User manual

ENG

OWNER’S GUIDE

BRV-BANK™

BRAVEN_BRVBANK_UserManual-DRAFT.indd 1 2/24/14 4:01 PM

2ENGLISH

OVERVIEW

INCLUDED

BRV-BANK™ PORTABLE BACKUP BATTERY is a

convenient power source that gives you remote access

to its status via your smart device. Working in sync with

the BRAVEN BRV-BANK Smart App, the power bank

uses Bluetooth® Smart technology to communicate with

your device to read battery levels, forecast charge and

discharge times, and location.

BRV-BANK™

Portable

Battery

Bluetooth®

Battery

Monitor/Control

2 USB

Charging

Ports

Rechargeable

Li-polymer

Battery

Find Me

Feature

IPX5 Dirt

& Waterproof

Impact

Resistant

USB

Charging

Cable

USB

Flashlight

Lanyard

BRAVEN_BRVBANK_UserManual-DRAFT.indd 2 2/24/14 4:01 PM

BRAVEN.COM

ENG

PRODUCT FEATURES

In: 5V/0.5-2A

Output: 5V 1AOutput: 5V 2.4A

Bluetooth® Pairing

Battery/Bluetooth Indicator Lights

(20% - 40% - 60% - 80% - 100%)

USB Charge ON / OFF /

Battery Capacity Check

Protection Cap

Output Port (2.4A)

Ideal for tablets

Charging Port (2A)

Recharges BRV-BANK

Output Port (1A)

Ideal for Smartphones

Reset Button

Reinitiate Pairing

BRAVEN_BRVBANK_UserManual-DRAFT.indd 3 2/24/14 4:01 PM

4ENGLISH

CHARGING THE BACKUP BATTERY

PAIRING YOUR DEVICE



until all the LEDs turn on, indicating a full charge.

To charge your BRV-

BANK, plug the included

USB-to-Micro-USB cable

into a wall power adapter

(not included) or into

any powered USB port

(example: computer). Plug

the Micro-USB connector

end of the cable into the

BRV-BANK charging port.

Download the free

BRAVEN BRV-BANK App

on your device and open it

All LEDs will blink 3 times

consecutively to indicate

pairing mode is on

Press and hold

for 2-3 seconds to

activate pairing mode

Scan and select your

BRV-BANK on the

BRV-BANK App

All LEDs will remain lit for

2-3 seconds to indicate

pairing is complete

1 2

BRAVEN_BRVBANK_UserManual-DRAFT.indd 4 2/24/14 4:01 PM

BRAVEN.COM

ENG

CHARGING YOUR DEVICE

RUGGED PROTECTION

To start: Plug in your device(s), press and hold for 2-3

seconds to start charging

Your BRV-BANK is IP68 dirt and waterproof (IP: Ingress

Protection) and MIL-STD 810G shockproof (US Military

Standard) designed to go anywhere you go.

IMPORTANT – To ensure your BRV-BANK is prepared

for rough environments, remove all cable connections and

tightly close the protection cap.

To stop: Simply unplug your device(s), or press and hold

for 2-3 seconds

WATERPROOFSHOCKPROOF

Protection Cap

BRAVEN_BRVBANK_UserManual-DRAFT.indd 5 2/24/14 4:01 PM

6ENGLISH

FIND ME FEATURE

SPECIFICATIONS

BRAVEN ONE YEAR LIMITED WARRANTY

BRAVEN STATEMENT

Locate your BRV-BANK remotely from your BRAVEN



app and your BRV-BANK will emit a noise until found (up

to a 10m/33ft range).

BLUETOOTH:

Detection range:

10m(33ft)

OUTPUT RATING:

6000mAh: 5V/3.4A max combined

8000mAh: 5V/3.4A max combined

CHARING TIME:

BRV-BANK 6K: 4-5 hours

BRV-BANK 8K: 5-6 hours

This product is guaranteed against defects in materials

and craftsmanship for one year. Please visit braven.com

for full details.

packaging are trademarks or registered trademarks of

BRAVEN LC in the United States or other countries. The

Bluetooth™ word mark and logos are owned by Bluetooth

SIG and any use of such marks is under license. Other

trademarks and trade names are registered mark of their

respective owners.

INPUT RATING:

5V/0.5-2A

BRAVEN_BRVBANK_UserManual-DRAFT.indd 6 2/24/14 4:01 PM

BRAVEN.COM

ENG

WARNINGS, CAUTIONS & LEGAL INFORMATION



the BRAVEN to rain or moisture while charging. The

BRAVEN should not be exposed to dripping or splashing,



be placed on or near it while being charged or charging

other devices. As with any electronic products, use care







-

promise safety, regulatory compliance, and system perfor-



sources, such as lighted candles, on or near the BRAVEN.

