Avaya Canada CTR2808M LMDS CPE Transceiver User Manual

Avaya Canada Corporation LMDS CPE Transceiver

Reference guide

NTP #:411-1333-923
Draft 01.03 November 2000
CTR 28-08 GHz MMIC
Quick Reference Guide
Product Overview
The CTR 28-08 MMIC (NTVG16BH) outdoor transceiver is a customer premise
transceiver designed to operate in various Receiver (Rx) and Transmitter (Tx)
frequency bands. It is a Nortel Networks Reunion product that operates in con-
junction with base station products, as well as customer premise products. It is
compatible with Reunion’s Release 1.2, 1.3 and 1.4 equipment.
Figure 1: CTR 28M Block Diagram
Rx IF
Tx IF/DC Input
Transceiver
Lightning
Radio
Protector
Lightning
Protector
Rx RF Input
Tx RF Output
Test Port
Tx IF Input
Test Port
Rx IF Output
Output
CTR 28M Transceiver
411-1333-923 Draft 01.03 November 2000
2
CTR 28-08 MMIC Specification
Table 1: CTR 28-08M Technical Specifications
TX IF Input RF Output
Frequency Range 28-08M
500-650 MHz 27.85-28.00 GHz
Output Level (P1 dB) 23 dBm, -40° to +55° C
Output Level (IP3) > +31 dBm
Input Impedance 50 Ohms
Input/Output Connector N-Type Female N/A (integrated antenna)
Input/Output VSWR 1:93:1 maximum N/A
Gain (not including antenna) 33 dB
Gain vs. Temperature ±2.0 dB ( -40° to +55° C)
Gain Flatness ±2.0 dB over bandwidth
Frequency Stability <±4 ppm, Over all Conditions
Noise Figure 24.5 dB
Tx IF Test Port Type SMA jack (F)
Antenna CTR
Frequency 27.5 - 31.3 GHz
Frequency band 2731
Bore-sight Gain (Azimuth) 37.4 ±1.4 dB
Polarity V/V or H/H determined mechanically on installation
Beam Width (azimuth)
Beam Width (elevation)
2.6±TBD°, minimum
2.6±TBD°, minimum
Flanges WR-42
Port-to-Port Isolation 35 dB, minimum
Cross-Polarization Discrimination > 30 dB
Diameter 14" (35 cm)
CTR 28-08 GHz MMIC Quick Reference Guide
3
RX RF Input IF Output
Frequency Range 28-08M 27.50 - 27.65 GHz 150-300 MHz
Input/Output Connector N/A (integrated antenna) N-Type Female
Output Impedance 50 Ohms
Input/Output VSWR N/A (integrated antenna) 1:93:1 maximum
Gain (not including antenna) 28.0 ±1.0 dB
Gain Flatness ±2.0 dB over bandwidth
Gain Stability ±2.0 dB over temperature
Frequency Stability <±4 ppm
Noise Figure 7.8 dB, -40° to +55° C
Rx IF Test Port Type SMA jack (F)
Power Requirements CTR
Input Voltage ±48 VDC, 3A. max
diplexed with TX cable
Input Inrush Current 4.5A max
Input Power 54 Watts, maximum
Environmental CTR
Humidity 100% condensing
Altitude 10,000 feet
Operating Wind Resistance 50m/second on all surfaces
Operating Temperature -40° to +55°C
Storage Temperature Range -45° to +70°C (packaged)
Solar Loading ETS 300 019 class 4.1 1120W/m2, 50°C max.
Mechanical CTR
Size (Length x Height x Width) 14" x 14" x 11" (35.6 x 35.6 x 27.9 cm)
Weight without brackets 25 lbs. (11.41 KG)
Information is subject to change without notice.
Nortel reserves the right to make changes in
design or components as progress in engineering
and manufacturing may warrant.
© 2000 Northern Telecom Ltd.
Converted Frequency Formula
Use the following formula to calculate the converted frequency:
TX: ƒRF OUT (GHz) = ƒIF IN (GHz) + 27.35
RX: ƒIF OUT (GHz) = ƒRF IN (GHz) - 27.35
Note: Electrostatic deposition powder coat, scratch free.
Note: Vent holes are covered with a GoretexTM patch.
Note: The transceiver mounts to a vertical pole of 2.5” to 4.5” outside diame-
ter. It has a range of motion of 90° over and -60° under horizon. The bases of
the antenna mount can rotate ±180°.
Technical Assistance Contact Information
In case additional technical assistance is required, or the transceiver unit is
damaged upon receipt, contact Nortel Networks.
Nortel Networks Broadband Wireless Access (BWA) provides 24-hour customer
service and technical support to ensure your service operation is trouble-free.
If you have questions or need technical support, contact Nortel Networks
Broadband Wireless Access at the following telephone numbers:
In the USA and Canada, call 972-BWA-ETAS/972-292-3827
