the actual

charge rate basis.

Philips755_GB_4311 255 58341.book Page 63 Mardi, 11. mai 2004 11:02 11

64 Operator services

14 • Operator services

Most items of this menu are subscription dependent

and specific to operators. Consequently, the menus

described below may or may not be available. Contact

your network operator for details.

The services provided may involve making a phone

call or sending a SMS for which you may be charged.

This menu allows you to access services

supplied with your network, such as

news, sports, weather, etc.

If your phone was pre-configured, it isn’t necessary for

you to change the settings described in this section.

With some operators, settings can be set remotely.

Your mobile phone connects to the network according

to the

Access settings

you have defined in the menu

Settings

Network

(see page 33).

Homepage

This is the link to the first WAP site you access when

launching a WAP session. In most cases, this menu

item is preconfigured and will connect to your

operator’s WAP homepage. To change this default

homepage see “Settings” page 65.

Bookmarks

This menu allows you to store your favourite WAP

site addresses, rename them and access them quickly

from the list.

Press

while browsing, then select

Bookmarks

: the

Name and URL fields will be automatically filled in

with the information of the page you are browsing.

WAP

Press and hold

To launch WAP.

You can also select

Operator

Services

WAP

Homepage

and press

Move

To browse the online pages

Press

To select a highlighted item.

WAP

Press

To return to the previous

page.

Press and hold

To end the WAP session.

You can also select

Options

Exit

and press

Philips755_GB_4311 255 58341.book Page 64 Mardi, 11. mai 2004 11:02 11

Operator services 65

Select

Add bookmark

and start entering the new name

for the edit screen to appear. Press

, then proceed

the same way to enter the URL address.

The Manage bookmarks menu allows you to

Delete

Edit

the selected bookmark.

Enter address

This menu allows you to enter a WAP site address, to

which you connect directly when selecting it (a quick

way to access WAP addresses without saving them as

bookmarks).

All the addresses you enter in this menu and connect

to at least once, will appear in a list. Select one of the

items and press

to reconnect to the corresponding

page, without having to re-enter its complete address.

Settings

Edit

homepage To change the Homepage name and

address.

Start entering the new name for the

edit screen to appear.

Select

profile To select one of the available

profiles, then define the connection

settings for each of them (press

to select / deselect).

All connection settings described

below apply to the selected profile.

Security To display the list of installed

security Certificates (then display

its details or delete it), the Session

info or the Current certificate.

Rename

profile To rename the currently selected

profile (start entering the new name

for the edit screen to appear).

Browser

options To activate or deactivate the

downloading of images attached to

WAP pages.

Selecting

Never

will speed up the

global downloading time of the pages

browsed.

Cache To empty an area of the phone’s

memory where the pages browsed

during a WAP session are stored.

Philips755_GB_4311 255 58341.book Page 65 Mardi, 11. mai 2004 11:02 11

66 Operator services

Push inbox

This menu allows you to read and manage messages

automatically sent to you by the network and / or by

your operator. If it contains a WAP address, press

to connect to the WAP site.

Options

While browsing, press the

key to access:

You can send DTMF tones (or “touch tones”) to

some phone services at any time during a call by

pressing any of the keys

and

You can also attach a DTMF sequence to a phone

number before dialling it (or storing it in the

contacts). The phone number and the DTMF part

must be separated by a wait character.

To obtain a pause or wait character, press and hold

. The display shows

for wait and

for pause.

For example, to hear messages (e.g. code 3) on your

Connection Select connection allows you to

select one of the data profiles you

have defined in

Settings

Access

settings

(see page 33).

Bearer allows you to select the type

of network used by the selected

profile when launching a connection

(see page 33).

Proxy address and Proxy port

allow you to define a gateway

address and port number to be used

when launching a WAP connection

using the selected profile.

Press and hold

to enter "."

Homepage To access the Homepage of the

WAP site you are browsing.

Back Brings you back to the previously

browsed page.

Forward Takes you to the next browsed page.

Refresh To reload the currently browsed

page from its original server.

Save as

homepage To save the currently browsed WAP

page as the default homepage.

Save as... To save images embedded in the

pages that are displayed in the

Picture album.

Exit To end a WAP session.

DTMF tones

Philips755_GB_4311 255 58341.book Page 66 Mardi, 11. mai 2004 11:02 11

Operator services 67

answering machine (password 8421) at phone

number 12345678, you could call:

12345678w8421p3.

