Baltech 10117501A01A RFID Card Reader User Manual

Baltech AG RFID Card Reader Users Manual

Users Manual

Operation Manual
RFID Reader “IDE-ZM-L2M-U2”
Covered Variants:
M/N: 10117-501
M/N: 10117-x
1
y1z1
REVISION 1.0, 2018-07-08
BALTECH AG
Lilienthalstraße 27
85399 Hallbergmoos
Germany
Phone: +49 (811) 99 88 1- 0
FAX: +49 (811) 99 88 1- 11
e-mail: info@baltech.de
http://www.baltech.de/
1
“x“, “y” and “z” shall represent any alphanumerical number or can be left blank.
- 1 -
Introduction
The “IDE-ZM-L2M-U2” Reader/Writer is a desktop contactless smart card USB/RS232 reader and
writer with 13.56 MHz card technology. It supports Legic Advant ISO 14443A/B, ISO 15693 and
Legic Prime standards.
Based on BALTECH’s core technology it provides support of the latest smartcard technologies,
encryption and security features.
Mounting and Connection
The reader generates a magnetic field at 13.56MHz which could be influenced by any electrically
conductive material close to the device.
To ensure good performances and functionalities in terms of read range and reliability a minimum
distance of 10cm from such materials is required. Mounting the unit directly to metal would result
in a severe reduction of read range down to zero functionality. Care should be taken when testing
the device after mounting at a problematic environment: Read ranges and performance vary from
card to card and very much from card to tag or key-fob.
When mounting multiple readers, the distance between readers should be minimum 0.5 m in
order to avoid degradation of performance due to interference.
To connect the device to a host system (a printer or a PC), please make sure that the system
provides an USB socket intended for connection of the reader.
Operation
Whenever the device is connected to a proper power supply, it will switch on the internal antenna
and periodically scan for a card. Once a card has been detected, the card number is read, the data
converted and sent to the host system through the USB Interface. To enable the device to read
cards, tags and key-fobs successfully, they should be placed centred above the reader.
- 2 -
Technical Features
Operating Frequency
13.56MHz
Data transmission
modulation reader to card:
ASK
Data transmission
modulation card to reader:
AM/Load modulation
Interfaces
USB: Full speed 2.0, RS 232
Contactless Card
Supported standards: ISO14443 A & B, ISO15693,Legic
Communication speed ISO14443A/B: Baud rate up to 424kBaud
Operating Range
• ISO14443A/B: up to 5cm
• ISO15693: up to 8cm
Human
RGB LED & Buzzer
Supply Power [VDC]
5 VDC(±5%)
Power Consumption [W]
Up to 1.5 / 1 typ.
Operating Temperature [°C]
-20 to +65
Operating Humidity [%]
20 to 80 relative humidity; non-condensing
Non-Operating Humidity [%]
10 to 90 relative humidity; non-condensing
Antennas
13.56MHz permanently attached coil antenna, dimension: 44mmx32mm
- 3 -
Pinning
Pin
Name
Type
Description
1
PWR
Power
5V Power Supply
2
D-
Output
USB-Data inverted
3
D+
Input
USB-Data
4
GND
Power
Signal and Power Ground
Pin#
Name
Type
Description
1
PWR
Power
5V Power Supply
2
GND
Power
Signal and Power Ground
3
MULTI_RX
Data
RX_UART / WGND_D1 / MAG_DATA
4
MULTI_TX
Data
TX_UART / WGND_D0 / MAG_CLK
5
MULTI_I/O
GPIO
Input, output pin.
- 4 -
General regulatory requirements for 10117-501
FCC ID OKY10117501A01A
IC: 7657A-10117501
NOTICE:
This device complies with Part 15 of the FCC Rules and with Industry Canada licence-exempt RSS
standard(s).
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitation est autorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre le fonctionnement.
Changes or modifications made to this equipment not expressly approved by BALTECH AG may void
the FCC authorization to operate this equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
