User Manual
Discover Your Phone
Philips continuously strives to improve its
products.Therefore, Philips reserves the rights to
revise this user guide or withdraw it at any time
without prior notice. Philips provides this user
guide “as is” and does not accept, except as
required by applicable law, liability for any error,
omission or discrepancy between this user guide
and the product described. The device is meant to be
connected to GSM/GPRS networks.
How to ...
Alphanumeric
keypad
Microphone
262K colour
TFT LCD
N
avigation
Hang up and o
n
off k
e
L
eft softkey
Right softkey
Pick up key
Micro SD
card slot
Headset,
charger and
dat cable
connector
Speaker
Switch the phone
On/Off Long press and release ).
Enter your PIN
code Enter your PIN code using
the keypad and press , or
L to confirm.
Lock the keypad Press #
Make a call Enter the phone number
using the keypad and press
(.
End a call Press ).
Answer a call When the phone rings, press
(.
Silent an
incoming call When the phone rings, press
right softkey.
Reject a call When the phone rings, press
).
Philips XNRG_Master_EN.book Page 0 Thursday, November 15, 2007 4:59 PM
1
Softkeys
The left and right soft keys are located at the top of
keypad area. Pressing the soft keys allows you to
select the option displayed on the screen directly
above them, including options during a call. The
functions of the soft keys change according to the
current context.
Main Menu
You can access the different features of your Xenium
9@9j from the main menu. The following table
summarises the structure of the Main menu, what the
icons represent and the page number on which you can
obtain more information regarding the menu
functions.
Activate call
handsfree When the phone rings, press
, and press left softkey to
confirm.
Adjust
conversation
volume
Press up and down volume
side keys to adjust the volume
during a call.
Adjust ringer
volume When the phone is in idle
mode, long press volume
side keys to adjust the ring
volume of an incoming call.
Access all calls list Press ( in idle mode.
Access Settings Press + in idle mode.
Access Contacts Press - in idle mode.
Access Camera Press < in idle mode.
Access My Files Press > in idle mode.
Access Main
Menu Press ,.
Go to previous
menu Press left softkey when
browsing menu or in editing
mode.
Quickly return to
idle when
browsing menus
Short press ).
Philips XNRG_Master_EN.book Page 1 Thursday, November 15, 2007 4:59 PM
2
Press , in idle mode to access the main menu and
press +, -, < or > to navigate through the icons and lists,
or press 0 - 9 keys, and * or # keys to
access the options and functions directly. When
navigating through a list, the scrolling bar on the right
of the screen will indicate your current position in the
list. Press left softkey
Options
or , to access the
corresponding options of the selected item in the list.
Press right softkey
Back
to return to the previous menu.
.
Entertainment Browser Music&Radio
page 19 page 20 page 23
Camera Messages My Files
page 26 page 31 page 39
Tools Contacts Profiles
page 47 page 51 page 55
Connectivity Calls Settings
page 56 page 60 page 63
Philips XNRG_Master_EN.book Page 2 Thursday, November 15, 2007 4:59 PM
3
Table of contents
1. Getting Started ............................................6
Inserting the SIM card ......................................6
Switching on the phone ...................................8
Charging the battery ........................................8
Insert a micro SD Card ................................ 10
Setting hotkeys ............................................... 10
2. Calling ............................................................. 11
Make a call ....................................................... 11
Options during a call ..................................... 11
Mute or unmute a call ................................... 11
Adjust speaker/earpiece volume ................ 11
End a call .......................................................... 12
Make an international call ............................ 12
Make an emergency call ............................... 12
Make a second call (Network dependent) 12
Make a Conference Call (Network
dependent) ...................................................... 12
Switch calls (Network dependent) ............ 13
Call Handsfree ................................................ 13
Answer a call ................................................... 13
Reject a call ..................................................... 13
Answer a second call (Network
dependent) ...................................................... 13
Contact Picture .............................................. 14
3. Text and number entry ...................... 15
Input method .................................................. 15
Function keys .................................................. 15
Multitap ABC/Abc/abc .................................. 15
T9® text input ............................................... 16
Numberic Input .............................................. 17
Symbol input ................................................... 18
4. Entertainment ........................................... 19
Games .............................................................. 19
Java .................................................................... 19
5. Browser ........................................................ 20
WAP ................................................................. 20
Homepage ....................................................... 20
Bookmark ........................................................ 20
6. Music & Radio ........................................... 23
Music Player .................................................... 23
FM Radio .......................................................... 24
7. Camera .......................................................... 26
Camera mode ................................................. 26
Video mode ..................................................... 28
Philips XNRG_Master_EN.book Page 3 Thursday, November 15, 2007 4:59 PM
4
8. Messages ....................................................... 31
Create Message .............................................. 31
Inbox ................................................................. 33
Outbox ............................................................. 34
Draft .................................................................. 34
Templates ........................................................ 35
SIM archive ...................................................... 35
Voice mail server............................................. 35
Spam messages box ....................................... 36
Message Settings ............................................. 36
9. My Files .......................................................... 39
Pictures ............................................................. 48
Sounds .............................................................. 41
Playlist ............................................................... 42
Videos ............................................................... 43
Game & Java applications ............................. 44
10. Tools ............................................................ 47
Alarm ................................................................ 47
Organizer ......................................................... 47
Calculator ........................................................ 49
Converter ........................................................ 49
Flight Mode ....................................................... 49
Stopwatch ........................................................ 49
Auto Switch On/Off ...................................... 49
Lunar date converter .................................... 50
Horoscope ...................................................... 50
Chinese Festival Calendar ............................ 50
11. Contacts .................................................... 51
View contacts ................................................. 51
View groups .................................................... 52
Special numbers ............................................. 53
Settings ............................................................. 60
12. Profiles ........................................................ 55
13. Connectivity ............................................ 56
Bluetooth ......................................................... 56
Network .......................................................... 57
Configure browser ........................................ 57
Configure JAVA .............................................. 58
USB function ................................................... 59
14. Calls .............................................................. 60
Call list .............................................................. 60
GPRS counters ............................................... 60
GSM counters ................................................. 60
Call settings ..................................................... 60
15. Settings ....................................................... 63
General ............................................................. 63
Sounds .............................................................. 67
Display .............................................................. 68
Icons & Symbols ............................................ 69
Philips XNRG_Master_EN.book Page 4 Thursday, November 15, 2007 4:59 PM
5
Precautions ....................................................... 70
Troubleshooting ............................................ 75
Philips Authentic Accessories .............. 77
Trademark Declaration ............................ 78
Limited warranty .......................................... 79
Philips XNRG_Master_EN.book Page 5 Thursday, November 15, 2007 4:59 PM
6 Getting Started
1. Getting Started
Please read the safety instructions in the
"Precautions" section before use.
Before you start using your phone, you must insert
a valid SIM card supplied by your GSM operator or
retailer. The SIM card contains your subscription
information, your mobile telephone number, and a
small quantity of memory in which you can store
phone numbers and messages (for more
information, see “Contacts” on page 51).
You can also insert a memory card. This provides
you with expanded memory capability, which
allows you to store additional music, photo, and
video files separate from the phone's built-in
memory.
Inserting the SIM card
Remove the back cover
Make sure that the phone is switched off. You need
to remove the back cover of your phone before you
can insert the SIM card. Hold the phone with the
front facing downwards as shown in the diagram
and slide the back cover upwards as shown below .
Remove the battery
Lift the battery up from the bottom as shown below.
You may lose all your personal settings if you
remove the battery when the phone is switched on.
Insert the SIM card
Philips XNRG_Master_EN.book Page 6 Thursday, November 15, 2007 4:59 PM
Getting Started 7
Make sure that the clipped corner of the SIM card is
facing the correct direction and the metallic contacts
are facing downwards. Slide the SIM card into the
card slot until it stops. When you remove your SIM
card the first time, make sure that you smoothen the
edges, otherwise you may have difficulty sliding in
the card.
Replace the battery
With the metallic contacts facing downwards, press
the battery down into its slot until it locks into place.
Replace the back cover
Slide the back cover down into its slot until it stops.
When inserting the battery, be careful not to
damage the metallic connectors of the SIM card
slot.
Philips XNRG_Master_EN.book Page 7 Thursday, November 15, 2007 4:59 PM
8 Getting Started
Switching on the phone
To switch on the phone, long press and release the )
key. Enter the PIN code if required (the 4 to 8 digit
secret code of your SIM card). It is preconfigured and
provided to you by your network operator or retailer.
For more information on PIN code, see “Security
settings” on page 65.
If you enter an incorrect PIN code 3 times in
succession, your SIM card will be blocked. To
unblock it, you must obtain the PUK code from your
network operator.
Charging the battery
Your phone is powered by a rechargeable battery. The
new battery is partially charged. A sound alert will be
emitted to warn you when the battery level becomes
low.
We recommend that you do not
remove
the battery
when the phone is switched on as you may lose all
your personal settings as a result. If you do remove
it, the date and time settings are only memorized
for a short while. As such, you need to reset the
information after you have installed the battery
back again.
Once the battery and battery cover are installed, you
can charge the phone. Plug in the connector as
shown below. Then plug the other end into an AC
power socket.
Charging with a dry battery
This product is packaged with an Energizer Lithium
AAA battery. When you need immediate backup
power, replace the AAA battery in your phone with
a fresh battery. To maximize backup power, use the
Energizer Lithium AAA battery. For short bursts
of backup power, use an Energizer alkaline AAA
battery for reliable backup power.
To enhance the use of your phone, use an Energizer
Rechargeable AAA battery (not included) in the
phone, which can be kept in the battery cavity and
will charge when you charge your phone.
Philips XNRG_Master_EN.book Page 8 Thursday, November 15, 2007 4:59 PM
Getting Started 9
You need to open the battery cover with the
decoration piece provided and then insert an AAA
battery as shown below.
The battery symbol indicates the state of charge.
During charging, the charge indicators will scroll; it
takes around 3 hours to fully charge the battery.
When all the scroll bars are steady, the battery is
fully charged. You can then disconnect the charger.
Depending on the network and condition of use, talk
time and stand-by time can go up to 10 hours* and
1 month* respectively. The dry battery (when fully
charged) can provide you with an extra 2 hours and
300 hrs of talk time and stand-by time respectively.
The phone supports Alkaline, Lithium and
rechargeable Nickel Metal Hydride (NiMH)
batteries regardless of the brand.
*Depending on the network conditions, user
settings, method of use, etc the actual results may
differ.
The scrolling icons of the dry battery level
indicator displays the status of charging only when
you use a rechargeable dry battery.
Keeping the charger plugged to the mobile phone
when the battery is fully charged will not damage
the battery. The only way to turn off the charger is
to unplug it, so it is advisable to use an easily
accessible AC power socket.
If you do not intend to use your phone for several
days, we recommend that you remove the battery.
You can use the phone while it is charging (note
that the vibra alert goes off when the charger is
connected). If the battery is completely flat, the
battery icon will only reappear after a few minutes
of charging.
Philips XNRG_Master_EN.book Page 9 Thursday, November 15, 2007 4:59 PM
Getting Started 10
Insert a micro SD Card
1. Gently slip the card into the micro SD card
slot, with the gold contacts facing downwards.
2. Then press the micro-SD down until the card
locks into place.
To remove the micro SD card, push down the card
into its slot and release it. The card will spring out
of the slot.
Setting hotkeys
You can configure the numeric keys 2 - 9, +, -
, <, >, up and down softkeys to access your favorite
features. Once they have been set, you can simply
long press the numeric key to access the
corresponding features.
Philips XNRG_Master_EN.book Page 10 Thursday, November 15, 2007 4:59 PM
Calling 11
2. Calling
Make a call
From idle screen
1. In idle mode, enter the phone number with the
keypad. To correct an error, press left softkey.
2. Press
(
to dial the number.
3. Press
)
to hang up.
To make an international call, long press
0
to
insert the international prefix “+”.
Using the phonebook
1.
