USER GUIDE
CONTENTS
1. BOOMBOT ANATOMY
2. GETTING STARTED
4. AUDIO CONTROLS
3. BLUETOOTH PAIRING
5. SPEAKERPHONE
6. SPECIFICATIONS
7. TROUBLESHOOTING
8. WARRANTY
BOOMBOT ANATOMY
VOLUME +VOLUME -
PL AY/PAUSE
COMMAND
2 x 36mm DRIVERS
MICROPHONE
HIP CLIP
REMOVABLE
GRILL
INDICATOR
LED
POWER ON/OFF
WATER
RESISTANT
DOOR
GETTING STARTED
FULLY CHARGE YOUR BOOMBOT REX
BEFORE USE WITH INCLUDED MICRO
USB CABLE
PULSING ORANGE - CHARGING
SOLID ORANGE - FULLY CHARGED
BLINKING RED - LOW BATTERY
FULL CHARGE IS REACHED IN
1.5 - 3 HOURS
BATTERY LIFE TYPICALLY RANGES
FROM 2.5 - 16 HOURS, 8 HOURS
OF PLAYBACK AT 70% VOLUME
YOUR BOOMBOT REX IS NOT
WATER RESISTANT WHILE CHARGING,
IT IS ONLY WATER RESISTANT
WITH THE REAR DOOR CLOSED
INDICATOR LED
CHARGING PORT
BLUETOOTH PAIRING
YOUR BOOMBOT REX CONNECTS EASILY
WITH YOUR BLUETOOTH DEVICE
1. POWER ON BOOMBOT REX INDICATED
BY A BLINKING BLUE LED
2. SELECT BOOMBOT REX ON YOUR
BLUETOOTH DEVICE’S DISCOVERABLE
DEVICE LIST
3. BOOMBOT REX WILL CHIME WITH A
PAIRING ALERT AND A SOLID BLUE LED
YOUR BOOMBOT REX WILL AUTOMATICALLY
BE PAIRED TO THE MOST RECENTLY
CONNECTED DEVICE
TO DISCONNECT YOUR BOOMBOT REX,
HOLD BOTH VOLUME BUTTONS (+ AND -)
SIMULTANEOUSLY FOR 2 SECONDS
TO RESET BLUETOOTH CONNECTION,
HOLD BOTH VOLUME BUTTONS (+ AND -)
SIMULTANEOUSLY FOR 2 SECONDS
HOLD (2 SECONDS)
HOLD
HOLD
AUDIO CONTROLS
YOUR BOOMBOT REX IS BUILT FOR
OPTIMAL AUDIO QUALITY WITH
THE SPEAKER CLIPPED ON OR SEATED
WITH BUTTONS FACING UPWARD
PLAY - PRESS COMMAND
PAUSE - PRESS COMMAND
NEXT TRACK - PRESS COMMAND X 2
VOLUME DOWN - PRESS VOLUME DOWN
VOLUME UP - PRESS VOLUME UP
VOLUME CONTROLS RAMP IN SPEED
WHEN HELD DOWN
-OR-HOLD HOLD
SPEAKERPHONE
THE BUILT IN MICROPHONE TURNS
YOUR BOOMBOT PRO INTO A
WIRELESS SPEAKERPHONE
FOR BEST RESULTS, SPEAK WITHIN
3 FEET OF THE FRONT OF THE SPEAKER
ANSWER CALL - PRESS COMMAND
END CALL - HOLD COMMAND
IGNORE CALL - PRESS A VOLUME BUTTON
SPEAKERPHONE CONTROLS ARE ENABLED
WHEN RECEIVING A CALL
-OR-
HOLD
SPECIFICATIONS
8 HOURS OF CONTINUOUS PLAYPLAY TIME
PROPRIETARY DUAL 36MM 3W ACOUSTIC
DRIVER + PASSIVE BASS WOOFER
AUDIO
UP TO 14 DAYSSTANDBY TIME
180g/ 6.3ozWEIGHT
90mm L x 51mm W x 85mm HDIMENSIONS
INPUT: BLUETOOTH WIRELESS
OUTPUT: 3.5mm JACK FOR DAISY CHAIN
+BLUETOOTH RECEIVER FUNCTIONALITY
STEREO INFORMATION
BLUETOOTH-ENABLED DEVICES INCLUDING
iPHONE, iPAD, iPOD TOUCH, ANDROID
SMARTPHONES AND TABLETS, AND MOST
MAC OR PC COMPUTERS
DEVICE COMPATIBILITY
IPX4 WATER RESISTANT
INGRESS PROTECTION
ACCEPT CALLS WHILE IN PLAY MODEMULTI-POINT TECHNOLOGY
PROFILES:
ADVANCED AUDIO DISTRIBUTION
PROFILE(A2DP) 1.2,
HANDS-FREE PROFILE(HFP) 1.5,
HEADSET PROFILE(HSP) 1.1,
100-FOOT RANGE
BLUETOOTH 2.1
SPEAKERPHONE TO ANSWER, END,
OR DENY PHONE CALLS
MIC CONTROL FUNCTIONS
RECHARGEABLE, NON-REPLACEABLE
LITHIUM POLYMER
BATTERY TYPE/CAPACITY
DISPLAYED ON HANDSET, AUTOMATICALLY
SHUTS DOWN AFTER 5 MINUTES OF
INACTIVITY OR UNPAIRED
BATTERY STATUS
MICRO USB (CABLE INCLUDED)CHARGE CONNECTOR PORT
LESS THAN 100 MINUTES FOR FULL CHARGECHARGE TIME (MAXIMUM)
1-YEAR LIMITED WARRANTY WARRANTY AND SERVICE
TROUBLESHOOTING
BE SURE USER VOICE INPUT IS WITHIN
3 FEET OF THE FRONT OF REX SPEAKER
MICROPHONE INPUT UNCLEAR
CHECK MUSIC SOURCE AND INTERNET/DATAMUSIC NOT PLAYING
CONFIRM MICRO USB CABLE IS SEATED
PROPERLY IN PORT AND DEVICE HAS
