Azumi S.A Mobile Phone Usemanual
User manual
-1-
Content
1General Information.................................................................................................................................................5
1.1Profile.............................................................................................................................................................. 5
1.2Safety Information .......................................................................................................................................... 5
1.3Safety warning and Attentions........................................................................................................................ 5
2Your phone.................................................................................................................................................................8
2.1Phone overview............................................................................................................................................... 8
2.2Functions of Keys........................................................................................................................................... 8
2.3Technical specifications.................................................................................................................................. 9
3Getting started.........................................................................................................................................................10
3.1Installing the SIM Cards and the Battery...................................................................................................... 10
3.2Installing T-Flash Card.................................................................................................................................. 12
3.3Charging the Battery..................................................................................................................................... 12
3.4Powering On/Off the Mobile Phone ............................................................................................................. 15
3.5Linking to the Network................................................................................................................................. 15
3.6Dialing Calls ................................................................................................................................................. 15
3.7Using the Headset ......................................................................................................................................... 16
-2-
4Input method...........................................................................................................................................................17
4.1Icons for Input Methods................................................................................................................................ 17
4.2To Shift Entry Methods................................................................................................................................. 17
4.3Numeric and English Input........................................................................................................................... 17
5Using the menu........................................................................................................................................................18
5.1TELCEL........................................................................................................................................................ 18
5.2Messaging ..................................................................................................................................................... 18
5.3Dialer ............................................................................................................................................................ 19
5.4Video player.................................................................................................................................................. 20
5.5Audio Player ................................................................................................................................................. 20
5.6Portal movil................................................................................................................................................... 20
5.7Camera.......................................................................................................................................................... 20
5.8Video recorder............................................................................................................................................... 20
5.9Phonebook..................................................................................................................................................... 20
5.10Settings.......................................................................................................................................................... 21
5.11Call logs ........................................................................................................................................................ 25
5.12Calendar........................................................................................................................................................ 25
5.13TV................................................................................................................................................................. 25
-3-
5.14Bluetooth....................................................................................................................................................... 25
5.15FM Radio...................................................................................................................................................... 26
5.16Profiles.......................................................................................................................................................... 26
5.17File manager.................................................................................................................................................. 27
5.18Alarm ............................................................................................................................................................ 27
5.19Image viewer................................................................................................................................................. 27
5.20Calculator...................................................................................................................................................... 27
5.21Sound recorder.............................................................................................................................................. 28
5.22Connectivity.................................................................................................................................................. 28
5.23World clock................................................................................................................................................... 28
5.24Lock .............................................................................................................................................................. 28
5.25Java ............................................................................................................................................................... 28
5.26E-book reader................................................................................................................................................ 29
5.27Browser......................................................................................................................................................... 29
5.28WLAN .......................................................................................................................................................... 29
5.29ITelcel ........................................................................................................................................................... 30
5.30Facebook....................................................................................................................................................... 30
6Appendix..................................................................................................................................................................30
-4-
-5-
1 General Information
1.1 Profile
Please read this pamphlet carefully in order to make your phone in perfect condition.
Our company may change this mobile phone without prior written notice and reserves the final right to
interpret the performance of this mobile phone.
Due to different software and network operators, display on your phone may be different, refer to your
phone for details.
1.2 Safety Information
If your phone has lost or been stolen, notify the telecommunication office the SIM card is disabled
(network support is required). This can avoid economic loss caused by unauthorized use.
Please take measures as following to avoid your phone being unauthorized use:
· Set PIN code of SIM card
· Set phone password
1.3 Safety warning and Attentions
Safety warning
¾ ROAD SAFETY COMES FIRST
Do not use a hand-held phone while driving. Use hands-free fittings when calls are unavoidable while driving.
In some countries, dialing or receiving calls while driving is illegal!
-6-
¾ SWITCH OFF IN AIRCRAFT
Wireless devices can cause interference in aircraft. Using a mobile phone in flight is illegal and risky.
Please make sure that your mobile phone is powered off in flight.
¾ SWITCH OFF BEFORE ENTERING RISKY AREAS
Strictly observe the relevant laws, codes, and regulations on the use of mobile phones in risky areas. Turn off
your mobile phone before entering a place susceptible to explosion, such as an oil station, oil tank, chemical
plant or a place where a blasting process is under way.