Press
-
in idle mode.
2. Select a contact from the list, press
(
to dial.
To select a different number, press
+
or
-
(see
“Contacts” for more information).
3. Press
)
to hang up.
IP call (China only)
You may select IP call. When you select IP call
option, the mobile phone will automatically add the
IP special service number preset by you in front of
the phone number and then make IP call.
When you have entered several IP special service
numbers, you will be prompted to verify them to
avoid adding them repeatedly.
Options during a call
During a call, you can press
L
Options
to carry out
the following operations:
- Activate/Deactivate Handsfree
-Use the BT headset
- Mute/Unmute the call
- Put the call on Hold
- Access the Scratchpad
- End the call
- Access Main menu
Mute or unmute a call
During a call, press left or right softkey to
Mute
or
Unmute
. If you select
Mute
, the microphone will be
deactivated.
When you switch from one call to another, muting
will be cancelled.
Adjust speaker/earpiece volume
During a call, call on hold or call waiting, you can
press +/- side keys to increase or decrease the
Philips XNRG_Master_EN.book Page 11 Thursday, November 15, 2007 4:59 PM
12 Calling
volume (if you are not browsing the call options
menu).
When the volume has been set, the call volume will
take effect immediately and the settings will be
applied to your subsequent calls.
End a call
Press left softkey and select
End call
or
)
to end a
call.
Make an international call
1. Long press
0
until "+" appears on the screen.
2. Enter the country code.
3. Enter the area code (normally without the 0 in
front), followed by the phone number.
4. Press
(
to call directly.
Make an emergency call
You can make an emergency call anytime,
irrespective of whether the mobile phone has been
registered on the network.
1. In idle mode, enter the emergency call number
(specific number in the caller's country)
2. Press
(
.
Note that an emergency call will not be stored in
the call record.
Make a second call (Network
dependent)
You can make a second call by putting the current
call on hold:
1. During a call with Party A, you can enter
Party's B number using the keypad.
2. Press
(
to dial Party B's number. Party A will
be put on hold automatically.
Make a Conference Call (Network
dependent)
Your phone supports multi-party call of up to five
members. The screen will display Conference call
during the multi-party call.
When there is a call waiting while you are already
on the phone, you can carry out the following
operations to establish the multi-party call:
1. Press
(
to answer the second call. The first call
will be put on hold automatically.
Philips XNRG_Master_EN.book Page 12 Thursday, November 15, 2007 4:59 PM
Calling 13
2. Select Conference Call from the call menu. The
two calls will be combined and a conference
call is established.
During the multi-party call, you can answer a new
incoming call or add a new member to the call by
dialing the new member (the ongoing multi-party
call will be put on hold automatically). Once the call
is established, select Establish conference call from
the call menu to add the new member to the multi-
party call (you can add up to five members).If you
wish to separate one member from the call, you can
select Split conference Call during the multi-party
call. To disconnect a member from the call, select
End call in conference.
Switch calls (Network dependent)
When you have one active call and one call on hold,
you can press left softkey
Options
, then select
Swap
calls
to switch between the 2 calls.
Call Handsfree
During a call, press left softkey
Options
and select
Handsfree
.
When the headset is plugged into the phone, you
cannot activate handsfree mode.
Answer a call
Press
(
to answer a call.
Reject a call
Press
)
to reject a call.
Answer a second call (Network
dependent)
If you have activated
Call waiting
, you will be alerted
when there is a second incoming call. You can:
1. Press
(
to answer the second call. The current
call will be put on hold automatically.
2. Press
)
to reject the second call and continue
with your current call.
3. When there is one active call and one call on
hold, you can press
L
Options
to carry out the
following operations:
If you press the numeric keys, the notepad editor
will opened under call waiting mode.
• Handsfree • BT headset • Mute
• Scratchpad • End call • Swap calls
• End all calls
Philips XNRG_Master_EN.book Page 13 Thursday, November 15, 2007 4:59 PM
14 Calling
Contact Picture
This feature allows you to link a contact in your
phonebook to a photo you have taken using the
Camera function, or a picture you have downloaded
via WAP or data cable. During a call, if the other
party's name card is linked to a picture, the
incoming call background will display the
corresponding picture. This feature is referred to as
Contact picture.
Contact picture is only available on the phone
memory. The photo size should not be larger than
128 x 160 pixels.
Philips XNRG_Master_EN.book Page 14 Thursday, November 15, 2007 4:59 PM
15 Text and number entry
3. Text and number entry
Input Method
Your phone supports 6 types of input methods:
Multitap ABC/Abc/abc
T9 ABC/Abc/abc
T9 PinYin
Simplified Chinese stroke
Numeric
Symbols
You can select in the option list the appropriate input
method to enter English letters, words, symbols and
numbers. Icons appearing on the screen indicate the
active input mode.
Function keys
Multitap ABC/Abc/abc Input
1. Press once on the numeric key (2 to 9) to
enter the first letter on the key, press twice to
enter the second letter on the key, so on and so
forth. If the letter you wish to enter and the one
you have just entered are on the same key, just
wait for a few seconds for the cursor to re-
appear.
2. Press right soft key to delete the characters on
the left of the cursor.
Example: how to enter the word "home":
Press 4, 4 (GHI) 6, 6, 6 (MNO), 6
(MNO), 3, 3 (DEF). Press , when the message
is completed.
You can press key
0
to insert a space in ABC/abc
Multitap input mode.
Right
softkey Delete the characters on the left of the
cursor or exit from editing mode.
+/-/</>Move the cursor, select a letter, word or
symbol from the list, or scroll down a list.
)Return to idle mode.
Left
softkey Select the highlighted word from the list
or enter Options menu.
*Enter symbols.
#long press to switch between Multitap and
T9 inputs.
Philips XNRG_Master_EN.book Page 15 Thursday, November 15, 2007 4:59 PM
Text and number entry 16
The letters located on each key are as follows:
T9® text input
T9® Predictive Text Input is an
intelligent editing mode for entering
text on a mobile phone. It allows you to
enter text more quickly by anticipating
the word you want to enter based on the
keys you have pushed. You press once on the key
corresponding to each letter needed to spell a word
and T9® suggests a word based on your keystrokes.
If several words are available, the first word in the
list is displayed and highlighted. Press +/- or left
softkey to browse the list and press , to insert the
word.
T9 ABC/Abc/abc Input
Smart English input method offers a faster way for
you to enter English words.
1. You only need to press once on the numeric
key (2 to 9) corresponding to each letter
needed to spell a word. As you enter the
letters, the words displayed on the screen will
be updated accordingly.
2. Press right softkey to delete the entries on the
left of the cursor.
3. Use + and - to select the desired word and
press left softkey to enter it.
Examples: how to enter the word "home":
1. Press 4, 6, 6, 3. The screen displays
the first word of a list: Good.
2. Press - to scroll and select Home.
3. Press , to confirm.
T9 PinYin Input (China & Hong Kong only)
This is an intelligent editing mode that not only
allows you to press only once on a key
corresponding to each letter needed to form a
Key
Characters in the order displayed
1 . ,' ? ! " @ : ; / ()1
2 a b c 2
3 d e f 3
4 g h i 4
5 j k l 5
6 m n o 6
7 p q r s 7
8 t u v 8
9 w x y z 9
00
Tegic Euro. Pat.
App. 0842463
Philips XNRG_Master_EN.book Page 16 Thursday, November 15, 2007 4:59 PM
17 Text and number entry
character, but is also equipped with association
input feature. Keystrokes are analysed and all the
possible pinyin combinations will be displayed at
the bottom of the screen.
Using T9 PinYin input method
1. Enter the pinyin letters accordingly. Press once
on the key corresponding to the pinyin letter
without having to consider its position on the
key. As you enter the letters using your
keypad, the pinyin combinations on the screen
will be updated accordingly.
2. Press < or > to select the character (the selected
pinyin character will be highlighted) and press
, to confirm.
3.
Enter the association character: As soon as you
have selected and entered a character, the
candidate list will be updated and a list of
association characters will be displayed. Press <
or > to select the desired association character
and press to , confirm entry.
Simplified Chinese Stroke Input (China & Hong
Kong only)
Using Stroke input method
1. Enter the strokes: Enter the strokes of the
chinese character according to its stroke
sequence. When you press the keys
corresponding to the required strokes, the
strokes will display on the screen. The phone
will display the candidate characters
corresponding to the strokes you have entered.
As you enter the strokes, the candidate
characters on the screen will be updated
accordingly.
2. Enter character: Press < or > to select the
required chinese character from the candidate
list. Press , input the chinese character and
press right softkey to clear the strokes you
have entered.
3. Enter associate character: As soon as you have
selected and entered a character, the candidate
list will be updated and a list of association
characters will be displayed. Press < or > to
select the desired association character and
press , to confirm entry.
Numeric input
1. Press # to switch to Symbol input method
list
2.
Press the numeric keys (0 to 9) to enter
the numbers corresponding to the keys.
3. To delete a number, press right softkey.
Philips XNRG_Master_EN.book Page 17 Thursday, November 15, 2007 4:59 PM
Text and number entry 18
Symbol Input
Press * to enter punctuation or symbols. Use the
navigation keys to select the desired punctuation or
symbol and press left softkey or to , to enter it.
Philips XNRG_Master_EN.book Page 18 Thursday, November 15, 2007 4:59 PM
Entertainment 19
4. Entertainment
This section describes the games and additional
tools installed on your mobile phone.
Some of the features described here are dependent
on the configuration of your mobile phone, the
country in which you purchased your mobile
phone, and/or your service provider.
Games
Default games
This menu features games that are pre-installed in
your mobile phone. Press , to enter the main menu
from idle mode and select Entertainment > Games.
Java
Your mobile phone features a Java run-time
environment, which allows you to run Java
applications, such as games downloaded from the
network.
•Press Java > Launch to launch a new application
after you download it into the phone.
Philips XNRG_Master_EN.book Page 19 Thursday, November 15, 2007 4:59 PM
20 Browser
5. Browser
Your phone comes with a WAP browser. You can
obtain news, sports and weather information, as
well as services from the internet via the WAP
browser.
This feature is available only if your subscription
includes WAP access services. The settings have
been pre-configured (depends on country
variants) and you do not need to modify them. For
more information, please contact your network
operator.
WAP
Normally, the phone would have been pre-
configured. If you wish to add or modify the
configuration parameters, you need to obtain the
necessary information from your network
operator before you proceed. Philips is not liable to
give prior notification nor shall it bear any
consequences for any failures arising from
changes of configuration made by you or by the
network operator. Please check with your network
operator for the most updated information.
Homepage
Select this menu to access the homepage directly.
You can also set the homepage address in the
settings menu.
Bookmark
You can save the current web page or the web pages
that you frequently visit to the
Bookmark
list, manage
and organize them.
When you enter the menu, a list of bookmark entries
is displayed. To connect to the web address of a
particular bookmark entry, select an entry using + or
- and press ,.
To add a new bookmark, press , to enter the main
menu from idle mode and select Browser >
Bookmark. Select <New bookmark> and press left
softkey or ,. Then Enter the Bookmark name and
URL of the new bookmark and press left softkey or
,.
To manage a bookmark, press , from idle mode to
enter the main menu and select Browser >
Philips XNRG_Master_EN.book Page 20 Thursday, November 15, 2007 4:59 PM
Browser 21
Bookmark. Then select a bookmark from the list and
press left softkey to access the following options:
History
This menu allows you to manage, organize and
quickly access the web pages you have previously
visited.
1. When you enter this menu, the web pages you
have previously visited will be listed.
2. Press left softkey
Options
to access the
following:
Go to address
Enter the web address and press left softkey or , to
access the following options:
Configure browser
This menu allows you to configure the
Browser
settings
and select the
WAP profiles
in
Browser connection
profiles
for web browsing. Your phone may have
been pre-configured with the settings of a specific
network operator. If you are a subscriber of the
network operator, you may start using your WAP
browser immediately. Otherwise, you need to re-
configure the settings.
