WirelessHD Tx/RX Module
User’s Manual
FCC Statement
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate this equipment.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with minimum distance 20cm between the radiator &
your body.
IMPORTANT NOTE:
This module is intended for OEM integrator. The OEM integrator is still responsible for the FCC
compliance requirement of the end product, which integrates this module.
20cm minimum distance has to be able to be maintained between the antenna and the users for the host
this module is integrated into. Under such configuration, the FCC radiation exposure limits set forth for
an population/uncontrolled environment can be satisfied.
Any changes or modifications not expressly approved by the manufacturer could void the user's
authority to operate this equipment.
USERS MANUAL OF THE END PRODUCT:
In the users manual of the end product, the end user has to be informed to keep at least 20cm
separation with the antenna while this end product is installed and operated. The end user has to be
informed that the FCC radio-frequency exposure guidelines for an uncontrolled environment can be
satisfied. The end user has to also be informed that any changes or modifications not expressly
approved by the manufacturer could void the user's authority to operate this equipment. If the size of the
end product is smaller than 8x10cm, then additional FCC part 15.19 statement is required to be available
in the users manual: This device complies with Part 15 of FCC rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference and (2) this device must accept any
interference received, including interference that may cause undesired operation.
LABEL OF THE END PRODUCT:
The final end product must be labeled in a visible area with the following " Contains TX FCC ID:
TLZ-WH029". If the size of the end product is larger than 8x10cm, then the following FCC part 15.19
statement has to also be available on the label: This device complies with Part 15 of FCC rules.
Operation is subject to the following two conditions: (1) this device may not cause harmful interference
and (2) this device must accept any interference received, including interference that may cause
undesired operation.
This Module may not be integrated into host devices that are addressed for operation inside
airplanes/satellites.
IC Statement
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B conforme á la norme NMB-003 du Canada.
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the
following two conditions: (1) this device may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts
de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire
de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre le fonctionnement.
This Module may not be integrated into host devices that are addressed for operation inside
airplanes/satellites.
IMPORTANT NOTE:
IC Radiation Exposure Statement:
This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm between
the radiator & your body.
IMPORTANT NOTE:
This module is intended for OEM integrator. The OEM integrator is still responsible for the IC compliance
requirement of the end product, which integrates this module.
20cm minimum distance has to be able to be maintained between the antenna and the users for the host
this module is integrated into. Under such configuration, the IC RSS-102 radiation exposure limits set
forth for an population/uncontrolled environment can be satisfied.
Any changes or modifications not expressly approved by the manufacturer could void the user's
authority to operate this equipment.
USERS MANUAL OF THE END PRODUCT:
In the users manual of the end product, the end user has to be informed to keep at least 20cm
separation with the antenna while this end product is installed and operated. The end user has to be
informed that the IC radio-frequency exposure guidelines for an uncontrolled environment can be
satisfied. The end user has to also be informed that any changes or modifications not expressly
approved by the manufacturer could void the user's authority to operate this equipment. IC statement is
required to be available in the users manual: This Class B digital apparatus complies with Canadian
ICES-003. Operation is subject to the following two conditions: (1) this device may not cause harmful
interference and (2) this device must accept any interference received, including interference that may
cause undesired operation.
LABEL OF THE END PRODUCT:
The final end product must be labeled in a visible area with the following " Contains TX IC : 6100A
-AWWH029 ".
Index
1 Introduction ...................................................................................................................... 1
1.1 Product Layout ........................................................................................................ 1
1.2 Features ..................................................................................................................... 1
1.3 Package Content ..................................................................................................... 2
1.4 Specification Table ................................................................................................. 2
2 Installation Steps ............................................................................................................ 3
3 Important Notice .............................................................................................................. 4
1
1 Introduction
AW-WH036T and AW-WH036R is a whole set of WirelessHD products. They can
stream uncompressed audio and video up Full HD (FHD) resolution. It works at 60GHz
band which is available on an unlicensed basis in many regulatory domains with a
typical range of 10 meter.
AW-WH036T and AW-WH036R replaces the HDMI cable and simplifies home theater
system installation. The source devices, such as BD player or Set Top Box, don’t need
to be located near to the TV.
1.1 Product Layout
1.2 Features
Standard: WirelessHD 1.0
Frequency: 60GHz
Data Rate: 4Gbps
Distance: 10m (In Room)
No Video Compression
Front View
Back View
2
Latency: <1ms
Video Resolution:
Up to 1920 X 1080 Progressive (1080P)
~ 8 Channels Audio (32 ~ 192KHz)
Array Antenna
HDMI 1.3 Compatible
DTCP (Digital Transmission Content Protection):AES-128 CTR mode
HDCP 2.0 Support
1.3 Package Content
The package include the below package content:
One set of AW-WH029T and AW-WH029R
Power Adapter
User’s Manual
1.4 Specification Table
Model Name AW-WH029T & R
Product Description HDMI (type-A ) wireless module
WirelessHD Standard WirelessHD V1.0
HDMI Standard HDMI 1.3a
Interface HDMI (type-A )
Major Chipset
Tx:
SB9210A HRTX RF Transceiver
SB9220A HRTX Network Processor
AT91SAM7S256 Microcontroller
Rx:
SB9221A HRRX Network Processor
SB9211A HRRX RF Transceiver
AT91SAM7S256 Microcontroller
Dimension 139.9 x 23.6 x 11.08 mm(exclude heat sinks)
Antenna 32 Antenna Array support Beam-forming
Operating Conditions
Voltage 5V
Currency 2A
Operating Temperature 0~40℃
℃℃
℃
3
Connector Micro USB Connector
Display
Resolution Support 480p/60Hz to 1080p/60Hz
Video Format RGB: 4:4:4
YCbCr: 4:4:4
Audio
Channel 2~8
Sample Rate 32-192kHz
RF Specifications
Frequency Range 57~66GHz
Modulation HRP: OFDM with QPSK , 16-QAM
LRP: OFDM with BPSK
Occupied Bandwidth HRP:1.76Ghz
LRP: 92Mhz
Output Power HRP: TBD
LRP: TBD
Receive Sensitivity HRP: TBD
LRP: TBD
Data Rates HRP: Up to 3.807 Gb/s
LRP: Omni-directional mode Up to 10.168 Mb/s
Operating Range
Indoor: 10 m
(The transmission speed may vary according to the
environment)
Security DTCP: AES-128 CTR mode
HDCP 2.0
Operation & Storage Environment
Temperature Operating temperature: 0 ~ 45℃
℃℃
℃
Storage temperature: -10 ~ 60℃
℃℃
℃
Humidity Operating Humidity: 20 ~ 80 %RH
Storage Humidity: 10 ~ 90 %RH
Air pressure Operating Altitude: ~7500ft (2286m) (760hpa)
Storage Altitude: ~20000ft (6096m) (468hpa)
2 Installation Steps
1. Remove the WirelessHD products and accessories from package
4
2. Connect the power adapter to the WirelessHD product and power outlet.
3. Connect HDMI connector on AW-WH036T to media source such as BD Player and
connect HDMI connector on AW-WH036R to flat panel display such as LCD TV by
HDMI cable.
4. Turn on power switch.
5. After 10 ~ 30 seconds, it will do auto-connection. If LCD TV shows display, that
means that the products begin working.
3 Important Notice
The Power adapter must be 5A / 2A.
The WirelessHD products are only for indoor use, the transmitting distance is
suggested to be less than 10 meters and no blocks between TX and RX.
