BSD RACING TECHNOLOGIES BT1001 1/12 Rock Crawler User Manual BT1001
BSD RACING TECHNOLOGIES CO., LTD. 1/12 Rock Crawler BT1001
User manual
(1). Small parts. Keep out of reach of small children.
(2). Please operate in an open field without any wave interference.
(3). When transmitter is low in power, please stop and change batteries immediately.
(4). On backout after the removal, please do not place discarded to avoid contamination sanitation.
(5). Please store the car and the transmitter in a dry and cool environment.
(6). Keep away from fire, hot or humid environment.
(7). If car battery is wet, be sure to wipe and dry it completely to avoid any damage.
1. Remove the battery cover.
2. Install 4*1.5V AA batteries (not included) in correct polarities.
3. Close the battery cover.
1. When installing batteries, please be sure to match the polarities
labeled on the battery holder.
2. Do not mix old and new batteries.
3. Do not mix different type of batteries.
Caution
!
Notice:
Car
Model:BT1001
2.4G Transmitter
Ni-MH battery pack AA batteries (6 pcs for car,
4 pcs for transmitter)
Charger
!
Product Configuration
Install Transmitter Batteries
Battery
Battery Cover
OFF
PUSH
ON
Optional Parts
23
1
8+
www.bsdracing.com
Transmitter Operation
Install Batteries
Slow Speed
Installed AA Batteries
Install Ni-MH Batteries
Power Switch
Front Back
Left
Right
Power Light
Steering Minitrim Knob
Fast / Slow Switch
Brake Neutral
Power Switch
Front Back
Left
Right
Power Light
Steering Minitrim Knob
Fast / Slow Switch
Fast Speed
Power Switch
Battery Cover
Knob
Power Switch
Battery Cover
Knob
Removed AA
Batteries Case
AA Batteries
Ni-MH Batteries
Federal Communications Commission (FCC) Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
●Reorient or relocate the receiving antenna.
●Increase the separation between the equipment and receiver.
●Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
●Consult the dealer or an experienced radio/TV technician for help.
Warning: Changes or modifications made to this device not expressly approved by BSD
RACING TECHNOLOGIES CO., LTD. may void the FCC authorization to operate this device.
Note: The manufacturer is not responsible for any radio or tv interference caused by
unauthorized modifications to this equipment. Such modifications could void the user’s
authority to operate the equipment.