You can make a second call during an active call or

during a call on hold. Dial a number or select a name

in the phonebook, then press

(

while already on

the phone. The first call is put on hold and the

number is displayed at the bottom of the screen. The

second number is then dialled. You can then:

When you receive a second call while already on the

phone, the phone emits an alert beep and the screen

displays

Call waiting

. You can then:

To receive a second call, you must have deactivated the

Call forward

for voice calls (see page 60) and activated

the

Call waiting

(see page 61).

While in communication and one call being on hold,

you may receive a third call. You can either end one of

the calls before being able to answer the third one or

introduce the calling party into a conference (see

below). This service is limited to two current

communications (one active and one on hold).

Make a second call

Press

To select

Switch calls

to toggle

between calls (one is put on hold and

the other one is then activated).

Press

)

To hang up the active line (the call on

hold remains as such).

Answer a second call

Press

(

To answer the call (the first one is put

on hold). Then press

and select:

•

Switch calls

to toggle between

calls (one is put on hold and the

other one is then activated),

•

Conference

to introduce the new

caller into a conference call.

Press

)

To reject the call.

Press

To select End call to end the current

call, then answer the incoming call.

Answer a third call

Philips755_GB_4311 255 58341.book Page 67 Mardi, 11. mai 2004 11:02 11

68 Operator services

You activate the conference call by

making several outgoing calls, or create

it from a multiparty call context. You

may have up to five members at the same time and

end all calls at once with

)

Make a first call with someone, then a second one (see

“Make a second call” above). Press

and select

Conference

. Repeat the process until five members are

connected.

If there is an incoming call during the conference call

and there are less than five members, you can accept

this new call and add this member to the

Conference

call (if five members are already connected, you can

answer the call, but not add it to the conference).

The

Conf. members

options allow you to disconnect a

member of the conference by selecting

Remove party

or select

Private call

to have a private call with this

member only (other members are put on hold).

You can connect an active call and a call on hold by

selecting the

Transfer

option. You are disconnected

when the transfer is completed.

This feature is different from the Call forward, which

takes place before you pick up the call (see page 60).

Conference call

Conference

Explicit call transfer

Philips755_GB_4311 255 58341.book Page 68 Mardi, 11. mai 2004 11:02 11

Icons & symbols 69

Icons & symbols

In idle mode, several symbols can be displayed

simultaneously on the screen.

If the network symbol isn’t displayed, the network is

not currently available. You may be in a bad reception

area, moving to a different location may help.

Silent - Your phone will not ring when

receiving a call.

Vibra - Your phone will vibrate when

receiving a call.

GPRS attach - Your mobile phone is

connected to the GPRS network.

SMS message - You have received a new

message.

Voice mail - You have received a new voice

mail.

Battery - The bars indicate the battery level

(4 bars = full, 1 bar = low).

Alarm clock activated.

Roaming - Displayed when your phone is

registered to a network other than your own

(especially when you’re abroad).

SMS full - Memory for messages is full. De-

lete old messages to receive new ones.

Call Forward Unconditional to number -

All your incoming voice calls are being for-

warded to a number other than voice mail.

Call Forward to voice mailbox - All your

calls are being forwarded to voice mail.

Home zone - A zone designated by your

network operator. Subscription dependent,

contact your service provider for details.

GSM Network: your phone is connected to

a GSM network

Reception quality:

the more bars are shown

the better the reception is.

SMS chat - option is set to On.

Memory full - The phone’s memory is full.

Delete items to store new ones.

MMS message - You have received a new

multimedia message.

Philips755_GB_4311 255 58341.book Page 69 Mardi, 11. mai 2004 11:02 11

70 Troubleshooting

Troubleshooting

The phone

does not

switch on

Remove/reinstall the battery (see

page 1). Make sure you plugged the

jack of the charger into the correct

connector (see “Charge the battery”

page 2). Then charge the phone

until the battery icon stops

scrolling. Unplug from charger and

try to switch the mobile on.

The display

shows

BLOCKED

when you

switch on

Somebody tried to use your phone

but didn’t know the PIN code nor

the unblocking code (PUK).

Contact your service provider.

The display

shows IMSI

failure

This problem is related to your

subscription. Contact your

operator.

Your phone

doesn’t

return to

the idle

screen

Press and hold

or switch off

the phone, check that the SIM card

and the battery are installed

correctly and switch it on again.

The

symbol is

not

displayed

The network connection is lost.

Either you are in a radio shadow (in

a tunnel or between tall buildings)

or you are outside the network

coverage area. Try from another

place, try to reconnect to the

network (especially when abroad),

check that the antenna is in place if

your mobile has an external

antenna, or contact your network

operator for assistance/

information.

