User Manual
User Guide
1
Table of Contents
1 GET STARTED ............................................................ 3
1.1
SIM
CARD INFORMATION
............................................... 3
1.2
I
NSTALL AND CHARGE THE PHONE
.................................. 3
1.3
F
OR
Y
OUR
S
AFETY
........................................................ 3
2 FUNCTION MENU .......................................................... 5
2.1
C
ALL HISTORY
............................................................... 5
2.2
M
ESSAGES
.................................................................... 5
2.3
F
ILE MANAGER
.............................................................. 7
2.4
P
HONEBOOK
.................................................................. 7
2.5
U
SER
P
ROFILES
............................................................. 7
2.6
WLAN ......................................................................... 8
2.7
C
ONNECTIVITY
.............................................................. 8
2.8
S
ETTINGS
...................................................................... 9
2.9
E
MAIL
......................................................................... 11
2.10
FM
R
ADIO
................................................................ 11
2.11
P
HOTO EDITOR
........................................................... 11
2.12
C
AMERA
................................................................... 12
2.13
N
OTES
....................................................................... 12
2.14
M
EDIA
P
LAYER
......................................................... 12
2.15
C
ALENDAR
................................................................ 12
2.16
S
OUND RECORDER
..................................................... 12
2.17
I
MAGE VIEWER
.......................................................... 13
2.18
E
BOOK READER
......................................................... 13
2.19
G
AMES
...................................................................... 13
2.20
MSN......................................................................... 13
2.21
O
PERA
...................................................................... 13
2.22
F
ACEBOOK
................................................................ 13
2
2.23
BLU
C
HAT
................................................................ 13
2.24
T
WITTER
................................................................... 14
2.25
F
UN
&G
AMES
............................................................ 14
2.26
Y
AHOO
...................................................................... 14
2.27
W
ORLD
C
LOCK
......................................................... 14
2.28
S
TOPWATCH
............................................................... 14
2.29
U
NIT CONVERTER
...................................................... 14
2.30
A
LARM
...................................................................... 15
2.31
C
ALCULATOR
............................................................ 15
2.32
B
LUETOOTH
.............................................................. 15
2.33
C
URRENCY CONVERTER
............................................. 15
2.34
T
ASKS
....................................................................... 15
2.35
STK* ........................................................................ 15
2.36
TV ............................................................................ 16
3
1 Get started
1.1 SIM card information
When you subscribe to a cellular network, you receive a
plug-in SIM (Subscriber Identity Module) card loaded with
your subscription details, such as your PIN, and available
optional services.
1.2 Install and charge the phone
Remove the battery cover and the battery
If the phone is already on, first turn it off by
pressing and holding on/off key.
Insert the SIM card.
Make sure that the gold-colored contacts on the
card are face down
Install the battery.
Replace the battery cover.
Plug the charger into the phone
Plug the charger into a standard AC wall outlet.
When the phone is completely charged (the battery
icon becomes still), unplug the charger from the
power outlet.
Remove the charger from the phone.
Switch the Phone On/Off.
Enter Your Pin (Access Codes is 1234) if it is
necessary.
Dial the Phone Number Required.
1.3 For Your Safety
Please read these safety guidelines before using your
mobile phone to assure the safe and proper use of the phone.
Switch off the phone when refueling.
4
Switch off in an aircraft.
Keep your phone dry.
Keep your phone away from small children and
pets.
Do not store the phone in hot areas.
Do not store the phone in cold areas.
Do not drop, knock or shake the phone.
Do not put the phone in or on heating devices, such
as a microwave oven, stove or radiator. The phone
may explode when overheated.
If your phone has a flash or light, do not use it too
close to the eyes.
Use only the supplied or an approved replacement
antenna.
Do not attempt to open the phone’s casing.
If the phone or any of its accessories are not
working properly, take them to your nearest
qualified service center.
Using the earpieces or stereo headset for extended
time can cause a serious damage to your hearing.
Do not use the phone while charging the phone.
Extreme heat or cold ：Avoid temperatures below
-10°C/14°F or above 40°C/104°F.
5
2 Function Menu
2.1 Call history
◆ SIM1/SIM2 call history
Missed calls: Displays the most recent received calls
that you did not answer.
