WWW.BEASENSORS.COM
MS31
MICROWAVE TOUCHLESS ACTUATOR WITH
ADJUSTABLE RANGE AND RELAY HOLD TIME
TECHNOLOGY
Silent Activation
Silent activation for hospitals and other noise-sensitive environments
Durable Design
IP54 rated enclosure for protection against outdoor weathering and
daily cleaning
Various Faceplates Available
Available in black, gray and white faceplate; options include jamb
style, single-gang, double-gang and 6 inch round
Adjustable Detection Zone
Detection zone from 4 to 24 inches (pulse or toggle)
DESCRIPTION
BEA’s MAGIC SWITCH® Family utilizes proven microwave
motion technology to ensure consistent, dependable
touchless activation and can be adjusted to comply with
the ANSI 156.10 knowing act standard.
The MS31 detects moving objects such as a hand, cart or
wheelchair and reduces touchpoints in high traffic areas
commonly found in shopping and transportation centers.
Applications requiring hygienic activation include hospitals,
pharmacies, clean rooms and foodservice facilities.
Watch the product video
VIDEO CERTIFICATIONS
4 - 24’’
EN
Adjustable LED Setting
Dipswitch position determines if LED illuminated when in detection or
when not in detection
BEA AMERICAS / RIDC Park West / 100 Enterprise Drive / Pittsburgh, PA
WWW.BEASENSORS.COM
T 1-800-523-2462 / F 1-888-523-2462 / E info-us@BEAsensors.com
79.0626.02 • 20200709
PRODUCT SERIES
Black, gray or white, kit w/
single and double gang
10MS31U - B/G/W
Black, gray or white, kit
with jamb
Black, gray or white, kit
with 6” round
10MS31J - B/G/W 10MS31R - B/G/W
900 MHz Receiver
10RD900
900 MHz retrofit
transmitter
10TD900TR
APPLICATIONS
Full Energy Swing Doors
Healthcare EnvironmentsIndustrial Doors
TECHNICAL SPECIFICATIONS
Technology
Radiated Frequency
Radiated Power Density
Microwave Doppler Radar
24.125 GHz
< 5 mW / cm²
Detection Mode Motion (bidirectional)
Detection Range 4 – 24” (adjustable)
Output
Max. Contact Voltage
Max. Contact Current
Max. Switching Power
Relay with switch-over contact (voltage-free)
60 VDC / 125 VAC
1 A (resistive)
30 W (DC) / 60 VA (AC)
Output Hold Time 0.5 – 30 s
Supply Frequency 50 – 60 Hz
Supply Voltage* 12 – 24 VAC ±10%, 12 – 24 VDC +30% / -10%
Power Consumption < 1.5 W
Weight 0.34 lbs
Material PC, PE
Temperature Range -4 – 131 ºF (-20 – 55 ºC)
IP Rating IP54
Certification EMC: 2004 / 108 / EC
FCC: G9B-210161
IC: 4680A-210161
MS31 MICROWAVE TOUCHLESS ACTUATOR WITH ADJUSTABLE RANGE AND RELAY HOLD TIME
DISCLAIMER Information is supplied upon the condition that the persons receiving it will make their own determination as to its suitability for their purposes prior to use. In no event will BEA
be responsible for damages of any nature whatsoever resulting from the use of or reliance upon information from this document or the products to which the information refers. BEA has the
right without liability to change descriptions and specifications at any time.
*To be operated from SELV-compatible power supplies only
Low Energy Swing Doors
10MS31BASE Choice of accessibility logo or plain in all size options
70.5869 Single gang - black, plain
70.5833 Single gang - black, text + hand logo
70.5834 Single gang - black, text + accessibility logo
70.5872 Jamb plate - black, plain
70.5825 Jamb plate - black, text + hand logo
70.5826 Jamb plate - black, text + accessibility logo
70.5887 Double gang - black, plain
70.5841 Double gabg - black, text + hand logo
70.5842 Double gabg - black, text + accessibility logo
70.5871 Round plate - black, plain
70.5849 Round plate - black, text + hand logo
70.5850 Round plate - black, text + accessibility logo
70.5835 Single gang - gray, plain
70.5836 Single gang - gray, text + hand logo
70.5837 Single gang - gray, text + accessibility logo
70.5827 Jamb plate - gray, plain
70.5828 Jamb plate - gray, text + hand logo
70.5829 Jamb plate - gray, text + accessibility logo
70.5843 Double gang - gray, plain
70.5844 Double gang - gray, text + hand logo
70.5845 Double gang - gray, text + accessibility logo
70.5851 Round plate - gray, plain
70.5852 Round plate - gray, text + hand logo
70.5853 Round plate - gray, text + accessibility log
70.5838 Single gang - white, plain
70.5839 Single gang - white, text + hand logo
70.5840 Single gang - white, text + accessibility logo
70.5830 Jamb plate - white, plain
70.5831 Jamb plate - white, text + hand logo
70.5832 Jamb plate - white, text + accessibility logo
70.5846 Double gang - white, plain
70.5846 Double gang - white, text + hand logo
70.5847 Double gang - white, text + accessibility logo
70.5854 Round plate - white, plain
70.5855 Round plate - white, text + hand logo
70.5856 Round plate - white, text + accessibility logo