Launch Access the bookmark
page.
View/Edit View/edit bookmark
name/address.
Set as homepage Set the bookmark as
homepage
Send bookmark Send the bookmark to
your contact.
Delete Remove the bookmark.
Homepage Save as
Back Send as MMS
Forward Save as homepage
Refresh Exit
Bookmark Setting
Enter address
Launch Access the web page.
View/Edit View/edit the web page
name/address.
Set as homepage Set the bookmark as
homepage
Send address Send the address to your
contact.
Delete Remove the web
address.
Philips XNRG_Master_EN.book Page 21 Thursday, November 15, 2007 4:59 PM
22 Browser
Philips is not liable to give prior notification nor
shall it bear any consequences for failures arising
from changes in configuration made by you or by
the network operator, or changes in WAP address
or contents made by the internet content provider.
Please check with your network operator and your
internet content provider for the most updated
information.
The following options are available for
Browser
settings
:
Display
settings
Title display: Allows you to choose
Show title or hide title.
Vertical scrolling: Allows you to
choose By line or By page.
Info on exit: Allows you to choose
No info, Volume only, Duration only or
Duration and volume.
Security
Settings
Cookies: Allows you to choose
Allow cookies or No cookies.
Clear cookies: Select to clear
cookies.
Show certificates : Display the list of
installed certificates.
Clear Cache
Allows you to delete all Cache
contents.
Philips XNRG_Master_EN.book Page 22 Thursday, November 15, 2007 4:59 PM
Music & Radio 23
6. Music & Radio
Music Player
This menu allows you to play music. The music
stored in the music player folder will be
automatically detected and added to the play list.
When the music is playing, you can dial or answer
an incoming call. The player will pause once the
connection is established.
Activate Music Player
Press , in idle mode to access the main menu, then,
select Music & Radio > Music Player.
The following table describes the operations of the
various keys when playing music:
, Play/Pause
+/+ side key Adjust volume up
-/- side key Adjust volume down
< Skip to the previous music track
>Skip to the next music track
Left softkey Access Option menu.
Right softkey Exit Music Player and return to
previous screen
Philips XNRG_Master_EN.book Page 23 Thursday, November 15, 2007 4:59 PM
24 Music & Radio
Option menu of the Music Player FM Radio
This menu allows you to listen to the radio on your
phone. Press , in idle mode to access the main
menu, then, select Music & Radio > FM radio.
Connect the headset connector to your phone before
you can activate the radio function.
The following table describes the operations of the
various keys when listening to the radio:
Play Play the selected music track.
Open tracks list Open the track list of the selected
folder.
Activate
Bluetooth
Enable the Bluetooth function for
file transfer.
Shuffle and
repeat
Select among Off, Repeat track,
Repeat all, Shuffle or Shuffle and
repeat.
Add to playlist Add the track to the Playlist folder
to choose from when selecting a
musc track in File Manager.
Delete Remove the selected track.
Details Display detailed info of the music
track.
Rename Edit the name of the track.
Background
play
Access other menus with music
playing at the background.
Exit Exit from the music play menu.
, Play/Pause
+/+ side key Adjust volume up
-/- side key Adjust volume down
</>Manual tune up/down the radio
frequency.
Left softkey Access Option menu.
Right softkey Exit FM radio and return to
previous screen
Philips XNRG_Master_EN.book Page 24 Thursday, November 15, 2007 4:59 PM
Music & Radio 25
Option menu of the FM radio
Start/Stop
radio
Start/Stop playing the radio.
Activate/
Deactivate
Handsfree
Enable/Disable the handsfree
function.
Save station Save the current radio frequency to
selected preset.
Strongest
stations list
Show the list of radio frequecy with
the strongest broadcast signals.
My stations Save the preferred radio frequency
to selected preset.
Set
frequency
Set a frequency for listening or
saved it into a preset.
When you starts manually tuning
from a preset station, the preset
number will be removed.
Auto Tune Automatically scan for radio
frequency and then saved it into the
20 preset stations.
Background
play
Access other menus with radio
playing at the background.
Exit Exit from the FM radio menu.
Philips XNRG_Master_EN.book Page 25 Thursday, November 15, 2007 4:59 PM
Camera 26
7. Camera
Your mobile phone features a digital camera that
allows you to take pictures and record videos, store
them in your phone and memory card, use them as
wallpaper or send them to your friends.
Please ensure that the camera lens is clean before
you take pictures, as small dust particles can
strongly affect the picture quality.
Camera mode
The following table describes the operations of the
various keys in camera mode. Options menu of the Camera
When the camera mode is activated and before a
picture is taken, you can change a number of
settings by pressing left softkey Options.
+
/
-
Zoom in / out
<
/
>
Switch between Camera/Video mode.
,
Take a picture.
The picture will be automatically saved
and stored in My Files > Pictures.
)
Exit Camera mode and return to idle
mode.
Left
softkey Access Option menu
Right
softkey Return to previous screen
+/- side
keys. Adjust brightness.
Brightness level is -3 to +3. Default
level is 0.
1
Set image size.
2
Set image quality.
5
Set Delay Timer.
6
Activate / deactivate Continous shot.
Options Description
Take
Press
,
.
View saved
pictures
Enter My Files > Pictures to view the
pictures taken.
Philips XNRG_Master_EN.book Page 26 Thursday, November 15, 2007 4:59 PM
27 Camera
Photo preview option menu
Once you have activated the camera, simply press
,
to take a picture. The picture is automatically saved
and displayed on the screen. You can press left
softkey Options to carry out the following
operations:
size
Select image size: 1280x1024,
1024x768, 800x600, 640x480,
320x240, 176x220 and 128x96.
Quality
Select image quality: Super fine, Fine
and Normal.
The last selected value will remain
active until you change it again.
Camera
modes
Self-timer: On or Off
The time limit is 8 seconds.
Multishot: On or Off
Six pictures can be taken at the
same time.
Snapshot
sound
No sound or select between Snapshot
1 to Snapshot 5.
Special
effects
Color effect: No effect (default), Black
and White or Sepia.
The selected color effect will be
displayed on the screen in real time.
Help View information for image effect.
Advanced Storage settng: Phone memory or
Memory card
Picture prefix name: modify the
default name of the photo
Options Description
Take
Press
,
.
Send via Send the picture via Bluetooth or MMS.
Delete Delete the current picture.
Rotate Select from +90 degree, 180 degree or
-90 degree.
Add to
contacts
Link the picture to a contact in your
mobile phone so that the picture will
be displayed when the contact calls
you.
Philips XNRG_Master_EN.book Page 27 Thursday, November 15, 2007 4:59 PM
Camera 28
When there is not enough memory space, you will
not be able to save the picture and you will be
prompted wtih a warning message. You have to
delete existing pictures before you can store new
ones.
Video mode
The following table describes the operations of the
various keys in video mode.
Options menu of the Video
When the video mode is activated and before you
start recording, you can change a number of settings
by pressing
L
Options.
Set as
wallpaper
Set the picture as a wallpaper in idle
screen.
+
/
-
Zoom in / out
<
/
>
Switch between Camera/Video mode.
,
Start/Pause recording.
The video will be automatically saved
and stored in My Files > Videos.
)
Exit Video mode and return to idle mode.
Left
softkey Access Options menu
Right
softkey Return to previous screen
+/- side
keys. Adjust brightness.
Brightness level is -3 to +3. Default
level is 0.
1
Set video size.
2
Set video quality.
Options Description
Record Press
,
.
View saved
videos
Enter My Files > Videos to view the
videos taken.
Video
size
Select image size: 176x144 and
128x96.
Video
Quality
Select image quality: Super fine, Fine
and Normal.
The last selected value will remain
active until you change it again.
Philips XNRG_Master_EN.book Page 28 Thursday, November 15, 2007 4:59 PM
29 Camera
Video preview option menu
Once you have activated the camera, simply press
,
to take a picture. The picture is automatically saved
and displayed on the screen. You can press left
Special
effects
Color effect: No effect (default), Black
and White or Sepia.
The selected color effect will be
displayed on the screen in real time.
Help View information for video effect.
Advanced Storage settng: Phone memory or
Memory card
Video prefix name: modify the default
name of the video.
Record time: Unlimited (free memory)
or MMS size.
If you select MMS, the size of the
recorded video will be smaller than
the currently specified maximum
MMS size. Recording will stop
when reaching the maximum MMS
size and the video will be stored
automatically. If you select
Unlimited, there will be no
restrictions on the size of the
recorded video. The maximum size
shall be determined by the memory
capacity of your mobile phone or
the memory card.
Philips XNRG_Master_EN.book Page 29 Thursday, November 15, 2007 4:59 PM
Camera 30
softkey Options to carry out the following
operations:
When there is not enough memory space, you will
not be able to save the picture and you will be
prompted wtih a warning message. You have to
delete existing pictures before you can store new
ones.
Options Description
Record Press
,
.
Play Play the recorded video.
Send Video Send the picture via Bluetooth or MMS.
Delete Delete the current picture.
Philips XNRG_Master_EN.book Page 30 Thursday, November 15, 2007 4:59 PM
31 Messages
8. Messages
This menu allows you to send and receive text or
multimedia messages, as well as manage the
messages you have sent and received. In idle mode,
press left softkey to access Messages menu directly.
You can also press
,
and select Messages to create,
edit and send your messages.
Create Message
When you have accessed the Messages menu, you
can press left softkey Select and select SMS or MMS
to create your message.
When writing messages, you can toggle between
smart input multitap and numeric by pressing
#
SMS
SMS enables you to send text messages to the other
party, using Short Messaging Service (SMS),. You
can use the SMS menu to send messages to another
another or a device that is capable of receiving
SMS. To compose and send an SMS, follow the
steps below:
1. Select Create Message and press left softkey
and select SMS. Then enter your text and
pressleft softkey to access the following
options:
Continue
Add from contacts: Select the
recipient from
Contacts
list.
Recipient from group: Select the
recipient from
Groups
.
Enter number: Enter the phone
number of the recipient.
Text format
Alignment: Select from: Left, Center
or Right.
Text size: Select from: Small, Normal
or Big.
Style: Select from: Normal, Bold or
Italic.
Attribut: Select from: None,
Underline or Strikethrough.
Save as
Save the SMS as Draft or Template.
Preferred
edition mode
Select from: Smart or Multi-tap.
Text input
language
Set the
Text input language
from the
list.
Philips XNRG_Master_EN.book Page 31 Thursday, November 15, 2007 4:59 PM
Messages 32
2. After you have finished, press
,
to send your
SMS.
MMS (network dependent)
Your mobile phone can also send and receive MMS
(Multimedia Messaging Service) messages. With
MMS, you can send messages that contain pictures,
sound and text.
Before you can send MMS, you need to enter the
correct MMS Center number and ensure that the
network profile of your MMS has been correctly
configured. You can obtain such information from
your network operator.
When sending MMS messages, your recipient must
also have an MMS-enabled phone in order to view
your messages. Follow the steps described below to
compose and send an MMS:
1. Select Create Message and press left softkey
and select MMS. Then enter your text and
pressleft softkey to access the following
options:
Continue
Add from contacts: Select the
recipient from
Contacts
list.
Recipient from group: Select the
recipient from
Groups
.
Enter number: Enter the phone
number of the recipient.
Add media
Add Pictures, Videos, Sounds, Contact
number and/or V-card into your
MMS.
Media file
and
attachment
Insert a file (txt, jar etc) to your
message.
Page...
Allows you to Add page or Delete
page.
Edit subject
Edit the subject of the MMS.
Preview
Preview the current MMS.
Save as
Save the MMS as Draft or Template.
Page timing
Set play time of the MMS slides.
The default value is 4 seconds.
Philips XNRG_Master_EN.book Page 32 Thursday, November 15, 2007 4:59 PM
33 Messages
2. After you have finished, press
,
to send your
MMS.