The display

doesn’t

respond (or

the display

responds

slowly) to

key presses

The display responds more slowly

at very low temperatures. This is

normal and does not affect the

operation of the phone. Take the

phone to a warmer place and try

again. In other cases please contact

your phone supplier.

Yo u r

battery

seems to

over heat

You might be using a Philips

charger that was not intended for

your phone. Make sure you always

use the Philips authentic accessory

shipped with your phone.

Philips755_GB_4311 255 58341.book Page 70 Mardi, 11. mai 2004 11:02 11

Troubleshooting 71

Your phone

doesn’t

display the

phone

numbers of

incoming

calls

This feature is network and

subscription dependent. If the

network doesn’t send the caller’s

number, the phone will display

Call

or Withheld instead. Contact

your operator for detailed

information on this subject.

You can’t

send text

messages

Some networks don’t allow

message exchanges with other

networks. First check that you

entered the number of your SMS

center, or contact your operator for

detailed information on this

subject.

You can’t

receive and/

or store

JPEG

pictures

A picture may not be accepted by

your mobile phone if it is too large,

if its name is too long, or if it

doesn’t have the correct file format.

See page 42 for complete

information on this subject.

You have

the feeling

that you

miss some

calls

To receive all calls, make sure that

none of the features «Conditional

call forward» or «unconditional call

forward» is activated (see page 60).

During

battery

charge, the

battery icon

shows no

bar and the

outline is

flashing

Only charge the battery in an

environment where the

temperature does not go below 0°C

(32°F) or above 50°C (113°F).

In other cases please contact your

phone supplier.

The display

shows SIM

failure

Check that the SIM card has been

inserted in the right position (see

page 1). If the problem remains,

your SIM card may be damaged.

Contact your operator.

When

attempting

to use a

feature in

the menu,

the mobile

displays

NOT

ALLOWED

Some features are network

dependent. They are only available,

therefore, if the network or your

subscription supports them.

Contact your operator for detailed

information on this subject.

The display

shows

INSERT

YOUR SIM

CARD

Check that the SIM card has been

inserted in the right position (see

page 1). If the problem remains,

your SIM card might be damaged.

Contact your operator.

Philips755_GB_4311 255 58341.book Page 71 Mardi, 11. mai 2004 11:02 11

72 Troubleshooting

The

autonomy

of your

phone

seems lower

that

indicated in

the user

guide

The autonomy is linked to your

settings (e.g., ringer volume,

backlight duration) and the features

you use. To increase the autonomy,

and whenever possible, you must

deactivate features you do not use.

Your phone

doesn’t

work well in

your car

A car contains many metallic parts

that absorb electromagnetic waves

which can affect the phone’s

performances. A car kit is available

to provide you with an external

antenna and enables you to make

and receive phone calls without

handling the handset.

Check with local authorities if you

are allowed to use the phone whilst

driving.

Yo u r

phone is

not

charging

Make sure you plugged the jack of

the charger into the correct

connector (see “Charge the battery”

page 2). If your battery is

completely flat, it might take

several minutes of pre-charge (up to

5 in some cases) before the charging

icon is displayed on the screen.

Philips755_GB_4311 255 58341.book Page 72 Mardi, 11. mai 2004 11:02 11

Precautions 73

Precautions

Your cellular mobile phone is a low power radio

transmitter and receiver. When it is operating, it

sends and receives radio waves. The radio waves

carry your voice or data signal to a base station that

is connected to the telephone network. The

network controls the power at which the phone transmits.

• Your phone transmits/receives radio waves in the GSM

frequency (900 /1800MHz).

• The GSM network controls transmission power (0.01

to 2 watts).

• Your phone complies with all relevant safety standards.

• The CE mark on your phone shows compliancy with

European electromagnetic compatibility (Ref. 89/336/

EEC) and low voltage directives (Ref. 73/23/EEC).

Your cellular mobile phone is your responsibility. To avoid

damage to yourself, to others or to the phone itself, read and

follow all the safety instructions and make them known to

anyone borrowing your phone. Furthermore to prevent

unauthorised use of your phone:

Keep your phone in a safe place and keep it out of

small children's reach.

Avoid writing down your PIN code. Try to

remember it instead.

Switch off the phone and remove the battery if you

are going to leave it unused for a long time.

Use the

Security

menu to change the PIN code after

purchasing the phone and to activate call restriction options.