The BRAVEN contains small parts that may be a choking



not continue charging the battery if it does not reach full



may cause the battery to become hot, rupture, or ignite. If

you see any heat deformation or leakage, properly dispose

of the battery. Do not attempt to charge the battery in tem-

peratures outside the range of 32°-104°F (0°-40°C). If the



contact with your skin or eyes. If contact has been made,

wash the affected area with plenty of water and seek

medical attention immediately. Do not expose the product

or battery to excessive heat, including direct sunlight or



it can be exposed to temperatures in excess of 115°F

(60°C). Doing so may cause the battery and power supply

to generate heat, rupture, or ignite. Using the product

in this manner also may result in a loss of performance

and a shortened life expectancy. Extended exposure to

direct sunlight may damage the external appearance and



or the power supply or device, or expose them to a strong

shock. Do not pierce, crush, dent, or deform the batteries

BRAVEN_BRVBANK_UserManual-DRAFT.indd 7 2/24/14 4:01 PM

8ENGLISH

or power supply in any way. If either becomes deformed,

properly dispose of it. Do not short-circuit batteries. Do

not attempt to service the BRAVEN yourself. Opening or

removing covers may expose you to dangerous voltages or





outlets, extension cords, or integral convenience recepta-

cles. Your Bluetooth device (mobile phone, music player,

tablet, laptop, etc.) must support the A2DP Bluetooth pro-





with built-in Bluetooth capability. Please refer to your





with part 15 of the FCC Rules. Operation is subject to the

following two conditions: (1) This device may not cause

harmful interference, and (2) this device must accept any

interference received, including interference that may

cause undesired operation.



comply with the limits for a Class B digital device, pursuant

to part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference





and used in accordance with the instructions, may cause

harmful interference to radio communications. However,

there is no guarantee that interference will not occur in a



interference to radio or television reception, which can be



is encouraged to try to correct the interference by one or

more of the following measures:—Reorient or relocate the

receiving antenna. —Increase the separation between the



outlet on a circuit different from that to which the receiver

WARNINGS, CAUTIONS & LEGAL INFORMATION

BRAVEN_BRVBANK_UserManual-DRAFT.indd 8 2/24/14 4:01 PM

BRAVEN.COM

ENG

is connected. — Consult the dealer or an experienced

radio/TV technician for help.

This device complies with Industry Canada license-exempt

RSS standard(s). Operation is subject to the following

two conditions: (1) this device may not cause interference,

and (2) this device must accept any interference, including

interference that may cause undesired operation of the

device. Under Industry Canada regulations, this radio

transmitter may only operate using an antenna of a type

and maximum (or lesser) gain approved for the transmitter

by Industry Canada. To reduce potential radio interference

to other users, the antenna type and its gain should be so



(e.i.r.p.) is not more than that necessary for successful

communication.

Lithium Battery installed is not intended to be replaced

by the user.

CAUTION: Danger of explosion if battery is incorrectly



Where the MAINS plug is used as the disconnect device,

the disconnect device shall remain readily operable.

Correct Disposal of this product. This marking indicates

that this product should not be disposed with other house-

hold wastes throughout the EU. To prevent possible harm

to the environment or human health from uncontrolled

waste disposal, recycle it responsibly to promote the

sustainable reuse of material resources. To return your

used device, please use the return and collection systems

or contact the retailer where the product was purchased.

This product complies with California Energy Commission



WARNINGS, CAUTIONS & LEGAL INFORMATION

BRAVEN_BRVBANK_UserManual-DRAFT.indd 9 2/24/14 4:01 PM

You are cautioned that changes or modifications not expressly approved by the party

responsible for compliance could void your authority to operate the equipment.

10 FRANÇAIS



COMPREND

La BATTERIE DE SECOURS PORTABLE BRV-BANK™ est







le chargeur utilise la technologie intelligente Bluetooth® pour





son emplacement.

Batterie

portable

BRV-BANK™

Contrôle/surveil-

lance Bluetooth®

de la batterie

2 ports de

charge USB

Batterie

lithium-polymère

rechargeable

Find Me

Feature



et à la poussière

IPX5



des chocs

Câble de

charge USB

Lampe torche

USB

Lanière

BRAVEN_BRVBANK_UserManual-DRAFT.indd 10 2/24/14 4:01 PM

BRAVEN.COM

FRA

FONCTIONS DU PRODUIT

In: 5V/0.5-2A

Output: 5V 1AOutput: 5V 2.4A

Jumelage Bluetooth®

Diodes de la batterie/Bluetooth

(20% - 40% - 60% - 80% - 100%)

Port de charge (2 A)

Recharge BRV-BANK

Charge USB ON / OFF /



de la batterie

Capuchon de

protection

Port de sortie (2.4 A)











BRAVEN_BRVBANK_UserManual-DRAFT.indd 11 2/24/14 4:01 PM

12 FRANÇAIS

CHARGER LA BATTERIE DE SECOURS

POUR JUMELER VOTRE APPAREIL







Pour charger votre



câble USB-vers-micro-USB

fourni dans un adaptateur







courant (p.ex. un ordinateur).





câble dans le port de charge

BRV-BANK.