Inbox
The Inbox stores the messages you have received.
1. In idle mode, press
,
to enter the main menu.
2. Select
Messages
>
Inbox
and press
,
.
3. If there are messages in the Inbox, they will be
listed on the screen in the order they were
received (the most recent message will appear
at the top of the list).
4. Press
+
/
-
to select a message. When a message
is selected, its contents will be displayed on the
screen. Press
L
Options to carry out the
following operations:
Preferred
edition mode
Select from: Smart or Multi-tap.
Text input
language
Set the
Text input language
from the
list.
View
View the selected message.
Reply to
sender by...
The sender's number will be used as
the destination number
automatically You can select SMS or
MMS to reply and send the message.
Forward
When you select
Forward
, the
contents of the selected message
will appear in the message editor.
You may edit the message before
sending.
Delete
Delete the message from the Inbox.
Delete all
Delete all the messages in the
Inbox.
Forward
When you select
Forward
, the
contents of the selected message
will appear in the message editor.
You may edit the message before
sending.
Call back
sender...
Call the sender.
Call back
with...
Allows you to call the sender with
IP, Handsfree or IP with handsfree.
Store number
Save the sender’s number in
Contacts
.
Details
View information of the message
such as date, time, sender and
message size.
Philips XNRG_Master_EN.book Page 33 Thursday, November 15, 2007 4:59 PM
Messages 34
Outbox
The
Outbox
allows you to save the messages you
have not sent successfully.
1. In idle mode, press
,
to enter the main menu.
2. Select
Messages
>
Outbox
and press
,
.
3. If there are messages in the
Outbox
, they will be
listed on the screen.
4. Press
+
/
-
to select a message. When a message is
selected, its contents will be displayed on the
screen. When you press left softkey
Options
, you
can carry out the following operations:
Draft
List the messages that were created and saved but
were not sent, and messages that were automatically
saved before you were able to save or send them
when you exit from the message editor.
Select a message from the Draft box and press left
softkey
Options
to:
View
,
Edit
, Send,
Details,
Delete
, and
Mark. If you select
View
, the subsequent procedures
would be similar to the Inbox operations.
Archive
Add the selected message to the
SIM card..
Save as
template
Save and use as a preset message.
Mark
You can select Mark one by one or
Mark all.
Mark as Spam
Message
Add the selected message to the
Spam Message box.
.and the sender’s
number to Blacklist.
View
View the selected message.
Resend
Resend the message to the recipient.
Details
View information of the message
such as date and time.
Delete
Delete the message from Outbox.
Delete all
Delete all the messages in Outbox.
Details
View the information of the message
such as date and time.
Save as
template
Save and use as a preset message.
Mark
You can select Mark one by one or
Mark all.
Philips XNRG_Master_EN.book Page 34 Thursday, November 15, 2007 4:59 PM
35 Messages
Templates
If you have save message as a template in creating
SMS or MMS, this menu allows you to send, add,
modify and delete your preset messages.
SIM archive
In the menu, you can see the read and unread
messages saved in the SIM Card. The available
options include:
Voice Mail Server
This menu allows you to set your voice mail server
number, as well as retrieve your voice mails. When
you receive a voice mail, your network operator will
Options Description
View Open the current message and view
the detailed contents of the message.
Reply to
sender by...
The sender's number will be used as
the destination number automatically
You can select SMS or MMS to reply
and send the message.
Delete Delete the message from SIM archive.
Delete all Delete all messages in SIM archive .
Forward When you select
Forward
, the contents
of the selected message will appear in
the message editor. You may edit the
message before sending.
Call back
sender...
Call the sender.
Call back
with...
Allows you to call the sender with IP,
Handsfree or IP with handsfree.
Store
number
Save the sender’s number in
Contacts
.
Details
View the information of the message
such as date and time.
Move to
phone
Move the message to the phone
memory.
Save as
template
Save and use as a preset message.
Mark
You can select Mark one by one or
Mark all.
Mark as
Spam
Message
Add the selected message to the
Spam Message box.
.and the sender’s
number to Blacklist.
Philips XNRG_Master_EN.book Page 35 Thursday, November 15, 2007 4:59 PM
Messages 36
send a notification to your phone.
You can enter four sets of voice mail server
numbers which are supplied by your network
operator.
Select a voice mail box and press left softkey to
access the following options:
You can quickly access your voice mail server by
long pressing
1
key in idle mode.
Spam messages box
This menu allows you to filter the SMS/MMS after
the firewall has been set. When the firewall is
activated, any SMS/MMS from a person on your
blacklist will go to the Spam messages box. Select a
message on the Spam messages box list in the and
press left softkey to access the following options:
Message Settings
SMS
Select Messages > message settings. Then press left
softkey and select SMS to open the SMS setting
options:
Delivery report
You can select left softkey
On
or
Off
. This option
allows you to set whether or not to notify you the
send status of your messages: successfully sent to
the recipient, or not sent successfully.
This feature is subscription dependent.
View/Edit Read or modify voice mail
number.
Call Call the voice mail number.
Handsfree Call the voice mail number
handsfree.
Delete Delete the voice mail number.
View spam
message
Read the selected spam message.
Delete spam
message
Delete the select spam message
from the Spam messages box .
Delete all spam
messages
Delete all the select spam
message from the Spam messages
box.
Move to inbox Move the spam message to Inbox
to edit or send.
Philips XNRG_Master_EN.book Page 36 Thursday, November 15, 2007 4:59 PM
37 Messages
Auto save in outbox
You can select left softkey
On
or
Off
. When
On
, all
the unsent email will be saved in
On
.
Signature
You can press leftsoft key and select
Activation > On
or
Off
. Then enter your signature on the
Enter
signature
option.
If the SMS is too long after adding the signature,
the signature will be ignored.
Validity period
Allows you to select the duration by which your
messages will be stored in the service center. You
can select from:
1 hour
,
8 hours
,
1 day
,
3 days
,
1 week
and
Maximum
. Press
+
/
-
to select a value.
This option is useful when your recipient is not
connected to the network and is not able to receive
your messages immediately.
This feature is subscription dependent.
SMS Center
This menu allows you to save and edit the SMS
service center number of your home network. If the
service center number is empty, you will not be able
to send any SMS.
Reply Path
When , this option allows you to transmit the
number of your SMS message center together with
the message. The recipient can then repy using your
SMS center and not theirs. This speeds up the rate
of transmission. This feature is subscription
dependent.
Storage location
You can press
L
Change to select the preferred
storage location of your messages:
SIM
card
(Default) or
Mobile phone
.
MMS
This menu allows you to set your MMS center and
personalize your MMS settings. Select Messages >
message settings. Then press left softkey and select
MMS to open the SMS setting options:
MMS connection profiles
You can select or edit the parameters.
Read report
You can press
<
/
>
to set this option
On
or
off
. When
set to
On
, a report will be sent to notify you if the
MMS has been read by the recipient.
Delivery report
You can press
<
/
>
to set this option
On
or
Off
. This
option allows you to set whether or not to notify you
Philips XNRG_Master_EN.book Page 37 Thursday, November 15, 2007 4:59 PM
Messages 38
the send status of your messages: successfully sent
to the recipient, or not sent successfully.
Auto save in outbox
You can press
<
/
>
to set this option
On
or
Off
. When
On
, all the unsent email will be saved in
On
.
Validity period
Allows you to select the duration by which your
messages will be stored in the service center. You
can select from:
1 hour
,
12 hours
,
1 day
,
1 week
and
Maximum
. Press
<
/
>
to select a value.
This option is useful when your recipient is not
connected to the network and is not able to receive
your messages immediately.
Retrieval mode
Allows you to select Automatic, or Manual when
downloading of MMS messages.
Default slide duration
Allows you to change the value of slide duration
and to set a delay between each slide.
Hide identity
You can press
<
/
>
to set this option
Never
or
Always
.
It is used to set if your identity will be visible when
MMS is sent.
Philips XNRG_Master_EN.book Page 38 Thursday, November 15, 2007 4:59 PM
My Files 39
9. My Files
This menu allows you to store the files in different
folders (Pictures, Sounds, Playlists, Videos, Game &
Java applications) to facilitate more efficient
management of files in your phone and the memory
card. In addition, you can obtain information
regarding your phone and memory card, such as
number of files, memory utilized, percentage of
memory utilised via the Memory status option. Press
, in idle mode to access the main menu, and select
My Files.
Then Press left softkey Options to access the
following folder options:
Pictures
When you enter this menu, the photos which you
have taken using the phone's camera as well as
pictures you have downloaded via MMS, WAP, BT,
or USB will be displayed in a list.
1. Select
My files
>
Pictures
and press , to enter the
menu.
Open folder Open the selected folder.
Folder
properties
Sort order: Sort the pictures and
folders by increasing or decreasing
alphabetical order.
Sort direction: Sort the pictures and
folders by name or date
Choose view: You can select to view
the pictures in
List view
,
Grid view
or
Full
screen
.
Rename
folder
Modify the name of the folder.
You cannot rename the preset
folders.
Delete Folder Remove the folder.
You cannot delete the preset
folders.
Philips XNRG_Master_EN.book Page 39 Thursday, November 15, 2007 4:59 PM
40 My Files
2. Press left softkey
Options
>
Open folder
to carry
out the following operations to a selected file:
Options Description
View picture
View the picture in full screen.
Send via
Send the selected file:
MMS
and
Bluetooth
.
Set as Set as wallpaper
: The selected photo
will be displayed as wallpaper.
Set as contact picture
: If you select this
option, the phonebook list will be
displayed. After you have selected a
contact from the phonebook, press
,
to associate the picture to the
selected contact.
Set as group picture
: If you select this
option, the phonebook group list
will be displayed. After you have
selected a contact group from the
phonebook, press ,
to associate the
picture to the selected group.
Rotate Select to rotate the picture by +90
degree, 180 degree or -90 degree.
Mark Mark one by one: select the picture
one by one and then move, copy,
delete or send the pictures.
Mark all: select all the pictures and
then move, copy, delete or send the
pictures.
Manage
file
Select Move to folder or Copy to folder
to move or copy the selected picture to
another folder. If Move to folder is
selected, the source picture will be
deleted once the file has been moved.
Rename
file
Modify the name of the selected
picture.
Delete Remove the selected picture.
File
properties
Display the detailed information of the
picture.
Folder
properties
Sort order: Sort the pictures and
folders by increasing or decreasing
alphabetical order.
Sort direction: Sort the pictures and
folders by name or date
Choose view: You can select to view
the pictures in
List view
or
Grid view
.
Philips XNRG_Master_EN.book Page 40 Thursday, November 15, 2007 4:59 PM
My Files 41
Sounds
When you enter this menu, the sounds which you
have stored or downloaded via MMS, WAP, BT,
Infrared or USB will be displayed in a list.
1. Select
My files
>
Sounds
and press , to enter the
menu.
2. Press L
Options
>
Open folder
to carry out the
following operations to a selected file:
Play sound/
Stop Playback
Play/Stop playing the selected
audio file.
Send sound
Send the audio file via
MMS
or
Bluetooth
.
Set as Set as ringtone
: The selected audio
file will be used as ringtone.
Set as contact ringtone
: If you select
this option, the phonebook list will
be displayed. After you have
selected a contact from the
phonebook, press ,
to associate
the ringtone to the selected contact.
Set as group ringtone
: If you select this
option, the phonebook group list
will be displayed. After you have
selected a contact group from the
phonebook, press ,
to associate
the ringtone to the selected group.
Set as message ringtone
: The selected
audio file will be used as message
ringer.
Philips XNRG_Master_EN.book Page 41 Thursday, November 15, 2007 4:59 PM
42 My Files
Playlists
When you enter this menu, the sounds which you
have stored or downloaded via MMS, WAP, BT,
Infrared or USB will be displayed in a list.
1. Select
My files
>
Playlists
and press , to enter the
menu.