¾ OBSERVE ALL SPECIAL REGULATIONS
Follow any special regulations in force in any area such as hospitals and always switch off your phone
whenever it is forbidden to use it or, when it may cause interference or danger. Properly use your mobile
phone near medical apparatuses, such as pacemakers, hearing aids and some other electronic medical devices,
as it may cause interference to such apparatuses.
¾ INTERFERENCE
The conversation quality of any mobile phone may be affected by radio interference. An antenna is built
inside the mobile phone and located below the microphone. Do not touch the antenna area during a
conversation, lest that the conversation quality deteriorate.
¾ QUALIFIED SERVICE
Only qualified personnel may install or repair phone equipment. Installing or repairing the mobile phone on
your own may bring great danger and violates the warranty rules.
¾ ACCESSORIES AND BATTERIES
Use only approved accessories and batteries.
¾ USE SENSIBLY
-7-
Use only in a normal and proper manner.
¾ EMERGENCY CALLS
Ensure the phone is switched on and in service, enter the emergency number, e.g. 112, then press the Dial key.
Give your location and state your situation briefly. Do not end the call until told to do so.
Note: Just like all other mobile phones, this mobile phone does not necessarily support all the features
described in this manual due to network or radio transmission problems. Some networks even do not support
the emergency call service. Therefore, do not rely solely on the mobile phone for critical communications
such as first aid. Please consult the local network operator.
Precautions
This mobile phone is well designed with fine art. Please exercise special care when using it. The following
suggestions will help your mobile phone survive the warranty period and extend its service life:
¾ Keep the mobile phone and all its fittings beyond children's reach.
¾ Keep the mobile phone dry. Keep away from rain, moisture, liquid or other substances that may corrode
electronic circuits.
¾ Do not use or store the mobile phone in dusty places, lest that active parts of the mobile phone be damaged.
¾ Do not store the mobile phone in a high-temperature place. High temperature will shorten the life of
electronic circuits and damage the battery and some plastic parts.
¾ Do not store the mobile phone in a chilly place. Otherwise, moistures will be formed inside the mobile
phone to damage electronic circuits when the mobile phone is moved to a constant temperature place.
¾ Do not throw, knock or shock the mobile phone, as that will destroy the internal circuits and high-precision
components of the mobile phone.
-8-
2 Your phone
2.1 Phone overview
2.2 Functions of Keys
The mobile phone provides the following keys:
Dial key
Press it to originate a call by entering the called number or selecting a contact from the phonebook; or
press it to receive an incoming call; or press it in standby state to show the latest call records
OK key
Press it to confirm your selection.
Direction key
Press them to scroll the options when browsing a function list. In edit state, press direction keys to
navigate.
End key
Press it to end a call being dialed or end an ongoing call; or press it to exit the menu and return to the
standby state; or hold it for two or three seconds to power on or off the mobile phone; or press it to lock
-9-
the keypad in standby interface.
Moreover, you can access dial interface by taping a telephone icon in the idle screen, and the following
keys would display on the dial interface: Number keys, * key, # key and dial key
Tap number keys 0 through 9 to input numbers;
Hold the # key up to 2s to activate or deactivate the silent mode.
Press and hold the * key up for 2s to input "+" in standby interface. When the symbol "+" appears,
press the * key quickly to input "P" or "W". "P" and "W" are used for calling the extension; "+" are used for
dialing an international call.
After inputting phone number, tap dial key to originate a call on SIM.
2.3 Technical specifications
Phone
Dimensions (W×D×H):
Weight:
Lithium battery
Rated capacity:
Continuous standby duration: (Relates to network status)
Continuous conversation duration: (Relates to network status)
Please refer to their labels for other data related to the battery and the charger.
-10-
3 Getting started
3.1 Installing the SIM Cards and the Battery
An SIM card carries useful information, including your mobile phone number, PIN (Personal
Identification Number), PIN2, PUK (PIN Unlocking Key), PUK2 (PIN2 Unlocking Key), IMSI
(International Mobile Subscriber Identity), network information, contacts data, and short messages data.
Note:
After powering off your mobile phone, wait for a few seconds before removing or inserting an SIM card.