Dialed calls: Displays the most recent calls you have
dialed.
Received calls: Displays the most recent calls you have
received.
Delete call logs: Delete all call logs.
Call timers: Can look over call time record up to now.
Call cost: Can look over call cost record up to now.
Text msg. counters: To view the current SMS counter,
include the two options: “Sent” and “Received”. Press
“Reset” to clear.
2.2 Messages
2.2.1 Write message
Use this menu to create and send a message (SMS or
MMS). The SMS/MMS function is dependent on the network
service and your network may or may not support the service.
Please confirm in writing short message has been properly set
before the information center number.
2.2.2 Inbox
Inbox/Conversations deposit received all text messaging
and MMS.
2.2.3 Drafts
After editing of information, information will select
6
save to draft box location.
2.2.4 Outbox
In sending messages, select save and send when after
the failure, and transmit information will be stored in boxes.
2.2.5 Sent messages
In sending messages, select save and send and the news
will save to transmit information.
2.2.6 Achive
You can move the message from Inbox to Archive to
archive.
2.2.7 Delete messages
You can choose delete inbox, draft, out boxes, already
issued information, folders and all the information for the
corresponding delete action.
2.2.8 Broadcast message
This network service allows you to receive the
broadcast messages on various topics such as weather, traffic,
local district code, local hospitals, taxis or pharmacy in your
area. For more information about broadcast message topics,
please contact your service provider.
2.2.9 Templates
Information list that phrase for the selected edit, delete,
template create new short message from template operation.
2.2.10 Message settings
Text message setting
Within the message settings sub-menu, you can define
7
default values on common parameters for mobile-originated
messages.
Multimedia Message settings
Within the message settings sub-menu, you can define
default values on common parameters for mobile-originated
messages.
Service Message
Enable push: According to Enable choose accept all,
accept authenticated or trusted, Disable.
Enable service loading: According to Enable service
loading choose Prompt, Auto launch, Disable.
2.3 File manager
Use this menu to view the stored files in the phone or
the micro SD card. In the main menu interface, click “File
Manager” to enter this submenu, menu display Phone and
“Memory Card：
：：
：\”( if the Memory card have insert into the
mobile-phone).
2.4 Phonebook
You can fast locate the number of the person you want
to contact. Please enter the initial letter of the person’s name,
and related records about it will display in the middle of the
screen. You can locate your records, and then you can view,
send SMS/MMS, call, edit, delete, copy, move and so on.
2.5 User Profiles
Your mobile phone provides many different user
profiles for you to set your mobile phone’s ring tone
according to case and environments.
Select the needful profile, and then press the “Option”:
8
Activate: to activate selecting profile.
Customize: to set the selected mode.
2.6 WLAN
How do I activate WLAN and connect to wireless
network equipment
1, Into the main menu, select wireless LAN, mobile
phones can tip "Turn on WLAN first?" , is confirmed the
function is open; Confirm or enter this menu list, but through
the options menu "enable wireless local area network" to open
this function.
2, Each entry "wireless LAN" function, cell phone will
automatically search nearby local area network, and displayed
on the list; Or manually add local area network.
3, Choose what you need connected network equipment,
in the options menu select 'connection' (part local area
network will set password, corresponding input password
continue), when tip 'has been launched' says WLAN has
activated and connect to a wireless network equipment.
2.7 Connectivity
2.7.1 Conn. management
Show the current connection.
2.7.2
Data account
This menu allows you to change the settings for the
GSM and GPRS network services. For further details, contact
your service provider.
9
2.8 Settings
2.8.1 Dual SIM switch
You can select two kinds of mode to switch SIM:
Manually and Automatically.
2.8.2 Dual SIM settings
You can select three kinds of mode: Dual SIM open,
only SIM1 open, Only SIM2 open and Flight mode.
2.8.3 Phone Settings
You can configure the following options as desired:
Time and Date, Schedule power on/off, Language, input
method, Encoding, Wallpaper, Screen saver, Power on/off
display, Auto update of date and time, dedicated key, UART
settings, LCD backlight.
2.8.4 Network Setup
2.8.4.1 Network Selection
Set Network selection mode to Automatic or Manual.
2.8.5 Security Settings
This function provides you with related settings about
safety use.
