Beautiful Enterprise BTSPK05 Bluetooth® Speaker User Manual Front side
Beautiful Enterprise Co., Ltd. Bluetooth® Speaker Front side
Users Manual
Safety Information
Setting up the System
To reduce the risk of fire or electric shock,
do not expose this apparatus to rain or
moisture.
To reduce the risk of fire or electric shock,
do not expose this apparatus to dripping
or splashing, and do not place objects
filled with liquids, such as vases, on the
apparatus.
To reduce the risk of fire, do not cover the
ventilation opening of the apparatus
with newspapers, tablecloths, curtains,
etc.
Do not place the naked flame sources
such as lighted candles on the apparatus.
Do not install the appliance in a confined
space, such as a bookcase or built-in
cabinet.
As the main plug of AC adaptor is used to
disconnect the AC adaptor from the
mains, connect it to an easily accessible
AC outlet. Should you notice an
abnormality in it, disconnect it from the
AC outlet immediately.
The AC adaptor is not disconnected from
the mains as long as it is connected to
PORTABLE CART WARNING
(Symbol provided by RETAC)
Instruction Book
WSBS2000 Bluetooth Speaker
Design and specifications are subject to change without notice.
the AC outlet, even if the main unit itself
has been turned off.
The nameplate is located on the bottom
exterior of the main unit and on the
surface of the AC adaptor.
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these Instructions.
3. Heed all Warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings.
Install in accordance with the
manufacturer's instructions.
8. Do not install near any heat sources
such as radiators, heat registers, stoves,
or other apparatus (including
amplifiers) that produce heat.
9. Do not defeat the safety purpose of the
polarized or grounding - type plug. A
polarized plug has two blades with
one wider than the other. A grounding
type plug has two blades and a third
grounding prong. The wide blade or
the third prong is provided for your safety. If
the provided plug does not fit into your
outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked
on or pinched particularly at plugs,
convenience receptacles, and the point
where they exit from the apparatus.
11. Only use attachments/accessories specified
by the manufacturer.
12. Use only with the cart, stand, tripod,
bracket or table specified by the
manufacturer, or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus
combination to avoid
injury from tip-over.
13. Unplug this apparatus during lightning
storms or when unused for long periods of
time.
14. Refer all servicing to qualified service
personnel. Servicing is required when the
apparatus has been damaged in any way,
such as power-supply cord or plug is
damaged, liquid has been spilled or objects
have fallen into the apparatus, the
apparatus has been exposed to rain or
moisture, does not operate normally, or has
been dropped.
Please read rating label at the bottom of system
for power input and other safety information.
FCC and IC Information:
This device complies with Part 15 of the FCC
Rules and RSS-210 of the IC Rules. Operation is
subject to the following two conditions: (1)
This device may not cause harmful
interference, and (2) this device must accept
any interference received, including
interference that may cause undesired
operation.
Warnings: The device meets the exemption
from the routine evaluation limits in section
2.5 of RSS 102 and users can obtain Canadian
information on RF exposure and compliance
from the Canadian Representative Burnport
Holdings Ltd. 72MT Belcher Pls, East, Calgary,
Alberta, T2Z 2G1, CANADA. Tel: 403-257-4961
Canada IC statments
Le présent appareil est conforme aux CNR
d'Industrie Canada applicables aux appareils
radio exempts de licence. L'exploitation est
autorisée aux deux conditions suivantes : (1)
l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout
brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre
le fonctionnement.
Information for Users on Disposal of Old
Equipment
[European Union]
This symbol indicates that the
electrical and electronic equipment
should not be disposed as general
household waste at its end-of-life.
Instead, the product should be handed
over to the applicable collection point for
the recycling in accordance with your
national legislation.
By disposing of this product correctly, you
will help to conserve natural resources
and will help prevent potential negative
eects on the environment and human
health that could otherwise be caused by
inappropriate waste handling of this
product. For more information about
collection point and recycling of this
product, please contact your local
municipal oce, your household waste
disposal service or the shop where you
purchased the product. Penalties may be
applicable for incorrect disposal of this
waste, in accordance with national
legislation.
[Other Countries outside the
European Union]
If you wish to dispose of this product,
please do so in accordance with
applicable national legislation or other
rules in your country for the treatment of
old electrical and electronic equipment.
Attention:
This symbol is
only valid in the
European Union.