2. Press L
Options
>
Open folder
to carry out the
following operations to a selected file:
Play with
music player
Play the selected audio file with the
music player.
This option is available for wav
and mp3 files only.
Mark Mark one by one: select the audio
file one by one and then move,
copy, delete or send the files.
Mark all: select all the audio files
and then move, copy, delete or send
the filess.
Manage file Select Move to folder or Copy to folder
to move or copy the selected audio
file to another folder. If Move to folder
is selected, the source audio file will
be deleted once the file has been
moved.
Rename file Modify the name of the selected
audio file.
Delete Remove the selected audio file.
File
properties
Display the detailed information of
the audio file.
Folder
properties
Sort order: Sort the audio files and
folders by increasing or decreasing
alphabetical order.
Sort direction: Sort the audio files
and folders by name or date
Choose view: You can select to view
the audio files in
List view
or
Grid view
.
Philips XNRG_Master_EN.book Page 42 Thursday, November 15, 2007 4:59 PM
43 My Files
Videos
When you enter this menu, the videos which you
have recorded using the phone's camera as well as
videos you have downloaded via MMS, WAP, BT,
or USB will be displayed as a list.
1. Select
My files
>
Videos
and press , to enter the
menu.
2. Press L
Options
>
Open folder
to carry out the
following operations to a selected file:
Options Description
Play with
music
player
Play the selected audio file with the
music player.
This option is available for wav and
mp3 files only.
Mark Mark one by one: select the videos
one by one and then move, copy,
delete or send the files.
Mark all: select all the videos and
then move, copy, delete or send the
videos.
Manage
file
Select Move to folder or Copy to folder
to move or copy the selected video file
to another folder. If Move to folder is
selected, the source video file will be
deleted once the file has been moved.
Rename
file
Modify the name of the selected
video.
Delete Remove the selected video.
File
properties
Display the detailed information of the
video.
Folder
properties
Sort order: Sort the video files and
folders by increasing or decreasing
alphabetical order.
Sort direction: Sort the video files and
folders by name or date
Choose view: You can select to view
the video files in
List view
or
Grid view
.
Philips XNRG_Master_EN.book Page 43 Thursday, November 15, 2007 4:59 PM
My Files 44
Videos are played in the middle of the screen. A
status bar is displayed at the top of the screen. The
keypad operations when playing videos are as
follows:
Games & Java applications
When you enter this menu, the applications which
you have stored or downloaded via MMS, WAP,
BT or USB will be displayed in a list.
Options Description
Play video
Play the selected video.
Send video
Send the selected video file via
bluetooth
or
MMS
.
Mark Mark one by one: select the videos
one by one and then move, copy,
delete or send the files.
Mark all: select all the videos and
then move, copy, delete or send the
videos.
Manage
file
Select Move to folder or Copy to folder
to move or copy the selected video file
to another folder. If Move to folder is
selected, the source video file will be
deleted once the file has been moved.
Rename
file
Modify the name of the selected
video.
Delete Remove the selected video.
File
properties
Display the detailed information of the
video.
Folder
properties
Sort order: Sort the video files and
folders by increasing or decreasing
alphabetical order.
Sort direction: Sort the video files and
folders by name or date
Choose view: You can select to view
the video files in
List view
or
Grid view
.
Key Operation
, Start/pause playback.
<Long press to rewind.
>Long press to fast forward.
RExit/return to an previous menu
level.
)Return to idle screen.
Philips XNRG_Master_EN.book Page 44 Thursday, November 15, 2007 4:59 PM
45 My Files
1. Select
My files
>
Games & Java applications
and
press , to enter the menu.
2. Press L
Options
>
Open folder
to carry out the
following operations to a selected file:
Options Description
Run applet Start the selected game or
application.
Send applet
Send the selected game or
application via
bluetooth
or
MMS
.
Mark Mark one by one: select the videos
one by one and then move, copy,
delete or send the files.
Mark all: select all the videos and
then move, copy, delete or send the
videos.
Manage
file
Select Move to folder or Copy to folder
to move or copy the selected video file
to another folder. If Move to folder is
selected, the source video file will be
deleted once the file has been moved.
Rename
file
Modify the name of the selected
video.
Delete Remove the selected video.
File
properties
Display the detailed information of the
video.
Philips XNRG_Master_EN.book Page 45 Thursday, November 15, 2007 4:59 PM
My Files 46
Folder
properties
Sort order: Sort the video files and
folders by increasing or decreasing
alphabetical order.
Sort direction: Sort the video files and
folders by name or date
Choose view: You can select to view
the video files in
List view
or
Grid view
.
Philips XNRG_Master_EN.book Page 46 Thursday, November 15, 2007 4:59 PM
Tools 47
10. Tools
Alarm
Your mobile phone has a built-in alarm clock. You
can set a maximum of 5 separate alarms.
To set an alarm, follow the steps below:
1.
Select <Add new alarm> and press left softkey
Select.
2.
Select Alarm time, then press
,
and edit the
time.
3.
Select Periodicity, then press
,
and select No
repetition, Every day, Except weekend or User
defined days.
4.
Select the Alarm Sound in the Sounds list.
Repeat above steps to set other alarms.
The alarm clock will ring even if your mobile
phone is switched off and/or the call alert mode is
set to Silent. When the alarm rings, press any key
to stop it.
You can access the alarm options to carry out the
following operations to a selected alarm:
Organizer
This menu allows you to create, store and manage
events in your organizer. displays the calendar.
Press left softkey to access the following options:
Options Description
Activate/
Deactivate
alarm
Set the alarm on or off.
View/Edit
alarm
Modify the alarm.
Delete alarm
Remove the selected alarm.
Delete all
alarms
Remove all alarms on the list.
Options Description
Day View
Events will be displayed in
Day View.
Week View
Events will be displayed in
Week
View.
Philips XNRG_Master_EN.book Page 47 Thursday, November 15, 2007 4:59 PM
48 Tools
If the memory space for events is full, the phone
will prompt you that there is no more space.
When editing date and time, the phone will
display the default or the selected date and time.
You can edit or confirm them directly.
When you change the date and time of your phone,
the next alert will be repeated based on the
modified date and time of the phone.
When you switched off the phone, the organizer alert
will be postponed until the next time you switch on
Create event
Event type: Select Task, Anniversary
or Holiday.
Subject: Enter the subject of the
event.
Description: Enter the detailed
information of the event.
Location: Enter the location where
the event will take place.
Start date: Enter the date when the
event starts.
Start time: Enter the time when the
event starts.
End date: Enter the date when the
event ends.
End time: Enter the time when the
event ends.
Alert: Allows you to select among:
No alert, At start time, 5 min.
before, 15 min before, 1 hour before
or 1 day before.
Repetition: Allows you to select
among: No repetition, Every day,
Every week, Every month or Every
year.
Go to one
day
Select a day in the calendar.
Delete all
events
Delete all events in the calendar.
Delete events
between
Enter the Period beginning and
Period end to delete the events
taking place between these two
periods.
Set alert
sound
Select the event alert sound in the
Sounds list
Philips XNRG_Master_EN.book Page 48 Thursday, November 15, 2007 4:59 PM
Tools 49
the phone. For repeated events, only the latest one
will be alerted.
Calculator
Your mobile phone has a built in calculator. Enter
the numbers with the keypad.
The result of the calculator is indicative. The
calculation accuracy is up to 3 decimal places
maximum. The result is then truncated after the
3rd decimal digit for the next operation
Converter
This application allows you to convert a sum from
one currency into another using the exchange rate of
your choice. Enter a currency and an amount in the
currency fields. Then enter a rate in the Conversion
rate. The sum is calculated automatically.
Flight Mode
This application allows you to activate or deactivate
the flight mode. If it is set to On, the network
functin will be closed and all related network
operations will be prohibited.
Stopwatch
Your phone features a stop watch and the minimum
unit is 0.1 second.
The starting time is 000:00.0, in the format
“mmm:ss.n”, where mmm stands for minutes of the
watch, ss stands for seconds, n stands for 0.x
second. The stopwatch will start the timing when
you press left softkey Start or
,
. You can press left
softkey Stop to stop the timing, Resume to resume
counting or press right softkey Reset to reset the
timing .
Auto Switch On/Off
This menu allows you to set your mobile phone to
switch itself on or off at pre-set times. This lets you
extend your phone’s battery life (e.g. during the
Options Description
+
Addition
-
Subtraction
>
Multiplication
<
Division
,
or left
softkey
L
Equals.
#
Add a decimal point.
Philips XNRG_Master_EN.book Page 49 Thursday, November 15, 2007 4:59 PM
50 Tools
night), not be disturbed at given times and have your
phone switch back on automatically. Press left
softkey Options to access the following options:
Lunar date converter
This menu gives you the correspondence between
Gregorian and Chinese calendars by displaying the
corresponding date in lunar mode from a selected
Gregorian date.
Features requiring date and time information
(e.g. organizer events) depend on Gregorian dates
only.
Press to access the date edition window. Change the
date if needed by pressing the corresponding keys,
then press to convert to lunar mode.
Lunar in idle
This option allows you to display the lunar calendar
on the idle screen. Press left softkey to acess Lunar
in idle option menu. Select On/Off to activate/
deactivate this option.
Horoscope
This menu allows you to display your horoscope for
any given day. To consult your horoscope, you must
enter your birth date. Press left softkey Options and
select Enter day of birth and press left softkey or
,
to display the corresponding sign.
You can also select For other sign or View another day
to consult another horoscope or day.
Chinese Festival Calendar
This menu informs you of the major Chinese
festivals, from a given date. The Chinese festivals
are displayed on a list based on the day from now.
Alternatively, you can press left softkey and enter a
date from which you want to know which Chinese
festivals will occur. In both cases, the six next
festivals will be displayed.
Auto Switch
On/Off
Select among:
On only
,
On and off
,
Disabled
or
Off only
.
Periodically Select the desired frequency Once,
Every day
,
Except weekend
or
User
choice
.
Switch on
time
Enter the time at which you want
your mobile phone to switch itself
on.
Switch off
time
Enter the time at which you want
your mobile phone to switch itself
off.
Philips XNRG_Master_EN.book Page 50 Thursday, November 15, 2007 4:59 PM
51 Contacts
11. Contacts
Contacts are stored in one of the two available
phonebooks: SIM phonebook (located on your SIM
card, by which the number of entries you can store
depends on the card capacity) or the Smart
Phonebook (located on your phone, which allows
you to store up to 500 names). When adding new
contacts, the contacts will only be added to the
phonebook you have selected..
You can store up to 500 name cards, provided
other features in the phone such as Organizer,
Sounds, Pictures, and Videos, etc. did not use up a
large amount of the phone's memory space.
View contacts
The View contacts feature allows you to view or
create contacts in your phonebook. From the
Contacts menu, select View contacts and the list of
contacts is displayed.
View contacts
Select a group and press left softky Options > View
contacts to display the list of contacts.
Contact Options
In the phonebook, you can display the details of a
contact by selecting it and pressing left softkey
Options to carry out the following operations:
Options Description
View View the details of the selected
contact.
Send
message
Send a SMS or MMS to the contact.
Call Call the contact.
Call with Allows you to select IP, Handsfree or
IP with handsfree.
Send
Contact
Send the selected record By MMS or
By bluetooth.
Mark Select Mark one by one or Mark all.
Philips XNRG_Master_EN.book Page 51 Thursday, November 15, 2007 4:59 PM
Contacts 52
Add new groups
You can also create a new SIM/phone contact by
following the steps below:
1.
Select Add contact. Then press left softkey to
enter contact details.
2.
Enter First name, Last name. Then press > and
select the Picture, Sound which are associated
with the new contact. If you want to add the
new contact into group, press > and press left
soft key Add in <Add to group> view and select
the group. Finally, press > and enter the Street
and City. You can press left softkey to Save,
select Preferred edition mode or Text input
language.
View groups
The View groups feature allows you to organize your
contacts so that you can associate images and/or
ringtones with a group of contacts and send
messages to all the members of the group. From the
Contacts menu, select View group and the list of
groups is displayed.
