BI orporated HG200C BI HomeGuary 200 User Manual inside page
BI Incorporated BI HomeGuary 200 inside page
UserManual
BI HomeGuard 200™
Officer’s Reference Manual
BI Part Number 8-90-00089-0
© 2001 BI Incorporated
Revision C
8-90-00089-0, Revision C i
Preface
Preface
Notice
HomeGuard 200 Officer’s Reference Manual
Copyright © 2001 by BI Incorporated
All Rights Reserved
Printed in USA
BI prepared this manual for use by BI customers only. All
comments concerning the contents of this manual should be
directed to BI’s Marketing Department, 6400 Lookout Road,
Boulder, CO 80301, USA. No part of this work covered by copy-
right may be reproduced in any form either graphically, elec-
tronically, mechanically; including photocopying, recording,
taping, or storage in an information retrieval system without
prior written permission from BI.
Trademarks and Patents
The following are registered trademarks of BI Incorporated:
• BI
• BI logo
• BI HomeGuard 200 Receiver
• BI HomeGuard 200 Transmitter
• BI HomeGuard Drive-BI
• BI GuardWare Host System
• BI 9010 Transmitter
• BI K2 Host System
• BI HES 600 Host System
• BI Sobrietor
Document History
This document was created using Adobe FrameMaker 6 and
PaintShop Pro 7. The body text is the Utopia typeface. This is
Revision C, September 2001, BI Part No. 8-90-00089-0.
HomeGuard 200 Officer’s Reference Manual
ii 8-90-00089-0, Revision C
Technical Support
For help related to client enrollment and schedules, report-
ing, and host computer functions call your monitoring center.
BI Incorporated has two monitoring centers, East and West.
For technical assistance with BI Products, call BI Technical
Support at (800) 241-9924 or your BI Account Service Represen-
tative.
Purpose
This manual provides an officer with the information neces-
sary to implement and use HomeGuard 200 radio frequency
monitoring products.
Scope
The Officer’s Manual presents a tutorial for use of the
HomeGuard 200 radio frequency monitoring system and a
guide in acquainting clients with home arrest procedures. It
provides all information required to:
• learn to use HomeGuard 200 Receiver, Transmitter, and
Drive-BI
• teach clients to use the HomeGuard 200 Receiver and
Transmitter
• install the HomeGuard 200 Receiver and Transmitter on site
• set up monitoring requirements
• troubleshoot and use the HomeGuard 200 products
Note: Throughout this manual, the name HomeGuard 200
refers to the HomeGuard 200 radio frequency monitoring
system.
GuardCenter West
BI Incorporated
6400 Lookout Road
Boulder, CO 80301 USA
(303) 218-1225
(800) 241-6768
FAX (303) 218-1250
GuardCenter East
BI Incorporated
One Citizen’s Plaza, Suite 501
Anderson, Indiana 46016
(765) 641-2496
(800) 825-1044
FAX (765) 649-3148
Preface
8-90-00089-0, Revision C iii
Preface
Audience
This manual is written for the attending officer who will
train the client, set up the equipment, and monitor the client.
United States FCC, Part 68
Compliance statement - This equipment complies with Part
68 of the FCC rules. On the bottom of the Receiver is a label that
contains, among other information, the FCC registration num-
ber and ringer equivalence number (REN) for this equipment. If
requested, this information must be provided to the telephone
company.
Jack type needed - The Receiver connects to the telephone
network with a USOC RJ11C jack. An FCC compliant telephone
cord and modular plug is provided with this equipment. This
equipment is designed to be connected to the telephone net-
work or premises wiring using a compatible modular jack which
is Part 68 compliant.
Explanation of the Ringer Equivalence Number (REN) - The
REN is used to determine the quantity of devices which may be
connected to the telephone line. Excessive RENs on the tele-
phone line may result in the devices not ringing in response to
an incoming call. In most, but not all areas, the sum of the RENS
should not exceed five (5.0). To be certain of the number of
devices that may be connected to the line, as determined by the
total RENs, contact the telephone company to determine the
maximum REN for the calling area.
Temporary discontinuance of service - If the Receiver
causes harm to the telephone network, the telephone company
will notify you in advance that temporary discontinuance of ser-
vice may be required. But if advance notice isn’t practical, the
telephone company will notify the customer as soon as possible.
Also, you will be advised of your right to file a complaint with the
FCC if you believe it is necessary.
Telephone company changes - The telephone company
may make changes in its facilities, equipment, operations, or
procedures that could affect the operation of the equipment. If
this happens, the telephone company may provide advance
notice in order for you to make the necessary modifications in
order to maintain uninterrupted service.
HomeGuard 200 Officer’s Reference Manual
iv 8-90-00089-0, Revision C
Disconnection in case of trouble and location of repair cen-
ter - If trouble is experienced with the Receiver, please contact
BI Incorporated. If the equipment is causing harm to the tele-
phone network, the telephone company may request that you
disconnect the equipment from the network until the problem
is resolved.
Repairs customers can make - There are no customer-ser-
viceable parts inside the BI HomeGuard Receiver. (Power and
phone cords are replaceable on the BI HomeGuard Receiver.)
Prohibitions - Connection to party lines or to telephone
company coin service is prohibited.
Industry Canada
NOTICE: The Industry Canada label identifies certified
equipment. This certification means that the equipment meets
telecommunications network protective, operational and safety
requirements as prescribed in the Terminal Equipment Techni-
cal Requirements document(s). The Department does not guar-
antee the equipment will operate to the user’s satisfaction.
Before installing this equipment, users should ensure that it
is permissible to be connected to the facilities of the local tele-
communications company. The equipment must also be
installed using an acceptable method of connection. The cus-
tomer should be aware that compliance with the above condi-
tions may not prevent degradation of service in some situations.
Repairs to certified equipment should be coordinated by a
representative designated by the supplier. Any repairs or alter-
ations made by the user to this equipment, or equipment mal-
functions, may give the telecommunications company cause to
request the user to disconnect the equipment.
Users should ensure for their own protection that the elec-
trical ground connections of the power utility, telephone lines
and internal metallic water pipe system, if present, are con-
nected together. This precaution may be particularly important
in rural areas.
Caution: Users should not attempt to make such connec-
tions themselves, but should contact the appropriate electric
inspection authority, or electrician, as appropriate.
NOTICE: The Ringer Equivalence Number (REN) assigned
to each terminal device denotes the percentage of the total load
Preface
8-90-00089-0, Revision C v
Preface
to be connected to a telephone loop which is used by the device
to prevent overloading. The termination on a loop may consist
of any combination of devices subject only to the requirement
that the total of the Ringer Equivalence Number of all the
devices does not exceed 5. The REN for the HomeGuard 200 is
0.7B.
Operation is subject to the following two conditions: (1) this
device may not cause interference, and (2) this device must
accept any interference that may cause undesired operation of
the device.
United States FCC, Part 15
This device complies with Part 15 of the FCC Rules. Opera-
tion is subject to the following two conditions: (1) This device
may not cause harmful interference, and (2) this device must
accept any interference received, including interference that
may cause undesired operation.
Any changes or modifications made by the user to this
equipment that are not expressly approved by BI Incorporated
could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to com-
ply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide rea-
sonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accor-
dance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or televi-
sion reception, which can be determined by turning the equip-
ment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and
receiver
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected
• Consult the dealer or an experienced radio/TV technician
for help
