BRAVEN LC BRAVA BRAVA User Manual 15 BRAVA UserMan
BRAVEN LC BRAVA 15 BRAVA UserMan
15_BRAVA UserMan.pdf
QUICK START GUIDE
BRAVA
ENG
WHAT’S IN THE BOX
BRAVEN Brava Universal Clip
Optional
Leather Strap
Micro USB
Charging Cable
ENG
GET TO KNOW YOUR BRAVEN
LED battery
status indicators
(Each LED = 20%)
3.5 mm
audio-in jack
Reset button
Power On/Off
(Long press)
Battery Check
(Short press)
Pairing / Answer-
End call / Pause-
Resume music
Volume down /
Skip track
(Press and hold)
Micro USB
charging port
Volume up /
Skip track
(Press and hold)
USB charging
port (1A)
Dual-mic
integration
ENG
HOW TO ATTACH / REMOVE
LEATHER STRAP
Strap release button
Slide left or right
to insert / remove
ENG
TURN ON & BLUETOOTH® PAIRING
1. Press the Power button for 2-3
seconds to turn on your BRAVEN
(BRAVA). Press the same button
again for 2-3 seconds to turn
your BRAVEN off.
2. Activate Bluetooth® on
the phone or device you
are pairing with (see your
device’s instruction manual for
information on activating its
Bluetooth® settings).
3. Press and hold the Play Button
on your BRAVEN until you hear
the BRAVEN pairing sound.
4. Go to your phone or device’s
Bluetooth® settings and select
“BRAVEN BRAVA” from the list.
5. If asked for a passcode enter
“0000”
Your BRAVEN will remember the
last 8 devices it has paired with.
NOTE: If your BRAVEN does
not have an active Bluetooth®
connection and is left on, it will
shut itself off after 30 minutes.
To restart your BRAVEN you
will need to press and hold the
power button for 2-3 seconds.
ENG
CHARGING
YOUR BRAVEN
• Before using your BRAVEN for the
rst time, charge the unit until all
5 Battery indicator lights are solid
(not ashing), indicating a full charge
(typically 3 to 5 hours).
• To charge your BRAVEN, plug the
included USB-to-Micro-USB cable
into a wall power adapter (not
included) or into a powered USB
port on a computer. Plug the Micro-
USB connector end of the cable
into the BRAVEN charging port.
Your BRAVEN is designed to charge
most USB devices that draw from 0.3A -
1A using the full-sized USB port. To use
external charging:
1. Turn your BRAVEN on.
2. Plug the USB power cable that came
with your phone, mp3 player, or other
mobile device into the USB port on
your BRAVEN.
3. Plug the other end of the cable
into your mobile device, and it will
immediately begin charging.
CHARGING
EXTERNAL DEVICES
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence.
L'exploitation est autorisée aux deux conditions suivantes :
(1) l'appareil ne doit pas produire de brouillage;
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en
compromettre le fonctionnement.
Le dispositif rencontre l'exemption des limites courantes d'évaluation dans la section 2.5 de RSS 102 et la conformité à
l'exposition de RSS-102 rf, utilisateurs peut obtenir l'information canadienne sur l'exposition et la conformité de rf.
ENG
• Press the Answer-End button on
your BRAVEN to answer the call
over the speaker. Press the Answer-
End button again to end the call.
• The BRAVA’s dual omnidirectional
microphones deliver crystal-clear
speakerphone audio within a 5 foot
range. Internal noise cancellation
technology blocks background
interruption for a premium call
experience from hello to goodbye.
DUAL MIC &
NOISE CANCELLATION
REMOVING PAIRED
DEVICES
• Hold down Reset Button for
8 seconds to removed stored
Bluetooth® devices from speaker.
The speaker remembers 8
paired devices.
RESETING SPEAKER
SPEAKERPHONE
• BRAVA remembers up to 8
paired Bluetooth® devices.
In order to remove
paired devices, press
for at least 8 seconds.