Exercise caution when operating an SIM card, as friction or bending will damage the SIM card.
Properly keep the mobile phone and its fittings such as the SIM cards beyond children's reach.
Installation
Hold the End key for a while to power off the mobile phone
Push the back cover above the battery and remove it.
Pull the left battery buckle outward and then lift the battery away.
Insert the SIM card into the SIM card slot lightly with the corner cutting of the card aligning to the
notch of the slot and the gold plate of the card facing download, till the SIM card cannot be further
pushed in.
With the metallic contacts of the battery facing the metallic contacts in the battery slot, press the
battery down until it locks into place.
Using code
The mobile phone and the SIM cards support sorts of passwords, in order to prevent the phone and the
SIM cards from being misused. When you are prompted to input any of the codes mentioned below, just
-11-
input the correct code and then confirm.
Phone lock code
The phone lock code may be set to prevent your mobile phone from being misused. In general, this code
is provided along with the mobile phone by the manufacturer. The initial phone lock code is set to 1122 by
the manufacturer. If the phone lock code is set, you need to input the phone lock code when powering on the
mobile phone.
PIN
The PIN (Personal identification number, 4 to 8 digits) code prevents your SIM card from being used by
unauthorized people. In general, the PIN is supplied with SIM card by the network operator. If PIN check is
enabled, you need to input the PIN each time when you power on your mobile phone. The SIM card will be
locked if you input wrong PIN code for three times.
Unlocking methods as follows:
-Input the correct PUK according to the screen tips to unlock the SIM card.
-Then input the new PIN and confirm.
-Input the new PIN again and then confirm.
-If the input PUK is correct, the SIM card will be unlocked and the PIN will be reset.
Note: The SIM card will be locked if you input wrong PIN code for three times. To unlock the SIM card,
you need to input the PUK. In general, the PUK can be obtained from the network operator.
PUK
The PUK code (Personal Unlocking Key) is required to change a blocked PIN. It is supplied with SIM
card. If not, contact your network operator. If you input wrong PUK code for 10 times, SIM card will be
invalid. Please contact the network operator to replace the SIM card.
-12-
Barring code
A barring code is required for setting the call barring function. You can obtain this code from the
network operator to set the call barring function.
3.2 Installing T-Flash Card
The T-Flash card is a pluggable mobile storage card inside the mobile phone.
To install the T-Flash card, open its latch, place its indented side downward, insert the card into the card
slot, and then close the latch.
To remove the T-flash card, open its latch and slightly take the card out. And then close the latch.
Note:
1. The mobile phone cannot automatically identify the T-flash card being inserted when the mobile phone is
powered on. You must power off the mobile phone and then power it on, so that the phone can identify the
T-Flash card.
2. The T-Flash card is a miniature object. Keep it out of the reach of children for fear that children swallow
it!
3.3 Charging the Battery
The lithium battery delivered with the mobile phone can be put into use immediately after being
unpacked.
Battery level indication:
Your mobile phone can monitor and display the battery state.
Normally the remaining energy of the battery is indicated by the battery level icon at the upper right
corner of the display screen.
-13-
When the battery energy is insufficient, the mobile phone prompts "Battery low". If you have set an
alert tone, an alert tone will be given off when the battery level is too low.
A charging animation appears when the battery is being charged. When the charging is complete, the
animation disappears.
Using a travel adapter:
Install the battery into the mobile phone before charging the battery.
Connect the adapter of the travel charger with the charging slot in the mobile phone. Ensure that the
adapter is fully inserted.
Insert the plug of the travel charger to an appropriate power outlet.
During the charging, the battery level grids in the battery icon keep flickering till the battery is fully
charged.
It is normal when the battery is become hot during the charging period.
The battery icon does no longer flicker when the charging process ends.
Note:
Ensure that the plug of the charger, the plug of the earphone, and the plug of the USB cable are inserted
in the right direction. Inserting them in a wrong direction may cause charging failure or other problems.
Before the charging, ensure that the standard voltage and frequency of the local mains supply match the
rated voltage and power of the travel charger.
Using the Battery
The performance of a battery is subject to multiple factors: radio network configuration, signal strength,
ambient temperature, chosen functions or settings, phone fittings, and the voice, data or other application
mode you choose to use.