View groups
Select a group and press left softky Options > View
groups to display the members of the group.
Contact
settings
View contact from: SIM memory
merged, or Phone memory.
Sort contact by: Last name
(alphabetical), First name
(alphabetical) or Phone memory.
Save new contact to: ask each time,
SIM memory or Phone memory.
Manage contacts: Copy all to SIM,
Copy all to phone, Delete all from SIM
or Delete all from phone.
Delete Delete the contact.
FDN only Allows you to consult, edit and
modify your a specific names list
called Public names FDN via a PIN2
code.
Philips XNRG_Master_EN.book Page 52 Thursday, November 15, 2007 4:59 PM
53 Contacts
Group Options
Add new groups
Select <Add new group> and press left softkey Select.
Then enter the name of the group. You can press left
softkey to Save, select Preferred edition mode or Text
input language.
Special numbers
This menu allows you to keep a list of useful
numbers such as your own numbers, service
numbers, voicemail and SOS numbers.
Settings
This menu allows you to manage yourt contact
settings. Select Contacts > Settings and press left
softkey to access the following options:
Options Description
View and
edit
members
Display the group members.
Delete Remove the group.
Rename Rename the group.
Create
message
Send a SMS or MMS to members of a
group.
Options Description
Own
number
View, Edit or Delete your own phone
number.
Public
names
(FDN)
Allows you to consult, edit and
modify your a specific names list
called Public names (FDN) via a PIN2
code.
Voice mail
number
Add or dial the number for your
voice mail service provider.
SOS
numbers
Display emergency phone numbers.
View contact
from
Select between: SIM memory
merged, or Phone memory.
Sort contact
by
Select between: Last name
(alphabetical), First name
(alphabetical) or Phone memory.
Save new
contact to
Select between: ask each time, SIM
memory or Phone memory.
Philips XNRG_Master_EN.book Page 53 Thursday, November 15, 2007 4:59 PM
Contacts 54
Manage
contacts
Select between: Copy all to SIM,
Copy all to phone, Delete all from
SIM or Delete all from phone.
FDN only Allows you to consult, edit and
modify your a specific names list
called Public names FDN via a
PIN2 code.
Philips XNRG_Master_EN.book Page 54 Thursday, November 15, 2007 4:59 PM
55 Profiles
12. Profiles
This menu allows you to set the ring tone, alert type,
ring volume, answer mode and backlight, etc when
you receive an incoming call or a new message so
that you can adapt the use of your phone to different
types of call environments.
You can select Deactivate to disable all profile
settings; or select Autonomy, Car, Headset, Outdoor,
Silence or Meeting and press left softkey Options to
access the following options:
Activate Activate the selected profile.
Modify Allows you to set the selected
mode including Ring volume, Call
alert mode (Silent and no vibrate,
Vibration only, Ring only, Vibra then
ring or Vibra and ring), Alert sounds
(On, Off and Beep), Key sound (On,
Off and Beep), Backlight duration
(10 sec, 20 sec, 30 sec and 1 min), ,
Any key answer (On and Off ).
Rename Modify the name of the selected
profile.
Philips XNRG_Master_EN.book Page 55 Thursday, November 15, 2007 4:59 PM
56 Connectivity
13. Connectivity
This menu provides you with more features to set up
a connection with these external devices.
Bluetooth
Your phone supports Bluetooth wireless
technology, allowing connection to a compatible
Bluetooth device. The Bluetooth connection can be
subject to interference from obstructions such as
walls or other electronic devices.
Before you can apply Bluetooth, make sure the
other device supports Bluetooth function by
contacting the device’s manufacturer or its
accompanied documentation.
Establish a Bluetooth connection
To activate, press , to enter the main menu from
idle mode and then select Connectivity > Bluetooth.
On the Bluetooth screen, select Activation > On.
Next, select My devices > <Find device>. When the
list of devices appears, press left softkey to select
the device you wish to establish a connection with.
If you do not intend to use the Bluetooth feature
for some time, you should deactivate it in order to
conserve battery power.
Bluetooth menu
Options Description
Activation Turn Bluetooth feature On or Off.
My devices • Search for the external devices
that you can connect to.
• Select to connect to devices that
you predefined.
Visible Choose to show or hide the device
by select toggle On or Off.
Phone
name
Edit the name of the device.
Philips XNRG_Master_EN.book Page 56 Thursday, November 15, 2007 4:59 PM
Connectivity 57
Network
This menu allows you to select the service network
You can select a network other than your home
network only if it has a valid roaming agreement
with your home network. If you change the
network, some problems may arise during the
operation of your phone.
Configure browser
This menu allows you to configure the
Browser
settings
and select the
WAP profiles
in
Browser connection
profiles
for web browsing. Your phone may have
been pre-configured with the settings of a specific
network operator. If you are a subscriber of the
network operator, you may start using your WAP
browser immediately. Otherwise, you need to re-
configure the settings.
Philips is not liable to give prior notification nor
shall it bear any consequences for failures arising
from changes in configuration made by you or by
the network operator, or changes in WAP address
or contents made by the internet content provider.
Please check with your network operator and your
internet content provider for the most updated
information.
Registration
Mode
Automatic: your phone will
automatically select and register
to an available network.
Manual: provides you with a list of
available network in the area.
Select the network you wish to
register with and press left softkey
to confirm.
You are recommended to select
Automatic.
Preferred
Network list
Select a preferred network to be
used currently.
Philips XNRG_Master_EN.book Page 57 Thursday, November 15, 2007 4:59 PM
58 Connectivity
The following options are available for
Browser
settings
:
Configure JAVA
Your mobile phone features a Java run-time
environment, which allows you to run Java
applications, such as games downloaded on the
network.
View Java list
Select Connectivity > Configure JAVA to view the Java
list and press left softkey to access the following
options:
Create a new Java application
Select Connectivity > Configure JAVA > <New profile...>
to configure a new Java.
The first time you launch Java, a message appears to
alert you that the installation and configuration of
Java will take several moments. This is a one-time
occurrence. Once Java has been installed, you may
then proceed to set the following Profile name,
Network connection profile (select and configure
whether GSM or GPRS will be used when lauching
a connection), User proxy (Yes or No), Proxy address,
Display
settings
Title display: Allows you to choose
Show title or hide title.
Vertical scrolling: Allows you to
choose By line or By page.
Info on exit: Allows you to choose
No info, Volume only, Duration only or
Duration and volume.
Security
Settings
Cookies: Allows you to choose
Allow cookies or No cookies.
Clear cookies: Select to clear
cookies.
Show certificates: Display the list of
installed certificates.
Clear Cache
Allows you to delete all Cache
contents.
Options Description
Activate Launch the selected Java
application.
View View the detailed information of the
selected Java application.
Rename Modify the name of the selected
Java application.
Delete Remove the selected Java
application.
Philips XNRG_Master_EN.book Page 58 Thursday, November 15, 2007 4:59 PM
Connectivity 59
Proxy port, Proxy login, Proxy password, DNS mode
(Automatic or Manual), DNS address and DNS port.
USB function
(need further information of how to operate)
Philips XNRG_Master_EN.book Page 59 Thursday, November 15, 2007 4:59 PM
60 Calls
14. Calls
Most options described in this chapter are operator
and/or subscription dependent and require either a
PIN2 code or a phone code. For more information
on PIN codes, see “Security settings” on page 53.
Calls list
This menu provides you with a list of calls you have
missed, answered and made. The calls include All
calls, Dialled call, Missed calls, Received call and
Rejected calls, which are displayed in chronological
order with the most recent call at the top of the list.
Select a call from one of the lists, then press left
softkey Options to access the following:
GPRS counters
Tabulates the amount of data sent and received via
GPRS. You can also reset the counter. The unit of
measurement is Byte.
GSM counters
Displays the number of calls that have been made
and received.
Call settings
This menu allows you to configure the call settings:
Options Description
Call Call the selected number.
Call with Allows you to select IP, Handsfree or
IP with handsfree.
Create
message
Send a message to the selected
number. You can send by SMS or
MMS.
Add to
contacts
Add the number if the number is not
in the Contacts list.
Ban caller To add the phone number into the
blacklist, see “Security settings” on
page 53.
Delete
record
Delete the selected number from the
list.
Delete all Delete all number from the list.
Options Description
Philips XNRG_Master_EN.book Page 60 Thursday, November 15, 2007 4:59 PM
Calls 61
Any key
answer
Turn Any key answer On or Off. When
this function is on, you can answer
incoming calls by pressing any key,
except ), right softkey, and +/- side
keys.
My identity
(network
dependent)
Select to Show or Hide your identity
to your corresponent. The Status will
inform you on which option is
activated.
Auto redial You can set auto redial option On or
Off. When set to On and the party
you wish to call is not connected,
you will be asked to redial or not.
Call waiting Call waiting GSM: Applies to All,
Voice, Fax, and Data calls. When this
option is active, you hear a beep if
someone tries to call you while
already on a call.
Call waiting if GPRS: Allows you to
Activate or Deactivate the call waiting
for voice incoming calls while a
GPRS connection is ongoing..
Call divert Voice: Set or cancel the following
call divert options to mailbox,
number or contact : Unconditional, All
conditional, If no reply, If unreachable
or If busy.
•When Unconditional is on, you will
not receive any calls until you
deactivate it.
•When is All conditional is on, you
can choose when you want to
divert incoming calls
• When If no reply is on, incoming
calls will be diverted if the user
does not answer.
• When If unreachable is on,
incoming calls will be diverted to
the pre-set number when the user
is not connected to the network.
• When If busy is on, calls will be
diverted if the user is already
online or if the call is rejected.
• You can also check the Status of
your call diverts
Philips XNRG_Master_EN.book Page 61 Thursday, November 15, 2007 4:59 PM
62 Calls
IP prefix
This menu allows you to store the IP service number
so that you need not enter the number before you
make an IP call.
The IP service number has to be supported by your
network operator before you can make an IP call.
When you change a new SIM card, the IP service
number you have stored with be cleared.
The phone does not validate the IP service number
you have entered. Therefore, please ensure that
the number is correct.
Call barring The types of calls you can bar are as
follows:
• Outgoing calls: All outgoing calls,
international calls or international
except home
• Incoming calls: All incoming calls or
when roaming.
In both cases, you can cancel the call
barring to Outgoing and Incoming
calls. You can also check the Status
of your call barring or Set password
to prevent the reception or making
of different types of calls.
This operation only supports GSM
calls.
Philips XNRG_Master_EN.book Page 62 Thursday, November 15, 2007 4:59 PM
Settings 63
15. Settings
You can configure your phone to best suit your
usage preference. You can configure the following
settings: General, Display, Sounds and Connectivity.
Press , to enter the main menu from idle mode mode
and select Settings. Press < or > to select a settings
menu. Press + or -. Enter the menu options.
General
Phone settings
Time & date Set local time & date:
• Set the time in the format
HH:MM and set the date format.
•Time zone: use the navigation
key to change the time zone.
• Daylight saving: Set the daylight
saving On (in summer time) or
Off (in winter time). If the
daylight saving is On and you set
the time to 12:00, it will
automatically switch to 11:00
when turning the option to Off.
•Display time: Select On or Off.
When you select On, the time
information will be displayed in
idle screen.
•Time format: Set the time format
as 24 hours or 12 hours.
•Date format: Set the date format
as DD/MM/YYYY, MM/DD/YYYY,
or YYYY/MM/DD.
Philips XNRG_Master_EN.book Page 63 Thursday, November 15, 2007 4:59 PM
64 Settings
International clock:
•Display in idle: The time will be
displayed on screen in idle mode.
•Set foreign zone: Set the time of a
selected foreign city.
• Daylight saving: Set the daylight
saving On (in summer time) or
Off (in winter time). If the
daylight saving is On and you set
the time to 12:00, it will
automatically switch to 11:00
when turning the option to Off.
