Avaya Canada Corporation BTS 24 GHz Service Transceiver
Product information
![](/img.php?id=134640&img=bg1.png)
NTP #: 411-1333-910
Preliminary 01.01 December 2000
BTR 24-01 GHz MMIC
Quick Reference Guide
Product Overview
The BTR 24-01 GHz MMIC (DSVG11BA) outdoor transceiver is a state-of-the-
art broadband microwave transceiver designed to operate at various frequency
bands downstream. It is a combined broadband transmitter and receiver deployed
in Nortel Networks Reunion point-to-multipoint system. It is compatible with
Reunion’s Release 1.2, 1.3 and 1.4 equipment.
Figure 1: BTR 31-01M Block Diagram
Rx IF Output
Tx IF Input
Transceiver
Lightning
Radio
Protector
Lightning
Protector
Rx RF Input
(Test Point ‘B’)
(Test Point ‘A’)
Tx RF Output
Test Por t
Rx IF Output
Test Por t
Lightning
Protector
BTR 24-01M Transceiver
![](/img.php?id=134640&img=bg2.png)
411-1333-910 Preliminary 01.01 December 2000
2
BTR 24-01 MMIC Specification
Table 1: BTR 24-01M Technical Specifications
TX IF Input RF Output
Frequency Range 24-01M 450-650 MHz 24.25 - 24.45 GHz
Output Level (P1 dB) ≥27.4 dBm, -40° to +30° C
≥27.2 dBm, +30° to +50° C
≥27.2 dBm, +50° to +60° C
Input Impedance 50 Ohms
Input/Output Connector N-Type Female WR-42 (hole pattern not standard)
Input/Output VSWR 1.925:1 (or 10
dB), maximum
2.3:1, max (or 8 dB)
Gain (mid-band at room temper-
ature not including antenna)
32 ±1.0 dB, minimum
Gain Variation ±5.5 dB over all conditions
Gain Flatness ±2 dB over 200 MHz BW
LO leakage <-43 dBm (outband)
Frequency Stability <±4 ppm over all conditions
Tx Noise Power -115 dBm/Hz, maximum
Tx IF Test Port Coupling -16± 1 dB
Antenna BTR
Frequency 24.25 - 24.45 GHz
Frequency Band 2426
Bore-sight Gain (Azimuth) 15.75±1.25 dBi, 90° Horn
18.9±1.25 dBi, 45°
23.8±1.3 dBi, 15°
Wave-guide Interface WR-42 (non-standard hole pattern)
Size (Length x Height x Width) 10" x 9" x 2" (90°)
Polarity Cross-polarized (co-polarized avialable)
Sectorized Angle Available 15°, 45°, and 90°
![](/img.php?id=134640&img=bg3.png)
BTR 24-01 GHz MMIC Quick Reference Guide
3
RX RF Input IF Output
Frequency Range 31-01M 25.05 - 25.25 GHz 150 - 350 MHz
Input/Output Connector WR-42 (hole pattern not standard) N-Type female
Input P1 dB -18 dBm
Output Impedance N/A 50 Ohms
Input/Output VSWR 2.3:1, max (or 8 dB) 2.1:1, max (or 9 dB)
Gain (mid-band at room tem-
perature not including
antenna)
28 ±1.0 dB
Gain Flatness ±2.0 dB over bandwidth
Gain Variation ±5.5 dB over all conditions
Frequency Stability <±4 ppm over all conditions
Tx IF Test Port Coupling -14± 1 dB
Noise Figure < 6.0 dB, -40° to +30° C
< 6.5 dB, +30° to +50° C
< 6.5 dB, +50° to +55° C
Power Requirements BTR
Input Voltage -48 VDC
Input Inrush Current <4.5A max
Input Power 66 Watts, maximum
Environmental BTR
Humidity 100% condensing
Altitude 3000 meters
Operating Wind Resistance 50m/second on all surfaces
Operating Temperature -40° to +60°C
Storage Temperature Range -45° to +70°C (packaged)
Solar Loading ETS 300 019 class 4.1 1120W/m2, 50°C max.
Mechanical BTR
Size (Length x Height x Width) 19.2" x 10.3" x 6.7" (49 x 26 x 17 cm)
Weight without brackets 35 lbs. (16KG)
![](/img.php?id=134640&img=bg4.png)
Information is subject to change without notice.
Nortel reserves the right to make changes in
design or components as progress in engineering
and manufacturing may warrant.
© 2000 Northern Telecom Ltd.
Converted Frequency Formula
Use the following formula to calculate the converted frequency:
TX: ƒRF OUT (GHz) = 24.9 - ƒIF IN (GHz)
RX: ƒIF OUT (GHz) = ƒRF IN (GHz) - 24.9
Note: Vent holes are covered with a GoretexTM patch.
Note: The transceiver mounts to a vertical pole of 2.5” to 4.5” outside diame-
ter. It has a range of motion of 90° over and -60° under horizon. The bases of
the antenna mount can rotate ±180°.
Technical Assistance Contact Information
In case additional technical assistance is required, or the transceiver unit is
damaged upon receipt, contact Nortel Networks.
Nortel Networks Broadband Wireless Access (BWA) provides 24-hour customer
service and technical support to ensure your service operation is trouble-free.
If you have questions or need technical support, contact Nortel Networks
Broadband Wireless Access at the following telephone numbers:
• In the USA and Canada, call 972-BWA-ETAS/972-292-3827