-14-
To guarantee the optimal performance of your battery, please stick to the following rules:
Use only the battery provided by the vendor. Otherwise, damages or even injuries could be caused
during the charging.
Power off the mobile phone before removing the battery.
The charging process lasts a longer time for a new battery or a battery not in use for long. If the battery
voltage is too low to enable the mobile phone to be powered on, charge the battery for a longer time. In
this case, the battery icon does not flicker until a long time after the battery enters the charge status.
During the charging, ensure the battery is placed in a room temperature environment or in an
environment close to room temperature.
Immediately stop using the battery if the battery produces odor, overheats, cracks, distorts or has other
damage, or if the electrolyte leaks.
The battery wears out with use. A longer charging time is required as the battery is put into use for a
long time. If the total conversation duration decreases but the charging time increases even though the
battery is properly charged, purchase a standard battery from the OEM or use a battery approved by
our company. Using any poor-quality fittings will cause harm to your mobile phone or even incur
danger!
Note: To guarantee your personal safety and protect the environment, do not litter the battery! Return the old
battery to the mobile phone manufacturer or place it in specified battery reclamation areas. Do not litter any
battery with other rubbish.
Warning: Short-circuits of the battery may cause explosion, fire, personal injury or other severe
consequences!
-15-
3.4 Powering On/Off the Mobile Phone
Hold the End key for a while to power on the mobile phone. A power-on animation appears on the display
screen.
Input the phone lock code and confirm if the mobile phone prompts you to input the phone lock code. The
original code is 1122.
Input the PIN and confirm if the mobile phone prompts you to input the PIN. The PIN is provided by the
network operator for new opening SIM card.
Enter the standby interface.
To power off the mobile phone, hold the End key for a while.
3.5 Linking to the Network
After the SIM card and the mobile phone are successfully unlocked, the mobile phone automatically searches
for an available network. After finding a network, the mobile phone enters the standby state. When the
mobile phone is registered in the network, the name of the network operator is displayed on the screen. Then
you can dial or receive a call.
3.6 Dialing Calls
In the dial interface, press number keys to input the area code and the telephone number. To end the call,
press the End key.
Dialing an international call
Hold the * key and input "+". Then input the country code, the area code and the telephone number.
Finally, press the Dial key.
-16-
Dialing a call to a number in the phonebook
Enter the phonebook and find the telephone number you want to call.
Press the Dial key. The mobile phone automatically dials the chosen telephone number.
Redialing the last number
In the standby interface, press the dial key to show the dialed calls.
Select a number you want to dial and then press the Dial key.
Answering incoming calls
Press the Dial key to answer an incoming call.
Press the End key to end the current conversation.
To reject an incoming call, press the End key.
Note: If the caller can be identified, the mobile phone will present the calling number. If the calling number
exists in the phonebook, the mobile phone will present both the name and the phone number of the caller. If
the caller cannot be identified, the mobile phone will present the calling number only. You can answer an
incoming call when using a function list or browsing the phonebook.
Using options during a conversation
Select Options during a conversation to pause, end the ongoing call, originate a new call, browse the
phonebook, view information, set the mute, set the DTMF, or perform other operations. For details, refer to
the menu guide.
3.7 Using the Headset
It would enter headset mode automatically when you insert headset to the slot. Make sure of inserting it
at the bottom of the slot, or you can’t use it normally.
-17-
4 Input method
This mobile phone provides multiple input methods, including English input and numeric input. You can
use these input methods when editing the phonebook, short messages, files and greeting text.
4.1 Icons for Input Methods
After you enter an edit window such as a window for editing the phonebook, short messages or the
memorandum, an icon is displayed to indicate the current input method:
Numeric input:“123”
English input in upper case:“ABC”
English input in lower case:“abc”
4.2 To Shift Entry Methods
Press options and touch input method icon on the screen keypad to select the input methods.
4.3 Numeric and English Input
You can input English by taping letters showed at the bottom of edit interface when the input icons turn
out to be ABC or abc, and you can input numbers when the input icons turns out to be 123.
