Avantronics Limited Bluetooth Headset AS6 Manual
User Manual
1. Product Description
Avantalk Jogger (AS6) is a lightweight sport headphone with in-ear drivers, it features with fashionable sport design, water resistant and
decent stereo sound.
Jogger is the ideal choice for active pursuits such as jogging and exercising.
2. Product Overview
(1). Speaker
(2). Next
(3). Led Indicator
(4). Previous
(5). Headband
(6). Charging Socket
(7). Multi-Function Button(MFB)
(8). Microphone
(9). Volume Down
(10). Volume Up
What’s in the box:
Avantalk Jogger
USB charging cable
Manual
Warranty card
Carry pouch
Optional:
Travel /car charger/Armband
3. Charging
Avantalk AS6 uses a popular USB charging socket.
1) First time, please charge the device for no less than 2 hours to make sure the headset is fully charged and the battery reach its full
capacity.
2) Afterwards, each charge cycle may take 2 hours around.
3) LED will indicate red in charging and off when charging is complete.
4) If you have not use the item for a few months, LED might not turn red when first charging. It might take 15-35 minutes before the
LED turn red.
Notice:
When battery power is low, the red indicator light will flash red every 15 seconds.
3
4. Turn On / Off
Turn On: From OFF, press and hold the “MFB” around 4 seconds until the indicator LED show Blue.
Turn Off: From On, press and hold the “MFB” around 4 seconds until the indicator LED show red.
5. Working with mobile phone (Tutorial online)
It is important to pair the headset with your Bluetooth Mobile phone for the first time use.
5.1 Pairing procedure :
A. Ensure the headset is off
B. Press and hold the MFB button for 7 seconds until LED blink blue and red alternatively.
C. Search the device from your phone ;
D. Once found “Avantalk Jogger’’, follow the steps and enter pin code 0000 to pair (some device does not request the pin code);
E. Connect the headset to the device.
F. Headset is ready for use now.
Once paired and connected, the headset will be automatically connected to the device whenever you turn the headset on again, provided
the device is in the range.
We found most of the online technical support questions are caused by improper pairing between the headset and the Bluetooth device.
Please follow the instruction step-by-step.
5.2 Basic Operations:
● Answering a call: press the “MFB” button once to answer the call.
● Ending a call: press the “MFB” button to end a call.
● Reject a call: press and hold the “MFB” button for 3 second to reject the call.
● Voice Dial: If your mobile phone has voice dialing enabled, when in standby mode short press both ”V+” and “V-” then say the voice
tag you wish to call
● Last number redialing: In standby mode, double click the “MFB” button
● Switching a call between headset and mobile phone:
● Headset to Mobile Phone: During a call, press and hold “MFB” for 2 seconds to transfer the call to your mobile phone.
● Mobile Phone to Headset: During a call, press and hold “MFB” for 2 seconds to transfer the call to your headset.
● Mute&Unmute: During a conversation, Short press ”V+” and ”V-“at the same time to mute the microphone, Short press the two button
again to unmute the microphone
● Restore the Default Setting: Under standby mode, press and hold ”Next” button for 8 seconds until the indicator flash blue and red,
then press and hold “MFB” button for 4 seconds, then you will hear a beep, the headphone is now back to original setting, and after
power on again, it will enter pairing mode automatically.
5.3 Music Streaming
Volume Up: Press and hold” Volume +” or short press “Volume+” to get volume increased
Volume Down: Press and hold “Volume –“ or short press “Volume-“to get volume decreased
Play Music : Press “ MFB” Button
Pause : Press “ MFB” Button
Previous Track: Press “ Previous” Button
Next Track: Press “Next” Button
Note: Some functions are dependent on the mobile phone being used with the headset and may not work with some phones where those
features are not supported.
6. Working with PC/ Laptop (Tutorial online)
With PC running Microsoft Vista with Built-in Bluetooth
5.1 Pairing procedure :
A. Ensure your PC with built-in Bluetooth. Turn On the Bluetooth of PC
B. Double click Bluetooth icon, click “ Add a new device”
C. Once found “Avantalk Jogger’’, follow the steps and enter pin code 0000 to pair (some does not need this);
D. Connect the headset to the device.
E. Headset is ready for use now.
6.2 Streaming the Music
Before streaming the music, you need to change the sound setting first. Go to “ Control Panel” – “Sound” – Playback, change the audio
setting to “Bluetooth Stereo Audio”.
Play music from your player
● Pause: During music streaming, press “MFB” Button, press “MFB” Button to resume it.
● Volume Up: Press and hold ”Volume +” or short press “ Volume+” to get volume increased
● Volume Down: Press and hold “Volume –“ or short press” Volume-“ to get volume decreased
● Previous / Back track: These two functions dependent on your PC system, some system, you can control it on Headset Previous /
Back buttons, some system does support.
6.3 For Skype Call
Some PC system can change the sound setting automatically, then you can make Skype call right now.
Some PC system needs change the sound setting first, go to Skype Tools – Options- Sound Devices, select “Audio in” / “ Audio
Out”/Ringing all three modes to “Bluetooth AV Audio”, save it. Then you can make Skype call
7. Product Specification
Bluetooth V2.1+EDR
Chipset: CSR BC05-Multimedia Single Chip
Support profiles: Headset, Handsfree, A2DP,AVRCP
Operation Range: Class 2, 10 meters
Battery: 170mA rechargeable lithium battery
Talk time: up to 9 hrs
Music time: up to 8 hrs
Standby time: up to 16 days
Weight: 23g(light)
Headset size: 85mm(L)x72mm(W)X25.5mm(H)
The talk and standby times may vary when used with different mobile phones or other compatible Bluetooth devices, usage settings,
usage styles and environments.
8. Safety Information
To avoid any damage or malfunction of the device do not drop device from high places.
Keep device away form humidity, water and any other liquid. If the device is exposed to water, moisture and other liquid, do not
operate it to avoid any electrical shock, explosion and damage to the device or yourself.
Do not place or keep this device near any heat source, such as, direct sun light, radiators, stoves or other apparatus which produces
heat. It may cause explosion, degrade the performance and/or reduce battery life.
Do not modify, repair or disassemble device at discretion (Especially battery: It may cause an explosion). Doing this will avoid the
warranty.
Do not place heavy objects on the device.
Use only supplied and approved charger.
Replacement or service must be done by qualified service center or manufacturer.
Unplug this device when unused for long periods of time or during lightning storms.
CAUTIONS: ELECTRIC SHOCK HAZARD
The battery used in this device may present a risk of fire or chemical burn if mistreated.
9. Declaration of Conformity
9.1. FCC Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired operation.
Note: The manufacturer is not responsible for ANY interference, for example RADIO or TV interference, caused by unauthorized
modifications to this equipment. Such modifications could void the user’s authority to operate the equipment.
9.2. EU
This product is CE certified according to the provision of the R&TTE Directive (99/5/EC).
Declares that this product is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.
9.3. RF Warning Statement:
The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition
without restriction. Changes or modifications not expressly approved by the party responsible for compliance. Could void the user's
authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radiofrequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
--Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
9.4. Trademark Statement
The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc.
Avantalk is a trademark owned by Avantronics limited.
10. Warranty
Please refer the warranty card included in the pack.
Online Tutorial & Technical Support
More information about this product and other Avantalk Bluetooth products, including the video user guide, product tutorial and
online technical support, please refer to www.avantalk.com website.
Due to software update, there could be some changes on operations. Please always refer to Product Tutorial page in Avantalk
website for the latest features.
Z-PKMN-AS6-0000
