MONARCH®, 9825®, 9855®, and 9860 are trademarks of Paxar Americas, Inc.
Paxar® is a trademark of Paxar Corporation.
Avery Dennison® is a trademark of Avery Dennison Corp.
Oracle, JD Edwards, PeopleSoft, and Siebel are registered trademarks of Oracle Corporation
and/or its affiliates. SAP and NetWeaver are trademarks of SAP AG in Germany and in several
other countries.
©2006 Paxar Americas, Inc. a subsidiary of Avery Dennison Corp.
All rights reserved.
TC9855XMLQR Rev. AD 11/07
XML QUICK REFERENCE
This Quick Reference lists the XML-enabled tags that the Monarch®
9825®, 9855® or 9860 printers can interpret.
Your printer has one of the following options:
Oracle® WMS (Warehouse Management) print jobs
SAP NetWeaver® Auto-ID (RFID) Infrastructure (AII-DC-RFID)
The following table lists the software versions that support the
XML options.
XML Options 9825 9855 9860
Oracle® WMS (Warehouse Management) print jobs 2.8 5.0 5.0
SAP NetWeaver® Auto-ID (RFID) 2.8 5.3 5.3
About This Quick Reference
This Quick Reference contains
information that applies to both XML-enabled options, including
“Defining the Format Header,” “Using Option 21 (Define Extended
Field Names),” and “Error Messages.”
specific information for each option. See the following sections as
necessary based on your printer.
a sample label format.
Note: This Quick Reference does not contain information about
installing or setting up the printer for use on a network running
Oracle® software or the SAP NetWeaver® platform.
Information in this document supercedes information in previous versions.
Check our Web site (www.paxar.com) for the latest documentation and
release information.
2 Quick Reference
Defining the Format Header
Use this section with either XML-enabled option. A Format Header
begins a format file.
Syntax {F,format#,action,device,measure,length,
width,"name"¦
F1. F Format Header.
F2. format# Number from 1-999 to identify the format.
F3. action Enter A to add a new format to the printer.
F4. device Format storage device. Use F (Flash).
F5. measure Unit of measure: E (English), M (Metric), or
G (Graphic Dots).
Printer Unit of Measure Length Width
9855/9860 English (1/100 inch)
Metric (1/10 mm)
203 dpi Dots
75-1600
191-4064
152-3248
32-400
81-1016
62-812
Refer to the optional Packet Reference Manual for
more information.
F6. length Length in selected units. Measure supply from the
leading edge of one label to the leading edge of the
next label. The leading edge is the edge that exits
the printer first.
F7. width Width, from left to right, in selected units.
F8. "name" Format name, 1-256 characters, enclose within
quotation marks. The name can contain special
characters, excluding non-printable control characters
and the quotation mark (").
Example {F,1,A,F,E,300,200,"XML_FORMAT_ONE"¦
Defines the name for format 1 as XML_FORMAT_ONE.
3
Using Option 21 (Define Extended Field Names)
Use this section with either XML-enabled option. Option 21 defines
names for each field in a format, which can be longer than eight
characters.
Syntax R,21,"field_name"¦
R1. R Option Header.
R2. 21 Option 21.
R3. field_name Specifies the field name. Must be enclosed within
quotations. The name can be up to 256 characters,
excluding non-printable control characters and the
quotation mark ("). This name must match the one
specified in the variable name or Field name attribute.
Example T,2,10,V,250,50,0,1,1,1,B,C,0,0,0¦
R,21,"SALEPRICE_FIELD
Defines the name for text field 2 as “SALEPRICE_FIELD.”
Error Messages
Use this section with either XML-enabled option. You may receive this
error when using XML supported tags.
002 The Format Name must be between 1 to 8 characters inside quotes.
Extended Format Names and Option 21 names can be between 1 and
256 characters excluding non-printable control characters and the
quotation mark (").
About Oracle WMS Print Jobs
The XML-enabled printer contains the following 10 Oracle® Warehouse
Management print jobs (label formats):
LPN Label LPN Content Label
LPN Summary Label Material Label
Serial Label Location Label
Shipping Label Shipping Content Label
WIP Content Label Flow Content Label
Refer to your Oracle
®
Integration Certification DocumentOracle
Warehouse Management Label Printing Integration Kit for information
about the format layout and descriptions of each field on the formats.