-18-
5 Using the menu
5.1 TELCEL
STK service is the tool kit of SIM card. This phone supports the service function .The specific items are
depended by SIM card and network. Service menu will be auto added to the phone menu when supported by
network and SIM card.
5.2 Messaging
If the short message memory is full, a blinking message icon appears on the top of the screen. To normally
receive short messages, you need to delete some of the existing short messages.
If the destination user has received the short message you sent and the short message delivery report function
is activated, the phone will give off a message report alert tone.
Write message
Access this menu to create a text message or a multimedia message.
Inbox
Received messages are listed in this item.
Drafts
From the main menu select “Messages” to create text message. You can type a message, and you're also able
to insert a pre-defined message from “Templates”. While writing a message, select “Options” to access all
-19-
the messaging options. You can save your messages that you send often to “Drafts”.
Outbox
The messages which are sent failed are stored in the Outbox.
Sent messages
Sent messages are listed in this menu.
Broadcast Message
This network service enables you to receive a variety of text messages, such as broadcast messages about
weather forecast or road conditions. At present, few networks provide this service. Please consult the network
operator.
Receive mode: Set it to On to enable or Off to disable cell broadcast service.
Channel settings: Select receiving some types of cell broadcast messages or edit/delete some channel
numbers.
Languages: Select the language in which cell broadcast messages are displayed. The selected language,
however, may not be supported by the network operator.
Read message: View cell broadcast messages.
Message Settings
This function enables you to set the default features about the SMS, MMS and service message.
5.3 Dialer
Touch the Dialer icon on the screen or in the Main menu to open dialpad screen. In dialpad screen, you can
-20-
input phone number to originate a call
5.4 Video player
Use this function to play video files. By pressing the direction key can you control the playing process of
video player: play(OK key), fast forward (press and hold right direction key) and rewind (press and hold left
direction key), press up direction key to switch to full screen play.
5.5 Audio Player
You can use this function to play audio files. By pressing the direction key can you control the playing
process of audio player: play/pause(OK key), switch to last song/next song (press left or right direction
key), fast forward (press and hold right direction key) and rewind (press and hold left direction key).
5.6 Portal movil
Log on Portal movil through a web page.
5.7 Camera
Use this function to capture pictures. In the capture interface, you can press up or down direction to zoom in
or zoom out; OK key to capture photos.
5.8 Video recorder
This function enables you to record dynamic pictures. You can press up or down direction to zoom in or
zoom out; OK key to capture videos clip.
5.9 Phonebook
The mobile phone can store up to 300 telephone numbers. The number of telephone numbers that an SIM
-21-
card can store depends on the storage capacity of the SIM card. The telephone numbers stored in the mobile
phone and in the SIM cards form a phonebook. After selecting a telephone number in the phonebook, select
Options to perform the following operations:
View: View the content of the telephone number.
Sent text message: sent text message to this number.
Sent multimedia message: sent multimedia message to this number.
Call: call the current number of the SIM.
IP dial: Make the IP dial of the SIM.
Edit: Edit the telephone number and name.
Delete: Delete the telephone number from the phonebook.
Copy: Duplicate the telephone number from the mobile phone to the SIM card or from the SIM card to
the mobile phone.
Groups: You can assign contacts to the new caller groups. For each group, you can edit group name, set
caller alert, call ringtone, caller picture and caller LED.
Phonebook settings: Set some parameters of phonebook.
5.10 Settings
Pen calibration
Click anywhere on the screen with your style to start calibration. Then follow the prompt and operate, this
operation allows the screen to respond more quickly and correctly.
-22-
Phone Settings
Time and date: set the date format, the time format, and detail time of the location.
Note: If you remove the battery from the mobile phone or if the battery energy was exhausted a long time ago,
you may need to reset the date and time when re-inserting the battery or powering on the mobile phone after
recharging.
Schedule power on/off: Set the time when the mobile phone will be automatically powered on or off.
Alert: Before entering an area where the use of mobile phones is forbidden, make sure that the scheduled
power-on function is deactivated to avoid accidents.
Language: Select the display language for the mobile phone.
International keyboards: Set Multi language and English settings as needed.
Widget manager: Select Widget display and order as needed.
Shortcut manager: Access this menu to select shortcuts function to display on idle screen
Display: Select images as wall paper and screen saver and you can select to show time and data.