ENG
To reduce the risk of re or electric shock, do not expose the
BRAVEN to rain or moisture while charging. The BRAVEN
should not be exposed to dripping or splashing, and objects
lled with liquids, such as vases, should not be placed on or
near it while being charged or charging other devices. As with
any electronic products, use care not to spill liquids into any
part of the product. Liquids can cause a failure and/or a re
hazard. The power supply must be used indoors only. Make
no modications to the product or accessories. Unauthorized
alterations may compromise safety, regulatory compliance,
and system performance, and will void the warranty. Do not
place any ame sources, such as lighted candles, on or near
the BRAVEN. The BRAVEN contains small parts that may be
a choking hazard and is not suitable for children under age
3. Do not continue charging the battery if it does not reach
full charge within the specied charging time. Overcharging
may cause the battery to become hot, rupture, or ignite. If you
see any heat deformation or leakage, properly dispose of the
battery. Do not attempt to charge the battery in temperatures
outside the range of 32°-104°F (0°-40°C). If the battery begins
to leak, do not allow the liquid to come in contact with your
skin or eyes. If contact has been made, wash the affected area
with plenty of water and seek medical attention immediately.
Do not expose the product or battery to excessive heat,
including direct sunlight or re and storage or use inside cars
in hot weather, where it can be exposed to temperatures in
excess of 115°F (60°C). Doing so may cause the battery and
power supply to generate heat, rupture, or ignite. Using the
product in this manner also may result in a loss of performance
and a shortened life expectancy. Extended exposure to direct
sunlight may damage the external appearance and material
qualities. Do not step on, throw, or drop batteries or the power
supply or device, or expose them to a strong shock. Do not
pierce, crush, dent, or deform the batteries or power supply
in any way. If either becomes deformed, properly dispose of
it. Do not short-circuit batteries. Do not attempt to service the
BRAVEN yourself. Opening or removing covers may expose
you to dangerous voltages or other hazards and will void the
manufacturer’s warranty. To prevent risk of re or electric
shock, avoid overloading wall outlets, extension cords, or
integral convenience receptacles. Your Bluetooth device
(mobile phone, music player, tablet, laptop, etc.) must support
the A2DP Bluetooth prole in order to work wirelessly with
your new BRAVEN speaker. The A2DP prole is supported by
most recent mobile products with built-in Bluetooth capability.
Please refer to your device’s user manual for details and
instruction regarding the Bluetooth proles it supports. This
device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept
any interference received, including interference that may
cause undesired operation.
NOTE: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
WARNINGS, CAUTIONS & LEGAL INFORMATION
ENG
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is
no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following
measures:—Reorient or relocate the receiving antenna. —
Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected. — Consult the
dealer or an experienced radio/TV technician for help.
CAUTION: Any changes or modications not expressly
approved by the party responsible for compliance could void
the user’s authority to operate the equipment.
FCC RADIATION EXPOSURE STATEMENT: This device
complies with FCC radiation exposure limits set forth for an
uncontrolled environment.
This device complies with Industry Canada license-exempt
RSS standard(s). Operation is subject to the following two
conditions: (1) this device may not cause interference, and
(2) this device must accept any interference, including
interference that may cause undesired operation of the device.
Under Industry Canada regulations, this radio transmitter
may only operate using an antenna of a type and maximum
(or lesser) gain approved for the transmitter by Industry
Canada. To reduce potential radio interference to other users,
the antenna type and its gain should be so chosen that the
equivalent isotropically radiated power (e.i.r.p.) is not more than
that necessary for successful communication.
Lithium Battery installed is not intended to be replaced by
the USER.
CAUTION: Danger of explosion if battery is incorrectly
replaced. Replace only with the same or equivalent type.
Where the MAINS plug is used as the disconnect device, the
disconnect device shall remain readily operable.
The device meets the exemption from the routine evaluation
limits in section 2.5 of RSS 102 and compliance with RSS-102
RF exposure, users can obtain Canadian information on RF
exposure and compliance.
Correct Disposal of this product. This marking indicates
that this product should not be disposed with other household
wastes throughout the EU. To prevent possible harm to
the environment or human health from uncontrolled waste
disposal, recycle it responsibly to promote the sustainable
reuse of material resources. To return your used device, please
use the return and collection systems or contact the retailer
where the product was purchased.
This product complies with California
Energy Commission efciency standards
for consumer battery chargers.