4 Quick Reference
When you turn on the printer, you see
WMS XML
Mode Ready
When you print test labels, the model number appears as M9855X, for
example.
Supported Tags – Oracle WMS Print Jobs
There are three supported XML tags for Oracle Warehouse Management
print jobs. The printer ignores any other XML tags/attributes not defined
in this document and no error is reported.
Syntax <labels attributes="values">
<label attributes="values">
<variable name="name">data</variable>
</label>
</labels>
labels This tag contains one or more labels, which may
include one or more of the following attributes:
_FORMAT The default name of the format.
This name must match the one
specified in the Format Header.
_QUANTITY Quantity to print. 1 is the default.
label This tag contains a single label, which may include
one or more of the following attributes:
_FORMAT The default name of the format.
This name must match the one
specified in the Format Header. If
no format name is given, then the
default format name from the
labels tag _FORMAT attribute is
used.
_QUANTITY Quantity to print. If no quantity is
specified, then the default quantity
from the labels tag _QUANTITY
attribute is used.
variable This tag specifies the field name and the variable
field data. It must contain the following attribute:
name The name of the field that matches
the ones specified using Option
21. It must contain the variable
data (batch data) associated with
the format.
5
Sample MPCL Format
{F,1,A,F,E,400,400,"XML_FORMAT_ONE" ¦
T,1,25,V,20,20,0,1,1,1,B,L,0,0¦
R,21,"TEXT_FIELD_XML"¦
B,2,30,V,100,20,8,8,75,0,L,0¦
R,21,"CODE_128_BARCODE_FIELD_XML"¦}
This MPCL format uses:
format – XML_FORMAT_ONE
text field – TEXT_FIELD_XML
bar code field – CODE_128_BARCODE_FIELD_XML.
Sample XML Print Job
<?xml version="1.0" encoding="UTF-8"
standalone="no"?>
<!DOCTYPE labels SYSTEM "label.dtd">
<labels _FORMAT ="XML_FORMAT_ONE" _QUANTITY="1">
<label>
<variable name= "TEXT_FIELD_XML">XML Test
Label</variable>
<variable name=
"CODE_128_BARCODE_FIELD_XML">Code128data</variable>
</label>
</labels>
This XML print job uses:
format – XML_FORMAT_ONE
text field – TEXT_FIELD_XML with data XML Test Label
bar code field – CODE_128_BARCODE_FIELD_XML with data
Code128data.
6 Quick Reference
About the SAP NetWeaver® Auto-ID Infrastructure
The XML-enabled printer is designed for use with the SAP NetWeaver®
platform and the Auto-ID Infrastructure component (AII-DC-RFID).
When you turn on the printer, you see
SAP XML
Mode Ready
When you print test labels, the model number appears as M9855X, for
example.
Supported Tags – SAP Auto-ID Infrastructure
There are five supported XML tags for the SAP NetWeaver Auto-ID
Infrastructure. The printer ignores any other XML tags/attributes not
defined in this document and no error is reported.
Syntax <Command>
<WriteTagData attributes="values">
<Item>
<FieldList attributes="values">
<Field attributes="values">
</Field>
</FieldList>
</Item>
</WriteTagData>
</Command>
Command This tag contains one or more WriteTagData tags.
There are no attributes required. The xmlns:xis
attribute is ignored.
WriteTagData This tag contains one or more Item tags. There are
no attributes required. The readerID attribute is
ignored.
Item This tag contains one FieldList tag or multiple TagID
tags. There are no attributes required. The TagID
tag is ignored.
7
FieldList This tag contains one or more Field tags, which may
include one or more of the following attributes:
format The default name of the format. This
name must match the one specified in
the Format Header.
This attribute is required.
jobname This attribute is ignored.
quantity Quantity to print. 1 is the default.
This attribute is optional.
Field This tag specifies the field name and the variable
field data. It must contain the following attribute:
name The name of the field that matches the
ones specified using Option 21. It must
contain the variable data (batch data)
associated with the format.
Note: The SAP software sends RFID
data in a field named “EPC”.