Motion: Set the default features about Motion.
Flight mode: when this function is engaged, it will suspend many of the device's signal transmitting
functions – thereby disabling the device's capacity to place or receive calls or text messages– while still
permitting use of other functions that do not require signal transmission (e.g., games, built-in camera,
MP3 player.)
Misc. settings: Set brightness and duration of LCD backlight.
Network Settings
Contact the network operator to obtain the following network services:
-23-
Network selection: Set Network selection mode to Automatic or Manual. Automatic is recommended.
When Network selection mode is set to Automatic, the mobile phone will prefer the network where the
SIM card is registered. When Network selection mode is set to Manual, you need to select the network
operator's network where the SIM card is registered.
Preferred networks: Select the preferred networks. By default, the network where the current SIM card
is registered will be displayed.
GPRS connection: You can select When needed or Always.
GPRS transfer pref.: You can select data prefer or call prefer.
Security Settings
This function provides you with related settings about safety use
SIM security
¾ PIN lock: To activate PIN lock, you need to input the correct PIN code. If you set PIN lock to On, you
need to input the PIN each time you power on the mobile phone. In the case you input a wrong PIN for
three consecutive times, you need to input the PIN Unblocking Key (PUK). The PUK is used to unlock
and change the locked PIN. To obtain the PUK, contact the network operator.
¾ Change PIN: To change PIN code of SIM card.
¾ Change PIN2: To change PIN2 code of PIN code.
Phone security
¾ Phone lock: The function enables you to lock/unlock the phone. Entering password to switch on or off
the phone. Password is required when the phone is locked. The password is 4 to 8 digits.
¾ Change password: to change phone password.
-24-
Certificate manager:You can manage your certificate in this interface
Call Setting
Call waiting: After you choose Activate, the mobile phone will contact the network. A moment later, the
network will make a response and send a message to acknowledge your operation. If the call waiting
function is activated, the network will alert you and the mobile phone screen will display the incoming
call number if others are calling you while you are already in a conversation.
Call diverts: this network function enables you to forward incoming calls to another number you have
previously specified.
Call barring: The call barring function enables you to bar calls as needed. When setting this function,
you need to use a network barring code, which can be obtained from the network operator. If the code is
wrong, an error message will be prompted on the screen. After selecting a call barring option, continue to
select Activate or Deactivate. The mobile phone will prompt you to input the call barring code and then
contact the network. A moment later, the network will make a response and send the operation results to
the mobile phone.
Line switching: Switch to Line 1 or Line 2. By default, Line 1 is used.
Note: If you choose Line 2, dialing may fail. This depends on the implementation of the network operator.
Auto redial: Set it to On or Off to enable or disable auto redial. If you set Auto redial to On, the mobile
phone will automatically redial the number a moment later if the called party does not reply. The number
of auto redial times can be set to a maximum of 10. In the auto redial period, you cannot dial other
numbers. To end the auto redial process, press the End key.
Note: This function requires support from the network operator to which the SIM card is registered.
-25-
IP dial: Activate/deactivate the IP dial function and add/edit IP numbers.
Call time reminder: To set single or circle tone in a call to make you know the time.
Answer mode: Set answer mode as per your need.
Restore Factory Settings
Use this function to restore factory settings. The preset password is 1122.
5.11 Call logs
Through this function, you can view a list of missed calls, dialed call and received calls.
5.12 Calendar
Once you enter this menu, there is a monthly-view calendar for you to keep track of important appointments,
etc. Days with events entered will be marked.
5.13 TV
You are able to access this menu to watch mobile TV programs and add the programs you like to channel list.
Before you watch TV programs, you’d better select the right area. Then you can search available channels
and select channel to play.
5.14 Bluetooth
With Bluetooth, you can make a wireless connection to other compatible devices, such as mobile phones,
computers, headsets and car kits. You can use the Bluetooth to send images, video clips, music, sound clips
and notes, and transfer files from your compatible pc.
-26-
5.15 FM Radio
You can use the application as a traditional FM radio with automatic tuning and saved channels. You need to
insert headset into its corresponding slot before using this function.
5.16 Profiles
The mobile phone provides multiple user profiles, so that you can customize some settings to adapt to the
specific events and environments.
