BSD RACING TECHNOLOGIES BT7101 Transmitter User Manual
BSD RACING TECHNOLOGIES CO., LTD. Transmitter
User manual
(1). Small parts. Keep out of reach of small children.
(2). Please operate in an open field without any wave interference.
(3). When transmitter is low in power, please stop and change batteries immediately.
(4). On backout after the removal, please do not place discarded to avoid contamination sanitation.
(5). Please store the car and the transmitter in a dry and cool environment.
(6). Keep away from fire, hot or humid environment.
(7). If car battery is wet, be sure to wipe and dry it completely to avoid any damage.
1. Remove the battery cover.
2. Install 4*1.5V AA batteries (not included) in correct polarities.
3. Close the battery cover.
1. When installing batteries, please be sure to match the polarities
labeled on the battery holder.
2. Do not mix old and new batteries.
3. Do not mix different type of batteries.
Caution
!
Notice:
Car
Model:BT7101
2.4G Transmitter
Ni-MH battery pack AA batteries (6 pcs for car,
4 pcs for transmitter)
Charger
!
Product Configuration
Install Transmitter Batteries
Battery
Battery Cover
OFF
PUSH
ON
Optional Parts
23
1
8+
www.bsdracing.com
Transmitter Operation
Install Batteries
Slow Speed
Installed AA Batteries
Install Ni-MH Batteries
Power Switch
Front Back
Left
Right
Power Light
Steering Minitrim Knob
Fast / Slow Switch
Brake Neutral
Power Switch
Front Back
Left
Right
Power Light
Steering Minitrim Knob
Fast / Slow Switch
Fast Speed
Power Switch
Battery Cover
Knob
Power Switch
Battery Cover
Knob
Removed AA
Batteries Case
AA Batteries
Ni-MH Batteries
www.bsdracing.com
FCC Statement
This device complies with Part 15 of the FCC rules. Operation is subject to the
following two conditions: 1) this device may not cause harmful interference, and 2)
this device must accept any interference received, including interference that may
cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
--Reorient or relocate the receiving antenna.
--Increase the separation between the equipment and receiver.
--Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
--Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
FCC Radiation Exposure Statement
This device complies with FCC RF radiation exposure limits set forth for an
uncontrolled environment. This transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