Apply Option 21 to the RFID Data
Field and name that field “EPC”.
8 Quick Reference
Sample MPCL Format
{F,1,A,F,E,600,400,"EPC_FORMAT_3"¦
C,560,10,0,1,1,1,O,L,0,0,"DOCUMENT_NO:"¦
T,1,40,V,560,140,0,1,1,1,O,L,0,0¦
R,21,"DOCUMENT_NO"¦
C,520,10,0,1,1,1,O,L,0,0,"DOCUMENT_TYPE:" ¦
T,2,40,V,520,150,0,1,1,1,O,L,0,0¦
R,21,"DOCUMENT_TYPE"¦
C,480,10,0,1,1,1,O,L,0,0,"EPC_TYPE:" ¦
T,3,40,V,480,110,0,1,1,1,O,L,0,0¦
R,21,"EPC_TYPE"¦
C,440,10,0,1,1,1,O,L,0,0,"EPC_URN:
T,4,60,V,420,20,0,1,1,1,O,L,0,0¦
R,21,"EPC_URN"¦
C,380,10,0,1,1,1,O,L,0,0,"EPC_URN_NO_HEADER:"¦
T,5,40,V,380,180,0,1,1,1,O,L,0,0¦
R,21,"EPC_URN_NO_HEADER
C,340,10,0,1,1,1,O,L,0,0,"GTIN:"¦
T,6,40,V,340,80,0,1,1,1,O,L,0,0¦
R,21,"GTIN"¦
C,300,10,0,1,1,1,O,L,0,0,"PRODUCT:
T,7,40,V,300,100,0,1,1,1,O,L,0,0¦
R,21,"PRODUCT"¦
C,260,10,0,1,1,1,O,L,0,0,"PRODUCT_DESCRIP:"¦
T,8,40,V,260,160,0,1,1,1,O,L,0,0¦
R,21,"PRODUCT_DESCRIPTION"¦
X,99,24¦
R,21,"EPC"¦}
This MPCL format uses:
format – EPC_FORMAT_3
text field – DOCUMENT_NO
text field – DOCUMENT_TYPE
text field – EPC_TYPE
text field – EPC_URN
text field – EPC_URN_NO_HEADER
text field – GTIN
text field – PRODUCT
text field – PRODUCT_DESCRIPTION
RFID data field – EPC (line beginning with X).
9
Sample XML Print Job
<?xml version="1.0" encoding="UTF-8" ?>
<Command xmlns:xsi="http://www.w3.org/2001/XMLSchema-
instance" xsi:noNamespaceSchemaLocation="Command.xsd">
<WriteTagData readerID="ICC_HTTP_DEVICE">
<Item>
<FieldList format="EPC_FORMAT_3"
jobName="WRITE20051215190125" quantity="1">
<Field name="DOCUMENT_NO">Nov_29_02</Field>
<Field name="DOCUMENT_TYPE">51</Field>
<Field name="EPC">30740242204031400000001C</Field>
<Field name="EPC_TYPE">SGTIN-96</Field>
<Field name="EPC_URN">urn:epc:tag:sgtin-
96:3.0037000.065733.28</Field>
<Field name="EPC_URN_NO_HEADER">3.0037000.065733.28</Field>
<Field name="GTIN">00037000657330</Field>
<Field name="PRODUCT">RFID_MAT1</Field>
<Field name="PRODUCT_DESCRIPTION">RFID Material 1</Field>
</FieldList>
</Item>
</WriteTagData>
</Command>
This XML print job uses:
format – EPC_FORMAT_3
text field – DOCUMENT_NO with data – Nov_29_02
text field – DOCUMENT_TYPE with data – 51
RFID Data Field – EPC with data – 30740242204031400000001C
text field – EPC_TYPE with data – SGTIN-96
text field – EPC_URN with data – urn:epc:tag:sgtin-
96:3.0037000.065733.28
text field – EPC_URN_NO_HEADER with data – 3.0037000.065733.28
text field – GTIN with data – 00037000657330
text field – PRODUCT with data – RFID_MAT1
text field – PRODUCT_DESCRIPTION with data – RFID Material 1.
10 Quick Reference
Sample Label

Navigation menu
