AzureWave Technologies NU150 802.11b/g/n wireless USB Adapter User Manual AW NU150
AzureWave Technologies, Inc. 802.11b/g/n wireless USB Adapter AW NU150
User Manual
User Manual
Wireless 802.11 b/g/n dongle
Chapter 1: Product Overview
AzureWave Technologies, Inc. introduces the advanced IEEE 802.11 b/g/n 1x1
WLAN USB 2.0 dongle - AW-NU150. The dongle supports 2.4GHz , By using
AW-NU150, the customers can easily enable the development of USB 2.0-based
802.11n WLAN client.
In Compliance with the IEEE 802.11b/g/n standard, the AW-NU150 uses Direct
Sequence Spread Spectrum (DSSS), orthogonal frequency division multiplexing
(OFDM), DBPSK, DQPSK, CCK and QAM baseband modulation technologies. A
high level of integration and full implementation of the power management
functions specified in the IEEE 802.11 standard minimize the system power
requirements. By using AW-NU150, state-of-the-art security is provided by
industry standard system support for WPA, WPA2, and hardware accelerated
AES encryption/decryption coupled with TKIP and IEEE 802.1X support.
The AW-NU150 dongle adopts 802.11n-based chip, AR9271 supports 1*1 stream
up to 300Mbps.
Chapter 2: Installation
Note:
The dongle is using with televisions and embedded application only and will be with the
platform model names as following:
This dongle must be away from human body at least 20 cm.
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance
20cm between the radiator & your body. This transmitter must not be co-located or
operating in conjunction with any other antenna or transmitter.