•Switch clock: Switch the time of the
local zone to foreign zone.
Lunar date in idle:
•Display in idle: Allows you to
display the lunar calendar on the
idle screen. Press left softkey to
acess Lunar in idle option menu.
Select On/Off to activate/
deactivate this option.
Languages Set the display language of the
phone.
Energy
reserve
transfer
mode
Automatic: Switch to dry battery/
main battery automatically
Upon user confirmation: Switch to
dry/main battery only when
confirmed by the user.
Transfer
energy now!
Transfer energy from the dry
battery to the main battery.
Philips XNRG_Master_EN.book Page 64 Thursday, November 15, 2007 4:59 PM
Settings 65
Security settings
Options Description
Pin code
settings
PIN activation: Select On or Off.
When you select On, you need to
enter the PIN code when you
switch on the phone.
The default PIN code is network
dependent on your service
provider. Please contact your
service operator for the PIN
information.
Change PIN: Modify the PIN code.
Change PIN2: Modify the PIN2
code.
Auto key lock Allows you to lock your keypad
automatically. THe default setting
is Deactivated. Select the time
interval after which the keypad will
be locked.
Safeguard You can safeguard important
information such as messages,
contacts on your phone by
activating safeguard. You can also
change the safeguard password.
The default safeguard password is
0000.
Philips XNRG_Master_EN.book Page 65 Thursday, November 15, 2007 4:59 PM
66 Settings
Shortcuts
Displays a list of shortcut features. You can set a
new shortcut key by establishing a link between a
certain feature and a numeric or navigation key.
You can also change or delete an existing shortcut
key.
Firewall Firewall activation: Allows you to set
the firewall option On or Off. When
On, you mobile phone will reject
all calls and messages received
from people listed in the blacklist.
Rejected calls appear in the Calls list
and rejected messages in the Spam
messages box.
Reject calls alert: Select No alert if
you do not want to receive alert for
rejected calls or Text alert if you
want to receive alert of the rejected
calls.
Spam messages alert: Select No
alert if you do not want to receive
alert for rejected messages or Text
alert if you want to receive alert of
the rejected messages.
Blacklist: Displays the list of
contacts whose calls and messages
will be rejected. Select to add a
Name, Blacklisted number and
whether to reject the Calls,
Messages or Messages and calls sent
by the blacklisted contact.
Shortcuts Displays a list of shortcut features.
You can set a new shortcut key by
establishing a link between a
certain feature and a numeric or
navigation key. You can also
change or delete an existing
shortcut key.
Default
storage
Set the default storage location:
Phone memory or Memory card.
Memory
status
You can check the memory status
of Contacts, Messaging and My files.
You can also check the memory
status of memory card if it is
inserted.
Default
settings
Restore your phone settings to the
default values.
Philips XNRG_Master_EN.book Page 66 Thursday, November 15, 2007 4:59 PM
67 Settings
Memory Management
Restore factory settings
This menu allows you to reset some settings in your
phone to its factory settings.
Enter the phone lock password and press left
softkey/, and press left softkey Yes to confirm.
Sounds
You can set your phone to operate with different
sound profiles. For details, see “Profiles” on
page 66.
Options Description
Storage
settings
Default storage location: Select the
preferred storage location: Phone
memory or Memory card.
Picture prefix name: assign a prefix
name on your picture files.
Video prefix name: assign a prefix name
on your video files.
Memory
status
Displays the percentage of memory
that has been utilized in Contacts,
Messages, JAVA, Phone memory and
Memory card (if available).
Format
phone
memory
If selected, all folders and files you
created will be removed.
Erase
personal
data
If selected, all personal files
(messages, pictures, videos, etc) will
be removed.
Options Description
Call Alert
Mode
Select from Silent, Vibrate only, Ring
only, Vibrate then ring or Vibrate and
ring.
Ring
volume
Select from 6 volume levels.
Default call
ringer
Select from Use theme, Use sound or
Use beep.
Contacts
call ringer
Select from Same as default ringer,
Use sound or Use beep.
Alert
sounds
New message tone: Select from Use
theme, Use sound, beep or None.
Other alert: Select from On, Off or
Beep.
Keytones Turn key sound On or Off.
Philips XNRG_Master_EN.book Page 67 Thursday, November 15, 2007 4:59 PM
Settings 68
If you have downloaded your own ring tones and
have selected such a ring tone to be the alarm
alert, then after you set the alarm and switched off
the phone, the alert tone will be changed back to
the original factory settings. This does not apply if
the ring tone you have chosen is one that comes as
default with your phone.
Display
You may configure your phone with different
display settings:
Options Description
Wallpaper Select from Use theme, Use picture
or None.
Backlight
duration
Select backlight duration from 60
sec., 30 sec., 20 sec. and 10 sec.
Backlight
brightness
Select from 5 backlight levels. You
can select the backlight level by
pressing + or - keys. Press , or left
softkey to confirm.
Greeting Turn greetings On or Off. When you
select On, you can edit the greetings
message.
The maximum length of greetings is
20 Chinese words or 50 English
characters.
Philips XNRG_Master_EN.book Page 68 Thursday, November 15, 2007 4:59 PM
Icons & Symbols 69
Icons & Symbols
In idle mode, several icons and symbols can be
displayed on the sub-display and main screen. The
status, network and battery icons are displayed all
the time. The rest of the icons are displayed if the
feature is available, and not displayed if the feature
is unavailable.
If the network symbol is not displayed, it implies
that the network is currently unavailable. You may
be in a bad reception area; moving to a different
location may help.
GSM Network - your phone is connected
to the GSM network.
Reception quality - the more bars are
shown the better the reception is..
Battery - Indicates battery level with 5
battery level indicator bars. When
charging, a scrolling icon will be
displayed.
Roaming - Displayed when your phone is
registered to a network other than your
own (especially when you’re abroad).
GPRS attach - Your phone is connected
to the GPRS network.
SMS/MMS message - You have received
a new SMS/MMS message.
SMS full - Memory for messages is full.
Delete old messages to receive new
ones.
Voicemail- You have received a new
voice message.
Home zone - A zone designated by your
network operator. Subscription
dependent, contact your service
provider for details.
Bluetooth - Feature is activated.
Silent - Your phone will not ring when
receiving a call.
Keypad lock - The keypad has been
locked.
Headset - The headset is plugged into the
phone.
WAP notification.
Philips XNRG_Master_EN.book Page 69 Thursday, November 15, 2007 4:59 PM
70 Precautions
Precautions
Radio Waves
Your cellular mobile phone is a low power
radio transmitter and receiver. When it
is operating, it sends and receives radio
waves. The radio waves carry your voice
or data signal to a base station that is connected to
the telephone network. The network controls the
power at which the phone transmits.
• Your phone transmits/receives radio waves in the
GSM frequency (900 / 1800 / 1900 MHz).
• The GSM network controls transmission power
(0.01 to 2 watts).
• Your phone complies with all relevant safety
standards.
• The CE mark on your phone shows compliancy
with European electromagnetic compatibility
(Ref. 89/336/EEC) and low voltage directives
(Ref. 73/23/EEC).
Your cellular mobile phone is your responsibility.
To avoid damage to yourself, to others or to the
phone itself, read and follow all the safety
instructions and make them known to anyone
borrowing your phone.Furthermore to prevent
unauthorized use of your phone:
Keep your phone in a safe place and keep
it out of small children's reach.
Avoid writing down your PIN code. Try to
remember it instead.
Switch off the phone and remove the battery if you
are going to leave it unused for a long time.
Change your PIN code after purchasing the phone
and to activate call restriction options.
The design of your phone complies with
all applicable laws and regulations.
However your phone may cause
interference with other electronic devices.
Consequently you should follow all local
recommendations and regulations when using
your cellular phone both at home and when away.
Regulations on the use of cellular phones in
vehicles and aircraft are particularly stringent.
Public concern has been focused for some time on the
possible health risks for users of cellular phones. The
current research on radio wave technology, including
the GSM technology, has been reviewed and safety
standards have been drawn up to ensure protection
from exposure to radio wave energy. Your cellular
telephone complies with all applicable safety
standards and the Radio Equipment and
Philips XNRG_Master_EN.book Page 70 Thursday, November 15, 2007 4:59 PM
Precautions 71
Telecommunications Terminal Equipment Directive
1999/5/EC.
Always switch off your phone
Inadequately protected or sensitive electronic
equipment may be affected by radio energy. This
interference can lead to accidents.
Before boarding an aircraft and/or when
packing the phone in your luggage: the use
of mobile phones in an aircraft may be
dangerous for the operation of the aircraft, disrupt
the mobile phones network and may be illegal.
In hospitals, clinics, other health care
centres and anywhere else where you may
be in the close vicinity of medical
equipment.
In areas with a potentially explosive
atmosphere (e.g. petrol stations and also
areas where the air contains dust particles,
such as metal powders).
In a vehicle transporting flammable products (even
if the vehicle is parked) or a vehicle powered by
liquefied petroleum gas (LPG), check first that the
vehicle complies with the applicable safety rules.
In areas where you are requested to turn off radio
transmitting devices, such as quarries or other areas
where blasting operations are in progress.
Check with the vehicle manufacturer that
electronic equipment used in your
vehicle will not be affected by radio
energy.
Pacemakers
If you have a pacemaker:
• Always keep the phone more than 15 cm from
your pacemaker when the phone is switched on,
in order to avoid potential interference.
• Do not carry the phone in a breast pocket.
• Use the ear opposite to the pacemaker to
minimize the potential interference.
• Switch off your phone if you suspect that
interference is taking place.
Users of hearing aids
If you are a user of a hearing aid, consult your
physician and hearing aid manufacturer to learn
whether your particular device is susceptible to
cellular phone interference.
Philips XNRG_Master_EN.book Page 71 Thursday, November 15, 2007 4:59 PM
72 Precautions
Improved performance
In order to improve the performance of your
phone, reduce radio energy emission, reduce
battery consumption and ensure safe operation
adhere to the following guidelines:
For the optimal and satisfactory operation
of the phone, you are recommended to use
the phone in the normal operating position
(when not using in hands-free mode or
with a hands-free accessory).
• Do not expose your phone to extreme
temperatures.
• Treat the phone with care. Any misuse will void
the International Guarantee.
• Do not immerse the phone in any liquid; if your
phone is damp, switch it off, remove the battery.
and let them dry for 24hrs before using them
again.
• To clean the phone, wipe it with a soft cloth.
• Placing and receiving calls consumes the same
amount of battery energy. However, the mobile
consumes less energy in idle screen when kept in
the same place. When in idle screen and while
you are moving, your phone consumes energy to
transmit updated location information to the
network. Setting the backlight for a shorter period
of time as well as avoiding unnecessary
navigating in the menus will also help to save the
battery's energy for longer phoning and stand-by
performances.
Battery information
• Your phone is powered by a rechargeable battery.
• Use specified charger only.
• Do not incinerate.
• Do not deform or open the battery.
• Do not allow metal objects (such as keys in your
pocket) to short circuit the battery contacts.
• Avoid exposure to excessive heat (>60°C or
140°F), moisture or caustic environments.
You should only use Philips authentic
battery and accessories, as the use of any
other accessories may damage your phone
and may be dangerous, and will make all
guarantees for your Philips phone null and
void. The use of an incorrect type of battery may
also cause an explosion.
Make sure damaged parts are replaced immediately
by a qualified technician and that they are replaced
with genuine Philips replacement parts.
Philips XNRG_Master_EN.book Page 72 Thursday, November 15, 2007 4:59 PM
Precautions 73
Your mobile phone and your car
Studies have shown that speaking on the
telephone while driving lowers your
concentration, which can be dangerous.
Adhere to the following guidelines:
• Give your full attention to driving. Pull off the
road and park before using the phone.
• Respect the local regulations in countries where
you drive and use your GSM phone.
• If you want to use your phone in a vehicle, install
the hands-free car kit which is designed for that
purpose.