BRAVEN BRV-BANK gratuite



Toutes les diodes clignoteront









pendant 2-3 secondes pour

activer le mode jumelage



votre BRV-BANK sur



Toutes les diodes resteront







1 2

BRAVEN_BRVBANK_UserManual-DRAFT.indd 12 2/24/14 4:01 PM

BRAVEN.COM

FRA

POUR CHARGER VOTRE APPAREIL

PROTECTION ROBUSTE





2-3 secondes pour lancer la charge







vous suivre partout





protection.







ETANCHEANTI-CHOCS

Capuchon de protection

BRAVEN_BRVBANK_UserManual-DRAFT.indd 13 2/24/14 4:01 PM

14 FRANÇAIS



SPECIFICITES



DECLARATION DE BRAVENBRAVEN

-







de 10 m).

BLUETOOTH :



10 m

VALEURS NOMINALES DE SORTIE :

6 000 mAh : 5 V/3,4 A max. en combinaison

8 000 mAh : 5 V/3,4 A max. en combinaison

TEMPS DE CHARGE :

BRV-BANK 6K : 4-5 heures

BRV-BANK 8K : 5-6 heures













® et ses logos









respectifs.

VALEURS NOMINALES



5 V/0,5-2 A

BRAVEN_BRVBANK_UserManual-DRAFT.indd 14 2/24/14 4:01 PM

BRAVEN.COM

FRA

AVERTISSEMENTS ET MISES EN GARDE /

INFORMATIONS JURIDIQUES





























et la performance du système, et elle annulera la garantie.

























entre en contact avec la peau ou les yeux. En cas de





produit ou la batterie à une chaleur excessive; entre autres,

ne pas les exposer aux rayons directs du soleil ni au feu et

ne pas les ranger ni les utiliser dans une auto par temps très









BRAVEN_BRVBANK_UserManual-DRAFT.indd 15 2/24/14 4:01 PM

16 FRANÇAIS











pas les lancer, les laisser tomber ni leur faire subir un choc





-

ment. Ne pas court-circuiter les batteries. Ne pas essayer

























A2DP est pris en charge par la plupart des produits mobiles









Ce produit est conforme à la section 15 des règlements de

la FCC. Son fonctionnement est soumis aux deux conditions

suivantes : (1) ce produit ne doit pas causer de brouillage

nuisible, et (2) ce produit doit pouvoir accepter tout brouil-



fonctionnement anormal.







AVERTISSEMENTS ET MISES EN GARDE /

INFORMATIONS JURIDIQUES

BRAVEN_BRVBANK_UserManual-DRAFT.indd 16 2/24/14 4:01 PM

BRAVEN.COM

FRA

Ces limitations visent à fournir une protection raisonnable

contre le brouillage nuisible pouvant survenir dans un



































Canada applicables aux appareils radio exempts de licence.





-





la classe B est conforme à la norme NMB-003 du Canada.



















AVERTISSEMENTS ET MISES EN GARDE /

INFORMATIONS JURIDIQUES

BRAVEN_BRVBANK_UserManual-DRAFT.indd 17 2/24/14 4:01 PM

18 ESPAÑOL

DESCRIPCIÓN

INCLUYE

La BATERÍA PORTÁTIL DE RESERVA BRV-BANK™ es una









Bluetooth® para comunicarse con su dispositivo y leer los







BRV-BANK™

Control/monitor



Bluetooth®

2 puertos de

carga USB



recargable de



Función



Grado de protección

IPX5 de resistencia

al polvo y al agua

Resistente a

los impactos

Cable de

carga USB

Linterna

USB Accesorio de

sujeción

BRAVEN_BRVBANK_UserManual-DRAFT.indd 18 2/24/14 4:01 PM

ESP

BRAVEN.COM

In: 5V/0.5-2A

Output: 5V 1AOutput: 5V 2.4A

CARACTERÍSTICAS DEL PRODUCTO

Emparejamiento

Bluetooth®

Indicador luminoso de carga de



(20% - 40% - 60% - 80% - 100%)

Carga USB ACTIVADA /

DESACTIVADA /

Comprobación de la



Tapa de protección

Puerto de salida (2,4 A)

Ideal para tabletas

Puerto de carga (2 A)

Recarga su BRV-BANK

Puerto de salida (1 A)



Botón de reinicio Reiniciar

el emparejamiento

BRAVEN_BRVBANK_UserManual-DRAFT.indd 19 2/24/14 4:01 PM

20 ESPAÑOL

CARGA DE LA BATERÍA DE RESERVA

EMPAREJAMIENTO DE SU DISPOSITIVO





está completamente cargada.

