General Description
Every consumer wants to be free from wires,
but system designers could never find a low-
cost, high-quality, easy-to-use wireless audio
solution for speakers, microphones,
headphones and headsets on the market.
Avnera’s proprietary wireless system changes
the game by taking a new approach to
wireless audio. The wireless protocol was
designed from the ground up and delivers
uncompressed stereo audio over the air
without interference problems.
Avnera’s wireless USB dongle offers a low-
touch, easy-to-integrate wireless audio
solution and enable fast time to market by
already solving the problem associated with
FCC, antenna tuning and board optimization.
Avnera’s AVRB7101A USB dongle provides
breakthrough wireless audio functionality with
point to point transport of uncompressed
stereo PCM audio data from an AVRB7101A
sender to an AVMD71x2 listener.
Applications
9 Wireless audio transmitter for wireless
USB headsets and headphones
9 Wireless audio distribution hub for
surround speakers
Features
9 Uncompressed audio, point to point
9 Forward audio path: stereo 91 dB SNR, 48
kHz sampling rate
9 Reverse voice path: mono 64 dB SNR, 16
kHz sampling rate
9 Support for 10m (typical) range
9 Frequency range: 2.4 GHz ISM band,
continuous dynamic frequency selection
9 Forward error correction coding, error
detection, and audio-specific error
concealment
9 Connector: USB connector
9 One programmable button
9 One programmable LED
9 Auto-search/synch and dynamic channel
selection
9 Low, fixed latency suitable for video lip-
synch
9 Support for 16, 20, 24, and 32 bit PCM
words at 16, 22.05, 24, 32, 44.1, 48, and 96
kHz
9 General purpose over-the-air (OTA) serial
interface:
9 2 kbps, bi-directional, full duplex
9 Support for meta-data and remote
control commands
AVRB7101A
Wireless Audio USB Dongle
User Guide
AVRB7101A Dongle User Guide v0p22
CONTENTS SUBJECT TO CHANGE WITHOUT NOTICE 2 AVNERA PROPRIETARY & CONFIDENTIAL
AVRB7101A Pin Information
Pin Number Pin Name Type Pin Description
1 VDC Power USB power connection (Vbus)
2 DM Analog USB D- connection
3 DP Analog USB D+ connection
4 GND Ground USB ground connection
Absolute Maximum Ratings
Absolute Maximum Ratings (AMR) are stress ratings only. AMR corresponds to the maximum value that can be applied without leading
to instantaneous or very short-term unrecoverable hard failure (destructive breakdown). Stresses beyond those listed under AMR may
cause permanent damage to the device.
Functional operation of the device at these or any other conditions beyond those indicated under “Recommended Operating Range” is
not implied. Exposure to absolute-maximum-rated conditions for extended periods may adversely affect device reliability.
Device functional operating limits and guaranteed performance specifications are given under Electrical Characteristics at the test
conditions specified.
CONDITION MIN MAX
USB VDC Supply Voltage Input -0.3V 6.5V
Operating Temperature -40ºC +85ºC
Storage Temperature -40ºC +100ºC
Static Discharge Voltage – HBM
* 1000V
*Terminology: HBM => ESD human body model
Recommended Operating Range
PARAMETER MIN TYP MAX UNIT
USB VDC Supply Voltage Input 4.5 5.0 5.5 V
Ambient Temperature (TA) -20 70 ºC
AVRB7101A Dongle User Guide v0p22
CONTENTS SUBJECT TO CHANGE WITHOUT NOTICE 3 AVNERA PROPRIETARY & CONFIDENTIAL
FCC certification information
This product is certified under US FCC ID: V3CAVRB7101A
Avnera makes the following representations:
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
(2) This device must accept any interference received, including
interference that may cause undesired operation.
Per FCC regulation 47 CFR 15.21: Changes or modifications not expressly approved by Avnera, as the party
responsible for compliance, can void the user’s authority to operate the equipment using AVRB7101A
dongles.
NOTE:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
AVRB7101A Dongle User Guide v0p22
CONTENTS SUBJECT TO CHANGE WITHOUT NOTICE 4 AVNERA PROPRIETARY & CONFIDENTIAL
Contact Information and Legal Disclaimer
Avnera Corporation
16505 Bethany Court, Suite 100
Beaverton, Oregon 97006
U.S.A.
Main: +1.503.718.4100
Fax: +1.503.718.4101
www.avnera.com
Avnera Corporation reserves the right to make changes without notice to the product to improve function,
reliability, or performance.
Avnera Corporation does not assume any liability arising from the application or use of the products or circuits
described herein.