2.8.5.1 SIM Lock
The PIN number can prevent the illegal use of your SIM
card.
2.8.5.2 Phone security
The Phone Lock can prevent the unauthorized use of
your mobile phone.
10
Attention: The default phone lock code is 1122.
2.8.5.3 Auto keypad lock
You can set auto keypad on or off.
2.8.5.4 Change password
User is allowed to change Phone Lock Password.
2.8.6 Call Settings
◆ SIM1/SIM2
Call Setting
Call waiting: To enable call waiting function.
Call divert: To set the call condition by which calls are
diverted to another number.
Call Barring: Allows you to restrict incoming calls and
outgoing calls from your phone.
Line switch (Line1/ Line2): This is a network service to
select phone line 1 or 2, which is the subscriber
number for making calls within ALS Setting
submenu.
◆ Advance settings
Blacklist: To filter and block incoming calls.
Auto redial: This option allow you set redial
automatically when the call receiver is busy.
IP dial: you can dial IP call.
Background sound: Set background sound when you
are calling.
Call time display: Set the phone to display the call time.
Call time reminder: You can set the call time reminder.
Auto quick end: Set to end the call automatically.
11
Reject by SMS: When you have incoming call you can
reject call and meanwhile send SMS by activate this
function.
Answer mode: you can select answer mode when
receive incoming call.
2.8.7 Restore Factory Settings
You can restore the relevant settings to the
manufacturer’s settings. The initial password is “1122”.
2.8.8 License manager
It will display list of license of this phone.
2.9 Email
The E-Mail application allows you to send and receive
e-mails. The application supports text and attachments. The
e-mail application could be either normal POP3 e-mail client
or IMAP4 based e-mail service.
2.10 FM Radio
In the FM Radio menu interface, press “Option”
Channel list: to save and edit the auto-search result;
Manual input: manually enter the figure of the channel
you want to start exact search;
Auto search: auto search channels.
Settings: to set Background Play and Loud Speaker.
2.11 Photo editor
You can edit the photo which is saved in your phone or
Memory card, and take the picture from camera. When you
edit it you can add effect, frame, icon, text, adjust and so on.
12
2.12 Camera
Your cell phone camera to provide the functions of the
camera into the menu option, during the view-finding mode,
adjust the lens to allow what is being photographed to appear
in the viewfinder.
During the view-finding mode, you can select the options
to activate the camera you desired.
Touch the icon to adjust the focus distance of the
camera and press up-key and down-key to switch between
camera and video recorder.
2.13 Notes
Enter
Notes
submenu, can add some contents should
be recorded, and can add the note content after being an editor,
delete operation.
2.14 Media Player
In the Audio Player menu interface, In the Audio
Player menu interface, press the “All media files” to display
the play list of music and video, press the “Option”, can Play
the current music or video, look over Detail message of files,
update, and add the songs/videos and so on.
2.15 Calendar
Enter Calendar submenu, screen will display the
current month, click date to change date. You can enter “Add
Event” menu to add and edit routing.
2.16 Sound recorder
You can record sound in AMR, WAV format and use it
as ring tone, MMS attachment and so on.
13
2.17 Image viewer
You can convenient look over the photos list.
2.18 Ebook reader
Enter Ebook read submenu, can read suffix expansion.
TXT electronic document called to document name can make
changes and display decoding way.
2.19 Games
Your mobile phone provides one game for you.
2.20 MSN
Your phone allows you use MSN to chat with friends for
free on-line, real-time with your friends and family using
instant messaging.
2.21 Opera
Your mobile phone supports wireless application
protocol (WAP) service. You can access many different WAP
services such as news, weather reports, flight information, and
others. These services are especially designed for mobile
phones and maintained by WAP service providers.
2.22 Facebook
Your phone allows you use Facebook to chat with
friends for free on-line, real-time with your friends and family
using instant messaging.
2.23 BLU Chat
Your phone allows you to chat on-line, real-time with
your friends and family using BLU chat
14
2.24 Twitter
Your phone allows you use Twitter to chat with friends
for free on-line, real-time with your friends and family using
instant messaging.
2.25 Fun&Games
Your mobile phone features a Java run-time
environment, which allows you to run Java applications, such
as games downloaded on the Network. You can setup audio,
network profile, and free data space.