Para cargar su BRV-BANK,

conecte el cable USB a

Micro-USB a un adaptador

para enchufe de pared

(no incluido) o a un puerto

USB con alimentación (por

ejemplo, un ordenador).

Conecte el extremo del

conector Micro-USB del

cable en el puerto de carga

del BRV-BANK.

Descargue gratis la aplicación

BRAVEN BRV-BANK en su

dispositivo y ábrala.

Todos los LED parpadearán

3 veces de forma consecutiva



el modo de emparejamiento.

Mantenga pulsado durante

2-3 segundos para activar el

modo de emparejamiento.

Escanee y seleccione su

BRV-BANK en la aplicación

BRV-BANK.

Todos los LED permanecerán

iluminados durante 2-3



modo de emparejamiento se

ha completado.

1 2

BRAVEN_BRVBANK_UserManual-DRAFT.indd 20 2/24/14 4:01 PM

ESP

BRAVEN.COM

CARGA DE SU DISPOSITIVO

PROTECCIÓN ROBUSTA





Su BRV-BANK dispone de un grado de protección IP68 de



protección de entrada) y MIL-STD 810G (Normativa militar de



diseñado para llevarlo a todos los sitios donde usted vaya.



preparado para entornos extremos, extraiga todas las

conexiones de cables y cierre bien la tapa de protección.

Para detener la carga: simplemente desconecte su dispositivo(s)

o mantenga pulsado durante 2-3 segundos.

RESISTENTE

AL AGUA

RESISTENTE A

LOS GOLPES

Tapa de protección

BRAVEN_BRVBANK_UserManual-DRAFT.indd 21 2/24/14 4:01 PM

22 ESPAÑOL



ESPECIFICACIONES

UN AÑO DE GARANTÍA LIMITADA BRAVEN

DECLARACIÓN DE BRAVEN

Localice su BRV-BANK de forma remota mediante la

aplicación BRAVEN BRV-BANK App. Seleccione la opción





metros/33 pies).

BLUETOOTH:

Distancia de detección:

10 metros (33 pies)

CAPACIDAD NOMINAL DE SALIDA:

6000 mAh: 5 V/3,4 A máximo combinado

8000 mAh: 5 V/3,4 A máximo combinado

TIEMPO DE CARGA:

BRV-BANK 6K: 4-5 horas

BRV-BANK 8K: 5-6 horas



en materiales y fabricación. Visite breven.com para obtener

más información.

Diseñado por BRAVEN en EE.UU. Fabricado en China.

es un nombre comercial o marca registrada de BRAVEN LC.

La marca denominativa y los logotipos Bluetooth® son marcas

comerciales registradas propiedad de Bluetooth SIG, Inc. y



resto de las marcas y nombres comerciales pertenecen a sus

respectivos propietarios.

CAPACIDAD NOMINAL

DE ENTRADA:

5 V/0,5-2 A

BRAVEN_BRVBANK_UserManual-DRAFT.indd 22 2/24/14 4:01 PM

ESP

BRAVEN.COM

ADVERTENCIAS Y PRECAUCIONES /

INFORMACIÓN LEGAL



no exponga el BRAVEN a la lluvia o la humedad mientras

se está cargando. El BRAVEN no debe exponerse a es-

currimientos o salpicaduras, y no se deben colocar cerca



se está cargando o se cargan otros dispositivos. Como













poner en riesgo la seguridad, el cumplimiento normativo













-





debida al calor o alguna fuga, deshágase debidamente



fuera del intervalo de entre 32 y 104 °F (0 a 40 °C).





contacto, lave inmediatamente el área afectada con agua







dentro de automóviles en climas cálidos, donde pueda

estar expuesto a temperaturas por encima de los 115 °F



de alimentación generen calor, se rompan o se incendien.

BRAVEN_BRVBANK_UserManual-DRAFT.indd 23 2/24/14 4:01 PM

ENG

BRAVEN_BRVBANK_UserManual-DRAFT.indd 24 2/24/14 4:01 PM

BRAVEN LC BPB6 BRV Powerbank 6000 User Manual

BRAVEN LC BRV Powerbank 6000

User manual

Navigation menu

Namespaces

Views

Navigation
