Operation Manual
BSM2-100 / 0533A03C-001 with 0001A04C and 0505A01A
REVISION 1.0, 2006-11-17
The BSM2-100 is a RFID Read-/Write-Device (short: reader) which is compatible to all
mifare® contactless smartcards. It provides a serial interface RS232 to output or exchange
data with a host computer and a 13.56MHz inductive interface to provide power to and
exchange data with the Mifare/ISO compliant card (or other available form-factors such as
tags, key-fobs).
Mounting and Connection
The reader generates a magnetic field with the frequency of 13.56MHz which is influenced by
any electrically conductive material in close proximity to the device. When mounting the
antenna, a distance to any such material of minimum 10 cm is required to ensure that there
will be no significant degradation of the performance in terms of read range and reliability.
Mounting the antenna directly to metal would result in a severe reduction of read range down
to zero functionality. Care should be taken when testing the device after mounting at a
problematic environment: Read ranges and performance vary from card to card and very
much between card and Tag’s or key-fob.
When mounting multiple readers, the distance between readers should be minimum 1 m to
avoid degradation of performance due to interference between the antennas.
To connect the device to a host computer, any serial RS232-interface (COM-port) can be
used. There is a special cable required to connect to the AMP MicroMatch 20-Pole connector
which provides the communication and power supply connections.
Operation
When the device is connected to a proper power supply, it will perform some initialization
routines and is then under control of the host system. The host software can initiate card scan
cycles and, after a card has been detected, perform read and write operations to the card
memory.
Technical Data
DC Electrical Characteristics
Symbol Parameter Condition Min Typ Max Units
Vdd Supply Voltage 4.75 5 5.5 VDC
Idd Supply current 450 mA
Idd1 Peak Supply current Inrush 650 mA
Power supply voltage to be measured at BSM2-100 connector (NOT including voltage drop
over connection cable).
Additional requirements for the supply voltage: Vripple = 50mVpp max.
0533A03C-001_manualR10.doc Page 2 of 2
RF Characteristics
Operating frequency: 13.56 MHz
Data transmission modulation reader to card: AM 100%
Data transmission modulation card to reader: AM/load modulation
Pinout 20-Pin AMP MicroMatch Connector BSM2-100<->Host
Pin Name Type Description
1,2 PWR Power 5V Power Supply
3,4, 20 GND Power Signal and Power Ground
5 TXD Output RS232-data from reader
6 RXD Input RS232-data to reader
7-19 - - Not connected
6-Pin AMP MicroMatch Connector Module 0533A03C-001 <->
0001A04C
To be connected 1:1 with a flatband ribbon cable AWG26-28, length 30cm (1’).
Serial Interface
The TXD/RXD signals are compatible with RS-232 level signals. The interface operates at
19200 baud, no parity, 8 data bits, 1 stop bit. The communication protocol used is the T3964R
protocol.
Temperature
Operating temperature range: 0…35°C
Storage temperature range: -20…+60°C
Thermal shock: 30°C/min maximum dT/dt
Humidity
Operating: 20% to 80% relative humidity; non condensing
Non-operating: 10% to 90% relative humidity; non-condensing
® mifare is a registered trademark of Philips Semiconductors, The Netherlands.
® mifare is a registered trademark of Philips Semiconductors, The Netherlands.
Any changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate the equipment.
The final product should contain labelling according to FCC requirements.
For example:
This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
This device contains FCC ID OKY1053300101A03C. This label will be placed on the final product, clearly
visible to all persons exposed to the transmitter