APPROPRIATE POWER INPUT
DEVICE NOT CHARGING
FOR ADDITIONAL SUPPORT HEAD OVER TO
BOOMBOTIX.COM/SUPPORT
TURN UNIT ON AND OFF AND RESET
BLUETOOTH BY HOLDING + AND -
DELETE ADDITIONAL BLUETOOTH
DEVICES FROM BLUETOOTH SETTINGS
DEVICE NOT PAIRING
WARRANTY
Boombotix warrants to the original retail purchaser
of this Boombotix portable speaker that should this
product or any part thereof during normal consumer
usage and conditions, be proven defective in material
or workmanship that results in product failure within
the first twelve (12) month period from the date of
purchase, such defect(s) will be repaired or replaced
(with new or rebuilt parts) at the Company’s option,
without charge for parts or labor directly related
to the defect(s). The antenna, keypad, display,
rechargeable battery and battery charger, if included,
are similarly warranted for twelve (12) months from
date of purchase. This Warranty is not transferable or
assignable. This Warranty does not apply to:
(a) Product subjected to abnormal use or conditions,
accident, mishandling, neglect, unauthorized
alteration, misuse, improper installation or repair
or improper storage;
(b) Product whose mechanical serial number or
electronic serial number has been removed,
altered or defaced;
(c) Damage from excessive exposure to moisture,
humidity, excessive temperatures or extreme
environmental conditions;
(d) Damage resulting from connection to, or use of any
accessory or other product not approved or
authorized by the Company;
(e) Defects in appearance, cosmetic, decorative
or structural items such as framing and
nonoperative parts;
(f) Product damaged from external causes such
as fire, flooding, dirt, sand, weather conditions,
blown fuse, theft or improper usage of any
electrical source.
(g) Product taken apart without written permission
by Boombotix. This includes and is not limited
to removing the metal clip or removing the
screws holding the casing together.
Boombotix reserves the right to inspect any
Product subject to a warranty claim to determine,
at its sole discretion, whether the claimed defect
is a Manufacturing Defect or otherwise. Note that
Boombotix regularly changes the models, colorways,
and styles of its Products and cannot guarantee the
availability of an exact replacement for any Product.
BOOMBOTIX DOES NOT ASSUME ANY LIABILITY FOR
ANY INCIDENTAL, CONSEQUENTIAL OR INDIRECT
DAMAGES UNDER THIS LIMITED WARRANTY.
FCC Statement
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful
interference in a residential installation. This equipment
generates uses and can radiate radio frequency energy
and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to
radio or television reception, which can be determined
by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or
more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and
receiver.
- Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV
technician for help.
This device complies with FCC radiation exposure limits
set forth for an uncontrolled environment.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired
operation.
Caution!
Any changes or modifications not expressly approved
by the party responsible for compliance could void the
user’s authority to operate the equipment.