10 cm
(3- 15
/
16")
15 cm
(5- 15
/
16")
15 cm
(5- 15
/
16")
15 cm
(5- 15
/
16")
15 cm
(5- 15
/
16")
Front view: Side view:
Front side Back side
FCC&IC Radiation Exposure Statement
This equipment complies with FCC radiation
exposure limits set forth for an uncontrolled
environment and meets the exemption from
the routine evaluation limits in section 2.5 of
RSS 102.
1. This Transmitter must not be co-located or
operating in conjunction with any other
antenna or transmitter.
2. This equipment complies with FCC RF
radiation exposure limits set forth for an
uncontrolled environment. This equipment
should be installed and operated with a
minimum distance of 20 centimeters from
user and bystanders.
Warning: Changes or modications to this
unit not expressly approved by the party
responsible for compliance could void the
user's authority to operate the equipment.
NOTE: This equipment has been tested and
found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide
reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses, and can radiate
radio frequency energy and, if not installed
and used in accordance with the instructions,
may cause harmful interference to radio
communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this equipment does
cause harmful interference to radio or
television reception, which can be determined
by turning the equipment o and on, the user
is encouraged to try to correct the
interference by one or more of the following
measures:
— Reorient or relocate the receiving antenna.
— Increase the separation between the
equipment and receiver.
— Connect the equipment into an outlet on a
circuit dierent from that to which the
receiver is connected.
— Consult the dealer or an experienced radio
TV technician for help.
QDID:
Place the System on a Flat Surface
CAUTION - Proper Installation
• Install the system in a place which is level, dry and neither too hot nor too cold. The
appropriate temperature is between 5 oC and 35 oC.
• Install the system in a location with adequate ventilation to prevent internal heat
from building up inside the unit.
• Leave sufficient distance between the system and TV.
• Keep the system away from TV to avoid interference with TV.
CAUTION - Proper Ventilation!
To avoid risk of electric shock and fire, and to prevent damage, locate the apparatus as
follows:
Front: No obstructions and open spacing.
Sides / Top / Back: No obstructions should be placed in the areas shown by the
dimensions below.
Bottom: Place on the level surface. Maintain an adequate air path for ventilation by
placing on a stand with a height of 10 cm (3-15/16") or more.
Connecting AC Adaptor
To Connect the AC Adaptor
WARNING! For optimal performance,
use only the supplied AC adaptor.
• Ensure that power supply outlet
matches with the unit AC's input
100-240V~, 50/60Hz before
connection.
AC adaptor
(Supplied)
Power Outlet
Connect one end of the AC adaptor to the
DC IN jack of the unit and the other end to
a power outlet.
Aug 17 2012 Size: 297 * 210 mm
Playing back via Bluetooth
You can listen to music from a target
Bluetooth device through the System.
Once the pairing is successful, the System
will switch the current source mode to
Bluetooth mode automatically.
NOTE:
• In order to use these functions, the
device must be compatible with AVRCP
and A2DP proles.
• Some Bluetooth devices may not be
available to the System.
Registering a Bluetooth device for the
rst time
1. Press the button to power on the
System.
2. Press the Volume down button to
turn down the volume.
3. Hold the button for more than 5
seconds. The LED indicator
blinks red
and white alternately
.
4. Perform the pairing operation on the
target Bluetooth device. For information
on operating the target Bluetooth device,
see the instruction manual for the
Bluetooth device.
Making Calls with a Bluetooth
Mobile Phone
Before you make a call with the
System, you need to pair and link
your Bluetooth-enabled phone with
the System. Please refer to
“Registering a Bluetooth device for
the first time” .
Answering a call
1. To answer a call, press the
button .
2. Speaker into the Microphone
(hidden on the behind of the
speaker grill ) and press the
Volume button to adjust the
call volume.
You can enjoy the sound from an
optional component such as a portable
digital music player through the
speakers of System. Be sure to turn off
the power of each component before
making any connections. For details, refer
to the instruction manual of the
component to be connected.
1. Set the volume level of the System to
minimum.
2. Connect an external device to the
LINE IN jack on the back of
System using a stereo mini plug cord.
3. Hold the button to power on
the System.
NOTE: The LED indicator starts
blinking slowly.
3. To end the call, press the button
again.
Dialing a call
1. Once the System is paired to a
Bluetooth mobile phone, you can
use the keypad on your phone to
dial a phone number.
2. Press the Volume button to
adjust the call volume.
3. Press the button to end the
call.
5. Select “Williams-Sonoma” from the list.
When the target device requests the
passkey during pairing operation, enter
“0000”. The pairing is completed and
the target Bluetooth device is
connected to the System automatically.
