B and W Electronics Development 16HB2030 Bluetooth Keyboard User Manual MS 041 Bluetooth Speaker
Shenzhen B&W; Electronics Development Limited Bluetooth Keyboard MS 041 Bluetooth Speaker
user manual
HB020_Keyboard Volks (EN)
User manual
It is recommended to read this user manual carefully and keep it for future reference.
1. Specifications:
Bluetooth specifications: Bluetooth Version 3.0.
Rechargeable Lithium battery included.
Operating distance: < 10M.
Stand-By time: Approx. 90days.
Working time: Approx. 45 hours.
Micro USB charging cable included.
2. Operation:
Before using your Bluetooth keyboard, please fully charge the unit and follow below
instructions to pair your devices on initial use.
Once you achieve this prior successful connection, your paired devices will make connections
automatically every time you use them afterward.
The Bluetooth Keyboard must be paired with a Bluetooth enabled device. To that end please
follow the following steps:
Step 1: On the keyboard, slide the power button to on. The blue status light will illumination for
4 seconds and then turn off to save power. Note: Your keyboard is still on.
Step 2: Press the “CONNECT” button, the Bluetooth indicator light will be blinking blue.
Step 3: From the Bluetooth menu of your device, search for new devices and select “4935” to
pair with your device.
Step 4: After you select it, the device will display a code.
Step 5: Type the code on the keyboard and press enter, keyboard will now be paired to the
device.
NOTE:
After successful connection with a corresponding device, press Fn + Q (Android), W (Windows)
or E (iOS) keys together to shift between Android, Windows or iOS systems. Otherwise some
keyboard’s function keys will only be partial valid.
3. Compatible Devices:
Windows (XP or above).
iOS (5.0 or above).
iMac / Macbooks with Mac OS X 10.2.8 or above (note that some
exceptions may apply. This keyboard may not be compatible with the
Mac mini).
Smartphones or tablets with Android 3.0 and above (with Bluetooth HID
profile).
Windows Mobile 5.0 and above.
4. Safety Instructions / Precautions:
1. Store and use this product at an ambient temperature.
2. Avoid product from falling as could cause serious damage.
3. Do not dismantle, repair or modify this product by yourself.
4. In order to avoid any risk, do not dispose of this product inappropriately or toss it into
the fire as there is a built-in Lithium battery.
5. Do not place this item near sources of heat or expose to direct sunlight.
6. Do not insert any metal object into this device, as there is a risk of causing a short
circuit in the unit!
MADE IN PRC
This symbol both in the product and its user manual indicates that at the end of the
devices electrical life, it should be recycled separately from your household waste.
There are adequate means to dispose of this material for proper recycling. For more
information, contact your local authorities.
NOTE:This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the r
eceiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible for comp
liance could void the user's authority to operate the equipment. This device complie
s with Part 15 of the FCC Rules. Operation is subject to the following two conditio
ns:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference th
at may cause undesired operation.