Customize the user profiles according to your preference and then activate the user profiles. The user profiles
fall into five scenarios: General, Silent, Meeting, Outdoor and My style.
When you insert an earpiece to the mobile phone, the mobile phone automatically enters the Headset mode.
There is no option for activating the Headset mode on the screen. For details on operation, refer to General.
If you set Headset > Customize > Answer mode to Auto, incoming calls will be automatically answered.
Activate
Select Activate to activate the selected mode.
Customize
After choosing one of the above five modes, select Customize to edit the following items: Alert type, Ring
type, incoming call ringtone, ringtone volume, message ringtone, keypad tone, power on/off tone, etc.
Reset
Use this function to restore factory settings of user profile.
Note: The mobile phone automatically enters the Headset mode when you insert the earpiece
-27-
5.17 File manager
The phone provides a certain space for users to manage files and supports the T-Flash card. You can use the
file manager to conveniently manage various directories and files on the phone and the T-Flash card.
Open
Choose File manager to enter the root directory of the memory. The root directory will list the default
folders, new folders and user files. When the mobile phone is powered on for the first time or when you have
not changed the directory, the root directory contains the default folders only.
Format
You can use this function to format all the data in the memory. The system will re-create a default folder. The
formatted data cannot be recovered. Therefore, think twice before using the formatting function.
5.18 Alarm
Five alarm clocks are set but deactivated by default. You can activate one, multiple or all of them as needed.
For each alarm clock, the ringing date and the ringing time can be set.
5.19 Image viewer
You can view the pictures or images through this function.
5.20 Calculator
The calculator can add, subtract, multiply and divide. To use the calculator:
Press the up, down, left and right key to select +, -, ×, ÷, = respectively.
Press clear to delete the figure.
-28-
5.21 Sound recorder
The phone support WAV and AMR. The AMR takes the compression algorithm. So in the same memory
condition, it has longer recording time than WAV. You can tap the red icon on the screen to start/pause
recording.
5.22 Connectivity
Data accounts
Access this menu to set GPRS-related parameters.
5.23 World clock
Access this menu to view time of main cities in various time zones.
5.24 Lock
Select this function to lock keypad. When the keypad is locked, you can slide lock icon upward to unlock
keypad
5.25 Java
Java
Java is a folder where downloaded games and applications are stored.
Java settings
You can set the java audio (1-7 or off), Java backlight (on/off), Java vibration (on/off), Select network,
![](/img.php?id=1833305&img=bg8.png)
-29-
Heap size.
5.26 E-book reader
E-book reader enables you to read TXT file. Through the USB connecting line putting files to E-book folder
of phone or T-Flash card. After finishing downloading, you can find the folder and open the E-book to read
text directly.
5.27 Browser
This function enables you to view the internet. Your phone will ask you with existed way. You can start to
view only by starting corresponding way.
Homepage: indicates the default website of the internet.
Bookmarks: used to save most commonly-used websites.
Search or input URL: input the website to be searched and press finish button to access to the network
directly.
Recent Pages: browse the record of the recently browsed web pages.
Settings: set up WAP-related service.
Note: Consulting the local network operator for related fee and specific setup.
5.28 WLAN
Access the WLAN function on your phone. From there, activate WLAN to find wireless networks.
Click the wireless network that displays the strongest signal. If you try to access a secured connection, you
will be prompted to enter a password.
Once connected, open your mobile web browser. You can now surf the Internet through your cell phone.
-30-
5.29 ITelcel
First you should create account, you can use the iTelcel to read and send email.
*Inbox: New email you’ve received.
*Outbox: The email you’ve sent.
*Sent: The message you’ve sent to others.
*Drafts: The Emails you haven’t finished were stored there.
*Write Email: Write an email.
*Email accounts:You can activate the Email account reserved in the phone or add new account.
*Select storage:You can select the email storage Phone or Memory card.
*Set default account:You can set default account.
5.30 Facebook
Log on Facebook through a web page.
6 Appendix
Appendix 1:Troubleshooting
If you find exceptions when operating the mobile phone, restore the factory settings and then refer to the
following table to solve the problem. If the problem persists, contact the distributor or service provider.