The design of your phone complies with all

applicable laws and regulations. However your

phone may cause interference with other electronic

devices. Consequently you should follow all local

recommendations and regulations when using

your cellular phone both at home and when away.

Regulations on the use of cellular phones in vehicles and

aircraft are particularly stringent.

Public concern has been focused for some time on the possible

health risks for users of cellular phones. The current research

on radio wave technology, including the GSM technology,

has been reviewed and safety standards have been drawn up to

ensure protection from exposure to radio wave energy. Your

cellular telephone complies with all applicable safety

standards and the Radio Equipment and

Telecommunications Terminal Equipment Directive 1999/

5/EC.

Inadequately protected or sensitive electronic equipment

may be affected by radio energy. This interference can lead to

accidents. Before boarding an aircraft and/or when packing

the phone in your luggage: the use of mobile

phones in an aircraft may be dangerous for the

operation of the aircraft, disrupt the mobile phones

network and may be illegal.

In hospitals, clinics, other health care centres and

anywhere else where you may be in the close

vicinity of medic

al equ

ipment.

Radio waves

Always switch off your phone

Philips755_GB_4311 255 58341.book Page 73 Mardi, 11. mai 2004 11:02 11

74 Precautions

In areas with a potentially explosive atmosphere

(e.g. petrol stations and also areas where the air

contains dust particles, such as metal powders).

In a vehicle transporting flammable products (even

if the vehicle is parked) or a vehicle powered by

liquefied petroleum gas (LPG), check first that the vehicle

complies with the applicable safety rules.

In areas where you are requested to turn off radio transmitting

devices, such as quarries or other areas where blasting

operations are in progress.

Check with the vehicle manufacturer that

electronic equipment used in your vehicle will not

be affected by radio energy.

If you are a user of a pacemaker:

• Always keep the phone more than 15cm from your

pacemaker when the phone is switched on, in order to

avoid potential interference.

• Do not carry the phone in a breastpocket.

• Use the ear opposite to the pacemaker to minimise the

potential interference.

• Switch off your phone if you suspect that interference is

taking place.

If you are a user of a hearing aid, consult your physician and

hearing aid manufacturer to learn whether your particular

device is susceptible to cellular phone interference.

In order to improve the performance of your phone, reduce

radio energy emission, reduce battery consumption and

ensure safe operation adhere to the following guidelines:

For the optimal and satisfactory operation of the

phone you are recommended to use the phone in

the normal operating position (when not using in

hands-free mode or with a hands-free accessory).

• Do not expose your phone to extreme temperatures.

• Treat the phone with care. Any misuse will void the

International Guarantee.

• Do not immerse the phone in any liquid; if your phone

is damp, switch it off, remove the battery and let them

dry for 24hrs before using them again.

• To clean the phone, wipe it with a soft cloth.

• Placing and receiving calls consumes the same amount

of battery energy. However, the mobile consumes less

energy in idle screen when kept in the same place.

When in idle screen and while you are moving, your

phone consumes energy to transmit updated location

information to the network. Setting the backlight for a

shorter period of time as well as avoiding unnecessary

navigating in the menus will also help to save the bat-

tery’s energy for longer phoning and stand-by perform-

ances.

• Your phone is powered by a rechargeable battery.

• Use specified charger only.

• Do not incinerate.

Users of pacemakers

Users of hearing aids

Performance improvement

Information displayed on battery

Philips755_GB_4311 255 58341.book Page 74 Mardi, 11. mai 2004 11:02 11

Precautions 75

• Do not deform or open the battery.

• Do not allow metal objects (such as keys in your

pocket) to short circuit the battery contacts.

• Avoid exposure to excessive heat (>60°C or 140°F),

moisture or caustic environments.

You should only use Philips Authentic Accessories,

as the use of any other accessories may damage

your phone and will make all guarantees for your

Philips phone null and void.

Make sure damaged parts are replaced immediately

by a qualified technician and that they are replaced with

genuine Philips replacement parts.

It lowers concentration, which can be dangerous.

Adhere to the following guidelines:

Give your full attention to driving. Pull off the

road and park before using the phone.

Respect the local regulations in countries where

you drive and use your GSM phone.

If you want to use your phone in a vehicle, install the hands-

free car kit which is designed for that purpose, still ensuring

you give full attention to driving.

Ensure that your phone and car kit do not block any air bags

or other security devices fitted in your car.

The use of an alarm system to operate a vehicle's light or horn

to indicate incoming phone calls is prohibited on public roads

in some countries. Check local regulations.

