BSD RACING TECHNOLOGIES B7001 RADIO CONTROL User Manual
BSD RACING TECHNOLOGIES CO., LTD. RADIO CONTROL
USERS MANUAL
Transmitter Antenna
Steering Wheel
1
Power Switch
2
Throttle Trigger
4
3
Steering Trim
LED Indicator
Throttle Trim
Crystal for Transmitter
8
6
5
7
1
The transmitter antenna is for transmiting
the radio waves.
The power switch is for switching the
power on/off.
The steering wheel is for controlling the
direction of right/left.
The throttle trigger is for controlling the
throttle and brake.
The steering trim is for adjusting the
position of neutral.(right/left)
The throttle trim is for adjusting the carb
in idle position.
The LED indicator is for showing the
remaining amount of the battery.when
turn on the power switch.
Crystal for transmitter is for changing
the radio frequency by replacing the c-
rystal.
2
3
4
5
6
7
8
Install the receiver antenna.
Install the transmitter antenna.
Loading the battery on the transmitter.
Install the charged battery on the truck.
1.Please pull out the transmitter antenna and then turn on the power switch first,
before turning on the receiver.
2.Please raises the tires off the ground and check if the control is responding.
3.Hold the throttle trigger to let truck running.if it doesn't work please adjust the
throttle servo and trim.
4.Please replace the battery,when speed drops down.
5.When you finish the racing,please turn the receiver switch off first,and then the
transmitter.
6.Please make sure the battery is disconnect and remove the battery after finishing
the racing.
GLOSSARY OF TRANSMITTER
BEFORE THE OPERATING
RC OPERATING PROCEDURES
Install eight "AA" batteries into transmitter,making
sure the polarity is correct.
Insert the antenna into the top of the transmitter and
tighten the screw.
Turn the transmitter on and check the battery light.
If all LED's light up,the batteries are acceptable.If
only the red LED lights up,immediately replace the
batteries.
-+
AA
-
AA
+
+
AA
-
-
AA
+
+
AA
-
-
AA
+
+
AA
-
+
AA
-
TRANSMITTER PREPARATION
Without permission, any company, business or user shall not change the frequency, nor increase
the capacity, nor modify the original characteristics or functions once this low frequency radio is
granted type approval certificate.
The usage of the low frequency radio shall not affect aviation safety or disturb legal communications.
Once found, it shall be stopped, and must be improved until this impact is eliminated.
The legal communications aforementioned refer to radio-communication under the
telecommunications act.
Low frequency radios must submit to disturbance produced by legal communications, and
radio-wave radiation generated by industrial, scientific and medical equipments.
FCC WARNING
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
NOTE: The manufacturer is not responsible for and radio or TV interference caused by
unauthorized modifications to this equipment. Such modifications could void the user’s authority
to operate the equipment.