Fault Cause Solution
-31-
The phone
slowly
responds to the
touch screen
pen
The touch
screen is not
appropriately
calibrated
Calibrate the touch screen
The SIM card
is damaged. Contact your network service provider
The SIM card
is not in
position.
Check the SIM card
SIM
card
error The metal
face of the
SIM card is
polluted.
Clean the SIM card with a clean cloth
-32-
Signals are
obstructed.
For instance,
radio waves
cannot be
effectively
transmitted
nearby a high
building or in
a basement.
Move to a place where signals can be effectively transmitted
Poor received
signal quality
Line
congestions
occur when
you use the
mobile phone
in high-traffic
hours
Avoid using the mobile phone in high-traffic hours
![](/img.php?id=1833305&img=bg9.png)
-33-
The mobile
phone cannot
be powered on
The battery
energy is
exhausted.
Charge the battery
Calls cannot be
dialed
Call barring is
activated Cancel call barring
The mobile
phone cannot
connect the
network
The SIM card
is invalid Contact your network service provider
-34-
The mobile
phone is not
in a service
area of the
GSM network
Move to the network operator's service area
The signal is
weak Move to a place where the signal quality is high
The charging
voltage does
not match the
voltage range
indicated on
the charger
Ensure the charging voltage matches the voltage range
indicated on the charger
An improper
charger is
used
Use the charger specially designed for the mobile phone
The battery
cannot be
charged
Poor contact Ensure the charger plug is in good contact with the mobile
phone
-35-
FCC Statement
1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may cause undesired operation.
2. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate
the equipment.
NOTE:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
-36-
SAR Information Statement
Your wireless phone is a radio transmitter and receiver. It is designed and manufactured not to exceed the emission limits for
exposure to radiofrequency (RF) energy set by the Federal Communications Commission of the U.S. Government. These limits are
part of comprehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines are based
on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific
studies. The standards include a substantial safety margin designed to assure the safety of all persons, regardless of age and health.
The exposure standard for wireless mobile phones employs a unit of measurement known as the Specific Absorption Rate, or SAR.
The SAR limit set by the FCC is 1.6 W/kg. * Tests for SAR are conducted with the phone transmitting at its highest certified power
level in all tested frequency bands. Although the SAR is determined at the highest certified power level, the actual SAR level of the
phone while operating can be well below the maximum value. This is because the phone is designed to operate at multiple power
levels so as to use only the power required to reach the network. In general, the closer you are to a wireless base station antenna,
the lower the power output. Before a phone model is available for sale to the public, it must be tested and certified to the FCC that
it does not exceed the limit established by the government adopted requirement for safe exposure. The tests are performed in
positions and locations (e.g., at the ear and worn on the body) as required by the FCC for each model. The highest SAR value for
this model phone when tested for use at the ear is 0.607W/Kg and when worn on the body, as described in this user guide, is
1.13W/Kg(Body-worn measurements differ among phone models, depending upon available accessories and FCC requirements).
While there may be differences between the SAR levels of various phones and at various positions, they all meet the government
requirement for safe exposure. The FCC has granted an Equipment Authorization for this model phone with all reported SAR
levels evaluated as in compliance with the FCC RFexposure guidelines. SAR information on this model phone is on file with the
FCC and can be found under the Display Grant section of http://www.fcc.gov/ oet/fccid after searching on
FCC ID: QRP-AZUMICHICWF Additional information on Specific Absorption Rates (SAR) can be found on the Cellular
Telecommunications Industry Asso-ciation (CTIA) web-site at http://www.wow-com.com. * In the United States and Canada, the
SAR limit for mobile phones used by the public is 1.6 watts/kg (W/kg) averaged over one gram of tissue. The standard
incorporates a sub-stantial margin of safety to give additional protection for the public and to account for any variations in
measurements.
-37-
Body-worn Operation
This device was tested for typical body-worn operations. To comply with RF exposure requirements, a minimum separation
distance of 15mm must be maintained between the user’s body and the handset, including the antenna. Third-party belt-clips,
holsters, and similar accessories used by this device should not contain any metallic components. Body-worn accessories that do
not meet these requirements may not comply with RF exposure requirements and should be avoided. Use only the supplied or an
approved antenna.