2.26 Yahoo
Your phone allows you use Yahoo to chat with friends
for free on-line, real-time with your friends and family using
instant messaging.
2.27 World Clock
Enter World Clock submenu, display world time zone
map, move coordinate location by the left/right icon, the
interface will show the city time located by the coordinate.
2.28 Stopwatch
Start Split Timing, and then select “View record” to
see timing records.
2.29 Unit converter
Enter Unit converter submenu, first choose conversion
unit, implement the length and the length, width and breadth
of the conversion between.
15
2.30 Alarm
The mobile-phone can set five alarms at most, and hold
out the alarm when the phone is power off.
2.31 Calculator
Your mobile phone provides a calculator with 4 basic
functions to facilitate simple calculations.
2.32 Bluetooth
You may establish wireless connection with other
compatible devices with the Bluetooth technology; you may
send music files and etc. with the Bluetooth technology; and
you may establish wireless connection with compatible PC, in
addition to establish communication via the connected
compatible Bluetooth earphone.
2.33 Currency converter
Enter Currency converter submenu, first input Rate,
and press the “OK” to enter. Press the “OK”, conversion
result will display in the other frame.
2.34 Tasks
This feature lists out all your tasks you have added. You
can also view, add, edit, delete, delete overdue, delete all,
jump to date, send vCalendar and save as file as desired.
2.35 STK*
Press the left soft key to enter the “STK” main menu.
Here you can use the value-added services provided by your
network operator.
16
2.36 TV
Analog TV allows users anywhere receive analog TV
signals, and adjust the volume in the player interface,
full-screen switching, regulating such as operating channel.
Federal Communication Commission
Interference Statement
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2)
this device must accept any interference received,
including interference that may cause undesired
operation.
This device has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses,
and can radiate radio frequency energy, and, if not
installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not
occur in a particular installation If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to
17
correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and
receiver.
Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV
technician for help.
FCC Caution:
Any Changes or modifications not expressly approved by the
party responsible for compliance could void the user‘s
authority to operate the equipment.
The antenna(s) used for this transmitter must not be
co-located or operating in conjunction with any other antenna
or transmitter.
Note: The country code selection is for non-US model only
and is not available to all US model. Per FCC regulation, all
WiFi product marketed in US must fixed to US operation
channels only.
18
4
44
4RF Exposure Information (SAR)
This device meets the government’s requirements for
exposure to radio waves.
This device is designed and manufactured not to exceed the
emission limits for exposure to radio frequency (RF) energy
set by the Federal Communications Commission of the U.S.
Government.
The exposure standard for wireless device employs a unit of
measurement known as the Specific Absorption Rate, or SAR.
The SAR limit set by the FCC is 1.6W/kg.
*
Tests for SAR are
conducted using standard operating positions accepted by the
FCC with the device transmitting at its highest certified power
level in all tested frequency bands. Although the SAR is
determined at the highest certified power level, the actual
SAR level of the device while operating can be well below
the maximum value. This is because the device is designed to
operate at multiple power levels so as to use only the poser
required to reach the network. In general, the closer you are
to a wireless base station antenna, the lower the power output.
The highest SAR value for the model device as reported to the
FCC when tested for use at the ear is 1.09 W/kg and when
worn on the body, as described in this user guide, is 1.08
W/kg (Body-worn measurements differ among device models,
depending upon available accessories and FCC requirements.)
While there may be differences between the SAR levels of
various devices and at various positions, they all meet the
government requirement.
19
The FCC has granted an Equipment Authorization for this
model device with all reported SAR levels evaluated as in
compliance with the FCC RF exposure guidelines. SAR
information on this model device is on file with the FCC and
can be found under the Display Grant section of
www.fcc.gov/oet/ea/fccid after searching on FCC ID:
YHLBLUNEOXT.
For body worn operation, this device has been tested and
meets the FCC RF exposure guidelines for use with an
accessory that contains no metal and be positioned a
minimum of 1.5 cm from the body. Use of other accessories
may not ensure compliance with FCC RF exposure guidelines.
If you do not use a body-worn accessory and are not holding
the device at the ear, position the handset a minimum of 1.5
cm from your body when the device is switched on.