• Ensure that your phone and car kit do not block
any air bags or other security devices fitted in your
car.
The use of an alarm system to operate a vehicle's
light or horn to indicate incoming phone calls is
prohibited on public roads in some countries. Check
local regulations.
EN 60950 Norm
In hot weather or after prolonged exposure to the
sun (e.g., behind a window or a windscreen), the
temperature of your phone's casing might increase,
especially when featuring a metallic finish. Be very
careful in this case when picking up your phone and
also avoid using it with an ambient temperature over
40° C or below 5° C.
For your phone, the socket-outlet shall be installed
near the phone and shall be accessible.
FCC Compliance Statement
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference in a residential
installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may
cause harmful interference to radio
communications. However, there is no guarantee
that interference will not occur in a particular
installation.
If this equipment does cause harmful interference to
radio or television reception, which can be
determined by turning the equipment off and on, the
user is encouraged to try to correct the interference
by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
Philips XNRG_Master_EN.book Page 73 Thursday, November 15, 2007 4:59 PM
74 Precautions
-- Increase the separation between the equipment
and receiver.
-- Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
Any changes or modifications not expressly
approved by the party responsible for compliance
could void the user’s authority to operate the
equipment.
Environmental care
Remember to observe the local regulations
regarding the disposal of the packaging
materials, exhausted batteries and old
phone and please promote their recycling.
Philips has marked the battery and packaging with
standard symbols designed to promote the recycling
and appropriate disposal of your eventual waste.
WEEE Marking in the DFU: “Information
to the Consumer”
Disposal of your old product
Your product is designed and manufactured with
high quality materials and components, which can
be recycled and reused.
When this crossed-out wheeled bin
symbol is attached to a product it means
the product is covered by the European
Directive 2002/96/EC
Please inform yourself about the local
separate collection system for electrical
and electronic products.
Please act according to your local rules and do not
dispose of your old products with your normal
household waste. The correct disposal of your old
product will help prevent potential negative
consequences for the environment and human
health.
The labelled packaging material is
recyclable.
A financial contribution has been made
to the associated national packaging
recovery and recycling system.
The plastic material is recyclable (also
identifies the type of plastic).
Philips XNRG_Master_EN.book Page 74 Thursday, November 15, 2007 4:59 PM
75
Troubleshooting
The phone does not switch on
Remove/reinstall the battery. Then charge the
phone until the battery icon stops scrolling. Unplug
from charger and try to switch on the phone.
Your phone doesn’t return to the idle screen
Long press the hangup key or switch off the phone,
check that the SIM card and the battery have been
installed correctly and switch it on again.
The network symbol is not displayed
The network connection is lost. Either you are in a
radio shadow (in a tunnel or between tall buildings)
or you are outside the network coverage area. Try
from another place, try to reconnect to the network
(especially when abroad), check that the antenna is in
place if your mobile has an external antenna, or
contact your network operator for assistance/
information.
The display doesn’t respond (or the display
responds slowly) to key presses
The display responds more slowly at very low
temperatures. This is normal and does not affect the
operation of the phone. Take the phone to a warmer
place and try again. In other cases, please contact
your phone supplier.
Your battery seems to over heat
You might be using a charger that was not intended
for use with your phone. Make sure you always use
the Philips authentic accessory shipped with your
phone.
Your phone doesn’t display the phone numbers
of incoming calls
This feature is network and subscription dependent.
If the network does not send the caller’s number, the
phone will display Call 1 or Withheld instead.
Contact your operator for detailed information on
this subject.
You can’t send text messages
Some networks don’t allow message exchanges
with other networks. First check that you entered
the number of your SMS centre, or contact your
operator for detailed information on this subject.
You have the feeling that you miss some calls
Check your call divert options.
The display shows INSERT SIM
Check that the SIM card has been inserted correctly.
If the problem remains, your SIM card may be
damaged. Contact your operator.
Philips XNRG_Master_EN.book Page 75 Thursday, November 15, 2007 4:59 PM
76
When attempting to use a feature in the menu,
the mobile displays NOT ALLOWED
Some features are network dependent. Therefore,
they are only available if the network or your
subscription supports them. Contact your operator
for detailed information on this subject.
Your phone is not charging
If your battery is completely flat, it might take
several minutes of pre-charge (up to 10 minutes in
some cases) before the charging icon is displayed on
the screen.
Philips XNRG_Master_EN.book Page 76 Thursday, November 15, 2007 4:59 PM
77
Philips Authentic
Accessories
Some accessories, such as a standard battery and a
charger, are included as standard accessories in your
mobile phone package. Additional accessories may
also be provided or sold separately. Package
contents may therefore vary.
To maximize the performance of your Philips
phone and not to void the warranty, always
purchase Philips Authentic Accessories that are
specially designed for use with your phone. Philips
Consumer Electronics cannot be held liable for
any damages due to use with non authorized
accessories.
Charger
Charges your battery in any AC outlet. Small
enough to carry in a briefcase/handbag.
Data connect kit
Provides easy data connection to your Philips
mobile phone. The USB cable enables high-speed
communication between your phone and your
computer. The provided software allows you to
download pictures and melodies and to synchronize
your contacts and appointments.
Deluxe Headset
The integrated answer button offers you a simple
way to answer your calls. Simply answer an
incoming call by pressing the button or long press to
reject the incoming call.
Philips XNRG_Master_EN.book Page 77 Thursday, November 15, 2007 4:59 PM
78
Trademark Declaration
JAVA is a trademark of Sun
Microsystems, Inc.
T9® is a trademark of Tegic
Communications Inc.
Bluetooth™ is a trade-mark
owned by
telefonaktiebolaget L M
Ericsson, Sweden and
licensed to Philips.
Tegic Euro. Pat.
App. 0842463
Philips XNRG_Master_EN.book Page 78 Thursday, November 15, 2007 4:59 PM
79
Limited warranty
1. What Does This Limited Warranty Cover?
Philips warrants to the original retail purchaser
(“Consumer” or “You”) that this Philips
cellular product and all accessories originally
provided by Philips in the sales package
(“Product”) are free from defects in materials,
design and workmanship under normal use in
accordance with the operating instructions and
pursuant to the following terms and conditions.
This limited warranty extends only to the
Consumer for Products purchased and used in
the original country of purchase. The limited
warranty is valid only in Philips’ intended
country of sales of the product.
2. How Long is The Limited Warranty Period?
The limited warranty period for the Product
extends for ONE (1) YEAR from the date of
purchase of the Product, documented by valid
proof of purchase. The limited warranty for
original Philips rechargeable battery extends
for six (6) months from the date of purchase.
3. What Will Philips Do if The Product is Not
Free From Material Defects in Materials and
Workmanship During The Limited Warranty
Period?
During the limited warranty period, Philips or
its authorized service representative will, at its
option either repair or replace, without charge
for parts or labour, a materially defective
Product with new or refurbished parts or
Product and return such repaired or replaced
Product to the Consumer in working condition.
Philips will retain defective parts, modules or
equipment.
Repaired or replaced Product will be covered
by this limited warranty for the balance of the
original limited warranty period or ninety (90)
days from the date of repair or replacement
whichever is longer. Repair or replacement of
Product, at Philips’ option is your exclusive
remedy.
4. What is Not Covered By This Limited
Warranty?
This limited warranty does not cover:
a) Product that has been subjected to misuse,
accident, shipping or other physical
damage, improper installation, abnormal
Philips XNRG_Master_EN.book Page 79 Thursday, November 15, 2007 4:59 PM
80
operation handling, neglect, inundation,
fire, water or other liquid intrusion; or
b) Product that has been damaged due to
repair, alteration, or modification by
anyone not authorized by Philips; or
c) Product that has reception or operation
problems caused by signal conditions,
network reliability or cable or antenna
systems; or
d) Product defects or problems caused by
uses with non-Philips products or
accessories; or
e) Product which warranty/quality stickers,
product serial number or electronic serial
number has been removed, altered or
rendered illegible; or
f) Product purchased, used, serviced, or
shipped for repair from outside the original
country of purchase, or used for
commercial or institutional purposes
(including but not limited to Products used
for rental purposes); or
g) Product returned without valid proof of
purchase or which proof of purchase has
been altered or is illegible.
h) Normal wear and tear or Force Majeure.
5. How Do You Get Warranty Service?
a) Return the Product to an authorized service
center of Philips. You may contact the
local Philips office for the location of the
nearest authorized service center.
b) The SIM card must be removed from the
Product before it is given to Philips. Philips
assumes no liability for damaged or loss of
the SIM card or the data contained therein.
c) If the Product failure is not covered by this
limited warranty, or this limited warranty
is inapplicable, void or invalid due to any
terms and conditions stated herein, the
Consumer will be charged for the cost of
repair or replacement of the Product and all
other related cost incurred in repairing or
replacing the Product.
d) IMPORTANT - you are required to return
the Product together with a valid proof of
purchase which must identify the point of
purchase, date of purchase, Product model
and Product serial number clearly.
6. Other Limitation: This Warranty is The Entire
Agreement.
EXCEPT FOR THE EXPRESS
WARRANTIES SET FORTH ABOVE AND
THOSE IMPLIED BY LAW AND WHICH
CANNOT BE EXCLUDED OR MODIFIED
BY AGREEMENT, PHILIPS PROVIDES NO
Philips XNRG_Master_EN.book Page 80 Thursday, November 15, 2007 4:59 PM
81
OTHER WARRANTY WHETHER
EXPRESS OR IMPLIED (WHETHER BY
STATUTE, UNDER THE OPERATION OF
LAW OR OTHERWISE) AND SPECIALLY
DISCLAIMS ANY WARRANTY OF
SATISFACTORY QUALITY
MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE.
PHILIPS’ TOTAL LIABILITY FOR
DAMAGES RELATING TO OR ARISING
OUT OF THE PURCHASE OR USE OF THE
PRODUCT, REGARDLESS OF THE TYPE
OR CAUSE OF SUCH DAMAGE OR THE
FORM OR CHARACTERISATION OF THE
CLAIM ASSERTED (E.G. CONTRACT OR
TOPIT), SHALL NOT EXCEED THE
ORIGINAL PURCHASE PRICE PAID FOR
THE PRODUCT.
HOWEVER IN NO EVENT SHALL PHILIPS
BE LIABLE FOR ANY PUNITIVE,
SPECIAL, INCIDENTAL, INDIRECT OR
CONSEQUENTIAL DAMAGES (INCLUDING
BUT NOT LIMITED TO THE LOSS OF USE,
LOSS OF TIME, INCONVENIENCE,
COMMERIAL LOSS, LOST PROFITS,
LOST BUSINESS OPPORTUNITIES, COST
OF SUBSTITUTION OF GOODS OR
SERVICES, INVESTMENTS, DAMAGE TO
GOODWILL OR REPUTATION, OR LOSS
OF DATA AND CLAIMS BY THIRD
PARTIES) RESULTING FROM PURCHASE
OR USE OF THE PRODUCT, TO THE
FULLEST EXTENT ALLOWED BY LAW,
WHETHER OR NOT PHILIPS HAS BEEN
ADVISED OF THE POSSIBILTY OF SUCH
DAMAGES. THESE LIMITATIONS SHALL
APPLY NOTWITHSTANDING THE
FAILURE OF THE ESSENTIAL PURPOSE
OF ANY LIMITED REMEDY.
This limited warranty represents the complete
and exclusive agreement between the
Consumer and Philips with respect to this
cellular Product and it supercedes all prior
agreements between the parties, oral or written,
and all other communications between the
parties relating to the subject matter of this
limited warranty. No carrier, retailer, agent,
dealer, employee, thereof, or employee of
Philips is authorized to make modifications to
this limited warranty and you should not rely on
any such representation.
This limited warranty does not affect the
Consumer’s statutory rights under applicable
national laws in force.
Philips XNRG_Master_EN.book Page 81 Thursday, November 15, 2007 4:59 PM
