BRAVEN LC BBAL BLUETOOTH SPEAKER User Manual Manual
BRAVEN LC BLUETOOTH SPEAKER Manual
Manual
QUICK START GUIDE
BALANCE
23
Full manual and troubleshooting: braven.com/manuals
ENG
GET TO KNOW YOUR BRAVEN
BATTERY INDICATOR LIGHTS
POWER SWITCH
BATTERY CHECK BUTTON
PAIRING / ANSWER-END CALL /
PAUSE-RESUME MUSIC
POWER / PAIRING STATUS LIGHT
BRAVEN CHARGING PORT
VOLUME UP /
SKIP TRACK (press and hold)
EXTERNAL USB
CHARGING PORT
RESET BUTTON
VOLUME DOWN /
SKIP BACK (press and hold)
3.5 MM AUDIO-IN JACK
20% - 40% - 60% - 80% - 100%
TURN ON & BLUETOOTH PAIRING
1. Press the Power button for 2-3
seconds to turn on your BRAVEN
(BALANCE). Press the same
button again for 2-3 seconds to
turn your BRAVEN off.
2. Activate Bluetooth® on the phone
or device you are pairing with (see
your device’s instruction manual
for information on activating its
Bluetooth® settings).
3. Press and hold the Play Button on
your BRAVEN until you hear the
BRAVEN pairing sound.
4. Go to your phone or device’s
Bluetooth® settings and select
“BRAVEN BALANCE” from the
list.
5. If asked for a passcode enter “0000”
Your BRAVEN will remember the last 8 devices it has
paired with.
NOTE: If your BRAVEN does not have an active
Bluetooth® connection and is left on, it will
shut itself o after 30 minutes. To restart your
BRAVEN you will need to press and hold the
power button for 2-3 seconds.
45
Full manual and troubleshooting: braven.com/manuals
ENG
CHARGING YOUR BRAVEN
• Before using your BRAVEN for the first
time, charge the unit until all 5 Battery
Capacity lights are solid (not flashing),
indicating a full charge (typically 2 to 3
hours).
• To charge your BRAVEN, plug the
included USB-to-Micro-USB cable
into a wall power adapter (not
included) or into a powered USB port
on a computer. Plug the Micro-USB
connector end of the cable into the
BRAVEN charging port.
Your BRAVEN is designed to charge USB devices that
draw from 0.3A - 1A (most cell phones & mp3 players
– tablets and other 2A devices cannot be charged by
your BALANCE) using the full-sized USB port located
behind the cap. To use external charging:
1. Turn your BRAVEN on.
2. Plug the USB power cable that came with your
phone, mp3 player, or other mobile device into
the USB port on your BRAVEN.
3. Plug the other end of the cable into your mobile
device, and it will immediately begin charging.
CHARGING EXTERNAL DEVICES SPEAKERPHONE
• Press the Answer-End button on your
BRAVEN to answer the call over the speaker.
Press the Answer-End button again to end
the call.
• The BALANCE is IPX7 Waterproof, and is
designed to withstand rainfall, water jets, and
water splashing.
• IMPORTANT - To ensure your BRAVEN
BALANCE speaker is prepared for use
in a wet environment, remove all cable
connections and tightly close the rear water
cap. If the water cap is not properly closed,
the BALANCE will not be water resistant.
WATERPROOF FEATURES
67
Full manual and troubleshooting: braven.com/manuals
ENG
WARNINGS, CAUTIONS & LEGAL INFORMATION
To reduce the risk of re or electric shock, do not expose the BRAVEN to rain or moisture while charging. The BRAVEN should not be exposed to dripping or
splashing, and objects lled with liquids, such as vases, should not be placed on or near it while being charged or charging other devices. As with any electronic
products, use care not to spill liquids into any part of the product. Liquids can cause a failure and/or a re hazard. The power supply must be used indoors only.
Make no modications to the product or accessories. Unauthorized alterations may compromise safety, regulatory compliance, and system performance, and will
void the warranty. Do not place any ame sources, such as lighted candles, on or near the BRAVEN. The BRAVEN contains small parts that may be a choking hazard
and is not suitable for children under age 3. Do not continue charging the battery if it does not reach full charge within the specied charging time. Overcharging
may cause the battery to become hot, rupture, or ignite. If you see any heat deformation or leakage, properly dispose of the battery. Do not attempt to charge the
battery in temperatures outside the range of 32°-104°F (0°-40°C). If the battery begins to leak, do not allow the liquid to come in contact with your skin or eyes. If
contact has been made, wash the affected area with plenty of water and seek medical attention immediately. Do not expose the product or battery to excessive
heat, including direct sunlight or re and storage or use inside cars in hot weather, where it can be exposed to temperatures in excess of 115°F (60°C). Doing so may
cause the battery and power supply to generate heat, rupture, or ignite. Using the product in this manner also may result in a loss of performance and a shortened life
expectancy. Extended exposure to direct sunlight may damage the external appearance and material qualities. Do not step on, throw, or drop batteries or the power
supply or device, or expose them to a strong shock. Do not pierce, crush, dent, or deform the batteries or power supply in any way. If either becomes deformed,
properly dispose of it. Do not short-circuit batteries. Do not attempt to service the BRAVEN yourself. Opening or removing covers may expose you to dangerous
voltages or other hazards and will void the manufacturer’s warranty. To prevent risk of re or electric shock, avoid overloading wall outlets, extension cords, or integral
convenience receptacles. Your Bluetooth device (mobile phone, music player, tablet, laptop, etc.) must support the A2DP Bluetooth prole in order to work wirelessly
with your new BRAVEN speaker. The A2DP prole is supported by most recent mobile products with built-in Bluetooth capability. Please refer to your device’s
user manual for details and instruction regarding the Bluetooth proles it supports. This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that
may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:—Reorient or relocate the
receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected. — Consult the dealer or an experienced radio/TV technician for help.
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause
interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Under Industry Canada
regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To
reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is
not more than that necessary for successful communication.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes :
(1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en
compromettre le fonctionnement."
FCC RF warning statement: The device has been evaluated to meet general RF exposure requirement. The device can be used in portable
exposure condition without restriction.
This device and its antenna(s) must not be co-located or operation in conjunction with any other antenna or transmitter.
This product complies with California Energy Commission efciency standards for consumer battery chargers.
Warning: Changes or modications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
TUTORIALS: www.braven.com/tutorials
PHONE: 1-877-9 BRAVEN (1-877-927-2836)
SUPPORT: www.braven.com/support
EMAIL: support@braven.com
ONLINE: www.braven.com
MANUAL: www.braven.com/manuals
v3