In case of hot weather or after a prolonged exposure to the sun

(e.g., behind a window or a windscreen), the temperature of

your phone's casing might increase, especially when featuring

a metallic finish. Be very careful in this case when picking up

your phone and also avoid using it with an ambient

temperature over 40°C.

Remember to observe the local regulations

regarding the disposal of your packaging materials,

exhausted batteries and old phone and please

promote their recycling.

Philips has marked the battery and packaging with

standard symbols designed to promote the recycling and

appropriate disposal of your eventual waste.

Do not use your phone

while driving

EN 60950 Norm

Environmental care

The battery should not be disposed of with

general household waste.

The labelled packaging material is recyclable.

A financial contribution has been made to the

associated national packaging recovery and

recycling system (e.g. EcoEmballage in France).

The materials are recyclable (also identifies the

plastic material).

Philips755_GB_4311 255 58341.book Page 75 Mardi, 11. mai 2004 11:02 11

76 Philips authentic accessories

Philips authentic

accessories

Charges your battery in any AC outlet. Small enough

to carry in a briefcase/handbag.

Designed to operate your Philips mobile phone

hands-free and easy to use, this compact hands-free

solution offers a high audio quality. Simply plug the

kit into the vehicle auxiliary outlet.

In-line answer button offers you a simplified

alternative to searching for the phone. Simply answer

an incoming call by pressing the button. In idle mode,

press to activate voice dial.

In certain countries, telephoning whilst driving is

prohibited. For safe and trouble free installation, we

recommend that specialized technicians install hands-

free car kits.

A black leather carry case allows easy key presses whilst

protecting your phone from nicks and scratches.

Supplied with necklace.

To maximise the performance of your Philips phone

and not to void the warranty, always purchase Philips

Authentic Accessories that are specially designed for

use with your phone. Philips Consumer Electronics

cannot be held liable for any damage due to use with

non authorised accessories. Ask for Philips Authentic

Accessories where you purchased your Philips Phone.

This data cable allows you to display a slide show on

your TV. Simply connect the data end of the cable to

the headset (top) connector on the right handside of

your phone, then connect the video end to the video

IN connector of your TV or VCR.

See “TV Slideshow” page 55 for detailed information

on how to select pictures and display them in a

slideshow.

This software is based in part on the work of the

Independent JPEG group.

Charger

Universal car kit

XTra deluxe headset

Carry case

TV Link

Philips755_GB_4311 255 58341.book Page 76 Mardi, 11. mai 2004 11:02 11

Philips authentic accessories 77

Easy data connection to your Philips mobile phone.

The USB cable enable high speed connection between

your phone and your computer. Just connect your

phone to the cable for an automatic organiser and

phonebook synchronization within a few seconds.

The software allows you to send faxes and SMS, access

data communication facilities on mobile networks

and connect to the Internet.

Data connect kit

Philips755_GB_4311 255 58341.book Page 77 Mardi, 11. mai 2004 11:02 11

Declaration of

conformity

We,

Philips France - Mobile Telephony

4 rue du Port aux Vins - Les patios

92156 Suresnes Cedex

FRANCE

declare under our sole responsibility that the product

Philips 755

CT 7558

Cellular Mobile Radio GSM 900/GSM 1800

TAC: 352773 00

to which this declaration relates, is in conformity with

the following Standards:

EN 60950, EN 50360 and EN 301 489-07

EN 301 511 v 7.0.1

We hereby declare that all essential radio test suites

have been carried out and that the above named

product is in conformity to all the essential

requirements of Directive 1999/5/EC.

The conformity assessment procedure referred to in

Article 10 and detailed in Annex V of Directive 1999/

5/EC has been followed related to articles 3.1 and 3.2

with the involvement of the following Notified Body:

BABT, Claremont House, 34 Molesey Road, Walton-

on-Thames, KT12 4RQ, UK

Identification mark: 0168

Le Mans, 12th March, 2004 Jean-Omer Kifouani

Quality Manager

In case your Philips product is not working correctly or

is defective, please return your phone to the place of

purchase or to the Philips National Service Center.

Refer to the International Guarantee shipped in the

box for information on Service centers and technical

documentation relevant to your equipment.

Philips755_3e Couv_GB.fm Page 78 Lundi, 17. mai 2004 3:02 15

Avantech Mobile CT7558 GSM 900/1800/1900 Mobile Phone User Manual Philips755 GB 4311 255 58341

Avantech Mobile GSM 900/1800/1900 Mobile Phone Philips755 GB 4311 255 58341

Contents

User Manual

Navigation menu

Namespaces

Views

Navigation