The LED indicator lights solidly.
• You can operate the target device to
pair with the System within the range
of 33 feet (10m).
• Try again above steps 3-5 if the LED
indicator starts blinking slowly after
blinking for 3 minutes.
6. Start playback of the target Bluetooth
device. The sound from the Bluetooth
device is emitted from the System.
• Playback may start automatically with
some Bluetooth devices.
NOTE: The pairing is necessary only when
connecting for the first time. If registering
other Bluetooth devices, you can repeat
the above steps 3-5.
NOTE: In this user manual, “iPod” is used as
a general reference to functions on an iPod,
iPhone or iPad, unless otherwise specified
by the text or illustrations.
The two USB ports can be used to
charge iPod devices.
The battery of the iPod is always charged
through the unit when it is connecting to a
wall outlet.
Troubleshooting
Charging an iPod/iPhone or an iPad
Charging the Built-in Battery
Technical Specification
The System has a built-in Lithium-Ion
battery to give you portable power when
not using the AC adaptor. When the
adaptor is plugged in, the unit will charge.
When operating the unit in battery mode, a
red LED indicator means the battery is
below. You must charge this unit for 12
hours before using for thefirst time.
NOTE:
• When the battery is in low, the LED
indicator lights red for 10 seconds,
and then the System is powered off .
• The battery cannot be replaced by the
user.
• It takes about 3 hours to charge the
battery from empty to full.
• Do not dispose of unit in fire; battery
may explode or leak.
Type: Lithium-Ion Rechargeable Battery
Rated Voltage: 3.7 V (* 1)
Capacity: 1200 mAh
WARNING！There is a danger of
explosion if the battery is incorrectly
replaced. Replace it only with the same or
equivalent type. Do not expose it to
excessive heat such as sunshine, fire, etc.
If you are having a problem with the System, check this list for a possible solution
before calling for service.
General
Power does not come on.
No power is supplied. Check the
power cord connection.
The System turns off automatically.
Auto power save function is
working. If the System is idle (no
operation and no sound output) for
more than 20 minutes.
No sound is heard.
The volume is set to the minimum.
iPod Operations
No sound is heard through the
System.
Disconnect the Bluetooth
connection and then the System
will restore the LINE IN mode
automatically.
Adjust the volume of the external
device.
Bluetooth Operations
No sound is heard through the
System.
The volume of the target Bluetooth
device connected to the System is
set to the minimum.
The target Bluetooth device is out of
the Bluetooth connection effective
range.
Unable to connect/operation a
Bluetooth device.
When performing a Bluetooth
connection between the System
and your target device for first
time, if the connection is not
completed, you need to disconnect
the AC power cable from the wall
outlet, wait for a while, then
connect the cable again and then
power on again to clear the target
device name. Perform a Bluetooth
connection again.
The device does not support
A2DP/AVRCP Bluetooth profile.
A2DP/AVRCP profile is necessary to
stream music data. Refer to the
instruction manual of the
Bluetooth device.
Calling Operations
Cannot hear caller’s voice.
The Bluetooth mobile phone is out
of the Bluetooth connection effect
range.
The volume of the System is too
low.
Cannot hear my voice/Voice is not
clear to listener.
You are too far from unit
microphone.
Input: AC 100-240V, 50/60Hz
Output: DC 12 V 2 A
120 mm
351 Kg
Model WSBS2000 Bluetooth Speaker
version
Prole
Output power
Input Sensitivity
Speaker
AC Adaptor
Dimensions (Diameter)
Weight
AUX Input 1100 mV
Output power 1.8 W
Bluetooth 2.1 + EDR certied
A2DP (Advanced Audio Distribution Prole),
AVRCP (Audio/Video Remote Control Profile)
Bluetooth power class 2
Bluetooth
iPod/iPhone
iPad
Location of Controls
Front Panel Back Panel
1
2
3
LED indicator
Microphone
Charging port for iPod/iPhone
7
8
9
Volume +/- buttons
Bluetooth button
Power on/Standby button
4
5
6
5
4
7
9
6
3
1
43
6
9
7
8
8
8
8
2
7
7
9
1
1
1
1
1
2
4. Start playback of the external device.
5. Adjust the volume of the System and
of the external device.
NOTE: Before enjoying music from an
external device, you need to unplug the
iPod from the System and disconnect
your Bluetooth connection.
Listening to an External Device
To audio output such
as CD/MD/digital
music player, etc.
Audio cable
(Not supplied)
Connections & Operations
